TFT-LCD TELEVISION
OWNER`S MANUAL
MODELS: L37A9-AK
L37A9-AKF
Please READ this manual carefully before
operating your TV, and retain it for future
reference.
Congratulations on your purchase, and welcome to the family !
Dear Haier product owner:
Thank you for your confidence in Haier. You`ve selected one of the
best-built, best-backed products available today. We`ll do everything
in our power to keep you happy with your purchase for many years to
come.
As a member of the Haier family, you`re entitled to protection by
one of the most comprehensive warranties and outstanding service
networks in the industry.
thanks for investing in a Haier product.
""
""
CONTENTCONTENT
BEFORE OPERATING
Warning..............................................................................................................1
Important Safety Instructions..............................................................................2
Buttons and interface location........................................................................... 4
Remote controller...............................................................................................6
Remote controller key function...........................................................................7
External equipment connections........................................................................8
BASIC OPERATING
Switching on/off the TV set................................................................................14
Choose the Menu language............................................................................. 14
Choose the Input Source ................................................................................. 14
Searching Channel............................................................................................15
Watching TV Program........................................................................................18
Picture Control Functions................................................................................. .19
Sound Control Functions....................................................................................21
Timer Functions..................................................................................................23
Function Menu...................................................................................................24
Adjust Menu.......................................................................................................27
Lock Setup ........................................................................................................28
OTHERS
Others functions................................................................................................30
Stream media broadcast system.......................................................................31
Maintenance......................................................................................................44
Troubleshooting.................................................................................................45
Specifications ...................................................................................................46
Format..............................................................................................................47
Accessories
Remote controller
User's manual
Alkaline battery
(AAA) 2
Power cable
Warning
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
*To avoid electric hazards, it is strongly suggested that the back cover not be opened, as
there is no any accessory inside the casing.
*If necessary, please contact authorized after-sales services.
*A lighting flash mark in a triangle: A potentially hazardous situation, which, if not avoided,
could result in serious injury by high voltage.
*An exclamation mark in a triangle: Major part or accessory of which technical specifications
must be followed if it is to be replaced.
Warning:
To avoid fire or electric hazards, never place your television receiver in an area
with heavy moisture. Attention should be paid to avoid accidental scratches or
impacts onto the screen.
Caution:
Please read this manual carefully before using your television and keep this
manual in a good place for future reference.
To achieve the best performance of your television, read this User's Manual
carefully and properly store it for future reference.
Information of screen displays and figures in the User's Manual may vary due
to technical innovations.
Caution:
Unauthorized disassembly of this product is prohibited.
1
Important Safety Instructions
The product should be tightly fixed to avoid
drop damages and even fire.
Do not locate the product close to water
or oil, which may cause fire hazards.
Do not use damaged or worn electric plugs
and keep electric cord away from heat sources
to avoid electric shocks or fire hazards.
To avoid fire hazards, do not use this
product under direct sunlight or closely
to heat sources.
Unplug the power supply and antenna of
the product when there is a rainstorm,
especially
Thunderstorm.
Do not connect excessive sockets in parallel
or share the same socket by multiple plugs
to avoid fire hazards.
The product must be placed on a solid and
stable surface to avoid collapse.
Keep the product away from a transformer
or heat source to avoid fire hazards.
2
Unauthorized disassembly of the television
is prohibited to avoid electric shocks or fire
hazards. Contact
authorized after-sales
service if technical
service is needed.
Disconnect the product from power supply
and contact authorized after-sales service
if abnormal sound is heard in the product.
Important Safety Instructions
Don't use or store inflammable materials
near the product to avoid explosion or fire
hazards.
The antenna of the product should be away
from electric cable to avoid
electric shocks.
Always make sure that the televisionis well
plugged as poor electric
connection might cause fire.
Don't place the product in a humid area to
avoid fire hazards.
Never touch the plug when your hand is wet
as this might cause electric shocks.
When antenna is used, measures should be
taken to prevent water
from flowing down
along the cable into
the television.
Unplug the television, use soft fabric, never
chemicals, if you are going to make
cleaning of the product.
Make sure that no
water drops in the
product.
Disconnect the television from power supply
and antenna when there is a
rainstorm or thunderstorm
to avoid electric shocks
or fire hazards.
The plug and electric cable must be kept
clean to avoid electric
shocks or fire
hazards.
Disconnect the television from power supply
to avoid electric shocks or fire
hazards in a long
vocation.
3
Buttons and interface location
- This is a simplified representation of front panel.
- Here shown may be somewhat different from your TV.
Front panel Control
- CH + - PRO +
TV/AV MENU
Buttons and functions
1 Channel number increase and decrease.
2 Volume decrease: for lowering the volume or adjusting the menu.
Volume increase: for enhancing the volume or adjusting the menu.
3 TV/AV button
4 Menu button
5 Power and indicator: for turning on or off the power supply.
6 Remote receiving window
7 Card jack
4
Buttons and interface location
Rear panel Control
9
10
IN1 IN2
AC IN
HDMI /DVI VIDEO
1 2
VGA IN
3
Side Av2
AUDIO Input
connect to hear
VIDEO
L
AUDIO
R
AC In
HDMI Input Connnect a signal to HDMI/DVI
VGA Input
DVD/DTV Input (Component )
Connect a component video/audiodevice to these jacks.
Input
AV1
Connect audio/video out from an audio/video device to these jacks.
S-Video Input Connect S-Video out from a S-Video device to these jacks.
Earphone jack Earphone Audio output terminal
Antenna Input Connect cable or antenna signals to the TV, either directly or
through your cable box.
WooferConnect loudhailer output
Video/Audio output terminal
Connect ordinary video/audio or other appliance audio input terminals.
stereo sound from an
external device.
VIDEO Input
Connects the video
signal from a video
device.
This TV operates on AC power. Never attempt to operate the TV on DC power.
Connect the monitor output connector from a PC to the jack
terminal
Y Pb/Cb Pr/Cr
AV OUT
L AUDIO R
IN
AV IN
4
WOOFER
L
ANT. IN
S-VIDEO IN
AUDIO OUT
R
L AUDIO R VIDEO
8
5
Remote controller
Battery loading
1.Slide open the cover of the battery compartment on the back of the remote controller.
2.Load two 7# (AAA)alkaline batteries in the compartment. (plus and minus poles to
respective mark)
3.Replace the cover of the battery compartment.
1
2
Precautions
As strong light may interfere the
signals, change your position to
operate the remote controller if
the television cannot be turned
on or off as you expect.
Keep the remote controller away from
heat source or humid area to ensure
effective performance of the remote
controller.
3
Make sure that two AA alkaline batteries
are loaded. The batteries must be of the
same type. The batteries must be
located properly. The batteries are not
rechargeable.
Make sure that there is no obstacle
between the remote controller and
television set.
6
Remote controller key function
Information display
Display of current channel
signals, program and systems
Picture still
Switches the sound on or off.
select S-Video.
VOLUME UP/DOWN
Increases/decreases
the sound level.
CHANNEL UP/DOWN
Selects available channels
found with Auto search.
Picture mode option
Standard, Soft,
Bright, Personal
CHANNEL select
PIP mode buttons
Swap: main picture and
sub picture exchange
MUTE
S-Video mode
TV/VIDEO
OK button
(no available)
PIP: PIP select
Shuttle button
Sleep button
POWER
Turns your TV or any other
programmed equipment on
or off, depending on mode.
DISPLAY
MUTE
STILL
POWER
I/II
PIC.SIZE
Nicam select button
Picture SIZE button
picture scale
DVD mode
S-VIDEO
DVD/DTV
TV/AV
PC/DVI
Select DVD mode
PC/DVI mode
OK
Q.VIEW
Select PC/DVI mode.
Q.VIEW
Return to the last channel
viewed.
MENU
VOL-
CH+
MENU
VOL+
Brings up the main menu
CH-
S
5
H.LOCK
SM
3
6
ZOOM/MOVE
CH.EDIT
Timer SKIP
PSM
1 2
4
7 8 9
-/-- 0
PIP SWAP SCAN
SHUTTLE
SLEEP
to the screen.
Sound mode option
, Personal,
Theater
Standard, Music
NUMBER buttons
Zoom/Move
Program edit
Scan
scan program
Timer skip button
USB
ZOOM
RETURN
HELPENTER
H.clock button
USB system buttons
7
External Equipment Connections
- Antenna or Cable Service without a Cable Box Connections
- For optimum picture quality, adjust antenna direction if needed.
outdoor
antenna
(not supply)
Antenna input
75 standard
coaxial type
ANT IN
300 twin-lead cable
Antenna adapter
(not supply)
75 coaxial cable
Plug
(additional purchase)
Note
* It is recommended that you'd better use 75
disturbance caused by airwave.
* Don't bind antenna cable and electric wire together.
To improve picture quality in a poor signal area, purchase
and install a signal amplifier.
If the antenna needs to be split for two Tv`s, install a 2-
WaySignal Splitter in the connections.
If the antenna is not installed properly, contact your dealer
for assistance.
coaxial cable to remove the
8
External Equipment Connections
NOTE: All cables shown are not included with the TV.
Choose Your Connection
There are several ways to connect your television, depending on the components you
want to connect and the quality of the signal you want to achieve. The following are
examples of some ways to connect your TV.
Choose the connection which is best for you.
VCR Connection
- To avoid picture noise (interference), leave an adequate distance between the VCR and TV.
Connection Option 1
Set VCR output switch to channel 3 or 4 and
then tune the TV to the same channel number.
Connection Option 2
1. Connect the audio and video cables from the
VCR's output jacks to the TV input jacks, as
shown in the figure.
When connecting the TV to VCR, match the
jack colors (Video = yellow, Audio Left = white,
and Audio Right = red).
If you connect an S-VIDEO output from VCR to
the S-VIDEO input, the picture quality is
improved; compared to connecting a regular
VCR to the Video input.
2. Insert a video tape into the VCR and press
PLAY on the VCR. (Refer to the VCR owner`s
manual.)
3. Select the input source with using the
INPUT button on the remote control, and
then press CH+/- button to select the source,
press the VOL+ button to confirm.
L AUDIO R
AV OUT
L AUDIO R
VIDEO
S-VIDEO IN
AV IN
ANT. IN
9
External Equipment Connections
DVD Setup
How to connect
1. Connect the DVD video outputs (Y, Pb/Cb,
Pr/Cr) to the COMPONENT (Y, Pb/Cb, Pr/Cr)
input jacks on the TV and connect the DVD
audio outputs to the AUDIO jacks on the TV,
as shown in the figure.
2. If your DVD only has an S-Video output jack,
connect this to the S-VIDEO input on the TV
and Connect the DVD audio outputs to the AV IN
jacks on the TV, as shown in the figure.
NOTE: If your DVD player does not have
component video output, use S-Video.
How to use
1. Turn on the DVD player, insert a DVD.
2. Use the S-Video button on the remote
control to select S-VIDEO or YPbPr/YCbCr
mode.
3. Press Play button on external equipment
for program play.
4. Refer to the DVD player's manual for
operating instructions.
Y PbPr CbCr
L AUDIO R
IN
or
DVD
AV1 IN
AV OUT
L AUDIO R VIDEO
S-VIDEO IN
HDMI or DVI Setup
-To watch digitally broadcast programs,
purchase and connect a digital set-top
box.
IN1 IN2
How to connect
Use the TV`s COMPONENT (Y, Pb/Cb,
Pr/Cr) INPUT jacks, VGA or HDMI port for
video connections, depending on your
set-top box connections available.
Then, make the corresponding audio
connections.
How to use
1. Turn on the digital set-top box.
(Refer to the owner`s manual for the digital set-top box.)
2. Use TV/AV on the remote control to select VGA or HDMI
(Y, Pb/Cb, Pr/Cr) mode.
3. Press Play button on external equipment for program play.
10
HDMI/DVI VIDEO
VGA IN
Y PbCb CbCr
L AUDIO R
AV OUT
L AUDIO R VIDEO
AV IN
External Equipment Connections
PC Setup
How to connect
1. Use the TV`s VGA IN port for video connections.
2. Then, make the corresponding audio
connection. If using a sound card, adjust the
PC sound as required.
How to use
1. Turn on the PC and the TV.
2. Turn on the display by pressing the POWER
button on the TV's remote control.
IN1 IN2
HDMI/DVI VIDEO
VGA IN
Y PbCb PrCr
L AUDIO R
IN
3. Use PC/DVI on the remote control to select
VGA source.
4. Check the image on your TV. There may be
noise associated with the resolution, vertical
pattern, contrast or brightness in PC mode.
If noise is present, change the PC mode to
another resolution, change the refresh rate to
another rate or adjust the brightness and contrast
on the menu until the picture is clear. If the refresh
rate of the PC graphic card can not be changed,
change the PC graphic card or consult the manufacturer
of the PC graphic card.
NOTES:
1 Avoid keeping a fixed image on the TV's screen for a long period of Time. The fixed image
may become permanently imprinted on the screen.
2 The synchronization input form for Horizontal and Vertical frequencies is separate.
3 To obtain the best picture, do not play the USB, YPbPr, HDMI or VGA source at the same
time.
Monitor Out Setup
The TV has a special signal output capability which allows
you to hook up a second TV or monitor.
Connect the second TV or monitor to the TV`s AV OUT.
See the Operating Manual of the second TV or monitor for
further details regarding that device`s input settings.
L AUDIO R
AV OUT
L AUDIO R VIDEO
S-VIDEO IN
AV IN
Notes:
YPbPr, VGA, HDMI, S-Video input sources cannot be used
for Monitor out.
When connecting with external audio equipments, such
as amplifers or speakers, please turn the TV speakers off.
11
External Equipment Connections
Connecting Headphones
You can connect a set of headphones to your set if you wish to watch a
TV programme without disturbing the other people in the room.
Plug a set of headphones into the 3.5mm
mini-jack socket on the rear panel of the set.
ANT IN
Note
Prolonged use of headphones at a high volume
may damage your hearing.
You will not receive sound from the speakers
when you connect headphones to the system.
Power source
Wider Hole
and Blade
Polarized AC Cord Plug
12
AC Outlet
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for
operation on AC. Insert the AC cord plug into
a standard polarized AC outlet.
NOTES:
Never connect the AC line cord plug to other
than the specified voltage. Use the attached power
cord only.
If the polarized AC cord does not fit into a nonÂpolarized AC outlet, do not attempt to file or cut
the blade. It is the user`s responsibility to have
an electrician replace the obsolete outlet.
If you cause a static discharge when touching
the unit and the unit fails to function, simply
unplug the unit from the AC outlet and plug it
back in. The unit should return to normal operation.
Polarized AC Cord Plug.
Switching ON/OFF the TV set
In the manual, the OSD (on screen display) may be different from your TV`s
because it is just an example to help you with the TV operation.
Switching ON/OFF the TV set
1 Please press down the power switch to switch on AC power supply and the power indicator
will light .
2 If the indicator is lighting in red, press POWER button on the remote control again.
3 If you want to exchange to standing by status, please press down POWER button on the
remote controller.
4 If you want to fully switch off the power supply for the TV set, please press down the power
switch button on the TV set.
Choose the Menu Language
When you start using your set for the first Time, you must select the language which will be
used for displaying menus and indications.
1 Press MENU and VOL+/-button to select the Function Menu.
2 Press VOL+ button and use CH+/-button to select Menu Set.
3 Press VOL+ button and use CH+/-button to select Language.
4 Select a particular language by pressing VOL+/- button
repeatedly.
You can choose one of two languages.(Chinese or English)
5 When you are satisfied with your choice, press MENU
button to return to normal viewing.
Language
Menu H-Position
Menu V-Position
Menu Timeout
Transparency
Picture Sound Adjust
Tuning
English
50
50
60s
0
Function Timer
Choose the Input Source
If you hope to enjoy the picture from the external input source,
before to select the source, you need to connect the devices,
otherwise, when you select the source, the none or no signal
will appears on the screen.
Press TV/AV button on remote control, the menu appears
on the screen. Then press CH+/- to select the TV item,
and press VOL+/- to ensure it.
Before watching TV program, you need to ensure
your TV in TV mode.
Source
14
Searching Channel
This TV set has three methods to set channels, which are respectively full automatic,
manual search fine tune.
In this section, how to use the remote control to set channel is explained. You can
also use buttons on the TV set to set channel.
Automatic search
1 Press MENU button and then use VOL+/- button to select the
Tuning menu.
Note : 1.the Tuning menu will be in normal
only operated
TV mode;
2. When the Tuning Lock is setting as Off, it is selectable.
2 Press VOL+ button and then use CH+/- button to select
"Auto Search" item.
3 Press VOL+ button to ensure automatic search function work.
After the search has finished, all channels now playing program
will be automatically preset in order and backtrack the 0 channel.
4 Press MENU button to stop automatic search function.
Manual search
If excessive channel signal of unwanted programs are
received in local area, manual search function is
recommended.
1 Press MENU button and then use VOL+/- button to select the
Tuning menu.
2 Press VOL+ button and then use CH+/- button to select
"Search Set" item.
3
Press VOL+ button to enter the submenu.
4 Press CH+/- button to select Search option, and use VOL+/-
button to
When searching successfully for the channel, the Manual
search stopping automatically and save to the current
channel.
5 Press OK or MENU button to stop searching.
start searching.
Fine tune
If the picture and/or sound are poor, try using the FINE
TUNE feature. Do not use this feature unless reception
is poor.
1 Repeat above steps 1-3, then press CH+/- button to select
the Fine Tune item.
2 Press VOL-/+ button repeatedly to carry out fine tune, till the
best picture and sound are obtained, then loosen the button.
15
Channel Edit
Exchange
Search Set
Auto Search
Picture Sound Adjust
Picture Sound Adjust
Picture Sound Adjust
Picture Sound Adjust
Tuning
Auto Search
Frequency 183MHz 7
Channel Edit
Exchange
Search Set
Auto search
Tuning
Fine Tune
Search
Frequency 791.22MHz
Tuning
Fine Tune
Search
Frequency 791.22MHz
Tuning
>>>
>>>
>>>
>>>
Function Timer
>>>
>>>
>>>
>>>
Function Timer
17
>>>
Function Timer
Function Timer
17
>>>
Searching Channel
Channel Edit
Press MENU button and then use VOL+/- button to
1
select the Tuning menu.
2 Press VOL+ button and then use CH+/- button to
select Channel Edit item.
3
Press VOL+ to enter the submenu.
Channel Edit
Exchange
Search Set
Auto Search
Picture Sound Adjust
Tuning
>>>
>>>
>>>
>>>
Function Timer
4 Press CH+/- button to select the item to , and
adjust
press VOL+/- button to adjust the item to select.
Channel No.
Press VOL+/- button to select the channel number to edit.
Channel Name
This will adjust the channel name.
Press VOL+/- button to move the cursor, and then use CH+/Âbutton to select the letter, then press MENU or OK button to
confirm.
Color System
Press CH+/- button to select "Color System", then press
VOL-/+ button to select the correct color system. In general,
you can set it as "AUTO".
Sound System
Press CH+/- button to select "Sound System", then press
VOL-/+ button to select the correct sound system.
Skip
After the programs are presetting, you can skip some programs
so that to select your favorite channels only.
Press VOL-/+ button to set Skip as On.
Channel No.
Channel Name
Color System
Sound System
Skip
Picture Sound Adjust
Tuning
17
---
SECAM
B/G
Off
Function Timer
If you want to recover the skipped channel
1. Use Direct-digit Choosing button to select the number of the
channel to be recovered.
2. Do the above steps again.
3. Press VOL+/- button to set Skip as Off.
16
Searching Channel
Channel Exchange
1 Press MENU button and then use VOL+/- button to
select the Tuning menu.
2 Press VOL+ button and then use CH+/- button to
select "Exchange" item.
Channel Edit
Exchange
Search Set
Auto search
>>>
>>>
>>>
>>>
3
Press VOL+ to enter the submenu.
4 Press CH+/- button to select the To Channel item,
and use VOL+/- button to set the desired channel
number.
5 When you are satisfied with your choice, press
CH+/- button to select Exchange item, and then
press VOL+ button to confirm, at this time, the
Exchange OK! will display on the screen.
Picture Sound Adjust
Picture Sound Adjust
Tuning
Current Channel
To Channel
Exchange
Tuning
Function Timer
17
10
>>>
Function Timer
17
Watching TV Program
You can watch TV program in a presetting channel.
To select the TV mode
Before watching TV program, you may ensure your TV in TV mode.
Press TV/AV button to select TV mode.
How to select the desired program
1 Using "Program number" buttons.
Directly enter the channel number with the numeric keypad on the remote control.
If to select channel numbers of double-digit or three-figure ,press continuously the
numeric buttons in three second.
2 Using CH+/- button.
Press the CH+ button to select a channel number in number increasing direction.
Press the CH- button to select a channel number in number decreasing direction.
How to select the desired sound
Press VOL+/- button on the remote or the front of the
TV set to adjust the volume level. The range is 0~100.
When the volume button are pressed the volume level is
displayed automatically on the TV screen.
Volume
Quick program view
This function enables quick swap to the last watched program.
1 Suppose the channel number you used just now is 8 and the channel
number you are using is 18 (as shown in the figure).
2
If you want to return to the last watched program channel 8, you can
simply press the Q.View button.
If you want to return to channel 18, press the button again. Use this
3
function, you can easily change between the channel you are using and
the channel you used last Timer.
Shuttle function
Shuttle function enables quick swap to setting program.
Press SHUTTLE button about 3 second, and the display Channel Stored
on the screen, at the time, you may operate other, then if you scan over
program, you may press again shuttle button to return to the setting
program.
Channel Stored
18
Picture Control Functions
The TV menu gives you can an overviews of the menus you can select.
Note: Depending on the input signal, one or more menu items may not be
selectable.
How to select picture modes
You can quickly select the desired picture mode from three preset modes and one
customized mode.
Press the PSM button to select the desired picture quality. Four kinds of picture modes
(i.e., "Soft", Personal" ) can be selected in turn. "Standard","Bright", "
Personal
Standard
Soft
Bright
A spare setting that can be adjusted to personal tastes
Designed for rooms that have good all round lighting
Designed for night time low light viewing
Designed for rooms with high ambient lighting such as day time sport;
How to customize your own picture status
1 Press MENU button and then use VOL+/- button to select
Picture menu .
2 Press VOL+ button and then use CH+/- button to select the
item to be adjusted, then press VOL+/- button to obtain the
desired effect.
ITEM
Brightness
Contrast
Sharpness
Chroma
Hue(only in NTSC mode)
Color Temperature
This will increase or decrease Warm (red) and Cool (blue)
colors to suit personal preferences.
Select Cool to give the white colors a blue tint, Standard to
give the white colors a neutral tint, Warm to give the white
colors a red tint.
1 Press MENU button and then use VOL+/- button to select
Picture menu .
Press VOL-
Dark
Weak
Soft
Shallow
More green
Press VOL+
Bright
Strong
Sharp
Deep
More purple
Brightness
Contrast
sharpness
Hue
Chroma
Color Temp.
Picture Sound Adjust
Tuning
50
50
50
50
50
Standard
Function Timer
NOTE
When Personal mode is not
selected, the Personal mode
can be entered automatically
if Contrast, Brightness, Color,
Hue and Sharpness parameters
are adjusted.
Brightness
Contrast
sharpness
Hue
Chroma
Color Temp.
50
50
50
50
50
Standard
2 Press VOL+ button and then use CH+/- button to select
Color Temp. Item, and then press VOL+/- button to select
the desired effect.
19
Picture Sound Adjust
Tuning
Function Timer
Picture Control Functions
Aspect Ratio Control
Press the PIC.SIZE button the Aspect Ratio menu appearance
on the screen.
4:3 mode
Choose 4:3 when you want to view a picture with an original 4:3
aspect ratio, with gray bars appearing at both the left and right
sides.
Full Screen
Choose Full Screen when you want to adjust the picture
horizontally, in a linear proportion to fill the entire screen.
Wide Screen
Choose Wide Screen when you want to view the picture to
be altered, both vertically and horizontally extended and
cropped.
Note:1. If a fixed image is displayed on the screen for a long
time, it image may become imprinted on the screen and
remain visible.
2. In VGA mode, there are only 4:3 and Full screen modes.
20
Sound Control Functions
How to choose sound mode
You can quickly select the desired sound mode from four preset modes and one
customized mode.
Press the SSM button to select the desired sound quality. Five kinds of sound modes
(i.e., "Standard","Personal", "Theater", "News"and"Music") can be selected in turn.
Personal
Standard N
Music
Theater
News
A spare setting that can be adjusted to personal tastes
ormal sound with moderate bass and treble setting
Designed the sound to best suit music programs
Enables extra bass and treble to enhance the movie experience;
Designed to reduce the bass and treble which enhances the voice for news programs
Equalizer
1 Press MENU button and then use VOL+/- button to select
Sound menu .
2 Press VOL+ button and then use CH+/- button to select
Equalizer item, then press VOL+/- button to enter the submenu.
3 Press VOL+/- button to select the item to be adjusted, then
press CH+/- button to obtain the desired effect.
.
Balance
This will adjust the output of the right and left speakers to
obtain the best stereo reproduction for your listening
position.
The intermediate value is 0. When indication value of Balance
increases toward+50, sound of the right and left speaker
becomes stronger and weaker, respectively. When indication
value of Balance decreases toward -50, sound of the right
and left speaker becomes weaker and stronger.
Press CH+/- button to select Balance,
Press VOL+ button to increase the audio output in the right
speaker;
press VOL- button to increase the audio output in the left
speaker.
Equalizer
Surround
Balance
Picture Sound Adjust
Tuning
Equalizer
>>>
Off
0
Function Timer
Surround Sound
The surround sound feature expands the audio listening
field wider and deeper to create exceptional sound
quality from the TV`s speakers.
Press CH+/- button to select Surround,
press VOL+/- button to set Surround as Off or On
21
Sound Control Functions
Eliminate Sound
When you need to pay attention to surrounded sounds,
or there is a telephone calling you or there are some
guests visiting you, the sound elimination (mute)
function is very convenient.
1 Press the MUTE button on the remote control and "Mute"
type face will display on the lower part of the screen. At this
Time, the sound of the TV set is turned off.
2 If you want to recover the sound, press the MUTE button
again or directly press VOL+ button.
22
Timer Functions
Current time setting
The current time will only work if the TV set is turned on or in standby. When the set is
disconnect from the power supply or is turned off by the main power on the rear panel,
the current time looses power and will need to be reset when the power is reconnected.
1 Press MENU button and then use VOL+/- button to select
Timer menu .
2 Press VOL+ button and then use CH+/- button to select
Current Time, and then press VOL+/- button to select hour
Current Time
Off Time
On Time
On Channel
Remind Time
Remind Channel
00:15
--:--
--:--
--:--
1
1
or minute position, and then press CH+/- button to set the
value of hour or minute.
Picture Sound Adjust
Tuning
Function Timer
3 Press MENU button to return to the previous menu.
On/Off Time
Using on/off Time function, the TV set can automatically turn on to a preset program or
shut down in a preset time. When the set is disconnect from the power supply or is turned
off by the main power, the on/offt time looses.
1 Press CH+/- button to select On Time, press VOL+/-button
to select hour or minute position; then press CH+/- button to
set the value of hours or minutes.
Current Time
Off Time
On Time
On Channel
Remind Time
Remind Channel
00:15
--:--
--:--
1
--:--
1
2 Press CH+/- button to select On Channel, then press CH+/-
button to select your desired channel.
Picture Sound Adjust
Tuning
Function Timer
3 Repeat step 1-2 to set Off Time item.
Remind Time and Remind Program
Program remind Time, that displays an on-screen reminder prompt, when a
program on a different channel is due to start.
1 Press MENU button and then use VOL+/- button to select
Timer menu .
2 Press VOL+ button and then use CH+/- button to select
Remind Time, and then press VOL+/- button to select hour
or minute position, and then press CH+/- button to set the
value of hour or minute, then press MENU or OK button to
confirm.
Current Time
Off Time
On Time
On Channel
Remind Time
Remind Channel
Picture Sound Adjust
Tuning
3 Press CH+/- button to select Remind Channel, and then
VOL+/- button to select the channel number.
23
00:15
--:--
--:--
1
--:--
1
Function Timer
Function Menu
Menu Set
1 Press MENU button and then use VOL+/- button to select
Function menu .
2 Press VOL+ button and then use CH+/- button to select
Menu Set, and then press VOL+ button to enter the submenu.
3 Press CH+/- button to select the item to be adjusted, then
press VOL+/- button to adjust the desired value.
Language
To select the menu language.
Menu H-Position
To adjust the menu H-positon, press VOL- button to move
menu toward left, press VOL+ button to move menu toward
right.
Menu V-Position
To adjust the menu V-positon, press VOL- button to move
menu toward down, press VOL+ button to move menu toward up.
Menu Timeout
Each Press of VOL+/- button repeatedly to select the number
of preset minutes, the Time will be set in sequence: 5s, 10s,
15s, 20s, 25s, 30s, 35s,40s,45s,50s,55s,60s.
Transparency
To set transparency background of OSD.
Menu Set
PIP
Picture Optimize
Scene Mode
Multicolor Window
Time Skip
Picture Sound Adjust
Picture Sound Adjust
Tuning
Language
Menu H-Position
Menu V-Position
Menu Timeout
Transparency
Tuning
>>>
>>>
>>>
Film
>>>
00:00
Function Timer
English
50
50
60s
0
Function Timer
Picture In Picture
1 Press MENU button and then use VOL+/- button to select
Function menu .
2 Press VOL+ button and then use CH+/- button to select PIP,
and then press VOL+ button to enter the submenu.
3 Press CH+/- button to select the item to be adjusted, then
press VOL+/- button to adjust the desired value.
PIP Size
To select the PIP menu size. Press VOL+ button to select the
desired size. Five kinds of sizes (i.e., Small, Large, POP, PBP
and Off) can be selected in turn.
PIP Source
To select the PIP picture source.
Press VOL+ button to select the desired source.
PIP H-Position
To adjust the PIP menu H-positon, press VOL+ button to move
menu toward right, press VOL- button to move menu toward left.
PIP V-Position
To adjust the PIP menu V-positon, press VOL+ button to move
menu toward down, press VOL- button to move menu toward up.
Menu Set
PIP
Picture Optimize
Scene Mode
Multicolor Window
Time Skip
Picture Sound Adjust
Picture Sound Adjust
Tuning
PIP Size
PIP Source
PIP H-Position
PIP V-Position
Tuning
Note: In LocK Set, if the
source lock is set as on, the
PIP source is not available.
>>>
>>>
>>>
Film
>>>
00:00
Function Timer
Small
TV
50
50
Function Timer
24
Function Menu
Picture Optimize
1 Press MENU button and then use VOL+/- button to select
Function menu .
2 Press VOL+ button and then use CH+/- button to select
Picture Optimize, and then press the VOL+ button to enter
the submenu.
3 Press CH+/- button to select the item to be adjusted, then
press VOL+/- button to adjust the desired value.
3A Optimize
The 3A optimize tracks picture contrast and color to improve
the quality of picture in terms of brightness and sharpness.
Repeat step 3 to set 3A optimize as on or off.
MADI (Motion, Adaption De-Interlacing)
To select the sport mode.
Press VOL+ button to select the desired mode.
Five kinds of sources (i.e., Standard, Theater, Personal, and
Music) can be selected in turn.
DCDI (Directional Correlational De-Interlacing)
To adjust and improves picture quality.
CCS(Gross Color and Control)
To adjust and improves picture quality.
3DNR (3D Noise Reduction )
Automatically filters out and reduces the image noise and
improves picture quality when receiving weak video signals.
Select Off/Auto/Low/Medium /High according to the image
noise of the broadcast signal.
Menu Set
PIP
Picture Optimize
Scene Mode
Multicolor Window
Time Skip
3A Optimize
MADI
DCDI
CCS
3DNR
Tuning
Tuning
Picture Sound Adjust
Picture Sound Adjust
>>>
>>>
>>>
Film
>>>
00:00
Function Timer
Off
Standard
Off
Off
Function Timer
Scene Mode
1 Press MENU button and then use VOL+/- button to select
Function menu .
2 Press VOL+ button and then use CH+/- button to Scene
Mode option.
3 Press VOL+/- button to select the Film,Vivid,Nature, Sport
in turn.
25
Menu Set
PIP
Picture Optimize
Scene Mode
Multicolor Window
Time Skip
Picture Sound Adjust
Tuning
>>>
>>>
>>>
Film
>>>
00:00
Function Timer
Function menu
Multicolor Window
1 Press MENU button and then use VOL+/- button to select
Function menu .
2 Press VOL+ button and then use CH+/- button to select
Multicolor Window, and then press VOL+ button to start.
Note:
1. In PIP On, the function will not be available.
2. In VGA mode, the function will not be available.
3. When the scene mode set as on, the function will not
be available.
4.In 4:3 and full screen mode, the Mult-color Window will
not be available.
Time Skip
1 Press MENU button and then use VOL+/- button to select
Function menu .
2 Press VOL+ button and then use CH+/- button to select Time
Skip, and then press VOL+ button to set the desired time.
Note:
1.
If prior to the completion of the countdown time,
press the Timer Skip button, the function will be
canceled.
2. The function will be available in TV mode.
3.
After start-up time skip function, if switched to other
sources, the function automatically canceled.
Menu Set
PIP
Picture Optimize
Scene Mode
Multicolor Window
Time Skip
Picture Sound Adjust
Picture Sound Adjust
Tuning
Menu Set
PIP
Picture Optimize
Scene Mode
Multicolor Window
Time Skip
Tuning
>>>
>>>
>>>
Film
>>>
00:00
Function Timer
>>>
>>>
>>>
Film
>>>
00:00
Function Timer
26
Adjust Menu
In VGA input mode , H-Position and V-Position can be used to adjust the picture
position.
When VGA HDMI input mode is set
1 Press MENU button and then use VOL+/- button to select
Adjust menu .
2 Press the VOL+ button and then use CH+/- button to select
the item to be adjusted, then press the VOL+/- button to adjust
the desired value.
Auto Adjust
Clock
Phase
H-Position
V-Position
I/P Info. 1366x768@50Hz
>>>
0
0
50
50
Auto Adjust
This is used to reset the default setting parameters (After
the operation, Auto Adjusting will be display on the screen)
Clock
This is used for adjusting H Position and V Position as well
as relative parameters in VGA modes.
Phase
This is used for adjusting the phase of pixel clock in VGA
mode.
H Position
Horizontal position of picture can be adjusted in this item.
V Position
Vertical position of picture can be adjusted in this item.
Note:
1.As adjusting H position or V position parameter, It is
natural that the picture will have faintness once in a
while if the range is more, then to adjust contrarily to
normal position.
2.As the frequency of display differ in PC device you
may select the appropriate frequency to obtain desired
effect. If the signal of receive is excess, the picture can
be not displayed or wrong on the screen.
Picture Sound Adjust
Tuning
Function Timer
27
Lock Setup
The television has the function of security default lock. Password needs to be entered
when the program lock mode is to be set.
How to use the password function
Press H.LOCK button, Password will appear on the
screen.
The initial password of the television is 0000. When the
password achieved, the Loct Set menu will display on
the screen.(as follow)
Note: If the password is not correctly entered, you will
be required to reenter the password and the cursor will
stay at the first place.
Press MENU to cancel the window.
Note: The Tuning Lock and Source Lock will be only
useful in TV mode.
To set new Password
The password can be changed.
After entering the Lock set menu, Press CH+/- to select
password, Press vol+ button, the screen will display the
follow.
Press the digit buttons, If correct password is entered, the
change successful will display on the screen, at this time,
the old password will be changed.
Password ----
Lock Set
Change Password
Tuning Lock
Source Lock
Preset Source
Preset Channel
Child Lock
Max Volume
UnLock
Lock Set
New Password
Confirm Password
------
------
>>>
Off
Off
Off
Off
Off
100
>>>
Tuning Lock
Press CH+/- to select Tuner Lock and VOL+/- to set On/Off. (To set On, some operation
such as search will be not available. When enter the Tuning menu, Tuner Lock will be on
the screen, and the Timer will be the same with the main menu if no operation. If you want
to operate Tuning menu, you need to enter the Lock menu to set Tuner Lock Off or operate
UnLock.
Source Lock
Source Lock will control the ON or OFF of hinder external input modes.
Press VOL+ button to set as on or off.
When the source lock is set as on, TV source will display, at this time, when press TV/AV,
S-VIDEO, DVD/DTV,PC/DVI button, the TV can not switch to corresponding source and
the Source Lock will display on the screen.
Preset Source
Preset Source is opted for setting up start source.
Press VOL+/-button to select Off, TV, AV1,AV2,S-Video,YPbPr/YCbCr, VGA, HDMI1,
HDMI2, VGA, USB in turn.
28
Lock Setup
Preset Channel
Preset Channel is opted for setting up preset channel.
Press CH+/- button to select preset Channel. Press VOL+/- button, to select channel
number.(The item is not available except TV signal.)
Child Lock
Press CH+/- button to select Child Lock.
Press VOL+/- button to set On or Off mode. If lock on mode is set, Child Lock
is in activated automatically. In such case, if Child Lock button (button on the
television) is pressed, the screen will display Child Lock, which can be
erased by press of MENU button. 5 seconds later after the latest press, the
screen display will disappear automatically. The Child Lock mode can be
resumed by entering Lock Set menu, set Child Lock On or Off.
Max Volume
Press CH+/- button to select Max Volume. Press VOL+/- button for
adjustment between 0 100. If a certain value is set, when volume is being
adjusted, the sound value can not exceed maximum volume value. If current
volume is over Max Volume, when Lock Set menu is set, current volume will
become set maximum volume. If current volume is below maximum volume,
customer set volume will stay unchanged.
UnLock
Press CH+/- button to select Unlock mode. Press VOL+/- button to unlock all
set modes, setting all lock options to off, and the maximum volume returns to
100.
29
Other functions
NICAM
Press the I/II button will result in fast swap of NICAM function of current program.
Display function
Press the DISPLAY button, then the channel number and
system will be displayed on the screen.
Press again,it is disappear.
the DISPLAY button
STILL
Press the STILL button, the STILL will display on the screen,
at this time, the picture of TV is still, and press the STILL button
again, the picture will resume.
Sleep
The TV set will switch automatically to standby at the preset time with the SLEEP
timer on. You may set the sleep time.
each press of SLEEP button repeatedly on the remote control to select the number of
preset minutes, the time will be set in sequence: (off, 10, 20, 30,60, 90, 120,150,180).
To confirm the sleep time setting, press SLEEP and the remaining time will be displayed
for a few seconds.
To cancel the sleep time, press SLEEP repeatedly until the display turns to off.
3
AUTO
B/G
Channel edit setup
1 Press CH.EDIT button to open/close the Channel Name menu,
Note opens when automatically will select the current channel
number.
2 Press CH+/- button to select the desired channel number, and then
press OK button to confirm.
3 Press VOL+ button to move the cursor, and then use CH+/- button
to alter the letter.
4 When you are satisfied with your change, press the EXIT button to
return to normal viewing or press MENU button to return to the
previous menu.
Channel Name
No
0 -----Â1 -----Â2 -----Â3 -----Â4 -----Â5 -----Â6 -----Â7 ------
Scan
This function fast glances over the channels(Skip as off) which each searches.
Press the SCAN button to start from the current channel, and switch a channel every 3
seconds, after scanning, and the program channel stop the current channel.
If you want to stop the function during auto tunning, simply press Scan or MENU button
again, at this time, the program will stop the program Finally glances over.
30
Stream media broadcast system
Stream media play prepare
1. Supporting equipment
1.Equipment supporting Mass and
Storage agreements include USB,
mobile hard disk, card reader, some
MP3 and digital camera.
2.Equipment supporting PTP
agreement includes some digital
camera.
2. 1 Supporting media:
picture, music, MPEG4, MPEG2
and MPEG1;
Supporting file format
*.Avi, *.DIVX, *.MPEG,*.DAT, *.MP3,
*.WMA, *.JPG and *.JPEG. Due to
particularity of file code and file mode,
It is possible that some files cannot be
read.
2 If Pic & Music mode is activated,
relative media file format will include
JPEG and MP3 files. After Picture is
selected, MP3 files set for play will
open both music and picture files for
sync play performance. As some files
must be read while music is being
played, the speed of picture operation
response might be affected.
3.Before starting operation, verify
USB storage device is of FAT32 and
FAT file system format. At present, this
television does not support NTFS and
the file systems of other format.
4.Many movie files use suffix of AVI and
MPG. However, many kinds of format
are used for internal files. This
television can only play some AVI
and MPG files of this format. Those
files with suffix of dat are not movie
files, but data files used by
computers, and cannot be played for
movies.
5.External card reader supports
most digital cards available in the
market. Readable digital cards are
classified according to the property
of card readers and can be
connected to mobile hard disks
(working voltage 5.0V, working
current not over 500mA).
6 . Some Time the television
operation may be halted due to
excessive rate of information code
errors. In such case, restart the
system. As there are many
nonstandard USB mobile devices in
the market. If this kind of USB mobile
devices are used in the stream media
play system, the problem of
identification failure might occur.
The same problem may also happen
with computers, not televisions.
7.It is suggested that the external
devices with USB2.0 interface be
used to improve velocity of
information reading and continuity of
information play.
31
Stream media broadcast system
Stream media system setup
Note: Memory cards or USB devices are not supplied with this TV.
USB setup
1 Insert USB in the card slots at the front of TV.
2 Insert it to be clicked in.
3 Press USB button on the remote controller to enter the stream media system.
CARD setup
This TV is Compatible with the card of SD/MMC/CF/MS format.
How to use
1 Jack of card Instructions
Jack of SM card
2 Insert the card as right direction. As following Card in common use
1 CF card
COMPACT FLASH
DIGITAL MEMORY CARD
Jacks of SD MMC MS card
Jack of CF card
2 MMC card
jack
128
MB
jack jack
MULTIMEDIA
CARD
128
Jack 1
Jack 2
MB
Note
1.Please note chooses uses
the digital memory card with
you corresponds the receptacle
2.Card reader in 1 cannot
simultaneously insert two kind
of cards in the graphical
representation position
3 MS card
128MB
MEMORY STICK
4 SDcard
jack
SD
128MB
Note:
1.the card insertion time, after the flows media system starts 2s , insert the card
to numerical code card reader , do not bring card to start flow media system.
2. After card insertion, indicator light will shines, and enters glitters condition,
after period of time , indicator light enters constant bright condition, indicates
already distinguishes finished, this time carries on play operation and so on .
3, In the market ,the digital card type are very many, please uses standard
product of the standard factory , meets reads takes difficult or reads speed
limits, please replaces the digital card.
32
Stream media broadcast system
Card data protection
- Do not remove the card/USB device when the content is being read or when
browsing. Such action may damage the memory card/USB device.
- Do not touch the terminals on the back of the card.
- Always insert a card in the correct direction. Failure to do so may result in
damage to the card and the unit.
- Do not subject the card to excessive pressure or strong impacts.
- Malfunctions of the unit or card may result in data loss or damage to the card.
- Haier shall not accept any liability for damage or loss of stored data.
Warning:
Memory cards can be swallowed
by young children. Do not allow
children to handle memory cards.
Please remove the memory card
immediately after use.
33
Stream media broadcast system
To start the media play
Press the USB button on
1
the remote to enter
DISPLAY
STILL
MUTE
S-VIDEO
TV/AV
OK
CH+
VOL-
MENU
CH-
PSM
1 2
5
4
7 8 9
-/-- 0
PIP SWAP SCAN
SHUTTLE
SLEEP
I/II
DVD/DTV
H.LOCK
ZOOM
POWER
PIC.SIZE
PC/DVI
Q.VIEW
VOL+
S
3
6
ZOOM/MOVE
CH.EDIT
TIME.SKIP
USB
RETURN
HELPENTER
stream media system.
2 The system start up about
2 seconds, and then i
USB in the card slots
3 Press
or to select the
desired item, and press
ENTER button to ensure it.
4 If to cancel the , press
EXIT button to return to the main menu, and
then press TV/AV button to select TV source.
SM
Note: If there are no operation two minute later, the
TV will enter the saver automatically, at the time, press
any button of USB system(with the exception of USB
button) to exit the saver menu.
nsert
stream media system
To operate the menu
1. Press or to select the item with up or down.
2 Press or to select the desired item of submenu with
left or right.
3 Press ENTER button to ensure the desired option to
enter the submenu to resume the speed of standard.
DEVICE
COPY
SETUP
AAA
Multimedia Player
4. Press or button to operate play quickly or slowly.
5.Press button to make the program stop and press
again to resume it.
6.Press ZOOM button to make zoom, and press or
or or button to enjoy the detail.
7 Press HELP button to call up or exit the OSD information.
And press HELP button to call up or exit the OSD during
operating file copy.
8 Press RETURN button to return to previous menu and stop
play, press RETURN button repeatedly to return to main menu.
34
Stream media broadcast system
To select stream media broadcast system
DISPLAY
MUTE
TV/AV
OK
VOL-
PSM
1 2
4
7 8 9
-/-- 0
PIP SWAP SCAN
SHUTTLE
Note:
1.the play file menu are different
with your USB devices.
2. May carry on the programming
playing: repeated step 2 to choose
many documents, ( right key choice
or cancellation picture choice),
press ENTER to play, at this time,
the picture of play will be the picture
be choosed.
STILL
S-VIDEO
SLEEP
CH+
MENU
CH-
DVD/DTV
5
H.LOCK
I/II
ZOOM
POWER
PIC.SIZE
PC/DVI
Q.VIEW
VOL+
S
3
6
ZOOM/MOVE
CH.EDIT
TIME.SKIP
USB
RETURN
HELPENTER
SM
1. Press or button to select
DEVICE item.
(The device be inserted and
identified).
2. Press ENTER button to enter
adjusted option.
To play picture
1 Press or button to
select Picture item.
2 Press ENTER button to
enter the menu of play.
3 Press or button to select
desired enjoy picture, and
then press ENTER button to
enter the play interface.
Note you may play the
pictures among selected.
4 During playing picture, Press
HELP button to call up picture
menu, at this time, you can
operate the picture of playing.
5 Press or or or button
to select the adjusted item,
Press ENTER button to
confirm.
play or pause
stop;
overturn;press button to
right turns over 90
no available;
12 pictures scan;
print picture;
play previous picture;
play next picture;
6 Press RETURN button to exit.
AAA
DEVICE
COPY
SETUP
DEVICE
COPY
SETUP
DEVICE
COPY
SETUP
DEVICE
COPY
SETUP
Note: The analysis rate basis picture
itself clarity different and is different.
Multimedia Player
Multimedia Player
AAA
Multimedia Player
AAA
Multimedia Player
AAA
F-007 .JPG
F-008 .JPG
F-009 .JPG
F-010 .JPG
F-011 .JPG
F-012 .JPG
35
Stream media broadcast system
To play Movie
DISPLAY
STILL
MUTE
S-VIDEO
DVD/DTV
TV/AV
OK
CH+
VOL-
MENU
CH-
PSM
1 2
5
4
7 8 9
-/-- 0
PIP SWAP SCAN
H.LOCK
SHUTTLE
SLEEP
ZOOM
I/II
POWER
PIC.SIZE
PC/DVI
Q.VIEW
VOL+
S
3
6
ZOOM/MOVE
CH.EDIT
TIME.SKIP
USB
RETURN
HELPENTER
1 Press or button to select
Movie option.
2 Press ENTER to enter playing
menu.
DEVICE
COPY
SETUP
Multimedia Player
AAA
Movie
3 Press again or button to
select desired movie, and
press again ENTER to enter
the playing movie interface.
4 During playing movie, Press
SM
HELP button to call up picture
menu, at this time, you can
DEVICE
COPY
SETUP
operate the movie of playing.
5 Press or or or button
to select the adjusted item,
Press ENTER button to
confirm.
: play or pause
: stop;
: no available;
: zoom
: quickly
: slowly
: play previous movie;
: play next movie;
Captions According to movie
document itself whether has the
captions to decide
Audio channel Mono, Stereo,
Left, Right
Play Mode Standard, Repeat All,
Repeat File
DEVICE
COPY
SETUP
Multimedia Player
AAA
Multimedia Player
AAA
F-007 .JPG
F-008 .JPG
F-009 .JPG
F-010 .JPG
F-011 .JPG
F-012 .JPG
37
6 Press RETURN button to exit.
Stream media broadcast system
To enjoy music
DISPLAY
STILL
MUTE
S-VIDEO
TV/AV
OK
CH+
VOL-
MENU
CH-
PSM
1 2
5
4
7 8 9
-/-- 0
PIP SWAP SCAN
SHUTTLE
SLEEP
I/II
DVD/DTV
H.LOCK
ZOOM
POWER
PIC.SIZE
PC/DVI
Q.VIEW
VOL+
S
3
6
ZOOM/MOVE
CH.EDIT
TIME.SKIP
USB
RETURN
HELPENTER
1 Press or button to select
Music option.
2 Press ENTER button to enter
play menu.
DEVICE
COPY
SETUP
Multimedia Player
AAA
Music
3 Press or button to select
the desired music, and then
press ENTER button to the
playing music interface.
DEVICE
Multimedia Player
AAA
Note: the play file menu are
different with your USB
device.
COPY
SETUP
4 When playing music, Press
SM
or or or button to
select the adjusted item,
Press ENTER button to
confirm.
: play or pause
: stop;
: No available
: Display or Close the OSD
: Quickly
: Slowly
: play previous music;
: play next music;
Play Mode Standard,Repeat File,
Repeat All
Press or button to select
the desired mode, and then
press ENTER button to confirm.
DEVICE
COPY
SETUP
Multimedia Player
AAA
F-007 .JPG
F-008 .JPG
F-009 .JPG
F-010 .JPG
F-011 .JPG
F-012 .JPG
5 Press RETURN button to exit
the playing.
38
Stream media broadcast system
To select the Music and PIC item
DISPLAY
STILL
MUTE
S-VIDEO
TV/AV
OK
CH+
VOL-
MENU
CH-
PSM
1 2
5
4
7 8 9
-/-- 0
PIP SWAP SCAN
SHUTTLE
SLEEP
I/II
DVD/DTV
H.LOCK
ZOOM
POWER
PIC.SIZE
PC/DVI
Q.VIEW
VOL+
S
3
6
ZOOM/MOVE
CH.EDIT
TIME.SKIP
USB
RETURN
HELPENTER
1Press or button to select
Music and Pic option, and
DEVICE
Multimedia Player
AAA
press ENTER button to enter
play menu.
COPY
SETUP
Comb
2 Press or to select desired
file(picture and music), and
press ENTER button to enter
play menu.
DEVICE
Multimedia Player
AAA
3 During playing music, Press
HELP button to call up picture
menu, at this time, you can
operate the movie of playing.
SM
COPY
SETUP
4 Press or or or button
to select the adjusted item,
Press ENTER button to
confirm.
play or pause
stop;
: No available
: No available
: No available
: No available
: play previous music;
:play next music;
DEVICE
COPY
SETUP
Multimedia Player
AAA
F-007 .JPG
F-008 .JPG
F-009 .JPG
F-010 .JPG
F-011 .JPG
F-012 .JPG
39
5 Press repeatedly RETURN button
to return.
Note: Under music and picture condition, because the
system reads the picture more longer than reads
time of
the music , therefore in the broadcast process,
the picture appears the time lag to the music, this belongs
to the normal phenomenon.
time of
Stream media broadcast system
To select text
DISPLAY
STILL
MUTE
S-VIDEO
DVD/DTV
TV/AV
OK
CH+
VOL-
MENU
CH-
PSM
1 2
5
4
7 8 9
-/-- 0
PIP SWAP SCAN
H.LOCK
SHUTTLE
SLEEP
I/II
ZOOM
POWER
PIC.SIZE
PC/DVI
Q.VIEW
VOL+
S
3
6
ZOOM/MOVE
CH.EDIT
TIME.SKIP
USB
RETURN
HELPENTER
1Press or button to select
text option, and press ENTER
button to enter text menu.
2 Press or to select desired
DEVICE
COPY
SETUP
Multimedia Player
AAA
Text
text, and press ENTER button
to confirm.
3 Press or or or button
to watch the text.
DEVICE
COPY
AAA
Multimedia Player
4 Press repeatedly RETURN
SM
button to return.
/
Rolls reads the text
/
Previous page/next page
SETUP
DEVICE
COPY
SETUP
Multimedia Player
AAA
F-007 .txt
F-008 .txt
F-009 .txt
F-010 .txt
F-011 .txt
F-012 .txt
40
Stream media broadcast system
Copy file function
1 Press or to select Copy item.
AAA
DISPLAY
STILL
MUTE
S-VIDEO
DVD/DTV
TV/AV
OK
CH+
VOL-
MENU
CH-
PSM
1 2
5
4
7 8 9
-/-- 0
PIP SWAP SCAN
H.LOCK
SHUTTLE
SLEEP
ZOOM
I/II
POWER
PIC.SIZE
PC/DVI
Q.VIEW
VOL+
S
3
6
ZOOM/MOVE
CH.EDIT
TIME.SKIP
USB
RETURN
HELPENTER
2 Press ENTER button to enter
the copy menu.
3 Press or button to select the
desired item of copy.
DEVICE
COPY
SETUP
4 Press HELP button to call up
Copy, Paste and delete, and
then press or button to select
Copy, and press ENTER button
to confirm.
SM
5 To select a folder, then Press
ENTER button to enter, and then
press HELP button to call up
Paste item, Press ENTER button
to confirm.
6 If there are the same texts
between the texts of paste, the
File already exist! Do you want
Overwrite it? will display on
the screen, at this time, press
or button to select the
desired item, Press ENTER
button to confirm.
DEVICE
COPY
SETUP
DEVICE
COPY
SETUP
Multimedia Player
Multimedia Player
AAA
Multimedia Player
AAA
F-007 .JPG
F-008 .JPG
F-009 .JPG
F-010 .JPG
F-011 .JPG
F-012 .JPG
Note:
RIGHT button to select
the all files;
LEFT button to cancel.
41
7. Press ENTER to cancel.
DEVICE
COPY
SETUP
Multimedia Player
AAA
F-007 .JPG
F-008 .JPG
F-009 .JPG
F-010 .JPG
F-011 .JPG
F-012 .JPG
Copy
Paste
Delete
Stream media broadcast system
To select language
DISPLAY
STILL
MUTE
S-VIDEO
TV/AV
OK
CH+
VOL-
MENU
CH-
PSM
1 2
5
4
7 8 9
-/-- 0
PIP SWAP SCAN
SHUTTLE
SLEEP
I/II
DVD/DTV
H.LOCK
ZOOM
POWER
PIC.SIZE
PC/DVI
Q.VIEW
VOL+
S
3
6
ZOOM/MOVE
CH.EDIT
TIME.SKIP
USB
RETURN
HELPENTER
1 Press or to select
AAA
SETUP item.
DEVICE
COPY
Multimedia Player
2 Press ENTER button to
enter SETUP menu.
SETUP
3 Press or to select
language option, and then
press ENTER button to
enter the submenu.
SM
4 Press or to select
desired language, and
DEVICE
COPY
SETUP
AAA
Language
Slideshow Model
Multimedia Player
press ENTER to ensure
it.
5 Press RETURN button to
DEVICE
COPY
Multimedia Player
AAA
English
Chinese
return.
SETUP
Slideshow Model
1 After entering the SETUP menu.
2 Press or to select
Slideshow Model option,
and then press ENTER
button to enter the submenu.
DEVICE
COPY
SETUP
Multimedia Player
AAA
Language
Slideshow Model
3 Press or to select
desired mode, and press
ENTER to ensure it.
4 Press RETURN button to
return.
Fine Model
DEVICE
COPY
SETUP
Picture clarity high, the
browsing speed is slow
Normal Model
Picture clarity normal, the browsing speed is quick
Multimedia Player
AAA
Fine Model
Normal Model
42
Maintenance
- Early malfunctions can be prevented. Careful and regular cleaning can
extend the amount of time you will have your new TV. Be sure to turn the power
off and unplug the power cord before you begin any cleaning.
Cleaning the Screen
1. Here`s a great way to keep the dust off your screen for a while. Wet a soft cloth in a
mixture of lukewarm water and a little fabric softener or dish washing detergent. Wring
the cloth until it`s almost dry, and then use it to wipe the screen.
2. Make sure the excess water is off the screen, and then let it air-dry before you turn on
your TV.
Cleaning the Cabinet
To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth. Please be sure
not to use a wet cloth.
Extended Absence
If you expect to leave your TV dormant for a long time (such as a vacation), it`s a good
idea to unplug the power cord to protect against possible damage from lightning or
power surges.
44
Troubleshooting
For the sake of time and cost, it is strongly recommended that you check out
the problem by yourself according to the instructions listed hereunder before
contacting the after-sales service for technical assistance.
Problem
No picture,
no sound
Good picture,
no sound
Failure of remote
controller
No color, weak
color or poor picture
Excessive brightness
or darkness
Picture too big or small
One speaker failure
Slight sound from display
Turn on the power supply;
Properly plug the TV set to the power socket;
Check to see if the power cable of other appliance is
plugged in the TV set. Make sure that the power cable
of the TV set is properly connected.
Depress the volume button;
Check out the audio frequency input signals.
Check to see if the remote controller display
receiving window are blocked by other objects and
if batteries are properly loaded.
Designate the item of color from the Picture menu
and depress the volume button;
Keep the display and VCR separate a reasonable space;
Activate some functions to store picture brightness;
Make sure that the display and signal source are
available and turned on.
Adjust brightness or contrast.
Adjust the setup of sizes.
Balance the sound in the menu.
It is a normal phenomenon.
Possible remedies
Note: Do not leave the television with static picture in an extended period as it may
result in residual image on your television screen.
Note: Production of the screen requires high and precision technologies. However,
there might be some dark or bright (red, blue or green) spots, or some anomalistic stripes or
spots. This is not defect. If the TV set is used in an area 2,400 meters above the sea level where
the air pressure is below 750hpa, the picture on the screen may be affected and a muffled sound
might be produced. These phenomena might happen in the area 1,500 meters above the sea
level. This is resulted from difference between air pressures inside and outside the display. This
is not a defect covered by the limited warranty.
45
Specifications
Basic specification and parameter
Model
Power
Power Consumption
Color System
Sound System
Video input
Environmental
condition
Accessories
AV CVBS , S-VIDEO, YPbPr/YCbCr, HDMI or DVI VGA
If the storage temperature is lower than 0 , please first lays
aside after in the operating temperature environment carries on restores
2 hours, then electrifies the use again, protects your television not to
receive the damage.
L37A9-AK
~ 150-240 /60
PAL NTSC, SECAM
D/KIB/G, M
Operating temperature range: 5 +35
Operating humidity range 20%-80%
Storage Temperature 15 +
Storage Humidity %-90%, non-condensing
: - 45
5
Use`s manual X1
Remote Control x1
Maintenance card x1
Power cable x1
Alkaline x2
Product main size (does not contain stand & speaker)
Model Net Size
L37A9-AKF
the machine
Net Weight
L37A9-AK
L37A9-AKF
1096x117x617mm
1071x102x659mm
NOTE
Design and specifications are subject to change without notice.
The dimension in this manual is a approximation.
25Kg
28Kg
46
Format
Recommendatory HDTV/SDTV(YPbPr/YCbCr) format
Sequence
Number
Format
Refresh Frequency
Hz
480i/480p
576i/576p
720p
1080i/1080p
60
50
50/60
50/60
Recommendation PC connection input format:
sequence
number
Format
640*480@60Hz
800*600@60Hz
1024*768@60Hz
(Recommendatory)
1280*1024@60Hz
1600*1200@60Hz
Recommendation DVI connection input format:
Sequence
Number
Resolution
640*480
800*600
1024*768
1280*1024
Refresh Frequency
Hz
60
60
60
60
H-Frequency
KHz
31.5
37.88
48.36
63.9
75
V-Frequency
Hz
60
60
60
60
60
Recommendation HDMI connection input format:
Sequence
Number
Format
480i/480p
576i/576p
720p
1080i
Refresh Frequency
Hz
60
50
50/60
50/60
47
Loading...
