Bar Blenders

Models 901/908/909/910/918/919

Operation Manual

Page 2

wWARNING

Electrical Shock Hazard

Plug into a grounded outlet.
Do not remove ground.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result

in death, fire, or electrical shock.

Blender Safety

You will

be killed or seriously injured if

you don’t follow instructions.

You can

be killed or seriously injured if

you don’t follow instructions.

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.

This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word “DANGER” or

“WARNING.” These words mean:

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what
can happen if the instructions are not followed.

wDANGER

wWARNING

IMPORTANT: This operation manual should be reviewed with all equipment operators as part of your
operator training program.

wWARNING

Cut Hazard

Always place cover on jar when blending.
Do not put hands, spoons, or other utensils in

jar when blending.
Failure to follow these instructions can result

in broken bones or cuts.

Call our Technical Service number: 866-285-1087 or 910-692-2223

8 a.m. – 5:30 p.m. EST Monday – Thursday, 8 a.m. – 5:15 p.m. EST Friday

(www.commercial.hamiltonbeach.com)

Requesting Assistance or Service

Before calling for assistance or service, please check
the “Troubleshooting Guide” in this manual. If you still
need help, follow the instructions below.

Whenever you call to request assistance or service,
you need to know the complete model number. You
can find this information on the label on the bottom of
your blender.

Please also record the purchase date of your
equipment and your dealer’s name, address,
and telephone number.

Model Number__________________________
Purchase Date__________________________
Dealer Name ___________________________
Dealer Address _________________________
Dealer Phone___________________________

You can also order replacement parts by calling your
nearest Hamilton Beach Commercial Service Center or
your local dealer.

2

Blender Safety

• Read all instructions.

• Plug into a grounded outlet.

• Do not touch surfaces that may be hot.

Use handles or knobs provided.

• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.

• Do not use appliance for other than intended use.

• To protect against electrical shock, do not

immerse cord, plug, or blender base in water
or any other liquid.

• Close supervision is necessary when any
appliance is used by or near children.

• The use of accessory attachments not recom­mended by Hamilton Beach may cause injuries.

• To reduce risk of personal injury, unplug cord
from outlet when not in use, and before putting on
or taking off parts or doing any other servicing of
the blender.

• Do not let cord hang over edge of table or
counter or touch hot surfaces.

• Do not place on or near a hot gas or electric
burner or in a heated oven.

• To reduce risk of personal injury and to prevent
damage to blender or jar and cutter assembly,
DO NOT insert utensils into blender jar while
operating blender, or store utensils in the blender
jar when it is not in use.

• Avoid contacting moving parts.

• Blades are sharp. Handle carefully.

• Inspect jar and cutter assembly daily. Check

cutter for wear, nicks, or broken blades. Replace
jar and cutter assembly at least every 12 months.

• Do not defeat the jar pad sensors.

• Do not use outdoors.

• This appliance is intended for short periods

of operation, with a rated operating time of
3 minutes.

– SAVE THESE INSTRUCTIONS –

• To prevent damage to blender, jar, or cutter
assembly, DO NOT move or shake blender
while in operation. If blending action stops during
operation, turn blender OFF, remove jar from
base, remove jar cover, and use a thin rubber
spatula to push mixture towards cutters.

• Do not spray the base with a high-pressure
spray gun.

• Disconnect power before cleaning or servicing.

• To prevent burns from hot liquids splashing out

of the jar, always remove the filler cap of the
container cover before blending hot liquids.

• Do not operate any appliance with a damaged
cord or plug or after the appliance malfunctions,
or is dropped or damaged in any manner.
Return appliance to the nearest service facility
for examination, repair, or electrical or
mechanical adjustment.

• If the supply cord of this appliance is damaged,
it must be replaced by the manufacturer or its ser­vice agent or a similar qualified person. If fitted
with a non-rewirable U.K. plug, the 13 amp fuse
approved by ASTA to be B.S. 1362 must be used.
If you need a replacement fuse carrier, it must be
replaced by the same colour coded carrier with
the same markings. Fuse covers and carriers
can be obtained from approved service agents.
IMPORTANT: If the molded plug is cut off,
dispose of it immediately. The plug is not rewirable
and would cause a shock hazard if inserted into
a socket.

• For a complete operation manual in this
language, please visit our website at
www.commercial.hamiltonbeach.com
or call 910-692-2223.

IMPORTANT SAFETY INSTRUCTIONS

WARNING – When using electrical appliances, basic safety precautions should be followed, including

the following:

Blender Operation – Quick Start Guide

1. Place the blender on a dry, level surface.

2. Make sure the power switch is in the “off” or O

position. Plug the blender into a grounded electrical
outlet.

3. Place the jar on the base with ingredients and jar
lid in place.

4. Set the controls to your preference.

5. Move the power switch to the “on” or I position.

3

4

Parts and Features

The parts and features for the 901/908/909/910/918/919 Blenders are shown on this page. Become familiar
with all parts and features before using your blender.

Your blender is designed for blending and mixing beverages.

Note: The Blender is not designed to crush ice. Ice cubes made in most icemakers may be added to liquid
ingredients in the blender to make daiquiris or similar drinks.

Cover

Container

Removable
Filler Cap

Models 910/918/919

On/Off/Pulse Switch

Models
908/909
On/Off
Switch

HIGH/LOW
Switch

Blender

Base

Model 908

Model 909 Model 918 Model 919

Gasket

Blades

Clutch

Cutter Unit Assembly

Model 910

Model 901

Model 901

On/Off

Switch

3. Plug the blender into an

electric outlet.

4. Place the ingredients to be
blended into container.

5. Place the container onto
the base. Make sure it
rests securely on the base.

6. Place the cover and filler
cap on the container.

7. Set the Hi/Low switch
(except model 901) to the
desired speed. See “Professional Blending
Techniques” for blending tips.

NOTE: If you want the blender to run for short
bursts, press the Pulse switch (on some models).
While you are pressing the Pulse switch, the blender
will run at the selected speed. Release the Pulse
switch to stop the blender.

5

Operation

Controls

Model 901:

• The ON/OFF switch will turn the blender ON for
continuous operation at approximately 18,000
RPM, or OFF.

Models 908, 909, 910, 918, 919:

Two separate switches on the front panel allow
you to control the blender for precise blending
requirements:

• The ON/OFF switch will turn the blender ON for
continuous operation or OFF.

• The HIGH.LOW switch allows you to select the
following speeds:

Hi – 17,800 RPM Low – 11,500 RPM

• The Pulse switch (Models 910, 918 and 919)
turns on the blender only when the switch is
pressed. When the switch is released, the blender
will stop. This will allow you to precisely control
the operation of the blender.

Using the blender

Before you use the blender for the first time, wash
the container, cover, and cutter unit assembly. Refer
to “Cleaning the Blender.” Do not put the cutter unit
assembly in the dishwasher.

To operate the blender, proceed as follows:

1. Place the blender on a clean, dry, level surface,

and set the ON/OFF switch to OFF.

2. Place cutter unit in the threaded collar, blades up.

Slip the gasket OVER the blades and onto the
base of the cutter unit. Screw the completed
blade assembly onto the container.

Operating the Blender

Models 908/909

Models 910/918/919

ON/OFF

Switch

HIGH/LOW

Switch

ON/OFF/

Pulse

Switch

HIGH/LOW

Switch

wWARNING

Electrical Shock Hazard
Plug into a grounded outlet.
Do not remove ground.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can

result in death, fire, or electrical shock.

wWARNING

Cut Hazard
Always place cover on jar when blending.
Do not put hands, spoons or other utensils

in jar when blending.
Failure to follow these instructions can

result in broken bones or cuts.

ON/OFF

Switch

Model 901

Professional Blending Techniques

Filling the container

When filling the container with ingredients, follow
these recommendations:

• Use sufficient amount of liquid to ensure that the
mixture is fluid and free-running at all times. Pour
the liquid into the container FIRST.

• Cut solid ingredients into pieces that are no
bigger than a 1″ (2.5 cm) cube.

• Add the ingredients to container in batches. Do not
blend maximum volume all at once.

• Do NOT overfill the container with product. This
may prevent the blender from processing the
product properly. Process dense foods or thick
mixtures in small batches, and remember that the
volume of the product normally increases during
processing.

• Do not exceed one quart of content when
blending hot product.

• Always place the cover and filler cap on the
container when blending. For blending hot
liquids, remove filler cap from container cover
before blending.

Blending techniques

Icy drinks – Do not use blender to crush large ice

cubes. The blender is not designed for this. Small
ice cubes or crushed ice is recommended. Pour in
liquid, then add ice. Cover. Set speed at HIGH
(except model 901) and process until desired
consistency is reached. Chunks of frozen fruit can
be added to milk or fruit juice to produce a sherbet
or slush.

Blending hot mixtures

IMPORTANT: To minimize the possibility of

scalding, the following precautions MUST be
observed:

• Do not exceed 1 quart of content when blending
hot product. Remember that the volume of the
product normally increases during processing.

• Always place the cover on the container and
remove the filler cap from container cover when
blending hot liquids to prevent the build up of
pressure.

• Never stand with your face directly over the

container when operating the blender where

steam may be released.

• Begin on LOW speed and then select a speed
that produces a column of air in the center of
the container.

Filler Cap

Use the filler cap to add liquids to the container
while the unit is running.

wWARNING

Burn Hazard

Always use caution when blending
hot contents.

Failure to follow these instructions
can result in burns.

Operating the Blender

6

7

Caring for the Blender

Cleaning Instructions

General cleaning

Do not allow food residue to dry on any part of the
blender. Wash and rinse container, cutter unit
assembly and base after each use, or whenever it
will not be used again within one hour, as follows:

1. Remove the container from the base, and then
remove the cover. Add cleaning solution to the
container. Use a washing solution of hot water
(less than 115° F/46° C) and a non-sudsing
detergent. Use the recommended amount of
detergent.

2. Scrub and flush out the container interior,
cover and filler cap to remove food residue.
Empty container.

3. Fill container

1

⁄4 full with fresh washing solution

and place it on the base.

4. Replace the cover on the container and run the
blender on high speed (except model 901) for 2
minutes.

5. Repeat step 3 using clean rinse water
(95° F/35° C).

6. Wipe down the container, filler cap, and cover
with a soft cloth or sponge, dampened with fresh
washing solution.

7. Wipe the exterior of the base with a damp cloth
or sponge. The base contains electrical
components: do not immerse, use a
high-pressure washer, or use a dishwasher
to clean the base.

Sanitizing

1. Wash container as instructed in “General

Cleaning.”

2. Fill container with sanitizing solution (See
“Recommended Sanitizing Solution” below)
and place on base.

3. Replace cover and filler cap and run on LOW
(except model 901) speed for 2 minutes. Empty
container.

4. Wipe the container exterior with a soft cloth or
sponge dampened with sanitizing solution.

5. Immerse the cover and filler cap in sanitizing
solution for two minutes.

6. Remove any remaining moisture from cutter
assembly by replacing container on base with
cover and filler cap in place. Then run blender
on HiGH (except model 901) speed for a minimum
of 2 minutes.

7. To dry, place empty container on base and run on
HIGH (except model 901) speed for two seconds.

8. When ready to use, rinse with clean water.

NOTE: Do not rinse container, cover or filler cap

after sanitizing.

Recommended Sanitizing Solution:

The sanitizing solution should consist of 1
tablespoon of household bleach per 1 gallon of
clean, cool water (60° F, 16° C) mixed according
to the instructions on the bleach. When using a
sanitizing solution other than that recommended,
the sanitizing solution concentration should be
tested using commercially available test strips
and should indicate a concentration between
100 and 200 parts per million of bleach to water.

wWARNING

Electrical Shock Hazard
Plug into a grounded outlet.
Do not remove ground.
Do not use an adapter.
Do not use an extension cord.
Do not immerse base in water or

other liquid.
Failure to follow these instructions can

result in death, fire, or electrical shock.

wWARNING

Cut Hazard
Always place cover on jar when blending.
Do not put hands, spoons or other utensils

in jar when blending.
Failure to follow these instructions can

result in broken bones or cuts.

8

Troubleshooting Guide

Replacement Parts

Caring for the Blender

Problem . . . Solution . . .

Blender fails to start
or stops while it is
running and cannot
be restarted

• Check to see if unit is securely plugged into an electric outlet.

• Check to see if the fuse for the electric outlet has blown or if a
circuit breaker has tripped.

Maintenance

Unplug the blender and remove the container from the base, and then inspect the container and
cutter unit assembly for wear, nicks, and broken or loose blades. Replace if necessary. If the
cutter assembly blades are loose, discontinue use immediately and replace the cutter assembly.
Do not attempt to repair or tighten the cutter assembly. See “Replacement Parts” below.

Unplug the blender, and then inspect the power cord insulation and power plug for cracks.
Refer to “Requesting Assistance or Service” for repair or replacement.

Replace the container and cutter unit assembly at least once a year. See “Replacement Parts”
below.

901 1 container 6126-901
908 1 container 6126-908
909 1 container 6126-909
910 1 container 6126-910
918 1 container 98000
919 1 container 98100
ALL Cutter unit assembly 99100

Model Part Description

Part Number

Inspect the blender and its various parts and replace as follows:

Daily

Weekly

Yearly

Ingredients will not mix
properly

• Check to see if enough liquid has been added to the ingredients. Mixture should
be fluid and free-running at all times.

• Solid pieces are too large. Pieces should not exceed 1″ (2.5 cm) cubes.

• Container is too full. Do not fill past highest graduation marking.

• Cutter unit blades are not sharp or are damaged. Inspect container and cutter
assembly daily. Replace container and cutter assembly at least every 12 months
or sooner if cutter assembly appears worn or damaged.

• Check to see if cutter unit assembly is installed properly.

• Select speed (on some models) to create a fluid blend.

Refer to “Requesting Assistance or Service” to order parts below.

9

LIMITED WARRANTY

This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the
date of original purchase, except as noted below. During this period, we will repair or replace this product, at our
option, at no cost to you. THE FOREGOING WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, WHETHER
EXPRESS OR IMPLIED, WRITTEN OR ORAL INCLUDING ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, ANY LIABILITY IS EXPRESSLY LIMITED TO AN AMOUNT EQUAL
TO THE PURCHASE PRICE PAID, AND ALL CLAIMS FOR SPECIAL,INCIDENTAL AND CONSEQUENTIAL
DAMAGES ARE HEREBY EXCLUDED. There is no warranty with respect to the following, which may be supplied
with this product: (motor brushes, container and cutter assembly, clutches, bristle brushes, funnel, stainless steel
cup, agitators, carafes, etc.). This warranty extends only to the original purchaser and does not cover a defect
resulting from abuse, misuse, neglect, unauthorized repair, or use not in conformity with the printed directions.
Always use this product in the manner provided in the Operation Manual. This warranty gives you specific legal
rights and you may also have other legal rights which vary from state to state, or province to province. Some states
do not allow limitations on implied warranties or special, incidental or consequential damages, so the foregoing
limitations may not apply to you.

If you have a claim under this warranty please contact our CUSTOMER SERVICE DEPARTMENT at
1-866-285-1087. (For faster service please have model, series, and type numbers ready for operator to
assist you.) Reasonable proof of date of purchase must be presented; otherwise the effective date of
the warranty will be based upon the date of manufacture plus ninety (90) days.

Product Warranty

Hamilton Beach/Proctor-Silex, Inc.
Commercial Customer Service
263 Yadkin Road
Southern Pines, NC 28387

This Warranty supercedes all other Product Warranties

5/03
