or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling, and all other
information provided with this product:
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Installation Precautions
1. Exercise special caution if working on roof
or another high location. Keep proper footing
and balance at all times. Follow ladder supplier’s
precautions whenever working near or on a ladder.
2. Install all sensitive electrical components
(including wiring connections, regulator,
and battery) inside a weatherproof
enclosure to prevent electric shock.
3. Do not wire multiple panels in series. If you
need to connect two or more solar panels together,
this work must be done by a qualied electrician
unless they are connected through a regulator.
DANGER indicates a hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION, used with the safety alert symbol,
indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE is used to address practices
not related to personal injury.
CAUTION, without the safety alert symbol, is used
to address practices not related to personal injury.
WARNING Read all safety warnings and
instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/
or serious injury.
Save all warnings and instructions for
future reference. The warnings, precautions,
and instructions discussed in this instruction
manual cannot cover all possible conditions and
situations that may occur. It must be understood
by the operator that common sense and caution
are factors which cannot be built into this
product, but must be supplied by the operator.
4. This solar panel kit is not designed for tie-in to a
grid. Only a licensed electrician and a licensed
building contractor can safely design and implement
a grid tie-in system. Any grid tie-in system must
meet all applicable building and electrical codes,
and must meet standards established by the area
power company. Improper grid tie-in can result in
electrocution, re, and other serious personal injury
and property damage. An incorrectly installed grid
tie-in system can cause feedback voltage, resulting
in electrocution of electrical utility workers.
5. Do not stand on or otherwise
apply pressure to panel.
6. Handle solar panel with care,
edges may be sharp.
7. Do not focus light on panel.
8. Install components with enough
space to allow proper cooling.
9. This product may occasionally produce more
current and/or voltage than its rated output.
Increase output ratings by 25% when determining
component required voltage and amperage
ratings. Refer to Section 690-8 of the National
Electrical Code for an additional multiplying factor of
125 percent (80 percent derating) which may apply.
10. Panel must be connected using UL listed outdoor
rated wire of the correct thickness (gauge) for the
amperage rating and length (see warning number
9 also). Follow the guidelines in the chart below:
Current
in Amps
0-5 18
6-7 1816
8 1816
10
11-12 1614
15
18
22-24 12
30
40
50 14
100 121064
150 108
200 86
Maximum Length
5' 10' 15'20' 25'
16
18
1412
181620 1412
16
14 10
12108
42
10
Minimum Wire Gauge
11. Install an appropriate charge controller/regulator
to regulate output and prevent damage. Do not
attach panel to battery or power grid without proper
regulator, inverter, and/or charge controller.
12. Install and use according to applicable
National Electrical Code (NEC) standards.
13. This panel is not rated for use as re-resistant
roong. If installing on a roof, install only over a re
resistant roof covering rated for the application.
14. Verify that installation surface has no hidden
utility lines before drilling or driving screws.
15. Install only according to these instructions.
Improper installation can create hazards.
Battery Precautions
1. Wear splash-resistant ANSI-approved
safety goggles and electrically insulated
gloves while working near batteries.
2. Use an appropriate charge controller
whenever connected to battery.
3. Charge, store, and maintain batteries
according to supplier’s instructions.
Service Precautions
1. Before service, maintenance, or cleaning:
a. Dry solar panels and outdoor
wiring thoroughly while wearing
electrically insulated gloves.
b. Cover all solar panels with an opaque
cover, such as a blanket.
c. Disconnect all solar panels.
d. Disconnect all batteries.
2. Do not service during rain, fog, or
any other wet/humid weather.
3. Do not stand on or otherwise
apply pressure to panel.
4. Do not allow children to play with or near
this item or electrical components.
5. Inspect at least monthly; do not use if damaged,
parts are loose, water is found inside the
housing, electrical insulation is cracked or
damaged, or connections are loose.
6. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact Harbor
Freight Tools for a replacement.
16. Wear ANSI-approved safety goggles and heavyduty work gloves during installation. Do not
wear jewelry or metal watches when working
near solar panels, wiring or batteries.
17. Handle panel with care. Glass may break or a
sharp edge may be exposed during movement.
18. Keep installation area clean and well lit.
19. Install out of reach of children.
20. Keep bystanders out of the area during installation.
21. Do not install when tired or when under
the inuence of drugs or medication.
22. Use in 12 VDC systems only.
7. WARNING: Handling the cord on this product will
expose you to lead, a chemical known to the State
of California to cause cancer, and birth defects or
other reproductive harm. Wash hands after handling.
(California Health & Safety Code § 25249.5, et seq.)
Rated Output14.5 V~ / 15 W (per solar panel)
Open Circuit Voltage23.5 OCV
Adapter Outlets3,6 and 12 VDC
Note: Output will decrease as the panel gets hotter
than room temperature (~70° F). Angle, solar intensity,
cloud cover and other factors will effect output.
Installation
IMPORTANT! Read the ENTIRE IMPORTANT
SAFETY INFORMATION section at the beginning of
this manual including all text under subheadings
therein before set up or use of this product:
Note: For additional information regarding the
parts listed in the following pages, refer to the
Assembly Diagram near the end of this manual.
Location
1. Locate the Solar Panels (14) where they will
receive full, unobstructed sunlight, especially during
midday. Nearby trees or tall plants will drop debris,
requiring the panels to be cleaned more frequently.
2. The setup location for the Solar Panel Kit must
be inaccessible to children to prevent electric
shock. Build a childproof enclosure if needed.
3. Install the charge controller/regulator and batteries
in a weatherproof enclosure with proper ventilation.
Mounting
1. First, attach all the components of the
frame together. See Figure 1, below.
NOTE: Do not fasten connections with hardware yet.
Mounting
Holes
Mounting
Holes
Figure 1
IMPORTANT: During assembly, make sure that
the solar panel mounting holes along the Top
Tubes (2) and Bottom Tubes (8) face OUT from
the frame assembly. See Figure 1, above.
2. Attach Corner Connectors (1) to Side Tubes (6).
Then use the Fixed Screws (9) and Nuts (10) to
fasten the Corner Connectors to the Top Tube.
See Figure 2, below.
Fixed Screw (9)
Top Tube (2)
Nut (10)
1. Select a mounting location for the Solar Panel
Kit. The Solar Panels should face the Sun, and
not be blocked by shadows. The location should
allow the Panels to be protected from accidental
damage. The location should be at, stable and
able to support the weight of the Solar Panel Kit’s
accessories. Before assembly, be sure that all
accessory cables reach their connection points
without placing any stress on the wiring.
2. Angle face of Solar Panel Frame toward true
south1 according to chart that follows:
Latitude Solar Panel Angle
0-4° 10°
5-20° Latitude + 5°
21-45° Latitude + 10°
46-64° Latitude + 15°
3. Use Fixed Screws and Nuts to fasten the Top Tubes
to the Leg Connectors (3) and then the Support Legs
(7) to Leg Connectors. See Figure 3, following.
Corner
Connector (1)
Side Tube (6)
Figure 2
