COLOUR TELEVISION
OPERATING
INSTRUCTIONS
2
◆Digital I C bus control
◆Auto search tuning & 250 programs stored
◆Full infrared remote control
◆Multi-picture modes selection
◆Multi-function timer, appointing program
2
WARNING AND CAUTIONS
1. When you clean the TV set, please pull
out the power plug from AC outlet.
Or may result in electric shock, fire or
damage to the TV set. Don't clean the
cabinet and the screen with benzene,
petrol and other chemicals.
4. Do not place the TV set near rain
or moisture as it may cause an electric
shock, or the TV set to catch fire. The TV
set must only be used
in dry indoor location.
2. In order to prolong the using life of the
TV set, please place it at a well ventilated
location.
5. The back cover must only be removed
by a registered electrical service person.
Removing the back cover may result in
electric shock, fire or damage to
the TV set.
3. Don't place the TV
set in direct sunlight
or near heat source.
6. If the TV set is not going to be used for
a long time, or there is a severe thunder &
lightening storm, it is recommended that
the TV set be disconnected from the AC
power outlet and the aerial plug
removed.
Explanation on the display tube
When the picture tube requires cleaning, please disconnect the power and use a dry
soft cotton cloth. Do not use any cleaner or abrasive cloth.
1
CONTENTS
Contents.................................................................................................................................1
Warning and Cautions...........................................................................................................2
Basic Feature.........................................................................................................................3
Technical Specification.........................................................................................................3
Function Buttons and External Sockets................................................................................4
AV Connection......................................................................................................................5
Remote Controller ................................................................................................................6
Control Your TV....................................................................................................................7
Tuning Procedure................................................................................................................10
Menu Operation...................................................................................................................11
Preparing for Operations....................................................................................................14
Trouble Shooting Guide......................................................................................................15
3
BASIC FEATURE
2
◆Digital I C bus control
◆Auto search tuning & 250 programs stored
◆Full infrared remote control
◆Multi-Picture modes selection
◆Multi-function timer, appointing program
4
TECHNICAL SPECIFICATION
1.POWER SUPPLY: See rating plate
2.COLOUR SYSTEM: PAL SECAM N TSC4.43/3.58(AV)
3.AUDIO SYSTEM: B/G D/K I
4.CRT: 25 /29 /34
5.ANTENNA INPUT : 75Ω Standard Coaxial Cable
6.SOUND OUTPUT POWER: 5W + 5W
7.POWER CONSUMPTION: See rating plate
8.NET WEIGHT(kg): HT-2599 29
HT-2999 40
HT-3499 60.5
9.NET DIMENSION(mm):
" " "
HT-2599 688×480×526
HT-2999 780×525×580
HT-3499 895×565×670
Supplied accessories:
Infrared remote control handset 1
Battery(AA) 2
Operating instruction 1
Design and specifications are subject to change without notice.
FUNCTION BUTTONS AND EXTERNAL SOCKETS
(1) S-VIDEO input
(2) AUDIO/VIDEO input
(3) YUV-DVD component input
(4) Antenna input
(5) AUDIO/VIDEO output
(1) (2) (3)
(4)
S-VIDEO
3
Y
C
b
C
r
OUT
IN
VIDEO
AUDIO
L
R
IN
(5)
2. Audio and video rear connections
1. Front panel
(1)Remote sensor: let the remote
controller aim here, the TV set
can receive remote control signal.
(2)Power switch: press the button to turn
on the TV set ,press the button again to
turn off the TV set.
(3)Power indicator: the indicator lights
in standby status .The indicator glints
when you use remote controller.
(4)Menu button
(5) Program up/down button
(6)Volume up/down button
(7)TV/AV switch button
( 2)
( 3)
( 1)
MENU
TV/AV
P
- +
- +
(4) (5)(6)(7)
AUDIO
VIDEO
AUDIO2-R
AUDIO2-L
VIDEO2
L
R
S-VIDEOS-VIDEO
YY
CC
bb
CC
rr
OUTOUT
ININ
VIDEOVIDEO
AUDIOAUDIO
LL
RR
ININ
