WIRELESS MONITORING SYSTEM
User Manual
SEW-3035WN , SEB-1018RW
SPECIFY SERVICE INSTRUCTIONS AND WARRANTY TERMS
FCC NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.
SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
WARNING
Some adult assembly or installation required.
This product contains small parts that may cause choking. Keep small parts away from
children.
This product is NOT intended to replace proper supervision of children.
You MUST check your child’s activity regularly, as this product will not alert parents to silent
activities of a child.
Before using this product, read and follow all instructions contained in this booklet, and
read and follow all instructions and warnings on the product.
To prevent entanglement with adapter cords, NEVER PLACE THE CORD IN OR NEAR A
CRIB OR PLAYPEN. DO NOT place the product or its AC adapter cords within reach of
children.
ALWAYS KEEP THE TRANSMITTER, RECEIVER AND AC ADAPTERS OUT OF REACH OF
CHILDREN.
NEVER use the transmitter or receiver near water, including near a bathtub, sink, laundry
tub, wet basement, etc.
This product is intended for indoor use only.
This product is not intended for use as a medical monitor and its use should not replace
adult supervision.
Check reception regularly. Test monitor before use and after changing camera location.
Always unplug AC adapters from wall outlets and power sources during periods of non-
use.
The wireless signal transfer range may be shortened if there exists an obstacle such
as a concrete wall
Samsung Techwin Co., Ltd. All rights reserved.
Trademark
is the registered logo of Samsung Techwin Co., Ltd.
The name of this product is the registered trademark of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their
respective company.
Restriction
Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no
circumstances, this document shall be reproduced, distributed or changed, partially or
wholly, without formal authorization of Samsung Techwin.
Disclaimer
Samsung Techwin makes the best to verify the integrity and correctness of the contents
in this document, but no formal guarantee shall be provided. Use of this document
and the subsequent results shall be entirely on the user’s own responsibility. Samsung
Techwin reserves the right to change the contents of this document without prior notice.
Wireless
Monitoring System
User Manual
Copyright
©2011
between.
•
•
•
•
•
•
•
•
•
•
•
This device complies with part 15 of the FCC Rules. Operation is subj ect to the following two conditions:
(1) this device may not cause harmful int erference; and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, p ursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equi pment generates, uses, and can radiate radio frequency
energy. If not installed and used in accordance with the instructions, it may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equip ment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the distance between the equipment and the receiver.
- Connect the equipment to outlet on a circuit different from that to which t he receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications no t expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
“This appliance and its antenna must not be collocated or operation in conjunction with
any other antenna or transmitter. A minimum separation distance of 20 cm must be
maintained between the antenna and the person for this appliance to satisfy the RF
exposure requirements."
To prevent overheating, keep the product and AC power adapters away from any
•
direct sunlight and heat sources such as radiators, heat registers, cooking devices
(e.g., stoves and ovens) and other appliances that produce heat (e.g., amplifiers,
televisions and stereos).
Ensure that the product is well ventilated during use. Avoid contact with pillows and
•
furniture that may block ventilation.
Use only the AC adapters provided with the product, as other adapters may damage
•
the product. Plug the adapters only into standard household current (120 volts AC).
Place the AC adapters avoiding pinch points otherwise you can damage the
adapters.
When an AC adapter is plugged into a power source, DO NOT touch the exposed
•
end of the AC adapter’s cord.
Do not use extension cords with the AC power adapters to avoid entanglement.
•
This product should only be serviced by qualified and authorized Samsung service
•
centers.
Images and sounds are transmitted by the product over public airwaves and
•
transmissions may be picked up by other units.
Caution if you use the system to watch a young child, do not place the camera where
•
the child can reach.
When using the system with only battery power and the charge is low, then the
•
picture and or sound may affected.
If this occurs then please connect the AC power adapter and/or replace with new
•
batteries.
If you are using the optional rechargeable battery then plug in the AC power adapter
•
to recharge.
BATTERY WARNING
When using the product in portable mode, check batteries regularly.
DO NOT use the monitor in portable mode when batteries are low.
•
DISPOSE OF OR RECYCLE BATTERIES PROPERLY IN ACCORDANCE WITH
APPLICABLE LAWS, which may vary by location.
•
Insert batteries with the correct polarity.
•
Do not mix new and used batteries.
•
Remove exhausted batteries from the product.
•
Keep all batteries away from children.
•
THERE IS A RISK OF EXPLOSION IF INCORRECT BATTERIES ARE USED.
•
Do not disassemble or modify the battery pack.
•
Do not use batteries if there is any evidence of leakage or deformity.
Contents
GETTING STARTED
Features ……………………………………………………… 4
Getting to know your Monitoring system …………………… 5
INSTALLATION
How to Install ………………………………………………… 9
Viewing Mode Display ………………………………………… 10
MENU OPERATION
Menu Operation ……………………………………………… 11
APPENDIX
Hardware and CD driver installation ………………………… 14
Troubleshooting ……………………………………………… 15
Specifications ………………………………………………… 16
GettinG Started
Features
Samsung’s digital wireless technology provides excellent image quality and clarity.
•
•
Virtually eliminates interference using a secure and private signal
•
Up to 100m/330ft wireless open space transmission range.
The actual range may vary depending on the use environment.
•
Listen in with exceptional sound clarity
•
Safety warning feature on monitor notifies you when the camera is out of range of the
transmitter.
•
System is expandable up to 4 cameras (additional cameras sold separately).
•
Two-way audio communication.
•
Camera temperature display on monitor.
•
Built-in music player with 4 different tunes.
Camera Features
•
VGA resolution camera.
•
Night vision allows for low-light viewing up to 3.0m/10ft .
Performance varies depending on environmental conditions.
•
Built-in microphone and speaker.
•
Camera can be battery operated for true portable wireless operation.
•
Plays up to 4 different tunes activated from monitor.
•
Temperature sensor.
•
Nightlight
Receiver Features
•
3.5” color LCD monitor/receiver with superior image quality.
•
Video/Audio output for viewing on TV/Monitor or recording on VCR/DVD recorder.
•
Rechargeable lithium polymer battery for true portability.
•
Audio level indicator and alarm.
•
Room temperature display.
What’s Included
The system comes with the following components:
Adapter (2EA) USB Cable
RCA Cable CD
User Manual Warranty Card & Quick Guide
Screws (2EA) & Plastic anchor (2EA) Wire Clips (6EA)
Check your package to confirm that you have received the complete system,
including all components shown above.
· English
Getting to know your Monitoring system
SEW-3035
Wireless Receiver
After opening the box, fully charge the monitor before use. After initial charge, recharge as needed.
Front Controls
Receives and sends signals from or to the camera.
Displays video from the camera.
Used to activate the screen saver mode.
Press the [A/M] or [S
on the Micro SD/SDHC card in search mode.
Navigation Controls / Button
Viewing Mode: The following controls are used while watching live video from the camera:
•
Press the [+] or [–] keys to increase or decrease the volume.
•
Press the [A] key to view cameras in automatic switching mode.
•
Press the [M] key to manually switch between cameras.
M
enu Mode: Use the [+/–/A/M] key arrows to navigate in Menu Mode.
LEEP] button again to release the
Used to delete the recorded data
Press the [
Receiver Antenna
3.5” LCD Screen
SLEEP Button
screen saver mode.
Delete Button
] button to confirm the menu selection.
MENU Button
Press to access the receiver menu.
Press the button again to exit.
Navigation Controls/ Button
Use the controls to move and select while in Viewing
Mode and Menu Mode.
Play/Stop
Used to play or stop playing the recorded data.
Microphone
Transmits audio to the camera when Talk Button is
pressed down and held like a walkietalkie.
01
Getting Started
Back Controls
ON
AV
OUT
DC IN 5V
Press to auto record or manual record during monitoring.
Night Light Button
Press to remotely turn on/off the night light on the camera
(for the camera currently being displayed on the LCD screen).
When the night light is on, an indication icon will be
You must have more than one camera configured on the system when using the functions that requires more than one camera.
`
n
displayed on the LCD screen.
Use to hold the receiver onto a table.
Side Controls
Connect the included USB cable to view video from the receiver
Receiver ON and low battery indication
If the LED blinks then the battery charge is low. Please connect
When the Unit is turned on the LED is solid green.
A Green LED shows battery is fully charged.
Connect the included AC power adapter to power and/or
charge the receiver battery (when the receiver is not placed in
Using this feature will disable the LCD screen. The LCD screen will turn back on when the A/V cable is disconnected.
`
n
USB Port (Optional Use)
to the AC power adapter to charge.
Charging Indication LED
A red LED shows battery is charging.
DC 5V Power Input
the optional Charge cradle).
A/M record
Stand lever
on your computer.
Antenna Locking Switch
Slide the switch to unlocking position, the receiver antenna
will pop up.
Then you can adjust the antenna for better signal reception.
Speaker
Produces the sound transmitted from the camera(s).
Belt hanger
When you carry the receiver, use the belt hanger to hold the
receiver onto your belt.
Talk Button
Press down and hold the button to talk back to the camera
currently being displayed on the LCD screen.
Power Slide Switch
Slide the switch to ON or OFF position to switch on/off the
receiver.
SD Memory Card Compartment
Insert SD memory card.
A/V Out Port (Optional)
Connect the included A/V cable to view video from a TV or
monitor, or record transmissions on a DVD recorder/VCR.
· English
Wireless Camera
Front & Back Controls
Sends & receives signals to or from the receiver.
Infrared LED’s provide viewing in no/low light
Receives sounds for the area near the camera, and
transmits sound from the camera to the receiver.
LED is off when there is no rechargeable battery inside
the camera base; the LED is red when the rechargeable
battery pack is charging; the LED turns off when the
n
rechargeable battery is fully charged.
The camera can also be powered using 3 AA batteries (not included) installed in the base. If the camera is plugged in with the AC adapter, the batteries will not be used.
`
The batteries are intended for short term, portable camera use.
Night Light is available only when the camera is paired to the receiver.
`
The IR indicator will be activated in a low contrast scene and cause an increase of the temperature, which may affect the temperature sensor.
`
Camera Antenna
Lens/IR LED Cover
conditions.
Microphone
Charging Indication LED
Night Light Switch
Press to turn the night light ON or OFF.
Alternatively, press the light button on the receiver to
remotely turn the camera light ON or OFF.
Temperature Sensor
Gives an indication of the air temperature where the
camera is placed.
Pairing Button
The pairing button is located on the back of the camera
behind by the stand mount.
DC 5V Power Input
Connect the AC power adapter to the camera.
01
Getting Started
Side Controls
Adjust the sensitivity knob to set the sound alarm
The receiver will beep to alert you when the sound is
Adjust to increase or decrease the level of sensitivity.
Detects light levels where the camera is placed.
Sound Alarm Trigger
sensitivity.
above a preset sound level.
Night vision sensor
To Use The Battery Mode
You can use the battery to power the camera if it’s distant from the power source or if
you want to carry the camera.
This camera has built-in IR LED’s, which provides the camera with the ability to view
`
n
images in no/low light conditions. It is important to use the provided power adapter
(and not the batteries) when using the camera for prolonged periods in low light
conditions, as the built-in IR LED’s will deplete the battery more quickly than regular
daytime use.
Remove the battery cover from the base of the camera.
1.
Insert 3 AA batteries (not included) into the Battery Pack. Make sure to
2.
correctly line up the Positive (+) and negative (-) terminals of the batteries.
Replace the battery pack cover.
3.
When the battery level is low and requires recharging, the LED light will blink
intermittently.
When using the system with only battery power and the charge is low, then the picture
and or sound may affected.
· English
Camera ON/OFF Switch
Turns the camera ON or OFF.
Camera on and low battery indication
Turn on the camera, the LED light will blink green once;
Low battery, the LED will blink repeatedly.
When the camera is turned on, the LED light would
appear green. After 2 seconds, it goes out.
If this occurs then please connect the AC power adapter and/or replace with new
batteries.
If you want to use the product for a longer time than using the default AA battery without
the AC adapter, purchase the optional charging battery (SEA-B100).
If you are using the optional rechargeable battery then plug in the AC power adapter to
recharge
BATTERY WARNING
When using the product in portable mode, check batteries regularly.
DO NOT use the monitor in portable mode when batteries are low.
•
DISPOSE OF OR RECYCLE BATTERIES PROPERLY IN ACCORDANCE WITH
APPLICABLE LAWS, which may vary by location.
•
Insert batteries with the correct polarity.
•
Do not mix new and used batteries.
•
Remove exhausted batteries from the product.
•
Keep all batteries away from children.
•
THERE IS A RISK OF EXPLOSION IF INCORRECT BATTERIES ARE USED.
•
Do not disassemble or modify the battery pack.
•
Do not use batteries if there is any evidence of leakage or deformity.
inStallation
How to Install
Caution if you use the system to watch a young child, do not place the camera where
the child can reach.
Wireless Receiver
Place the receiver in a place that will have clear reception with your camera(s).
1.
Pull out the stand.
2.
Do not pull up the stand lever with an excessive force. Otherwise, it may be broken.
`
n
Wireless Camera
Before you install the camera, carefully plan where and how it will be positioned, and
where you will route the cable that connects the camera to the power adapter.
Before starting permanent installation, verify its performance by observing the image
on the receiver when camera is positioned in the same location/position where it will
be permanently installed and the receiver is placed in the location where it will be used
most of the time.
Installation Warnings
Aim the camera(s) to best optimize the viewing area: Select a location for the camera
that provides a clear view of the area you want to monitor, which is free from dust,
and is not in line-of-sight to a strong light source or direct sunlight.
Avoid installing the camera where there are thick walls or obstructions between the
camera and the receiver.
1.
arefully unpack the camera.
C
If you are installing cameras that did not come with the system, please see the
pairing camera section of this manual for details on installation.
Mount the camera to the wall.
2.
Mark the position of the screw holes on the
wall, and drill holes and insert 2 screws, then
firmly attach the camera to the wall by placing
the stand over the installed screws and
pushing the base downwards.
The camera can also be placed on a flat surface,
`
n
such as a table or shelf, and no mounting
hardware is required.
Adjust the viewing angle of the camera
3.
You can install additional cameras (maximum of 4 cameras).
`
n
When adding cameras that were not included in the original box, you will need to pair
up the cameras with the receiver.
For paring to add a camera, refer to “Pairing”. (Page 13)
How it works in viewing mode
If you want to view the child’s scene (on the camera display) on a larger screen such
as TV or computer monitor, use the provided AV cable to connect the wireless
receiver with the TV.
When using with a TV or computer monitor, the picture may appear to be grainy as
`
n
the camera limits video resolution to VGA.
This is not a product defect. For best performance, use with the TV/Monitor PIP
(Picture in Picture) function.
Check your TV/Monitor product manual to see if this feature is available on your TV/
Monitor.
When connected to the TV or monitor, the receiver will display the message of
`
“A/V monitoring”.
02
Installation
SEW-3035
Viewing Mode Display
Wireless Receiver
Signal Indicator
The signal indicator shows the strength of the signal being received from the
camera. The number of bars in the signal indicator shows the strength of the
signal – One or no bars indicate the signal is poor, and 4 bars indicate a strong
signal.
Camera Number
Indicates the number of camera that is displayed on the current screen. Press
the [M] key on the receiver to switch between available cameras.
To automatically switch between channels, press the [A] key (AUTO).
`
n
For paring to add a camera, refer to “Pairing”. (Page 13)
`
Temperature
Shows the ambient temperature where the wireless camera is installed.
Trigger Alert
Indicates the type of alert when audio is detected on the camera.
Talk
It displays if you press and hold [ ] in the left corner.
Indicates that it is on talking mode.
Night light
If you press [
the wireless camera turns on with the applicable message.
Auto Mute
If you set Auto Mute to <YES>, the applicable message appears on the screen.
SD card status
Indicates when a Micro SD card is inserted.
It displays the recording type if you press record button.
Volume adjustment
The receiver volume can be adjusted by using the [+], [–] keys when viewing a
camera.
Press the [–] key to decrease the volume, and press the [+] key to increase the
volume. When the volume is set to one bar (lowest setting), the volume will be
muted and no sound will be emitted by the device.
The volume adjustment icon will be displayed
during volume changes, and will disappear after 10 seconds of inactivity.
Alarm adjustment
The Trigger Alert volume will be adjusted with the applicable message on the
screen.
Press the [–] key to decrease the volume, and press the [+] key to increase the
volume.
Time/ZO
Displays the time that is set in the current receiver.
Displays zoom size if it sets x2.
] in the wireless receiver or wireless camera, the night light of
OM
No Signal Warnings
You will see the following warning message when the camera is out of range of the
receiver.
The "OUT OF RANGE" message means the receiver cannot access the camera.
Please reposition the camera, or check the camera power.
10
· English
Menu operation
Menu Operation
How to use the buttons to setup
Zoom
Zoom in 1x or 2x of the video image.
In double size mode, press the navigation control
buttons to pan up/down and left/right while viewing
live image.
► ► ► ►
Enter menu
setting
Press [MENU] button to enter the menu setting or exit the menu setting.
1.
Move to other menu by press [A] or [M] key.
2.
Press the [
3.
Adjust option level by [+] or [–] key.
4.
Press the [
5.
Brightness
Adjusts the brightness of the image.
Move to a
menu
] button for option selection mode.
] button to complete.
Select the
menu
Adjust level Save the
change
Power Saving
Enables receiver power save mode (when no activity
on the camera is detected).
The Power Saving Menu is used to turn off the screen
at a predetermined time, to conserve battery power.
After selected time, the monitor will go to a select
screen saver or black screen if blank is selected as
the screen saver.
Power Saving mode will be deactivated by pushing
any key on the front panel of monitor or by higher sound detected by cameras.
If Power Saving mode is deactivated by pushing [A], [M] and [SLEEP], the monitor will
go back to black screen after the time you set if there is no sound trigger during that
time.
If Power Saving mode is deactivated by a sound trigger, the device will go back to
black screen approximately 8 seconds after the last trigger.
Screen Saver
After selected time, the monitor will go to a select
screen saver or black screen if blank is selected as
the screen saver.
11
03
Menu Operation
Auto Mute
Automatically cuts off the audio when there is only
slight environmental noise on the camera side.
Choose <YES> to enable this function.
If auto mute is enabled, the receiver will automatically
mute if there is no audio detected from the camera. If
the audio is detected on the camera, the receiver will
automatically unmute.
Alarm Setting
Sets the time value with HH, MM and select the ON
or OFF to decide alarm or not.
Alert Setting
Select the type of alert when audio is detected on the
camera.
You may select the Vibration or Beep as the trigger
alert manner while something has been detected by
camera side.
Temperature Unit
Select the temperature unit ˚C or ˚F for you option to
show in the screen.
Temperature Alert
Sets the temperature alert range.
When temperature on camera side is out of the set
range, the monitor will be alerted.
12
· English
Date Setting
Sets the year, month, date value to show in the
monitor screen.
Date Format
Sets the date format to show in the monitor screen.
Time Setiing
Sets the time value with hour, minute to show in the
monitor screen.
A/V Out Format
Choose the TV system when outputting the video/
audio to TV, DVR/VCR or other viewing/recording
devices.
Pairing
You can register a wireless camera with the receiver
using the registration menu where you can view the
video of the selected wireless camera.
Pairing The system comes with a camera that has
already been paired with the receiver unit.
The pairing function assigns the camera to a channel
on the wireless receiver. Up to 4 Cameras (each
additional camera sold separately) may be paired,
which each optional camera on its own channel.
If additional cameras are paired, they must each be configured separately.
It is highly recommended to pair the cameras to the receiver before permanently
`
n
mounting the cameras. See the pairing section on this manual for details.
Pairing Camera
Power on and turn the switch to ON.
1.
The power LED for the camera and receiver should be ON.
Press the [ME
2.
Select Pairing menu by pressing [A] or [M] key.
3.
Press the [
Select a channel by pressing the [+] or [–] key.
4.
The receiver will count down from 30~0 sec as showing a message you must
press the pairing button on the camera during this time to successfully pair the
camera.
NU] button on the receiver.
] button to go into the Pairing menu.
Press the [ ] button on the back of the camera.
5.
If not, the receiver will return to the view screen, and no pairing will take place.
Once the camera has been paired, it will be immediately viewable on the
receiver monitor.
Reset
Choose <YES> to reset the receiver to factory
defaults.
All menu settings will be reset.
Camera pairing settings will NOT be affected by
`
n
a reset. The camera will remain paired with the
receiver.
Memory-format
Delete recorded data Choose <YES> to delete all
data.
03
Menu Operation
13
appendix
Hardware and CD driver
installation
Put CD into CD ROM on computer
1.
and click the icon of Install USB
Driver to run installation program.
2.
Click the <Ne
continue
xt >> button to
Select “I accept the terms of the
3.
license agreement” and then press
<Next >> button.
Click the <Browse...> button, select
4.
the destination folder and then press
<Ne
xt >> button.
Press the <Finish> button to
5.
complete the driver program.
After installation is finished, you can
6.
find “W
ireless Monitoring System”
in the Device Manager
It can also work as a wireless
`
n
webcam for MSN Messenger and
SKYPE after installation is complete.
1
· English
Troubleshooting
If you have problems with the system, there is often a quick and simple solution. Please
try the following:
Problem Solution
No picture from a
camera
The picture is
dropping
Audio problems Ensure that the volume on the TV is on.
The picture is or has
become choppy
1.
Check all connections to the camera. Make sure the adapter is plugged in.
2.
Make sure that the cameras and receiver are both ON.
3.
Make sure that the camera is in range of the receiver.
4.
If using the battery adapter, try replacing the batteries.
5.
Make sure the camera and monitor are paired.
Move the camera closer to the receiver.
1.
Try repositioning the camera, receiver or both to improve the reception.
2.
Adjust the monitor antenna to vertical position.
3.
1.
Make sure that there is sound within range of the camera microphone.
2.
If the unit emits a loud screeching noise (feedback), move the camera or
3.
receiver farther apart.
The picture may become choppy when experiencing a lower frame rate
(i.e. 10 frames per second vs. a higher 20 frames per second).
1.
Try moving the camera closer to the receiver.
2.
Remove obstructions between the receiver and camera.
3.
Adjust the monitor antenna to vertical position.
Problem Solution
The Picture appears
to be grainy when
using AV out function
to view on a large
screen TV/Monitor
`
n
The purpose of the AV output is for convenience only. When using with large
screen TV/Monitor, the picture might be grainy as the camera limits video
resolution to VGA.
This is not a product defect.
For best performance use with TV/Monitor PIP (Picture in Picture) function.
1.
Check your TV/Monitor product manual to see if this feature is available on
your TV/Monitor.
View video on a smaller screen TV/Monitor.
2.
Low batteries will cause the supply current to become unstable and will affect the
quality of the video/audio. Please charge the battery fully or replace the batteries for
use for superior video.
04
Appendix
1
Specications
Item Details
Camera
Transmit Frequency Range 2.400GHz~2.4835GHz
Data Rate 2.0 Mbps
Transmitting Power 16dBm (MAX)
Modulation Type GFSK
Transmitting Distance 100m (Line of Sight)
Image Sensor Type 1/4” Color CMOS Image Sensor
Effective Pixels H: 640 V: 480
Image Processing Motion JPEG
Image Resolution / Frame Rate H: 640 V: 480 / 15FPS Max (H: 320, V:240 / 30 fps)
White Balance Auto
Lens 4.9mm / F2.8
Viewing Angle (Diagonal) 50°
Minimum Illumination 2 LUX (without IR LED illumination)
IR LED Type / Night Vision
Range
Power Requirement 5V DC ±10%
Power Consumption
Operating Temperature -10°C ~ 50°C (14°F ~ 122°F)
Operating Humidity 85% RH
Weight
Size(WXHXD)
940nm 3m
500mA MAX (IR LED)
340mA (IR LED)
145.6 g
94 X 148 X 94 mm
Item Details
Receiver
Receiving Frequency Range 2.400GHz~2.4835GHz
Monitor 3.5” Color LCD
Data Rate 2.0 Mbps
Receiving Sensitivity -81dBm
Demodulation Type GFSK with FHSS
Resolution 320 x 240 (RGB)
Viewing Angle H: 120° V: 100°
A/V Output / Resolution VGA /QVGA Optional
Power Requirement 5V DC ±10%
Power Consumption 450mA Max without charging
Operating Temperature -10°C ~ 50°C (14°F ~ 122°F)
Operating Humidity 85% RH
Weight
Size(WXHXD)
No. of cameras supported Max. 4
170 g
75 X 128 X 24.2 mm
1
· English
USA-Federal Communications Commission (FCC)
This device complies with part 15 of the FCC Rules. Operation is subj ect to the following two conditions:
(1) this device may not cause harmful interference; and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, p ursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This eq uipment generates, uses, and can radiate radio frequency
energy. If not installed and used in accordance with the instructions, it may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equip ment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the distance between the equipment and the receiver.
- Connect the equipment to outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications no t expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Samsung Techwin cares for the environment at all product manufacturing stages, and
is taking measures to provide customers with more environmentally friendly products.
The Eco mark represents Samsung Techwin’s devotion to creating environmentally
friendly products, and indicates that the product satisfies the EU RoHS Directive.
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery
return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this
product should not be disposed of with other household waste at the end of their
working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the reference levels in EC Directive
2006/66. If batteries are not properly disposed of, these substances can cause harm
to human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries
from other types of waste and recycle them through your local, free battery return system.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate
collection systems)
This marking on the product, accessories or literature indicates that the product and
its electronic accessories (e.g. charger, headset, USB cable) should not be disposed
of with other household waste at the end of their working life. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please
separate these items from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they can take
these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions
of the purchase contract. This product and its electronic accessories should not be
mixed with other commercial wastes for disposal.
TEMPLATE
This template is used to install
the camera on the wall.
67mm [2.6 inch]
Screw holes for the Camera
installation
CAMERA FRONT
SALES NETWORK
SAMSUNG TECHWIN CO., LTD.
Samsungtechwin R&D Center, 701, Sampyeong-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea, 463-400
TEL : +82-70-7147-8740~60 FAX : +82-31-8018-3745
SAMSUNG TECHWIN AMERICA Inc.
1480 Charles Willard St, Carson, CA 90746, UNITED STATES
Tol Free : +1-877-213-1222 FAX : +1-310-632-2195
www.samsungcctvusa.com
SAMSUNG TECHWIN EUROPE LTD.
Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey,
Surrey, UNITED KINGDOM KT16 OPS
TEL : +44-1932-45-5300 FAX : +44-1932-45-5325
Loading...
