Instruction Manual
HI 9126
Calibration Check
Waterproof
pH/mV/ºC Meter
www.hannainst.com
1
Dear Customer,
Thank you for choosing a Hanna Instruments product.
Please read this instruction manual carefully before using the instrument.
This manual will provide you with the necessary information for correct
use of the instrument, as well as a precise idea of its versatility.
If you need additional technical information, do not hesitate to e-mail
us at tech@hannainst.com.
WARRANTYWARRANTY
WARRANTY
WARRANTYWARRANTY
HI 9126 is guaranteed for two years against defects in workmanship
and materials when used for their intended purpose and maintained
according to instructions. Electrodes and probes are guaranteed for six
months. This warranty is limited to repair or replacement free of charge.
Damage due to accidents, misuse, tampering or lack of prescribed
maintenance is not covered.
If service is required, contact the dealer from whom you purchased the
instruments. If under warranty, report the model number, date of
purchase, serial number and the nature of the problem. If the repair
is not covered by the warranty, you will be notified of the charges
incurred. If the instruments are to be returned to Hanna Instruments,
first obtain a Returned Goods Authorization number from the Technical
Service department and then send it with shipping costs prepaid.
When shipping any instrument, make sure it is properly packed for
complete protection.
TABLE OF CONTENTSTABLE OF CONTENTS
TABLE OF CONTENTS
TABLE OF CONTENTSTABLE OF CONTENTS
WARRANTY .................................................................................. 2
PRELIMINARY EXAMINATION ......................................................... 3
GENERAL DESCRIPTION ................................................................. 3
FUNCTIONAL DESCRIPTION ........................................................... 4
SPECIFICATIONS...........................................................................5
OPERATIONAL GUIDE.................................................................... 6
pH CALIBRATION ....................................................................... 10
pH BUFFER TEMPERATURE DEPENDENCE ....................................... 15
SETUP MENU ............................................................................. 16
mV CALIBRATION .......................................................................18
TEMPERATURE CALIBRATION ....................................................... 18
BATTERIES REPLACEMENT ............................................................ 19
LCD MESSAGE GUIDE .................................................................. 21
TEMPERATURE CORRELATION FOR pH SENSITIVE GLASS................ 22
ELECTRODE CONDITIONING & MAINTENANCE ................................ 23
TROUBLESHOOTING GUIDE ......................................................... 25
ACCESSORIES ............................................................................. 26
2 3
PRELIMINARY EXAMINATIONPRELIMINARY EXAMINATION
PRELIMINARY EXAMINATION
PRELIMINARY EXAMINATIONPRELIMINARY EXAMINATION
Remove the instrument from the packing material and examine it to
make sure that no damage has occurred during shipping.
If there is any damage, notify your dealer or the nearest Hanna
Customer Service Center.
Each meter is supplied with:
• HI 1230B combination double-junction, gel pH electrode
• HI 7662 stainless steel temperature probe with 1 m (3.3’’) cable
• pH 4.01 & pH 7.01 buffer solutions, 20 mL sachet
• HI 700661 electrode cleaning solution
• 100 mL plastic beaker
• 3 x 1.5V AAA Batteries
• Instruction manual
• Rugged carrying case
Note: Save all packing material until you are sure that the instrument
functions correctly. All defective items must be returned in the
original packing with the supplied accessories.
GENERAL DESCRIPTIONGENERAL DESCRIPTION
GENERAL DESCRIPTION
GENERAL DESCRIPTIONGENERAL DESCRIPTION
HI 9126 is a state-of-the-art waterproof, heavy-duty pH meter designed
to provide laboratory results and accuracy under harsh industrial
conditions.
A large multil-level LCD, with clear indications related to the electrode and
instrument status, pH and temperature displayed simultaneously, and
user friendly graphic symbols during calibration.
This meter is provided with a series of new diagnostic features which add
an entirely new dimension to pH measurement, by allowing the user to
dramatically improve the reliability of the measurement:
• 7 memorized buffers (pH 1.68, 4.01, 6.86, 7.01, 9.18, 10.01
and 12.45) for calibration
• Custom calibration (up to two custom buffers)
• Messages on the LCD to make the calibration easy and accurate
• Diagnostic features to alert the user when the electrode needs cleaning
• Monitoring of the electrode aging
• User-selectable “calibration time-out” to remind you when a new
calibration is necessary
HI 9126 can also measure for Oxidation Reduction Potential in the mV
range with a resolution of 0.1 mV.
It offers an extended temperature range from –20 °C (–4 °F) to 120 °C
(248 °F).
GENERAL DESCRIPTION
EGNAR
Hp00.61ot00.2–
Vm9991±/Vm9.996±
)F°0.842ot0.4–(C°0.021ot0.02–
NOITULOSER
Hp10.0
Vm1/Vm1.0
)F°1.0(C°1.0
YCARUCCA
Fº86/Cº02@
Hp10.0±
Vm1±/Vm2.0±
)F°8.0±(C°4.0±
)rorreeborpgnidulcxe(
noitaiveDCMElacipyT
Hp20.0±
Vm1±/Vm2.0±
)F°8.0±(C°4.0±
noitarbilaCHp
sreffubdeziromem7htiw,tniop-2ro1
,81.9,10.7,68.6,10.4,86.1Hp(
sreffubmotsuc2dna)54.21,10.01
noitarbilaCtesffO Hp1±
noitarbilaCepolS %801ot08morF
noitasnepmoCerutarepmeT
(C°0.021ot0.02–morf,citamotuA
launamro)F°0.842ot0.4–
eborperutarepmettuohtiw
edortcelEHp B0321IH )dedulcni(
eborPerutarepmeT 2667IH )dedulcni(
ecnadepmItupnI 01
21
smho
efiL&epyTyrettaB
seirettabezisAAAV5.1x3
esusuounitnocfosruoh002.xorppa
htiwsruoh05(thgilkcabtuohtiw
)thgilkcab
ffo-otuA delbasidrosetunim02:elbatcelesresU
snoisnemiD )”4.1x8.2x3.7(mm63x27x581
thgieW ).zo6.01(g003
tnemnorivnE
)F°221–23(C°05–0
%001HRxam
ytnarraW sraey2
FUNCTIONAL DESCRIPTIONFUNCTIONAL DESCRIPTION
FUNCTIONAL DESCRIPTION
FUNCTIONAL DESCRIPTIONFUNCTIONAL DESCRIPTION
1) Liquid Crystal Display (LCD).
2) RANGE key, to select pH or mV.
3) ON/OFF key, to turn the meter ON and OFF.
4) CAL key, to enter or exit calibration mode.
5) SETUP/CFM key, to enter SETUP mode or to confirm calibration.
6) Battery compartment cap.
7) Temperature probe socket.
8) BNC electrode connector.
9) MR/CUST BUF key, to recall the stored value from memory or
to enter custom buffer values.
10) MEM/CLR key, to store the reading in memory or to clear
calibration.
11)p and q keys, for manual temperature setting, entering
menu parameters or changing buffer value.
12) LIGHT key, toggle to switch the display backlight on and off.
13) Secondary display.
14) Primary display.
4 5
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
OPERATIONAL GUIDEOPERATIONAL GUIDE
OPERATIONAL GUIDE
OPERATIONAL GUIDEOPERATIONAL GUIDE
INITIAL PREPARATION
The meter is supplied with batteries (for details see page 19).
To prepare the instrument for use, connect the pH electrode and the
temperature probe to the BNC and temperature sockets on the top of
the instrument. The temperature probe can be used independently to
take temperature measurements, or it can be used in conjunction
with the pH electrode to utilize the meter's Automatic Temperature
Compensation (ATC) mode. If the probe is disconnected, temperature
can also be set manually with the ARROW keys.
Turn the instrument ON by pressing ON/OFF.
At start-up the display will show all LCD segments and then the
battery percentage while the instrument performs a self check (or as
long as the button is held).
The meter will automatically enter measurement mode.
After measurement switch the meter off. Clean the electrode and store
it with a few drops of HI 70300 storage solution in the protective cap.
To save the batteries, the auto-off feature turns the meter off
after 20 minutes (no button pressed). To disable this feature, see
“Setup Menu” section on page 16.
The LCD will show the pH measurement and the temperature of the
sample.
In order to take more accurate pH measurements, make sure that the
instrument is calibrated (see page 10 for details).
The glass bulb and the junction on your electrode should always be
moist, never allow it to dry out.
If several measurements are taken successively in different samples,
rinse the electrode thoroughly with deionized or tap water and a
small amount of the sample to be measured.
The pH reading is directly affected by temperature. In order for the meter
to measure the pH accurately, temperature must be compensated for. If
the sample temperature is different from the temperature at which the pH
electrode was kept, allow a few minutes for thermal equilibration.
To use the meter's Automatic Temperature Compensation feature,
submerse the temperature probe into the sample as close to the
electrode as possible and wait for a few minutes.
If manual temperature compensation is desired the temperature
probe must be disconnected from the instrument.
The display will show the default temperature of 25 °C, or the last
temperature set the “°C” (or “°F”) indicator will blink.
The temperature can now be adjusted with the ARROW keys.
pH MEASUREMENTS
To take a pH measurement remove the electrode
protective cap and submerse the electrode and
the temperature probe 3 cm (1¼”) into the
sample and stir gently.
If necessary, press the RANGE key until the
display shows pH mode.
Allow time for the reading to stabilize.
6 7
3 cm
(1¼”)
ORP MEASUREMENTS
To perform ORP measurements, connect an optional ORP electrode
(see “Accessories“ section) to the meter and turn it ON.
If necessary, enter the “mV” mode by pressing RANGE.
Submerse the ORP electrode 3 cm (1¼”) into the sample to be tested
and wait for the reading to stabilize.
Measurements within the ±699.9 mV range are displayed with 0.1 mV
resolution, while outside this range the resolution is 1 mV.
Note: While in MEM mode, the user can switch between pH and mV
by pressing the RANGE key.
A stored value can be recalled by pressing MR: the display will show
the memorized reading and the “RECALL MEMORIZED” tag, as
long as the MR key is pressed.
Note: MR will only display the range that was active when MEM was
pressed.
The ATC (or MTC) key is turned off because the mV readings are not
temperature compensated.
For accurate ORP measurements, the surface of the electrode must be
clean and smooth. Pretreatment solutions are available to condition
the electrode and improve the response time (see “Accessories“ section).
Notes:
• When the reading is out of range, the display will flash the closest
full-scale value.
• If using a pH electrode while in mV mode, the meter will measure
the mV generated by the pH electrode.
MEM & MR FUNCTIONS
Pressing the MEM key will memorize the reading on the display and
store it in the internal memory. The pH (mV) and temperature,
electrode condition and the buffers used for calibration will be stored.
The “MEMORIZE” tag blinks and the display remains frozen until the
MEM key is pressed again.
BACKLIGHT FEATURE
The meter is provided with a Backlight feature,
which can be easily accessed through the LIGHT
key.
Note: The backlight automatically shuts off after approximately 1 minute
of nonuse.
8 9
pp
H CALIBRATIONH CALIBRATION
p
H CALIBRATION
pp
H CALIBRATIONH CALIBRATION
It is recommended to calibrate the instrument frequently, if high
accuracy is required.
The instrument should be recalibrated:
• Whenever the pH electrode is replaced.
• At least once a week.
• After testing aggressive chemicals.
• When extreme accuracy is required.
• When the calibration time-out is expired (if feature is enabled).
PROCEDURE
The meter offers a choice of 7 memorized buffers (1.68, 4.01, 6.86,
7.01, 9.18, 10.01 and 12.45 pH) and two user defined values, C1
and C2 (see “Custom Buffer Selection” section on page 12 for details).
• Pour a small quantity of selected buffer solutions into clean beakers.
For accurate calibration use two beakers for each buffer solution, the
first one for rinsing the electrode and the second one for calibration.
• Remove the protective cap and rinse the electrode with some of
the buffer solution to be used for the first calibration point.
TWO-POINT CALIBRATION
• Press the CAL key. The “CAL” and “ ” indicators will be
displayed. The secondary LCD will display buffer “7.01”. If a
different calibration buffer is desired (e.g. “6.86”), use the
ARROW keys to change the displayed value.
• Submerse the electrode approximately 3 cm (1¼”) into the
solution, place the temperature probe as close as possible to the
electrode and stir gently.
• The LCD will flash “WAIT NOT
READY” for 12 seconds, then:
if the reading is not close to the
selected buffer, “WRONG “ and
“WRONG ” will blink alternatively;
if it is close to the selected buffer the
meter will advise the user with an
audible signal (if enabled) when the reading becomes stable and
the display will change to “READY” and blinking “CFM”.
• Press the CFM key to confirm the calibration: the meter stores the
first calibration point; the primary LCD will show the calibrated
reading, while the secondary LCD will show the second buffer to be
used for calibration (“pH 4.01”).
If you’re going to calibrate with a different buffer, select the
desired value by pressing the arrow keys.
Note: The meter automatically skips the buffer used for the first calibration
point to avoid erroneous procedure. A difference of at least 1.5 pH
unit is required between the two buffers: once calibrated at either
pH 7.01 or 6.86, the instrument automatically ignores the other
value for the second point (same for pH 10.01 and 9.18).
• Submerse the electrode approximately 3 cm (1¼”) into the
second buffer solution, place the temperature probe as close as
possible to the electrode and stir gently.
• The LCD will flash “WAIT NOT READY” for 12 seconds, then:
if the reading is not close to the
selected buffer, “WRONG “ and
“WRONG ” will blink alternatively;
if it is close to the selected buffer the meter
will advise the user with an audible
signal (if enabled) when the reading
becomes stable and the display will change
to “READY” and blinking “CFM”.
• Press the CFM key: the value is stored in memory and the meter
returns to measurement mode. The tags corresponding to the
buffers used for calibration and the “condition” bargraph (if
enabled) will be light up.
10 11
Note: During calibration, the secondary LCD shows the selected buffer
value; press RANGE to display the buffer temperature.
Note: To clear a previous calibration and return to the default
values, press CLR at any time after entering the calibration
mode. The LCD will show “CLr CAL” for one second, and then
will return to normal measurement mode.
The LCD will show an empty bargraph to warn the user that
the meter is not calibrated.
ONE-POINT CALIBRATION
For optimum accuracy it is always recommended to perform a twopoint calibration, but for a faster operation it is also possible to carry
out a single-point calibration.
pH 7.01 or pH 6.86 (NIST) are typically used, however the meter can
be calibrated with any of the memorized calibration values.
After calibrating the first point (see two-point calibration), press the
CAL key to end the calibration procedure.
Note: With one-point calibration electrode “condition” is not available
and only the frame is shown. Calibration time-out is active.
CUSTOM BUFFER SELECTION
• The meter allows the user to calibrate with custom buffers.
• To select a custom buffer press the CUST BUF key while in calibration
mode. Use the arrow keys to set the desired value for C1 (the default
value is 7.00).
Note: To increase the speed, continuously press the ARROW keys.
• Once the desired value is reached,
press CFM to confirm the value. The
meter will continue calibration as
with memorized buffers.
• The meter will display “C2”. Use the
arrow keys to change the value of
the second custom buffer, or press
CUST BUF to select a memorized
buffer.
EXPIRED CALIBRATION
The instrument has a real time clock (RTC), in order to monitor the
time elapsed since the last pH calibration.
The real time clock is reset every time the meter is calibrated and the
“expired calibration” status is triggered when the meter detects a
calibration time-out. The CAL tag will start blinking to warn the user
that the meter should be recalibrated.
The calibration time-out can be set (see “Setup menu” section on
page 14) from 0 (function disabled) to 14 days.
For example, if a 4 days time-out has been selected the meter will
issue the alarm exactly 4 days after the last calibration.
If the expiration value is changed (e.g. to 7 days), then the alarm
will be immediately recalculated and appear 7 days after the last
calibration.
Notes:
• When the meter is not calibrated or calibration is cleared (default
values loaded) there is no “expired calibration”, and the display
always shows a blinking CAL tag.
• When an abnormal condition in the RTC is detected the meter
forces the “expired calibration” status.
12 13
PMET SREFFUBHp
Cº Fº 86.1 10.4 68.6 10.7 81.9 10.01 54.21
0 23 76.1 10.4 89.6 31.7 64.9 23.01 83.31
5 14 76.1 00.4 59.6 01.7 93.9 42.01 81.31
01 05 76.1 00.4 29.6 70.7 33.9 81.01 99.21
51 95 76.1 00.4 09.6 50.7 72.9 21.01 08.21
02 86 86.1 00.4 88.6 30.7 22.9 60.01 26.21
52 77 86.1 10.4 68.6 10.7 81.9 10.01 54.21
03 68 86.1 20.4 58.6 00.7 41.9 69.9 92.21
53 59 96.1 30.4 48.6 99.6 11.9 29.9 31.21
04 401 96.1 40.4 48.6 89.6 70.9 88.9 89.11
54 311 07.1 50.4 38.6 89.6 40.9 58.9 38.11
05 221 17.1 60.4 38.6 89.6 10.9 28.9 07.11
55 131 27.1 80.4 48.6 89.6 99.8 97.9 75.11
06 041 27.1 90.4 48.6 89.6 79.8 77.9 44.11
56 941 37.1 11.4 48.6 99.6 59.8 67.9 23.11
07 851 47.1 21.4 58.6 99.6 39.8 57.9 12.11
57 761 67.1 41.4 68.6 00.7 19.8 47.9 01.11
08 671 77.1 61.4 78.6 10.7 98.8 47.9 00.11
58 581 87.1 71.4 78.6 20.7 78.8 47.9 19.01
09 491 97.1 91.4 88.6 30.7 58.8 57.9 28.01
59 302 18.1 02.4 98.6 40.7 38.8 67.9 37.01
CONDITION
The display is provided with a 5-dot bargraph (unless disabled)
which gives an indication of the electrode status after calibration:
Bargraph indication Condition value
All 5 dots steady 81 to 100% of life
4 dots steady 61 to 80%
3 dots steady 41 to 60%
2 dots steady 21 to 40%
1 dot steady 1 to 20%
1 dot blinking 0%
Only frame is ON No info available
The “condition” bargraph remains active for 12 hours after calibration,
then only the frame is shown.
Note: When an abnormal condition in the RTC is detected, the “condition”
is cleared and only the bargraph frame is shown on the display.
CLEAN ELECTRODE
Each time pH calibration is performed, the meter internally compares
the new calibration with the one previously stored.
When this comparison indicates a significant
difference, the “CLEAN ELECTRODE”
message blinks on the LCD to advise the
user that the pH electrode may need to
be cleaned (see “Electrode Conditioning &
Maintenance” section).
After cleaning, perform calibration.
Note: If the calibration data are cleared, the comparison is done
with the default values.
pp
H BUFFER TEMPERATUREH BUFFER TEMPERATURE
p
H BUFFER TEMPERATURE
pp
H BUFFER TEMPERATUREH BUFFER TEMPERATURE
DEPENDENCEDEPENDENCE
DEPENDENCE
DEPENDENCEDEPENDENCE
The temperature has an effect on pH. The calibration buffer solutions
are affected by temperature changes to a lesser degree than normal
solutions. During calibration the instrument will automatically calibrate
to the pH value corresponding to the measured or set temperature.
During calibration the instrument will display the pH buffer value at
25 °C.
14 15
SETUP MENUSETUP MENU
SETUP MENU
SETUP MENUSETUP MENU
The instrument allows the user to configure several parameters
through the Setup Menu.
To enter the Setup Menu, while in measurement mode, press and
hold the SETUP key for about 5 seconds.
Once the menu is entered, each parameter can be changed by using
the arrow keys; then pressing the CFM key will confirm the value and
scroll to the next parameter.
1. Audible signal: On (default) or Off
2. Auto-off feature: 20 minutes (default) or disabled
4. Calibration segments: On (default) or Off. This enables or disables
the bargraph, the “CLEAN ELECTRODE” message and the buffer
segments.
5. Calibration time-out: 1 (default) to 14 days or disabled (0 days)
After the last parameter, press the CFM key to confirm the setting
and return to measurement mode.
3. Temperature measure unit: ºC (default) or ºF
16 17
mm
V CALIBRATIONV CALIBRATION
m
V CALIBRATION
mm
V CALIBRATIONV CALIBRATION
BATTERIES REPLACEMENTBATTERIES REPLACEMENT
BATTERIES REPLACEMENT
BATTERIES REPLACEMENTBATTERIES REPLACEMENT
HI 9126 has been precalibrated for mV range at the factory.
For optimum accuracy, it is recommended to recalibrate the meter for
mV readings at least once a year. Contact your Dealer or the nearest
Hanna Customer Service Center for more information.
TEMPERATURE CALIBRATIONTEMPERATURE CALIBRATION
TEMPERATURE CALIBRATION
TEMPERATURE CALIBRATIONTEMPERATURE CALIBRATION
HI 9126 has beenprecalibrated for temperature at the factory.
For optimum accuracy, it is recommended to recalibrate the meter for
temperature at least once a year. Contact your Dealer or the nearest
Hanna Customer Service Center for more information.
The instrument is supplied with batteries. First time you start working
with the instrument, insert the supplied batteries in the battery
compartment observing the correct polarity (see page 20).
At start-up the battery percentage is displayed.
If the batteries become weak, the display will flash the battery
symbol to advise the user that approximately 1 hour of working time
remains. It is recommended to change the batteries as soon as the
battery symbol appears blinking.
The meter is also provided with the BEPS (Battery Error Prevention
System) feature which automatically turns the instrument off when
the battery level is too low to ensure reliable readings. At start-up the
display will show “0 batt” for few seconds, then the meter automatically
turns off.
18 19
To replace the batteries, follow the next steps:
• Turn OFF the instrument.
• Open the battery compartment cap (located on the top of the
instrument).
• Remove old batteries.
• Insert three new 1.5V AAA batteries in the battery compartment,
observing the polarity on the rear of the instrument.
• Reattach the battery compartment cap.
LCD MESSAGE GUIDELCD MESSAGE GUIDE
LCD MESSAGE GUIDE
LCD MESSAGE GUIDELCD MESSAGE GUIDE
TAGS & SYMBOLS
• Mode tags light up for indicating the corresponding active mode,
and blink for warning the user.
SETUP on: setup menu mode has been entered.
MEASURE on: measurement mode.
CALIBRATION on: calibration mode has been entered.
MEMORIZE on: measurement stored in the internal memory and
frozen on the display
RECALL MEMORIZED on: stored value recalled.
• Indication of temperature compensation mode:
MTC for manual, ATC for automatic compensation.
• Battery symbol blinking: low battery condition. Batteries should
be replaced.
• Calibration messages.
WAIT NOT READY blinking: buffer has been recognized, but
reading is not stable.
READY on: buffer has been recognized and reading is stable.
WRONG and WRONG blinking alternatively: wrong
buffer, value not recognized.
CLEAN ELECTRODE blinking: an abnormal difference between
new and previous calibration has been detected. Electrode cleaning is suggested. Follow the cleaning procedure described in the
“Electrode conditioning & maintenance” section. If the problem
remains, check the buffer solutions.
20 21
TEMPERATURE CORRELATIONTEMPERATURE CORRELATION
TEMPERATURE CORRELATION
TEMPERATURE CORRELATIONTEMPERATURE CORRELATION
FOR FOR
pp
FOR
FOR FOR
The resistance of glass electrodes partially depends on the temperature.
The lower the temperature, the higher the resistance. It takes more time
for the reading to stabilize if the resistance is higher. In addition, the
response time will suffer to a greater degree at temperatures below 25 °C.
Since the resistance of the pH electrode is in the range of 50 – 200
Mohms, the current across the membrane is in the pico Ampere range.
Large currents can disturb the calibration of the electrode for many
hours.
For these reasons high humidity environments, short circuits and static
discharges can be detrimental to a stable pH reading.
The pH electrode’s life also depends on the temperature. If constantly
used at high temperatures, the electrode life is drastically reduced.
Typical Electrode Life
Ambient Temperature 1 – 3 years
90 °C Less than 4 months
120 °C Less than 1 month
Alkaline Error
High concentrations of sodium ions interfere with readings in alkaline
solutions. The pH at which the interference starts to be significant
depends upon the composition of the glass. This interference is called
alkaline error and causes the pH to be underestimated. Hanna’s glass
formulations have the indicated characteristics.
Sodium Ion Correction for Glass at 20-25 °C
Concentration pH Error
0.1 Mol L-1 Na
1.0 Mol L-1 Na
H SENSITIVE GLASSH SENSITIVE GLASS
p
H SENSITIVE GLASS
pp
H SENSITIVE GLASSH SENSITIVE GLASS
+
+
13.00
13.50
14.00
12.50
13.00
13.50
14.00
0.10
0.14
0.20
0.10
0.18
0.29
0.40
EE
LECTRODE CONDITIONING & MAINTENANCELECTRODE CONDITIONING & MAINTENANCE
E
LECTRODE CONDITIONING & MAINTENANCE
EE
LECTRODE CONDITIONING & MAINTENANCELECTRODE CONDITIONING & MAINTENANCE
Not present in gel electrodes.
PREPARATION PROCEDURE
Remove the electrode protective cap.
DO NOT BE ALARMED IF ANY SALT DEPOSITS ARE PRESENT. This is
normal with electrodes and they will disappear when rinsed with water.
During transport tiny bubbles of air may have formed inside the glass
bulb. The electrode cannot function properly under these conditions.
These bubbles can be removed by "shaking down" the electrode as you
would do with a glass thermometer.
If the bulb and/or junction are dry, soak the electrode in HI 70300
Storage Solution for at least one hour.
22 23
SMOTPMYS MELBORP NOITULOS
evissecxe/esnoperwolS
.tfird
.edortceleHpytriD ebotsdeenedortceleehT
.naelc
gninaelCehtwolloF
.42egapnoerudecorP
pusetautculfgnidaeR
.)esion(nwoddna
.noitcnujytrid/deggolC
leveletylortcelewoL
sedortceleelballifer(
.)ylno
.edortceleehtnaelC
etylortcelehserfhtiwllifeR
.)ylnosedortceleelballifer(
dnaelbackcehC
.rotcennoc
swohsyalpsiD
elacsllufgniknilb
.eulav
fotuognidaeR
.egnar
siedortceleehterusekaM
.detcennoc
sielpmastahtkcehC
;egnarelbarusaemnihtiw
dnaleveletylortcelekcehC
.sutatsedortcelelareneg
fotuoelacsVm
.egnar
yrdroenarbmemyrD
.noitcnuj
niedortcelekaoS 00307IH
tsaeltarofnoitulosegarots
.setunim03
.rotcennocdnaelbackcehC
swohsyalpsiD
“gniknilb C° “ro” F° .”
erutarepmetnekorB
.eborp
erutarepmetecalpeR
.eborp
swohsyalpsiD
“ EDORTCELENAELC
.gniknilb“
neewtebecnereffiD
suoiverpdnawen
neebsahnoitarbilac
.detceted
dnaedortcelenaelC
melborpehtfI.etarbilacer
reffubehtkcehc,sniamer
.snoitulos
swohsyalpsiD
yrettabgniknilb
.lobmys
.levelyrettabwoL .seirettabehtecalpeR
krowtonseodreteM
erutarepmethtiw
.eborp
erutarepmetnekorB
.eborp
erutarepmetgnorW
.desueborp
erutarepmetecalpeR
.eborp
etarbilacotsliafreteM
ytluafsevigro
.sgnidaer
.edortceleHpnekorB .edortceleecalpeR
“ GNORW
NOITARBILAC si”
Hpgniruddeyalpsid
.erudecorpnoitarbilac
rognorW
.reffubdetanimatnoc
noitulosreffubtahtkcehC
.hserfdnatcerrocsi
.ffostuhsreteM roseirettabdaeD
sierutaefffo-otuA
,esacsihtni:delbane
retfaffostuhsretem
.esu-nonfonim02
.seirettabehtecalpeR
sserP FFO/NO .
“ 0rE “,“ 1rE “,“ 2rE ”
.putratstaegassem
.rorreMORPEE ynarorelaedruoytcatnoC
.retneCecivreSannaH
“ rlC tratstaegassem”
.pu
HptluafeddedaoL
.seulavnoitarbilac
.noitarbilacHpmrofreP
For refillable electrodes, if the refill solution (electrolyte) is more than
2½ cm (1") below the fill hole, add the appropriate Electrolyte Solution.
MEASUREMENT
Rinse the electrode tip with distilled water, submerse it 3 cm (1¼”) in
the sample and stir gently for a few seconds.
For a faster response and to avoid cross contamination of the samples,
rinse the electrode tip with the solution to be tested, before taking
any measurements.
STORAGE PROCEDURE
To minimize clogging and ensure a quick response time, the glass
bulb and the junction should always be kept moist.
When not in use, store it with a few drops of HI 70300 storage
solution in the protective cap.
NEVER STORE THE ELECTRODE IN DISTILLED OR DEIONIZED
WATER.
PERIODIC MAINTENANCE
Inspect electrode and cable. The cable must be intact. No cracks
should be seen on the electrode stem or bulb. If any scratches or cracks
are present, replace the electrode. Rinse off any salt deposits with water.
Connectors must be perfectly clean and dry.
For refillable electrodes:For refillable electrodes:
For refillable electrodes:
For refillable electrodes:For refillable electrodes:
Refill the electrode with fresh electrolyte (see the electrode’s specifications
to select the correct refilling solution). Allow the electrode to stand
upright for 1 hour. Follow the Storage Procedure above.
CLEANING PROCEDURE
•
General
•
Protein
•
Inorganic
•
Oil/grease
IMPORTANT: After performing any of the cleaning procedures, rinse
the electrode thoroughly with distilled water and soak it in HI 70300
Soak in Hanna HI 7061 General Cleaning
Solution for approximately ½ hour.
Soak in Hanna HI 7073 Protein Cleaning
Solution for 15 min.
Soak in Hanna HI 7074 Inorganic
CleaningSolution for 15 min.
Rinse with Hanna HI 7077 Oil & Fat Cleaning
Solution for 1 min.
Storage Solution for at least 1 hour before taking measurements.
24 25
TROUBLESHOOTING GUIDETROUBLESHOOTING GUIDE
TROUBLESHOOTING GUIDE
TROUBLESHOOTING GUIDETROUBLESHOOTING GUIDE
120 mm
4.7"
12 mm
0.5"
9.5mm DIA
0.37"
"S" VERSION
HI 1043
120 mm
4.7"
12 mm
0.5"
"S" VERSION
HI 1053
120 mm
12 mm
0.5"
5 mm
0.2"
3 mm
0.12"
3.0 mm DIA
0.12"
HI 1083
120 mm
4.7"
12 mm
0.5"
9.5mm DIA
0.37"
"S" VERSION
HI 1131
ACCESSORIESACCESSORIES
ACCESSORIES
ACCESSORIESACCESSORIES
pH CALIBRATION SOLUTIONS
HI 70004P pH 4.01 Buffer Solution, 20 mL sachet, 25 pcs
HI 70007P pH 7.01 Buffer Solution, 20 mL sachet, 25 pcs
HI 70010P pH 10.01 Buffer Solution, 20 mL sachet, 25 pcs
HI 7004L pH 4.01 Buffer Solution, 500 mL bottle
HI 7004M pH 4.01 Buffer Solution, 230 mL bottle
HI 7006L pH 6.86 Buffer Solution, 500 mL bottle
HI 7006M pH 6.86 Buffer Solution, 230 mL bottle
HI 7007M pH 7.01 Buffer Solution, 500 mL bottle
HI 7007M pH 7.01 Buffer Solution, 230 mL bottle
HI 7009L pH 9.18 Buffer Solution, 500 mL bottle
HI 7009M pH 9.18 Buffer Solution, 230 mL bottle
HI 7010L pH 10.01 Buffer Solution, 500 mL bottle
HI 7010M pH 10.01 Buffer Solution, 230 mL bottle
ELECTRODE STORAGE SOLUTION
HI 70300L Storage Solution, 500 mL bottle
HI 70300M Storage Solution, 230 mL bottle
ELECTRODE CLEANING SOLUTIONS
HI 70000P Electrode Rinse Solution, 20 mL sachet, 25 pcs
HI 7061L General Cleaning Solution, 500 mL bottle
HI 7061M General Cleaning Solution, 230 mL bottle
HI 7073L Protein Cleaning Solution, 500 mL bottle
HI 7073M Protein Cleaning Solution, 230 mL bottle
HI 7074L Inorganic Cleaning Solution, 500 mL bottle
HI 7074M Inorganic Cleaning Solution, 230 mL bottle
HI 7077L Oil & Fat Cleaning Solution, 500 mL bottle
HI 7077M Oil & Fat Cleaning Solution, 230 mL bottle
REFILLING ELECTROLYTE SOLUTIONS (50 mL, 4 pcs)
HI 7071 3.5M KCl+AgCl Electrolyte for single junction electrodes
HI 7072 1M KNO3 Electrolyte
HI 7082 3.5M KCl Electrolyte for double junction electrodes
HI 8093 1M KCl+AgCl Electrolyte
ORP PRETREATMENT SOLUTIONS
HI 7091L Reducing Pretreatment Solution, 500 mL bottle
HI 7091M Reducing Pretreatment Solution, 230 mL bottle
HI 7092L Oxidizing Pretreatment Solution, 500 mL bottle
HI 7092M Oxidizing Pretreatment Solution, 230 mL bottle
ORP SOLUTIONS
HI 7020L Test Solution 200-275 mV, 500 mL bottle
HI 7020M Test Solution 200-275 mV, 230 mL bottle
HI 7021L Test Solution 240 mV, 500 mL bottle
HI 7021M Test Solution 240 mV, 230 mL bottle
HI 7022L Test Solution 470 mV, 500 mL bottle
HI 7022M Test Solution 470 mV, 230 mL bottle
pH ELECTRODES
All electrodes part numbers ending in B are supplied with a BNC
connector and 1 m (3.3') cable, as shown below:
HI 1043B
Glass-body, double junction, refillable, combination pH electrode.
Use: strong acid/alkali.
HI 1053B
Glass-body, triple ceramic, conic shape, refillable, combination pH
electrode.
Use: emulsions.
HI 1083B
Glass-body, micro, Viscolene, non-refillable, combination pH electrode.
Use: biotechnology, micro titration.
HI 1131B
Glass-body, single junction, refillable, combination pH electrode.
Use: general purpose.
26 27
120 mm
4.7"
12 mm
0.5"
FC 100
75 mm
2.95"
6 mm
0.25"
FC 200
120 mm
4.7"
12 mm
0.5"
FC 210
120 mm
4.7"
12 mm
0.5"
9.5mm DIA
0.37"
FC 220
110 mm
4.3"
12 mm
0.5"
FC 911
HI 1330B
120 mm
4.7"
5mm
0.2"
5mm DIA
0.2"
"S" VERSION
HI 1330
120 mm
4.7"
12 mm
0.5"
HI 1230
75 mm
2.95"
6 mm
0.25"
HI 2031
120 mm
4.7"
12 mm
0.5"
"S" VERSION
HI 1332
210 mm
8.25"
8 mm
0.3"
7.5mm DIA
0.29"
"S" VERSION
HI 1331
Glass-body, semimicro, single junction, refillable, combination pH
electrode.
Use: laboratory, vials.
HI 1331B
Glass-body, semimicro, single junction, refillable, combination pH
electrode.
Use: flasks.
FC 100B
Plastic-body (PVDF), double junction, refillable, combination pH electrode.
Use: general purpose for food industry.
FC 200B
Plastic-body (PVDF), open junction, conic, Viscolene, non-refillable,
combination pH electrode.
Use: meat & cheese.
HI 1230B
Plastic-body (PES), double junction, gel-filled, combination pH
electrode.
Use: general, field.
HI 2031B
Glass-body, semimicro, conic, refillable, combination pH electrode.
Use: semisolid products.
HI 1332B
Plastic-body (PES), double junction, refillable, combination pH
electrode.
Use: general purpose.
FC 210B
Glass-body, double junction, conic, Viscolene, non-refillable, combination
pH electrode.
Use: milk, yogurt.
FC 220B
Glass-body, triple-ceramic, single junction, refillable, combination pH
electrode.
Use: food processing.
FC 911B
Plastic-body (PVDF), double junction, refillable with built-in amplifier,
combination pH electrode. Use: very high humidity.
28 29
HI 1413B
110 mm
4.3"
12 mm
0.5"
HI 1413
150 mm
5.9"
12 mm
0.5"
"S" VERSION
HI 3131
120 mm
4.7"
12 mm
0.5"
HI 3230
"S" VERSION
120 mm
4.7"
12 mm
0.5"
HI 4430
"S" VERSION
Glass-body, single junction, flat tip, Viscolene, non-refillable, combination
pH electrode. Use: surface measurement.
ORP ELECTRODES
HI 3131B
Glass-body, refillable, combination platinum ORP electrode.
Use: titration.
HI 3230B
Plastic-body (PES), gel-filled, combination platinum ORP electrode.
Use: general purpose.
HI 4430B
Plastic-body (PES), gel-filled, combination gold ORP electrode.
Use: general purpose.
RECOMMENDATIONS FOR USERS
Before using these products, make sure they are entirely suitable for
the environment in which they are used.
Operation of these instruments in residential areas could cause
unacceptable interferences to radio and TV equipment, requiring the
operator to follow all necessary steps to correct interferences.
The glass bulb at the end of the pH electrode is sensitive to
electrostatic discharges. Avoid touching this glass bulb at all times.
During operation, ESD wrist straps should be worn to avoid possible
damage to the electrode by electrostatic discharges.
Any variation introduced by the user to the supplied equipment may
degrade the instruments’ EMC performance.
To avoid electrical shock, do not use these instruments when voltages
at the measurement surface exceed 24 VAC or 60 VDC.
To avoid damage or burns, do not perform any measurement in
microwave ovens.
Consult the Hanna General Catalog for a complete and wide selection
of electrodes.
OTHER ACCESSORIES
HI 721317 Rugged carrying case
HI 740157 Plastic electrode refilling pipet (20 pcs)
HI 76405 Electrode holder
HI 7662 Temperature probe with 1 m (3.3') screened cable
HI 8427 pH and ORP electrode simulator with 1 m (3.3')
coaxial cable ending in female BNC connectors
HI 931001 pH and ORP electrode simulator with LCD and 1 m
(3.3') coaxial cable ending in female BNC connectors
30 31
Hanna Instruments reserves the right to modify the design,
construction and appearance of its products without advance notice.
Hanna Instruments Inc.
Highland Industrial Park
584 Park East Drive
Woonsocket, RI 02895 USA
Technical Support for Customers
Tel. (800) 426 6287
Fax (401) 765 7575
E-mail tech@hannainst.com
www.hannainst.com
Local Sales and Customer Service Office
Printed in EUROPE
(ROMANIA)
MAN9126Y 09/10
32
Loading...
