Harbor Freight Tools 95058 User Manual

Mini Convex HID Fog Lights

®

95058

INSTALLATION AND OPERATION INSTRUCTIONS

Due to continuing improvements, actual product may differ slightly from the product described herein.

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our website at: http://www.harborfreight.com

TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND

ALL WARNINGS AND INSTRUCTIONS BEFORE USE.

Copyright© 2007 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.

For technical questions or replacement parts, please call 1-800-444-3353.

Construction

Specifications

High Impact Plastic Body with
Tempered Glass Lens, Aluminum
Starter Box

Power Requirement

Bulb Color

Bulb Type

Total Weight

Light Dimensions

12 VDC, 3A (both lights),

5A fuse (included)

Blue

H3 6000K

1.6 lb.

3-7/8” D x 3-1/4” W x 3” H

Save This Manual

You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this manual.
Write the invoice number on the inside of the front cover. Keep the manual and invoice in a safe
and dry place for future reference.

Safety Warnings and Precautions

WARNING: When using equipment, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.

Read all instructions before installing or using!

1.

Keep your work area clean and well lit. Cluttered benches and dark areas invite ac-

cidents.

2.

3.

4.

5.

6.

7.

Do not operate automotive accessories in explosive atmospheres, such as in the

presence of flammable liquids, gases, or dust. Batteries and automotive accessories

may create sparks which may ignite the dust or fumes.

Keep bystanders, children, and visitors away from the installation area. Distractions

can cause you to lose control. Protect others in the work area from debris such as corro-

sion materials and sparks. Provide barriers or shields as needed.

Do not abuse the Power Cord. Never use the Power Cord to carry the lights. Keep

the Power Cord away from heat, oil, sharp edges, or moving parts. Replace damaged

Power Cords immediately. Damaged Power Cords increase the risk of fire.

Stay alert. Watch what you are doing, and use common sense when operating a

automotive accessory. Do not use a automotive accessory while tired or under the

influence of drugs, alcohol, or medication. A moment of inattention while operating a

automotive accessory may result in serious personal injury.

Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your

hair, clothing, and gloves away from moving engine parts. Loose clothes, jewelry, or

long hair can be caught in moving engine parts.

Use safety equipment. Always wear eye protection. Dust mask, nonskid safety shoes,

hard hat, or hearing protection must be used for appropriate conditions. ANSI-approved

goggles and heavy work gloves should be worn during installation.

SKU 95058 For technical questions, please call 1-800-444-3353 Page 2

8.

Use only with vehicles with 12 volt DC electrical systems.

9.

10.

11.

12.

13.

14.

15.

16.

Use bolts and included fasteners to properly secure and support the fog lights to a

stable platform. This automotive accessory is designed to be installed to a firm structure

near the vehicle front grill or bumper.

Turn vehicle ignition off before making cable connections. Vehicle’s engine must be

cooled down before making cable connections.

Disconnect the battery cable before installing lights or changing bulbs. Such preven-

tive safety measures reduce the risk of accident.

Keep automotive accessory maintained and clean. Do not use a damaged automotive

accessory. Tag damaged automotive accessories “Do not use” until repaired.

Use only accessories that are recommended by the manufacturer for your model.

Accessories that may be suitable for one item may become hazardous when used on

another item.

Avoid contact with Battery Acid. If splashed, immediately wash affected area with clean

water and baking soda for at least 15 minutes. If irritation persists get medical help im-

mediately.

Connect Fog Lights cables to proper polarities. Connect black cable to the negative

battery terminal, and the red cable to the positive battery terminal (for a negative grounded

system). Failure to do so could result in sparks, possible fire and severe personal injury.

Keep cables clear of fan blades, belts, pulleys, and other moving parts of the engine

that may cause injury, or damage to the Fog Lights.

17.

18.

19.

20.

21.

22.

23.

24.

25.

26.

Do not allow the Black and Red battery cables or terminals to touch. Failure to adhere

to these directions could result in severe personal injury. If this happens, sparks will occur

that can melt connection lugs, or other metal objects, and create the potential for fire.

Disconnect the positive battery cable of the vehicle before connecting fog lights.

These lights are not DOT approved for use on public roads. Always follow all local,

state and federal regulations regarding installation and use of these lights.

Read all instructions and warnings on any battery or automotive electrical systems

before working on vehicle.

Do not expose the battery or bare wires, switches or connections to rain or wet

conditions.

To avoid damage of cable and plug, never pull the cable to disconnect the Fog

Lights.

Always unplug the Fog Lights from their electrical connection and allow to cool com-

pletely before performing any inspection, maintenance, or cleaning procedures.

Repairs should be carried out only by a qualified technician.

An appropriate in-line switch and fuse are essential to help prevent fire in the event

of a short circuit. These components are not included in this kit and will need to be pro-

vided by the customer.

WARNING: This product contains or, when used, produces a chemical known to the

State of California to cause cancer and birth defects or other reproductive harm.

(California Health & Safety Code § 25249.5, et seq.)

SKU 95058 For technical questions, please call 1-800-444-3353 Page 3
