Hamilton Beach 62667, 62668 User Guide

READ BEFORE USE LIRE AVANT UTILISATION LEA ANTES DE USAR

Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guides – as well as delicious recipes, tips, and to register your product online.

Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos manuels utilisateur – ainsi que nos délicieuses recettes et nos conseils.

Visite www.hamiltonbeach.com ( o

www.hamiltonbeach.com.mx (México) para ver otros productos de Hamilton Beach o para contactarnos.

Questions Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

Questions N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider. CAN : 1.800.267.2826

Preguntas Por favor llámenos – nuestros amables representantes están listos para ayudar. EE. UU.: 1.800.851.8900 MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

EE. UU.)

ErgoMixTM Hand Mixer

Batteur à main

ErgoMix

Batidora de Mano

ErgoMix

English ...................... 2

Français .................... 7

Español ................... 13

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

1. Read all instructions.

2. This appliance is not intended for use by persons (including

children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety.

3. Close supervision is necessary when any appliance is used by or

near children. Children should be supervised to ensure that they do not play with the appliance.

4. To protect against risk of electrical shock, do not put cord,

plug, or mixer body in water or other liquid.

5. Unplug from outlet when not in use, before putting on or

taking off parts, and before cleaning.

6. Avoid contacting moving parts. Keep hands, hair, and clothing,

as well as spatulas and other utensils, away from beaters during operation to reduce risk of injury to persons and/or damage to mixer.

7. Remove beaters from mixer before washing.

8. Do not let cord hang over edge of table or counter or touch hot

surfaces, including stove.

9. Do not operate any appliance with a damaged supply cord or

plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Supply cord replacement and repairs must be conducted by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard. Call the provided customer service number for information on examination, repair, or adjustment.

10. The use of attachments not recommended or sold by the

appliance manufacturer for use with this model may cause fire, electric shock, or injury.

11. Do not use outdoors.

12. Do not place on or near a hot gas or electric burner, or in a

heated oven.

13. Check that control is off before plugging cord into wall outlet. To

disconnect, turn control to OFF ( wall outlet.

14. Do not use appliance for other than intended purpose.

) and then remove plug from

SAVE THESE INSTRUCTIONS

Other Consumer Safety Information

This appliance is intended for household use only.

w WARNING

with a polarized plug (one wide blade) to reduce the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the

Electrical Shock Hazard: This appliance is provided

extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

w CAUTION

To reduce the risk of personal injury, always unplug mixer before inserting or removing beaters.

WATTAGE/PEAK POWER INFORMATION

The marked rating of the hand mixer is determined by Underwriters Laboratories as the maximum stabilized power consumption of the hand mixer at high speed under a loaded condition.

Peak power is an average of the maximum wattage a hand mixer may consume during initial operation at high speed.

Moving Parts Hazard.

Parts and Features

*To order parts: US: 1.800.851.8900 www.hamiltonbeach.com Canada: 1.800.267.2826 Mexico: 01 800 71 16 100

Twisted Wire Beaters*

(General/Heavy Use)

Stand

BEFORE FIRST USE: Wash beaters and whisk in hot, soapy water. Rinse and dry.

Beater Eject Slider

Whisk*

Speed Dial With Burst Function

(Whipping/Aerating)

Eject

How to Use Hand Mixer

1. Make sure mixer is unplugged

and speed control is set to (OFF). Insert beaters or whisk into proper openings on the bottom of the mixer. Push and click into place. Plug into outlet. Place beaters into bowl.

Cookie Mixing Guide:

• Cookie dough is one of the thickest doughs to mix.

• Use a large mixing bowl to spread out ingredients for easier mixing.

• Have butter or margarine at room temperature.

• Add flour 1 cup (237 ml) at a time, thoroughly mixing after each addition.

• If adding chips or nuts, we recommend stirring them in by hand at the very end of the recipe.

2. Move the speed control to

desired speed, starting at 1 and increasing to a higher speed as desired.

3. When finished mixing, move

the speed control to (OFF) and unplug mixer.

NOTE: This hand mixer has a safety feature to protect the motor. If the beaters become locked for more than 3 seconds, the mixer will shut off automatically. Move the speed dial to move dial to desired speed to start mixing.

4. Slide Beater Eject ( ) forward

to remove the beaters.

(OFF), and then

Additional Feature

Burst Function – Press and hold down the speed dial for additional power at any speed.

How to Use

Care and Cleaning

Hand Mixer (cont.)

General Mixing Guide

The following mixing guide is a suggestion for selecting mixing speeds for 6-speed mixers. Begin on speed 1 and increase to desired speed depending on the recipe consistency.

SPEED FUNCTION

1 Stirring Mixing in dry ingredients or liquids 2 Folding Combining a lighter mixture into a heavier

3 Mixing Combining most packaged cake mixes 4 Beating Whipping heavy cream using the whisk 5 Creaming Beating butter and sugar for cookie doughs 6 Whipping Incorporating air into egg whites

OFF

Must be OFF/

mixture and for kneading dough

to eject beaters

w WARNING

Disconnect power before cleaning. Do not immerse mixer, cord, or plug in any liquid.

1. Always unplug mixer from electrical outlet and eject the

attachments before cleaning.

2. Twisted wire beaters and whisk attachments are dishwasher-safe

or wash in hot, soapy water; rinse and dry.

3. Wipe the mixer body and cord with a clean, damp cloth.

NOTE: Do not use abrasive cleaners or scouring pads. To reduce the

risk of electrical shock, do not immerse the mixer body in water at any time.

Electrical Shock Hazard.

Troubleshooting

The motor works very slowly.

• Too many ingredients in the bowl. Remove some ingredients and restart.

The speed control is set too low. Set the speed control to higher speed.

•

The motor does not start.

• The power plug is not plugged into the wall outlet, or the circuit breaker is tripped. Plug into outlet and check function of outlet.

• The hand mixer is not turned on. Move speed control dial to desired speed.

• The motor is damaged. Call our customer service department.

Hand mixer has shut off.

• This hand mixer has a safety feature to protect the motor. If the beaters become locked for more than 3 seconds, the mixer will shut off automatically. Move speed dial to dial to desired speed to start mixing.

(OFF), and then move

Limited Warranty

This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of five (5) years from the date of original purchase in Canada and one (1) year from the date of original purchase in the U.S. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the rating label (e.g., 120 V ~ 60 Hz).

We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition

of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have

other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.
