Haier HL40B, HL42S User Manual

Download

OWNER S MANUAL'

Please READ this manual carefully before operating your TV, and retain it for future reference.

TFT-LCD TV

MODELS:

HL26B HL32B HL37B HL40B HL42B

HL26S HL32S HL37S HL42S

WARNING

RISK ELECTRIC SHOCK DO NOT OPEN

WARNING : To reduce the risk of electric shock do not remove cover or back. No user-serviceable parts inside refer service to qualified service personnel.

Safety of operators has been taken into consideration at the design and manufacture phase, but inappropriate operation may cause electric shock or fire. To prevent the product from being damaged, the following rules should be observed for the installation, use and maintenance of th product. Read the following safety instruction before starting the operation.

The User Manual uses the following symbols to ensure a safe operation and prevent any damage to operators or properties:

THIS SYMBOL INDICATES THAT HIGH VOLTAGE IS PRESENT INSIDE. IT IS DANGEROUS TO MAKE ANY KIND OF CONTACT WITH ANY INSIDE PART OF THIS PRODUCT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rule. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, use and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However ,there is no guarantee that interference with not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encourage to try to correct the interference by one or more of the following measures: *Reorient or relocate the receiving antenna. *Increase the separation between the equipment and receiver. *Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. *Consult the dealer or an experienced radio/TV technician for help. This device compiles with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may be not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC CAUTION: To assure continued compliance and possible undesirable interference, the provided ferrite cores must be used when connecting this plasma display to video equipment; and maintain at least 40cm spacing to other peripheral device.

CANADIAN NOTICE: This Class B digital apparatus compiles with Canadian ICES-003.

2 TV LCD-TFT

IMPORTANT SAFETY INSTRUCTIONS

Read all of the instructions before using this appliance. When using this

appliance, always exercise basic safety precautions, including the following:

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer`s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of

time.

14) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) WARNING-To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture.

Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases,

shall be placed on the apparatus.

PORTABLE CART WARNING

(symbol provided by RETAC)

S3126A

Owner s Manual 3

SAVE THESE INSTRUCTIONS

Thank you for using our Haier product. This easy-to-use manual will guide you in getting the best use of your product. Remember to record the model and serial number. They are on label in back of the unit.

Model number

serial number

Date of purchase

Staple your receipt to your manual. You will need it to obtain warranty service.

4 TV LCD-TFT

Contents

Introduction

War nin g . . . . . . . ...... ... ... .. . . . . . . . . . . . . . . . . . . . . . . .

Saf ety I nst ruc tio ns . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...

Introduction

Con tro ls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... ... ... ... ..

Connection Options . . . . . . . . . . . . . . . . . . . . . .............

Universal Remote Controller . ............ . . . . . . . . ......

Installation

Acc ess ori es . . . . . . . . . . . . . . . . . . . . . . . . . . . . .... ...... ..

Antenna Connection . . . . . . . . . . ..............................

VCR Connection. . . . . . . . . . . . . . . . . . . . . ............... ..

External A/V Source Setup . . . . .. . . . . ......................

DVD Connection . . . . . ...... . . . . . . . . . . . . . ................

DTV Connection.....................................................

Digital Audio Output . . . . . . . . . . . . . . . . . . . . ..............

PC Connection. . . . . . . . . . . . . . . . . . . . . . . ................

Monitor Out Setup . . . . . . . . . . . . . . . . . . . . ............... .

HDM I . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..... ... ... ... ... .

Cable Sample.........................................................

Connecting Headphones . . . . . . . . . . . . . . . . . . . ....... .

Pow er so urc e.. ... ...... ... .. . . . . . . . . . . . . . . . . . . . . . . . . .

Operation

Switching On/Off the TV set . . . . . ... . . . . . . . . . . . ... ...

Choose the Menu Language . . . . ..... .......................

Choose the input Source.........................................

Channel Menu

Automatic Scan. . . . . . . . . . . . . ............................. . .

Man ual S can . . . . ... ... ...... .. . . . . . . . . . . . . . . . . . . . . .. .

Fine Tune................................................................

Edi t Pro gra m.. ... ...... ... . . . . . . . . . . . . . . . . . . . . . . . . . ..

Rename .............. . . . . . . . . . . . . . . . . . . . . . . . . ..........

elect the desired program

S . . . . . ........... ............ . . ..

elect the desired sound

S . . .............. . . . ............ . . ..

Mute .............. . . . ............................................ . . ..

Video Menu

How to select picture modes.....................................

How to customize your own picture status .................

Aspect Ratio Control . . . . . . . . . . . . . . . . . . . . .. . . .. . . ..

Audio Menu

How to select audio modes......................................

How to customize your own audio status ..................

SAP Broadcasts Setup............................................

Time Menu

Date /Time setting...................................................

Timer on setting......................................................

Timer off setting......................................................

Sleep Timer setting.................................................

Time zone setting...................................................

Daylight Saving setting...........................................

Function Menu

Closed Captions.....................................................

CC mode...............................................................

NTSC Caption

DTV Caption..........................................................

DTV Caption Style..................................................

OSD Timeout Blue screen OSD transparency

Adjust

Screen Setup for PC mode......................................

Lock Menu

Parental Control rating and categories......................

Others Functions

Bri ef In fo. . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... ... ... .. . .

Quick program view................................................

Setting up your remote control ................................

Remote Control Codes ...........................................

Maintenance . . ...... . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Product Specifications . . . . . . . . . . . . . . . . . . . . . . .. .

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .

Warranty . . . . ... ...... ... . . . . . . . . . . . . . . . . . . . .. . . . . . .

........................................................

.........................................................

...........................................................

..................................................

Owner s Manual 5

Controls

-This is a simplified representation of front panel.

-Here shown may be somewhat different from your TV.

Front panel controls

Introduction

HL26B

1.INPUT:

HL32B

HL37B

HL40B HL42B

all input source display and OK

confirm.

2.CH( ) Program minus and plus, menu options

3.VOL( ) Volume increase and decrease, menu reset and entry

4.MENU Menu display

POWER : Is used to activate the

display or return to standby mode.

HL26S

HL32S

HL37S HL42S

INPUT

VOL

4 5

AUDIO2 Input

connect to hear

stereo sound from an

external device.

Connects the video signal

This TV operates on AC power.

VIDEO2 Input

from a video device.

Power Cord Socket

The voltage is indicated

on the Specifications page.

Never attempt to operate

the TV on DC power.

(Only for HL42S )

AUDIO

VIDEO

AC IN

1.INPUT: all input source display and OK confirm.

2.CH ( ) : program minus and plus, menu options.

3.VOL ( ): volume decrease and increase, menu reset and entry.

4.MENU: menu display.

5. POWER : Is used to activate the display or return to standby mode.

6.Power indicator: in red when standby mode, in blue when display.

7.Remote control signal receive window.

6 TV LCD-TFT

INPUT CH VOL MENU

The buttons are on the bottom of the TV set)

VOL

INPUT

Only for: HL42S

7 6

Connection Options

Back panel controls

Antenna Input

Connect cable or antenna signals to the TV, either directly or through your cable box.

HDMI2

ANT IN

HDMI connect a signal to HDMI/DVI.

PC VIDEO Input

Connect the monitor output connector from a PC to the jack

Audio Output

S-Video Input

Connect S-Video out from an S-VIDEO device to the S-VIDEO input.

Pr2Pb2

DVD/DTV Input

(Component )

Connect a component video device to these jacks.

L R L R

Pr1Pb1

AUDIO/VIDEO

output

AV OU T L R

S-VIDEO

VIDEO L R

VIDEO Input

Connects the

video signal

from a video

device.

AUDIO Input

connect to hear

stereo sound from an

external device.

HDMI2 connect a signal to HDMI/DVI.

HDMI1

Earphone jack:

Earphone audio output terminal.

DVI/PC Audio Input

Connect the audio out from the external device, used while using a DVI to HDMI connector.

Connect audio from various types of equipment.

Note: In standby mode, these ports will not work.

PC/DVI AUDIO IN

OPTICAL

AC IN

Power Cord Socket

This TV operates on AC power. The voltage is indicated on the Specifications page. Never attempt to operate the TV on DC power

(for HL26S, It is on the left. )

Owner s Manual 7

Universal Remote Controller

- The remote controller cannot be operated unless the batteries are properly loaded.

- When using the remote control, aim it at the remote control sensor on the TV.

Introduction

Function introduction

Turns your TV or any other programmed

equipment on or off, depending on mode.

Open the channel list.

PIP function buttons

Selects the picture appropriate

for the program's character.

CC(closed caption)

Select a closed caption:

CC MUTE, CC ON, CC OFF.

Brings up the main menu to the screen.

Clears all on-screen displays and

returns toTV viewing from any menu.

Switches the sound on or off

(Aspect Ratio Control)

Changes the aspect ratio.

POWER

CH.LIST

(no available)

P.MODE

TIME

EXIT

MUTE

ARC

TV DVD VCR SETBOX CABLE AUDIO

Press the SELECT button repeatedly to select one of the system modes in which the remote control can be used.

When the desired device is selected, the corresponding LED lights on 5seconds.

FAVORITE

Open the favorite channel list.

CH.LIST

PIP SWAP

FAV.LIST

AUDIO LIST

AUDIO SWA P

SEL ECT

POSITION

AUDIO.LIST

Open the audio channellist.

VCR/DVD Functions

Control some video cassette recorders or DVD players.

/ Rewind / Fast / backward /Forward

Stop Play/Pause REC

S.MODE

Selects the sound appropriate for the program's character.

FREEZE

Freezes the currently-viewed picture, but audio continues. Press FREEZE button again to resume the normal picture.

S.MO DE

P.MODE

FREE ZE

NPUT

TIM

INFO

INPUT

show the input source mode.

.Shows time

VOL +

VOL-

CH+

CH-

INFO

When you watch the TV, press the key, the information displays on bottom of the screen.

THUMBSTICK (Up/Down/Left/Right/OK)

Allows you to navigate the on-screen menus and adjust the system settings to your preference.

SLEEP button

Displays the Sleep Timer option.

LIGHT

Press the light button, white LED will be ON, release this key, white LED will be OFF.

SAP

Selects MTS sound: Mono, Stereo, and SAP in Analog mode. Change the audio language in DTV mode.

Increases/decreases the sound level.

Numeric buttons

VOLUME UP/DOWN

press to change the channel.

- button

Press to select additional channels

being broadcast by the same station.

“54-3”, press “54”, then press “-” and “3”.

For example, to select channel

8 TV LCD-TFT

(digital and analog)

CHANNEL UP/DOWN

Selects available channels

Q.VIEW

Switch the current channel to the last channel you have viewed.

External Equipment Connections

Accessories

SELECT

CH.LIST

FAV.LIST

AUDIO LIST

PIP SWAP

AUDIO SWAP

POSITION

S.MODE

P.MODE

FREEZE

IN F

N E

I T

L S

A R

VOL+

CH+

VOL-

CH-

Q.VIEW

OWNER S MANUAL'

TFT-LCD TV

MODEL:L40A8A

Please READ this manual carefully before operating your TV, and retain it for future reference.

Installation

Remote controller

Owner`s manual

Alkaline battery(AAA) 2

Power cable

Antenna Connection

Generally speaking, to enjoy a clearer picture, we recommend that you use a CATV system or an outdoor antenna .In different places, the suitable antenna type and position are different.

Multi-family Dwellings/Apartments (Connect to wall antenna socket)

Wall Antenna Socket

Bronze Wire

RF Coaxial Wire (75 ohm)

VHF Antenna UHF Antenna

Single-family Dwellings /Houses (Connect to wall jack for outdoor antenna)

Outdoor Antenna

Turn clockwise to tighten.

Bronze Wire

Be careful not to bend the bronze wire when connecting the antenna.

To improve the picture quality in a poor signal area,

please purchase a signal amplifier and install properly.

If the antenna needs to be split for two TV`s, install a 2-

Way Signal Splitter in the connections.

If the antenna is not installed properly, contact your dealer

for assistance.

Owner s Manual 9

External Equipment Connections

NOTE: All cables shown are not included with the TV.

Choose Your Connection

There are several ways to connect your television, depending on the components you want to connect and the quality of the signal you want to achieve. The following are examples of some ways to connect your TV. Choose the connection which is best for you.

VCR connection

- To avoid picture noise (interference), leave an adequate distance between the VCR and TV

Connection Option 1

Set VCR output switch to channel 3 or 4 and then tune the TV to the same channel number.

Installation

Connection Option 2

1. Connect the audio and video cables from the

VCR's output jacks to the TV input jacks, as shown in the figure. When connecting the TV to VCR, match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red). If you connect an S-VIDEO output from VCR to the S-VIDEO input, the picture quality is improved; compared to connecting a regular VCR to the Video input.

2. Insert a video tape into the VCR and press

PLAY on the VCR. (Refer to the VCR owner`s manual.)

3. Select the input source with using the

INPUT button on the remote control, and then press / button to select the source, press the button to confirm.

ANT IN

Pr2Pb2

L R L R

Pr1Pb1

S-VIDEO

AV OU T L R

VIDEO L R

10 TV LCD-TFT

External Equipment Connections

External A/V Source Setup

How to connect

Connect the audio and video cables from the external equipment's output jacks to the TV input jacks, as shown in the figure. When connecting the TV to external equipment, match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red).

How to use

1. Select the input source with using the INPUT button on the remote control.

2. Press the / button to select the desired source.

3. Press the ok button to confirm

2. Operate the corresponding external equipment.

Y2 Y1

Pr2Pb2 Pr1Pb1

Installation

L L

S-VIDEO

AV OU T L R

VIDEO L R

Camcorder

DVD connection

How to connect

1. Connect the DVD video outputs (Y, Pb/Cb, Pr/Cr) to the Y, Pb, Pr jacks on the TV and connect the DVD audio outputs to the YPbPr Audio IN jacks on the TV, as shown in the figure.

2. If your DVD only has an S-VIDEO output jack, connect this to the S-VIDEO input on the TV. as shown in the figure.

NOTE: If your DVD player does not have component video

output, use S-Video.

How to use

1. Turn on the DVD player, insert a DVD.

2. Use the INPUT button on the remote control to select YPbPr mode.

3. Press Play button on external equipment for program play.

4. Refer to the DVD player's manual for operating instructions.

Component Input ports To get better picture quality, connect a DVD player to the component input ports as shown below.

Component ports on the TV

Y Pb Pr

Video Game Set

Pr2Pb2

Pr1Pb1

L L

S-VIDEO

AV OU T L R

VIDEO L R

Video output ports on DVD player

Y Pb Pr Y B-Y R-Y

Y Cb Cr Y P P

Owner s Manual 11

Installation

External Equipment Connections

DTV connection

- This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive Digital signals from a digital set-top box or other digital external device, refer to the figure as shown below.

- This TV supports HDCP (High-bandwidth Digital Contents Protection) protocol for Digital Contents (480p,720p,1080i).

How to connect

Use the TV`s (Y, PB, PR) , VGA or HDMI jack for video connections, depending on your set-top box connector. Then, make the corresponding audio connections.

How to use

1. Turn on the digital set-top box. (Refer to the owner`s manual for the digital set-top box.)

2. Use INPUT on the remote control to select YPbPr, VGA,or HDMI source.

Pr2Pb2

L R L R

Pr1Pb1

S-VIDEO

AV OU T L R

VIDEO L R

HDMI1

PC/DVI AUDIO IN

OPTICAL

Signal

480i

480p

720p

1080i

YPbPr

Yes

HDMI/DVI

Yes

Audio Output

Send the TV`s audio to external audio equipment (stereo system) via the Audio Output (Optical) port.

How to connect

1. Connect one end of an optical cable to the TV Audio (Optical) Output port.

2. Connect the other end of the optical cable to the digital audio (optical) input on the audio equipment. See the external audio equipment instruction manual for operation.

Digital Set-top Box

PC/DVI

OPTICAL

AUDIO IN

AC IN

Note: When connecting with external audio equipments, such as amplifers or speakers, please turn the TV speakers off.

Caution: Do not look into the optical output port. Looking at the laser beam may damage your vision.

12 TV LCD-TFT

Installation

External Equipment Connections

PC connection

How to connect

1. To get the best picture quality, adjust the PC graphics card to 1024

2. Use the TV`s PC or DVI (Digital Visual Interface)Audio IN port for video connections, depending on your PC connector.

If the graphic card on the PC does not output analog and digital RGB simultaneously, connect only one of eitherVGA r DVI IN to

display the PC on the TV.

If the graphic card on the PC does output analog and digital RGB simultaneously, set the TV to eithe DVI; (the other mode is

set to Plug and Play automatically by the TV.)

3. Then, make the corresponding audio connection. If using a sound card, adjust the PC sound as required.

How to use

1. Turn on the PC and the TV.

2. Turn on the display by pressing the POWER button on the TV's remote control.

3. Use INPUT on the remote control to select VGA or HDMI source.

4. Check the image on your TV. There may be noise associated with the resolution, vertical pattern, contrast or brightness in PC mode.

If noise is present, change the PC mode to another resolution, change the refresh rate to another rate or adjust the brightness and contrast on the menu until the picture is clear. If the refresh rate of the PC graphic card can not be changed, change the PC graphic card or consult the manufacturer of the PC graphic card.

NOTES: 1 Use a DVI cable. 2 Avoid keeping a fixed image on the TV's screen for a long period of time. The fixed image may become permanently imprinted on the

screen. 3 The synchronization input form for Horizontal and Vertical frequencies is separate.

x768 .

IN o

r VGA or

Resolution

Mode

VGA

SVGA

XGA

Resolution

Frame frequency (Hz)

640*480 60Hz

800*600 60Hz/75Hz

60Hz

1024*768

75Hz

ANT IN

HDMI2

PC/DVI

HDMI1

AUDIO IN

OPTICAL

Owner s Manual 13

External Equipment Connections

Monitor Out Setup

The TV has a special signal output capability which allows you to hook up a second TV or monitor.

Connect the second TV or monitor to the TV`s AV OUT. See the Operating Manual of the second TV or monitor for further details regarding that device`s input settings.

Notes:

YPbPr, VGA, HDMI,DTV input sources cannot be used for Monitor out.

When connecting with external audio equipments, such as amplifers or speakers, please turn the TV speakers off.

Installation

Pr2Pb2

L R L R

Pr1Pb1

S-VIDEO

AV OU T L R VIDEO L R

HDMI

How To Connect

1. Connect the source device to HDMI port of this TV with an HDMI cable(not supplied with this product).

2. No separated audio connection is necessary.

How To Use

- If the source device supports Auto HDMI function, the output resolution of the source device will be automatically set to 1280x720p.

- If the source device does not support Auto HDMI, you need to set the output resolution appropriately. To get the best picture quality, adjust the output resolution of the source device to 1280x720p.

- Select HDMI input source in input source option of Select Main source menu.

How To Connect

1. Connect the source device to HDMI port of this TV with a HDMI-to-DVI cable(not supplied with this product).

2. A separated audio connection is necessary.

3. If the source device has an analog audio output connector, connect the source device audio output to DVI Audio In port located on the left side of HDMI port.

How To Use

- If the source device supports Auto DVI function, the output resolution of the source device will be automatically set to 1280x720p.

- If the source device does not support Auto DVI, you need to set the output resolution appropriately. To get the best picture quality, adjust the output resolution of the source device to 1280x720p.

- Press the INPUT button to select HDMI input source in input source option of Select Main source menu.

14 TV LCD-TFT

Cable sample

Installation

HDMI Cable (not supplied with the product)

HDMI to DVI Cable (not supplied with the product)

Analog Audio Cable (Stereo to RCA type) (not supplied with the product)

Owner s Manual 15

External Equipment Connections

Connecting Headphones

You can connect a set of headphones to your set if you wish to watch a TV programme without disturbing the other people in the room.

Plug a set of headphones into the 3.5mm mini-jack socket on the rear panel of the set.

PC/DVI

HDMI1

AUDIO IN

OPTICAL

Note

Prolonged use of headphones at a high volume

may damage your hearing.

You will not receive sound from the speakers

when you connect headphones to the system.

Installation

Power source

Wider Hole and Blade

Polarized AC Cord Plug

AC Outlet

TO USE AC POWER SOURCE

Use the AC polarized line cord provided for operation on AC. Insert the AC cord plug into a standard polarized AC outlet.

NOTES:

Never connect the AC line cord plug to other than the specified voltage. Use the attached power cord only.

If the polarized AC cord does not fit into a nonpolarized AC outlet, do not attempt to file or cut the blade. It is the user`s responsibility to have an electrician replace the obsolete outlet.

If you cause a static discharge when touching the unit and the unit fails to function, simply unplug the unit from the AC outlet and plug it back in. The unit should return to normal operation.

16 TV LCD-TFT

Operation

-In the manual, the OSD (on screen display) may be different from your TV`s, because it is just an example to help you with the TV operation.

-There are several options you might need to set up in order for your TV to work properly. Read the instructions that follow.

Switching On/Off the TV set

1. First, connect power cord correctly.

2. Select the viewing source by using INPUT button on the remote control.

3. When finished using the TV, press the POWER button on the remote control. The TV reverts to standby mode.

4. If you intend to be away on vacation, disconnect the power plug from the wall power outlet.

Note:

If the TV in power on , the screen show information according the type of input signal . the information will disappear. If there is no signal and bluescreen in ON the screen enter in bluescreen and display No signal on top and center of the screen.

Choose the Menu Language

When you start using your set for the first time, you must select the language which will be used for displaying menus

and indications.

1 Press the MENU button and then use / button to select the

Video

Audio

Time

Channel

Function

Menu Language English

CC Mode On

Basic Caption CC1

Advanced Caption Service1

Caption Type Basic

Caption Style

OSD Timeout Middle

Blue Screen On

OSD transparency Middle

Lock

: Move cursor, /OK: Go to submenu, EXIT/ MENU: Exit main menu

English

Spanish

French

Function menu.

2 Press the button and then use / button to select Menu

Language.

3 Press the button and then use / button to enter the list of

available language. English Spanish or French

4 Select your language with the / button and press the OK

button to confirm you selection.

5 When you are satisfied with your choice, press the EXIT button

to return to normal viewing or press MENU button to return to the

previous menu.

Choose the Input source

- Change the picture source so you can watch your TV, cable TV, VCR, DVD, or any other devices that are connected to your TV.

1. Press the INPUT button to enter the Select Main picture Source menu and then use / button to select the desired items. Cable/Air TV, , VIDEO2

, SVIDEO, YPBPR1, YPBPR2, VGA, HDMI1, HDMI2.

VIDEO1

2. Press the OK button to confirm.

3. Press INPUT button to return to TV viewing or press EXIT button to return to the previous menu.

Note:

1. According to your connection device, you can change the name of every source.

2. In channel menu, if the Tuner item is set ting as Air or Cable, the source menu will display Air TV or Cable TV;

Select Main Source

Air TV

VIDEO1

VIDEO2

SVIDEO

YPBPR1

YPBPR2

VGA

HDMI1

HDMI2

Up/Down:Move Cursor OK: Change MP Source Right:Activale Source Name Edit Menu

DVD

STB

PVR

Cable

Game

Owner s Manual 17

Channel menu

This TV set has three methods to set channels, which are respectively Auto Scan, manual Scan fine tune. In this section, how to use the remote control to set channel is explained. You can also use buttons on the TV

set to set channel.

A password is required to gain access to Channel menu if the Lock of Edit program menu is turned on.

Automatic Scan

- Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the All Channel List.

Note : the Channel menu will be only operated in normal TV mode.

1 Press the MENU button and then use / button to select the

Channel menu.

2 Press the button and then use / button to select Tuner.

3 Press the button and then use / button to Select Cable or

Air mode.

4 Press the OK button

5 When you are satisfied with your choice, press MENU button to

return to the previous menu.

6 Press the / button to select Auto Scan.

7 Press the button and press the OK button to start searching.

8 To cancel searching, press the OK button.

Video

Audio

Time

Channel

Function

Lock

Video

Audio

Time

Channel

Function

Lock

Tuner Air

Auto Scan

Manual Scan

Fine Tune

Edit Program

Rename

: Move cursor, /OK: Go to submenu, EXIT/ MENU: Exit main menu

Tuner Air

Auto Scan

Manual Scan

Fine Tune

Edit Program

Rename

: Move cursor, OK: Enter, MENU: Return to upper menu, EXIT: Exit main menu

Operation

Air

Cable

OK Cancel

Air Tuner Number: 47 Found: 1

When Air is selected, the TV will detect antenna signals and will search for antenna TV (NTSC and ATSC) channels available in your local area. When Cable is selected, the TV will detect cable company supplied signals and will search for cable TV (NTSC,ATSC, QAM modulated) channels available in your area.

18 TV LCD-TFT

Channel menu

Manual Scan

If excessive channel signals of unwanted programs are received in local area, manual search function is recommended.

Operation

Tuner Air

Auto Scan

Manual Scan

Fine Tune

Edit Program

Rename

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

1 Press the MENU button and then use / button to select the

Channel menu.

2 Press the button and then use / button to select Tuner.

3 Press the button and then use / button to Select Cable or Air

mode.

4 Press the OK button.

Video

Audio

Time

Channel

Function

Lock

5 When you are satisfied with your choice, press MENU button to return

to the previous menu.

6 Press the / button to select Manual Scan.

7 Press the button and then use digital buttons to select channel number you want to add or delete.

8 Press the button to select OK item and press OK button to add for the channel number.

9 Press EXIT button to return to TV viewing or press MENU button to return to the previous menu.

Fine Tune (only in anolog signal )

1 Press the MENU button and then use / button to select the

Channel menu.

2 Press the / button to select Fine Tune.

3 Press the or OK button

4 Press the button to tune.

5 Press EXIT button to return to TV viewing or press MENU button

to return to the previous menu.

Video

Audio

Time

Channel

Function

Lock

Tuner Air

Auto Scan

Manual Scan

Fine Tune

Edit Program

Rename

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Type

Channel NO

Frequency

For the tune of the analog channels

Air

67.250MHz

Owner s Manual 19

Operation

Channel menu

Edit Program

You can create your own Favorite List. Use the FAV.LiST butt

then you can add or delete the channel to/from the Favorite List.

You can skip some channel; You can lock some channel;

1 Press the MENU button and then use / button to select the

Channel menu.

2 Press the button and then use / button to select Edit Program.

3 Press the button. You will now see a screen filled with channel numbers.

4 Use / / / button to select FAV., Lock or Skip item, and then use the OK button to confirm.

5 When you are satisfied with your choice, press MENU button to return to the previous menu or Press EXIT button

to return to TV viewing.

on on the remote control when a channel is highlighted and

B C

Video

Audio

Time

Channel

Function

Lock

Tuner Air

Auto Scan

Manual Scan

Fine Tune

Edit Program

Rename

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Ch No Name SkipLock

Music

Fav

Page 1/1

Skip

After the programs are presetting, you can skip some programs so that to select your favorite channels only.

Lock

After the programs are presetting, you can lock some programs so that to select your favorite channels only.

Fav (Favorite)

Press the FAV.LiST button open the favorite channel list, press / button to select the channel and press OK button to confirm.

Tuner Air

Auto Scan

Manual Scan

Fine Tune

Edit Program

Rename

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Program No

Program Name

Rename (only in anolog signal )

1 Press the MENU button and then use / button to select the

Channel menu.

2 Press the button and then use / button to select Rename.

3 Press the or OK button to enter the Submenu.

4 The cursor flashs, Use the digital button to select the letter, and

press / button to move the cursor and OK button to confirm.

(Press the Q.VEIW button to delete the letter. )

5 When you are satisfied with your choice, press MENU button to

return to the previous menu or Press EXIT button to return to TV

viewing.

Video

Audio

Time

Channel

Function

Lock

20 TV LCD-TFT

Operation

Select the desired program

Using the CH+/- buttons.

Press the CH+ button to select a channel number in number increasing direction.

Press the CH- button to select a channel number in number decreasing direction.

(Note: If Skip is ON on one channel, press CH+/- button, the channel will not appear.)

Select the desired sound

Press the VOL-/+ or / buttons on the remote or the front of the TV set to adjust the volume level. The range is 0~100. When the volume buttons are pressed the volume level is displayed automatically on the TV screen.

Volume

+ 21

Mute

When you need to pay attention to surrounded sounds, or there is a telephone calling you or there are some guests visiting you, the sound elimination (mute) function is very convenient.

1 Press the MUTE button on the remote control and " "

type face will display on the screen. At this time, the sound of the TV set is turned off.

2 If you want to recover the sound, press the MUTE

button again or directly press VOL+ buttons.

Owner s Manual 21

Video menu

The TV menu gives you an overview of the menus you can select.

Note: Depending on the input signal, one or more menu items may not be selectable.

How to select picture modes

The picture mode provides the pre-defined images settings. There are four settings: standard/ vivid /mild/custom.

Press P.MODE button on the remote controller the Video Mode list is out , press P.MODE to select the option (Standard/Vivid/Mild/Custom)

Operation

Standard:

Vivid:

Mild:

Custom:

normal mode.

mode of watching the movement of picture.

the effect of the picture is soft.

picture effect which you favorite.

How to customize your own picture status

1 Press the MENU button and then use / button to select the Video menu.

2 Press the button and then use / button to select the desired items.

3 Press the button and then use / button to adjust the setting.

4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Contrast

This will adjust the intensity of bright parts in the picture but keep the dark parts unchanged.

Brightness

This will adjust the light output of the complete picture, which will mainly affect the darker areas of the picture.

Tint

Allows you to select the color mix (Tint) of the picture.

Color

This will adjust the saturation level of the colors to suit your personal preference.

Sharpness

This will adjust the sharpness of fine details in the picture.

Video

Audio

Time

B C

Channel

Function

Lock

Mode Custom

Contrast 50

Brightness 50

Tint 0

Color 50

Sharpness 50

DNR Off

Color Temperature Standard

Black Stretch Off

: Move cursor, /OK: Go to submenu, EXIT/ MENU: Exit main menu

Note:

Only when the item of mode is custom , the Contrast Brightness Tint color Sharpness can be set by user . In other mode the value of them are preset by program .

Standard

Vivid

Mild

Custom

DNR (Digital Noise Reduction )

Automatically filters out and reduces the image noise and improves picture quality when receiving weak video signals. Select Off/Weak/Medium /Strong according to the image noise.

Color temperature

This will increase or decrease Warm (red) and Cold (blue) colors to suit personal preferences. Select Cold to give the white colors a blue tint, Standard to give the white colors a neutral tint, Warm to give the white colors a red tint.

Black Stretch

This will increase automatically the contrast rage.

22 TV LCD-TFT

Operation

Aspect Ratio Control

- Lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV with a 16:9 ratio picture format.

- Note: If a fixed image is displayed on the screen for a long time, it image may become imprinted on the screen and remain visible.

1 Press the ARC button the Aspect Ratio menu appearance on the screen. 2 Press the / button to select the desired picture format. 3 Press the OK button to confirm.

4:3 mode Choose 4:3 when you want to view a picture with an original 4:3 aspect ratio, with gray bars appearing at both the left and right sides.

16:9 mode Choose 16:9 when you want to adjust the picture horizontally, in a linear proportion to fill the entire screen.

Zoom 1 Choose Zoom 1 when you want to view the picture without any alteration. However, the top and bottom portions of the picture will be cropped.

Zoom 2 Choose Zoom 2 when you want the picture to be altered, both vertically extended and cropped. The picture taking a halfway trade off between alteration and screen coverage.

Subtitle Choose Subtitle when you want to adjust the picture in a non-linear proportion, that is, more enlarged at top sides and no alteration , at bottom side.

PANORAMA Choose PANORAMA when you want to enlarge the picture in correct proportion.

Note: When enlarging or reducing the picture size, the image may become distorted.

Notes

In TV, VIDEO1, VIDEO2,SVIDEO modes, all screen modes can be selected.

(16:9 Mode . Panorama . Zoom1 . Zoom2 . 4:3 Mode. Subtitle).

In YPbPr, HDMI modes, only 16:9 Mode, 4:3 modes, Zoom1 or Zoom2 can be selected. In VGA mode, only 16:9 Mode, 4:3 mode, dot by dot can be selected. In DTV mode, only 16:9 Mode, 4:3 mode can be selected.

Owner s Manual 23

Audio menu

How to Select Audio modes

Press S.MODE button on the remote controller the Audio Mode list is out , press S.MODE to select the option (Live/POP/Rock/Custom).

Operation

Custom

Live

POP

Rock

A spare setting that can be adjusted to personal tastes.

Normal sound with moderate bass and treble setting.

Designed to reduce the bass and treble which enhances the voice for news programs.

Enables extra bass and treble to enhance the movie experience.

How to Customize your own audio status

1 Press the MENU button and then use / button to select the Audio menu.

2 Press the button and then use / button to select the desired items.

3 Press the button and then use / button to adjust the setting.

4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Headphone volume

This controls the level of sound through the headphones.

Volume

This will adjust the sound output level.

Balance

This will adjust the output of the right and left speakers to obtain the best stereo reproduction for your listening position.

Equalizer Mode

This sound setting can be adjusted to suit your personal preference.

Digital Audio (only selectable with digital broadcast signals)

Make your selection of the source to which the device with digital audio input has been connected. In addition to accepting audio input via Digital Audio In, the TV can output Digital audio via the Optical connector to an external amplifier or receiver. If your amplifier or receiver has a matching connector for Digital Audio In, you can connect it with a single cable to the TV`s Optical.

AVL (

Automatic volume control)

This will r

educes the differences in volume level among broadcasters.

Video

Audio

Time

B C

Channel

HeadPhone Volume 10

Volume 20

Balance 0

Equalizer Mode Custom

Digital Audio

AVL off

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Video

Audio

Time

B C

Channel

HeadPhone Volume 10

Volume 20

Balance 0

Equalizer Mode Custom

Digital Audio

AVL off

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Video

Audio

Time

B C

Channel

HeadPhone Volume 10

Volume 20

Balance 0

Equalizer Mode Custom

Digital Audio

AVL off

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Live POP Rock Custom

120Hz

500Hz

1.5KHz

5KHz

10KHz

Digital Audio Output Mode

Dolby Digital

PCM

24 TV LCD-TFT

Audio menu

SAP Broadcasts Setup

- This TV can receive MTS stereo programs and SAP (Secondary Audio Program) that accompanies the stereo program; if the station transmits an additional sound signal as well as the original one.

- When having selected SAP button on the remote control, this TV can only receive the signal when the TV station transmits the proper signals.

- Mono sound is automatically received if the broadcast is only in Mono; even though Stereo or SAP has been selected.

- Select Mono if you want to listen to mono sound during stereo/SAP broadcasting.

- Stereo or SAP can be received in a Analog channel.

1. Use the SAP button to select your desired MTS mode in a analog signal. Each time you press the SAP button, Mono,Stereo, or SAP appear. If other languages are available on the digital signal, select them with the SAP button.

2. Press EXIT button to save and return to TV viewing.

Operation

Owner s Manual 25

Time menu

Date /Time setting

Setting the clock is necessary in order to use the various timer features of the TV. Also, you can check the time while watching the TV.

1 Press the MENU button and then use / button to select the Time menu.

2 Press the button and then use / button to select the Date/Time.

3 Press the button and then use / button to select the Mode:

Manual or Auto.

4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Video

Audio

Time

B C

Channel

Date/Time

Timer on

Timer Off

Sleep Timer 0 min

Time Zone Newfoundland

Daylight Saving On

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Operation

Mode Manual Auto

Date 2004.12.31

Time 08 38 PM

Timer on setting

Switch on automatically at the time you presetting.

1 Press the MENU button and then use / button to select the Time menu.

2 Press the button and then use / button to select the Timer On.

3 Press the button and then use / button to select the Mode:

Off, Once or Daily.

4 Press the OK button to confirm.

When selecting Once or Daily item, On time item will be active, press /

button to set the desired level, press / button to button move cursor.

5 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Timer off setting

Switch off automatically at the time you presetting.

1 Press the MENU button and then use / button to select the Time menu.

2 Press the button and then use / button to select the Timer Off.

3 Press the button and then use / button to select the Mode:

Off, Once or Daily.

4 Press the OK button to confirm.

When selecting Once or Daily item, On time item will be active, press /

button to set the desired level, press / button to button move cursor.

5 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Video

Audio

Time

B C

Channel

Date/Time

Timer on

Timer Off

Sleep Timer 0 min

Time Zone Newfoundland

Daylight Saving On

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Video

Audio

Time

B C

Channel

Date/Time

Timer on

Timer Off

Sleep Timer 0 min

Time Zone Newfoundland

Daylight Saving On

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Mode Off Once Daily

On time 08 38 PM

Mode Off Once Daily

Off time 08 38 PM

26 TV LCD-TFT

Time menu

Sleep Timer setting

The sleep timer automatically shuts off the TV after a preset time (from 15 to 120 minutes).

1 Press the MENU button and then use / button to select the Time menu.

2 Press the button and then use / button to select the SleepTimer.

3 Press the button and then use / button to select the number of minutes.

Select 0Min, 15Min, 30Min, 60Min, 90Min, 120Min.

When the number of minutes you want is displayed on the screen, press

the OK button. The time begins to count down from the number of minutes

selected.

4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

5 To cancel the set sleep timer:

Press the / button to select 0min.

You can use the SLEEP button also to select quickly the sleep timer.

Video

Audio

Time

B C

Channel

Date/Time

Timer On

Timer Off

Sleep Timer 0 min

Time Zone Newfoundland

Daylight Saving On

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Operation

0 min

15min

30min

60min

90min

120min

Time zone setting

(only available when date/time mode is set to Automatic) This function allows you to select your local time zone. Broadcasted time information will correct the clock display for your local time.

1 Press the MENU button and then use / button to select the Time menu.

2 Press the button and then use / button to select the Time Zone items.

3 Press the button and then use / button to adjust the setting.

4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Press the button and then use / button to select your viewing area time zone: Newfoundland, Atlantic, Eastern, Central, Mountain, Pacific, Alaska, Hawaii

or Samoa.

Daylight Saving setting

(only available when date/time mode is set to Automatic) Daylight saving time is automatically set by specially broadcasted signals. This menu item allows you to disable the automatic setting of daylight saving time. This is useful if you live in an area or state where daylight saving is not applied, but you receive channels from other areas where daylight saving signals are broadcasted.

1 Press / button to select Daylight Saving item. 2 Press the buttont to select On for automatic clock correction for daylight saving time, based on specially broadcasted signals. Select Off to disable automatic clock correction based on the specially broadcasted signals.

Video

Audio

Time

B C

Channel

Date/Time

Timer on

Timer Off

Sleep Timer 0 min

Time Zone Newfoundland

Daylight Saving On

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Video

Audio

Time

B C

Channel

Date/Time

Timer on

Timer Off

Sleep Timer 0 min

Time Zone Newfoundland

Daylight Saving On

Function

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Newfoundland

Atlantic

Eastern

Central

Mountain

Pacific

Alaska

Hawaii

Samoa

Off

Owner s Manual 27

Function menu

Closed Captions

Closed captioning is a process which converts the audio portion of a television program into written words which then appear as subtitles on the television screen. Closed captions allow viewers to read the dialogue and narration of television programs.

Using Closed Captions

Captions are the subtitles of the dialogue and narration of television programs. For prerecorded programs, program dialogue can be arranged into captions in advance. Its possible to caption a live program by using a process called real-time captioning, which creates captions instantly. Real-time captioning is normally done by professional reporters using a machine shorthand system and computer for translation into English. Captioning is an effective system for the hearing-impaired, and it can also aid in teaching language skills.

CC mode

1. Press the MENU button and then use / button to select the

Function menu.

2. Press the / button to select the CC mode.

3. Press the button and then use / button to select the items:

(On, Off or On When mute.)

4. When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Operation

Video

Audio

Time

B C

Channel

Function

Lock

Menu Language English

CC Mode On

Basic Caption CC1

Advanced Caption Service1

Caption Type Basic

Caption Style

OSD Timeout Middle

Blue Screen On

OSD transparency Middle

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

off

On when mute

Note: The captions do not always use

correct spelling and grammar. Not all TV programs and product commercials are made for broadcast with Closed Caption information included. Refer to your area`s TV program listings for the TV channels and times of Closed Caption shows. The captioned programs are usually noted in the TV listings with service marks such as CC .

Basic Caption

This allows you to configure the way you choose to view the digital captioning.

1. Press the MENU button and then use / button to select the

Function menu.

2. Press the button and then use / button to select Basic Caption.

3. Press the button and then use / button to select caption: CC1, CC2,

CC3, CC4, Text1, Text2, Text3, or Text4.

4. When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

CAPTION The term for the words that scroll across the bottom of the TV screen; usually the audio portion of the program provided for the hearing impaired. TEXT The term for the words that appear in a large black frame and almost cover the entire screen; usually messages provided by the broadcaster.

Advanced Caption(In DTV mode)

This allows you to configure the way you choose to view the digital captioning. Select one of the digital service channels made available by the caption provider. There are 6 standard services. Service 1 is designated as the Primary Caption Service. This service contains the verbatim, or near-verbatim captions for the primary language being spoken in the accompanying program audio. Service 2 is designated as the Secondary Language Service. This service contains captions in a secondary language which are translations of the captions in the primary Caption Service. The other service subchannels are not pre-assigned. It is up to the discretion of the individual caption provider to utilize the remaining service channels.

Video

Audio

Time

B C

Channel

Function

Lock

Video

Audio

Time

B C

Channel

Function

Menu Language English

CC Mode On

Basic Caption CC1

Advanced Caption Service1

Caption Type Basic

Caption Style

OSD Timeout Middle

Blue Screen On

OSD transparency Middle

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Menu Language English

CC Mode On

Basic Caption CC1

Advanced Caption Service1

Caption Type Basic

Caption Style

OSD Timeout Middle

Blue Screen On

OSD transparency Middle

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

CC1

CC2

CC3

CC4

Text1

Text2

Text3

Text4

Service1

Service2

Service3

Service4

Service5

Service6

28 TV LCD-TFT

Caption Style (In DTV mode)

This allows you to modify how digital captions are displayed on your TV. Select from the following options to change the visual characteristics of your TV`s digital captioning.

Operation

1. Press the MENU button and then use / button to select the Function menu.

2. Press the button and then use / button to select Caption Style.

3. Press the button and then use / button to set style as Custom.

4. Use / button to customize the Style, Font, etc., to your preference.

5. When you are satisfied with your choice, press MENU button to return to the previous menu or press the EXIT button to return to TV viewing.

Style

Video

Audio

Time

B C

Channel

Function

Menu Language English

CC Mode On

Basic Caption CC1

Advanced Caption Service1

Caption Type Basic

Caption Style

OSD Timeout Middle

Blue Screen On

OSD transparency Middle

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Style Default

Size Default

Font Default

Text Color Default

Text Opacity Default

BG Color Default

BG Opacity Default

Preview

Closed Caption

Select this option to select the font style of caption display according to your own preference. Press the / button to select Default, Custom, Style1, Style2, Style3,

Style4,Style5, Style6, Style7, Style8.

Press the OK button to confirm.

Size

Select this option to select the size of caption display according to your own preference. Press the / button to select Default, Small, Normal or Large , Press the OK button to confirm.

Font

Select this option to select the font of caption display according to your own preference. Press the / button to select Default, Font1 Font2, Font3, Font4, Font5, Font6, Font7,Font8. Press the OK button to confirm.

Text color

Select this option to select the text color or the opacity of the text box of caption display according to your own preference. Select a color and one of the opacity options.

Text Opacity: Specify the opacity for the text color.

BG (Background) Color: Select a background color.

BG (Background) Opacity: Select the opacity for the background color.

OSD Timeout

1. Press the MENU button and then use / button to select the Function menu.

2. Press the button and then use / button to select OSD Timeout.

3. Press the button and then use / button to select short, middle or Long.

4. Press the OK button to confirm.

Blue screen

Select this option to select the character background color.

1. Press the MENU button and then use / button to select the Function menu.

2. Press the button and then use / button to select Blue screen.

3. Press the button and then use / button to select on or off.

4. Press the OK button to confirm.

OSD transparency

1. Press the MENU button and then use / button to select the Function menu.

2. Press the button and then use / button to select OSD transparency.

3. Press the button and then use / button to select Low ,middle or High.

4. Press the OK button to confirm.

Video

Audio

Time

B C

Channel

Function

Lock

Video

Audio

Time

B C

Channel

Function

Lock

Menu Language English

CC Mode On

Basic Caption CC1

Advanced Caption Service1

Caption Type Basic

Caption Style

OSD Timeout Middle

Blue Screen On

OSD transparency Middle

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Menu Language English

CC Mode On

Basic Caption CC1

Advanced Caption Service1

Caption Type Basic

Caption Style

OSD Timeout Middle

Blue Screen On

OSD transparency Middle

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Short

Middle

Long

Low

Middle

High

Owner s Manual 29

Adjust menu

Screen Setup for PC mode

- When RGB connect to PC input and select the VGA, this function is used.

Adjustment for screen Position, Size, Phase, Reset

- Display PC Adjust Menu by pressing INPUT button then use / button to select the VGA item.

Position : Adjust the screen position.

Size : Adjust the screen size.

Phase : Adjust the phase of Pixel clock.

Mode : there are two modes: Auto Sync and default

1 Press the MENU button and then use / button to select the

Adjust menu.

2 Press the button and then use / button to select the desired items.

3 Press the button and then use / button to adjust the setting.

4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Video

Audio

Time

Adjust

Function

Lock

: Move cursor, /OK: Go to submenu, EXIT/ MENU: Exit main menu

Operation

H Size 20

H Position 20

V Size 20

V Position 20

Phase Adjust 18

Mode

30 TV LCD-TFT

Operation

Lock Menu

Parental Control can be used to block specific channels, ratings and other viewing sources.

The Parental Control Function is used to block program viewing based on the ratings sent by the broadcasting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the type of the program and the categories. It is also possible to block all program viewing for a time period. To use this function, the following must be done :

1. Set ratings and categories to be blocked.

2. Specify a password

3. Enable the lock

Parental Control rating and categories

Rating guidelines are provided by broadcasting stations. Most television programs and television movies can be blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or direct-to-video movies use the Movie Rating System (MPAA) only.

Ratings for Movies previously shown in theaters:

Movie Ratings : NR (Permits all programs)

G (General audience) PG (Parental guidance suggested) PG-13 (Parents strongly cautioned) R (Restricted) NC-17 (No one 17 and under admitted) X (Adult only) If you set PG-13 : G and PG movies will be available , PG-13, R, NC-17 and X will be blocked.

Ratings for Television programs including made-for-TV movies :

TV-Y (All children)

TV-Y7 (Children 7 years older) TV-G (General audience) TV-PG (Parental guidance suggested) TV-14 (Parents strongly cautioned) TV-MA (Mature audience only)

TV Rating Children: ALL (Age) (applies to TV-Y, TV-Y7) FV (Fantasy Violence) (applies to TV-Y7)

TV Rating General: ALL (Age) (applies to TV-G, TV-PG, TV-14, TV-MA) D (Dialogue - sexual dialogue) (applies to TV-PG, TV-14) L (Language - adult language) (applies to TV-PG, TV-14, TV-MA) S (Sex - sexual situations) (applies to TV-PG, TV-14, TV-MA) V (Violence) (applies to TV-PG, TV-14, TV-MA)

Owner s Manual 31

Lock setup

- Set up blocking schemes to block specific channels, ratings, and external viewing sources.

- A password is required to gain access to this menu.

1. Press the MENU button and then use / button to select the LOCK menu.

Then, press the button.

The TV is set up with the initial password 0-0-0-0 and

security default password is 9-4-4-3.

2. Use the / button to choose from the right Lock Menu options.

Once the option is selected, change the settings to your preference.

Password: Change the password by inputting a new password twice.

Parental Lock:

Parental

1. P ress / button to select Lock item.

2. Press the button to select On or Off.

3. Press the OK button to confirm.

Video

Audio

Time

B C

Channel

Function

Password

Parental Lock On

MPAA Rating

Parental Guide

CA Eng Rating

CA Fren Rating

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Operation

Input Password:

Confirm Password:

Note:

if the Parental Lock is setting as Off, the change of the MPAA Rating, Parental Guide ,CA Eng Rating and CA Fren Rating will be no useful.

Movie Rating (MPAA): Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind that the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.

1 Press / button to select MPAA Rating item. 2 Press the button and then use / button to select the rating. 3 Press the ok button to set block or unblock. 4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

Video

Audio

Time

B C

Channel

Function

Password

Parental Lock On

MPAA Rating

Parental Guide

CA Eng Rating

CA Fren Rating

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

NR G PG PG-13 R NC17 X

32 TV LCD-TFT

Lock setup

Parental Guide

: Blocks any channels that you do not want to watch or

Parental Guide

that you do not want your children to watch.

Note : The will automatically block certain categories that are

more restrictive . For example, if you block TV-Y category, then TV-Y7 will automatically be blocked. Similarly, if you block the TV-G category, then all the categories in the young adult group will be blocked (TV-Y, TV-Y7, TV-G, TV-PG, TV-14, and TV-MA). The sub-ratings (D, L, S, V) work together similarly.

How to set the FV, D, L, S and V sub-ratings.

First, the / button select one of these Ratings: TV-Y, TV-Y7, TV-G, TV-PG,TV-14, or TV-MA , and press the / button. A symbol will be displayed for each sub-rating. While is selected, press the OK button to go to a sub rating. To select a different Rating, press the / buttons and then repeat the process. Note: The V-chip will automatically block certain categories that are More restrictive .For example, if you block sub-rating in TV-PG, then the sub-ratings in TV-14 and TV-MA will automatically be blocked.

Parental control

Video

Audio

Time

B C

Channel

Function

Password

Parental Lock On

MPAA Rating

Parental Guide

CA Eng Rating

CA Fren Rating

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Operation

ALL FV D S L V TV-Y V TV-Y7 V V TV-G V TV-PG TV-14 TV-MA

CA Eng Rating

Canadian English Language Rating

1 Press / button to select CA Eng Rating item.

2 Press the button and then use / button to select the rating. 3 Press the ok button to confirm. 4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

C Children C8+ Children eight years and older G General Programming, suitable for all audiences PG Parental Guidance 14+ Viewers 14 years and older 18+ Adult Programming

CA Fren Rating

Canadian French Language Rating

1 Press / button to select CA Fren Rating item. 2 Press the button and then use / button to select the rating. 3 Press the ok button to confirm. 4 When you are satisfied with your choice, press MENU button to return to

the previous menu or press the EXIT button to return to TV viewing.

G General 8 ans+ 8+ General - Not recommended for young children 13 ans+ Programming may not be suitable for children under the age of 13 16 ans+ Programming is not suitable for children under the age of 16 18 ans+ Programming restricted to adults

Video

Audio

Time

B C

Channel

Function

Password

Parental Lock On

MPAA Rating

Parental Guide

CA Eng Rating

CA Fren Rating

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

Video

Audio

Time

B C

Channel

Function

Password

Parental Lock On

MPAA Rating

Parental Guide

CA Eng Rating

CA Fren Rating

Lock

: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu, EXIT: Exit main menu

C C8+ G PG 14+ 18+

Block All

8 ans+

ans

13 +

ans

16 +

ans

18 +

Block All

Owner s Manual 33

Brief Info.

- Brief Info shows the present screen information.

- Press the INFO button to show the Brief Info on the screen.

- Press the INFO button or EXIT button to exit.

Function:

Show the present screen information. Press the INFO button or EXIT button to exit.

A: Program title

Program rating

B: categories C: Video resolution D: Program name E: Additional information. F: Program signal intensity G: Present time, Day of week, Month

Operation

Quick program view

This function enables quick swap to the last watched program.

1 Suppose the channel number you used just now is 8 and the channel number you are

using is 18 (as shown in the figure).

If you want to return to the last watched program channel 8, you can simply press the

Q.View button.

If you want to return to channel 18, press the button again. Use this function, you can

easily change between the channel you are using and the channel you used last time.

34 TV LCD-TFT

Setting Up Your Remote Control

After it has been set up properly, your remote control can operate in six different modes: TV, VCR, CABLE, DVD, SETBOX or AUDIO Pressing the corresponding button on the remote control

allows you to switch between these modes, and control whichever piece of equipment you choose.

Note

The remote control might not be compatible with all DVD Players, VCRs and Cable boxes.

Setup the desired device code

1 Find one code number from code list according to device`s brand and model.

P41-P43

(See of the remode codes)

2 Press SELECT button continuously to select desired device. 3 Press and hold OK button, then press SELECT button about 5 seconds, till LED is on.

CH.LIST

PIP SWAP

FAV.LIST

AUDIO LIST

AUDIO SWAP

SELECT

POSITION

Release OK and SELECT buttons. LED flashes with the speed of 2 times one second. It indicates the remote controller to enter Setup Mode.

4 Using the number buttons on the remote controller, enter three digits of code number

in order. The LED will flash once for each of press.

5 If the code number is correct, LED will keep on for 3 seconds then flash with the speed of twice

per second. You may press OK or PLAY to test if it can control your device. If no, turn to procedure step 4 to try another code number. If ok, you may press OK to exit Setup Mode, the code number

S.MOD E

P.MODE

ENU

FREEZ E

will be stored. LED is off. If the code number is incorrect, LED will flash with the speed of 4 times per second for 3 seconds, then flash with the speed of 2 times per seconds. You may turn to step 4 to try another code number.

6 During Setup mode, press the other keys except digit keys(0-9) or no any key is pressed,

it will exit Setup Mode or with LED off.

Operation

Search Mode (Manual Search)

XIT

1 Turn on the desired device. If the device is VCR or DVD, etc, you should insert tape or disc into

the device.

2 Press SELECT button continuously to select desired device.

VOL +

VOL-

CH+

CH-

3 Press and hold OK, then press SELECT about 3 seconds till LED is on (aim it at the remote

control sensor on the device). Release the two buttons. LED flashes with the speed of twice per second, which indicates the remote controller to enter Setup Mode.

4 Press and release CH+/- button, it will send POWER IR signal of next or previous code number.

LED flashes.

5 During searching, if the device switch off, it indicates the code is searched successfully, Press

OK button to confirm.

Q.VIEW

6 During manual searching mode, p or no any key is pressed within

30 seconds , it will exit Setup Mode.

Search Mode(Auto Search)

Turn on the device. If the device is VCR or DVD, etc, you should insert tape or disc into the device.

Press SELECT button continuously to select desired device.

Press and hold OK button, then press SELECT button about 3 seconds till LED is on

()

aim it at the remote control sensor on the device .

Press MUTE button to enter Auto Search Mode.

5 During searching, if the device switch off, it indicates the code is searched successfully, Press

OK button to confirm.

During Auto Search Mode, Press any key except OK button, it will exit Auto Search Mode.

LED is off.

ress any key except OK button

Owner s Manual 35

Setting Up Your Remote Control

Code Display Mode

1 Press and release SELECT button to desired device. 2 Press and hold OK button, then press SELECT button about 3 seconds till

LED is on. Release 2 keys. LED flashes with the speed of twice per second.

3 Enter [9][8][0] in turn to enter Code Display Mode . LED is off. 4 Press and release [1] once, LED will flash. The times LED flashes is the first digit

of code number.(no flash = 0)

5 Press and release [2] once, LED will flash. The times LED flashes is the second

digit of code number. (no flash = 0)

CH.LIST

PIP SWAP

FAV.LIST

AUDIO LIST

AUDIO SWAP

SELECT

POSITION

6 Press and release [3] once, LED will flash. The times LED flashes is the third digit

of code number. (no flash = 0)

7 Code Display process is end and exit the mode automatically.

S.MOD E

P.MODE

FREEZ E

8 Under Code Display Mode, the remote controller will be no reaction to other buttons

pressed, and will automatically exit the mode if no any key is pressed within 10 seconds.

Operation

VOL +

VOL-

CH+

CH-

Q.VIEW

36 TFT-LCD TV

Remote Control Codes

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Haier

Abex

Admiral

Adventura

Aiko

Akai

Alaron

A-Mark

Ambassador

America Action

Ampro

Anam

Anam National

AOC

Archer

Audinac

Audiovox

Baysonic

Belcor

Bell & Howell

Bradford

Brockwood

Broksonic

Candle

Carnivale

Carver

CCE

Celebrity

Chang Hong

Cineral

Citizen

Concerto

Contec

Craig

Croslex

Crosley

Crown

Curtis Mathes Curtis Mathes

Curtis Mathis

CXC

Daewoo

Daytron

Denon

Dumont

Dwin

Electroband

Electrohome

Emerson Emerson

Envision

Fisher

Fujitsu

Funai

Futuretech

General Electric

Gibralter

Goldstar

Goldstar/LG

Gradiente

Grunpy

Hallmark

Harley Davidson

Harman/Kardon

Harvard

Hitachi

Infinity

Inteq

Janeil

JBL

JC Penny

JCB

JVC

Kata

KEC

Kenwood

9 001 002 003 004 005 006 007 084 085 1 145 5 009 021 016 159 198 1 148 1 158 2 010 144 1 175 1 135 1 173 1 176 1 216 2 176 155 1 152 4 019 144 140 135 1 135 1 041 5 197 176 203 158 135 1 176 1 140 5 166 137 021 016 045 1 176 1 140 6 010 019 079 182 198 135 4 144 153 148 178 1 144 1 151 2 180 190 1 133 7 110 111 112 118 124 125 129 2 197 158 8 154 144 153 158 147 187 148 178 1 153 2 176 168 5 029 041 027 028 176 1 018 1 151 3 041 176 147 12 149 215 219 223 151 166 197 159 154 144 153 161 4 137 171 199 147 3 010 026 041 1 176

12 042 043 010 048 036 197 140 203 204 158 147 157 2 020 140 1 161 2 138 140 2 214 217 1 133 2 191 194 12 029 020 027 028 010 022 049 041 166 182 198 176 11 174 175 140 203 204 173 188 147 187 146 177 1 144 2 032 166 2 175 209 3 176 175 172 1 176 12 149 215 219 223 197 159 174 141 152 188 143 186 5 009 025 010 014 052 3 138 144 140 7 144 174 153 140 145 134 194 8 010 020 019 037 053 057 058 056 3 150 153 193 2 176 175 1 174 1 175 1 151 2 176 155 12 038 020 010 039 153 161 137 165 145 146 186 194 1 151 1 138 1 148 1 151 4 010 009 037 014 1 133 4 035 150 177 169 1 131 1 176 2 144 140

Operation

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Kloss

Konka

Konka KTV

Logik

80 81

Luxman

LXI

LXI(Sears)

Magnavox

Majestic

Marantz

Matsushita

Megatron

Memorex

MGA

Midland

Minutz

Mitsubishi Mitsubishi

Motorola

MTC

Multitech

NAD

NEC

100

Nikko

101

Noblex

102

Noshi

103

NTC

104

Ntnci

105

Onwa

106

Optmus

107

Optonica

108

Orion

109

Panasonic

110

Penney Penney

111

Peony

112

Philco

113

Philips

114

Pilot

115

Pioneer

116

Portland

117

Princeton

118

Proscan

119

Proton

120

Pulsar

121

Quasar Radio Shack

122

Radio Shack

123

RCA

124

RCA RCA/Proscan Realistic

125

Runco

126

Sampo

127

Samsung

128

Samsung Samsux

129

Sansei

130

Sansui

131

Sanyo

132

Scimitsu

133

Scotch

134

Scott

135

Sears

136

Semivox

137

Semp

138

Sharp

139

Shogun

140

Signature

141

Signature 2000

142

Simpson

143

Skyworth

144

Sony

145

Soundesign

146

Spectricon

147

2 148 142 12 088 096 100 101 102 103 104 116 117 122 123 127 7 128 130 212 205 206 207 211 9 040 020 010 041 176 144 147 187 180 1 153 1 137 1 153 7 149 215 151 166 167 174 163 7 009 010 018 032 026 019 059 12 018 019 020 010 050 054 151 221 144 175 179 178 2 192 142 1 137 3 031 151 144 1 184 3 174 161 135 8 166 184 198 164 174 175 153 137 4 164 144 174 140 5 149 215 138 147 145 1 141 4 159 164 174 140 4 031 010 019 073 2 159 152 5 154 144 153 140 157 2 176 180 3 167 174 171 6 010 019 144 153 140 201 3 144 174 158 1 196 1 139 1 158 1 138 1 176 3 166 184 171 2 159 170 3 182 198 175 10 025 023 014 056 074 081 083 184 152 181 12 149 215 223 167 154 144 174 141 153 140 139 145 3 147 135 143 1 097 11 018 020 010 075 042 038 151 198 144 161 140 5 018 063 050 024 151 3 144 140 147 6 044 025 026 171 208 146 5 010 015 140 158 147 1 213 2 149 215 3 174 199 135 2 138 140 6 025 014 055 184 152 170 12 009 019 031 030 144 174 153 140 170 147 145 194 4 149 215 166 176 12 149 215 218 219 220 223 224 156 159 140 208 139 2 146 185 11 009 010 011 012 013 014 015 051 052 053 060 9 166 176 144 174 153 1 40 170 147 145 4 138 144 202 201 3 144 147 145 12 033 019 020 010 062 154 144 174 153 140 145 190 2 195 200 1 147 1 197 1 198 5 032 030 061 166 162 1 140 1 174 7 041 019 182 176 174 175 140 11 149 215 151 166 167 174 175 153 172 162 163 1 176 1 167 10 021 020 022 077 159 210 170 147 192 168 1 140 1 137 2 021 016 2 179 178 11 091 092 099 105 106 113 114 115 119 120 126 4 008 133 160 136 4 176 174 175 178 1 135

Owner s Manual 37

Remote Control Codes

Operation

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Squareview

148

SSS

149

Starlite

150

Supre-Macy

151

Supreme

152

Sylvania

153

Symphonic

154

Tandy

155

Tatung

156

TCL

157

TCL Technics

158

Technol Ace

159

Techwood

160

Teknika

161

Telefunken

162

TMK

163

Toshiba

164

Totevision

165

Trical

166

Universal

167

Vector Research

168

Victor

169

Videch

170

Vidikron

171

Vidtech

172

Viking

173

Wards

174

White Westinghouse

175

Words

176

Yamaha

177

Zenith

178

Zonda

179

Others

180

Others

1 172 2 176 140 1 176 1 148 1 133 7 018 019 010 080 151 144 191 5 030 046 047 041 172 1 159 2 152 135 12 086 087 089 090 093 094 095 098 107 108 109 121 1 132 1 184 1 175 2 153 135 12 151 176 164 154 175 153 140 137 158 147 178 189 1 153 3 174 153 173 10 067 026 021 059 066 082 166 167 154 222 1 147 1 168 1 143 1 144 1 150 3 038 010 019 2 151 183 2 174 140 2 148 189 4 020 010 022 019 3 198 203 204 11 151 144 174 141 175 153 140 137 170 143 160 2 144 140 7 016 017 138 198 204 137 158 1 135 12 034 064 065 068 069 070 071 072 076 078 169 170 1 171

DVD

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Aiwa

Akai

Apex

Daewoo

Dansai

Denon

Elta

Emerson

Fisher

Go-Video

Harman/Kardon

Hitachi

Integra

JVC

KEF

Kenwood

KLH

Konka

Lasonic

Magnavox

Marantz

Mitsubishi

Mustek

NAD

Nakamichi

Onkyo

Optimus

Oritron

Panasonic

Philips

Pioneer

Profilo

PS2

Radioshack

RCA

Sampo

Samsung

SEG

Sharp

Sherwood

Shinco

Skyworth

Sony

Sony Sylvania

Teac

Theta Digital

Thomson

Toshiba

X Box

Yamaha

Yamakawa

Zenith

Others

2 032 016 2 089 126 2 127 129 4 046 121 124 134 1 005 4 023 034 094 108 2 117 123 1 090 1 104 2 114 133 1 098 1 035 4 025 096 106 120 1 109 4 024 054 97 131 1 001 2 094 113 1 027 4 100 101 412 102 1 125 2 092 099 2 092 099 1 095 1 115 1 116 1 135 2 033 109 2 096 120 1 103 12 019 023 044 045 051 052 053 059 062 087 087 094 5 029 086 092 099 110 6 021 036 038 050 096 120 2 004 006 2 011 014 4 88 122 132 136 9 022 068 073 088 114 122 132 133 136 1 105 4 031 058 098 128 1 112 3 028 065 091 1 111 3 039 114 133 2 007 015 12 018 040 041 042 047 048 049 057 083 084 085 077 7 078 079 067 081 008 009 093 3 037 061 066 1 120 2 096 120 3 030 012 017 7 020 055 056 063 92 436 130 3 002 003 010 3 023 094 107 1 119 4 026 064 090 118 11 043 060 069 070 071 072 074 075 076 080 082

38 TV LCD-TFT

Remote Control Codes

Operation

VCR

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

030

Admiral

Aiwa

Akai

Audio Dynamic

Bell & Howell

Broksonic

Canon

Citizen

Craig

Curtis Mathis

Daewoo

DBX

Dimensia

Emerson

Fisher

Funai

General Electric

GO VIDEO

Goldstar/LG

Hitachi

Instant Replay

JC Penny

JVC

Kenwood

LXI(Sears)

Magnavox

Marantz

Marta

Memorex

Minolta

Mitsubishi/MGA

Multitech

NEC

Olympic

Optimus

Orion

Panasonic

Pentax

Philco

Philips

Pioneer

Quasar

RCA/PROSCAN

Realistic

Samsung

Sansui

Sanyo

Scott

Sharp

Shintom

Signature 2000

Singer

Sony

Sylvania

Symphonic

Tashiro

Tatung

Teac

Technics

Toshiba

Wards

Yamaha

Zenith

Others

041 050 035

052 053 054

017 040

033 046

020 022 017

012 011

035

018 035

007 041 012

044 015 012 064

017 039 040

007

044 022 023 019 020 021 041 058

033 037 038 036

041

032 007 012 062

051 042 043

035

011 007 008

015

012 011

012 008 007 033 017 039 040

017 047 048 049 039 040

017 039 035 040

041 035 008 036 037 033 038 052

013 011 012 010 063

017 039 040

035

012 038

008 007

026 027 028 029 056 057 065 059

028 041 024

017 039 040

012 011

027

055

009 010 011 012 060

008 007

011 012 044 020

035 013 011 012 063

011

011 012 009 010 006

007 008 011 012 013 014 015 016

012 033 031 038 027 041

025 016 024

017

033 038 046 044 035

015 016 024 038 026 027 028 029

030 031

018

041 030

018

001

013 011 012 041

041

035

017 039 040

017 039 041 040

012 011

015 014 052

030 031 038 034 035

033 017 039 040

034

002 003 004 005

SETBOX

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Alphastar

Chaparral

Echostar

Expressvu

General Instrument

Hitachi

Homecable

HTS

Hughes Net.Sys.

IQ Prism

Jerrold

JVC

Magnavox

Memorex

Next Level

Panasonic

Philips

Primestar

Radioshack

RCA

RCA/Proscan

Realistic

Samsung

Scientific Atlanta

Sony

Starchoice

STS

Toshiba

Uniden

Zenith

028

015 011

029 035 017

029

018 021 034

031 005

016

029

027 004

014

018 021

029

025 024 026

025

034

023 003

025 024 036 026

018 021

034

020 013 032 019

002 007

010

037

008 009

022 001

034

014

027 030 012 006

025 024 010 016

033

CABLE

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Hamlin/Regal

Hitachi

Hughes

Jerrold/G.I

Jerrold/G.I. Motorola

OAK

Panasonic

Philips

Pioneer

RCA/Proscan

Scientific Atlanta

Sony

Tocom

Toshiba

Zenith

022 023 024 025 026

005

004

031 001 002 003 004 005 006 007 008 018 022 032

015

027 028 029

019 020 021 003

016

014 015

002 007

009 010 011 014

013 001

031 016 017

006

012 013

Owner s Manual 39

Remote Control Codes

AUDIO TYPES

RECEIVER

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Aiwa

Denon

Fisher

JVC

Kenwood

Magnavox

Marantz

Panasonic

Philips

Pioneer

Sanyo

Sharp

Sherwood

Sony

Technics

Yamaha

TAPE

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Denon

Fisher

GoldStar/LG

Pioneer

Sanyo

Sony

Technics

022 023

010 024 027 028

011

019 020

015 016 025

021

029

008

017

006 018

011

028

012 013

001 002

007 026

014 030

2 055 056 1 057 1 054 1 052 1 057 4 049 050 051 058 1 053

Operation

MD/DAT

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

1 2 3 4 5 6 7 8

Denon JVC Kenwood Marantz Panasonic Sansui Sony Teac

1 061 2 063 066 1 062 1 065 1 064 1 067 2 059 060 1 063

NO. B ran d Cod e 1 2 3 4 5 6 7 8 9 10 11 12

Denon

GoldStar/LG

JVC

Kenwood

Magnavox

Panasonic

Philips

Pioneer

Sanyo

Sherwood

Sony

Technics

Yamaha

2 038 039 1 037 1 048 2 044 045 1 046 1 036 1 046 2 037 047 1 040 2 041 042 3 031 032 033 1 035 1 043

40 TFT-LCD TV

Operation

Maintenance

- Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have your new TV. Be sure to turn the power off and unplug the power cord before you begin any cleaning.

Cleaning the Screen

1. Here`s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of lukewarm water and a little

fabric softener or dish washing detergent. Wring the cloth until it`s almost dry, and then use it to wipe the screen.

2. Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.

Cleaning the Cabinet

To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth. Please be sure not to use a wet cloth.

Extended Absence

If you expect to leave your TV dormant for a long time (such as a vacation), it`s a good idea to unplug the power cord to protect against possible damage from lightning or power surges.

Owner s Manual 41

1366X768(Dot)

120V~ , 60Hz

NTSC ATSC Clear QAM

Specifications

External Antenna Impedance

HL26S

HL32S

HL37S

HL42S

HL26B

HL32B

Dimensen(WX X ) Unit::inches/mmDH (Including stand)

31.3X11.2 X20.3inches 794X285X515 mm

37.0X11.2X23.4 inches 940X285X595 mm

43.1X12.8X27.0 inches 1096X325X687mm

44.5X13.3X29.5inches 1131X337X750mm

26.7X9.7X20.7inches 679X246X525 mm

31.9X9.7X24.4 inches 811X246X621mm

75 ohm

37.5/17.0

52.9/24.0

62.8/28.5

72.8/33.0

27.6/12.5

35.3/16.0

The specifications shown above may be changed without prior notice for quality improvement.

42 TV LCD-TFT

HL37B

HL40B

HL42B

37.2X12.2X28.0 inches 946X310X710 mm

39.9X12.2X29.1inches 1014X310X738mm

41.9X12.2X31.5inches 1065X310X800mm

50.7/23.0

55.1/25.0

57.3/26.0

Troubleshooting

For the sake of time and cost, it is strongly recommended that you check out the problem by yourself according to the instructions listed hereunder before contacting the after-sales service for technical assistance.

Verify if the television is properly plugged.

No picture, no sound

Blank screen

No sound

Verify if the television is properly supplied power. Verify if electricity is available.

Verify if correct signals are input. Press INPUT button to change signal input to TV input. Restart the television of power supply is interrupted.

Press Mute button and verify if Mute mode is set. Switch to other channel and verify if the same problem happens. Press VOL+ button to see if the problem can be solved.

Poor sound

No picture in some channel

No color for some channel program (black and white)

Spots with some or all pictures

Horizontal/vertical bars or picture shaking

Television out of control

Note: Do not leave the television with static picture in an extended period as it may result in residual image on your

television screen.

Verify if sound system is correct. Refer to some chapter for adjust.

Verify if correct channel is selected. Adjust the antenna. Make adjustments by Fine Tune and Manual Scan.

Verify if the same problem exists in other channels. Check out of picture and sound systems. Refer to relative instructions in the Manual for color adjust.

Verify if the antenna is correctly connected. Verify if the antenna is in good condition. Make fine adjustment of channel.

Check for local interference such as an electrical appliance or power tool.

Disconnect the television from power supply and, 10 seconds later, connect the television to the power supply. If the problem still exists, contact authorized after-sales service for technical assistance.

Note: Production of the plasma screen requires high and precision technologies. However, there might be some dark or bright (red, blue or green) spots, or

some anomalistic stripes or spots. This is not defect. If the TV set is used in an area 2,400 meters above the sea level where the air pressure is below 750hpa,

the picture on the plasma screen may be affected and a muffled sound might be produced. These phenomena might happen in the area 1,500 meters above

the sea level. This is resulted from difference between air pressures inside and outside the display. This is not a defect covered by the limited warranty.

44 TV LCD-TFT

Warranty

This Haier brand product, when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective product with a new or re-manufactured equivalent at no change to the purchaser, for parts or labor for the periods set forth below:

This warranty does not apply to the appearance of the product or the exterior of the product, which has been damaged or defaced, altered or modified in design or construction. It does not apply to the additional excluded items set forth below:

The warranty commences on the date the item was purchased and the original purchase receipt must be presented to the authorized service center before warranty repairs are rendered.

Responsibility of Haier to the purchaser with respect to the product, and shall

constitute full satisfaction of all claims, whether based on contract, negligence, strict duality or otherwise. In no event shall Haier be liable, or in any way responsible for any damages or defects in the product which were caused by repairs or attempted repairs performed by anyone other than an authorized service center or dealer; nor shall Haier be liable, or in any way responsible for incidental or consequential economic or property damage. Some states do not allow the exclusion of incidental or consequential damages, so that above exclusion may not apply to you.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(s) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Haier.

The warranties described herein shall be the sole and exclusive warranties granted by Haier and shall be the sole and exclusive remedy available to the purchaser. Correction of defects in the manner and for the period of time described herein, shall constitute complete fulfillment of all abilities and

Warranty period for this product:

and labor

Additional items excluded from warranty coverage: non-rechargeable batteries. Where to obtain service: For the location of the nearest Haier authorized service center or to obtain product literature, accessories, supplies or customer assistance, please call 1-877-337-3639. What to do to obtain service: ship or carry in your product to an authorized service dealer or center .Be sure to have proof of purchase. If you ship the product, be sure it is packaged carefully. Haier America New York, NY 10018

one year parts

Owner s Manual 47

Haier HL40B, HL42S User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
