Haier HUF205PA, HUF138PA User Manual
Upright Frost Free Freezer
Congélateur Vertical
Congelador Vertical
User Manual Model
HUF138PA • HUF168PA • HUF205PA
Guide de l’Utilisateur
HUF138PA • HUF168P
Manual del Usuario Modelo
HUF138PA • HUF168PA • HUF205PA
A • HUF205PA
Quality •Innovation •Style
English
SAFETY PRECAUTIONS
Read all of the instructions before using this appliance. When
using this appliance, always exercise basic safety precautions,
including the following:
1. Use this appliance only for its intended purpose as described in this
use and care guide.
2. This appliance must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in
the installation section.
3. This appliance should not be recessed or built into an enclosed
cabinet. It is designed for freestanding installation only.
4. Never unplug your appliance by pulling on the power cord. Always
grasp the plug firmly and pull straight out from the outlet.
5. Repair or replace immediately, all electrical service cords that have
become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length, the plug or the connector
end.
6. If your old appliance is not being used, we recommend that you
remove the doors and leave the shelves in place. This will reduce the
possibility of danger to children.
7. When your freezer is in operation, do not touch the cold surfaces in
the freezer compartment, particularly when hands are damp or wet.
Skin may adhere to these extremely cold surfaces.
8. Do not refreeze foods that have been thawed completely. The United
States Department of Agriculture in Home and Garden Bulletin No. 69
reads:
"…You may safely refreeze frozen foods that have thawed if they still
contain ice crystals or if they are still cold - below 40˚F."
"…Thawed ground meats, poultry, or fish that have any off-odor or
off-color should not be refrozen and should not be eaten. Thawed ice
cream should be discarded. If the odor or color of any food is poor or
questionable, discard it. The food may be dangerous to eat."
"…Even partial thawing and re-freezing may reduce the eating quality
of foods, particularly fruits, vegetables, and prepared foods. The eating quality of red meats is affected less than that of many other foods.
Use refrozen foods as soon as possible, to save as much of their eat
ing quality as you can."
1
-
9. Do not use any electrical device or any sharp instrument to defrost
your freezer.
10. Unplug your freezer before cleaning or before making any repairs.
Note: If for any reason this product requires service, we strongly
recommend that a certified technician perform the service.
11. Do not operate your freezer in the presence of explosive fumes.
SAVE THESE
INSTRUCTIONS
DANGER
English
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors. Leave the shelves in
place so that children may not easily climb inside.
Thank you for using our Haier
product. This easy-to-use manual
will guide you in getting the best
use of your freezer.
Remember to record the model and
serial number. They are on a label
in back of the freezer.
Staple your receipt to your manual. Y
warranty service.
Model number
Serial number
Date of purchase
ou will need it to obtain
2
English
Table Of Contents
PAGE
Safety Precautions
Unpacking
Parts and Features
Freezer Installation
Electrical Connections
Operating Your Freezer
Normal Operating Sounds
Proper Care and Cleaning
Frost-Free
Extended Non-Use and Moving
Troubleshooting Guide
Warranty
....................................................................................4
....................................................................................13
......................................................................................15
....................................................................1-2
......................................................................5
......................................................................6
..................................................................7
........................................................8-11
........................................................11
........................................................12
..............................................................14
................................................13
3
Unpacking
Unpacking
1. Remove all packing materials. This includes the corrugated base and all
adhesive tape holding the accessories inside and outside.
2. Inspect and remove any remaining packaging, tape and printed materials
before turning ON the freezer.
Note: Allow the freezer to stand in an upright position for at least 24 hours
before turning on the power, if the freezer has been tilted for any reason.
Check to make sure that the accessories are present and in good condition. If
you find that they are not in good condition or are missing, please contact our
customer service department for assistance.
1-877-337-3639.
Our Toll-Free number is
English
4
English
Parts And Features
1
2
3
9
4
6
5
1. Interior Light
2. Cabinet Wire Shelves (quantities
vary per model)
3. Temperature Control Dial
4. Storage Drawers (quantity varies by
model)
Temperature Alarm Switch with
5.
Indicator Light
5
7
8
6. Power Indicator Light
7. Locking Plate
8. Lock (not shown)
9. Fixed Door Shelves (quantity varies
by model)
