Hamilton Beach 45400 User Guide

READ BEFORE USE LIRE AVANT UTILISATION LEA ANTES DE USAR

Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guides – as well as delicious recipes, tips, and to register your product online.

Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos manuels utilisateur – ainsi que nos délicieuses recettes et nos conseils.

Visite www.hamiltonbeach.com ( o

www.hamiltonbeach.com.mx (México) para ver otros productos de Hamilton Beach o para contactarnos.

EE. UU.)

Grounds Dispensing

Coffee Maker

Questions Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

Questions N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider. CAN : 1.800.267.2826

Preguntas Por favor llámenos – nuestros amables representantes están listos para ayudar. EE. UU.: 1.800.851.8900 MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

Cafetière/distributrice

de café moulu

Cafetera Dispensadora

de Café Molido

English ....................... 2

Français .................... 13

Español .................... 25

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

Read all instructions.

This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety.

Close supervision is necessary when any appliance is used by or near children. Children should be supervised to ensure that they do not play with the appliance.

Do not touch hot surfaces. Use handles or knobs. Care must be taken as burns can occur from touching hot parts or from spilled, hot liquid.

To protect against electric shock, do not place cord, plug, or coffee maker in water or other liquid.

Unplug from outlet when either the coffee maker or clock is not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.

Coffee maker must be operated on a flat surface away from the edge of counter to prevent accidental tipping.

Do not operate any appliance with a damaged supply cord or plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Supply cord replacement and repairs must be conducted by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard. Call the provided customer service number for information on examination, repair, or adjustment.

The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electrical shock, or personal injury.

10.

Use only the carafe provided with the appliance.

11.

Do not use outdoors.

12.

Do not let cord hang over edge of table or counter or touch hot surfaces, including stove.

13.

The carafe is designed for use with this coffee maker. It must never be used on a range top or in a microwave oven.

14.

Do not set a hot carafe on a wet or cold surface.

15.

Do not use a cracked carafe or one with a loose or weakened handle.

16.

Do not clean carafe with cleansers, steel wool pads, or other abrasive materials.

17.

Be certain carafe lid is securely in place during brew cycle and when pouring coffee. Do not use force when placing lid on carafe.

18.

Do not place coffee maker on or near a hot gas or electric burner or in a heated oven.

19.

To disconnect coffee maker, turn controls to OFF ( ) and then remove plug from wall outlet.

20.

WARNING! To reduce the risk of fire or electric shock, do not remove

the bottom cover. No user-serviceable parts are inside. Repair should be done by authorized service personnel only.

21.

Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS

Other Consumer Safety Information

IMPORTANT SAFEGUARDS

This appliance is intended for household use only.

w WARNING

with a polarized plug (one wide blade) to reduce the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician replace the outlet.

Electrical Shock Hazard: This appliance is provided

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

To avoid an electrical circuit overload, do not use another high-wattage appliance on the same circuit with this appliance.

Parts and Features

*To order parts: US: 1.800.851.8900 www.hamiltonbeach.com Canada: 1.800.267.2826 Mexico:

BEFORE FIRST USE: Wash carafe and brew basket in hot, soapy water. Rinse and dry. Brew one cycle with water and discard water.

01 800 71 16 100

SMART Brew Basket

Grounds Container With Lid*

Water Reservoir Lid

Top Cover (use when grounds container is removed)

Open Button for Brew Basket

Lid to Access Water Reservoir Filter

Control Panel With Clock and Scoop Indicator

PROGRAM Button TIME Button

BREW OPTIONS Button

Scoop –/+ Selectors

BREW NOW (I/ ) Button

Water Filter* Not Included

Pod*

Carafe*

Keep-Warm Plate

Power Light

Cleaning Brush*

How to Make Coffee With Grounds Container

w WARNING

To avoid hot coffee overflowing from the filter basket:

• When using decaffeinated coffee, do not exceed the coffee

manufacturer’s recommended serving amount.

• Ensure swivel filter basket is completely closed. If filter basket overflow occurs, unplug coffee maker and allow coffee

in filter basket to cool before removing filter basket.

w WARNING

Do not immerse cord, plug, or coffee maker in any liquid.

1. Make sure coffee maker is unplugged.

Place grounds container into opening on top of coffee maker, aligning the three arrows. Turn clockwise until you hear a click and the arrow is aligned to the lock icon.

2. Plug into outlet.

Burn Hazard.

Electrical Shock Hazard.

3. Press TIME button until hours flash in

display. Pulse TIME button to set current hour in AM or PM. Release TIME button and minutes will flash in display.

4. Press TIME button within 3 seconds to

set current minutes. Set time will display constant in 3 seconds.

5. Fill carafe with water; lift water reservoir

lid to add water.

6. Press OPEN button to open SMART brew

basket. Add paper filter to basket. Push basket until it clicks closed. Do not open until brewing cycle is complete and unit is cool.

7. Pour one bag ground coffee (no more

than a 12-ounce [340-g] bag) into grounds container. Place lid onto container and push to seal. This coffee maker is for grounds only. Do not use whole beans; this is not a coffee grinder.

How to Make Coffee With Grounds Container (cont.)

8. Press BREW OPTIONS. Choose BOLD for

stronger coffee or 1–4 CUPS for smaller quantity. Default is REGULAR.

9. Press + or – button to select the amount

of scoops (1 scoop = 1 tablespoon [15 ml]) of ground coffee you want to brew.

10. Press BREW NOW button once to turn on the coffee

maker and button will illuminate. When finished, press BREW NOW button once and unplug. NOTE: If the coffee maker is not turned off manually, it will shut off automatically in 2 hours and the light will turn off.

How to Make Coffee Without Using Grounds Container

This coffee maker can be used like a standard automatic drip coffee maker by adding ground coffee to the brew basket yourself.

Option 1: To remove grounds container.

1. Turn grounds container counterclockwise, aligning the container

arrow with the unlocked icon. Lift container up to remove.

2. Place top lid on coffee maker.

3. Press – or + buttons until 0 scoops are

displayed. When grounds container is removed, this coffee maker will not brew unless the scoop count is 0.

4. Press OPEN button to open SMART

brew basket. Add paper filter and desired amount of ground coffee.

5. Add water to water reservoir. Press

BREW NOW button.

OR Option 2: Leaving grounds container

locked in place.

1. Press – or + buttons until 0 scoops are

displayed. IMPORTANT! This coffee maker will dispense the amount of scoops showing in display, adding additional grounds to brew basket.

2. Press OPEN button to open brew

basket. Add paper filter and desired amount of ground coffee.

3. Add water to water reservoir. Press

BREW NOW button.

To Program

Tips for

Automatic Brew

NOTE: White LED comes on to indicate PROGRAM is activated. White LED light goes off when unit begins to brew at preprogrammed time.

1. Choose a brew option.

2. Press and hold PROG button until HOUR light flashes.

3. While pressing PROG button, press the

TIME button to select the desired brew time. Release PROG button and time will be set.

4. Programmed time will be stored and the

current time will be displayed.

5. Press and release PROG button again

to activate automatic brew. PROG light comes on.

Best-Tasting Coffee

• All coffees are made from either arabica beans or robusta beans, or some combination of both. Arabica beans are slightly more expensive, but tend to produce better-tasting coffee.

• Ground coffee will become stale much faster than whole beans. If buying preground coffee, chose a package with the latest expiration date or a smaller quantity.

• If grinding whole beans, set your coffee grinder on a fine/medium grind. This will yield the best-tasting grounds. Try to use freshly ground coffee within about a week of grinding.

• Using a water filter, filtered water, or bottled water will yield bettertasting coffee than tap water.

• Use approximately 1 tablespoon (15 ml) of grounds for each cup of coffee being made. To avoid overflow, use about 1/3 less grounds when brewing decaf or flavored coffees.

• Make sure your coffee maker is clean. See “Care and Cleaning” section.

Care and Cleaning

How to Replace

w WARNING

Do not immerse cord, plug, or coffee maker in any liquid. All coffee makers should be cleaned at least once a month (once a

week for areas with hard water).

1. Unplug.

2. Wipe coffee maker with a damp cloth or sponge. Dry.

3. Remove water filter and water filter base (see “How to Replace

the Water Filter”).

4. Pour a minimum of 1 pint (2 cups/473 ml) white vinegar into

water reservoir.

5. Plug in and press BREW NOW (I/ ) button once. After 30 seconds,

turn OFF. Wait 30 minutes to allow vinegar to clean. Then turn ON again. When brew cycle is finished, wait for unit to cool.

6. Empty carafe and rinse. Run 2–3 more brew cycles with CLEAN

WATER only. Allow to cool between cycles.

7. Wash in warm, soapy water. Rinse and dry. The carafe and filter

basket are dishwasher-safe to wash and dry in TOP RACK only.

Electrical Shock Hazard.

the Water Filter

1. Soak filter pod for 15 minutes in water.

15 min.

2. Add pod to bottom of water filter and

snap on filter handle.

3. Place assembly into right side of water

reservoir. For better-tasting coffee, use a water filter. Filter replacement is recommended every

30 cycles.

Carafe Safety Precautions

This symbol alerts you to the potential danger for personal injury if you fail to read and follow these safety precautions.

This symbol reminds you that glass is fragile and can break which could result in personal injury.

• Do not use a cracked carafe or a carafe having a loose or weakened handle.

• This carafe is designed to be used only on the keep-warm plate of your coffee maker. Do not use on a gas or electric rangetop, or in a microwave or conventional oven.

• To avoid breakage, handle carafe with care. Avoid impact. Glass will break as a result of impact. Use care when filling with water to avoid hitting faucet.

• Do not place hot carafe on cool or wet surface. Allow to cool before washing or adding liquids.

• Do not set empty carafe on a hot heating surface.

• Do not clean with steel wool pads, abrasive cleanser, or any other materials that may scratch.

• Do not place hands inside carafe. When handling, be careful if wearing any hand jewelry, especially diamond rings. Jewelry can scratch the glass, which increases possibility of breakage.

• Do not bump, scratch, or boil dry.

• Discard carafe if it is cracked, scratched, or heated while empty for an extended period of time.

• To avoid accidents, do not pour in the direction of people.

• If stirring in the carafe, use only wooden, plastic, or rubber utensils. Do not use metal utensils.

• Follow the above safety precautions carefully to avoid serious burn injuries which may result if breakage occurs while carafe holds heated liquids.

Troubleshooting

Filter basket overflows or coffee brews slowly.

• The BOLD or 1–4 CUPS brew option is recommended for brewing

decaffeinated coffee.

• Excessive amounts of coffee.

• Coffee ground too finely (not automatic drip grind).

• Carafe not securely placed on keep-warm plate or SMART brew

basket not closed completely.

• Carafe removed during brewing for more than 20 seconds and not

placed securely back on keep-warm plate.

• Coffee maker needs cleaning.

• Coffee grounds between paper filter and basket holder.

• Paper filter not open and in proper position.

• Poor-quality paper filter.

Coffee not brewing/unit will not turn on.

• Water reservoir is empty.

• Unit is unplugged.

• Power outage.

• Power surge. Unplug; then plug the unit back in.

• Clock requires reset after power outage.

Reminders

• Stopping a dispensing cycle by opening

the basket holder or pressing the I/ button will cause the scoop number to flash. This means that a new dispense cycle will begin once the unit is restarted. Empty the dispensed coffee grounds to avoid having too much in the basket holder, and start process from the beginning.

• When the SMART brew basket is not

in place or not closed all the way and a cycle is started, the message “nO bAS” is displayed. This message is removed when the SMART brew basket is detected.

• If there is no water in the reservoir, the

message “FIL H2O” is displayed. Once water is added and the cycle is restarted, the message disappears, coffee grounds dispensing is bypassed, and brewing begins.

sec

• If the basket holder is not opened after

the last brew (to clean out old grounds), the message “bAS Err” is displayed. Once the basket holder is opened, the message is removed.

• If the grounds container is not in place

and scoop number is set to anything but 0 and a cycle is started, the unit shuts off.

• When programming the Auto On time,

the clock display shows “START TIME.” Once this time is set, this message is turned off.

• When the program mode is enabled,

a white LED is illuminated above the PROG button.

sec

Limited Warranty

This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of five (5) years from the date of original purchase in Canada and one (1) year from the date of original purchase in the U.S. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the rating label (e.g., 120 V ~ 60 Hz).

We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition

of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have

other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.
