Haier DDW6FSS User Manual
Domestic Dishwasher
DDW6FSS DDW6FWH
GB
Code: 0120504816
Safety Is Very Important
Close-up View (Interior)
Carefully read the instructions contained in this manual, as they
provide important information which is essential to safe and
proper installation, use and maintenance of this appliance.
This appliance complies with the following EEC
directives:
-73/23/EEC of 19/02/73 (Low Voltage) and subsequent
modifications;
- 89/336/EEC of 03/05/89 (Electromagnetic
Compatibility) and subsequent modifications.
- Carefully dispose of the packing material.
- After removing the packing, check to make sure that the appli ance is not damaged. If in doubt, contact a qualified professional.
- The dishwasher must only be used by adults for the washing of
household dishes and cooking utensils.
- The appliance is not intended for use by young children or inform
persons without supervision.
- Young children should be supervised to ensure that they do not
play with the appliance.
- Keep detergents out of the reach of children.
- This appliance cannot be installed outdoors, not even if the
area in which it is installed is covered by a roof; It is also very
dangerous to leave it exposed to the rain and elements.
- Do not lean or sit on the door when it is open as this could
overturn the dishwasher.
- Do not touch the heating element during or after a wash cycle.
- If the appliance malfunctions turn off water supply to the appli ance and disconnect the plug from the wall socket. Refer to
the section entitled, "Troubleshooting". If you cannot solve the
problem, contact a authorised service centre.
- Only specialised personnel are authorised to make repairs.
- Appliances which are no longer being used must be made
inoperable by cutting the power supply cord and removing the
door lock.
- If the supply cord is damaged, it must be replaced by a special
cord or assembly available from the manufacturer or its service
agent.
- This appliance is intended for built-in and must be installed ac
cording to the installation instruction and in particular, it is re quired
to have the plug accessible after installation.
- Rules to follow when using this appliance:
* Never touch the dishwasher when barefoot or with wet hands;
* We discourage the use of extension cords and multiple sockets;
* During installation, the power supply cord must not be exces sively or dangerously bent or flattened;
* If the appliance is not operating properly, maintenance must
be performed, disconnect the appliance from the power supply.
Warning: Dishwasher detergents can be extremely dangerous
if swallowed. Avoid contact with skin and eyes and keep
children away from the dishwasher when the door is open.
Check that the detergent receptacle is empty after completion
of the wash cycle.
To maintain the EFFICIENCY and SAFETY of this appliance,we
recommend:
- call only service centres authorised by the manufacturer.
- always use original Spare Parts
A
B
C
D
Upper Rack
Rack Height Adjustor
Top Spray Arm
Lower Rack
Bottom Spray Arm
E
Washing Filter
F
Detergent and Rinse Aid Dispenser
G
Third Sprayer
H
Close-up View (Control Panel)
.1.
POWER Light
A
POWER Button
B
Water heating Indicator Light
C
Low Rinse Aid Indicator Light
D
Knob For Selecting Cycle
E
Handle For Opening Door
F
G
"Eco" Button
H
"Half Load" Button
"Fast" Button
I
Width
Depth
Height
Capacity
Mains water pressure
Power voltage
Total absorber power
GB GB
Technical Characteristics
60 cm
60 cm
85 cm
12 standard place settings
0.03-0.6MPa
240V~ 50Hz
2200W
.2.
