Hanna Instruments pH 209R Instruction Manual

Instruction Manual

www.hannainst.com

pH 209 • pH 209R

Bench Top pH Meters

3

2

pH 209 bench-top pH meter is designed for simplicity of use.
It features a large easy-to-read liquid crystal display (LCD) and user

friendly keyboard.
The pH calibration is made simple through the easy-to-operate front

panel knobs for offset and slope adjustment.
A front knob is provided for easy manual temperature compensation of

the pH reading.
pH 209 can also measure ion concentration (ISE) and ORP (Oxidation

Reduction Potential) in the mV range.
The range selection (pH, mV or °C for temperature compensation) is

made simple through the front membrane keyboard.
The large LCD is provided with arrows that quickly and clearly indicate

the selected range.
It is also available the model pH209R with recorder output feature.

GENERAL DESCRIPTION

PRELIMINARY EXAMINATION

Remove the instrument from the packing material and examine it
carefully to make sure that no damage has occurred during shipping.
If there is any damage, notify your dealer.

Each meter is supplied complete with:

• HI 1332B plastic-body combination double-junction refillable
pH electrode with BNC connector and 1m (3.3') cable

• 12 Vdc adapter

• Instruction manual.

Note: Save all packing material until you are sure that the instru-

ment functions correctly. All defective items must be returned in
the original packing with the supplied accessories.

Dear Customer,
Thank you for choosing a Hanna Instruments Product.
Please read this instruction manual carefully before using the instru-

ment.
This manual will provide you with all the necessary information for the

correct use of the instrument, as well as a precise idea of its versatility
in a wide range of applications.

If you need additional technical information, do not hesitate to e-mail
us at [e-mail].

These instruments are in compliance with the directives.

PRELIMINARY EXAMINATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

GENERAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

FUNCTIONAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

OPERATIONAL GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

PH CALIBRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

PH VALUES AT VARIOUS TEMPERATURES . . . . . . . . . . . . . . . . . . . .10

ELECTRODE CONDITIONING & MAINTENANCE . . . . . . . . . . . . . . . . . 11

TEMPERATURE-RESISTANCE CORRELATION

FOR HANNA pH SENSITIVE GLASS . . . . . . . . . . . . . . . . . . . . . . . . 14

ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

ELECTRODE APPLICATION REFERENCE GUIDE . . . . . . . . . . . . . . . . . 21

WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

CE DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . 23

TABLE OF CONTENTS

5

4

FUNCTIONAL DESCRIPTION

Range 0.00 to 14.00 pH

±1999 mV

Resolution 0.01 pH / 1 mV
Accuracy (@20°C) ±0.01 pH / ±1 mV
Typical EMC Deviation ±0.03 pH / ±2 mV
pH Calibration Manual, 2 point, through knobs
Temperature Compensation

Manual from 0 to 100°C (32 to 212°F)

pH Electrode (included)

HI 1332B plastic body, double junction,

refillable, with BNC and 1m (3.3') cable

Analog output 0 to 5V
(pH209R only) 0 to 14 pH / -1999 to +1999 mV

Temperature: always 0

Input Impedance 1012 ohm
Power Supply 12 Vdc adapter (included)
Environment 0 to 50°C (32 to 122°F);

RH max 95% non-condensing

Dimensions 240 x 182 x 74 mm (9.4x7.2x2.9")
Weight approx. 1.0 kg (2.2 lb.)

SPECIFICATIONS

1) Liquid Crystal Display (LCD)

2) pH slope adjustment knob

3) pH offset adjustment knob

4) pH range selection key

5) mV range selection key

6) °C range selection key

7) Temperature setting knob

8) ON/OFF switch

9) Power adapter socket

10) BNC electrode connector

11) Electrode reference socket

12) Analog output (PH209R only)

7

6

4 cm

(1½")

• Press the pH key to display the pH measurement.

• The display shows the pH value of the test solution compensated
for temperature.

If measurements are taken in different samples successively, it is
recommended that the electrode be rinsed thoroughly for better condi­tioning and to eliminate cross-contamination of the sample.

For the rinsing process, it is recommended to use a liberal amount of
the next solution to be measured.

TAKING ORP MEASUREMENTS

pH 209 has the capability to take ORP measurements, using an ORP
electrode. Hanna Instruments offers a variety of ORP electrodes for this
purpose (see accessories). Contact your Dealer for more information.

• Connect the ORP electrode to the meter and
submerge the tip (4 cm / 1½") into the sample
to be tested.

Note: ORP measurements are taken without temperature compensa-

tion.

• Press the mV key to enter the mV mode. Allow a few
minutes for the reading to stabilize.

• The display will indicate the mV value (positive or negative).

AFTER MEASUREMENTS

• Press the ON/OFF switch again to switch the instrument off.

Power connection

Plug the supplied 12 Vdc adapter into the power supply socket (#9
on page 4).

Note: Make sure the mains line is protected by a fuse.

Electrode connection

For combination pH or ORP electrodes (with internal reference)
connect the electrode's BNC to the socket provided (#10 on page 4).

For an electrode with a separate reference, connect the measuring
electrode's BNC to the BNC socket (#10 on page 4) and the reference
electrode's jack to the socket provided (#11 on page 4).

Note: to prevent damage to the electrode, remove the pH electrode

from the solution before turning the meter off.
If the meter is OFF, detach the electrode from the meter before

immersing the electrode in the storage solution.

TAKING pH MEASUREMENTS

Make sure that the instrument has been calibrated for pH before
taking pH measurements.

• Switch the instrument on by pressing the ON/OFF
switch.

• Immerse the electrode tip (4 cm/1½") into the
sample and shake briefly.

• Take the temperature of the solution with a
ChecktempC or a glass thermometer (e.g.25°C).

• Press the °C key to display temperature setting on the LCD and
adjust the temperature knob to display the temperature of the
sample.

4 cm

(1½")

OPERATIONAL GUIDE

9

8

HI 7004 HI 7007

HI 7004

IMPORTANT

The instrument's pH range should be re-calibrated:

• When the meter is new.

• Whenever the pH electrode is replaced.

• At least once a month.

• After use in aggressive chemicals.

• After cleaning procedure and changing the reference electrolyte.

• For greatest accuracy.

INITIAL PREPARATION

Pour small quantities (up to 4cm / 1½" level)
of pH 7.01 (HI 7007) and pH4.01 (HI 7004)
or pH 10.01 (HI 7010) solution into clean
beakers. If possible use plastic beakers to
minimize any EMC interferences.

If you are measuring in the acid range, use pH 4.01 as second
buffer; if you are measuring in the alkaline range, use pH 10.01 as
second buffer.

For accurate calibration, use two bea­kers for each buffer solution; the first
for rinsing the electrode, the second
for calibration. In this way, contami­nation of the buffer is minimized.

Note: The electrode should be submerged approximately 4 cm (1½")

into the solution.

Note: If you need to calibrate to NBS standards, use pH 6.86 (HI

7006) and pH 9.18 (HI 7009) instead of pH 7.01 and 10.01

respectively.

Use a ChecktempC or a glass thermometer as reference.

PROCEDURE

• Switch the instrument on by pressing the
ON/OFF button.

• Rinse and immerse the pH electrode into
pH 7.01 buffer and shake briefly. Wait for
the reading to stabilize.

pH CALIBRATION

• Note the temperature of the buffer solution using
a ChecktempC or a glass thermometer
(e.g.20°C).

• Press the °C key to select temperature setting.

• Adjust the Temperature knob until the LCD shows the noted
temperature.

• Press the pH key to select pH measurement.

• Wait a couple of minutes and adjust the OFFSET knob until
display shows the pH value at the noted temperature (see the pH
versus temperature chart).

• Rinse and immerse the pH electrode in pH 4.01/pH 10.01 buffer
and shake briefly.

• Wait a couple of minutes and adjust the SLOPE knob until
display shows the pH value at the noted temperature (see the pH
versus temperature chart).

• The pH calibration is now complete.

4 cm

(1½")

HI 7007

RINSE

HI 7007

CALIBRATION

11

10

Reference
Filling Hole

Reference
Filling Hole

Sensitive

Wire

Reference

Wire

Reference

Junction

Glass

Bulb

Glass
Bulb

Reference
Junction

Reference
Junction

Reference

Junction

Platinum or
Gold tip

Platinum or

Gold tip

Reference
Wire

Reference
Wire

Sensitive
Wire

Glass Body

pH Electrode

Plastic Body

pH Electrode

Plastic Body

ORP Electrode

Glass Body

ORP Electrode

Reference

Wire

ELECTRODE CONDITIONING

AND MAINTENANCE

PREPARATION

Remove the protective cap.
DO NOT BE ALARMED IF SALT DEPOSITS ARE PRESENT. This is normal
with electrodes and they will disappear when rinsed with water.
During transport tiny bubbles of air may form inside the glass bulb
affecting proper functioning of the electrode. These bubbles can be
removed by "shaking down" the electrode as you would do with a
glass thermometer.
If the bulb and/or junction is dry, soak the electrode in HI 70300
storage solution for at least one hour.

pH VALUES AT VARIOUS TEMPERATURES

Temperature has an effect on pH. The calibration buffer solutions are
affected by temperature changes to a lesser degree than normal
solutions.

For manual temperature calibration please refer to the following chart.

For instance, if the buffer temperature is 25°C, the display should
show pH 4.01, 7.01 or 10.01 at pH 4, 7 or 10 buffers, respectively.

At 20°C, the display should show pH 4.00, 7.03 or 10.06. The meter
reading at 50°C will then be 4.06, 6.98 or 9.82.

Note: to prevent damage to the electrode, remove the pH electrode

from the solution before turning the meter off.
If the meter is OFF, detach the electrode from the meter before

immersing the electrode in the storage solution.

TEMP pH VALUES

°C °F 4.01 6.86 7.01 9.18 10.01

0

5
10
15
20
25
30
35
40
45
50
55
60
65
70

32
41
50
59
68
77
86

95
104
113
122
131
140
149
158

4.01

4.00

4.00

4.00

4.00

4.01

4.02

4.03

4.04

4.05

4.06

4.07

4.09

4.11

4.12

6.98

6.95

6.92

6.90

6.88

6.86

6.85

6.84

6.84

6.83

6.83

6.84

6.84

6.85

6.85

7.13

7.10

7.07

7.04

7.03

7.01

7.00

6.99

6.98

6.98

6.98

6.98

6.98

6.99

6.99

9.46

9.39

9.33

9.27

9.22

9.18

9.14

9.10

9.07

9.04

9.01

8.99

8.97

8.95

8.93

10.32

10.24

10.18

10.12

10.06

10.01

9.96

9.92

9.88

9.85

9.82

9.79

9.77

9.76

9.75

13

12

Follow the Storage Procedure above.

CLEANING PROCEDURE

General Soak in HI 7061 general cleaning solution for approxi-

mately 30 minutes.

Removal of films, dirt or deposits on the membrane/junction:

- Protein Soak in HI 7073 protein cleaning solution for 15 min.

- Inorganic Soak in HI 7074 inorganic cleaning solution for 15
minutes.

- Oil/grease Rinse with HI 7077 Oil & Fat cleaning solution.

IMPORTANT: After performing any of the cleaning procedures rinse
the electrode thoroughly with distilled water, refill the reference cham­ber with fresh electrolyte (not necessary for gel-filled electrodes) and
soak the electrode in HI 70300 storage solution for at least 1 hour
before taking measurements.

TROUBLESHOOTING

Evaluate your electrode performance based on the following.

• Noise (Readings fluctuate up and down) could be due to:

– Clogged/Dirty Junction: Refer to the Cleaning Procedure

above.

– Loss of shielding due to low electrolyte level (in refillable

electrodes only): refill with fresh HI 7071 for single junction or
HI 7082 for double junction electrodes.

• Dry Membrane/Junction: soak in HI 70300 storage solution for

at least 1 hour.

• Drifting: soak the electrode tip in warm (approx. 50-60°C)

Hanna HI 7082 solution for one hour and rinse the tip with
distilled water. Refill with fresh HI 7071 for single junction
electrodes and HI 7082 for double junction electrodes (refillable
electrodes only).

• Low Slope: refer to the cleaning procedure above.

• No Slope: check the electrode for cracks in glass stem or bulb

and replace the electrode.

• Slow Response/Excessive Drift: soak the tip in HI 7061

solution for 30 minutes, rinse thoroughly in distilled water and
then follow the Cleaning Procedure above.

For refillable electrodes:

If the filling solution (electrolyte) is more than 2½ cm (1") below the
fill hole, add HI 7082 3.5M KCl electrolyte solution for double junction
or HI 7071 3.5M KCl+AgCl electrolyte solution for single junction
electrodes.

For a faster response, unscrew the fill hole screw during measure­ments.

For AmpHel® electrodes:

If the electrode does not respond to pH changes, the battery is run
down and the electrode should be replaced.

MEASUREMENT

Rinse the electrode tip with distilled water. Immerse the tip (bottom 4
cm /1½") in the sample and stir gently for a few seconds.

For a faster response and to avoid cross contamination of the samples,
rinse the electrode tip with a few drops of the solution to be tested,
before taking measurements.

STORAGE

To minimize clogging and assure a quick response time, the glass bulb
and the junction should be kept moist and not allowed to dry out.

Replace the protective cap with a few drops of HI 70300 storage
solution or, in its absence, electrolyte solution (HI 7071 for single
junction, or HI 7082 for double junction electrodes). Follow the
Preparation Procedure above before taking measurements.

NEVER STORE THE ELECTRODE IN DISTILLED OR DEIONIZED WATER.

PERIODIC MAINTENANCE

Inspect electrode and cable. The cable used for connection to the
meter must be intact and there must be no points of broken
insulation on the cable or cracks on the electrode stem or bulb.
Connectors must be perfectly clean and dry. If any scratches or cracks
are present, replace the electrode. Rinse off any salt deposits.

For refillable electrodes:

Refill the reference chamber with fresh electrolyte (HI 7071 for single
junction or HI 7082 for double junction electrodes). Allow the electrode
to stand upright for 1 hour.

15

14

ACCESSORIES

pH CALIBRATION SOLUTIONS

HI 70004P pH 4.01 buffer solution, 20 mL sachet, 25 pcs
HI 70007P pH 7.01 buffer solution, 20 mL sachet, 25 pcs
HI 70010P pH 10.01 buffer solution, 20 mL sachet, 25 pcs
HI 7004L pH 4.01 buffer solution, 500 mL
HI 7006L pH 6.86 buffer solution, 500 mL
HI 7007L pH 7.01 buffer solution, 500 mL
HI 7009L pH 9.18 buffer solution, 500 mL
HI 7010L pH 10.01 buffer solution, 500 mL
HI 8004L pH 4.01 buffer solution in FDA bottle, 500 mL
HI 8006L pH 6.86 buffer solution in FDA bottle, 500 mL
HI 8007L pH 7.01 buffer solution in FDA bottle, 500 mL
HI 8009L pH 9.18 buffer solution in FDA bottle, 500 mL
HI 8010L pH 10.01 buffer solution in FDA bottle, 500 mL

ELECTRODE STORAGE SOLUTION

HI 70300L Storage solution, 500 mL
HI 80300L Storage solution in FDA bottle, 500 mL

ELECTRODE CLEANING SOLUTIONS

HI 70000P Electrode rinsing solution, 20 mL sachet, 25 pcs
HI 7061L General cleaning solution, 500 mL
HI 7073L Protein cleaning solution, 500 mL
HI 7074L Inorganic cleaning solution, 500 mL
HI 7077L Oil & Fat cleaning solution, 500 mL
HI 8061L General cleaning solution in FDA bottle, 500 mL
HI 8073L Protein cleaning solution in FDA bottle, 500 mL
HI 8077L Oil & Fat Cleaning solution in FDA bottle, 500 mL

ELECTROLYTE SOLUTIONS

HI 7071 3.5M KCl + AgCl electrolyte solution, 4 x 30 mL, for

single junction electrodes

HI 7072 1M KNO3 electrolyte solution, 4 x 30 mL
HI 7082 3.5M KCl electrolyte solution, 4 x 30 mL, for double

junction electrodes

HI 8071 3.5M KCl + AgCl electrolyte solution in FDA bottle, 4 x

30 mL, for single junction electrodes

HI 8072 1M KNO3 electrolyte solution in FDA bottle, 4 x 30 mL
HI 8082 3.5M KCl electrolyte solution in FDA bottle, 4 x 30 mL,

for double junction electrodes

Alkaline Error

1.0 Mol L-1 Na

+

0.1 Mol L-1 Na

+

Sodium Ion Correction for the Glass at 20-25°C
Concentration pH Error

13.00

13.50

14.00

12.50

13.00

13.50

14.00

0.10

0.14

0.20

0.10

0.18

0.29

0.40

TEMPERATURE-RESISTANCE CORRELATION

FOR HANNA pH SENSITIVE GLASS

The resistance of glass electrodes partially depends on the temperature.
The lower the temperature, the higher the resistance. It takes longer time
for the reading to stabilize if the resistance is higher. In addition, the
response time will suffer to a greater degree at temperatures below 10°C.

Since the resistance of the pH electrode is in the range of 200 Mohm,
the current across the membrane is in the pico Ampere range. Large
currents can disturb the calibration of the electrode for many hours.

For these reasons high humidity environments, short circuits and
static discharges are detrimental to a stable pH reading.

The pH electrode's life also depends on the temperature. If constantly
used at high temperatures, the electrode life is drastically reduced.

Typical Electrode Life
Ambient Temperature 1- 3 years
90 °C Less than 4 months
120°C Less than 1 month

High concentrations of sodium ions interfere with readings in alkaline
solutions; the pH at which the interference starts to be significant
depends upon the composition of the glass. This interference is the
alkaline error and causes the pH to be underestimated. Hanna's glass
formulations have the indicated characteristics.

-20-2

0

-10

0+10+20+30+40+50+60+70+80+90

°

C

-10

-10

Ω

-10

-10

-10

-10

Ω

2x10

9

1x10

9

2x10

8

1x10

8

2x10

7

1x10

7

-20 -10 0 +10 +20+30+40 +50 +60 +70 +80 +90 °C

17

16

HI 1330B

Glass body, semimicro, single junction, refillable, combination pH
electrode. Use: laboratory, vials.

HI 1331B

Glass body, semimicro, single junction, refillable, combination pH
electrode. Use: flasks.

HI 1230B

Plastic body, double junction, gel-filled, combination pH electrode.
Use: general, field.

HI 2031B

Glass body, semimicro, conic, refillable, combination pH electrode. Use:
semisolid products.

HI 1332B

Plastic body, double junction, refillable, combination pH electrode.
Use: general purpose.

ORP PRETREATMENT SOLUTIONS

HI 7091L Reducing pretreatment solution, 500 mL
HI 7092L Oxidizing pretreatment solution, 500 mL

pH ELECTRODES

All electrodes part numbers ending in B are supplied with a BNC
connector and 1 m (3.3') cable.

HI 1043B

Glass body, double junction, refillable, combination pH electrode.
Use: strong acid/alkali.

HI 1053B

Glass body, triple ceramic, conic shape, refillable, combination pH
electrode. Use: emulsions.

HI 1083B

Glass body, micro, Viscolene, non-refillable, combination pH electrode.
Use: biotechnology, micro titration.

HI 1131B

Glass body, single junction, refillable, combination pH electrode.
Use: general purpose.

120 mm

4.7"

12 mm

0.5"

9.5mm DIA

0.37"

"S" VERSION

HI 1043

120 mm

4.7"

12 mm

0.5"

"S" VERSION

HI 1053

120 mm

4.7

"

12 mm

0.5"

5 mm

0.2"

3 mm

0.12"

3.0 mm DIA

0.12"

HI 1083

120 mm

4.7"

5mm

0.2"

5mm DIA

0.2"

"S" VERSION

HI 1330

120 mm

4.7"

12 mm

0.5"

"

"

HI 1230

75 mm

2.95"

6 mm

0.25"

"

"

HI 2031

120 mm

4.7"

12 mm

0.5"

"S" VERSION

HI 1332

120 mm

4.7"

12 mm

0.5"

9.5mm DIA

0.37"

"S" VERSION

HI 1131

210 mm

8.25"

8 mm

0.3"

7.5mm DIA

0.29"

"S" VERSION

HI 1331

19

18

FC 100B

PVDF body, double junction, refillable, combination pH electrode.
Use: general purpose for food industry.

FC 200B

PVDF body, open junction, conic, Viscolene, non-refillable, combination
pH electrode. Use: meat & cheese.

FC 210B

Glass body, double junction, conic, Viscolene, non-refillable, combina­tion pH electrode. Use: milk, yogurt.

FC 220B

Glass body, triple-ceramic, single junction, refillable, combination pH
electrode. Use: food processing.

FC 911B

PVDF body, double junction, refillable with built-in amplifier, combi­nation pH electrode. Use: very high humidity.

120 mm

4.7"

12 mm

0.5"

FC 100

75 mm

2.95"

6 mm

0.25"

FC 200

120 mm

4.7"

12 mm

0.5"

FC 210

120 mm

4.7"

12 mm

0.5"

9.5mm DIA

0.37"

FC 220

HI 1413B

Glass body, single junction, flat tip, Viscolene, non-refillable, combina­tion pH electrode. Use: surface measurement.

ORP ELECTRODES
HI 3131B

Glass body, refillable, combination platinum ORP electrode.
Use: titration.

HI 3230B

Plastic body, gel-filled, combination platinum ORP electrode.
Use: general purpose.

HI 4430B

Plastic body, gel-filled, combination gold ORP electrode.
Use: general purpose.

110 mm

4.3"

12 mm

0.5"

FC 911

110 mm

4.3"

12 mm

0.5"

HI 1413

150 mm

5.9"

12 mm

0.5"

"S" VERSION

HI 3131

120 mm

4.7"

12 mm

0.5"

HI 3230

"S" VERSION

120 mm

4.7"

12 mm

0.5"

HI 4430

"S" VERSION

21

20

ELECTRODE APPLICATION

REFERENCE GUIDE

Application Electrodes

1. Aquarium HI 1332B, HI 1911B

2. Bath-water HI 1910B, HI 1130B

3. Beer HI 1131B

4. Bread HI 2031B, FC 200B

5. Cheese FC 200B

6. Dairy products FC 911B, FC 100B

7. Dirty water HI 1910B, HI 1912B

8. Emulsions HI 1053B

9. Environment HI1230B

10. Flasks HI 1331B

11. Food industry general use FC 911B, FC 100B

12. Fruit FC 200B, FC 220B

13. Fruit juices, organic FC 210B

14. Galvanizing waste solution HI 1130B, HI 1912B

15. Heavy-duty applications HI 1135B

16. High purity water HI 1053B

17. Horticulture HI 1053B, FC 200B

18. In-line applications HI 1134B, HI 1135B, HI 2114B, HI 2910B

19. Laboratory general use HI 1131B, HI 1230B, HI 1332B, HI 1330B

20. Leather H I1413B

21. Lemon juice FC 100B

22. Meat FC200B, HI 2031B

23. Micro plate sampling of less than HI1083B
100 mL

24. Milk and Yogurt FC 210B

25. Paints HI 1053B

26. Paper HI 1413B

27. Photographic chemicals HI 1230B

28. Quality control HI 1332B

29. Sausages FC 200B, HI 2031B

30. Semisolid products HI 2031B

31. Skin HI 1413B

32. Soil samples HI 1230B

33. Solvents HI 1043B

34. Strong acid HI 1043B

35. Submersion application HI 1130B

36. Surface measurements HI 1413B

37. Swimming pool H I1130B, HI 2114B, HI 2910B

38. Titrations with constant HI 1131B
temperature range

39. Titrations with wide temperature HI 1131B
range

40. Very high humidity FC 911B, HI 1912B, H I 1911B

41. Vials and test tube HI 1330B

42. Wine processing FC 220B

Extension cables for screw-type electrodes (screw to BNC
adapter)
HI 7855/1 Extension cable 1m (3.3') long
HI 7855/3 Extension cable 3m (9.9') long
HI 7855/5 Extension cable 5m (16.5') long
HI 7855/10 Extension cable 10m (33') long

HI 7855/15 Extension cable 15m (49.5') long

OTHER ACCESSORIES

HI 710005 Voltage adapter from 115 Vac to 12 Vdc
HI 710006 Voltage adapter from 230 Vac to 12 Vdc
ChecktempC Pocket-size thermometer (range -50.0 to 150.0°C)
HI 76405 Electrode holder

HI 8427 pH and ORP electrode simulator with 1 m (3.3')

coaxial cable ending in female BNC connectors

HI 931001 pH and ORP electrode simulator with LCD and 1 m

(3.3') coaxial cable ending in female BNC connectors

CONNECT TO
SCREW TYPE

ELECTRODES

CONNECT TO THE

BNC SOCKET

OF THE METER

HI 7855 SERIES CABLE CONNECTORS

CONNECTOR AND 3.0 mm (0.12") CABLE WITH BNC

23

22

CE DECLARATION OF CONFORMITY

Recommendations for Users

Before using this product, make sure that it is entirely suitable for the environment in which it is used.
Operation of this instrument in residential area could cause unacceptable interferences to radio and TV equipment,

requiring the operator to take all necessary steps to correct interferences.
The glass bulb at the end of the electrode is sensitive to electrostatic discharges. Avoid touching this glass

bulb at all times. During calibration of instruments, ESD wrist straps should be worn to avoid possible damage
to the electrode by electrostatic discharge.

To maintain the EMC performance of this equipment, the recommended cables noted in the user's manual
must be used. Any variation introduced by the user to the supplied equipment may degrade the instrument's
EMC performance.

To avoid electrical shock, do not use this instrument when voltages at the measurement surface exceed 24 Vac
or 60 Vdc. To avoid damage or burns, do not perform any measurement in microwave ovens.

WARRANTY

All Hanna Instruments meters are guaranteed for two years
against defects in workmanship and materials when used for their
intended purpose and maintained according to instructions. The

electrodes and the probes are guaranteed for a period of six
months. This warranty is limited to repair or replacement free of

charge.
Damage due to accident, misuse, tampering or lack of prescribed

maintenance are not covered.
If service is required, contact the dealer from whom you purchased the

instrument. If under warranty, report the model number, date of
purchase, serial number and the nature of the failure. If the repair is
not covered by the warranty, you will be notified of the charges
incurred. If the instrument is to be returned to Hanna Instruments, first
obtain a Returned Goods Authorization number from the Customer
Service department and then send it with shipping costs prepaid.
When shipping any instrument, make sure it is properly packaged for
complete protection.

All rights are reserved. Reproduction in whole or in part is prohibited
without the written consent of the copyright owner.

Hanna Instruments reserves the right to modify the design, construction and

appearance of its products without advance notice.

MANPH209R3 07/05

SALES AND TECHNICAL SERVICE CONTACTS

Australia:

Tel. [phone] • Fax [phone]

China:

Tel. [phone] • Fax [phone]

Egypt:

Tel. & Fax [phone]

Germany:

Tel. [phone] • Fax [phone]

Greece:

Tel. [phone] • Fax [phone]

Indonesia:

Tel. [phone] • Fax [phone]

Japan:

Tel. [phone] • Fax [phone]

Korea:

Tel. [phone] • Fax [phone]

Malaysia:

Tel. [phone] • Fax [phone]

Singapore:

Tel. [phone] • Fax [phone]

South Africa:

Tel. [phone] • Fax [phone]

Taiwan:

Tel. [phone] • Fax [phone]

Thailand:

Tel. [phone] • Fax [phone]

United Kingdom:

Tel. [phone] • Fax [phone]

USA:

Tel. [phone] • Fax [phone]

For e-mail contacts and complete list of Sales and
Technical offices, please see www.hannainst.com
