Hanna Instruments HI 933000 User Manual
Untitled-19
1
Instruction Manual
HI 8033 - HI 8633
HI 8733 - HI 8734
HI 933000
Portable Multi-Range
Conductivity/TDS Meters
mS
H
I 8633 C
onductivity m
COND.
TEMP.
199.9
1999
µS
19.99
mS
TEMPERATURE
µS
1
9
9
.9
m
S
ins
OFF
2
Dear Customer,
Thank you for choosing a Hanna Product. Please read this instruction
manual carefully before using the instrument. It will provide you with
the necessary information for a correct use of the instrument, as well
as a more precise idea of its versatility.
These instruments are in compliance with the
EN 50081-1 and EN 50082-1.
TABLE OF CONTENTSTABLE OF CONTENTS
TABLE OF CONTENTS
TABLE OF CONTENTSTABLE OF CONTENTS
PRELIMINARY EXAMINATION....................................................... 3
GENERAL DESCRIPTION .............................................................. 3
FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI 8033 ......... 4
FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI 8633 ......... 5
FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI 8733 ......... 6
rum
n
s
eter
ON
FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI 8734 ......... 7
FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI 933000 ..... 8
OPERATIONAL GUIDE ................................................................. 9
CALIBRATION........................................................................... 11
CONDUCTIVITY VERSUS TEMPERATURE CHART ........................... 18
TDS VERSUS TEMPERATURE CHART .......................................... 19
DETERMINING THE TEMPERATURE COEFFICIENT OF A SOLUTION
(HI 8733) .............................................................................. 20
PROBE MAINTENANCE.............................................................. 21
BATTERY REPLACEMENT ............................................................ 22
SHOCKPROOF RUBBER BOOTS (for HI 933000 only)................. 23
ACCESSORIES .......................................................................... 23
WARRANTY.............................................................................. 25
CE DECLARATION OF CONFORMITY............................................ 26
directives
http://www.hannainst.com
These Instruments are in
Compliance with the CE Directives
ISO 9000 Certified
Company since 1992
2
Untitled-19
3
PRELIMINARY EXAMINATIONPRELIMINARY EXAMINATION
PRELIMINARY EXAMINATION
PRELIMINARY EXAMINATIONPRELIMINARY EXAMINATION
Remove the instrument from the packing material and examine it
carefully to make sure that no damage has occurred during shipping.
If there is any noticeable damage, notify your Dealer or the nearest
Hanna office immediately.
Each meter is supplied with:
• Conductivity probe with 1m (3.3') cable
• 9V battery.
Note: Save all packing materials until you are sure that the instru-
ment functions correctly. Any damaged or defective item must
be returned in its original packing materials together with the
supplied accessories.
GENERAL DESCRIPTIONGENERAL DESCRIPTION
GENERAL DESCRIPTION
GENERAL DESCRIPTIONGENERAL DESCRIPTION
HI 8033, HI 8633, HI 8733, HI 8734 and HI 933000 are some of
the most complete and versatile portable conductivity/TDS meters
ever manufactured. Designed with utmost precision and simplicity,
these meters provide for up to 3 or 4 measurement ranges. The
conductivity of a solution depends on the temperature and for this
reason measurements are carried out with reference to a standard
temperature of 25°C. If the solution measured has a different temperature than 25°C, compensation must be performed.
HI 8033, HI 8633 and HI 8734 compensate for temperature manually.
HI 8733 and HI 933000, with a built-in temperature sensor and
circuitry, automatically compensate for temperature changes.
With HI 8733, the temperature coefficient is adjustable from 0 to
2.5% per degree Celsius depending on the type of solution tested.
For all the other meters the temperature coefficient is fixed at 2%.
4
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
SPECIFICATIONS OF HI 8033SPECIFICATIONS OF HI 8033
SPECIFICATIONS OF HI 8033
SPECIFICATIONS OF HI 8033SPECIFICATIONS OF HI 8033
mS
1
Conductivity meter
HI 8033
ppm
salinity
0-199,9
0-19,990
CaCO
3
OFF
2
°C
0
10
20
34
30
40
50
ins rum n
1) 3½-digit Liquid Crystal Display
2) Rotary switch
3) Manual temperature compensation knob
4) Calibration knob
Range µS/cm 0.0 to 199.9 / 0 to 1999
mS/cm 0.00 to 19.99
ppm CaCO
TDS 0 to 19990
3
Resolution µS/cm 0.1 / 1
mS/cm 0.01
ppm CaCO
TDS 10
3
Accuracy ±1% Full Scale
(@20°C/68°F) excluding probe error
Typical EMC ±2 % Full Scale
Deviation
Calibration Manual single setpoint through K% knob
Temperature Manual from 0 to 50°C (32 to 122°F)
Compensation with a ß of 2% per degree °C
Probe (included) HI 76301W with 1 m (3.3') screened cable
Environment 0 to 50°C (32 to 122°F);
Battery Type 9 Volt (alkaline)
Life 100 hours of continuous use
Dimensions 185 x 82 x 40 mm (7.3 x 3.2 x1.8")
Weight 355 g (13 oz.)
max 95% RH non-condensing
µS
µS
0-1999
µS
0-19,990
k%
15
10
+
5
0
5
-
10
15
s
3
4
Untitled-19
5
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
SPECIFICATIONS OF HI 8633SPECIFICATIONS OF HI 8633
SPECIFICATIONS OF HI 8633
SPECIFICATIONS OF HI 8633SPECIFICATIONS OF HI 8633
mS
1
ins
HI 8633 Conductivity meter
COND.
3
TEMP.
199.9
µS
4
19.99
mS
5
TEMPERATURE
1) 3½-digit Liquid Crystal Display
2) ON/OFF key
3) Conductivity/temperature selection key
4) Measurement range selection keys
5) Manual temperature compensation knob
6) Calibration trimmer
Range µS/cm 0.0 to 199.9 / 0 to 1999
mS/cm 0.00 to 19.99 / 0.0 to 199.9
Resolution µS/cm 0.1 / 1
mS/cm 0.01 / 0.1
Accuracy 1% Full Scale
(@ 20°C / 68°F) excluding probe error
Typical EMC ±2 % Full Scale
Deviation
Calibration Manual single setpoint through trimmer
Temperature Manual from 10 to 40°C (50 to 104°F)
Compensation with a ß of 2% per degree °C
Probe (included) HI 76301W with 1 m (3.3') screened cable
Environment 0 to 50°C (32 to 122°F);
Battery Type 9 Volt (alkaline)
Life 100 hours of continuous use
Dimensions 185 x 82 x 45 mm (7.3 x 3.2 x1.8")
Weight 355 g (13 oz.)
max 95% RH non-condensing
5
rum n
OFF
1999
199.9
6
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
SPECIFICATIONS OF HI 8733SPECIFICATIONS OF HI 8733
SPECIFICATIONS OF HI 8733
SPECIFICATIONS OF HI 8733SPECIFICATIONS OF HI 8733
mS
1
6
s
ON
2
µS
mS
3
4
1) 3½-digit Liquid Crystal Display
2) ON/OFF key
3) Measurement range selection keys
4) Automatic Temperature Compensation coefficient knob
5) Calibration trimmer
Range µS/cm 0.0 to 199.9 / 0 to 1999
mS/cm 0.00 to 19.99 / 0.0 to 199.9
ins
HI 8733
Conductivity
meter
199.9
µS
19.99
mS
0
0.5
1.51
TEMPERATURE COEFFICIENT
Resolution µS/cm 0.1 / 1
mS/cm 0.01 / 0.1
Accuracy 1% Full Scale
(@ 20°C / 68°F) excluding probe error
Typical EMC ±2 % Full Scale
Deviation
Calibration Manual single setpoint through trimmer
Temperature Automatic from 0 to 50°C (32 to 122°F) with
Compensation an adjustable ß from 0 to 2.5% per degree °C
Probe (included) HI 7633W ATC with 1 m (3.3') screened cable
Environment 0 to 50°C (32 to 122°F);
Battery Type 9 Volt (alkaline)
Life 100 hours of continuous use
max 95% RH non-condensing
Dimensions 185 x 82 x 45 mm (7.3 x 3.2 x1.8")
Weight 355 g (13 oz.)
6
rum n
OFF
1999
199.9
2.5
2
5
s
ON
2
µS
mS
Untitled-19
7
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
SPECIFICATIONS OF HI 8734SPECIFICATIONS OF HI 8734
SPECIFICATIONS OF HI 8734
SPECIFICATIONS OF HI 8734SPECIFICATIONS OF HI 8734
1) 3½-digit Liquid Crystal Display
2) ON/OFF key
3) TDS/temperature selection key
4) Measurement range selection keys
5) Manual temperature compensation knob
6) Calibration trimmer
Range mg/L 0.0 to 199.9 / 0 to 1999
Resolution mg/L 0.1 / 1
Accuracy ±1% Full Scale
(@ 20°C / 68°F) excluding probe error
Typical EMC ±2 % Full Scale
Deviation
Calibration Manual single setpoint through trimmer
Temperature Manual from 0 to 50°C (32 to 122°F)
Compensation with a ß of 2% per degree °C
Probe (included) HI 76301W with 1 m (3.3') screened cable
Environment 0 to 50°C (32 to 122°F);
Battery Type 9 Volt (alkaline)
Life 100 hours of continuous use
Dimensions 185 x 82 x 45 mm (7.3 x 3.2 x1.8")
Weight 355 g (13 oz.)
g/L 0.00 to 19.99
g/L 0.01
max 95% RH non-condensing
8
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &
FUNCTIONAL DESCRIPTION &FUNCTIONAL DESCRIPTION &
SPECIFICATIONS OF HI 933000SPECIFICATIONS OF HI 933000
SPECIFICATIONS OF HI 933000
SPECIFICATIONS OF HI 933000SPECIFICATIONS OF HI 933000
1) 3½-digit Liquid Crystal Display
2) ON/OFF key
3) Measurement range selection keys
4) Probe connector
Range µS/cm 0.0 to 199.9 / 0 to 1999
mS/cm 0.00 to 19.99 / 0.0 to 199.9
Resolution µS/cm 0.1 / 1
mS/cm 0.01 / 0.1
Accuracy 1% Full Scale
(@ 20°C / 68°F) excluding probe error
Typical EMC ±2% Full Scale
Deviation
Calibration Manual single setpoint through
Temperature Automatic from 10 to 40°C (50 to 104°F)
Compensation with a ß of 2% per degree °C
Probe (included) HI 76302W ATC with 1 m (3.3') screened cable
Environment 0 to 50°C (32 to 122°F);
Battery Type 9 Volt (alkaline)
Life 100 hours of continuous use
Dimensions 143 x 80 x 38 mm (5.6 x 3.2 x1.5")
Weight 360 g (13 oz.)
trimmer in the battery compartment
max 95% RH non-condensing
7
8
Untitled-19
9
OPERATIONAL GUIDEOPERATIONAL GUIDE
OPERATIONAL GUIDE
OPERATIONAL GUIDEOPERATIONAL GUIDE
• Each meter is supplied complete with a 9V battery. Slide off the
battery compartment cover on the back of the meter (see page 22).
Install the battery while paying attention to its polarity.
• Connect the probe to the meter securely by aligning the pins with
the socket and pushing the plug in.
With HI 933000, tighten the threaded ring.
• Make sure that the meter has been calibrated before taking any
measurements (see page 11 for calibration procedure).
• Immerse the conductivity probe into the
sample, with the holes on the shaft completely submerged.
If possible, use plastic beakers or containers to minimize any EMC interference.
• Tap the probe lightly on the bottom of the beaker to remove any
air bubbles which may be trapped inside the PVC sleeve.
• Turn the instrument on by pressing the
ON/OFF key or by setting the rotary switch
(for HI 8033 only) to the desired mea-
surement range.
•
For HI 8033, HI 8633 and HI 8734 only:
Take the temperature of the solution with
a ChecktempC or an accurate thermometer.
10
With HI 8633 and HI 8734 press the COND/TEMP key (for
HI 8633) or TDS/TEMP (for HI 8734) to display the temperature
and adjust the temperature knob to that of the solution e.g. 20°C.
• Select the appropriate measurement range.
Note: If the display shows only a "1" on the
•
For HI 8733:
Adjust the TEMPERATURE COEFFICIENT
knob to 2% to compensate for the temperature effect of average solutions (to
determine exact value for a particular solution, see page 20).
•
For HI 8733 and HI 933000:
Wait for a couple of minutes for the temperature sensor to reach
thermal equilibrium with the sample before taking measurements.
When the sample's temperature is lower than 20°C or higher
than 30°C, allow more time for the thermal equilibrium of the
ON
µS
ppm
salinity
0-199,9
0-19,990
CaCO
3
µS
OFF
0-1999
µS
OFF
ON
OFF
0-19,990
°C
system to be achieved.
• After the measurement has been completed, the instrument should
be switched off and the probe should be cleaned and dried (see
"Probe Maintenance" on page 21).
COND.
TEMP.
TDS
TEMP.
far left hand side, the meter is out of
range. Select the next (higher) range.
ºC
TEMPERATURE COEFFICIENT
2.5
0
2
0.5
1.51
With HI 8033 set the temperature knob to
the measured value e.g. 20°C.
9
TEMPERATURE
10
Loading...
