95105

ASSEMBLY AND OPERATING INSTRUCTIONS

Due to continuing improvements, actual product may differ slightly from the product described herein.

3491 MISSION OAKS BLVD., CAMARILLO, CA 93011

VISIT OUR WEB SITE AT HTTP://WWW.HARBORFREIGHT.COM

For technical questions and replacement parts, please call 1-800-444-3353

SPECIFICATIONS

Item Description

Function Inflates tires with nitrogen instead of air Power Requirement 110 VAC, 60 Hz, 234 watts Nitrogen Output 85 PSI from 3 internal tanks (50 liter total capacity) Nitrogen Input Rear connector for external tank Air Inlet Pressure 130 to 140 PSI Power Switch Toggle: On/Off Power Indicator LED Lights when Power Switch is on. Tire Inflator Pressure gauge with tire chuck hose Overall Dimensions 39-5/8 (H) x 13-3/4 (D) x 25-5/8 (W) inches;

4 inch floor clearance

Weight 174 lb.

SAVE THIS MANUAL

You will need the manual for the safety warnings and precautions, assembly instructions, operating and maintenance procedures, parts list and diagram. Keep your invoice with this manual. Write the invoice number on the inside of the front cover. Keep the manual and invoice in a safe and dry place for future reference.

GENERAL SAFETY RULES

WARNING!

READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious injury.

SAVE THESE INSTRUCTION

Work Area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite

accidents.

2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children, and visitors away while operating a power tool.

Distractions can cause you to lose control. Protect others in the work area from debris such as chips and sparks. Provide barriers or shields as needed.

SKU 95105

For technical questions, please call 1-800-444-3353

Page 2

Electrical Safety

4. Avoid body contact with grounded surfaces such as pipes, radiators, ranges, and refrigerators. There is an increased risk of electric shock if your body is

grounded.

5. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

6. Grounded tools must be plugged into an outlet properly installed and grounded

in accordance with all codes and ordinances. Never remove the grounding prong or modify the plug in any way. Do not use any adapter plugs. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. If the tools should electrically malfunction or break down, grounding

provides a low resistance path to carry electricity away from the user.

7. Double insulated tools are equipped with a polarized plug (one blade is wider

than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized outlet. Do not change the plug in any way. Double insulation

cord and grounded power supply system.

eliminates the need for the three wire grounded power

8. Do not abuse the Power Cord. Never use the Power Cord to the Plug from an

outlet. Keep the Power Cord away from heat, oil, sharp edges, or moving parts. Replace damaged Power Cords immediately. Damaged Power Cords increase the

risk of electric shock.

9. When operating a power tool outside, use an outdoor extension cord marked “W-A” or “W”. These extension cords are rated for outdoor use, and reduce the risk of electric shock.

Personal Safety

10. Stay alert. Watch what you are doing, and use common sense when operating a power tool. Do not use a power tool while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may

result in serious personal injury.

11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.

12. Avoid accidental starting. Be sure the Power Switch is off before plugging in. Plugging in power tools with the Power Switch on, invites accidents.

13. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enables better control of the power tool in unexpected situations.

14. Use safety equipment. Always wear eye protection. Dust mask, nonskid safety shoes, hard hat, or hearing protection must be used for appropriate conditions.

SKU 95105

For technical questions, please call 1-800-444-3353

Page 3

Tool Use and Care

15. Do not force the tool. Use the correct tool for your application. The correct tool will do the job better and safer at the rate for which it is designed.

16. Do not use the power tool if the Power Switch does not turn it on or off. Any tool that cannot be controlled with the Power Switch is dangerous and must be replaced.

17. Disconnect the Power Cord Plug from the power source before making any adjustments, changing accessories, or storing the tool. Such preventive safety measures reduce the risk of starting the tool accidentally.

18. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the hands of untrained users.

19. Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained tools with a sharp cutting edge are less likely to bind and are easier to control. Do not use a damaged tool. Tag damaged tools “Do not use” until repaired.

20. Check for misalignment or binding of moving parts, breakage of parts, and any

other condition that may affect the tool’s operation. If damaged, have the tool serviced before using. Many accidents are caused by poorly maintained tools.

21. Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for one tool may become hazardous when

used on another tool.

Service

22. Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury.

23. When servicing a tool, use only identical replacement parts. Follow

instructions in the manual. Use of unauthorized parts or failure to follow maintenance instructions may

create a risk of electric shock or injury.

“Inspection, Maintenance, And Cleaning”

section of this

SPECIFIC SAFETY RULES FOR THIS PRODUCT

1. Maintain labels and nameplates on the Nitrogen Generator and Inflater. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replacement.

2. Always wear ANSI-approved safety impact eye goggles and heavy work gloves when using the Nitrogen Generator and Inflater. Using personal safety devices reduce the risk for injury. Safety impact eye goggles and heavy work gloves are available from Harbor Freight Tools.

3. Maintain a safe working environment. Keep the work area well lit. Make sure there is adequate surrounding workspace. Always keep the work area free of obstructions, grease, oil, trash, and other debris. Do not use a power tool in areas near flammable chemicals, dusts, and vapors. Do not use this product in a damp or wet location.

SKU 95105

For technical questions, please call 1-800-444-3353

Page 4

4. Avoid unintentional starting. Make sure you are prepared to begin work before turning on the Nitrogen Generator and Inflater.

5. Do not force the Nitrogen Generator and Inflater. This tool will do the work better and safer at the speed and capacity for which it was designed.

6. Always unplug the Nitrogen Generator and Inflater from its electrical outlet

before performing any inspection, maintenance, or cleaning procedures.

7. Never leave the Nitrogen Generator and Inflater unattended while running. Turn power off if you have to leave the Nitrogen Generator and Inflater.

8. Before each use, check all nuts, bolts, and hose connections for tightness. Vibration during mixing may cause these to loosen.

9. Keep extension cord off the ground and away from water.

10. Always connect the Line Cord to a Ground Fault Circuit Interrupter (GFCI) protected electrical outlet.

11. Install this product on a proper surface. Locate on a flat, level, and solid surface that is capable of supporting the weight of the Nitrogen Generator and Inflater.

GROUNDING

WARNING!

Improperly connecting the grounding wire can result in the risk of electric shock. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify the power cord plug provided with the tool or product. Never remove the grounding prong from the plug. Do not use the tool if the power cord or plug is damaged. If damaged, have it repaired by a service facility before use. If the plug will not fit the outlet, have a proper outlet installed by a qualified electrician.

Grounded Tools with Three Prong Plugs

1. This product comes with a three prong plug. Tools marked with “Grounding Required” have a three wire cord and three prong grounding plug. The plug must be connected to a properly grounded outlet. If the tool should electrically malfunction or break down, grounding provides a low resistance path to carry electricity away from the user, reducing the risk of electric shock. (See Figure A.)

2. The grounding prong in the plug is connected through the green wire inside the cord to the grounding system in the tool. The green wire in the cord must be the only wire connected to the tool’s grounding system and must never be attached to an electrically “live” terminal. (See Figure A.)

(1)

3. Your tool must be plugged into an appropriate outlet, properly installed and grounded in accordance with all codes and ordinances. The plug and outlet should look like those in the following illustration. (See Figure A.)

SKU 95105

For technical questions, please call 1-800-444-3353

Page 5
