Dear Customer,
Thank you for choosing a Hanna product. This manual will provide you with the necessary
information for the correct use of the instrument. Please read it carefully before using the meter. If
you need additional technical information, do not hesitate to e-mail us at tech@hannainst.com.
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner,
Hanna Instruments Inc., Woonsocket, Rhode Island, 02895 , USA.
3
PRELIMINARY EXAMINATION
Please examine this product carefully. Make sure that the instrument is not damaged. If any
damage occurred during shipment, please notify your Dealer.
Each HI 96734C Ion Selective Meter is supplied complete with:
• Two Sample Cuvets and Caps
• 9V Battery
• Scissors
• Tissue for wiping cuvets
• Instruction Manual
• Instrument Quality Certificate
• Rigid carrying case
Note:Save all packing material until you are sure that the instrument works correctly. Any
defective item must be returned in its original packing.
4
GENERAL DESCRIPTION
The HI 96734 is an auto diagnostic portable microprocessor meter that benefits from Hanna’s
years of experience as a manufacturer of analytical instruments. It has the advanced optical
system based on a special tungsten lamp and a narrow band interference filter that allows most
accurate and repeatable readings. All instruments are factory calibrated and the electronic and
optical design minimizes the need of frequent calibration.
With the powerful CAL CHECK
of your instrument at any time. The validation procedure is extremely user friendly. Just use the
exclusive HANNA ready-made, NIST traceable standards to verify the performance of the
instrument and recalibrate if necessary.
All instruments are splash waterproof and the lamp and filter units are protected from dust or dirt
by a transparent cup. This makes the instruments fulfill field applications. Display messages aid
the user in routine operation. The meter has an auto-shut off feature that will turn off the
instrument after 10 minutes of non use in measurement mode or after 1 hour if left incalibration mode.
The meter uses an exclusive positive-locking system to ensure that the cuvet is in the same
position every time it is placed into the measurement cell. It is designed to fit a cuvet with a
larger neck making it easier to add both sample and reagents. The cuvet is made from special
optical glass to obtain best results.
The HI 96734 meter measures the free and total chlorine (Cl
0.00 to 10.00 mg/L (ppm) range. The method is an adaptation of the USEPA Method 330.5 for
wastewater, and Standard Method 4500-Cl G for drinking water.
The reagents are inpowder and liquid form and are supplied in packets and bottles. The amount
of reagent is precisely dosed to ensure the maximum repeatability.
TM
validation function, you are able to validate good performance
) content in water samples in the
2
ABBREVIATIONS
degree Celsius
°C:
US Environmental Protection Agency
EPA:
degree Fahrenheit
°F:
milligrams per liter. mg/L is equivalent to ppm (part per million)
mg/L:
milliliter
mL:
mV:
millivolts
5
SPECIFICATIONS
RangeFree Cl2 0.00 to 10.00 mg/L
0.00 to 10.00 mg/L
Total Cl
Resolution0.01 mg/L from 0.00 to 3.50 mg/L; 0.10 mg/L above 3.50 mg/L
Precision±0.06 mg/L @ 3.00 mg/L
Typical EMC Deviation ±0.01 mg/L
Light SourceTungsten lamp
Light DetectorSilicon Photocell with narrow band interference filter @ 525nm
MethodAdaptation of the USEPA method 330.5 and Standard Method 4500-Cl G.
Environment0 to 50°C (32 to 122°F); max 95% RH non-condensing
Battery Type1 x 9 volt
Auto-Shut offAfter 10' of non-use in measurement mode;
Dimensions192 x 102 x 67 mm (7.6 x 4 x 2.6")
Weight290 g (10 oz.).
REQUIRED REAGENTS
CodeDescriptionQuantity/test
HI 93701-0Free Chlorine Reagent1 packet
HI 93734B-0Free & Total Chlorine Reagent5 mL
HI 93734C-0Total Chlorine Reagent3 drops
2
The reaction between free chlorine and the DPD reagent causes a pink
tint in the sample.
after 1 hour of non-use in calibration mode;
with last reading reminder.
PRECISION AND ACCURACY
Precision is how closely repeated measurements
agree with each other. Precision is usually
expressed as standard deviation (SD).
Accuracy is defined as the nearness of a test
result to the true value.
Although good precision suggests good accuracy,
precise results can be inaccurate. The figure
explains these definitions.
In a laboratory using a standard solution of 3.00
mg/L chlorine and a representative lot of reagent,
an operator obtained with a single instrument a
standard deviation of 0.06 mg/L.
6
PRINCIPLE OF OPERATION
Absorption of Light is a typical phenomenon of interaction between electromagnetic radiation and
matter. When a light beam crosses a substance, some of the radiation may be absorbed by
atoms, molecules or crystal lattices.
If pure absorption occurs, the fraction of light absorbed depends both on the optical path length
through the matter and on the physical-chemical characteristics of the substance according to the
Lambert-Beer Law:
-log I/I
Where:
-log I/I
=Absorbance (A)
o
Io=intensity of incident light beam
I=intensity of light beam after absorption
ε
=molar extinction coefficient at wavelength λ
λ
c=molar concentration of the substance
d=optical path through the substance
Therefore, the concentration "c" can be calculated from the absorbance of the substance as the
other factors are known.
Photometric chemical analysis is based on the possibility to develop an absorbing compound
from a specific chemical reaction between sample and reagents. Given that the absorption of a
compound strictly depends on the wavelength of the incident light beam, a narrow spectral
bandwidth should be selected as well as a proper central wavelength to optimize measurements.
The optical system of Hanna's HI 96 series colorimeters is based on special subminiature
tungsten lamps and narrow-band interference filters to guarantee both high performance and
reliable results.
= ελ c d
o
or
A = ελ c d
HI 96 series block diagram (optical layout)
7
A microprocessor controlled special tungsten lamp emits radiation which is first optically
conditioned and beamed to the sample contained in the cuvet. The optical path is fixed by the
diameter of the cuvet. Then the light is spectrally filtered to a narrow spectral bandwidth, to
obtain a light beam of intensity Io or I.
The photoelectric cell collects the radiation I that is not absorbed by the sample and converts
it into an electric current, producing a potential in the mV range.
The microprocessor uses this potential to convert the incoming value into the desired measuring
unit and to display it on the LCD.
The measurement process is carried out in two phases: first the meter is zeroed and then the
actual measurement is performed.
The cuvet has a very important role because it is an optical element and thus requires particular
attention. It is important that both, the measurement and the calibration (zeroing) cuvets, are
optically identical to provide the same measurement conditions. Whenever possible use the same
cuvet for both. It is necessary that the surface of the cuvet is clean and not scratched. This to
avoid measurement interference due to unwanted reflection and absorption of light. It is
recommended not to touch the cuvet walls with hands.
Furthermore, in order to maintain the same conditions during the zeroing and the measuring
phases, it is necessary to close the cuvet to prevent any contamination.
FUNCTIONAL DESCRIPTION
INSTRUMENT DESCRIPTION
1) RANGE/GLP/ key
2) CAL CHECK key
3) ZERO/CFM key
4) READ/
5) ON/OFF key
6) Liquid Cristal Display (LCD)
7) Cuvet alignment indicator
8) Cuvet holder
8
/TIMER key
KEYPAD DESCRIPTION
• ON/OFF: to turn the meter on and off.
• ZERO/CFM: to zero the meter prior to measurement, to confirm edited values or to confirm
factory calibration restore.
• READ/
/TIMER: this is a multi-functional key. In measurement mode, press to make a
measurement, or press and hold for three seconds to start a pre-programmed countdown prior
to measurement. In GLP mode press to view the next screen.
• CAL CHECK: this is a bi-functional key. Just press to perform the validation of the meter, or
press and hold for three seconds to enter calibration mode.
• RANGE/GLP/
: this is a multi-functional key. Just press to change the parameter. Press
and hold for three seconds to enter GLP mode. In calibration mode press to edit the date and time.
OPERATING MODES
• Measurement mode: default operation mode, enables both validation and measurement.
• Calibration mode: may be entered by keeping CAL CHECK pressed for three seconds (the
“CAL” tag appears), it enables calibration of the instrument.
• GLP mode: may be entered by keeping RANGE/GLP/
pressed for three seconds (“GLP”
appears), it enables consulting of user calibration date or restore factory calibration.
DISPLAY ELEMENTS DESCRIPTION
5
6
7
4
3
2
1
8
9
10
1) The measuring scheme (lamp, cuvet, detector), appears during different phases of zero or
reading measurement
2) Error messages and warnings
3) The battery icon shows the charging level of the battery
4) The hourglass appears when an internal checking is in progress
5) Status messages
6) The chronometer appears when the reaction timer is running
7) The month, day and date icons appear when a date is displayed
8) Four digit main display
9) Measuring units
10) Four digit secondary display
9
ERRORS AND WARNINGS
The instrument shows clear messages when erroneous condition appears. Messages are also displayed
when the obtained values are outside expected range. The beeper is playing a beep on errors.
a) on zero reading
Light High: There is too much light to perform a measurement.
Please check the preparation of the zero cuvet.
Light Low: There is not enough light to perform a measurement.
Please check the preparation of the zero cuvet.
No Light:The instrument cannot adjust the light level. Please
check that the samples does not contain any debris.
b) on sample reading
Inverted cuvets: The sample and the zero cuvet are inverted.
Zero: A zero reading was not taken. Follow the instructions of
the measurement procedure for zeroing the meter.
10
c) during calibration procedure
Under range: A blinking “0.00” indicates that the sample
absorbs less light than the zero reference. Check the procedure
and make sure you use the same cuvet for reference (zero) and
measurement.
Over Range: A flashing value of the maximum concentration
indicates an over range condition. The concentration of the
sample is beyond the programmed range: dilute the sample and
re-run the test.
Standard Low: The standard reading is less than expected.
Standard High: The standard reading is higher than expected.
d) other errors and warnings
Cap error: Appears when external light enters in the analysis
cell. Assure that the cuvet cap is present.
Cooling lamp: The instrument waits for the lamp to cool down.
11
Battery low: The battery must be replaced soon.
Dead battery: This indicates that the battery is dead and must
be replaced. Once this indication is displayed, the meter will
lock up. Change the battery and restart the meter.
GENERAL TIPS FOR AN ACCURATE MEASUREMENT
The instructions listed below should be carefully followed during testing to ensure best accuracy.
• Color or suspended matter in large amounts may cause
interference, therefore these should be removed by
treatment with active carbon and by prior filtration.
• For a correct filling of the cuvet: the liquid in the cuvet
forms a concavity on the top; the bottom of this concavity
must be at the same level of the 10 mL mark.
• It is important that the sample does not contain any debris.
This would corrupt the reading.
• Each time the cuvet is used, the cap must be tightened to
the same degree.
• Whenever the cuvet is placed into the measurement cell,
it must be dry outside, and completely free of fingerprints,
oil or dirt. Wipe it thoroughly with HI 731318 or a lintfree cloth prior to insertion.
12
• Proper use of dropper:
(a) to get good reproducible results, tap the dropper on the table for several times and wipe
the outside of the dropper with a cloth.
(b) always keep the dropper bottle in a vertical position while dosing the reagent.
(a)(b)
• In order to measure exactly 5 mL of reagent with the 5 mL syringe:
(a) push the plunger completely into the syringe and insert the tip into the reagent bottle.
(b) pull the plunger up until the lower edge of the seal is exactly on the 5 mL mark.
(c) take out the syringe and clean the outside of the syringe tip. Be sure that no drops
are hanging on the tip of the syringe, if so eliminate them. Then, keeping the syringe
in vertical position above the cuvet, push the plunger completely down into the syringe.
Now the exact amount of 5 mL has been added to the cuvet.
(a)(b)(c)
• Proper use of the powder reagent packet:
(a) use scissors to open the powder packet;
13
(b) push the edges of the packet to form a spout;
(c) pour out the content of the packet.
• Shaking the cuvet can generate bubbles in the sample, causing higher readings. To obtain
accurate measurements, remove such bubbles by swirling or by gently tapping the cuvet.
• Do not let the reacted sample stand too long after reagent is added, or accuracy will be lost.
• It is possible to take multiple readings in a row, but it is recommended to take a new zero
reading for each sample and to use the same cuvet for zeroing and measurement.
• After the reading it is important to discard immediately the sample, otherwise the glass
might become permanently stained.
• All the reaction times reported in this manual are referred to 20°C (68°F). As a general rule
of thumb, they should be doubled at 10°C (50°F) and halved at 30°C (86°F).
• In order to maximize accuracy, prior to a measurement follow the validation procedure to
be sure that the instrument is properly calibrated. If necessary, calibrate the instrument.
STARTUP
Prepare the instrument for measurement as follows:
• Unpack the instrument by removing the dust protection sleeve from the instrument cuvet holder.
• Place the battery in the instrument as described in the “BATTERY REPLACEMENT” chapter.
• Place the instrument on a flat table.
• Do not place the instrument under direct sun light.
14
RANGE SELECTION
The HI 96734 can measure Free chlorine when range P1 is selected or Total chlorine when
range P2 is selected. To change the active range follow the procedure:
• Turn the meter on by pressing ON/OFF. The
display briefly shows all tags on.
• After startup, the range identification number is
displayed on the secondary LCD as P1 or P2.
Code Parameter
P1 Free Chlorine
P2Total Chlorine
• Press RANGE/GLP/ to change the range.
The range can be changed any time when the
instrument is in measurement mode.
The selected range is memorized and the selection
remaines unchanged at power off or when the
battery is removed.
MEASUREMENT PROCEDURE
To compensate the meter for the sample turbidity or color, the measurement takes place in two
phases. First, the meter is zeroed using the unreacted sample. After the reagents are added the
reacted sample is measured.
Important note: Free and Total Chlorine have to be measured separately with fresh unreacted
samples if both values are requested.
• Turn the meter on by pressing ON/OFF. The display
briefly shows all tags on.
• When the beeper sounds briefly and the LCD displays
dashes, the meter is ready. The blinking “ZERO” indicates
that the instrument needs to be zeroed first.
15
• Pay attention to the selected range.
To change the range, simply press
RANGE/GLP/ .
• Add to the cuvet 5 mL of HI 93734B-0
reagent by means of the 5 mL syringe.
Note: in order to measure exactly 5 mL
of reagent with the syringe follow the
instructions on page 13.
• Fill the cuvet up to the 10 mL mark with
5 mL of unreacted sample, using the 3
mL plastic pipette.
Note: rinse the 3 mL plastic pipette
several times with sample before adding
it to the cuvet.
• Replace the cap and shake gently for
some seconds.
• Place the cuvet into the cuvet holder and
ensure that the notch on the cap is
positioned securely into the groove.
• Press ZERO/CFM and the lamp, cuvet
and detector icons will appear on the
display, depending on the measurement
phase.
• After a few seconds, the display will show
“-0.0-”. The meter is now zeroed and
ready for measurement.
• Remove the cuvet.
16
• Only in case of total chlorine measurement,
add 3 drops of HI 93734C-0 reagent to
the cuvet.
• For both free and total chlorine, add the
content of one packet of HI 93701-0
Free Chlorine reagent. Replace the cap
and shake gently for 20 seconds (or 2
minutes in case of seawater analysis).
• Replace the cuvet into the cuvet holder
and ensure that the notch on the cap is
positioned securely into the groove.
for Total
Chlorine
only
• Press and hold READ/
three seconds. The display will show the
countdown prior to measurement. The
beeper is playing a beep at the end of
countdown period.
Alternatively, wait for 1 minute for free
chlorine or 2’30’’ for total chlorine and
just press READ/ /TIMER.
In both cases, the lamp, cuvet and detector
icons will appear on the display,
depending on the measurement phase.
• At the end of measurement, the instrument
directly displays concentration in mg/L of
free or total chlorine and the range
number on the LCD.
or acidity above 150 mg/L CaCO3 will not reliably develop the
3
full amount of color or it may rapidly fade. To resolve this, neutralize the sample with diluted
HCl or NaOH.
In case of water with hardness greater than 500 mg/L CaCO
, shake the sample for approximately
3
2 minutes after adding the powder reagent.
VALIDATION PROCEDURE
Use the validation procedure to ensure that the instrument is properly calibrated.
Warning: Do not validate the instrument with any standard solutions other than the HANNA CAL
CHECKTM Standards, otherwise erroneous results will be obtained.
Note: The validation is performed only for the selected parameter. For full validation of the
instrument, the following procedure must be performed for each parameter.
Turn the meter on by pressing ON/OFF.
•
• When the beeper sounds briefly and the
LCD displays dashes, the meter is ready.
TM
• Place the CAL CHECK
Standard
HI 95734-11 Cuvet A into the cuvet
holder and ensure that the notch on the
cap is positioned securely into the groove.
• Press ZERO/CFM and the lamp, cuvet
and detector icons will appear on the
display, depending on the measurement
phase.
18
• After a few seconds, the display will
show “-0.0-”. The meter is now zeroed
and ready for validation.
• Remove the cuvet.
• Place the CAL CHECKTM Standard HI 95734-11
Cuvet B into the cuvet holder and ensure that
the notch on the cap is positioned securely
into the groove.
• Press CAL CHECK
TM
and the lamp, cuvet and
detector icons together with “CAL CHECK” will
appear on the display, depending on the
measurement phase.
• At the end of the measurement the display
will show the validation standard value.
The reading should be within specifications as reported in the CAL CHECK
TM
Standard
Certificate. If the value is found out of the specifications, please check that the cuvets are free
of fingerprints, oil or dirt and repeat validation. If results are still found out of specifications,
then recalibrate the instrument.
CALIBRATION PROCEDURE
Note: It is possible to interrupt calibration procedure at any time by pressing CAL CHECK or
ON/OFF keys.
Warning: Do not calibrate the instrument with standard solutions other than the HANNA CAL
CHECKTM Standards, otherwise erroneous results will be obtained.
When calibrating, only the selected range is affected.
• Turn the meter on by pressing ON/OFF.
19
• When the beeper sounds briefly and the
LCD displays dashes, the meter is ready.
• To change the range, simply press
RANGE/GLP/ .
• Press and hold CAL CHECK for three
seconds to enter calibration mode. The
display will show “CAL” during
calibration procedure. The blinking
“ZERO” asks for instrument zeroing.
TM
• Place the CAL CHECK
Standard
HI 95734-11 Cuvet A into the cuvet
holder and ensure that the notch on the
cap is positioned securely into the groove.
• Press ZERO/CFM and the lamp, cuvet
and detector icons will appear on the
display, depending on the measurement
phase.
• After a few seconds the display will show
“-0.0-”. The meter is now zeroed and
ready for calibration. The blinking “READ”
asks for reading calibration standard.
• Remove the cuvet.
TM
• Place the CAL CHECK
Standard
HI 95734-11 Cuvet B into the cuvet
holder and ensure that the notch on the
cap is positioned securely into the groove.
• Press READ/ /TIMER and the lamp,
cuvet and detector icons will appear on
the display, depending on the
measurement phase.
20
• After measurement the instrument will show
for three seconds the Cal Check Standard value.
Note: If the display shows “STD HIGH”, the
standard value was too high. If the display
shows “STD LOW”, the standard value was
too low. Verify that both CAL CHECK
Standards HI 95734-11 Cuvets, A and B are
free from fingerprints or dirt and that they are
inserted correctly.
Then the date of the last calibration (e.g.:
”01.08.2005”) appears on the display, or
“01.01.2005” if the factory calibration was
selected before. In both cases the year number
is blinking, ready for date input.
DATE INPUT
• Press RANGE/GLP/ to edit the desired
year (2000-2099). If the key is kept
pressed, the year number is automatically
increased.
TM
• When the correct year has been set, press
ZERO/CFM or READ/ /TIMER to
confirm. Now the display will show the
month blinking.
• Press RANGE/GLP/ to edit the desired
month (01-12). If the key is kept pressed
the month number is automatically
increased.
• When the correct month has been set,
press ZERO/CFM or READ/
/TIMER
to confirm. Now the display will show
the day blinking.
or
or
21
• Press RANGE/GLP/ to edit the desired
day (01-31). If the key is kept pressed
the day number is automatically increased.
Note: It is possible to change the editing
from day to year and to month by pressing
READ/ /TIMER.
• Press ZERO/CFM to save the calibration
date.
• The instrument displays “Stor” for one
second and the calibration is saved.
• The instrument will return automatically
to the measurement mode by displaying
dashes on the LCD.
GLP
In the GLP mode, the last user calibration date can be consulted and the factory calibration can
be restored.
LAST CALIBRATION DATE
To display the calibration date:
• Press and hold for three seconds
RANGE/GLP/ to enter GLP mode. The
calibration month and day will appear on
the main display and the year on the
secondary display.
• If no calibration was performed, the
factory calibration message, “F.CAL” will
appear on the main display and the
instrument returns to measurement mode
after three seconds.
22
FACTORY CALIBRATION RESTORE
It is possible to delete the calibration and
restore factory calibration.
• Press and hold for three seconds
RANGE/GLP/ to enter GLP mode.
• Press READ/ /TIMER to enter in the
factory calibration restore screen. The
instrument asks for confirmation of user
calibration delete.
• Press ZERO/CFM to restore the factory
calibration or press RANGE/GLP/ again
to abort factory calibration restore.
• The instrument briefly notifies “done”
when restores factory calibration and
returns to measurement mode.
BATTERY MANAGEMENT
To save battery, the instrument shuts down after 10 minutes of non-use in measurement mode and after
1 hour of non-use in calibration mode.
If a valid measurement was displayed before
auto shut off, the value is displayed when the
instrument is switched on. The blinking “ZERO”
means that a new zero has to be performed.
One fresh battery lasts for around 750 measurements, depending on the light level.
The remaining battery capacity is evaluated at the instrument startup and after each measurement.
The instrument displays a battery indicator with three levels as follows:
• 3 lines for 100 % capacity
• 2 lines for 66 % capacity
• 1 line for 33 % capacity
• Battery icon blinking if the capacity is under 10 %.
If the battery is empty and accurate measurements can’t be taken anymore, the instrument
shows “dead batt” and turns off.
To restart the instrument, the battery must be replaced with a fresh one.
23
BATTERY REPLACEMENT
To replace the instrument’s battery, follow the steps:
• Turn the instrument off by pressing ON/OFF.
• Turn the instrument upside down and remove the battery cover by turning it counterclockwise.
• Extract the battery from its location and replace it with a fresh one.
• Insert back the battery cover and turn it clockwise to close.
ACCESORIES
REAGENT SET
HI 93734-01Reagents for 100 tests
HI 93734-03Reagents for 300 tests
OTHER ACCESORIES
HI 95734-11CAL CHECKTM Standard Cuvets (1 set)
HI 7213109V battery (10 pcs.)
HI 731318Tissue for wiping cuvets (4 pcs.)
HI 731331Glass cuvets (4 pcs.)
HI 731335Caps for cuvets
HI 93703-50Cuvets cleaning solution (230 mL)
24
WARRANTY
HI 96734 is warranted for two years against defects in workmanship and materials when used
for its intended purpose and maintained according to the instructions.
This warranty is limited to repair or replacement free of charge.
Damages due to accident, misuse, tampering or lack of prescribed maintenance are not covered.
If service is required, contact your dealer. If under warranty, report the model number, date of
purchase, serial number and the nature of the failure. If the repair is not covered by the warranty,
you will be notified of the charges incurred.
If the instrument is to be returned to Hanna Instruments, first obtain a Returned Goods Authorization
Number from the Customer Service Department and then send it with shipment costs prepaid.
When shipping any instrument, make sure it is properly packaged for complete protection.
To validate your warranty, fill out and return the enclosed warranty card within 14 days from the
date of purchase.
Recommendations for Users
Before using these products, make sure that they are entirely suitable for your specific application and for the environment in
which they are used.
Operation of these instruments may cause unacceptable interferences to other electronic equipments, this requiring the operator
to take all necessary steps to correct interferences.
Any variation introduced by the user to the supplied equipment may degrade the instruments' EMC performance.
To avoid damages or burns, do not put the instrument in microwave oven. For yours and the instrument safety do not use or
store the instrument in hazardous environments.
Hanna Instruments reserves the right to modify the design, construction and appearance of its
products without advance notice.
25
www.hannainst.com
26
MAN96734 03/06
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
