NETWORK CAMERA

User Manual

SNP-6230RH

Network Camera

User Manual

Copyright

©2015 Hanwha Techwin Co., Ltd. All rights reserved.

Trademark

Each of trad emarks herein is re gistered. The nam e of this product and o ther trademark s mentioned in this m anual are
the registe red trademark of th eir respective c ompany.

Restriction

Copyrigh t of this document is r eserved. Unde r no circumstanc es, this document sh all be reproduce d, distributed or
changed, partially or wholly, without formal authorization.

Disclaimer

Samsung makes the bes t to verify the inte grity and corr ectness of the co ntents in this docu ment, but no formal
guarantee s hall be provided. U se of this document a nd the subsequent r esults shall be ent irely on the user’s ow n
responsibility. Samsung reserves the righ t to change the conte nts of this documen t without prior n otice.

Design and specifications are subject to change without prior notice.

The initi al administra tor ID is “admin” a nd the passwor d should be set wh en logging in for t he first time.

Please ch ange your pass word every thr ee months to saf ely protect p ersonal inf ormation and t o prevent
the damage of the information theft.
Please, t ake note that it ’s a user’s respo nsibility fo r the securit y and any other pr oblems cause d by
mismanaging a password.

overview

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/ accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by

the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for

long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. This product is intended to be supplied by Power Unit marked “Class 2” or “LPS” and

rated 24 Vac, 6 A.

● OVERVIEW

English _3

overview

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC
OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS
ON THE EQUIPMENT.

Apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus.

To prevent injury, this apparatus must be securely attached to the Wall/ceiling
in accordance with the installation instructions.

CAUTION

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the product.

4_ overview

Battery

Batteries(battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.

CAUTION

Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.

These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock do not perform any servicing other than
that contained in the operating instructions unless you are qualified to do so.

The CVBS out terminal of the product is provided for easier installation, and is
not recommended for monitoring purposes.

Please use the input power with just one camera and other devices must not
be connected.

The ITE is to be connected only to PoE networks without routing to the
outside plant.

● OVERVIEW

English _5

overview

Please read the following recommend safety precautions carefully.

yDo not place this apparatus on an uneven surface.
yDo not place this apparatus near conductive material.
yDo not attempt to service this apparatus yourself.
yDo not install near any magnetic sources.
yDo not block any ventilation openings.
yDo not place heavy items on the product.
yDo not expose the camera to radioactivity.

User’s Manual is a guidance book for how to use the products.
The meaning of the symbols are shown below.

yReference : In case of providing information for helping of product’s usages
yNotice : If there’s any possibility to occur any damages for the goods and

human caused by not following the instruction



Please read this manual for the safety before using of goods and keep it in

the safe place.

6_ overview

CONTENTS

OVERVIEW

3

INSTALLATION &

CONNECTION

16

NETWORK CONNECTION

AND SETUP

31

3 Important Safety Instructions
9 Product Features
10 Recomended PC Specifications
11 Recomended SD/SDHC/SDXC

Memory Card Specifications

11 NAS recommended specs
12 What’s Included
13 At a Glance

18 Connecting with other Device
20 Installation
28 Inserting/Removing a SD Memory

Card

30 Memory Card Information

(Not Included)

31 Connecting the Camera Directly

to Local Area Networking

32 Connecting the Camera Directly

to a DHCP Based DSL/Cable
Modem

33 Connecting the Camera Directly

to a PPPoE Modem

34 Connecting the Camera to a

Broadband Router with the
PPPoE/Cable Modem

35 Buttons used in IP Installer
36 Static IP Setup
40 Dynamic IP Setup
41

Port Range Forward (Port Mapping)
Setup

43 Connecting to the Camera from a

Shared Local PC

43 Connecting to the Camera from a

Remote PC via the Internet

● OVERVIEW

English _7

overview

WEB VIEWER

44

SETUP SCREEN

61

APPENDIX

137

44 Connecting to the Camera
45 Password setting
46 Login
47 Installing STW WebViewer Plugin
49 Using the Live Screen
54 Playing the recorded video

61 Setup
61 Basic Setup
71 PTZ setup
84 Video & Audio setup
98 Network Setup
107 Event Setup
112 NAS (Network Attached Storage)

guide

130 System Setup
136 Viewing profile information

137 DIP Switch Setting
139 Camera Wiring
140 Specification
145 Product Overview
146 Troubleshooting
148 Open Source Announcement

8_ overview

PRODUCT FEATURES

• Full HD Video Quality

• Multi-Streaming

This network camera can display videos in different resolutions and qualities
simultaneously using different CODECs.

• Web Browser-based Monitoring

Using the Internet web browser to display the image in a local network environment.

• Alarm

If an event occurs, the camera sends the relevant videos to the e-mail address or the FTP
server registered by the user, saves them in an SD card or NAS, or sends the signal to the
alarm output terminal.

• Tampering Detection

Detects tempering attempts on video monitoring.

• Motion Detection

Detects motion from the camera’s video input.

• Intelligent Video Analysis

Analyzes video to detect logical events of specified conditions from the camera’s video
input.

• Face Detection

Detects faces from the camera’s video input.

• Audio Detection

Detects sound louder than a certain level specified by user.

• Auto Detection of Disconnected Network

Detects network disconnection before triggering an event.

• ONVIF Compliance

This product supports ONVIF Profile-S.
For more information, refer to www.onvif.org.

● OVERVIEW

English _9

overview

RECOMENDED PC SPECIFICATIONS

• CPU : Intel Core 2 Duo 2.6 GHz or higher (for using 1920x1080 30 fps)
Intel Core i7 2.8 GHz or higher (for using 1920x1080 60 fps)

Web Plug-in is optimized to SSE 4.1 Instruction Set.

`

• Resolution : 1280X1024 pixels or higher (32 bit color)

• RAM : 2GB or higher

• Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7

• Supported Browser : Microsoft Internet Explorer (Ver. 8~11),

Mozilla Firefox (Ver. 9~19), Google Chrome (Ver. 15~25),
Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) *Mac OS X Only

Windows 8 is supported only in the Desktop mode.

`

Neither a beta test version unlike the version released in the company website nor the developer version will

`

be supported.
It is recommended to connect to IPv6 in Windows 7.

`

The camera does not support Internet Explorer Compatability View settings.

`

For Mac OS X, only the Safari browser is supported.

`

• Video Memory : 256MB or higher

If the driver of the video graphic adapter is not installed properly or is not the latest version, the

`

J

video may not be played properly.

For a multi-monitoring system involving at least 2 monitors, the playback performance can be

`

deteriorated depending on the system.

It is advisable to use Intel Core 2 Duo 2.93GHz or higher in a multi-browser environment.

`

10_ overview

RECOMENDED SD/SDHC/SDXC MEMORY CARD
SPECIFICATIONS

• Recommended capacity : 4GB ~ 64GB

• For your camera, we recommend you use a memory card from the following
manufacturers:
SD/SDHC/SDXC Memory Card : Sandisk, Transcend

• For the framerate below 30 fps, it is recommended to use the specification memory card
of Class 6 or higher.

• For the framerate over 31 fps, it is recommended to use the specification memory card of
Class 10 UHS or higher.

NAS RECOMMENDED SPECS

• Recommended capacity : 200GB or higher is recommended.

• Simultaneous access : One unit of NAS can accept a maximum of sixteen camera
accesses.

• For this camera, you are recommended to use a NAS with the following manufacturer’s
specs.

Recommended products Available sizes

Netgear NAS A maximum of 16 cameras can access simultaneously.

Synology NAS A maximum of 16 cameras can access simultaneously.

When you use Netgear’s NAS equipment, do not allocate the capacity for use.

`

J

If you use NAS equipment for purposes other than video saving, the number of accessible

`

cameras may be reduced.

● OVERVIEW

English _11

overview

WHAT’S INCLUDED

Please check if your camera and accessories are all included in the product package.

Appearance Item Name Quantity Description

Main Body 1

12_ overview

Instruction book,
Installer S/W CD

Quick Guide

(Optional)

Warranty card

(Optional)

Cable for the testing monitor 1

Hexagon screw 3

L Wrench 1

Installation base 1 Bracket for mounting outdoors

Waterproofing accessory 1 Install and use where there is high humidity.

1

1

1

Used to test the camera connection to a

portable display device

Used for attaching the installation base to

the camera

Used for fixing the installation base after

attaching it to the camera

AT A GLANCE

Appearance

● OVERVIEW

a

b

Item Description

Main unit

a

Shield cover Shield cover for the lens and unit protection.

b

Safety Cable The cable prevents the product from dropping during installation.

c

Protects the internal PTZ mechanism from the direct sunlight, rain or
external impact.

c

English _13

overview

Inside

c

d
e

Item Description

SD Memory Card

a

Compartment

Initialization Switch

b

a b

Compartment for the SD memory card.

MRefer to <Inserting/Removing a SD Memory Card> for the SD

memory card insertion position. (page 28)

The camera is reset to factory initialization condition.

For details, refer to <Upgrade / Reboot>. (page 131)

M

`

Refer to <Inserting/Removing a SD Memory Card> for the

`

switch position. (page 28)

Illumination Sensor Detects incoming light to control the IR LED.

c

IR LED These infrared LED’s are controlled by the illumination sensor.

d

Lens Lens for the camera.

e

14_ overview

Bottom View of Installation

Inner View of Installation Base

Base

Item Description

Communications

a

and AUX Ports

Audio Input Port Used to connect the audio input cable.

b

Audio Output Port Used to connect the audio output cable.

c

Video Out Port Analog video output port. (for installation)

d

Communications

e

Setup Switch

Network

f

Connections

Power Port Used to connect the power.

g

Used for RS-485/422 communications.

Communication method and terminal value are set up.

Used to connect the LAN cable. (10/100Mbps supported)

g

fed h

ON DIP

Video Out

Power

AC 22~26V

D+ D- TXD+

D+ D- TXD+

AUDIO_OUTAUDIO_IN

TXD-

TXD­ GND

GND

A.COM

A.COM

A.NO

A.NO

AXICOM

IMO3

5VDC

AXICOM

AUDIO_OUTAUDIO_IN

1143Н

1143Н

1143Н

AXICOM

IMO3

5VDC

AXICOM

IMO3

5VDC

AXICOM

IMO3

5VDC

AXICOM

IMO3

5VDC

IMO3

5VDC

Alarm2 ONAlarm1 ON

Alarm2 ON

Alarm1 ON

a b c

2N.C

2N.0

COM2

1N.C

1N.0

COM1

GND

IN4
IN3

GND

IN2

IN1 IN2 GND IN3 IN4 GND 1C0M 1.N0 1.NC 2C0M 2.N0 2.NC

IN1 IN2 GND IN3 IN4 GND 1C0M 1.N0 1.NC 2C0M 2.N0 2.NC

IN1

Alarm

● OVERVIEW

Alarm I/O Port Used to connect the alarm I/O cable.

h

English _15

installation & connection

`Camera Wiring Interface Board

For the camera wiring, please refer to the picture below.

Power Supply

AC24V 6A

Video

Output

ON DIP

Video Out

D+ D- TXD+

D+ D- TXD+

TXD-

TXD­ GND

GND

A.COM

A.COM

A.NO

A.NO

1143Н

1143Н

AXICOM

IMO3

AXICOM

IMO3

5VDC

AXICOM

IMO3

AXICOM

IMO3

5VDC

Alarm1 ON

ETHERNET

Communications and AUX

D+ D- TXD+ TXD- GND

Refer to Control Signal

Connection Diagram

5VDC

5VDC

Power

AC 22~26V

AUDIO_OUTAUDIO_IN

AUDIO_OUTAUDIO_IN

AXICOM

IMO3

5VDC

AXICOM

Alarm2 ONAlarm1 ON

Alarm2 ON

Audio IN

1143Н

IMO3

5VDC

A.COM

A.NO

Alarm

2N.C

2N.0

COM2

1N.C

1N.0

COM1

GND

IN4
IN3

GND

IN2

IN1 IN2 GND IN3 IN4 GND 1C0M 1.N0 1.NC 2C0M 2.N0 2.NC

IN1 IN2 GND IN3 IN4 GND 1C0M 1.N0 1.NC 2C0M 2.N0 2.NC

IN1

Alarm

Audio OUT

Power Input
Ground

Alarm output

Alarm Input

AUX Output

16_ installation & connection

The maximum power capacity of the alarm and AUX outputs is 30VDC/2A, 125VAC/0.5A, and

`

J

250VAC/0.25A.

When connecting alarm input and output cables, be sure to connect one cable to each terminal

`

respectively.

To connect products over the camera’s capacity, please use an additional relay device.

`

Connecting the power connector and GND incorrectly to the alarm out port may lead to fire and

`

damage the camera.

● INSTALLATION & CONNECTION

English _17

installation & connection

CONNECTING WITH OTHER DEVICE

Preparing Adapter and Cable

Connect the camera to the power adaptor. Then, plug the power cord of the adaptor to the wall

`

J

outlet.

D+ D- TXD+

TXD-

GND

A.COM A.NO

D+ D- TXD+

TXD-

GND

A.COM A.NO

AXICOM
IMO3
AXICOM
5VDC
IMO3
5VDC

Alarm1 ON

AXICOM

AXICOM
IMO3

IMO3
5VDC

5VDC

Alarm2 ONAlarm1 ON

AXICOM

Alarm2 ON

IMO3
AXICOM
5VDC
IMO3
5VDC

Check out the rated voltage and current before making connections.

ON DIP

1143Н

Video Out

1143Н

AC 22~26V

AUDIO_OUTAUDIO_IN

AUDIO_OUTAUDIO_IN

Power

1143Н

IN1 IN2 GND IN3 IN4 GND 1C0M 1.N0 1.NC 2C0M 2.N0 2.NC

IN1 IN2 GND IN3 IN4 GND 1C0M 1.N0 1.NC 2C0M 2.N0 2.NC

Alarm

COM2

COM1

1N.C

2N.C

GND

GND

1N.0

2N.0

IN4

IN3

IN2

IN1

Rated Power Allowable Input Voltage Current Consumption

AC 24V AC 22V ~ 26V 6 A

The product cannot be used at -50°C or below ambient temperature.

`

J

The product may not be defrosted depending on the installation area at -50°C.

`

Leave the product always turned on to maintain the internal temperature of -10°C or higher.

`

After the product is left alone under a low temperature environment, it will take up to 3 hours to

`

normally operate.

The zooming speed of the IR dimmer may slow down at -40°C or lower environment.

`

If the product is turned on after being exposed to -40°C or below environment for some time,

`

reset the time.

18_ installation & connection

Electrical Resistance of Copper Wire at [20°C (68°F)]

Copper Wire Gauge (AWG) #24(0.22mm2) #22(0.33mm2) #20(0.52mm2) #18(0.83mm2)

Resistance (Ω/m) 0.078 0.050 0.030 0.018

Drop Voltage (V/m) 0.028 0.018 0.011 0.006

Recommended Distance (m) Less than 20 Less than 30 Less than 30 Less than 30

As shown in the table above, you may encounter a voltage-sag depending on the wire length.

`

If you use an excessively long wire for camera connection, the camera may not work properly.

Camera Operating Voltage: AC 24V±10%

-

Voltage drop measurements on the chart above may vary depending on the type and manufacture of

-

the copper cable.

Ethernet Connection

Connect the Ethernet cable to the local network or to the Internet.

Connecting the installation monitor

Connect the cable to the camera’s rear video output terminal and the installation monitor’s
video input terminal.

Alarm2 ONAlarm1 ON

Alarm2 ON

Alarm1 ON

AXICOM

IMO3

5VDC

AXICOM

IMO3

5VDC

AXICOM

IMO3

5VDC

AXICOM

IMO3

5VDC

AXICOM

IMO3

5VDC

AXICOM

IMO3

5VDC

Alarm

1143Н

1143Н

1143Н

IN1

IN1 IN2 GND IN3 IN4 GND 1C0M 1.N0 1.NC 2C0M 2.N0 2.NC

IN1 IN2 GND IN3 IN4 GND 1C0M 1.N0 1.NC 2C0M 2.N0 2.NC

IN2

GND

IN3
IN4

GND

COM1

1N.0

1N.C

COM2

2N.0

2N.C

The wiring varies depending on your monitor type and peripheral devices; please refer to the user manual

`

for each device.
Please make sure the monitor and camera are turned off when connecting them.

`

A.NO

A.NO

A.COM

A.COM

GND

GND
TXD-

TXD-

AUDIO_OUTAUDIO_IN

AUDIO_OUTAUDIO_IN

D+ D- TXD+

D+ D- TXD+

AC 22~26V

Power

Video Out

ON DIP

Monitor

● INSTALLATION & CONNECTION

English _19

installation & connection

This product is a network camera that transfers video over a network; the video output terminal is

`

J

used to set the imaging range of the camera at installation.

Using the terminal for monitoring purposes may cause problems such as degradation in video

`

quality.

It is not suitable for 24-hour monitoring using professional CRT monitors or TFT/LCD portable

`

monitors.

Use the network transfer screen for 24-hour monitoring and storage.

`

INSTALLATION

Preparing & Installing Camera Bracket

For installation guidelines for brackets and housings, refer to the installation manual that is
enclosed with the bracket or housing.

`Available Bracket Models

Model Item

SBP-300WM1

SBP-300WM

SBP-300CM Ceiling Mount

SBP-300LM Parapet Mount

SBP-300KM Corner Mount

SBP-300PM Pole Mount

See “Optional Accessories for Installation” for the appearance of each bracket (unbundled).

`

M

(page 24)

Wall Mount

20_ installation & connection

Installing by wall mount

하우징
또는 마운트

BUSH

인터페이스

`Fix the installation base with the bracket

1. Fix the base with the bracket by turning it

clockwise.

● INSTALLATION & CONNECTION

2. As shown in the picture below, gently press

and lift up the handle of the hinged door on the
bottom of the installation base. Please refer to
the “Camera Wiring Interface Board” on page
16, connect the wires.

Do not connect the camera to a power outlet until the

`

J

installation is complete. Supplying power while the
installation is in progress may cause fire or damage
the product.

Check cable connection method and install.

M

Note that BUSHINGs are provided for outdoor

`

installations where exposed to a moisture
condition through the PIPE or MOUNT, install
the HOUSING using the BUSHING to prevent
moisture entering.

Apply grease of proper dose on the BUSHING

-

before assembling, and run cables through each hole of the
bushings. Use PINS to stop up empty holes having no cable
running.
Assemble the BUSHING to the top side of HOUSING’s inside

-

as shown in the diagram below. At the moment, apply pressure
evenly on the BUSHING to secure it tightly to the HOUSING as
shown in the diagram.

Knob

POE+ 또는 이더넷 케이블

POE+ or Ethernet cable

POWER

POWER (AC24V)

(AC24V)

기타 케이블

인터페이스

INTERFACE

핀

PIN

BUSH

BUSH

HOUSING OR

ETC CABLE

하우징
또는 마운트

MOUNT

BUSH

BUSH

하우징

HOUSING

BUSH

BUSH

BUSH

BUSH

BUSH

BUSH

English _21

installation & connection

3. Connect the camera safety wire to the

installation base.

4. Assemble Camera and Installation Base

Assemble the installation base and camera by
matching the installation direction guides.

5. Attach Camera

Turn the camera frame counterclockwise until
the protrusions on the camera frame and
installation base become matched perfectly.

Safety Cable

22_ installation & connection

6. Secure Camera and Installation Base

As shown in the picture below, secure the
installation base and camera using 3 hexagon
screws.

Notes for Waterproofing

This model is an integrated housing product for outdoor installation.

`When combining the main body and the wall mount for installation on the

wall

1. Install the wall mount on the vertical

wall. When it is installed on an inclined
wall, moisture may permeate into the
main body through the external cable.

2. Wrap the screw part of the housing with

a sufficient amount of Teflon tape for
assembly.

3. Please make sure that the gasket is

not disassembled from the shield cover
when the shield cover is separated and
mounted on the housing body.

4. Install the wall mount adapter for

waterproofing, and apply the silicon
sealant between and around the wall
and wall mount for sealing.

Take particular caution to ensure that there

`

J

is proper sealing if the installed side is not
flat.

Silicon

sealant

Wall mount

Screw

unit

Concrete wall

Teflon tape

Shield gasket

● INSTALLATION & CONNECTION

English _23

installation & connection

`When combining the main body and the ceiling mounting adaptor for

installation on the wall

1. Wrap the screw part of the housing

with a sufficient amount of Teflon tape
for assembly.

2. Please make sure that the gasket is

not disassembled from the shield cover
when the shield cover is separated and
mounted on the housing body.

3. Install the ceiling mount adapter for

waterproofing, and apply the silicon
sealant between and around the wall
and ceiling mount for sealing.

Take particular caution to ensure that

`

J

there is proper sealing if the installed side
is not flat.

Ceiling mount

adapter

Ceiling board

Screw

unit

Optional Accessories for Installation

For your easier installation, you can purchase appropriate optional accessories available.

1. If installing the camera on the wall

• Wall mount (SBP-300WM1)

Concrete ceiling

Silicon
sealant

Teflon tape

Shield gasket

24_ installation & connection

• Wall mount (SBP-300WM)

2. If installing the camera on the ceiling

• Ceiling Mount (SBP-300CM)

3. If installing the wall mount (SBP-300WM/SBP-300WM1) on an at least 80mm-long

cylinder

• Pole Mount (SBP-300PM)

● INSTALLATION & CONNECTION

English _25

installation & connection

4. If installing the wall mount (SBP-300WM/SBP-300WM1) on a corner of the wall

• Corner Mount (SBP-300KM)

5. If installing on a building rooftop

• Parapet Mount (SBP-300LM)

26_ installation & connection

`Mount Joint

● INSTALLATION & CONNECTION

Wall mount (SBP-300WM1)

Ceiling Mount (SBP-300CM)

Wall mount (SBP-300WM)

Parapet Mount (SBP-300LM)

English _27

installation & connection

INSERTING/REMOVING A SD MEMORY CARD

Disconnect the power cable from the camera before inserting the SD memory card.

`

J

Tighten the screws when assembling the camera body, shield cover and SD holder bracket to

`

prevent moisture penetration.

When mounting or dismounting an SD memory card, place the main body on the floor first to

`

prevent part loss and falling accident.

Inserting a SD Memory Card

1. Separate with hands the screws in front of and on

the rear of the shield cover.

2. Unfasten four screws by turning them

counterclockwise using a driver to separate the
shield cover.

3. Unfasten two screws on the SD holder bracket by

turning them counterclockwise using the driver.

Do not remove the screws.

`

J

28_ installation & connection

4. Pull up the SD holder bracket and push the SD

memory card to the arrow direction as shown in
the figure.

Do not insert the SD memory card while it’s upside

`

J

down by force. Otherwise, it may damage the SD
memory card.

5. Assemble the camera in the reverse order of

disassembly after the SD memory card is inserted.

Tighten the screws when assembling the camera to prevent moisture penetration.

`

J

Removing a SD Memory Card

Gently press down on the exposed end of the memory
card as shown in the diagram to eject the memory card
from the slot.

Pressing too hard on the SD memory card can cause

`

J

the card to shoot out uncontrollably from the slot when
released.

To turn off the camera or remove the SD memory card,

`

set the card to <Off> in <Storage> menu and press
the [Apply (

If you turn off the camera or remove the SD memory card that contains data from the product, the

`

data may be lost or damaged.

)] button. (page 108)

● INSTALLATION & CONNECTION

English _29

installation & connection

MEMORY CARD INFORMATION (NOT INCLUDED)

What is a memory card?

The memory card is an external data storage device that has been developed to offer an
entirely new way to record and share video, audio, and text data using digital devices.

Selecting a memory card that’s suitable for you

Your camera supports SD/SDHC/SDXC memory cards.
You may, however, experience compatibility issues depending on the model and make of
the memory card.

For your camera, we recommend you use a memory card from the following
manufacturers:
SD/SDHC/SDXC Memory Card : Sandisk, Transcend

Memory cards of 4GB ~ 64GB is recommended for using with this camera.

Playback performance can be affected depending on the speed of memory card, so use
the high-speed memory card.

For the framerate below 30 fps, it is recommended to use the specification memory card of
Class 6 or higher.

For the framerate over 31 fps, it is recommended to use the specification memory card of
Class 10 UHS or higher.

Memory Card Use

SD and SDHC memory cards feature a switch that disables writing data on to the media.
Having this switch to the Lock position will prevent accidental deletion of data stored in the
memory card but at the same time will also prevent you from writing data on to the media.

30_ installation & connection

network connection and setup

You can set up the network settings according to your network configurations.

CONNECTING THE CAMERA DIRECTLY TO LOCAL AREA
NETWORKING

Connecting to the camera from a local PC in the LAN

1. Launch an Internet browser on the local PC.

2. Enter the IP address of the camera in the address bar of the browser.

Camera

●

NETWORK CONNECTION AND SETUP

Firewall

INTERNET

External Remote PC

DDNS Server
(Data Center, KOREA)

Switch

Camera

Local PC

<Local Network>

A remote PC in an external Internet out of the LAN network may not be able to connect to the

`

M

camera installed in the intranet if the port-forwarding is not properly set or a firewall is set.
In this case, to resolve the problem, contact your network administrator.

In the IP installer, you can use the initial password, “4321” to set IP Address, Subnet Mask,

`

Gateway, HTTP Port, VNP Port, IP type. After changing the network interface, for better security,
access the web viewer and change the password.

By factory default, the IP address will be assigned from the DHCP server automatically.

`

If there is no DHCP server available, the IP address will be set to 192.168.1.100.
To change the IP address, use the IP Installer.
For further details on IP Installer use, refer to “Static IP Setup”. (Page 36)

English _31

network connection and setup

CONNECTING THE CAMERA DIRECTLY TO A DHCP
BASED DSL/CABLE MODEM

DSL/Cable

Camera

1. Connect the user PC directly with the network camera.

2. Run the IP Installer and change the IP address of the camera so that you can use

the web browser on your desktop to connect to the Internet.

3. Use the Internet browser to connect to the web viewer.

4. Move to [Setup] page.

5. Move to [Network] – [DDNS] and configure the DDNS settings.

6. Move to [Basic] – [IP & Port], and set the IP type to [DHCP].

7. Connect the camera, which was removed from your PC, directly to the modem.

8. Restart the camera.

For configuring the DDNS settings, refer to “DDNS”. (page 98)

`

M

For registering the DDNS settings, refer to “Registering with DDNS”. (page 99)

`

Refer to “IP & Port” for how to setup IP. (page 69)

`

Modem

INTERNET

DDNS Server

(Data Center, KOREA)

External Remote PC

32_ network connection and setup

CONNECTING THE CAMERA DIRECTLY TO A PPPoE
MODEM

PPPoE Modem

Camera

1. Connect the user PC directly with the network camera.

2. Run the IP Installer and change the IP address of the camera so that you can use

the web browser on your desktop to connect to the Internet.

3. Use the Internet browser to connect to the web viewer.

4. Move to [Setup] page.

5. Move to [Network] – [DDNS] and configure the DDNS settings.

6. Move to [Basic] – [IP & Port] Setup Page, set the IP type to [PPPoE], and enter the

network service’s ID and password.

7. Connect the camera, which was removed from your PC, directly to the modem.

8. Restart the camera.

For configuring the DDNS settings, refer to “DDNS”. (page 98)

`

M

For registering the DDNS settings, refer to “Registering with DDNS”. (page 99)

`

Refer to “IP & Port” for how to setup IP. (page 69)

`

INTERNET

DDNS Server

(Data Center, KOREA)

External Remote PC

●

NETWORK CONNECTION AND SETUP

English _33

network connection and setup

CONNECTING THE CAMERA TO A BROADBAND ROUTER
WITH THE PPPoE/CABLE MODEM

This is for a small network environment such as homes, SOHO and ordinary shops.

Camera

INTERNET

PPPoE or

Cable Modem

DDNS Server
(Data Center, KOREA)

External Remote

PC

Camera

Local PC

Broadband

Router

PPPoE or

Cable Modem

Configuring the network settings of the local PC connected to a
Broadband Router

Configuring the network settings of the local PC connected to a Broadband Router, follow
the instructions below.

• Select : <Network>  <Properties>  <Local Area Connection>  <General>
<Properties>  <Internet Protocol (TCP/IP)>  <Properties>  <Obtain an



IP address automatically> or <Use the following IP address>.

• Follow the instructions below if you select <Use the following IP address>:

ex1) If the address (LAN IP) of the Broadband Router is 192.168.1.1

IP address : 192.168.1.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.1.1

ex2) If the address (LAN IP) of the Broadband Router is 192.168.0.1

IP address : 192.168.0.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.0.1

ex3) If the address (LAN IP) of the Broadband Router is 192.168.xxx.1

IP address : 192.168.xxx.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.xxx.1

For the address of the Broadband Router, refer to the product’s documentation.

`

M

For more information about port forwarding of the broadband router, refer to “Port Range

`

Forward (Port Mapping) Setup”. (Page 41)

34_ network connection and setup

BUTTONS USED IN IP INSTALLER

a b c d e f g

h i j k l m

Item Description

Device Name

a

Alias This function is not currently implemented.

b

Mode

c

MAC(Ethernet)

d

Address

IP Address

e

Protocol

f

Model name of the connected camera.
Click the column to sort the list by model name.
However, search will be stopped if clicked during the search.

Displays either <Static>, <Dynamic> or <PPPoE> for the current network
connection status.

Ethernet address for the connected camera.
Click the column to sort the list by Ethernet address.
However, search will be stopped if clicked during the search.

IP address.
Click the column to sort the list by IP address.
However, search will be stopped if clicked during the search.

Network setting for the camera.
The factory default is “IPv4”.
Cameras with the IPv6 setting will be displayed “IPv6”.

●

NETWORK CONNECTION AND SETUP

English _35

network connection and setup

Item Description

URL

g

IPv4 Scans for cameras with the IPv4 setting.

h

IPv6

i

Search

j

Auto Set The IP Installer automatically configures the network settings.

k

Manual Set You should configure the network settings manually.

l

Exit Exits the IP Installer program.

m

For the IP installer, use only the installer version provided in the installation CD or use the latest one if

`

M

available. You can download the latest version from the Samsung web site.

STATIC IP SETUP

Manual Network Setup

Run <IP Installer_v2.XX.exe> to display the camera search list.
At the initial startup, both [Auto Set] and [Manual Set] will be grayed out.

For cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not

`

M

support this function.

1. Select a camera in the search list.

Check the MAC address of the camera
on the camera’s label.
Both the [Auto Set] and [Manual Set]
buttons will be activated.

2. Click [Manual Set].

The Manual Setting dialog appears.
The default values of <IP Address>,
<Subnet Mask>, <Gateway>, <HTTP Port> and <VNP Port> of the camera will
be displayed.

DDNS URL address enabling access from the external Internet.
However, this will be replaced with the <IP Address> of the camera if
DDNS registration has failed.

Scans for cameras with the IPv6 setting.
Activated in an IPv6 compliant environment only.

Scans for cameras that are currently connected to the network.
However, this button will be grayed out if neither IPv4 nor IPv6 is checked.

36_ network connection and setup

3. In the <Address> pane, provide the

necessary information.

• MAC (Ethernet) Address : The MAC
address imprinted on the camera
label is automatically displayed and
requires no user setting.

You can configure the static IP settings

`

M

only if the DHCP checkbox is unchecked.

If not using a Broadband Router

For setting <IP Address>, <Subnet Mask>, and <Gateway>, contact your network administrator.

4. In the <Port> pane, provide necessary

information.

• HTTP Port : Used to access the
camera using the Internet browser,
defaulted to 80.

• VNP Port : Used to control the video
signal transfer, defaulted to 4520.

5. Enter the password.
Enter the password of “admin” account, which was used to access the camera.

For the security purposes, you are recommended to use a combination of numbers, alphabets

`

J

uppercase and lowercase and special characters for your password.

If you want to change the password, refer to “Administrator password change” of the user

`

setup. (page 66)

6. Click [OK].
Manual network setup will be completed.

●

NETWORK CONNECTION AND SETUP

English _37

network connection and setup

If using a Broadband Router

• IP Address : Enter an address falling in
the IP range provided by the Broadband
Router.
ex) 192.168.1.2~254,

192.168.0.2~254,

192.168.XXX.2~254

• Subnet Mask : The <Subnet Mask>
of the Broadband Router will be the
<Subnet Mask> of the camera.

• Gateway : The <Local IP Address> of
the Broadband Router will be the <Gateway> of the camera.

The settings may differ depending on the connected Broadband Router model.

`

M

For more information, refer to the user manual of the applicable router.

For more information about port forwarding of the broadband router, refer to “Port Range

`

Forward (Port Mapping) Setup”. (Page 41)

If the Broadband Router has more than one camera connected

Configure the IP related settings and the Port related settings distinctly with each other.

ex)

Category Camera #1 Camera #2

IP related settings

Port related settings

If the <HTTP Port> is set other than 80, you must provide the <Port> number in the address bar

`

M

of the Internet browser before you can access the camera.
ex) http://IP address : HTTP Port

38_ network connection and setup

IP Address
Subnet Mask
Gateway

HTTP Port
VNP Port

http://192.168.1.100:8080

192.168.1.100

255.255.255.0

192.168.1.1

8080
4520

192.168.1.101

255.255.255.0

192.168.1.1

8081
4521

Auto Network Setup

Run <IP Installer_v2.XX.exe> to display the camera search list.
At the initial startup, both [Auto Set] and [Manual Set] will be grayed out.

For cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not

`

M

support this function.

1. Select a camera in the search list.

Check the MAC address of the camera
on the camera’s label.
Both the [Auto Set] and [Manual Set]
buttons will be activated.

2. Click [Auto Set].

The Auto Setting dialog appears.
The <IP Address>, <Subnet Mask>,
and <Gateway> will be set automatically.

3. Enter the password.
Enter the password of “admin” account,
which was used to access the camera.

For the security purposes, you are

`

J

recommended to use a combination
of numbers, alphabets uppercase and
lowercase and special characters for your
password.

If you want to change the password, refer

`

to “Administrator password change” of
the user setup. (page 66)

4. Click [OK].
Auto network setup will be completed.

●

NETWORK CONNECTION AND SETUP

English _39

network connection and setup

DYNAMIC IP SETUP

Dynamic IP Environment Setup

• Example of the Dynamic IP environment

- If a Broadband Router, with cameras connected, is assigned an IP address by the
DHCP server

- If connecting the camera directly to modem using the DHCP protocols

- If IPs are assigned by the internal DHCP server via the LAN

Checking the Dynamic IP

1. Run the IP Installer on the user’s local

computer.
Cameras allocated with <Dynamic IP>
address are shown in the list.

2. Select a camera from the search result.

3. Click the [Manual Set] button and

check the camera’s <Dynamic IP>
address.
If you uncheck <DHCP>, you can
change IP to <Static>.

40_ network connection and setup

PORT RANGE FORWARD (PORT MAPPING) SETUP

If you have installed a Broadband Router with a camera connected, you must set the port range
forwarding on the Broadband Router so that a remote PC can access the camera in it.

Manual Port Range Forwarding

1. From the Setup menu of the Broadband
Router, select <Applications &
Gaming> - <Port Range Forward>.

For setting the port range forward for
a third-party Broadband Router, refer
to the user guide of that Broadband
Router.

2. Select <TCP> and <UDP Port>
for each connected camera to the
Broadband Router.
Each port number for the Broadband
Router should match that specified in
<Setup> - <Basic> - <IP & Port> from
the camera’s web viewer menu.

3. When done, click [Save Settings].
Your settings will be saved.

Above sample instructions are based on the CISCO’s Broadband Router.

`

M

The settings may differ depending on the connected Broadband Router model.

`

For more information, refer to the user manual of the applicable router.

●

NETWORK CONNECTION AND SETUP

English _41

network connection and setup

Setting up Port Range Forward for several network cameras

• You can set a rule of Port Forwarding on the Broadband Router device through its
configuration web page.

• A user can change each port using the camera setting screen.

When Camera1 and Camera2 are connected to a router :

User

Start End Protocol IP Address
3000 3000 TCP/UDP 192.168.1.100
3001 3001 TCP/UDP 192.168.1.101
4520 4520 TCP/UDP 192.168.1.100
4521 4521 TCP/UDP 192.168.1.101
8080 8080 TCP/UDP 192.168.1.100
8081 8081 TCP/UDP 192.168.1.101

`

M



Broadband Router

Port forwarding can be done without additional router setup if the router supports the UPnP
(Universal Plug and Play) function.
After connecting the network camera, set <Quick connect> of <Samsung DDNS> to <On> in
the “Setup  Network  DDNS” menu.

Internet



Camera1 (192.168.1.100)



Camera2 (192.168.1.101)



HTTP port 8080

Device port 4520

RTSP port 3000

HTTP port 8081

Device port 4521

RTSP port 3001

42_ network connection and setup

CONNECTING TO THE CAMERA FROM A SHARED LOCAL PC

1. Run the IP Installer.

It will scan for connected cameras and
display them as a list.

2. Double-click a camera to access.

The Internet browser starts and
connects to the camera.

Access to the camera can also be gained by typing the camera’s IP address in the address bar of

`

M

the Internet browser.

CONNECTING TO THE CAMERA FROM A REMOTE PC VIA
THE INTERNET

Since using the IP Installer on a remote computer that is not in the Broadband Router’s network
cluster is not allowed, users can access cameras within a Broadband Router’s network by using
the camera’s DDNS URL.

1. Before you can access a camera in the Broadband Router network, you should have

set the port range forward for the Broadband Router.

2. From the remote PC, launch the Internet browser and type the DDNS URL address

of the camera, or the IP address of the Broadband Router in the address bar.
ex) http://www.samsungipolis.com/Product ID

For registering the DDNS settings, refer to “Registering with DDNS”. (page 99)

`

M

●

NETWORK CONNECTION AND SETUP

English _43

web viewer

CONNECTING TO THE CAMERA

Normally, you would

1. Launch the Internet browser.

2. Type the IP address of the camera in

the address bar.

ex) • IP address (IPv4) : 192.168.1.100

http://192.168.1.100



- the Login dialog should appear.
IP address (IPv6) : 2001:230:abcd:

•

ffff:0000:0000:ffff:1111

http://[2001:230:abcd:ffff:0000



:0000:ffff:1111] - the Login dialog
should appear.

If the HTTP port is other than 80

1. Launch the Internet browser.

2. Type the IP address and HTTP port number of the camera in the address bar.

ex) IP address : 192.168.1.100:HTTP Port number(8080)

http://192.168.1.100:8080 - the Login dialog should appear.



Using URL

1. Launch the Internet browser.

2. Type the DDNS URL of the camera in the address bar.

ex) URL address : http://www.samsungipolis.com/Product ID

- the Login dialog should appear.

Connecting via UPnP

1. Run the client or operating system in support of the UPnP protocol.

2. Click the camera name for search.

In the Windows operating system, click the camera name searched from the
network menu.

- The login window is displayed.

44_ web viewer

Connecting via Bonjour

1. Run the client or operating system in support of the Bonjour protocol.

2. Click the camera name for search.

In the Mac operating system, click the camera name searched from the Bonjour tab
of Safari.

- The login window is displayed.

To check the DDNS address

If the camera is connected directly to the DHCP cable modem, DSL modem, or PPPoE
modem, the IP address of your network will be changed each time you try to connect to
the ISP (Internet Service Provider) server.
If this is the case, you will not be informed of the IP address changed by DDNS.

Once you register a dynamic IP-based device with the DDNS server, you can easily check
the changed IP when you try to access the device.
To register your device to the <DDNS> server, visit www.samsungipolis.com and register
your device first, and then set the Web Viewer’s <Network> - <DDNS> to <Samsung
DDNS>, as well as providing <Product ID> that had been used for DDNS registration.

You can use a DDNS connection only if you are connected to the external network.

`

J

PASSWORD SETTING

When you access the product for the first time,
you must register the login password.
When the “Password change” window appears,
enter the new password.

For a new password with 8 to 9 digits,

`

J

you must use at least 3 of the following:
uppercase/lowercase letters, numbers
and special characters. For a password
with 10 to 15 digits, you must use at least
2 types of those mentioned.

Special characters that are allowed. : ~`!@#$%^*()_-+=|{}[].?/

-

For higher security, you are not recommended to repeat the same characters or consecutive

`

keyboard inputs for your passwords.

If you lost your password, you can press the [RESET] button to initialize the product. So, don’t lose

`

your password by using a memo pad or memorizing it.

● WEB VIEWER

English _45

web viewer

LOGIN

Whenever you access the camera, the login window appears.
Enter the User ID and password to access the camera.

1. Enter “admin” in the <User name>

input box.
The administrator ID, “admin”, is fixed
and can not be changed.

2. Enter the password in the <Password>

input field.

3. Click [OK].

If you have logged in successfully, you
will the Live Viewer screen.

When you access the camera web viewer, pay special attention to the security by checking

`

J

whether the image data is encrypted.

If you check the “Remember my credentials” option when your input is done, in future you will

`

M

be logged in automatically without being prompted to enter the login information.

You will experience the best video quality if the screen size is 100%. Reducing the ratio may cut

`

the image on the borders.

46_ web viewer

INSTALLING STW WebViewer PLUGIN

If connecting to a camera for the first time, you will see the installation message. Then, install the
required WebViewer Plugin to access the camera and control the video from it in real time.

1. When the monitoring page is accessed

for the very first time, the installation
page is displayed. Click [Click Here] to
begin installation.

If the plug-in installation file download status is suspended at 99% in the Internet Explorer

`

J

browser, retry it after selecting “Release SmartScreen filter” in “Tool  SmartScreen filter”.

2. Click [Run] in the message window.

3. Click [Yes] when the notice window

saying that all browser windows will be
closed.

4. When the old version of the Web Viewer

Plug-in is installed, a notice window
saying the old version will be deleted is
displayed.
Click [Yes] when the notice window is
displayed.

Steps 4 and 5 will be skipped if no Web Viewer Plug-in is installed.

`

M

● WEB VIEWER

English _47

web viewer

5. Click [OK].

The old version of Web Viewer Plug-in
is deleted.

6. Click [Install] to begin installation of the

Web Viewer Plug-in.

7. Click [Finish].

STW Web Viewer Plug-in installation is
completed.

In your internet explorer, if you need

`

J

to move to the installation screen
after installing the STW webviewer
plugin, check whether webviewer_
activexplugin_lib.control in the “Tool 
Additional Function Management” menu
is “Activated”. If not, and if there is a
persisting problem, then select “Tools 
Internet Options  General” and delete all the search records.

48_ web viewer

USING THE LIVE SCREEN

a b c d e

f
g
h
i
j
k
l

m

n

o

Item Description

Monitoring Move to the monitoring screen.

a

Playback

b

Setup Move to the Setup screen.

c

Profile access

d

information

Viewer Screen

e

Profile type

f

Screen

g

Optimization

Move to the screen where you can search for the video recording saved in your SD
memory card or NAS.

You can read the profile information.

Displays the Live video on the screen.

You can use the mouse wheel to activate the digital zooming in Viewer screen.

`

You can select a profile type in <Video profile> under the <Basic> setup menu.

When the Web Viewer is connected, the profile information currently using is

`

displayed.

The video size of the camera will switch to as big as the Web browser.

● WEB VIEWER

English _49

web viewer

Item Description

Fix the resolution

h

Full Screen Switch the current video to the maximum size of the monitor.

i

Capture Saves the snapshot as an image file in the .jpg format.

j

Manual recording

k

Audio/Microphone

l

Control

Alarm output Activate the Alarm Out port.

m

PTZ Control the pan/tilt/zoom operations of the camera.

n

Hide the context

o

menu

Regardless of the resolution setup configured in the camera, it sets the resolution to
640x480. Press it again to switch back to the default resolution.

Users can save their video in the SD memory card or NAS on their own.

To take video manually, change the recording setting first. Refer to “Storage” for

`

how to set recording (page 108).

Enable Audio and Microphone are control the Audio volume.

Only the Audio volume can be controlled.

`

The left-corner context menu will disappear but only the menu icon.

50_ web viewer

To capture the snapshot

1. Click [Capture ( )] on the scene to capture.

2. When a captured video is saved, a notification message appears.

When using Internet Explorer, the captured video is saved in My Computer / My
Documents / Pictures.
In Mac OS, it is saved in “~/Pictures” or “/Users/{user account}/Pictures/”.

If you encounter an interrupted video when capturing the image with IE8 on a Windows 7-based

`

M

PC, deselect “Turn On Protected Mode” from “Tools – Internet Options – Security”.

If the screen is not captured by IE browser in Windows 7 or 8, run the IE Browser with the Admin

`

privilege.

How to record videos manually

1. Press [Manual recording ( )].

2. To end the recording, press [Manual recording (

After inserting the SD card, go to <Event> - <Storage> and turn on the SD card by selecting “On”

`

M

or turn on NAS by selecting “On” after connecting to it. Then you can use the manual recording
function.

)] again.

To fit the full screen

1. Click the [Full Screen (

2. This will fit the Viewer to the full screen.

3. To exit the full screen mode, press [Esc] on the keyboard.

For the Internet Explorer and Google Chrome browser, you can switch to the full screen.

`

M

)] button.

To Use Microphone

Click [Mic ( )] icon to activate the microphone.

● WEB VIEWER

English _51

web viewer

To Use Audio

1. Click [Audio ( )] icon to activate audio communication.

2. Use [

To control the PTZ

1. Press the [PTZ ( )] tab.

2. Adjust the direction of the camera

To run a sequence

•

•

•

•

] bar to control the volume.

If there is no sound from pulling in and out the audio jack while it is in operation, click the

`

M

[Audio (

by controlling the cursor [
screen moving pad, or control the
zoom or focus.

For further details on PTZ use, refer to

`

M

“PTZ setup”. (page 71)

: Run a saved preset.

Refer to “To configure the detailed
settings for the preset” for details of
preset setting. (page 73)

: Run a saved swing.

Refer to “To configure the swing
settings” for details of swing setting.
(page 74)

: Run a saved group.

Refer to “To set a group” for details of
group setting. (page 75)

: Run a saved tour.

Refer to “To configure the tour settings” for details of tour setting. (page 76)

)] icon to enable it again.

] of the

52_ web viewer

•

: Run a saved trace.

Refer to “To set the tracing function” for details of trace setting. (page 76)

•

: Run a saved home position.

Refer to “To add the home position” for details of home position setting. (page 72)

•

: Configure preset.

For details on preset configuration, see “To configure the detailed settings for the

preset”. (page 73)

To enable the Area Zoom mode

•

: For zoom movement, click and drag to the location on the screen that you want

to move to.

•

: Change the current zoom factor to x1.

•

: Return to the previous area and settings.

•

: If navigated with Prev, it is switched to area and setting before navigation.

To use the auto tracking function

•

: Run auto tracking action for the set tracing time.

Refer to “Auto tracking setup” for detailed setting methold. (page 79)

To use the Lock-On function

Right-click on a video, and select the object of auto tracing manually.

● WEB VIEWER

English _53

web viewer

PLAYING THE RECORDED VIDEO

Before you can play the video, you must configure the record settings. For details on record settings,

`

M

refer to “Storage”. (page 108)

Name of event search screen and its function

a

b
c

Item Description

Search range setting

a

Set the search date and time range for data saved in your SD memory card
or NAS.

Search event setting Set the event type to search within the search period.

b

Event search Run the event search.

c

54_ web viewer

To play the content after searching by event

1. Click the [Playback ( )] button.

2. Specify the start time and end time of

your search.

3. Select an event type for your search

within the specified period.

4. Click the [Event search] button.

The search results will be displayed in
the list.

If more than 800 events are recorded

`

M

within the search period, your search will be limited up to the date when the 800th event is
recorded.
For instance, if the search period is between 10th and 15th day of the month, and more than 800
events were recorded 10th through 11th, your search will be limited up to 11th day with a total of
800 events, and events after then (from 12th) will not be found.

5. Select a data item to play in the search

list.

6. Click the [Play (

7. To stop playing the video, click

[Stop (

8. To return to the search screen,

click [Exit (

)] button.

)].

)].

● WEB VIEWER

English _55

web viewer

Name of time search screen and its function

b

c
d
e

f
g
h
i

Item Description

Time bar The section in the specific period is played by moving the time bar.

a

Search date setting

b

Speaker

c

Screen optimization The camera image is converted to fit the Web browser window.

d

Fix the resolution

e

Capture The current image is saved as a .jpg image file.

f

Set the search date using the calendar.

If there is data saved in your SD memory card or NAS on the day, it is

`

marked as a box on the calendar.

To listen to a voice signal (if present) in the recorded video, then activate the
voice signal icon when you play it.

Regardless of the resolution setup configured in the camera, it sets
the resolution to 800x600. Press it again to switch back to the default
resolution.

a

Full screen The current image is converted to cover the maximum size of the monitor.

g

56_ web viewer

Item Description

Video information Time data of the replayed video is displayed on the screen.

h

Set the desired date to make a backup copy of video data saved in your SD

i

Backup

memory card or NAS.

Can be set as up to 5 minutes.

`

To play after searching by time

1. Click [Time Search ( )].

2. Click a desired date in the calendar.

The video on the specified date will be
played.

3. If the video playback is stopped, select

a time and click [Play (
The video on the selected time will be
played.

4. While the video is being played, the

recording time for the current video will be shown.

5. Search for the video forward or backward, and control the play speed.

- How to Control the Play Interval
: Select this button to move 1 frame forward.
: Select this button to move 1 second back.

- To control the play speed

If selecting ), the button will switch to x1, x2, x4, x8, and the play speed will
increase accordingly.
When the ( button is selected, the playing speed is decreased to -1x, -2x, -4x, -8x
and the playing speed slows down gradually. Subsequently the quick playing speed
is returned to the normal speed and the reverse playing speed increases.

- To control the playback direction

If you see the ) button with the play speed displayed, the video will be played
forward; Whereas, if you see the ( button with the play speed displayed, the video
will be played backward.

- How to set the time bar

If you press the
If you press the
can be selected more easily.

)].

button, the details of the time bar section can be viewed.
button, you can view a wider range of times and the desired time

● WEB VIEWER

English _57

web viewer

6. Move [Time bar (

The time containing a normal recoding file will be highlighted in blue; the time with
the event recording will be highlighted in red.

)] to a desired time point of the video before playing it.

To back up the searched video

1. During playback, click [ ] on the

scene to back up.
The scheduling window for backup
start and end time appears.

2. Click [

The Save As window appears.

3. Confirm the save path and click [Save]

button.
The screenshot will be backed up to
the specified path.

] button.

To play the backup video

The backed up images are saved in an .avi format. Gom Player, VLC Player, and Window
Media Player are recommended as the media player compatible with this format.

In case of Windows Media Player, download the latest codec from www.windows7codecs.com

`

M

and install it prior to use.

58_ web viewer

To Play an AVI File

(1) SD memory card

1. Separate the SD memory card from the camera.

Before separating the SD memory card, set the <Device> to <Off> in the “Setup  Event 

`

J

Storage” menu.

2. Insert the SD memory card into the PC.

3. Play the AVI file in the “\ch00\img\
YYYY_mm_DD\AVI” directory, using a

media player.

A filename starts with the format “001_

`

M

YYYYMMDD_HHMMSS.avi” and the file
number is incremented by one.
YYYYMMDD_HHMMSS indicates the start
time of data saving.

“001_YYYYMMDD_HHMMSS.smi” file

`

is a caption file, and you can view it if it
exists in the same directory as its related
AVI file.

The max recording time per AVI file is 5

`

minutes.

Once corrupted, the data in the SD memory card cannot be replayed in the Web Viewer’s

`

[Playback].

● WEB VIEWER

English _59

web viewer

(2) NAS (Network-Attached Storage)

1. In Windows browser, use \\<ip

address>\ to access.
ex)\\192.168.20.31\defaultfolder\ch01\
img\2013_07_02\AVI

2. Go to <Computer>  <Network drive
connection>  Enter 1.

3. Connected to the NAS.

The directory structure is same as the
directory structure for a SD memory
card.

A filename starts with the format “001_

`

M

YYYYMMDD_HHMMSS.avi” and the file
number is incremented by one.
YYYYMMDD_HHMMSS indicates the start time of data saving.

“001_YYYYMMDD_HHMMSS.smi” file is a caption file, and you can view it if it exists in the

`

same directory as its related AVI file.

The max recording time per AVI file is 30 minutes.

`

If you change or damage the saved data on your own, it will not play back or save properly.

`

60_ web viewer

setup screen

SETUP

On the network, you can set up basic information on the camera, video and audio, network
events and system.

)

(

]

1. In the Live screen, click [Setup

2. The Setup screen appears.

The setting page for preview video requires the STW web viewer plug-in to be installed on the PC.

`

J

If it is not intalled properly, the installation page automatically apprears.

BASIC SETUP

Video profile

1. From the Setup menu, select the

<Basic ( )> tab.

2. Click <Video profile>.

3. Set the <Video profile connection

policy>.

• Keep connection when profile
setting is changed : Changing profile
properties that is used by existing
connection does not affect such
connection and remains with old
profile setup.
If not selected, changing a profile
used by an existing connection
resets such connection.

.

● SETUP SCREEN

English _61

setup screen

4. Select each profile properties.
For more details, refer to “To Add/Change the Video Profile”. (Page 64)

5. Click the input box of each item and enter / select a desired value.

The context menu may differ depending on the selected codec type.

`

• Default profile : If no profile is selected when using the Web Viewer, the default
video profile is applied.

• E-mail/FTP profile : Video profile to be transferred to the specified email or FTP
site.

Only the MJPEG codec can be set as the E-mail/FTP profile.

`

• Record profile : This is the profile applied to video recording on SD card or NAS.

• Audio-In : Sets whether to use audio for video recordings.

6. According to your situation, set ATC (Auto Transmit Control) mode.

• ATC mode : It adjusts the video
properties according to the variance
in the network bandwidth, controlling
the bit rate. Adjusting the bit rate
depends on the ATC mode.

- Control framerate : Reduce the frame rate if the network bandwidth drops down.

- Control compression : Control the compression rate if the network bandwidth
drops down.
Compression adjustment can cause deterioration of the image quality.

- Event (MD) : This function works when a Motion Detection (MD) event is selected.
If an event occurs, the system controls the frame rate.
If no movement is detected, the system outputs signals at the minimum frame rate,
thus reducing use of the bandwidth.

If <Bitrate control> is set to <CBR>, the encoding priority according to the ATC mode will be

`

fixed as below:

Bitrate control / ATC

mode

CBR Framerate Compression Framerate

Control framerate Control compression Event(MD)

62_ setup screen

• ATC sensitivity : Affect the transfer rate according to the variance in the network
bandwidth.
The transfer rate will be adjusted to the fastest if the bandwidth is <Very high>,
and adjusted to the latest if the bandwidth is <Very low>.

• ATC limit : If the quality or frame rate is adjusted, the property will be changed to
the applied value (%) against the previous setting value (100%).
Note that if you reduce the property value too much, you may encounter flickering
on the screen. So it is advisable to adjust the value within the threshold.

It is recommended to apply ATC control only for cameras supporting ATC.

`

J

Set the ATC sensitivity to <Very low> in a network environment with high variance in the network

`

bandwidth.
If the network connection is unstable, you may encounter flickering on the screen.

`

7. When done, click [Apply (

)].

● SETUP SCREEN

MJPEG, H264 is the default profile and you cannot delete it or change the name and codec.

`

M

English _63

setup screen

To Add/Change the Video Profile

The profile setup can be added or modified to accommodate various profiles depending on
the recording conditions.

1. Select one from the <Video profile> options.

2. Provide the name and select a codec.

3. Specify the conditions under which the codec will be applied.

4. Specify the details of the selected codec including resolution and frame rate.

Click <Advanced> to display the context menu.

• Resolution : Set the video size of the H.264 and MJPEG files.

• Framerate : Set the max number of video frames per sec.

The <Sensor> mode setup in Video Setup changes the maximum configurable framerate.

`

M

Sensor 25 fps 30 fps 50 fps 60 fps

Framerate 1~25 fps 1~30 fps 1~50 fps 1~60 fps

• Maximum bitrate : Set the max bit rate of video when the bit rate control is set to
VBR.

As the bit rate can be adjusted limitedly according to the resolution, frame rate and screen

`

J

complexity, the actual bit rate can be greater than the maximum bit rate. So you must
consider the use conditions when setting the value.

• Target bitrate : Set the target bit rate when the bit rate control is set to CBR.

• Bitrate control : You can select one from constant bit rate and variable bit rate for
compression. Fixed bitrate means that the network transmission bitrate is fixed
while varying the video quality or frame rate, variable bitrate means that a higher
priority is placed on the video quality while varying the bitrate.

After setting the fixed bit rate for bit control, if you select the video quality priority mode,

`

J

depending on the complexity of the screen, the actual transmitted frame rate may differ from
the frame rate setup in order to guarantee the optimal video quality for the given bit rate.

64_ setup screen

• Encoding priority : You can set the priority of video transmission to frame rate or
compression.

• GOV length : It specifies the distance (in terms of number of frames) between two
consecutive I-Frames in a video sequence when H.264 codec was selected. (One
I-Frame + 0~Several P-Frames)

• Smart codec : Specify the use of Smart codec.

The Smart Codec will be active only if the codec is of H.264 and the compression system is

`

M

CBR.

• Multicast(SVNP) : Specify the use of the SVNP protocol.

- IP address : Enter an IPv4 address with which you can connect to the IPv4 network.

- Port : Specify the video communication port.

- TTL : Set the TTL for the SVNP packet.

• Multicast(RTP) : Specify the use of the RTP protocol.

- IP address : Enter an IPv4 address with which you can connect to the IPv4
network.

- Port : Specify the video communication port.

- TTL : You can set the TTL for the RTP packet.

If you set the Multicast address to 224.0.0.0~224.0.0.255, multicast may not work properly

`

J

in all environments. In that case, we recommend you change the multicast address.

What is GOV length?

GOV(Group of Video object planes) is a set of video frames for H.264 compression,
indicating a collection of frames from the initial I-Frame (key frame) to the next I-Frame.
GOV consists of 2 kinds of frames: I-Frame and P-Frame.

I-Frame is the basic frame for the compression, also known as Key Frame, which contains
one complete image data. P-Frame contains only the data that has changed from the
preceding I-Frame.

For H.264 codec, you can determine the GOV length.
If you set a recording profile with H.264 codec, the GOV length will be framerate/2.

● SETUP SCREEN

English _65

setup screen

User

1. From the Setup menu, select the
<Basic ( )> tab.

2. Click <User>.

3. Provide the necessary user information.

• Administrator password change :
Change the password for the
administrator.

For the security purposes, you are

`

J

recommended to use a combination
of numbers, alphabets uppercase and
lowercase and special characters for
your password.

It is recommended to change your

`

password once every three months.

The password length and limits are shown as follows.

`

A combination of at least three types of upper case, lower case, numeric, and special

-

characters: 8 to 9 characters.
A combination of at least two types of upper case, lower case, numeric, and special

-

characters: 10 to 15 characters.
Should be different from the ID.

-

Cannot repeat the same letter, number of special characters more than 4 times.

-

Don’t use 4 or more characters consecutive together. (examples : 1234, abcd)

-

Don’t use 4 or more characters repeated. (examples : !!!!, 1111, aaaa)

-

Special characters that are allowed. : ~`!@#$%^*()_-+=|{}[].?/

-

After the factory setting, the admin and user passwords are initialized. You need to reset

-

the password.
When you access the camera web page for the first time or access it after the initialization,

-

you will be moved to the admin password setting menu.
In this menu, you need to login again with the new password before using the camera web

-

page menus.

66_ setup screen

If the existing password is not matched, when you change the admin password, you

-

cannot change the password.
After changing your password, if there is a camera connected to a CMS or NVR client,

-

then you need to re-register it with the newly changed password. If the camera is still
connected with the same password, then the account may be locked because a client
uses the previous password.

If you try to login with the registered account, 5 or more consecutive password authentication

`

has failed, and then the account may be locked for thirty seconds.

When the password is changed while multiple connections are active from a PC, the browser

`

may malfunction. In that case, reconnect to the server.

• Guest setup : If you select <Enable guest access>, the guest account can access

the Web viewer screen but can only view the live Viewer screen.

The ID/password for the guest account is <guest/guest>, which cannot be changed.

`

• Authentication setup : If you select <Enable RTSP connection without
authentication>, you can access RTSP without logging in and view the video.

• Current users : If you select <Use>, you can set or change the user permissions.

The administrator can set the audio input, audio output, alarm output and PTZ control permissions.

`

Profile : If you select <Default>, you can only see the default profile video; if selecting <All>, you

`

can see the full profile videos.

ONVIF functions available to a registered user allowed to use ONVIF functions are limited to those

`

J

of granted with permission.

Video Transfer and Changing Video Information: Set the profile to <All>, and set Audio Input and

`

Audio Output.

Video Transfer, Changing Video Information, Alarm Output : Set the profile to <All>, and select at

`

your preference for the rest.

PTZ control : Select <PTZ>.

`

4. When done, click [Apply (

)].

● SETUP SCREEN

English _67

setup screen

Date & Time

1. From the Setup menu, select the
<Basic ( )> tab.

2. Click <Date & Time>.

3. Specify the time and date that will be

applied to the camera.

• Current system time : Displays the
current time settings of your system.

• Timezone : Specify the local time
zone based on the GMT.

• Use daylight saving time :
If checked, the time will be set one
hour before the local time zone for
the specified time period.
This option will be displayed only in areas where DST is applied.

• System time setup : Specify the time and date that will be applied to your system.

- Manual : Specify the time manually.

- Synchronize with NTP server : Sync with the time of the specified server address.

- Synchronize with PC viewer : Sets to the time of the computer connected.

4. When done, click [Apply (

When you select <Synchronize with PC viewer>, please select the appropriate standard time

`

J

zone for PC and camera.

)].

68_ setup screen

IP & Port

1. From the Setup menu, select the
<Basic ( )> tab.

2. Click <IP & Port>.

3. Set the <IPv4 setup>.

• IP type : Select an IP connection type.

- Manual : Specify the IP address,
Subnet mask, Gateway, DNS1,
and DNS2.

- DHCP : Specify the DNS1 and
DNS2.

- PPPoE : Specify the DNS1, DNS2,
ID and Password.

If you set it to <Manual>, you should

`

specify the IP, Subnet mask, Gateway, DNS 1 & 2 manually.

• MAC address : Shows the MAC address.

• IP address : Displays the current IP address.

• Subnet mask : Displays the <Subnet mask> for the set IP.

• Gateway : Displays the <Gateway> for the set IP.

• DNS1/DNS2 : Displays the DNS(Domain Name Service) server address.

4. Set the <IPv6 setup>.

Set to <Use> to use IPv6 address.

`

• Default : Use the default IPv6 address.

• DHCP : Display and use the IPv6 address obtained from the DHCP server.

• Manual : Enter IP address and gateway manually and use it.

The IP addressing system will be defaulted to DHCP. If no DHCP server is found, the previous

`

J

settings will be restored automatically.

Once completed with editing, click [Apply ( )] to apply changes and the browser exits.

`

After a while, connect again with the changed IP.

● SETUP SCREEN

English _69

setup screen

5. Type in each item in the Port menu as necessary.

Neither the port range between 0 and 1023 nor port 3702 is available.

`

• HTTP : HTTP port used to access the camera via the web browser.
The default is 80(TCP).

Setting the HTTP port for Safari and Google Chrome browsers to 65535 is not allowed by security

`

policy.

• HTTPS : In this version, the security of the web communication protocol HTTP is
strengthened. It can be used when you set HTTPS mode in SSL.
The initial value is set to 443(TCP).

The available setting range is 1024~65535. (For security reasons, in your Safari or Google Chrome

`

browser, you may not use 65535 as your HTTPS port.)

• RTSP : Used to transfer videos in the RTSP mode; the default is 554.

• Use timeout : When connecting to RTSP, this function resets the connection if
there’s no response for a certain time.

• Device port : Set a port used to transfer video signals with the Samsung
protocols.

If changed the HTTP port, the browser exits.

`

M

Afterwards, address should contain the newly assigned HTTP port trailing the IP.
ex) IP address: 192.168.1.100, HTTP port : Assigned 8080  http://192.168.1.100:8080
(If HTTP port is set to 80, no need to specify the port number)

Using RTSP and HTTPS is recommended in order to prevent the image information from being

`

restored.

6. When done, click [Apply (

Event setup

You can easily set the event detection items, and move to the detailed setting.

1. From the Setup menu, select the
<Basic (

2. Click <Event setup>.

3. Activate desired items on the Event list.

4. When done, click [Apply (

)> tab.

)].

)].

To make detailed event settings, click

`

M

on your desired settings. Go to detailed
<Event> setting.

70_ setup screen

PTZ SETUP

Preset setup

You can change the direction of lens and activate the zoom.

1. From the Setup menu, select the <PTZ

(

)> tab.

2. Click <Preset setup>.

3. Click [▼ Show].

4. Click the cursor [

moving pad to control movement of the
screen.

• Move screen: Scroll the cursor in the
direction desired.

• Control screen movement rate: The
further away the cursor is from the
center, the faster it moves on the
screen.

5. Control zoom movement.

• Zoom In: Move up the bar in the right
of the UI, or press the [
The farther the bar is from the center,
the faster the screen expands.

• Zoom Out: Move down the bar in the
right of the UI, or press the [
button. The farther the bar is from the center, the faster the screen reduces in
size.

6. Adjust the focus.

• Manual focus (

• Auto focus (

When performing the sequence action at a high or low temperature, the system may respond

`

J

slower than the set rate for accurate sequence action.

] on the screen

] button.

]

/ ) : The user sets the focus.

) : The system sets the focus automatically.

● SETUP SCREEN

English _71

setup screen

To add the home position

1. Move to a desired start screen point and press [ ].

The point will be set to the home position.

2. Click [

3. When the camera is rebooted after setting, the screen is located at the home

To add a preset

1. Click on the [ ] button.

2. Select the preset number to be added.

3. Set the preset name and click on the [OK] button.

To delete a preset

1. Select the preset number to delete.

2. Press the [

To move to a desired preset

1. Click preset number you want to move in the preset settings.

] in the home position. You will move to the predetermined home position.

position. (If the camera was on another sequence operation, the sequence is
performed.)

] button.

72_ setup screen

To configure the detailed settings for the preset

1. Select the number of preset that you

want to configure.

• After action : For <After action>,
execute the given preset and specifiy
whether to run automatic trace/
automatic execution/ image analysis
motion. (This setting does not apply
in the swing function.)

- Auto tracking : Run the automatic
trace motion until the configured trace time.

- Auto run : The sequence setting for auto execution is performed. If you turn off the
function or if there is no auto-executing operation, the preset operation status is
maintained. (This setting is not applied if preset is run with a group or tour function.)

- Video analysis : MD/VA operation is run.

• Camera setup : You can change the camera setting to the environment of the
selected preset.
Refer to “Camera setup” for how to set the camera. (page 87)

• MD / VA : You can set the system to generate an event signal when a movement
is detected in the preset, or an intelligent video analysis event is detected.
For more details, refer to “MD / VA”. (Page 120)

2. When done, click [Apply (

After saving the preset setting, make sure to select <Sequence Setup> or run the preset. If

`

J

the operation is not performed, the system may run a wrong operation, such as an unintended
change of preset setting.

While setting preset edit, you cannot use the functions, such as preset setting, home position

`

setting and move to the home position.

)].

● SETUP SCREEN

English _73

setup screen

PTZ sequence

1. From the Setup menu, select the <PTZ
( )> tab.

2. Click <PTZ sequence>.

3. Set swing, group, tour, tracing & auto

operation.

To configure the swing settings

Swing is a monitoring function that moves
between two preset points and enables you
to trace the motion.

1. Select <Swing>.
The menu screen will switch to the
swing setting screen.

2. Select a swing setting mode.

• Pan : You can set the swing
monitoring using the PAN function.

• Tilt : You can set the swing
monitoring using the Tilt function.

• Pan&Tilt : You can set the swing monitoring only using both PAN and Tilt
functions.

3. Set <First preset> and <Second preset> to specify a swing range.

When moving to the second preset from the first preset, the camera will move to the right

`

J

direction on the screen.
If you set <Flip/Mirror> to <On> in the video setup, it will move in the opposite direction. (Page 84)

4. Set movement speed and switching time.

5. Press the [

The first preset, the second preset, speed, and switching time are saved in
accordance with the mode.

6. Press the [

It performs the swing operation.

7. Press the [

The running swing will be stop.

If you want to set the swing, then you need at least two presets set already.

`

J

] button.

] button.

] button.

74_ setup screen

To set a group

The group function enables you to group various presets before calling them in sequence.
Six groups can save a total of 128 presets each.

1. Select <Group>.

The menu screen will switch to the
group setting screen.

2. Select a group setting mode.

• Group No. : Select a group number.

• Preset No. : Select a preset number.

• Speed : Specify the speed of
movement.

• Dwell time : Specify the duration for
which an operation is kept at the preset position.

3. Press the [

] button.

Saved in the bottom list.

4. Press the [

] button.

It performs the group operation.

5. Press the [

] button.

The running group will be stop.

6. Press the [

] button.

Selected group data will be deleted.

● SETUP SCREEN

English _75

setup screen

To configure the tour settings

The tour function enables you to call groups of your presets in sequence.

1. Select <Tour>.

The menu screen will switch to the tour
setting screen.

2. Configure the tour settings in detail.

• Group No. : Select a group number.

• Dwell time : Specify a waiting time
before a new group is called.

3. Press the [

Saved in the bottom list.

4. Press the [

It performs the tour operation.

5. Press the [

The running tour will be stop.

6. Press the [

Selected tour data will be deleted.

To set the tracing function

Tracking remembers the trace of movements instructed using the direction button and
reproduces it for your reference.

1. Select <Trace & Auto Run>.

This will bring up the tracing and auto
operation setting menu screen.

2. Select a tracking number.

The operation will be saved with display
of the memory usage. The saving time differs, depending on the level of the PTZ
operation.
If memory is filled to 100% or the recording end configuration is not completed in
2 minutes from the beginning of saving, it will be automatically terminated.

] button.

] button.

] button.

] button.

76_ setup screen

3. Press the [ ] button.

Selected tracing number will be saved.

4. Move the navigation path of saving using the pan/tilt/zoom.

5. Press the [

] button.

Saving is terminated.

6. Press the [

] button.

Selected tracing number will be activated as set.

To set the auto run

This feature will activate the predefined sequence function if the user does not manipulate
anything on the product for a certain time.

1. Select <Trace & Auto Run>.

This will bring up the tracing and auto
operation setting menu screen.

2. Select an auto run mode.

• Home : It is moved to the home
position.

• Preset : It is moved to the selected preset number.

• Swing : Automatically executes the operation in Swing mode.

• Group : Automatically executes the operation in Group mode.

• Tour : Automatically executes the operation in Tour mode.

• Trace : Automatically executes the operation in Trace mode.

• Auto pan : Automatically executes the 360° rotation in the pan direction.
You can designate the tilt angle and speed.

• Schedule: You can set autorun function by day / time. You can set the action in
minutes, and the default setting is home position.

3. Set the start time of autorun. After selecting the mode, select time (5s/10s/20s/30s/

1m/2m/3m/4m/5m).

4. Press the [

] button.

Selected operation will be performed automatically.

● SETUP SCREEN

English _77

setup screen

PT limit

You can specify restrictions on the pan or tilt function.

1. From the Setup menu, select the
<PTZ (

2. Click <PT limit>.

3. Decide if you want to limit the PT

operations. If so, specify the details.

4. Set the Propotional PT mode.
Pan and tilt speed is adjusted according to the zoom magnification. As the zoom
magnification grows, the pan and tilt speed decreases.

)> tab.

• Mode : Select a mode to set
between Pan limit and Tilt limit.

• Use : Select whether to use limit in
set mode.

• Action : PT limiting operation is set.

- [

] : Start limit setting.
] : Provide the start and

- [
end points.

- [

] : If you want to change the point setting, click this to return to the

input dialog.

• Off : Turns off the zoom interworking mode.

• Slow : The manual pan and tilt control speed is changed according to the zoom
magnification. It slows down by 20%.

• Normal : he manual pan and tilt control speed is changed according to the zoom
magnification.

• Fast : the manual pan and tilt control speed is changed according to the zoom
magnification. It speeds up by 20%.

78_ setup screen

Auto tracking setup

You can set up as per setup environment as appropriate to camera auto tracking or
change settings.

1. From the Setup menu, select the
<PTZ (

2. Click <Auto tracking setup>.

3. Set the camera auto tracing action.

)> tab.

• Camera height : Set the height of the
camera.
Height settings as accurate as
possible are needed for correct
operations. (Range: 2.5 m ~ 30 m)

• Zoom : Selects whether to include
Zoom while auto tracking.

• Maintain size : When Zoom selected,
this designates the size step as you
want to maintain within screen for tracked object.

• Indicator display : Sets up whether to display the square indicator that shows
what is tracked on video.

• Area activaction : Sets up whether to activate auto tracking area you have set up.

• Auto mode

- Unlimited : Starts auto tracking without time limit. When an object tracked but
missed, it stands by on the position, and then starts tracking again when a
moving object detected.

- It ends when being unable to detect the object. : It ends auto tracking when the
auto tracking missed an object. At this time, auto tracking does not start even
when an moving object detected.

● SETUP SCREEN

English _79

setup screen

To set the auto tracking area

You can set up the area to be excluded from auto tracking objects. (You can set up to 8
non detection areas.)

1. Click [▼ Show].

2. Mouse-click on the image, and drag to

set the desired area.

3. Enter name, and click [OK].

Under the following conditions, auto

`

M

tracking normally works.

Setup height : At least 2.5 m or

-

over, Up to 30 m and less
Setup type : Level maintained

-

indoor without slope or outdoor
ceiling type
Tracked object : A person who is

-

walking errect and moving on the
horizontal plane (Height about 170 cm)

Camera Height
(2.5 m~30 m)

Target

80_ setup screen

It may be unable to track a target or lead to misoperations under the following situations.

`

J

When multiple moving objects exist in the shot area

-

When it is hidden or overlapped by other moving objects or facilities

-

When there is no little difference between moving object and background

-

An object too small or too large

-

When an object moves too fast or too slow

-

When a moving object passes right below the installed camera

-

When the moving route of a moving object is not the ground with the installed height as its

-

standard
Bad weather such as strong wind, snow and rain

-

When the shot area is dark

-

When any sudden light changes exist

-

When there is light flash toward camera or shot area

-

When there is any light or light reflection toward the camera

-

When video shakes due to camera shaking

-

When lens cover and dimmer cover are stained or wet

-

When there is any change in the axis of camera lens

-

● SETUP SCREEN

English _81

setup screen

RS-485/422

Configure the controller connection so that the camera’s PTZ can be controlled using the
controller connected to the camera’s RS-485/422 terminal.

1. From the Setup menu, select the
<PTZ (

2. Click <RS-485/422>.

3. Click <▼ Show>.

4. Specify the serial port.

The communication protocol used by
the controller connected to the network
camera can be set (RS-485/422).

5. When done, click [Apply (

M

J

)> tab.

• Protocol : Select the same protocol
version as the controller, choosing
from SAMSUNG-T / SAMSUNG-E /
PELCO-D / PELCO-P / PANASONIC
/ HONEYWELL / AD / VICON / GE /
BOSCH.

• Camera ID : Set the camera ID (1-255).

• Baudrate : Set the RS-485/422 communication speed.

)].

For this operation, the network camera and controller must be properly connected. Also, the

`

controller must have a serial port set to control the camera.

There may be functions that are not supported depending on the controller or protocol

`

specifications. Please see the following table for details.

82_ setup screen

Functions Supported for Each Protocol

Zoom

Protocol P control P movement

SAMSUNG-T O O (1~6) O O (1~6) O O (1~4) O O (1~4) O

SAMSUNG-E O O (1~6) O O (1~6) O O (1~4) O X O

PELCO-D O O (1~6) O O (1~6) O X O X O

PELCO-P O O (1~6) O O (1~6) O X O X O

PANASONIC O O (1~6) O O (1~6) O O (1~4) O O (1~4) O

HONEYWELL O O (1~6) O O (1~6) O X O X O

AD O O (1~6) O O (1~6) O x O X O

VICON O O (1~6) O O (1~6) O x O X O

GE O O (1~6) O O (1~6) O O (1~4) O X O

BOSCH O O (1~6) O O (1~6) O O (1~4) O X X

Company Protocol Name Version

AD RS-422/RS-485 Communications REV.B

BOSCH AutoDome Protocol 5/30/11

GE Calibur ImpacNet(RS485 Protocol) REV.4.01(05/21/2004)

HONEYWELL ScanDomeII Protocol V1.05(02/11/2004)

PANASONIC WV-CS950 Protocol VER,4.0

PELCO-D “D” Protocol Ver.4, Rev.1(4/7/2004)

PELCO-P “P” Protocol

SAMSUNG-E Samsung Protocol Ver. 2.3(2006/09)

VICON

speed

T control T movement

Zoom

movement

control

speed

RS-422 Receiver Communications

speed

Protocol

Focus
control

Focus

control

speed

Rev 404(4/08/04)

Preset Remarks

● SETUP SCREEN

English _83

setup screen

VIDEO & AUDIO SETUP

Video setup

1. From the Setup menu, select the
<Video & Audio ( )> tab.

2. Click <Video setup>.

3. Select a <Video source> mode.

• Flip/Mirror : Displays the video from
the camera upside down or reversely.

• Digital Flip : This limits the vertical
screen navigation range of the
camera lens.

4. Click Activate or Inactivate of the analog

video output function.

5. Select the matching <Video type> of

the display equipment.

6. Select the sensor mode.

You can set the number of frames
captured by the CMOS sensor per
second.

Refer to “Video profile” for the framerate setup range of the <Video profile> according to mode

`

M

setup. (Page 61)

You cannot select <WDR> for the <Back light> mode if the sensor mode is 50 fps or 60 fps.

`

7. Specify the privacy zone.

8. When done, click [Apply (

)].

84_ setup screen

To set the privacy zone

You can specify a certain area of the camera video to be protected for your privacy.

1. Set it to <On>.

2. Select the color masking of desired

privacy area.

3. When done, click [Apply (

4. Click [▼ Show].

5. Place the cursor at a point in the video

and drag it to whatever you need.
Move the set area to the center of the
screen by controlling pan/tilt.

6. Check whether the field indicated on

the screen is consistent with the field to
be set and enter the name. When not
using the zoom indication restriction
function, select [Off] and then click on
the [OK] button. If the displayed field
and setting field are different, press on
the [Cancel] button and reset.

7. When using the zoom indication restriction function, select [On] and click on the [OK]

button. The privacy field will be set and a popup will appear. At this time, move to
the zoom position that you wish to set for the zoom operation and click on the [OK]
button. To cancel the privacy field setting, click on the [Cancel] button and reset.

The privacy field can be set only when shaking compensation (DIS, digital image stabilizer) is not used

`

M

and when zoom is under 23x.

Privacy fields that apply zoom indication restriction functions are shown with [ZOOM] following the

`

name.

)].

● SETUP SCREEN

English _85

setup screen

Audio setup

You can configure the I/O settings of the audio source from the camera.

1. From the Setup menu, select the
<Video & Audio (

2. Click <Audio setup>.

3. Set the audio input value.

• Source : Sets the audio input.

- Line : Connect the cable to the
audio device.

- External microphone : 3.5 pi(¢)
mono type external MIC.

• Apply power to Ext. Mic. : If the
external microphone connected has no separate power supply, check this option
to set camera to supply power to the connected external microphone. The option
is enabled if <External microphone> is selected.

• Codec : Specify the audio codec.

- G.711 : A audio codec standard, it uses 64 Kbps PCM (Pulse Code Modulation)
encoding.
ITU standard audio codec that is adequate for digital voice transfer in PSTN
network or through a PBX.

- G.726 : ITU standard audio codec applying ADPCM (Adaptive Differential Pulse
Code Modulation) for variable bit rates of 40/32/24/16 Kbps to 64 Kbps PCM
encoding.

• Bitrate : Set the bit rate to differentiate compression ratio if using G.726 codec.

• Gain : Specify the audio input amplification.

Excessive volume or gain values from the sound source may cause problems such as degradation in

`

M

sound quality or howling.

4. Set the audio output level.

• Enable : Sets whether to use audio output.

• Gain : Set the amplification value for the audio output.

5. When done, click [Apply (

)> tab.

)].

86_ setup screen

Camera setup

You can change the camera settings according to the environment where the camera is
located.

1. From the Setup menu, select the
<Video & Audio (

2. Click <Camera setup>.

3. Configure the settings as necessary

of : SSDR, White balance, Back light,
Exposure, Special, Focus, OSD, IR

4. When done, click [Apply (

If a certain time (timeout: 240s) is elapsed

`

M

with your not pressing the [Apply (
button after changing the settings, your
changes will not be applied.

SSDR (Samsung Super Dynamic Range) Setup

In a scene where the difference between bright and dark is severe, you can increase the
brightness of the dark area alone to regulate the overall brightness.

1. Select <SSDR>.

2. Set <Mode> to <On>.

3. Configure the <Level> setting as

necessary.

• Level : Adjust the level of the dynamic range.

)> tab.

)].

)]

● SETUP SCREEN

English _87

setup screen

White balance Setup

You can correct the image colors based on white under any lighting conditions.

1. Select <White balance>.

2. Select <Mode>.

• ATW : Corrects the colors of the
camera video automatically.
ATW does not work under mercury/sodium lamps.

• Manual : You can adjust the red and blue gains of the camera video manually.

• AWC : Corrects the colors of the camera video to be optimized to the
current lighting condition and screen mode.
To obtain the optimal condition for the current lighting, put the focus of the
camera to a white paper and press the [Set] button. If the lighting environment is
changed, you should readjust the settings accordingly.

• Outdoor : Automatically corrects the video colors of the camera to be
optimized to the outdoor environment.

• Indoor : Automatically corrects the video colors of the camera to be optimized to
the indoor environment.

• MERCURY : The image automatically compensates to the mercury lamp
environment.

• SODIUM : The image automatically compensates to the sodium lamp
environment.

In AWC mode, click the [Set] button if you want to keep the white balance level of the current

`

M

image.

The white balancing may not work properly in the following conditions:

`

J

If this is the case, switch to AWC mode.

If the surrounding condition of the object is out of the temperature correction range

-

ex) Clear sky, sunset
If the surrounding of the object is dark

-

If the focus of the camera directly faces the florescent lighting or if the camera is installed in a

-

place of variable illumination, the white balancing operation may be unstable.

88_ setup screen

BLC Setup

You can specify a desired area on the video manually and set the area to be displayed
more clearly.

1. Select <Back light>.

2. Set <Mode> to <BLC>.

If you select BLC, the Box adjustment
screen and the BLC box step are
displayed on the PTZ Control screen.

3. Select each item and set it properly.

• BLC level : You can change the
level to adjust the brightness of the
monitoring area.

• BLC box Mode : Specify the mode of
BLC box.

• Box adjustment : Use the arrow
buttons to adjust the size and position of the BLC Box.

• BLC box Step : Specify the pixel unit for movement. You can use the arrow
buttons of <Box adjustment> to add or reduce the pixels.

HLC (Highlight Compensation) Setup

If a strong light like a streetlamp or vehicle headlight points toward the camera, the area can
be set to be cut off to prevent a saturated area on the monitor.

1. Select <Back light>.

2. Set <Mode> to <HLC>.

3. Select each item and set it properly.

• HLC level : This adjusts the
brightness level to cut off the
highlighted area.

• Mask tone : This adjusts the brightness of the cut-off area.

As the number increases, the color is set to change from dark to white.

`

● SETUP SCREEN

At night operation, this function will be activated only if the incoming highlight exceeds a certain

`

M

area in a low contrast environment.

At night operation, HLC will not function in too a bright or too a dark scene.

`

English _89

setup screen

WDR Setup

You can set to display a sharp image of the objects in a scene where both bright and dark
areas exist.

1. Select <Back light>.

2. Set <Mode> to <WDR>.

3. Select each item and set it properly.

• WDR level : Specify the WDR
sensitivity level.

If WDR mode is active, the shutter mode

`

M

cannot be changed. Data transfer via the network is available at up to 15 fps.

If the WDR mode is active, a moving object can cause an afterimage on the screen.

`

Ex)

<WDR OFF> <WDR ON>

If you select WDR, you may encounter the following problems. So set it to Not Used.

`

J

Unnatural change of colors that cause an unnatural image on the screen

-

Noise on the bright area of the image

-

As the performance of the WDR function may differ depending on the bright-area size of the

`

image, it is recommended to optimize the installation angle for the best performance.

At night operation, this function will be activated only if the incoming highlight exceeds a certain

`

area in a low contrast environment.

Increasing the maximum value may cause an unnatural portion of the image.

`

For the best WDR performance, it is recommended to set the Iris mode to <Auto>.

`

Since the auto focus operation can be repeated depending on the lighting condition if user

`

backlight compensation is used, it is recommended to use the focusing mode of <One Shot AF>
or <Manual>.

90_ setup screen

Exposure Setup

You can adjust the exposure level of the camera.

1. Select <Exposure>.

2. Select each item and set it properly.

• Brightness : Adjust the screen
brightness.

• Minimum shutter : The limit of the
longest exposure time.

Shutter is the mode to set up the range of

`

the sensor exposure time which will specify
the upper and lower limits for the electronic
shutter movement.

The framerate may be reduced in the dark condition if Shutter has a lower value than specified in

`

the Sensor mode.

• Maximum shutter : The limit of the shortest exposure time.

• Anti flicker : Select this feature if you encounter a flickering screen due to a
frequency mismatch with the ambient lighting.

• SSNR : Specify whether you want to remove the noises in the video.

When AGC mode is set to <Off>, SSNR cannot be used.

`

• SSNR level : Adjust the noise reduction level.

• Iris : You can set the camera iris to Auto or Manual to your preference.

- Auto : Automatically sets the iris adaptively to the ambient lighting and shutter
speed.

- Manual : Iris F-No is set manually.

• Iris F-No : If the iris mode is set to Manual, specify the F number of the iris.

As F-No increases, the iris decreases, so the screen is darkened, and as F-No decreases, the

`

screen is brightened.

• AGC : Select AGC Control mode.
Adjust the gain value of the video (that, in particular, was recorded at a low
contrast scene and had a lower brightness level than normal) to control the video
brightness.

If the AGC mode is set to <Off> or <Manual>, you cannot use SSNR and cannot select the

`

<Auto> mode for the Date/Night mode setting.

• AGC level : If the AGC mode is set to Manual, specify one between 0dB and
42dB.

● SETUP SCREEN

English _91

setup screen

Special Setup

1. Select <Special>.

2. Select each item and set it properly.

• DIS : Compensates the image
automatically when it is seen to
shake for stable image output.

Mitigates image blurring that occurs when

`

there is vibration of the camera due to
external factors like wind.

DIS cannot be used if VA/MD and tempering detection are used.

`

Digital zoom cannot be used if DIS is used.

`

• Day/Night : You can switch the mode to adjust the black and white level as well
as the colors.

- Color : Always displays the video in colors.

- B/W : Always displays the video in black and white.

- Auto : Displays in color mode during normal daytime and switches to black and
white mode in a low contrast scene at night.

When the AGC mode of <Exposure> is set to <Off>, automatic day/night mode setting cannot

`

be selected.

• Dwell time : This is the time while each applicable lighting condition is kept in
order to enable the switch between day and night modes.

• Duration : Specify the time interval of lighting at which the sequence operation is
triggered.

• Sharpness mode : Adjust the overall sharpness of the image.
If selecting <On>, you can adjust the sharpness of the image.

• Sharpness level : The higher the level is, the sharper and clearer the outline of the
image becomes.

92_ setup screen

• Color level : Adjust the strength of video color.

• Defog : You can improve images in foggy or cloudy weather.

It is set to <Off> as a default. Specials are used when the video looks blurry in the
foggy weather.

- Off : Fog removal function is not active.

- Auto : Images are compensated automatically according to the amount of fog.

To improve the effects of this function, adjust the <Defog level>.

- Manual : You can set the amount of compensation manually for the image.

Use this function if the image is unclear due to foggy weather.

`

M

If <Auto> is selected for the defog mode, the level is reduced as the fog is reduced.

`

J

If you wish to maintain the fog removal level even when the amount of fog is reduced, select
<Manual>.
Note that the image can be dark if the fog level is high with the amount of fog being small.

`

• Defog level : Adjust the fog removal level.

● SETUP SCREEN

English _93

setup screen

Focus Setup

1. Select <Focus>.

2. Select each item and set it properly.

• Mode

- Manual : The focus will be adjusted
manually according to the zoom
factor.

- Auto : The focus will be adjusted
automatically according to the zoom factor.

- One Shot AF : Auto Focus will be performed once after the zooming operation.

• Digital zoom : Specify the use of digital zoom.

Digital zoom cannot be used if DIS is used.

`

• Digital zoom limit : Specify the limit of the digital zoom.

• Zoom tracking : Specify the focus sync mode with the panning/tilting/zooming
operation.

- Off : Only the zoom lens will work.

- Auto-Track : It will control (detect and correct) the zooming operation to keep
fitting the focus.

- Tracking : The zooming operation will be guided by the focus track.

• Zoom speed : Adjust the zoom tracking speed.

• Init. lens : Reset the lens to prevent the step-out in zoom mode.

• Duration : Specify the frequency of resetting the lens.

You can specify the date of resetting the lens that will perform in auto focus mode. Specify the time

`

between 1 and 7 days, and the resetting will be performed at 24-hour interval starting from the
specified date.

The auto focus function might not work properly under any of the following conditions:

`

J

Bright or flashing lights (ex.- neon sign)

-

Low illumination of the target area

-

Slow-shutter action

-

Dark object

-

Excessive illumination of the target area

-

If a short-distance object and a long-distance object are in the target area

-

If there is no contract gap (sky, wall, etc.)

-

If the camera is taking a picture of a thin horizontal line

-

In the auto focus mode, because the camera focuses on the object at the center of the area, other

`

objects which are not in the center can be out of focus.

94_ setup screen

OSD Setup

1. Select <OSD>.

2. Select each item and set it properly.

• Camera title : Specify whether or
not to display the camera title on the
screen.

You can enter up to 15 characters for the

`

title.

• Camera title X, Y : Specify the
coordinates where the camera title is
displayed on the screen.

• Date & Time : You can set the date and time, and if they should be displayed on
the screen.

• Date & Time X, Y : Set the position of time to be displayed on the screen.

• Weekday overlay : You can display the day on the screen.

• PTZ position : Set the PTZ location on the screen.

• Preset name : Specify whether or not to display preset name on the screen.

• Camera ID : Specify whether or not to display the camera ID number on the screen.

• Azimuth : This function allows you to indicate the azimuth of the field seen in the
current screen.
Eight compass directions appear on the lower right side of the screen, reflecting the
current orientation: E/W/S/N/NE/NW/SE/SW.

A position-adjustable item (Camera title, Date & Time) may not be displayed normally if it overlaps

`

J

with another fixed OSD item.
PTZ position appears on the bottom left of the screen and it cannot move to other area. Use this

`

information when placing other items on the screen.

Setting Azimuth

1. Click [▼ Show].

After pointing the center of the camera

2.

view to the north and pressing the [ ]
button, the corresponding orientation will
be saved as north.

● SETUP SCREEN

English _95

setup screen

IR Setup

1. Select <IR>.

2. Select each item and set it properly.

• IR Mode:

- Off : Turns off IR LED.

- On : Turns on IR LED.
When using, the daytime/nighttime
mode of the special is set to B/W.

- Day/Night : Turns on/off IR according to the day & night mode.
When the mode is set, the day & night mode of the special cannot be set.

- Sensor : Changes the IR and day & night mode according to the light flux
detected by the light sensor.
When the mode is set, the daytime/nighttime mode of the special cannot be
set.

- Timed : Sets the IR usage time.
When the mode is set, the day & night mode of the special cannot be set.

• LED On Level : LED is turned on when the light flux is lower than the LED usage
level. 1 ~ 90 can be set.

• LED Off Level : LED is turned off when the light flux is higher than the LED usage
level. 11 ~ 100 can be set.

• LED On Time : Sets the time when IR will remain turned on.

• LED Max. Power : Sets the highest brightness of IR.

• LED Power Control: Controls screen saturation caused by a nearby object.
If set to <Off>, the LED output is not controlled even when the screen is
saturated.

When you set the IR mode to <On>, the LED comes on and the screen is automatically set to

`

M

black-and-white mode. When you set the IR mode to <Off>, the LED goes off and day-and-night
mode is automatically set.

If the zoom magnification is changed while the IR dimmer is being used, the IR dimmer is

`

interfaced to the zoom magnification.
However, the interface of IR dimmer to zoom magnification may slow down at a low temperature.

If the ambient temperature is too high, IR LED may be forcefully turned off to protect the product.

`

96_ setup screen

Smart codec

Set a desired area of the video incoming from the camera as ROI area and specify the
detection sensitivity for the area.

1. From the Setup menu, select the
<Video & Audio (

2. Click <Smart codec>.

3. Select ROI Area.

• Manual : Specify the ROI area to
monitor manually.

• Face detection : Active if a face is
recognized on the monitoring screen.

Face detection is enabled only if the

`

M

following conditions are met:

-

-

-

Only when a face-detection event is activated can the field of interest be set as face detection.

`

J

For details on face detection events, see ‘”Face detection”. (page 126)

4. Select a quality for the ROI area.

The ROI area will be displayed in the specified quality.

5. If you set the area of interest by <Manual>, then select the desired area with your

mouse and drag it.

You can specify up to 5 distinct areas.

`

6. To cancel all the settings for the area, click the [Clear (

7. When done, click [Apply (

)> tab.

The face is positioned at ±45
degrees to the left or right from
the top.
The effective range of the face rotation is ±30 degrees vertically, and ±60 degrees horizontally.
The minimum size of the face is 20x20 based on the resolution of 320x240.

)] button.

)].

● SETUP SCREEN

The Smart codec will not be active if it is set to <Off> in <Video profile>. (page 61)

`

J

English _97

setup screen

NETWORK SETUP

DDNS

DDNS is an abbreviation of Dynamic Domain Name Service that converts the IP address of
a camera into a general Host Name so that the user can easily remember it.

You can use the DDNS service only if the internet is connected.

`

J

1. From the Setup menu, select the
<Network (

2. Click <DDNS>.

3. Select the <DDNS> connection type.

4. Type in the DDNS items according to

the selected type.

• Samsung DDNS : Select this if you
use the DDNS server provided by
Samsung.

- Product ID : Enter the product ID
that is registered with the Samsung
DDNS service.

- Quick connect : It sets port forwarding automatically when used with a UPnP
(Universal Plug and Play) supporting router.

• Public DDNS : Select one of provided public DDNS servers when you use a public
DDNS server.

- Service : Select desired public DDNS service server.

- Host name : Enter the name of the host that is registered with the DDNS server.

- User name : Enter the user name for the DDNS service.

- Password : Enter the password for the DDNS service.

5. When done, click [Apply (

)> tab.

If you want to use the DDNS service without using a hub that supports the UPnP function,

`

M

click Quick connect, then go to the hub menu and activate port forwarding for your hub.
For more on how to set port forwarding for your hub, refer to “Port Range Forward (Port
Mapping) Setup”. (page 41)

)].

If selected <Quick connect>, be sure to select Samsung DDNS service.

`

J

98_ setup screen

Registering with DDNS

To register your product with the Samsung DDNS

1. Visit the iPOLiS web site

(www.samsungipolis.com) and sign in
with a registered account.

2. From the top menu bar, select <DDNS
SERVICE> - <MY DDNS>.

3. Click [PRODUCT REGISTRATION].

4. Enter the product ID.

You must perform the duplicate check for the

`

ID that you entered.

5. Select a <CLASSIFICATION> and
specify the <MODEL NUMBER>.

6. Specify the product location with a
description if necessary.

7. Click [REGISTRATION].
The product will be added to the
product list that you can check.

● SETUP SCREEN

English _99

setup screen

To connect to the Samsung DDNS in camera setup

1. From the DDNS setup page, set
<DDNS> to <Samsung DDNS>.

2. Provide the <Product ID> that you

registered product ID with the DDNS
site.

3. Click [Apply (
When the connection is successfully
made, you will see the message of
<(Success)> on the screen.

Configuring public DDNS in Camera Settings

1. Open the DDNS settings page and select <Public DDNS> for <DDNS>.

2. Enter the corresponding site’s host name, user name and password.

3. Click [Apply (
If the connection properly establishes, <(Success)> appears.

4. When done, click [Apply (

To use DDNS service properly, both DDNS setup and the router’s port forwarding setup are

`

M

required.
For port forwarding setup, refer to “Port Range Forward (Port Mapping) Setup”. (page 41)

)].

)] button.

)].

100_ setup screen
