Exhaust Type Tumble Dryer
HLP140E
User's Manual
Please read this manual
carefully before using.
Retain it for future reference.
Names Of The Parts
Transparent Windows
Drum
Door
Door
Door Gasket
Power Cord
Casing
Exhaust Shroud
Air Intake Shroud
Control Panel
Exhaust Vent
Back Cover
Please check if the power receptacle has good earthing
Condition before using to guarantee your safety.
The manufacturer will not take responsibility for those
Risks occurred from not obeying this manual.
1
Important Safety Instructions
Warning-To reduce the risk of fire ,electric shock, or injury to
persons when using your appliance, follow basic precautions,
including the following:
1.Read all instructions before using the appliance.
2.Do not dry articles that have been previously cleaned in, washed in, soaked in,
or spotted with gasoline, dry cleaning solvents, or other flammable or explosive
substances, as they give off vapours that could ignite or explode.
3.Do not allow children to play on or in the appliance. Close supervision of children
is necessary when the appliance is used near children.
4.Before the appliance is removed from service or discarded, remove the door to
the drying compartment.
5.Do not reach into the appliance if the drum is moving.
6.Do not install or store this appliance where it will be exposed to the weather.
7.Do not tamper with controls.
8.Do not repair or replace any part of the appliance or attempt any servicing unless
specifically recommended in the user-maintenance instructions or in published
user-repair instructions that you understand and have the skills to carry out.
9. Do not use fabric softeners or products to eliminate static unless recommended
by the manufacturer of the fabric softener or product.
10.Do not use heat to dry articles containing foam rubber or similarly textured
rubber-like materials.
11. Clean lint screen before or after each load.
12.Keep area around the exhaust opening and adjacent surrounding areas free
from the accumulation of lint, dust, and dirt.
2
Important Safety Instructions
13.The interior of the appliance and exhaust duct should be cleaned periodically
by qualified service personnel.
14. Do not place items exposed to cooking oils in your dryer. Items contaminated
with cooking oils may contribute to a chemical reaction that could cause a load to
catch fire.
15.Keep your dryer away from combustible materials (such as gasoline) during
operation to prevent the risk of fire.
16.Do not use or place stove, gas device, water heater, tinder or similarities close to
your dryer. Do not install or store this appliance where it will be exposed to water
and/or to the weather.
17.The tumble dryer is not to be used if chemicals have been used for cleaning.
18.The tumble dryer is intended only for drying textile material washed in water.
19.There has to be adequate ventilation to avoid the back flow of gases into the
room from appliances burning other fuels including open fires, when operating
the tumble dryer.
20.Lint is not to be allowed to accumulate around the tumble dryer.
21.For appliances with ventilation openings in the base, that a carpet must not
obstruct the openings.
22.Exhaust air must not be discharged into a flue which is used for exhausting
fumes from appliances burning gas or other fuels.
23.If material has been used with any flammable liquids or solids it should not be
used in the dryer until all traces of the flammable liquids and its fumes have
been removed.
24.This dryer shall be connected to a three-wire, single phase, 120V AC power
receptacle more than 15A, which must be reliably grounded. A leakage
protector shall be used, if possible.
25.Do not share a receptacle with other appliances. Do not use it when a plug
loosely inserted into a receptacle.
Important Safety Instructions
26.When normally using, the power cord of dryer shall be easily plugged or
unplugged by hand. It must be unplugged during power blackout, moving, not
in use or cleaning. Do not plug or unplug the power cord with wet hands.
27.Always disconnect dryer from electrical supply before attempting any service.
Disconnect power cord by grasping the plug, not the cord.
28.Do not block the exhaust vent when dryer operating to prevent it from
overheating or other dangers.
29.Do not let your dryer operate on packing foam. Otherwise it maybe cause fire
since heat accumulation or other external factors.
30.Only place sufficiently dehydrated clothes into your dryer for drying to prevent
leakage and longer drying time.
31.Do not place washed wet clothes in your dryer for a long time not drying them
(which may result in water leakage).
32.Don't touch the intake for the high temperature during the drying cycle.
33.Do not exceed dryer rated Max. Capacity.
34.The appliance must not be installed behind a lockable door, a sliding door
or a door with a hinge on the opposite side to that of the tumble dryer.
35.Do not excessively bend, stretch, twist, bind power cord or put heavy stuff on
it. Keep the terminator of power cord clean. Carefully clean it with dry cloth if
dusts accumulated. If damaged, power cord or plug must be replaced by our
service agent or qualified after-sale service person to avoid the risk of danger.
Operation Cautions
Clothes with ribbon or lace
should be dried in a nylon net
Put chemical fiber and/or clothes
with ribbon or lace
into a nylon net
before drying.
Clothes with zipper
Dry this kind of clothes with zipper
zipped or fastener
buckled and inside
out (to reduce the
impact noise between
metal and the drum)
Do not load your dryer when
it is running.
Loading the dryer when it is running
shall be avoided to prevent the clothes
overdried or
incompletely
dried.
Please flip clothes over manually
from time to time, if necessary,
when drying large ones.
It is not easy to flip over large clothes
(such as overcoat) in the drum, uneven
drying therefore happens sometimes.
If necessary, flip them over manually
from time to time to make them dried
completely.
Flip over clothes
Avoid to dry starched clothes in
your dryer to prevent link filter
from clogging, which may lead
to bad exhaust performance.
Put rumpled clothes in order
Put all clothes in order after
dehydrated
before drying
them.
Anti-wrinkle method for clothes
crumpled easily
Decrease capacity to get good antiwrinkle result (the capacity shall be
4/5 of that of normal clothes).
Capacity reduced
.
Remove the clothes out of your dryer
as early as possible
to reduce rumples.
Please hang the easily crumpled clothes
up with a hanger after dried
6
Hoop
around the joint
of the exhaust pipe
and the dryer
7
Using Method
Do not tumble dry
Hang to dry
Drip dry
Dry flat
Dry in the shade
1. Plug the power cord
The appliance shall be supplied with120V,60Hz,
connected to a special receptacle more than
15A (reliably grounded).
2. Place the dehydrated clothes in your dryer
Check the following items before putting clothes in.
They shall be loaded in such a way that 2-3 pieces
each time and not in a group to avoid tangling, which
is not easy to turn it over resulting in uneven drying
since the clothes were wrapped.
Please put clothes into the drum. Avoid clothes being
pressed by the door due to exposure out of the port,
which will cause clothes entangle and door gasket
release and consequently poor drying effect.
Before drying your clothes
Make sure if clothes have any special requirements and suitable for drying.
Do not dry your clothes in your dryer if the materials of which cannot be dried
in a dryer or they bear the following labels:
Dry flat
Carefully check the clothes to be dried and remove combustible
material such as lighter and match as well as sharp metal items
like coin, hair clip and safety pin maybe mixed with the clothes
and in pockets.
Clothes with zipper or fastener shall be put into your dryer inside
out with zipper zipped and fastener buckled.
Separate dark and light colored items, like you do for washing.
Check for stains that may not have been removed in washing.
Dryer heat may permanently set some stains. Properly dried clothes
will need minimum of care when removed from dryer.
For optimum results,use dryer load of similar fabric, weight and construction. Place
small items in a mesh bag prevent from tangling.Do not overload the dryer. An
average load will fill up half the drum.
Dry in the shade
8
Using Method
3. Drying Procedure Setting
Instruction for the operation button
a
Status and implication of the indicator light
Flash- indicates the program that is functioning
On- indicates the program that is going to function or the state that has been chosen
Indicator lights of the status
The implication of the
indicator lights.
Dry
The dryer is working.
Cool Down
The cycle will be
completed soon,and the
heater stops heating. the
temperature decreases.
Cycle End
The cycle is completed.
Clean Lint
Remind you clean the lint
in time each time you dry
your clothes.
' button
Time
'Dry
After the power is on, you can press in the
'DryTime' to choose the drying time directly.
When you choose 'Timed Dry',press in the
'Time' button to choose drying time in a range
of 30, 60,90,120,150.
If the 'Temp' function is set as 'Air-Dry',
subsequently the 'Dry Time' will adapt to 30 or
60 minutes.
Status
Dry
Cool Down
Cycle End
Clean Lint
150
120
90
60
30
Dry
Time
'Cycle'
Possible cycle
Normal Normal drying
Heavy Huge and heavy garments
Delicate Low level heat resistance
Timed Dry You can set the drying time
as required
A
U
T
O
D
R
Y
Cycle
button
Normal
Heavy
Delicate
Timed Dry
9
Using Method
'PowerOn/Off ' button
Press in the'PowerOn/Off' button to connect the
power connector.
Press in the
power connector after there is power to the machine.
Press in the
power connector, then press in the
if not, the machine will cut off the power connector
by itself.
'PowerOn/Off' button to cut off the
'PowerOn/Off' button to connect the
'Start/Pause' button,
High
Low
Air-Dry
Start
Pause
Temp
'Temp' button
When you choose'Timed dry',press in
the 'Temp' button to choose temperature
in a range of High, Low and Air Dry
(without heating).
'Normal' and 'Heavy' of 'Cycle' is
originally set as 'High'.'Delicate’ is originally
set as 'Low'.
Power
On/Off
'Start/Pause' button
Press in the'Start/Pause' button when
there is power to the machine to run the
dryer.
Pause when press in in the middle
of running.
Start again when in status of
pause.
Power
On/Off
Temp
Using Method
Operation button using procedure and instruction for each step
b
HLP140E
Start
Pause
Power
On/Off
Power
On/Off
Dry
Time
150
120
A
U
Normal
T
O
90
60
30
D
R
Y
Cycle
Heavy
Delicate
Timed Dry
High
Low
Air-Dry
Temp
Status
Dry
Cool Down
Cycle End
Clean Lint
Press in the 'PowerOn/Off' button to run the machine.
Press in the 'Cycle' button to choose appropriate mode.
The clothes dryer is originally set as 'Normal ' when the power is on . You may want to
choose other cycles; please press in the 'Cycle' button .
If a 'AUTO DRY' cycle is chosen, please directly move to step 5.
If a 'Timed Dry ' cycle is chosen, please follow up step 3,4,5.
Press in the 'Temp' button to choose the appropriate temperature.
The clothes dryer is originally set as 'High' for 'Normal' and 'Heavy' mode of
cycle, and 'Low' for 'Delicate'.The temperature change is forbidden. If you choose 'Timed dry'
mode of cycle, you can choose other temperature mode freely.
Attention
Start
Pause
Dry
Time
Using Method
Press in the 'Dry Time' button to set appropriate drying time.
Dry
Time
For 'High' and 'Low' mode,you can choose drying time freely.
For 'Air Dry' mode, only 30 or 60 are available.
Please choose the drying time and Temperature according to the quality and quantity of the
garments.
Heating apparatus won't heat in'Air dry' mode, and is proper for down, sweater,
mohair, cotton sweater, cotton-padded clothes. You may choose this mode to make garments
fluffier after dried. The machine can also achieve same results for garments left unused for
long in the wardrobe.
Press in the 'Start/ Pause' button
Make sure the front door is properly closed before you press in the
Start
Pause
'Start/Pause' button, otherwise, the clothes dryer won't start and give an alarm.
The machine will stop to work if the front door is opened in middle of operation
(including heater and engine) .It will continue to work after pressing the
when the front door is closed again.
There is power to heating screen after 30 seconds' spinning of the engine.
'Start/Pause' button
Using Method
4. Take out the clothes when the program is finished
There comes a beeper alarm when the drying
procedure is done, the dryer will cut off electricity
by itself after giving alarm.
Stop heating 10 minutes before the program
finish, cold wind blowing makes the dryer become
cool gradually and the temperature of garments
will be lower.
If you want to take out clothes in the middle of
high temperature operation, please firstly make
the dyer cool and then take out the clothes.
Under normal condition, static electricity comes
as a result of garments made from chemical fiber
rubbing against each other.
5. Pull out the plug
When pull out the plug, please hold the plug top
rather than dragging the line, in case the inner
electric wire was broken or caused a loose
connection.
6. Rinse the filter-net
Referring to Page 14
Care And Cleaning
Clean the buildup such as lints on filters in time after each use, otherwise it will affect
the performance of your dryer.
Please unplug the power cord first when cleaning it.
Cleaning of filters
The lint filter must be used for drying.
It must be cleaned in time befor and after each use.
1. Remove the filters
Remove by pulling straight up with hands inserted
into the four holes around the exhaust vent shroud
in the sequence of "Exhaust vent shroud - Lint filter Exhaust filter", as shown in figure 1.
2. Clean the lints
Exhaust
vent shroud
Separate "exhaust vent shroud","lint filter" and "exhaust
filter" and clean the lints on the filter and exhaust filter
with a soft brush or vacuum cleaner.
Do not damage the filters (as shown in figure 2)
3. Install the filters
After cleaning, assemble in the sequence of "exhaust filter
-filter-exhaust vent shroud",align the recesses in the center
of filter with the projection in the center of drum and make
sure that it is firmly inserted (as shown in figure 3).
Note: The filter fixed in the bottom of the drum shall also
be cleaned with a soft brush.
DO NOT USE YOUR DRYER WITHOUT THE LINT FILTER.
Clean the interior drum or dryer
housing, with wet soft cloth, if stained.
Do not wash directly with water.
Do not use thinner, gasolene or alcohol.
Do not use any type of spray cleaner when
cleaning the interior. Hazardous fumes or electric
shock could occur. If dryer drum becomes stained,
clean the drum with a damp cloth. Remove any
residue before drying the next load.
Clean cabinet with mild soap and water. Donot use
harsh or abrasive cleaners, this could damage the dryer.
The filter fixed in the
bottom of the drum
Lint
filter
Lint Filter
Lints
Exhaust
Filter
Exhaust Filter
Figure 1
Dust Cleaner
Figure 2
Figure 3
Trouble Shooting
(If problems occur, please pull out the plug to check)Before calling out a Service engineer have
a quick look through the following fault list- it could have save a lot of time and trouble. If your
machine is still not working properly you should contact your nearest Service office or obtain
after sales service quickly. Please do not fix the machine by yourself.
SYMPTOM
Dryer won't heat.
Dryer won't heat.
Garments won't dry
enough. ( Not all the
garments are dry
enough after the
machine stops work)
Drum won't turn.
(The three indicator
lights of Cycle
button are on at the
same time)
Drum won't turn.
(The "150", " 90",
"60” indicator lights
of Drying Time
button are on at the
same time)
Is the outlet filter-net been
blocked?
Are the garments fully dehydrated?
Have you dried too many garments
in weight?
Is a garment filling occurs when the
machine is working?
Have the garments got tangled up?
Are the easy/hard dry clothes not
sorted?
Is the dryer standing position
narrow and stuffy?
You may have chosen the "Auto-Dry"
mode of drying if the garments are
not dried over 5 hours .
( Referring to symptom 3)
CAUSE
No power to machine
Is the plug properly put in the
socket?
Is the front door properly shut?
Has the Power/ ON/OFF, or
Start/Pause button been
pressed in?
Is the Temperature button Indicator
light indicating "Air Dry"?
Is the clothes dryer working?
Close the front door.
CURE
Reset circuit breaker; use the
machine when there is power.
Check and tighten plug.
Close the front door.
Press in the Power/ ON/OFF,
or Start/Pause button.
Reset the "Temp" button till the
indicator light indicates "High"
or "Low", and the light is on.
This is probably as a result of
the heat been absorbed by the
wet clothes for a while when
starting the machine, after 30
minutes it will be normal.
Rinse the filter-net clear.
Got the garments fully
dehydrated.
Reduce the garments amount.
Select out the garments that
not dry to make them dried.
Separate the tangled-up
garments and make them dried.
Select out the garments that
not dry to make them dried.
Place the machine in a position
that ventilate well.
Press in the Start/Pause
button.
After troubleshoot problem 3,
press in the Power/ ON/OFF,
or Start/Pause button.
Loading...
