Xeo 10/20/30

Owner’s manual

Hello

Welcome to Dynaudio Xeo.

We’ve taken care of the tech;

you take care of the music.

This is Xeo

9 Introduction 9 Important safety instructions 10 Warning

10 Xeo 10/20/30 speakers 10 Remote control battery

11 Unpacking

11 Removing the protection cap 11 Packaging material 11 Disposal

12 Scope of delivery 13 Connections and control elements

13 Elements on the rear panel 14 Buttons on top of the cabinet (Xeo 10) 14 Remote control

15 Connecting and setting up

15 Positioning and connecting to mains voltage 15 Cloth cover 15 General settings 16 Connecting sources directly 16 Connecting a Bluetooth device 16 Connecting sources via Hub or Connect

17 Operation

17 Switching on

17 Playback of connected sources 17 Playback of a Bluetooth device

18 Fixing the volume

18 Standby 19 Status LEDs on the front

21 Malfunctions 22 Accessories

22 Desk stand 22 Wall bracket 22 VESA100 bracket (Xeo 10/20)

23 Setting up 25 Connection options

26 Division into audio zones 27 Components of the Xeo system 27 The Xeo system 28 Combination examples 30 Declaration of Conformity (EU only) 30 Reminding (USA and Canada only) 31 IC NOTICE 31 MPE Reminding

33 Technical data

Dynaudio Xeo 10/20/30 Introduction

Thank you

for choosing Dynaudio Xeo. Xeo combines the latest wireless technology with impressive sound quality and makes listening to music truly convenient and easy. The next few pages contain important information on connecting the system and its operation to ensure perfect function and the best-possible sound quality. We hope you have a great time listening to your favourite music.

Dynaudio

About this product

The active Xeo 10/20/30 speakers are equipped with powerful integrated ampliers and

allow for the direct connection of various analog and digital audio sources. A Bluetooth

interface enables the operation of Bluetooth devices and plays them back in optimal

sound quality. Optional components like Xeo Hub or Dynaudio Connect enable setting

up a wireless multiroom system without any restrictions to the highest sound quality.

The speakers can be fully controlled with a remote control. The operational state of the

system is indicated by two LEDs on the front.

About this manual

This manual describes the operation of the Xeo 10/20/30 speakers. Information about

the optional Xeo modules (Hub, Connect, Extender, Link) can be found in the Owner´s

manual provided with these modules.

Important safety instructionsDynaudio Xeo 10/20/30

Xeo

The quintessential wireless hi- system

Important safety instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves,

or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug.

USA and Canada only: A polarized plug has two blades with one wider than

the other. A grounding type plug has two blades and a third grounding prong.

The wide blade or the third prong are provided for your safety. If the provided

plug does not t into your outlet, consult an electrician for replacement of the

obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs,

convenience receptacles, and the point where they exit the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. Unplug this apparatus during lightning storms or when unused for long

periods of time.

13. Refer all servicing to qualied service personnel. Servicing is required when

the apparatus has been damaged in any way, such as power supply cord

or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not

operate normally, or has been dropped.

14. WARNING: To reduce the risk of re or electric shock, this apparatus should

not be exposed to rain or moisture and objects lled with liquids, such as

vases, should not be placed on this apparatus.

15. To completely disconnect this equipment from the mains, disconnect the

power supply cord plug from the receptacle.

16. The mains plug of the power supply cord shall remain readily operable.

8 9

Dynaudio Xeo 10/20/30

Warning / Unpacking

Xeo 10/20/30 speakers

RISK OF ELECTRIC SHOCK! DO NOT OPEN!

If the speakers are connected to the mains voltage, a dangerous electrical

voltage is present inside the speakers.

► Use the supplied power cable to connect the speakers to the mains voltage. Make

sure that the power supply cable is not damaged; replace it with a new one if it has

been damaged.

► To reduce the risk of electric shock, do not remove the back panel and never open

the speaker housing. Do not expose the speakers to rain or moisture.

No user serviceable parts inside. Refer servicing to qualied personnel.

► Do not operate defective speakers and disconnect defective speakers from the

mains voltage. Please contact your Dynaudio Xeo distributor if you have any

problems. Distributor addresses can be found on the Internet at dynaudio.com.

Remote control battery

DANGER OF EXPLOSION

Danger of explosion if battery is incorrectly replaced.

► Replace only with the same or equivalent type.

CHEMICAL BURN HAZARD

If the coin/button cell battery is swallowed, it can cause severe internal burns

in just 2 hours and can lead to death.

► If you think batteries might have been swallowed or placed inside any part of the

body, seek immediate medical attention.

UnpackingWarning

After unpacking, make sure the system is complete and check the device and

all accessories for transport damage. Transport damage may be expected if the

packaging is already severely harmed. Do not attempt to start up a damaged

device. If the contents are incomplete or damaged, please contact your Dynaudio

Xeo distributor. Distributor addresses can be found on the Internet at

dynaudio.com.

Removing the protection cap

The tweeter is protected by a cap to prevent damage during transport and unpacking.

► After you have unpacked the speaker, remove the cap by just pulling it straight out.

Packaging material

The packaging has been designed so that it may be reused as long as it has not been

damaged during transport. Keep the packaging and use the original packaging for all

further transport.

Disposal

Disposal of used electrical and electronic equipment (applicable in European

countries with separate collection systems for this equipment)

This symbol on the product or its packaging indicates that the product must not

be treated as household waste. Instead, it must be handed over to the applicable

collection point for the recycling of electrical and electronic equipment. By ensuring this

product is disposed of correctly, you will help prevent potential negative consequences

for the environment and human health. The recycling of materials helps to conserve

natural resources. For more detailed information on recycling this product, please

contact your local authority, community waste disposal ofce, or the shop where you

purchased the product.

1110

Dynaudio Xeo 10/20/30

Scope of delivery / Connections and control elements

Scope of delivery

2 Xeo 10/20/30 speakers

2 Xeo 10/20/30 speaker cloth covers

1 Xeo 10/20/30 remote control

2 power cables (country-specic version, length: 2.5 m)

1 stereo cable (RCA – RCA, length: 1.5 m) (Xeo 10 only)

1 optical cable (Toslink – Toslink, length: 1.5 m) (Xeo 10 only)

1 stereo cable mini jack (3.5 mm – 3.5 mm, length: 1.5 m) (Xeo 10 only)

1 Xeo rst time setup manual (quick guide for installation, not shown)

MUTE ON OFF

Line

Opt

Coax

VOLUME

Line

USB

Opt

Aux

DIRECT

HUB

1 2 3 7

Connections and control elements

This section describes the connections and control elements. Please contact your

Dynaudio Xeo distributor if you have any problems with connection and start-up.

Distributor addresses can be found on the Internet at dynaudio.com.

Elements on the rear panel

The Xeo 10/20/30 set consists of a master and a slave unit. The master unit carries the

audio input interfaces.

Speaker

position

Sound adjustment (depending on the position of the speakers)

• Neutral = with free-standing placement

• Wall = if placed near a wall

• Corner = if placed in a corner

Speaker placement

• Left = left speaker for stereo mode

• Right = right speaker for stereo mode

Speaker

ID/Zone

Position

Speaker

Neutral

Corner

Left

Wall

Right

Red

Green

Blue

Zone

Selection of audio zones: Speakers assigned to different zones can be

controlled separately via the remote control. The zones are identied as Red,

Green, and Blue.

Aux In: To connect an analog audio source to the speaker via mini jack.

Line In

To connect an analog audio source to the speaker via RCA.

Optical In (Toslink):To connect a digital audio source to the speaker.

R L

Aux In Line In

2 3 4

Optical In

Service Mains socket

USB In

For rmware update only.

Mains socket

To connect the speaker to the mains voltage.

II (master unit only)

1312

Dynaudio Xeo 10/20/30

Connections and control elements / Connecting and setting up

MUTE ON OFF

VOLUME

Line

Opt

Aux

DIRECT

Buttons on top of the cabinet (Xeo 10)

Speaker on/off

► Press

signal.

► Press and hold

Input selection

► When switched on, press

Volume control

► Press

volume level. Press and hold for

to switch on the speakers. The Xeo 10 will scan the inputs for a

to switch off the speakers.

to jump to another input.

Bluetooth pairing

or to raise or lower the

► Press and hold both

start pairing (see page 16).

Connecting and setting up

and to

Positioning and connecting to mains voltage

► Position the speaker in the desired location.

– Do not expose the speaker to direct sunlight, heat, or moisture.

– Do not place the speaker near devices with strong electromagnetic radiation or

devices that could be destroyed or damaged by magnetic elds.

► Use the power cable to connect the speaker to the mains voltage.

Tip Xeo 10:

• For easier access, the plate at the bottom of the cabinet can be removed. Use a coin

or screwdriver to loosen the screw and attach the plate after connecting the power

cable.

faster adjustment.

Cloth cover

The cloth cover has been designed so it does not inuence the sound dispersion of the

Remote control

speaker. It is attached to the housing with magnets and may be removed if needed.

Commands will always apply to both of the speakers.

General settings

MUTE Muting the speakers

Line

Opt

Coax

USB

ON/OFF Speaker on/off

HUB

► Press

to mute or unmute the

speakers.

to switch on the speakers.

for standby mode. Press

for at least 5seconds to put the

speakers in sleep mode.

VOLUME Volume control

► Press

or to raise or lower the volume level.

Fixing the volume

► Press

for at least 2seconds to set

a high volume for the speakers (see

page 18).

Reset

► Press

for at least 5seconds to

reset the speakers to the factory

settings.

► In stereo mode:

– Select Left operating mode for the left speaker.

– Select Right operating mode for the right speaker.

► Set the speaker position switch that best describes the speakers´ need for acoustic

compensation.

– Neutral = with free-standing placement

– Wall = if placed near a wall

– Corner = if placed in a corner

► Select the Red, Green, or Blue zone. Select the same zone for the right and left

speakers (for additional information about the audio zones, see page 26).

INPUT Signal source

► Press a button to select the

respective signal source.

selects a Bluetooth device or

►

Hub/Connect.

Controls

Press to control most Bluetooth4.1

compliant devices:

Bluetooth pairing

► Press

for at least 5seconds to

enter pairing mode.

= backward, = play or pause,

=forward

1514

Dynaudio Xeo 10/20/30

Connecting and setting up / Operation

Operation

Connecting sources directly

Aux

Line

► Connect your source cables to one or more of the audio inputs

master speaker (see „Connection options“ on page 13).

After it is turned on, the speaker automatically searches for an audio signal and then

plays it back immediately. If several signal sources are active, one of the signal sources

will be played back.

Tip (Xeo 10):

• For easier access, the plate at the bottom of the cabinet can be removed. Use a coin

or screwdriver to loosen the screw and attach the plate after connecting the power

cable.

Opt

of the

Connecting a Bluetooth device

1. To begin Bluetooth pairing, press and hold both and buttons on either one of

your speakers (Xeo 10). Alternatively, hold Bluetooth on remote for 5 seconds.

– Once available for pairing, the status indicator will blink white and it will be

available for pairing for one minute.

2. Go to settings on your device, nd the Bluetooth sub-menu, and simply pair your

device with your Xeo speaker by selecting Red, Green, or Blue. The speaker will

store your pairing.

Connecting sources via Hub or Connect

Xeo Hub and Dynaudio Connect are optional components that allow you to connect

analog and digital sources and are linked with your Xeospeaker via a wireless, lossless

signal. For further information about the complete Xeo system, please see „The Xeo

system“ on page27.

Switching on

To switch the speakers on from standby mode:

► Press

speaker and press .

– The speakers will automatically search for an active audio signal. If found, the

– If there is no input signal, the speakers will continue scanning the inputs for the

If there is no input signal, the speakers will go into standby mode after a certain period.

on top of one of the speakers (Xeo 10) or point the remote control at a

signal will be output (autoplay function).

next 20minutes and enter sleep mode.

Playback of connected sources

► Once you have connected your Xeo speaker with a direct input, simply choose your

desired source on the remote.

– The speakers will automatically detect the signal and start playback. Master and

slave speaker will connect wirelessly if set in the same zone.

– If no signal is applied to either input, the speakers will continue scanning the

inputs for the next 20minutes and enter sleep mode.

Playback of a Bluetooth device

Once you have paired your device with your Xeo10/20/30, you can connect by

choosing the Xeo10/20/30 from your list of Bluetooth devices.

► Select Bluetooth on the remote control and press play on your Bluetooth device.

Disconnect

► Press and hold to disconnect a connected device or disconnect from the device

directly.

1716

Dynaudio Xeo 10/20/30

Fixing the volume

You can set the speaker to a higher volume using the function to x the volume. This

setting also remains in effect in standby mode. If a signal source is connected to the

Xeo10/20/30 with its own volume control, you have the option to change the output

volume across a broad range with the signal source.

To x the volume:

► Point the remote control at a speaker and press for at least 2 seconds. To undo

xing, press one of the two volume buttons.

Standby

To switch speakers to sleep mode:

► Point the remote control at a speaker and press or press

speakers.

– The speakers will enter sleep mode.

– The speakers also enter sleep mode if there is no audio signal for 20 minutes.

– In this mode, the wireless network is active and all connected units remain

synchronized.

– Sleep mode power consumption is <2 W.

To switch speakers to low-power standby mode:

► Press and hold on the remote control for at least 5seconds.

– The speakers go to low-power standby mode.

– In this mode, the wireless network is disabled and the speakers are not connected

to each other.

– Low-power standby mode power consumption is <0.5 W.

To turn off auto standby:

► Press and hold

Opt

on the remote control for at least 5 seconds.

on top of one of the

Status LEDs on the front

The two LEDs in the upper left corner of the cabinet front indicate the operational state

of the speakers and system with various colours and blinking functions.

On-state Illuminated in blue The speaker is switched on, connected to a Hub or Connect, and an

audio signal is played back.

On-state Slow blinking in blue The speaker is switched on, connected to a Hub or Connect, but an

audio signal cannot be found.

On-state Illuminated in purple The speaker is switched on, connected to a local input, and an audio

signal is played back.

On-state Slow blinking in purple The speaker is switched on, connected to a local input, but an audio

signal cannot be found.

Connection Slow blinking in red There is no active transmitter2)/master or no connection possible.

Search Fast blinking in blue for 20min Searching for an active input.

Synchronization/

Connection

Firmware loading White LED: slow to fast blinking

Volume Fast blinking in blue Volume is being adjusted.

Off-state Illuminated dimly in red Speaker is in standby mode.

Fast blinking in red for 10s System synchronization during no transmitter2)/master connection.

Blue LED is turned off for 0.2s New transmitter

Illuminated in red for 5s Receiver mode is changing.

Illuminated in white Bluetooth connection is established.

Slow blinking in white Speaker is in pairing mode.

Firmware is being loaded.

during the load sequence,

Red LED: illuminated

Mute Fading in and out Speaker is muted.

depending on the resolution of the audio source, 2) Hub, Connect, mobile device, etc.

ID, transmitter2) input, or direct input is selected.

LED blinking code

off Illuminated in

white

Illuminated in

a colour

Slow blinking

(1 or 2 Hz)

Fast blinking

(3 or 4 Hz)

1918

Dynaudio Xeo 10/20/30

Malfunctions

Interruptions, clicking noises, or other audible interference when playing music is usually not caused by radio transmission in the Xeo system. Often, other external causes inuence the transmission quality.

Below are a few tips for improving transmission quality:

1. Position all radio transmitters and receivers away from each other. WLAN devices,

radio receivers, and radio systems may inuence each other if they are too close

together. Test out various locations for each device.

2. Switch off the automatic search function in WLAN devices. WLAN devices and

other radio systems permanently scan for available frequencies, thus sending

signals that could disrupt other radio systems. This automatic search function can

usually be switched off.

3. Xeo technology radio signals can, of course, transmit through walls. However,

walls may consist of very different materials, such as wood breboard, stone, or

even steel. The walls may also contain complex cable installations for electrics,

phones, TVs, and radios, as well as water pipes and air shafts. These can divert

radio signals. This is why you should test different locations for the Xeo Hub,

Extender, and Link and favour the most direct radio path between the Xeo

components.

4. Some electrical devices, such as microwaves, generate strong electromagnetic

elds that could disrupt radio systems. Do not operate such electrical devices near

Xeo components.

You can ask your Dynaudio Xeo distributor for assistance at any time

Or go to dynaudio.com/support to read the FAQ or to contact the Customer Support

Team. Further information can also be found on the Xeo website at dynaudio.com/xeo

2120

Dynaudio Xeo 10/20/30

Accessories / Setting up

Accessories Setting up

Accessories (Xeo 10)

A desk stand or wall brackets extend

the range of applications of your Xeo10

speakers. For further information, please

see the website at dynaudio.com or

contact your Dynaudio distributor.

Distributor addresses can also be found

at dynaudio.com

VESA100 bracket (Xeo 10/20)

VESA is a standard for wall brackets

developed by the Video Electronics

Standards Association. The Xeo10 and

Xeo 20 speakers allow you to mount

brackets according to the VESA100

standard. This means that the screws on

the back plate are spaced 100mm apart.

Desk stand

The Dynaudio desk stand for Xeo10 is

an elegantly designed stand for placing

the speakers on a desk or shelf. A

installation instruction is provided with

the stand.

Wall bracket

The wall bracket allows you to mount the

Xeo10 speakers on the wall.

To mount a VESA100 bracket

(Xeo 10):

1. Loosen the four screws (Torx type)

and unmount the back plate.

2. Keep the back plate for future use.

Follow the instructions provided with

the bracket you want to mount.

Spikes with pointed ends

Xeo 30 oor-standing speakers are

delivered with spikes for permanent

installation on the oor. The pointed ends

of the spikes may result in injuries and

damage delicate oors.

► Pay attention that you do not injure

yourself with the spikes.

► We recommend inserting the spikes

in aluminium feet if you have delicate

oors, such as parquet or laminate.

► Position the speaker in the desired

location.

– Do not expose the speakers to

direct sunlight, heat, or moisture.

– Do not place the speakers

near devices with strong

electromagnetic radiation or

devices that could be destroyed or

damaged by magnetic elds.

2322

Dynaudio Xeo 10/20/30 Connection options

Connection options

► Connect your signal source to the appropriate input on the Xeo10/20/30 speaker.

► Following table gives a selection of signal sources and options for connecting to the Xeospeaker.

Your signal source Signal source

output

Notebook, Mac™, PC

Smartphone, other portable devices Headphones Aux in Jack 3.5 mm – 3.5 mm –

Astell&Kern

PonoPlayer Jack Aux in Jack 3.5 mm – 3.5 mm –

Docking station, network client,

Sonos, Bluesound, etc.

Google Chromecast Audio

Apple AirPort Express Optical Optical In Mini Toslink – Toslink –

Apple TV* Optical Optical In Toslink – Toslink * up to 3

Hard disk, network player,

CD player

Analog radio, digital radio

Analog record player Line out* Line in RCA – RCA * On phono preamplier

Stereo preamplier Pre-out, main out Line in RCA – RCA

Stereo power amplier

Subwoofer Analog output Line in RCA – RCA

AV receiver, AV processor
