Hamilton Beach 62632, 62682, 62633, 62695 Instructions Manual

READ BEFORE USE
LIRE AVANT UTILISATION
LEA ANTES DE USAR

Visit www.hamiltonbeach.com for our
complete line of products and Use and
Care Guides – as well as delicious recipes,
tips, and to register your product online!

Rendez-vous sur www.hamiltonbeach.ca
pour notre liste complète de produits et de
nos manuels utilisateur – ainsi que nos
délicieuses recettes et nos conseils

Visite www.hamiltonbeach.com (
o

www.hamiltonbeach.com.mx (México)
para ver otros productos de Hamilton Beach
o para contactarnos

Questions
Please call us – our friendly
associates are ready to help.
USA: 1.800.851.8900

EE. UU.)

Hand Mixers

Batteur

à main

Questions
N’hésitez pas à nous appeler –
nos associés s’empresseront
de vous aider.
CAN : 1.800.267.2826

Preguntas
Por favor llámenos – nuestros
amables representantes están
listos para ayudar.
EE. UU.: 1.800.851.8900
MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este
instructivo antes de usar su aparato.

Batidora

de Mano

English ...................... 2

Français .................... 8

Español ................... 15

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

1. Read all instructions.

2. This appliance is not intended for use by persons with reduced physical,

sensory, or mental capabilities, or lack of experience and knowledge, unless
they are closely supervised and instructed concerning use of the appliance by a
person responsible for their safety.

3. This appliance shall not be used by children. Keep the appliance and its cord
out of reach of children.

4. Close supervision is necessary when any appliance is used near children.
Children should be supervised to ensure that they do not play with the
appliance.

5. To protect against risk of electrical shock, do not put cord, plug, or mixer body
in water or other liquid.

6. Turn the appliance OFF( ), then unplug from outlet when not in use, before
putting on or taking off parts, and before cleaning. To unplug, grasp the plug
and pull from the outlet. Never pull from the power cord.

7. Avoid contacting moving parts. Keep hands, hair, and clothing, as well as
spatulas and other utensils, away from beaters during operation to reduce risk
of injury to persons and/or damage to mixer.

8. Remove beaters from mixer before washing.

9. Do not let cord hang over edge of table or counter or touch hot surfaces,

including stove.

10. Do not operate any appliance with a damaged supply cord or plug, or after
the appliance malfunctions or has been dropped or damaged in any manner.
Supply cord replacement and repairs must be conducted by the manufacturer,
its service agent, or similarly qualified persons in order to avoid a hazard. Call
the provided customer service number for information on examination, repair,
or adjustment.

11. The use of attachments not recommended or sold by the appliance
manufacturer for use with this model may cause fire, electric shock, or injury.

12. Do not use outdoors.

13. Do not place on or near a hot gas or electric burner, or in a heated oven.

14. Check that the appliance is OFF ( ) before plugging cord into wall outlet. To

disconnect, turn the control to OFF ( ); then remove plug from wall outlet. To
unplug, grasp the plug and pull from the outlet. Never pull from the power cord.

15. Do not use appliance for other than intended purpose.

16. CAUTION! In order to avoid a hazard due to inadvertent resetting of the thermal

cut-out, this appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly switched on
and off by the utility.

SAVE THESE INSTRUCTIONS

Other Consumer Safety Information

This appliance is intended for household use only.

IMPORTANT SAFEGUARDS

w WARNING

polarized plug (one wide blade) to reduce the risk of electric shock. The plug fits
only one way into a polarized outlet. Do not defeat the safety purpose of the plug by
modifying the plug in any way or by using an adapter. If the plug does not fit fully
into the outlet, reverse the plug. If it still does not fit, have an electrician replace
the outlet. The length of the cord used on this appliance was selected to reduce
the hazards of becoming tangled in or tripping over a longer cord. If a longer cord
is necessary, an approved extension cord may be used. The electrical rating of the
extension cord must be equal to or greater than the rating of the appliance. Care
must be taken to arrange the extension cord so that it will not drape over the

2

Electrical Shock Hazard: This appliance is provided with a

countertop or tabletop where it can be pulled on by children or accidentally tripped
over.

w CAUTION

To reduce the risk of personal injury, always unplug mixer before inserting or
removing beaters.

WATTAGE/PEAK POWER INFORMATION

The marked rating of the hand mixer is determined by Underwriters Laboratories as
the maximum stabilized power consumption of the hand mixer at high speed under
a loaded condition.

Peak power is an average of the maximum wattage a hand mixer may consume
during initial operation at high speed.

Moving Parts Hazard.

Parts and Features

Optional Accessory on Select Models
To order parts:
US: 1.800.851.8900
www.hamiltonbeach.com
Canada: 1.800.267.2826
Mexico: 01 800 71 16 100

Speed Control

(varies by model)

Please visit www.hamiltonbeach.com for a list of parts, accessories,
and replacement parts that are available for your model.

Flat Beaters

(General Use)

Straight Wire Beaters

(General/Heavy Use)

Speed Control Eject

OR

Eject Button

Attachment

(depending

on model)

Bowl Rest™

Twisted Wire Beaters

(General Use)

Milk Shake

(Ice Cream/Powdered

Drink Mixes)

Snap-On Case

Whisk

(Whipping/Aerating)

Dough Hooks

(Mixing/Kneading)

3

How to Use Your Hand Mixer

1

Make sure mixer is unplugged
and turned to (OFF).

2

Following diagrams on bottom of
mixer, insert desired attachment(s)
into proper openings on bottom
of mixer. Push and click into place.

3

4

OR

5

Move speed control to desired
speed. Start at 1 and increase
speed as needed.

4 4

6

When finished, turn speed control
to (OFF) and unplug mixer.

Speed Control Models

Push speed control to eject
attachments.

Eject Button Models

Push eject button to eject
attachments.

Additional Features

Speed
Control
Button

QuickBurst™
Button

QuickBurst™

Press and hold down the
QuickBurst button for additional
power at any speed.

NOTE: Do not use QuickBurst
for more than two minutes at
a time or motor may overheat.

Bowl Rest™

Use the Bowl Rest while adding
ingredients or checking a recipe.
To use, TURN MIXER OFF; then
set the mixer on the edge of the
bowl.

Never use Bowl Rest when mixer
is on.

Do not use Bowl Rest on small
or plastic mixing bowls.

General Mixing Guide

The following mixing guide is a suggestion for selecting mixing
speeds for 6-speed mixers. Begin on speed 1 and increase to
desired speed depending on the recipe consistency.

SPEED

1

2

3
4
5
6

FUNCTION

OFF ( ) and/or Eject
LOW speed for folding or mixing in dry ingredients,

muffins, or quick breads
To cream butter and sugar; most cookie dough

MEDIUM speed for most packaged cake mixes

Frosting and mashed potatoes; kneading dough
Beating egg whites; kneading dough

HIGH speed for whipping cream

Cookie Dough Mixing Guide

• Use a large mixing bowl so that the ingredients spread out for
easier mixing.

• Butter and margarine should be at room temperature.

• Add flour 1 cup (237 ml) at a time, mixing thoroughly after each
addition.

• Chips and nuts should be stirred by hand.

5

Cleaning

1 2

Storage Options

w WARNING

Disconnect power before cleaning. Do not
immerse mixer, cord, or plug in any liquid.

Electrical Shock Hazard.

OR

Cord Stored in Case Cord-Wrap Storage

6

OR

Wrap-Around Cord Storage

Limited Warranty

This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and
is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of five (5) years from the date of original
purchase in Canada and one (1) year from the date of original purchase in the U.S. During this period, your exclusive remedy is repair
or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs
associated with returning the product to us and our returning a product or component under this warranty to you. If the product or
component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to
the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or
gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the
product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the
rating label (e.g., 120V ~ 60 Hz).

We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All
liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition

of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such
warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have

other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or
special, incidental, or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada
or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers
on your appliance.

7

PRÉCAUTIONS IMPORTANTES

Pour utiliser un appareil électroménager, vous devez toujours prendre des mesures élémentaires de sécurité pour réduire le risqued’incendie, d’électrocution et/ou de
blessure corporelle, en particulier les mesures suivantes :

1. Lire toutes les instructions.

2. Cet appareil n’est pas destiné à être utilisé par des personnes dont les

capacités physiques, sensorielles ou mentales sont réduites, ou manquant
d’expérience et de connaissance, sauf si elles sont étroitement surveillées et
instruites sur l’utilisation de l’appareil par une personne responsable de leur
sécurité.

3. Cet appareil ne devrait pas être utilisé par des enfants. Garder l’appareil et son
cordon hors de la portée des enfants.ts.

4. Une surveillance étroite est requise pour tout appareil utilisé près des enfants.
Surveiller que les enfants ne jouent pas avec l’appareil.

5. Pour protéger contre le risque de choc électrique, ne pas immerger le cordon, la
fiche ou le boîtier du batteur dans l’eau ou autre liquide.

6. Fermer l’appareil ( ), puis le débrancher de la prise lorsqu’il n’est pas utilisé,
avant d’assembler ou de désassembler des pièces ou avant de le nettoyer. Pour
le débrancher, tenir la fiche et la retirer de la prise. Ne jamais tirer sur le cordon.

7. Éviter le contact avec les pièces mobiles. Garder les mains, les cheveux et
les vêtements, de même que les spatules et autres ustensiles, loin des fouets
durant l’opération pour réduire le risque de blessure aux personnes et/ou des
dommages au batteur.

8. Enlever les fouets du batteur avant le lavage.

9. Ne pas laisser le cordon pendre du bord d’une table ou d’un comptoir, ou

toucher des surfaces chaudes, y compris la cuisinière.

10. Ne pas faire fonctionner un appareil électroménager avec un cordon ou une
fiche endommagée, ou lorsque l’appareil ne fonctionne pas bien ou a été
échappé ou endommagé d’une manière quelconque. Le remplacement et la
réparation du cordon d’alimentation doivent être faits par le fabricant, son agent
de service ou toute personne qualifiée de façon à éviter tout danger. Appeler
le numéro de service à la clientèle fourni pour des renseignements concernant
l’examen, la réparation ou l’ajustement.

11. L’utilisation d’accessoires non recommandés ou vendus par le fabricant de
l’appareil pour utilisation avec ce modèle peut causer un incendie, un choc
électrique ou une blessure.

12. Ne pas utiliser à l’extérieur.

13. Ne pas placer l’appareil sur ou près d’un brûleur à gaz ou d’un élément

électrique chaud, ou dans un four chauffé.

14. S’assurer que l’appareil est OFF ( /arrêt) avant de brancher la fiche dans la
prise de courant. Pour débrancher, tourner la commande à et mettre à OFF
( /arrêt) puis débrancher la fiche de la prise de courant. Pour débrancher,
saisir la fiche et la retirer de la prise. Ne pas tirer sur le cordon d’alimentation.

15. Ne pas utiliser l’appareil pour un usage autre que celui auquel il est destiné.

16. ATTENTION ! Afin d’éviter un danger découlant d’une réinitialisation

accidentelle du rupteur thermique, se dispositif ne doit pas être alimenté par
l’entremise d’un appareil de connexion externe, comme une minuterie, ou
connecté à un circuit qui est régulièrement mis sous et hors tension par le
service public.

CONSERVEZ CES INSTRUCTIONS

8

8
