Grundig MC 6540 User Manual

ǵ
PRO CERAMIC HAIR CLIPPER SET
MC 6540
2
_________________________________________________________
3
_________________________________________________________
F
G
H
I
B
C
D
E
4
_________________________________________________________
5
_________________________________________________________
DEUTSCH 6 - 15 ENGLISH 16 - 25 POLSKI 26 - 35
16
SAFETY
_______________________________________________
ENGLISH
Please note the following information when using the appliance:
7
The appliance is designed for domestic use only.
7
Observe these instructions in order to prevent damage to the appliance or danger arising from improper use. Keep them in a safe place.
7
Never use the appliance in the bath, shower or over a wash­basin filled with water; nor should it be operated with wet hands.
7
Do not immerse the appliance in water or let it come into contact with water, even during cleaning.
7
Do not drop the appliance.
7
Do not use the appliance near water in bathtubs, wash basins or other vessels.
7
Pull out the mains plug after use.
7
If the appliance is used in the bathroom, it is essential that the mains adapter is pulled out after use, as water close to the appliance can still constitute a danger, even if it is switched off.
7
Never use the appliance if it is visibly damaged.
7
Keep the appliance away from children.
7
Do not open the appliance under any circumstances. No warranty claims are accepted for damage resulting from improper handling.
ENGLISH
17
OVERVIEW
__________________________________________
Fold out page 2 so that you have the illustrations in front of you.
Controls
On/off switch. LED, lights red when the
appliance is connected to the mains.
Lever for moving the lower blade.
Cutting head. Socket for mains adapter lead.
E
D
C
B
A
Accessories
Combs of various sizes for different trimming grades (#1 to #7).
Two combs for side-on fine trimming (right and left).
Comb for short hair and graduation (blending).
Mains adapter.
Other accessories
1 x Scissors. 1 x Face/neck cleaning brush. 3 x Hair clips. 1 x Appliance cleaning brush. 1 x Oil for cutting head.
I
H
G
F
18
ENGLISH
POWER SUPPLY
___________________________________
Operation with rechargeable batteries
When using the built-in recharge­able nickel metal hydride batteries, use the mains adapter supplied as a charger.
1 Plug the mains adapter into the
socket, and plug the mains
adapter into the mains socket.
Notes
7
Completely charge up the batter­ies (16 hours) before you first use them or if you have not used them for a long time.
7
When switched off the charging time is approximately 8 hours. If you switch on the appliance while it is charging, charging will stop.
7
The ambient temperature should be between 5 °C and 40 °C.
E
7
When fully charged, the appliance works for around 45 minutes. It is not advisable to charge the batteries after every use, especially if you do not use the appliance for the full 45 min­utes. Only charge the batteries when they are completely discharged. This increases their life. Do not charge them every day.
Environmental note
7
This appliance contains nickel metal hydride batteries. Do not dispose of it with your household waste at the end of its service life. Open the housing. Remove the batteries and take them to a bat­tery collection box in a shop or public collection point.
ENGLISH
19
POWER SUPPLY
___________________________________
Mains operation (with mains adapter)
Check that the voltage on the mains adapter type plate corresponds to your local mains supply. The only way to disconnect the device from the mains supply is to unplug the adapter.
1 Insert the mains adapter plug in
the socket.
2 Insert the mains adapter plug in
the socket. – The built-in batteries are
switched off.
Note
7
Only use the appliance in battery mode when in the bathroom or beside a water connection; never run it from the mains.
E
20
ENGLISH
OPERATION
________________________________________
Special features
The appliance has a ceramic/stain­less steel cutting head . You can adjust the steel blade while trimming using the lever . This allows you to finely adjust the trim­ming length.
Trimming hair
1 Put on a comb for the cutting
grade you need (see the table below).
C
D
2 To do this, put the teeth of the
cutting head in the central grove of the comb and gently press on the bottom of the blade head until it catches (1 and 2).
3 Place a towel around the neck
and shoulder of the person whose hair you are trimming. Make sure the person is seated so that their head is roughly at your eye level. Before trimming, comb the hair so that it falls nat­urally and you can see the direc­tion in which it grows.
4 Switch on the appliance using
the switch and start trimming.
5 Turn off the appliance using
the switch when you have finished trimming.
6 Take off the comb. Gently pull
the bottom catch away from the cutting head until it comes loose. Then lift off the comb.
A
A
2
1
ENGLISH
21
OPERATION
________________________________________
Using the lever
You can continuously adjust the lever while trimming. This adjusts the trimming length without you having to attach a comb.
When the lever is at the top, the cutting length is shortest. The further you push down the lever, the greater the cutting length.
With the lever right down, the cutting length is the same as with a 3 mm comb attachment.
Using the lever extends the life of the blades, because the cutting angle changes with each adjust­ment.
If the blades are blocked by very thick hair, you can unblock them by moving the lever without having to remove the lower steel blade.
C
When you have finished trimming, clean the blades of hair clippings by quickly moving the lever from maximum to minimum with the appliance still on.
Comb attachment grades
Note
7
All the lengths here are approxi­mate.
Comb #1 Comb #2 Comb #3 Comb #4 Comb #5 Comb #6 Comb #7
3 mm 6 mm
9 mm 12 mm 16 mm 20 mm 25 mm
22
OPERATION
________________________________________
ENGLISH
Useful tips
7
Hold the appliance with a relaxed and comfortable grip.
7
Always cut against the natural direction of the hair.
7
As you cut, take a break at regu­lar intervals. You can always make a correction, but not once the hair has been cut.
7
Only cut a small amount the first time you use the trimmer. This is the only way to get used to the variable grades.
7
Do not force the comb through the hair. Let it guide you.
7
Keep combing the hair. Only look for hair which is too long and comb out clippings.
7
To ensure good results, the hair should be dry.
Environmental note
This product has been made from high-quality parts and materials which can be re-used and recycled.
Therefore, do not throw the product away with normal household waste at the end of its life. Take it to a col­lection point for recycling electrical and electronic devices. This is indi­cated by this symbol on the product, in the operating manual and on the packaging.
Please find out about collection points operated by your local authority.
Help protect the environment by recycling used products.
ENGLISH
23
CLEANING AND CARE
___________________________
Cleaning and care
1 Switch off the appliance and
unplug it if you are running it from the mains.
2 Take off the comb and clean the
blades with the brush supplied.
3 Only clean the housing and the
comb with a damp, soft cloth.
Note
7
Never immerse the appliance, lead or mains adapter in water or other liquids.
4 Before using the appliance
again, dry all parts completely using a towel.
5 Do not use cleaning agents. 6 Put on the protective cover sup-
plied.
Note
7
Remove any clippings after each use.
Adjusting the blades
When new, the blades are optimally aligned. However, you need to readjust the blades if you replace them or if you have removed the lower blade for cleaning.
1 Loosen the screws. 2 Align the teeth of upper blade
(ceramic) and the lower blade (stainless steel). The points of the teeth on the upper blade should be roughly 1.2 mm behind those of the lower blade.
3 If the blades are not correctly
aligned, switch off the appliance, loosen the screws again and readjust the blades.
4 Tighten the screws once you
have aligned the blades.
24
CLEANING AND CARE
___________________________
ENGLISH
Note
7
Normally you do not need to oil the blades, because they are made of two different materials (ceramic and steel). If you want to maintain the original condition of the blades for as long as possible, it is worth oiling the cut­ting head at regular intervals.
Storage
If you do not want to use the appli­ance for a long period of time, please store it carefully.
1 Ensure that it is unplugged and
is completely dry.
2 Store the parts in the original
packaging in a cool, dry place. To prevent damage to the cutting head, put on the protective cover supplied.
3 Make sure the appliance is kept
out of reach of children.
ENGLISH
25
INFORMATION
____________________________________
This product fulfils the European directives 89/336/EEC and
73/23/EEC.
Technical data
Power supply
Batteries: Nickel metal hydride Mains adapter
Guarantee
The guarantee does not cover the cutting head or defects which do not significantly impair the value or function of the appliance. The guarantee is invalidated if the appliance is damaged, opened or improperly used.
Technical and design modifications reserved.
Ni-MH
Grundig Multimedia B.V.
Atrium, Strawinskylaan 3105 • NL-1077 ZX Amsterdam • http://www.grundig.com
