PNEG-1742
VTDL-48 - 8 x 9 Door Assembly
Instruction Manual
PNEG-1742
Date: 06-02-10
2 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
Table of Contents
Contents
Chapter 1 Safety .....................................................................................................................................................4
Safety Guidelines .................................................................................................................................. 4
General Safety Statement ..................................................................................................................... 5
Safety Sign-Off Sheet ........................................................................................................................... 8
Chapter 2 Safety Decals ........................................................................................................................................9
Roof Damage Warning and Disclaimer ................................................................................................. 9
Chapter 3 Suggested Tools ................................................................................................................................12
Chapter 4 Assembly Instructions ......................... .................................................... ..........................................13
Chapter 5 Assembly Drawings ...........................................................................................................................16
Sidewall and Stiffener Layout .................... ... .... ... ... ... .... ... ... ... .... ... ... ... ... .... ......................................... 16
Door Assembly Exploded View ........................................................................................................... 17
Column Installation .............................................................................................................................. 18
Header Beam Installation ................................. ... ... ... .... ... ... .......................................... ... ... ................ 19
Header Beam Connection Details ....................................................................................................... 20
Center Column Installation .................................................................................................................. 21
Door Panel Assembly .......................................................................................................................... 22
Stiffener/Sidewall Attachment ............................................................................................................. 23
Weld Details . ... ... .... ... ... ... .... ... ... .......................................... ... ............................................................. 24
Outer Cover Assembly ........................................................................................................................ 25
Chapter 6 Warranty ..............................................................................................................................................27
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 3
1. Safety
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
CAUTION used without the safety alert symbol indicates a
potentially hazardous situation which, if not avoided, may
result in property damage.
NOTE indicates information about the equipment that you
should pay special attention.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
Safety Guidelines
This manual contains information that is important for you, the owner/operator, to know and understand.
This information relates to protecting personal safety and preventing equipment problems. It is the
responsibility of the owner/operator to inform anyone operating or working in the area of this equipment
of these safety guidelines. To help you recognize this information, we use the symbols that are defined
below. Please read the manual and pay attention to these sections. Failure to read this manual and its
safety instructions is a misuse of the equipment and may lead to serious injury or death.
4 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
1. Safety
This product has sharp edges, which may cause serious injury. To avoid injury, handle
sharp edges with caution and always use proper protective clothing and equipment.
General Safety Statement
Our foremost concern is your safety and the safety of others associated with grain handling equipment.
This manual is to help you understand safe operating procedures and some problems which may be
encountered by the operator and other personnel.
As owner and/or operator, you are responsible to know what requirements, hazards and precautio ns exist
and inform all personnel associated with the equipment or in the area. Safety precautions may be required
from the personnel. Avoid any alterations to the equipment, which may produce a very dangerous
situation, where SERIOUS INJURY or DEATH may occur.
You should consider the location of the bin site relative to power line locations or electrical transmission
equipment. Contact your local power company to review your installation plan or for information
concerning required equipment clearance. Clearance of portable equipment that may be taken to the bin
site should also be reviewed and considered. Any electrical control equipment in contact with the bin
should be properly grounded and installed in accordance with National Electric Code provisions and other
local or national codes.
This product is intended for the use of grain storage only. Any other use is a misuse of the product.
Sidewall bundles or sheets must be stored in a safe manner. The safest method of storing sidewall
bundles is laying horizontally with the arch of the sheet upward, like a dome. Sidewall sheets stored on
edge must be secured so that they cannot fall over and cause injury. Use care when handling and moving
sidewall bundles.
Personnel operating or working around equipment should read this manual. This manual must be
delivered with equipment to its owner. Failure to read this manual and its safety instructions is a
misuse of the equipment.
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 5
1. Safety
Follow Safety Instructions
Carefully read all safety messages in this manual and
safety signs on your machine. Keep signs in good
condition. Replace missing or damaged safety signs. Be
sure new equipment components and repair parts include
the current safety signs. Replacement safety signs are
available from the manufacturer.
Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
Keep your machinery in proper working condition.
Unauthorized modifications to the machine may impair
the function and/or safety and affect machine life.
If you do not understand any part of this manual or need
assistance, contact your dealer.
Read and Understand Manual
Practice Safe Maintenance
Understand service procedures before doing work. Keep area
clean and dry.
Never lubricate, service, or adjust machine while it is in operation.
Keep hands, feet and clothing away from rotating parts.
Keep all parts in good condition and properly installed. Fix
damage immediately . Replace worn or broken p arts. Remove any
built up grease oil and debris.
Maintain Equipment
and Work Area
Prepare for Emergencies
Be prepared if fire starts.
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctors, ambulance service,
hospital and fire department near your telephone.
Keep Emergency Equipment
Quickly Accessible
6 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
1. Safety
Wear Protective Clothing
Wear close fitting clothing and safety equipment appropriate
to the job.
Remove all jewelry.
Long hair should be tied up and back.
Safety glasses should be worn at all times to protect eyes
from debris.
Wear gloves to protect your hands from sharp edges on
plastic or steel parts.
Wear steel toe boots to help protect your feet from falling
debris. Tuck in any loose or dangling shoe strings.
A respirator may be needed to prevent breathing potentially
toxic fumes and dust.
Wear hard hat to help protect your head.
Wear appropriate fall protection equipment when working at
elevations greater than six feet (6').
Eye Protection
Gloves
Steel Toe Boots
Respirator
Hard Hat
Fall Protection
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 7
1. Safety
Safety Sign-Off Sheet
As a requirement of O.S.H.A., it is necessary for the employer to train the employee in the safe operating
and safety procedures for this equipment. This sign-off sheet is provided for your convenience and
personal record keeping. All unqualified persons are to stay out of the work area at all times. It is strongly
recommended that another qualified person who knows the shut down procedure be in the area in the
event of an emergency.
Date Employee Name Supervisor Name
8 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
2. Safety Decals
CAUTION!
Excessive vacuum (or pressure) may
damage roof. Use positive aeration
system. Make sure all roof vents are
open and unobstructed. Start roof
fans when supply fans are started.
Do not operate when conditions exist
that may cause roof vent icing.
DC-969
The manufacturer does not warrant any roof damage caused by excess ive v acuum or internal
pressure from fans or other air moving systems. Adequate ventilation and/or “makeup air”
devices should be provided for all powered air handling systems. The manufacturer does not
recommend the use of downward flow systems (suction). Severe roof damage can result from
any blockage of air passages. Running fans durin g high humidity/cold weather conditions can
cause air exhaust or intake ports to freeze.
Roof Damage Warning and Disclaimer
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 9
2. Safety Decals
Rotating flighting will
kill or dismember.
Flowing material will
trap and suffocate.
Crusted material will
collapse and suffocate.
Keep clear of all augers.
DO NOT ENTER this bin!
Failure to heed these
warnings will result in
serious injury or death.
If you must enter the bin:
1. Shut off and lock out all power.
2. Use a safety harness and safety line.
3. Station another person outside the bin.
4. Avoid the center of the bin.
5. Wear proper breathing equipment or respirator.
DC-GBC-1A
ATTENTION: The decal shown below should be present on the outside of the door cover of the 2 ring,
24" porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any of
these locations, contact the manufacturer for a free replacement decal.
GSI Decals
1004 E. Illinois St.
Assumption, IL. 62510
Phone: 1-217-226-4421
10 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
2. Safety Decals
Failure to heed these warnings
could result in serious injury, death,
structural damage or collapse of tank.
1. Use CENTER FLOOR OUTLET ONLY until NO grain
remains above this outlet.
2. Side floor outlets to be used ONLY when above
condition is satisfied.
3. Lock all side floor outlets to avoid accidental
premature use.
4. See manufacturers instructions for proper use of
factory supplied sidedraw (wall) discharge systems.
UNLOADING INSTRUCTIONS:
DC-GBC-2A
WARNIN
DON’T
DO
ATTENTION: The decal shown below should be present on the outside of the door cover of the 2 ring,
24" porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any of
these locations, contact the manufacturer for a free replacement decal.
GSI Decals
1004 E. Illinois St.
Assumption, IL. 62510
Phone: 1-217-226-4421
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 11
3. Suggested Tools
1. Forklift or a similar piece of equipment capable of lifting 1500 lbs. at heights above 10'.
2. Welder.
3. Plasma cutter, torch or a similar tool for cutting base plates.
4. Concrete drill for installing 3/4" epoxy type anchors (if anchors are used).
5. 1/2", 7/16" and 1-1/8" drill bits.
6. Sockets and wrenches including 9/16", 5/8", 15/16", 1" and 1-1/4" sizes.
7. Drift pins and/or pry bars.
12 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
4. Assembly Instructions
Installation of the Large Vehicle Traffic Door in 48' diameter, externally stiffened tanks.
Prior to door installation, the tank should be fully erected and anchored. The SCTDL 48-8 x 9 Door is to
be installed in the bottom 4 rings of the tank. Adequate provisions should be made for door installation.
A list of necessary tools and equipment is attached. Also, some field fabrication and welding will
be necessary.
1. The VTDL door is to be installed in the bottom 4 rings of the tank.
2. The door must be placed near an intermediate discharge well such that grain will clear away from the
door panels when the tank is emptied. Installation of a standard 1 ring access door or 2 ring doo r in
addition to the VTDL door is recommended.
3. Tank erection will be constructed as normal until the fifth
fifth ring will be installed as normal except that the orientation of the sidewall sheets should match
the sidewall layout shown on Page 16. At the door location, install special punched, special length
door sheets at the correct position as shown on Page 16. Use two (2) non-laminated sidewall sheets
(minimum 12 gauge) per ring without caulk to temporarily complete the ring. Use only horizontal
seam bolts to connect the filler sheets to the door sheets. Continue installing the sidewall as normal
except for installing the special door sheets and temporary sheets. These sheets are used as filler
sheets to keep the tank round until fully erected. They will be removed prior to door installation. Also,
four (4) sets of stiffeners should be omitted at the door location. (See Page 16.) Standard base
stiffener weldments will be used in these locations after the door frame is completely installed.
Anchor the tank securely before installing the door.
ring from the bottom to be installed. The
4. When the tank is properly anchored, remove the filler sheets. Be sure the sidewall is installed as
shown on Page 18.
5. Review Pages 17 and 22 to identify the door frame and door panel parts.
6. Place threshold weldments (VTDL-0547 and VTDL-0548) in the door opening between the
sidewall sheets. Install the left and right column weldments (VTDL-0537 and VTDL-0540) as
shown on Page 18. Fasten column weldments to sidewall sheets with 3/8" x 1" bolts (S-455) and
3/8" nuts (S-456).
NOTE: Bolt size may change slightly with gauge changes.
Use a flat washer on the inside of this connection. Bolt heads with a sealing washer will be used on
the outside. Do not tighten bolts at this time. Insert corrugated sealing strips onto the o uter e dge
of the sidewall sheets and the inner edge of the sidewall attachment plates. Caulk around the seal
strip as well. Align the edge of the column base plate with the edge of the threshold weldment. Also,
the door panel attachment strips of the columns and threshold must be aligned. (See Pages 18
and 20.) The columns and threshold weldments will be anchored with 3/4" epoxy type anchors or by
field welding to the tunnel girder. The column weldments must be field welded to the threshold
weldments. Do not anchor or weld until the door is fully installed.
7. Install header beam weldments (VTDL-0534) on the top of the column weldments. The header
beam weldment will slide onto the top of the columns from the inside of the tank. Fasten loosely with
3/4" x 2-1/2" grade 8 bolts (S-7640), 3/4" washers (S-866) and 3/4" nuts (S-234). See detail A
on Page 20. Be sure that the sidewall attachment plate holes of the header and column are aligned.
Attach the sidewall of the fifth ring to the header seal strip with 3/8" x 1" bolts. Use flat washers on
the inside of this connection. Do not tighten bolts until door panels are installed.
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 13
4. Assembly Instructions
8. The center column weldment (VTDL-0541) will be installed within the door frame. The bottom of the
center column weldment will rest between the column outer cover strip on the threshold weldment.
The top of the center column weldment will bolt to the header beam weldment with 3/4" x 2-1/2" bolts.
See details B and C on Page 21. Use VTDL-0403 shim plates between the center column and the
header beam and threshold weldment. Place one shim plate on the threshold weldment splice prior
to the placement of the center column. The center column should be placed inside of the tank with
the base of the column near the threshold weldment splice. Tilt the column upward into position and
bolt it to the header beam. Install the top shim plate. The door panel attachment plates of the column,
header and threshold weldments should be aligned. (See Page 21.) The center column is to be
removed when the door is opened. Do no field weld to the center column. Do not tighten bolts
until the door panels are installed.
9. Verify that the door frame is square and all door panel attachments plates are in alignment prior to
installing the door panels.
10. Assemble the door panels as shown on Page 22. Door panels must be installed in this manner to
maintain proper orientation of the hinges. Door hinge plate weldments (VTDL-0402) are to be placed
as shown on Page 22. Use 3/8" x 1-1/2" bin bolts at the door panel splices and 3/8" x 1-1/2" bolts at
hinge plate weldments. The bolt head with a sealing washer should be on the outside for all splice
connections and on the inside for all hinge weldment connections. Follow installation details on
Page 22 for door panel placement. Use 1" x 3-1/2" grade 8 bolts to attach the door panels to the door
frame. Flat washers are to be used on both sides of all 1" bolt connections. Use only enough bolts to
hold panels in place and clamp the panels to the door frame. Be sure that the panels are closed
completely and all holes are aligned. The door panels will be opened later to allow for field welding
and sealing. Caulk all along door panel splices.
11. Insert hinge pins (VTDL-0244) through hinge plates on the door panels and column weldments.
See detail D, Page 23. Place a 1/2" washer over the top of the hinge pin and secure it with a
1/8" cotter pin (S-7241). Tighten all door panel bolts and door frame connection bolts at this time.
12. Attach standard base stiffener weldments above the header beam as shown on Page 23. Use
1" x 3-1/2" bolts for attaching to the seal strip and sidewall plates. Tighten all sidewall and stiffener
bolts at this time. Shim as necessary and field weld stiffeners to the header beam. Base plates may
have to be trimmed to align with the header beam. (See Page 23.)
13. Anchor the threshold weldments to the foundation or either field weld to the tunnel beam. Then, field
weld the columns to the threshold weldments. Open the door panels and field weld the door panel
attachment plates of the header and threshold to the left and right column weldments. Be sure that
the door panels open and close smoothly. Field weld the threshold weldment splice and access cover
plates on the column weldments. Welding should be done on both the inside and outside of t he door
frame. Refer to Page 24 for complete field welding details.
14. Clean, inspect and paint all welds. Place foam seal strip all along the outer edge of the door panel
assembly to seal door panels. Close the door panels and install all door panel bolts with a washer
on each side. Tighten the door panel bolts. Inspect all of the welds and door assembly bolts at
this time. Place the decals DC-GBC-1A and DC-GBC-1S on the inside of the door panels. Decals
DC-GBC-2A and DC-GBC-2S must be placed on the outside of the door panels. Caulk any gaps
around the center column weldment and threshold weldments.
14 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
4. Assembly Instructions
15. To open the door, unbolt the door panels from the door frame. Do not remove the hinges or unbolt
the door panels from one another. Swing the door panels open to remove the center column.
Provisions should be made to hold the door panels open while the center column is being removed
and the bin is being cleaned. Unbolt the top of the center column from the header beam and remove
the shim plate. Slide the center column section inside off the threshold weldment, tilt outward
and then remove. Please be aware that the center column is extremely heavy and proper
equipment should be used for removal. Temporary ramps should be made to avoid driving over
the door panel attachment plates of the threshold weldment. Once the bin is f ully emptied, re-insta ll
the center column section, close the door panels and bolt the panels to the door frame. It may be
necessary to re-seal around the door panels and column weldments. Inspect all decals each time the
door is opened and replace if damaged or missing.
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 15
5. Assembly Drawings
Continue tank erection as normal until fifth ring from bottom is reached. Note the location of the vertical seams and stiffener columns above the door
opening. The fifth ring must be positioned this way for door to fit properly. Assemble door sheets and stiffener columns as shown. It may be necessary
to use filler sheets at the door installation location to finish erecting the tank. These sheets must be removed when tank is set and door installation is to
begin. Do not caulk filler sheets. 12 Gauge or heavier sheets may be used as filler sheets. Omit the four (4) stiffeners directly above the door opening.
These stiffeners will be installed after the door installation is completed.
Sidewall and Stiffener Layout
Figure 5A
16 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
Door Assembly Exploded View
Door panel assembly
(See Page 22.)
5. Assembly Drawings
Figure 5B
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 17
5. Assembly Drawings
Remove filler sheets and install threshold weldments. Threshold weldments will either be anchored to the concrete or field welded to a tunnel beam. Do
not anchor or field weld threshold weldments until door assembly is completed. Set right and left column weldments on threshold weldments and attach
to the sidewall with 3/8" x 1" bin bolts. (Bolts size may vary slightly with sidewall thickness.) The sidewall will be on the outside of the column weldment.
Bolt head with sealing washer will be on the outside of this connection. Use flat washer on the inside of this connection. All of the sidewall bolts may be
installed at this time but do not tighten until the door assembly has been completed. Use the provided measurements to assure that the columns are in
the correct position and that the header beam will slide in place.
Column Installation
Figure 5C
18 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
Header Beam Installation
The header beam must slide onto the columns from the inside of the tank. The seal strip atop the header will bolt to the fifth ring from the inside of
the tank. Attach the header to the columns with 3/4" x 2-1/2" grade 8 bolts, nuts and washers. Refer to Page 20 for header to column connection
details. Required field welding should be done after door is completely installed. Field weld sidewall plates and door attachment plates as shown.
Refer to Page 24 for complete weld details. (Viewed from inside of tank.)
5. Assembly Drawings
Figure 5D
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 19
5. Assembly Drawings
NOTE: Install header beam onto columns as shown on Page 19. Use 3/4" x 2-1/2" grade 8 bolts with washer on each side. Insert bolt from the
column side upward and hand tighten. Be sure that the edge of the threshold plate is aligned with the edge of the column. Field weld threshold
plates, sidewall plates and door panel plates after door is completely installed.
Header Beam Connection Details
Figure 5E
20 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
Center Column Installation
NOTE: Center column weld (VTDL-0541) will be installed from the
inside of the tank. Place shim plate (VTDL-0403) in position on the
threshold weldments. Place bottom of the column near the threshold
weldment and tilt the column upward into position. Bolt the column to
the header as shown. Install shim plate prior to tightening bolts. Bolts
may be hand tightened at this time. Do not fully tighten until door is
completely installed. Be sure that all the door panel plates are aligned.
Do not weld the center column to any part of the door frame. Center
column weldment must be removed when door is opened.
5. Assembly Drawings
Figure 5F
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 21
5. Assembly Drawings
Door Panel Assembly
Figure 5G
22 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
Stiffener/Sidewall Attachment
NOTE: Install standard base stiffeners above header beam as shown. Shim stiffeners as
necessary and tighten all sidewall and stiffener bolts around the door. Field weld base stiffeners to
header beam. It may be necessary too trim the stiffener base plate to match the outer edge of the
header beam. Install all hinge pins as shown in detail D. Remove door panel bolts and make sure
all door panels swing freely.
5. Assembly Drawings
Figure 5H
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 23
5. Assembly Drawings
All sidewall, stiffener and door assembly bolts must be
tight prior to welding of door frame. Shim thresholds
and columns as necessary and field weld as shown.
Door panels not shown for clarity.
Weld Details
Figure 5I
24 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
Outer Cover Assembly
NOTE: Attach angles to columns and header with 3/8" x 1" bin bolts. The outer cover hinge brackets will attach to the outside of the column outer cover
flanges. Attach the center post to the header and threshold weldments with 3/8" x 1" bin bolts. Attach reinforcement channels, outer cover handles and
latch brackets to the outer cover with 3/8" x 1" bin bolts. Place outer cover assembly in position and insert the hinge pin through the hinge weldment and
bracket. Secure the hinge pin with cotter pin and washer. Be sure the door cover opens and closes smoothly. Adjust hinges and latches as necessary.
Open outer cover and apply foam seal strip all along outer edge of cover. Caulk as necessary to seal outer cover.
5. Assembly Drawings
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 25
Figure 5J
5. Assembly Drawings
Outer Cover Assembly (Continued)
Figure 5K
26 PNEG-1742 VTDL-48 - 8 x 9 Door Assembly
6. Warranty
9101239_1_CR_rev7.DOC (revised July 2009)
GSI Group, LLC Limited Warranty
The GSI Group, LLC (“GSI”) warrants products which it manufactures to be free of defects in materials and workmanship
under normal usage and conditions for a period of 12 months after sale to the original end-user or if a foreign sale,
14 months from arrival at port of discharge, whichever is earlier. The end-user’s sole remedy (and GSI’s only obligation)
is to repair or replace, at GSI’s option and expense, products that in GSI’s judgment, contain a material defect in materials
or workmanship. Expenses incurred by or on behalf of the end-user without prior written authorization from the GSI
Warranty Group shall be the sole responsibility of the end-user.
Warranty Extensions:
The Limited Warranty period is extended for the following products:
Product Warranty Period
Performer Series Direct Drive Fan Motor 3 Years
AP Fans and Flooring
Cumberland
Feeding/Watering
Systems
Grain Systems Grain Bin Structural Design 5 Years
Grain Systems
Farm Fans
Zimmerman
All Fiberglass Housings Lifetime
All Fiberglass Propellers Lifetime
Feeder System Pan Assemblies 5 Years **
Feed Tubes (1-3/4" and 2.00") 10 Years *
Centerless Augers 10 Years *
Watering Nipples 10 Years *
Portable and Tower Dryers 2 Years
Portable and Tower Dryer Frames and
Internal Infrastructure †
5 Years
* Warranty prorated from list price:
0 to 3 years - no cost to end-user
3 to 5 years - end-user pays 25%
5 to 7 years - end-user pays 50%
7 to 10 years - end-user pays 75%
** Warranty prorated from list price:
0 to 3 years - no cost to end-user
3 to 5 years - end-user pays 50%
† Motors, burner components
and moving parts not included.
Portable dryer screens included.
Tower dryer screens not included.
GSI further warrants that the portable and tower dryer frame and basket, excluding all auger and auger drive components,
shall be free from defects in materials for a period of time beginning on the twelfth (12
and continuing until the sixtieth (60
th
) month from the date of purchase (extended warranty period). During the extended
th
) month from the date of purchase
warranty period, GSI will replace the frame or basket components that prove to be defective under normal conditions
of use without charge, excluding the labor, transportation, and/or shipping costs incurred in the performance of this
extended warranty.
Conditions and Limitations:
THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE LIMITED WARRANTY DESCRIPTION SET FORTH
ABOVE. SPECIFICALLY, GSI MAKES NO FURTHER WARRANTY OF ANY KIND, EXPRESS OR IMPLIED,
INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE OR USE IN CONNECTION WITH: (I) PRODUCT MANUFACTURED OR SOLD BY GSI OR (II) ANY ADVICE,
INSTRUCTION, RECOMMENDATION OR SUGGESTION PROVIDED BY AN AGENT, REPRESENTA TIVE OR
EMPLOYEE OF GSI REGARDING OR RELATED TO THE CONFIGURATION, INSTALLATION, LAYOUT, SUITABILITY
FOR A PARTICULAR PURPOSE, OR DESIGN OF SUCH PRODUCTS.
GSI shall not be liable for any direct, indirect, incidental or consequential damages, including, without limitation, loss of
anticipated profits or benefits. The sole and exclusive remedy is set forth in the Limited Warranty, which shall not exceed
the amount paid for the product purchased. This warranty is not transferable and applies only to the original end-user. GSI
shall have no obligation or responsibility for any representations or warranties made by or on behalf of any dealer, agent
or distributor.
GSI assumes no responsibility for claims resulting from construction defects or unauthorized modifications to products
which it manufactured. Modifications to products not specifically delineated in the manual accompanying the equipment at
initial sale will void the Limited Warranty.
This Limited Warranty shall not extend to products or parts which have been damaged by negligent use, misuse, alteration,
accident or which have been improperly/inadequately maintained. This Limited Warranty extends solely to products
manufactured by GSI.
Prior to installation, the end-user has the responsibility to comply with federal, state and local codes which apply to the
location and installation of products manufactured or sold by GSI.
PNEG-1742 VTDL-48 - 8 x 9 Door Assembly 27
This equipment shall be installed in accordance with
the current installation codes and applicable
regulations which should be carefully followed in all
cases. Authorities having jurisdiction should be
consulted before installations are made.
Copyright © 2010 by GSI Group
Printed in the USA
GSI Group
1004 E. Illinois St.
Assumption, IL 62510-0020
Phone: 1-217-226-4421
Fax: 1-217-226-4420
www.gsiag.com
Loading...
