Hamilton Beach 49618 User Guide
READ BEFORE USE
LIRE AVANT UTILISATION
LEA ANTES DE USAR
Visit www.hamiltonbeach.com for our
complete line of products and Use and
Care Guides – as well as delicious recipes,
tips, and to register your product online!
Rendez-vous sur www.hamiltonbeach.ca
pour notre liste complète de produits et de
nos manuels utilisateur – ainsi que nos
délicieuses recettes et nos conseils !
¡Visite www.hamiltonbeach.com (
o
www.hamiltonbeach.com.mx (México)
para ver otros productos de Hamilton Beach
o para contactarnos!
Questions?
Please call us – our friendly
associates are ready to help.
USA: 1.800.851.8900
Questions ?
N’hésitez pas à nous appeler –
nos associés s’empresseront
de vous aider.
CAN : 1.800.267.2826
¿Preguntas?
Por favor llámenos – nuestros
amables representantes están
listos para ayudar.
EE. UU.: 1.800.851.8900
MEX: 01 800 71 16 100
Le invitamos a leer cuidadosamente este
instructivo antes de usar su aparato.
EE. UU.)
Coffeemaker
Cafetière
Cafetera
English ...................... 2
Français ................... 11
Español ................... 21
840239200 ENv08.indd 1 3/12/14 11:08 AM
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to
persons, including the following:
1. Read all instructions.
2. This appliance is not intended for use by persons (including
children) with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, unless they are closely
supervised and instructed concerning use of the appliance by a
person responsible for their safety.
3. Close supervision is necessary when any appliance is used by or
near children. Children should be supervised to ensure that they
do not play with the appliance.
4. Do not touch hot surfaces. Use handles or knobs. Care must
be taken, as burns can occur from touching hot parts or from
spilled, hot liquid.
5. To protect against electric shock, do not place cord, plug, or
coffeemaker in water or other liquid.
6. Unplug from outlet when either the coffeemaker or clock is not
in use and before cleaning. Allow to cool before putting on or
taking off parts and before cleaning the appliance.
7. Coffeemaker must be operated on a flat surface away from the
edge of counter to prevent accidental tipping.
8. Do not operate any appliance with a damaged cord or plug,
or after the appliance malfunctions or is dropped or damaged
in any manner. Call our toll-free customer service number for
information on examination, repair, or adjustment.
9. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
10. Do not use outdoors.
11. Do not let cord hang over edge of table or counter or touch hot
surfaces, including stove.
12. Do not place coffeemaker on or near a hot gas or electric burner
or in a heated oven.
13. The carafe is designed for use with this coffeemaker. It must
never be used on a range top or in a microwave oven.
14. Do not set a hot carafe on a wet or cold surface.
15. Do not use a cracked carafe or one with loose or weakened
handle.
16. Do not clean carafe with cleansers, steel wool pads, or other
abrasive materials.
17. Be certain carafe lid is securely in place during brew cycle and
when pouring coffee. Do not use force when placing lid on
carafe.
18. To disconnect coffeemaker, turn controls to OFF (O) and then
remove plug from wall outlet.
19. WARNING! To reduce the risk of fire or electric shock, do not
remove the bottom cover. No user-serviceable parts are inside.
Repair should be done by authorized service personnel only.
20. Do not use appliance for other than intended use.
SAVE THESE INSTRUCTIONS!
2
840239200 ENv08.indd 2 3/12/14 11:08 AM
Other Consumer Safety Information
This appliance is intended for household use only.
WARNING! Shock Hazard: This appliance has a polarized plug (one
wide blade) that reduces the risk of electric shock. The plug fits only
one way into a polarized outlet. Do not defeat the safety purpose of
the plug by modifying the plug in any way or by using an adapter.
If the plug does not fit fully into the outlet, reverse the plug. If it still
does not fit, have an electrician replace the outlet.
Carafe Safety Precautions
The length of the cord used on this appliance was selected to
reduce the hazards of becoming tangled in or tripping over a longer
cord. If a longer cord is necessary, an approved extension cord
may be used. The electrical rating of the extension cord must be
equal to or greater than the rating of the appliance. Care must be
taken to arrange the extension cord so that it will not drape over
the countertop or tabletop where it can be pulled on by children or
accidentally tripped over.
To avoid an electrical circuit overload, do not use another highwattage appliance on the same circuit with your appliance.
This symbol alerts you to the potential danger for personal
injury if you fail to read and follow these safety precautions.
• Do not use a cracked carafe or a carafe having a loose or
weakened handle.
• This carafe is designed to be used only on the warming plate of
your coffeemaker. Do not use on a gas or electric rangetop, or in
a microwave or conventional oven.
• To avoid breakage, handle carafe with care. Avoid impact. Glass
will break as a result of impact. Use care when filling with water to
avoid hitting faucet.
• Do not place hot carafe on cool or wet surface. Allow to cool
before washing or adding liquids.
• Do not set empty carafe on a hot heating surface.
• Do not clean with steel wool pads, abrasive cleanser, or any other
materials that may scratch.
840239200 ENv08.indd 3 3/12/14 11:08 AM
• Do not place hands inside carafe. When handling, be careful if
• Do not bump, scratch or boil dry.
• Discard carafe if it is cracked, scratched, or heated while empty for
• To avoid accidents, do not pour in the direction of people.
• If stirring in the carafe, use only wooden, plastic, or rubber utensils.
• Follow the above safety precautions carefully to avoid serious burn
This symbol reminds you that glass is fragile and can break
which could result in personal injury.
wearing any hand jewelry, especially diamond rings. Jewelry can
scratch the glass, which increases the possibility of breakage.
an extended period of time.
Do not use metal utensils.
injuries which may result if breakage occurs while carafe holds
heated liquids.
3
Parts and Features
*To order parts:
US: 1.800.851.8900
www.hamiltonbeach.com
Canada: 1.800.267.2826
Mexico: 01 800 71 16 100
Control Panel/Display
Water Reservoir
Lid
Filter Basket*
Carafe*
4
840239200 ENv08.indd 4 3/12/14 11:08 AM
Warming Plate
How to Make Coffee
w WARNING
To avoid hot coffee overflowing from the filter basket:
• When using decaffeinated coffee, do not exceed the coffee
manufacturer’s recommended serving amount.
• If filter basket overflow occurs, unplug coffeemaker and allow
coffee in filter basket to cool before removing filter basket.
Burn Hazard.
1
Lift lid. Insert filter basket. Place a cone-shaped #4 paper filter in filter basket. For each cup of
5
840239200 ENv08.indd 5 3/12/14 11:09 AM
2
6
Place carafe, with carafe lid
attached, on nonstick warming
plate.
coffee being made, place one level Tablespoon (15 ml) ground coffee
into filter.
7
Press (ON/OFF) button to
start and the red ON light will
illuminate.
43
5
How to Make Coffee (cont.)
PAUSE AND SERVE:
To serve coffee during the
brewing cycle, remove carafe
and pour a cup. By removing the
carafe, the flow of coffee from
the bottom of the filter basket will
stop.
WARNING! Burn Hazard. The
carafe must be replaced within
20 seconds of being removed to
prevent overflow.
8
Press BREW OPTIONS button
until desired option is selected:
Regular, Bold, or 1–4 cups, if
brewing a smaller amount of
coffee.
Tips for Best-Tasting Coffee
• All coffees are made from either arabica beans or robusta beans,
or some combination of both. Arabica beans are slightly more
expensive, but tend to produce better-tasting coffee.
• Ground coffee will become stale much faster than whole beans.
If buying preground coffee, choose a package with the latest
expiration date or a smaller quantity.
• If grinding whole beans, set your coffee grinder on a fine/medium
grind. This will yield the best-tasting grounds. Try to use freshly
ground coffee within about a week of grinding.
NOTE: Empty coffee grounds
from filter basket after each use.
Wash with warm soapy water and
rinse after each use.
9
Press (ON/OFF) button when
finished. NOTE: If the coffeemaker
is not turned off manually, it will
automatically shut off in 2 hours
and the red ON light will turn off.
• Using a water filter, filtered water, or bottled water will yield bettertasting coffee than tap water.
• Use approximately 1 Tablespoon (15 ml) of grounds for each cup of
coffee being made. To avoid overflow, use slightly less grounds
(3/4 Tablespoon [11.1 ml]) when brewing decaf or flavored coffees.
Also, be aware that using coffee that is ground too finely may also
cause the filter basket to overflow.
• Make sure your coffeemaker is clean. See “Care and Cleaning”
section.
6
840239200 ENv08.indd 6 3/12/14 11:09 AM
Programming
1 2
Press HOUR and then MINUTE to
set clock. Make sure to select AM
or PM.
840239200 ENv08.indd 7 3/12/14 11:09 AM
While holding PROG (program)
button, press HOUR and MINUTE
until the desired brewing start
time is reached.
3
Press and release PROG button
for less than 1 second to
set coffeemaker to come on
automatically at the desired
time. Press PROG again to cancel
automatic brew. A green light
above AUTO will illuminate next
to the display to let you know
your DELAYED START is set.
7
w WARNING
Care and Cleaning
All coffeemakers should be cleaned at least once a month (once a week for areas with hard water).
Do not immerse cord, plug, or coffeemaker in any liquid.
Shock Hazard.
1 2
Remove optional water filter. Pour 1 pint (2 cups/473 ml) vinegar into
water reservoir.
Press
seconds and wait 30 minutes.
Press (ON) button. Press
(OFF) button again when finished.
(ON) button. Press
(OFF) button again after 30
43
Run 2–3 more brew cycles with
CLEAN WATER only. Allow to
cool between cycles.
TOP-RACK
DISHWASHER-SAFE
DO NOT use the “SANI” setting when washing in the dishwasher.
“SANI” cycle temperatures could damage your product. DO NOT
clean warming plate until coffeemaker is unplugged and completely
cooled.
8
840239200 ENv08.indd 8 3/12/14 11:09 AM
5
Troubleshooting
PROBLEM PROBABLE CAUSE/SOLUTION
Filter basket overflows or
coffee brews slowly.
Coffee tastes bad. • Coffeemaker needs cleaning.
Coffee not brewing or
unit will not turn on.
• Excessive amounts of ground coffee.
• Decaffeinated and/or coffee ground too finely can cause overflow. Use slightly less grounds when brewing
decafeinated, flavored, or finely ground coffee. Or use medium ground coffee.
• Coffeemaker needs cleaning.
• Coffee ground too coarsely or too finely. Use medium ground coffee.
• Coffee-to-water ratio unbalanced. Adjust for personal preference.
• Poor coffee quality and freshness.
• Poor water quality (use filtered or bottled water).
• Water reservoir is empty.
• Unit is unplugged.
• Power outage.
• Power surge. Unplug; then plug the unit back in.
• Clock requires reset after power outage.
9
840239200 ENv08.indd 9 3/12/14 11:09 AM
Limited Warranty
This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and
is in lieu of any other warranty or condition.
This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original
purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective,
at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or
component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal
or greater value.
This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to
the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or
gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the
product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the
rating label (e.g., 120V ~ 60 Hz).
We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All
liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition
of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such
warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have
other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or
special, incidental, or consequential damages, so the foregoing limitations may not apply to you.
To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada
or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers
on your appliance.
10
840239200 ENv08.indd 10 3/12/14 11:09 AM
Loading...
