Harbor Freight Tools 32916 User Manual

ENGINE STAND
1000 LBS. CAPACITY
32916
ASSEMBLY AND OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
Copyright © 2003 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353
Specifications
Engine Stand Capacity 1000 Lbs. Dead Weight Assembled Dimensions 36” L x 31” W x 34-3/4” H Face Plate Size 7/16” Th. x 10-3/16 “W x 6”H Weight 58 Lbs. Rotation 360
o
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions, operating and maintenance procedures, parts list and diagram. Keep your invoice with this manual. Write the invoice number on the inside of the front cover. Keep the manual and invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using the Stand, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this Stand!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Don’t expose to rain. Keep work area well lighted.
3. Keep children away. Children must never be allowed in the work area. Do not let them handle, ride on, or be in close proximity of the Stand.
4. Store idle equipment. When not in use, the Stand must be stored in a dry location to inhibit rust. Always keep the Stand out of reach of children.
5. Use the right tool for the job. Do not attempt to force a small Stand to do the work of a larger industrial Stand. There are certain applications for which this Stand was designed. It will do the job better and more safely at the rate for which it was intended. Do not modify this Stand and do not use this Stand for a purpose for which it was not intended.
6. Dress properly. Do not wear loose clothing or jewelry as they can be caught in moving parts. Protective, electrically non-conductive clothes and non-skid footwear are recommended when working. Wear restrictive hair covering to contain long hair.
7. Use eye protection. Always wear ANSI approved impact safety goggles.
8. Do not overreach. Keep proper footing and balance at all times. Do not reach over or across running machines.
9. Maintain products with care. Keep the Stand clean for better and safer performance. Follow instructions for lubricating and changing accessories. The handle must be kept clean, dry, and free from oil and grease at all times.
Page 2SKU 32916
10. Stay alert. Watch what you are doing, use common sense. Do not operate the Stand when you are tired.
11. Check for damaged parts. Before using any product, any part that appears damaged should be carefully checked to determine that it will operate properly and perform its intended function. Check for alignment and binding of moving parts; any broken parts or mounting fixtures; and any other condition that may affect proper operation. Any part that is damaged should be properly repaired or replaced by a qualified technician.
12. Guard against electric shock. Prevent body contact with grounded surfaces such as pipes, radiators, ranges, and refrigerator enclosures.
13. Replacement parts and accessories. When servicing, use only identical replacement parts. Use of any other parts will void the warranty. Only use accessories intended for use with this tool. Approved accessories are available from Harbor Freight Tools.
14. Do not operate product if under the influence of alcohol or drugs. Read warning labels if taking prescription medicine to determine if your judgment or reflexes are impaired while taking drugs. If there is any doubt, do not operate the product.
15. Maintenance. For your safety, service and maintenance should be performed regularly by a qualified technician.
16. Stand movement. Do not attempt to move the Stand when under load. The Caster (#13) and the Wheels (#11) are not designed to be rolled when the Engine Stand is supporting a heavy weight.
17. Stay Clear of Stand. Never go under an object being held by the Stand. It is possible for the object to slip and fall, resulting in serious injury.
18. Do not pinch fingers or hands. Be careful not to pinch fingers and hands when adjusting and using the Engine stand.
Caution: Always stand behind the main upright Post (#3) when the Stand is in
use, not to the side; use both hands on the Handle (#2).
Warning: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be under­stood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator.
Unpacking
When unpacking, check to make sure the parts listed on page 6 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual as soon as possible.
Page 3SKU 32916
Assembly
Refer to the Assembly Drawing on page 6 and the pictures below and on the cover.
1. Insert the Middle Beam (#17) into the bottom of the Post (#3). Line up the hole in the
middle of the Rear Beam (#6) with the hole on the bottom of the Middle Beam (#17) and use a Bolt (#9) and a Washer (#24) to secure both the Middle Beam (#17) and the Rear
Beam (#6) to the Post (#3). See FIGURE 1 and the Assembly Drawing on page 6.
FIGURE 1
Rear Beam (#6)
Bolt (#9) enters from underneath (not shown)
2. Attach the four Holders (#20)
to the Plate (#21) with Bolts (#18), Washers (#19), and Nuts (#22). See FIGURE 2 and the Assembly Drawing on page 6.
3. Insert the Plate (#21) assembly
into the tube on top of the Post (#3) and secure it with the Pin (#1).
4. Put the Handle Sleeve (#4) on
the Handle (#2) and secure it to the Handle (#2) on the Post (#3) with the Split Pin (#25). See FIGURE 2 and the Assembly Drawing on page 6.
Post (#3)
Pin (#1)
Handle (#2)
Split Pin (#25)
Nut (#22)
Washer (#19)
Plate (#21)
Tube
Middle Beam (#17)
Bracket
Front Cross Beam (#16)
FIGURE 2
Bolt (#18)
Holder (#20)
5. Attach the Front Cross Beam (#16) under the Bracket, to the Middle Beam (#17) using
Bolts (#5), Washers (#7), and Nuts (#8). See FIGURE 1 and the Assembly Drawing.
6. Attach the Caster (#13) plate to the metal tabs on the Front Cross Beam (#16) using four
Bolts (#23), Washers (#26), Spring Washers (#14) and Nuts (#15). Repeat with the other Caster (#13). See the Assembly Drawing on page 6. Note: After assembly, test if the Stand rolls properly, if the hardware is secure, and practice
using the Handle (#2) and rotating the Plate (#21). Check it for cracks, bends in the metal, or signs of unusual wear. If any are found, do not use the Stand. Take it to an authorized technician for service or repair.
Page 4SKU 32916
Operation
Additional Warnings! Do not exceed the maximum capacity of 1000 Lbs..
1. Always use the Engine Stand on a dry, flat, level surface.
2. Never work directly under a suspended engine.
3. Do not attempt to move the Stand when under load. The Caster (#13) is not designed to
be rolled when the Stand is supporting a heavy weight. If you need to move the engine, you must transfer it to an approved, appropriate moving device such as an engine hoist.
4. Make sure the stand is stable. Before using the stand, check it for cracks, bends in the
metal, or signs of unusual wear. If any are found, do not use the Stand. Take it to an authorized technician for service or repair.
5. Do not attempt to remove an engine from a vehicle using this device. Use an engine hoist
(not included). Read all the safety warnings and instructions that came with the engine hoist.
6. Be careful not to pinch fingers and hands when adjusting and using the Engine stand.
Using the Engine Stand
1. Follow instructions in the vehicle’s manual to determine the diameter and length of the bolts
(not included) needed to connect your engine block to the four Holders (#20). Make sure you use bolts that are long enough to fit through the Holders (#20) and thread as deeply as possible into the engine block. Place the bolts (not included) through the rear of the Holders (#20) (closest to the Post (#3)) and securely tighten them into the engine block. The head of the bolts must be flush with the rear of the Holders (#20).
2. Bring the engine on a hoist in close proximity to the Plate (#21), so you can adjust the
Plate (#21) to properly fit and support the engine block. Remove the Pin (#1) and use both hands on the Handle (#2) to turn the Plate (#21) to the desired angle; always stand behind the Engine stand when adjusting the Plate (#21). Replace the Pin (#1). Secure one of the
Nuts (#22) on the rear of the Plate (#21) while loosening a Bolt (#18). Do not remove the Bolt (#18), just loosen it enough to move the Holder (#20) into position. Repeat on the other
three Holders (#20) until they are in position to match up with the mounting bolts (not in­cluded) coming from the engine block. Tighten the Bolts (#18) securely to the Plate (#21).
3. Attach the engine to the Stand after properly aligning the mounting bolts (not included).
Note: Use all four Holders (#20) when attaching an engine to the Stand.
4. When finished working on the engine, follow the the safety warnings and instructions that
came with the engine hoist to safely remove the engine from the Stand.
Maintenance
1. Keep Engine Stand clean and free of dirt or grease.
2. Periodically check that hardware is securely fastened.
3. Check that the Caster (#13) and the Wheels (#11) are clean and turn properly.
Page 5SKU 32916
Parts ListAssembly Drawing
Part No. Description Qty. 1Pin 1 2 Handle 1 3 Post 1 4 Handle Sleeve 1 5 Bolt M10x70 2 6 Rear Beam 1 7 Washer (10) 2 8 Nut M10 2 9 Bolt M12x80 1 10 Washer (14) 2 11 Wheels 2 12 Fixed Ring (14) 2 13 Caster 2 14 Spring Washer (8) 8 15 Nut M8 8 16 Front Cross Beam 1 17 Middle Beam 1 18 Bolt M12x45 4 19 Washer (12) 4 20 Holders 4 21 Plate 1 22 Nut M12 4 23 Bolt M8x20 8 24 Spring Washer (12) 1 25 Split Pin 1 26 Washer (8) 8
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBU­TOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts.
Page 6SKU 32916
