Grundfos RSI Series Installation And Operating Instructions Manual

RSI, 1.5 - 37 kW

Installation and operating instructions

GRUNDFOS INSTRUCTIONS

English (GB)

2

English (GB) Installation and operating instructions

Original installation and operating instructions

CONTENTS

Page

1. Symbols used in this document

2. Purchase inspection before
installation

If any deviation from the order is found, please
contact Grundfos. Once you get the product, please
perform the following inspections before installation:

1. Symbols used in this document

2

2. Purchase inspection before installation

2

3. Technical data

3

3.1 Product range

3

3.2 Technical data

6

4. Installation

7

4.1 Installation example

7

4.2 Electrical connection

8

5. Operation

9

5.1 Control panel

9

5.2 Control panel operation

11

5.3 Quick setup parameter description

13

6. Fault finding

14

6.1 Fault codes and remedies

14

6.2 Fault codes reset

20

6.3 Fault history

20

7. Service and maintenance

20

7.1 Routine inspection

20

7.2 Inspection and replacement of wear parts

22

7.3 Storage and warranty

22

8. Disposal

22

Warning
Prior to installation, read these installation

and operating instructions. Installation and
operation must comply with local
regulations and accepted codes of good
practice.

Advanced IO
http://net.grundfos.com/Appl/

ccmsservices/public/literature/filedata/
Grundfosliterature-5261450.pdf

Warning
If these safety instructions are not

observed, it may result in personal injury.

Warning
If these instructions are not observed, it

may lead to electric shock with consequent
risk of serious personal injury or death.

Warning
The surface of the product may be so hot

that it may cause burns or personal injury.

Caution

If these safety instructions are not
observed, it may result in malfunction or
damage to the equipment.

Note

Notes or instructions that make the job
easier and ensure safe operation.

Caution

Check the condition of the inverter before
installation. Please do not install the
inverter if the equipment appears to be
damaged.

Inspection item Inspection method

Consistency with
ordered product

Inspect the product's
nameplate

Damage or scratches

Inspect the product
visually

Completeness of main
inverter and accessories

Check carefully
according to the product
list

Are fastening parts,
such as screws,
tightened properly

Check with screwdriver,
if necessary

English (GB)

3

3. Technical data

3.1 Product range

3.1.1 Dimensions

Fig. 1 Frame A 1.5 - 5,5 kW

TM06 6526 1813

E

W

W2

L1

L

L2

H

H2

H1

Frame Size

Product

Net weight

[kg]

E

[mm]W [mm]W2[mm]L[mm]L1[mm]L2[mm]H[mm]H1[mm]H2[mm]

Frame A 8.8 ∅5.9 143.5 191.0 297.0 293.0 315.0 188.0 197.0 214.0

Frame Size

Package

Gross weight

[kg]

Length

[mm]

Width

[mm]

Height

[mm]

Frame A 310 250 200 295

English (GB)

4

Fig. 2 Frame B 7.5 - 15 kW

TM06 6527 1813

E

W

W2

H

H2

H1

L1

L

L2

Frame Size

Product

Net weight

[kg]

E

[mm]W [mm]W2[mm]L[mm]L1[mm]L2[mm]H[mm]H1[mm]H2[mm]

Frame B 14.9 ∅6.1 180.0 233.0 349.0 345.2 368.0 204.0 214.0 231.0

Frame Size

Package

Gross weight

[kg]

Length

[mm]

Width

[mm]

Height

[mm]

Frame B 310 250 200 295

English (GB)

5

Fig. 3 Frame C 18,5 - 37 kW

TM06 6528 1914

E

W

W2

H

H2

H1

L1

L

L2

Frame Size

Product

Net weight

[kg]

E

[mm]W [mm]W2[mm]L[mm]L1[mm]L2[mm]H[mm]H1[mm]H2[mm]

Frame C 31.5 ∅8.2 322.0 350.0 385.0 382.5 500.0 230.0 236.0 254.0

Frame Size

Package

Gross weight

[kg]

Length

[mm]

Width

[mm]

Height

[mm]

Frame C 310 250 200 295

English (GB)

6

3.2 Technical data

3.2.1 Low Voltage Range (3 x 208-240 V)

3.2.2 High Voltage Range (3 x 380-415 V)

Voltage 3 x 208-240 V 3 x 380-415 V

Installation
environment

Min. ambient temperature [°C] -10 -10

Max. ambient temperature [°C] 60 60

Max. relative humidity [%] 100 100

Electrical data

Min. recommended MPP voltage [VDC] 230 400

Max. Input voltage [VDC] 380 800

Min. frequency [Hz] 5 5

Max. frequency [Hz] 60 60

Phases 3

Rated output voltage [VAC] 220 380

Enclosure class IP66 IP66

Power

[kW]

Product number

Electrical Data

Frame size

Max. P2

[kW]

Rated Output Current

[A]

1.5 99090622 1.5 8 A

2.2 99090633 2.2 11 A

3.0 99090634 3.0 12.5 A

4.0 99090635 4.0 18 A

5.5 99090636 5.5 24.2 A

7.5 99090637 7.5 31 B

11 99090638 11 48 B

15 99090639 15 62 B

Power

[kW]

Product number

Electrical Data

Frame size

Max. P2

[kW]

Rated Output Current

[A]

2.2 99044348 2.2 5.6 A

3.0 99044349 3.0 8 A

4.0 99044350 4.0 9.6 A

5.5 99044351 5.5 12 A

7.5 99044352 7.5 16 B
11 99044363 11 23 B
15 99044364 15 31 B

18.5 99044365 18.5 38 C
22 99044366 22 46 C
30 99044367 30 61 C
37 99044368 37 72 C

English (GB)

7

4. Installation

4.1 Installation example

Fig. 4 Installation example showing the required clearance when mounting the product

Warning
Installation must be carried out by qualified

staff.

Caution

You must adjust the minimum frequency to
a value that ensures water is discharged
from the outlet of the pump

Note

To adjust the min Frequency click the
home button on the control panel and
select min Frequency

Caution

To ensure a good convective cooling
effect, install the inverter vertically with at
least 10 cm free space at the top and
bottom.

To be installed indoors. Do not install the
equipment in direct sunlight.

Caution

Please ensure that the mounting wall can
support the weight of the inverter. Find
weight in 3.2 Technical data.

TM06 6529 1813

A

C B

A

Type A

B C

сůĞĂƌĂŶĐĞůĞŌĂŶĚƌŝŐŚƚĨƌŽŵƚŚĞĚƌŝǀĞ
сůĞĂƌĂŶĐĞĂďŽǀĞƚŚĞĚƌŝǀĞ
сůĞĂƌĂŶĐĞůƵŶĚĞƌŶĞĂƚŚƚŚĞĚƌŝǀĞĚƌŝǀĞ

80 160 60

DŝŶĐůĞĂƌĂŶĐĞ΀ŵŵ΁

ůůƚLJƉĞƐ

100X

T

A = Clearance left and right from the drive
B = Clearance above the drive
C = Clearance underneath the AC drive

Min clearance

[mm]

Type A B C

All types 80 160 60

English (GB)

8

4.2 Electrical connection

Fig. 5 Position of terminals

Warning
To avoid the risk of electric shock or fire,

make sure that the power supply has been
cut off before connecting the equipment.

To avoid live voltage on the cabinet, make
sure the earth terminal is reliably
grounded.

Caution

To avoid arcing and fire, tighten all
terminals with the specified torque.

For distances (pump to inverter) exceeding
30 m, we recommend a reactor with
matching current ratings.

TM06 6530 1914

Terminal DescripƟon

L1
L2
L3

These terminals are the input cŽŶŶĞĐƟŽŶƐ for the power
supply.

DC-
DC+/R+
R-

DC bus terminals (DC- DC+)
and
Brake resistor terminals (R+ R-)

U/T1
V/T2
W/T3

These terminals are for motor cŽŶŶĞĐƟŽŶƐ

FILTER

AC power supply

PUMP

W/T3

V/T2

(V)

(U)

(W)

(PE)

U/T1 DC+/R+R+ DC-

L3 L2 L1

(PE)

3

11221331441551661771881993010A11

B

Standard I/O

Terminal Signal

1 +10 Vref Reference output

2

AI1+

Analogue input,
voltage or current

3

AI1-

Analogue input com-
mon

4

AI2+

Analogue input,

voltage or current

5

AI2-

Analogue input com-
mon

6

24Vout 24V aux. voltage

7

GND I/O ground

8

DI1 Digital input 1

9

DI2 Digital input 2

10

DI3 Digital input 3

11

CM

Common for DI1-DI6

*

12

24Vout 24V aux. voltage

13

GND I/O ground

14

DI4 Digital input 4

15

DI5 Digital input 5

16

DI6 Digital input 6

17

CM Common for DI1-DI6*

18

AO1+

Analogue output,
voltage or current

19

AO-/GND

Analogue output com-

mon

30 +24 Vin

24V auxiliary input
voltage

A RS485 Serial bus, ŶĞŐĂƟve

B RS485 Serial bus, ƉŽƐŝƟve

Reference

poteŶƟŽŵĞƚĞƌ 1...10 k

ё

Remote reference

4...20mA/0...10V

mA

100X

Terminal Description

L1
L2
L3

These terminal are the input connections
for the power supply.

DC­DC+/R+
R-

DC bus terminal (DC- DC+)
and
Break resistor terminals (R+ R-)

U/T1
V/T2
W/T3

These terminal are for motor connections.

Pump

Filter

AC power supply

3~

Standard I/O

Terminal Signal

1 +10 Vref Reference output

2 AI1+

Analogue input,
voltage or current

3 AI1- Analogue input common

4 AI2+

Analogue input,
voltage or current

5 AI2- Analogue input common
6 24 Vout 24 V aux. voltage
7 GND I/O ground
8 DI1 Digital input 1

9 DI2 Digital input 2
10 DI3 Digital input 3
11 CM Common for DI1-DI6

12 24 Vout 24 V aux. voltage
13 GND I/O ground

14 DI4 Digital input 4
15 DI5 Digital input 5
16 DI6 Digital input 6
17 CM Common for DI1-DI6
18 AO1+ Analogue output, voltage or current
19 AO-/GND Analogue output common
30 +24 Vin 24 V auxiliary input voltage

A RS485 Serial bus, negative

B RS485 Serial bus, positive

Reference

potentiometer

1...10 kΩ

Remote reference

4...20mA / 0...10V

English (GB)

9

5. Operation

5.1 Control panel

The Renewable Solar Inverter control panel is shown
in fig. 6 below. The control panel has four LEDs, a
digital display and nine operating keys.

Fig. 6 Control panel layout

Warning
Check all electrical connections before

powering up the system.

Warning
The heat sink becomes hot during running

and stays hot for a long time. Touching it
while it is hot will cause burns.

Caution

In case of altitudes over 1000 m, the
output current should be reduced by 10 %
for every 1500 m increase in altitude.

Note

Adjust control parameters according to the
steps indicated in this manual before the
first start.

TM05 4446 2412

Digital display control panel

Operating keys
(The function of the keys is shown in the

table below.)

Mode indicator lights (LEDs):
On
RUN
FLT (FAULT)
Ready

Indicator lights and keys Function description

On On indicator light Yellow On: Inverter is on.

Run Run indicator light Green On: Inverter is running.

FLT Fault indicator light Red On: System fault.

Ready Ready indicator light Yellow On: System is ready to run.

Return key

Returns to previous screen in the control panel and is
used to reset faults.

Home key Returns to home screen in the control panel.

English (GB)

10

Off key Turns the inverter output OFF.

On key Turns the inverter output ON.

Up key Navigate control panel and edit parameter values.

Down key Navigate control panel and edit parameter values.

Right key Navigate control panel and edit parameter values.

Left key Navigate control panel and edit parameter values.

OK key Confirm selection and parameter values.

Indicator lights and keys Function description

English (GB)

11

5.2 Control panel operation

5.2.1 Grundfos start-up wizard

Display Directions Notes

Select Language

Select Start up Wizard

Verify or adjust the rated motor voltage

Verify or adjust the rated frequency

Verify or adjust the nominal speed

Verify or adjust the rated current

Verify or adjust the power factor

Verify or adjust the rated P2 power

English (GB)

12

Select pump type or Other and adjust
parameters

Select solar modules or other and adjust
Vmp (maximum power voltage)

Select the number of solar modules

Select if sinus filter is used or not

Display Directions Notes

English (GB)

13

5.3 Quick setup parameter description

The User settings column is left blank to allow users
to write down their own input settings.

Name Description Factory Setting User Setting

Motor Nom Voltage Motor Rated Voltage 380

Motor Nom Freq Motor Rated Frequency 50

Motor Nom Current Motor Rated Current Size Dependent

Current Limit

Maximum Current from

drive

Size Dependent

Motor Cos Phi Motor Power Factor Size Dependent

Motor Nom Power Motor Rated Power Size Dependent

Pump Selection Grundfos Pump Family SP

Min Freq Reference Lower frequency 30

Max Freq Reference Target frequency 50

Acceleration time Initial ramp time 3

Deceleration time Final ramp time 3

PV modules type Solar panel type sw260

Module MP Voltage

Vmp Maximum power

point voltage

31, 4 V

Series Modules No.

Number of solar panels in

series

18

Output Sinus Filter

Select in Sinuw wave filter

is used or not

No

Advanced Level PW

Password for advance

menu and service

0

Digitial inputs Description

DI1 Start/Stop

DI2 Tank Level switch

DI3 Well Level switch

DI4 Flow switch

DI5 Flow meter (Pulsating)

DI6 AC operation

Note

After modifying the parameters in the table
above, the inverter needs to be stopped
and started again to update the
parameters.

Note

No record is made of undervoltage fault
caused by insufficient power due to low
sunlight intensity.

English (GB)

14

6. Fault finding

6.1 Fault codes and remedies

Fault
code

Fault

ID

Fault name Possible cause Remedy

1

1

Overcurrent
(hardware fault)

AC drive has detected too high a
current (> 4*I

H

) in the motor cable:

• sudden heavy load increase

• short circuit in motor cables

• unsuitable motor

Check loading.
Check motor.
Check cables and connections.
Make identification run.
Check ramp times.

2

Overcurrent
(software fault)

2

10

Overvoltage
(hardware fault)

The DC-link voltage has exceeded
the limits defined.

• too short a deceleration time

• brake chopper is disabled

• high overvoltage spikes in supply

• Start/Stop sequence too fast

Make deceleration time longer.
Use brake chopper or brake
resistor (available as options).
Activate overvoltage controller.
Check input voltage.

11

Overvoltage
(software fault)

3

20

Earth fault
(hardware fault)

Current measurement has detected
that the sum of motor phase current
is not zero.

• insulation failure in cables or
motor

Check motor cables and motor.

21

Earth fault
(software fault)

540Charging switch

The charging switch is open, when
the START command has been
given.

• faulty operation

• component failure

Reset the fault and restart.
Should the fault re-occur,
contact the distributor near to
you.

760Saturation

Various causes:

• defective component

• brake resistor short-circuit or
overload

Cannot be reset from keypad.
Switch off power.
Do not re-connect power!
Contact factory.
If this fault appears
simultaneously with F1, check
motor cables and motor.

English (GB)

15

8

600

System fault

Communication between control
board and power unit has failed.

Reset the fault and restart.
Should the fault re-occur,
contact the distributor near to
you.

601

Communication between control
board and power unit has
interference, but it is still working.

602 Watchdog has reset the CPU

603

Voltage of auxiliary power in power
unit is too low.

604

Phase fault: Voltage of an output
phase does not follow the reference

605

CPLD has faulted but there is no
detailed information about the fault

606

Control and power unit software are
incompatible

Update software. Should the
fault re-occur, contact the
distributor near to you.

607

Software version cannot be read.
There is no software in power unit.

Update power unit software.
Should the fault re-occur,
contact the distributor near to
you.

608

CPU overload. Some part of the
software (for example application)
has caused an overload situation.
The source of fault has been
suspended

Reset the fault and restart.
Should the fault re-occur,
contact the distributor near to
you.

609

Memory access has failed. For
example, retain variables could not
be restored.

610

Necessary device properties cannot
be read.

614 Configuration error.
647 Software error

Update software. Should the
fault re-occur, contact the
distributor near to you.

648

Invalid function block used in
application. System software and
application are not compatible.

649

Resource overload.
Error when loading parameter initial
values.
Error when restoring parameters.
Error when saving parameters.

9

80

Undervoltage
(fault)

DC-link voltage is under the voltage
limits defined.

• most probable cause: too low a
supply voltage

• AC drive internal fault

• defect input fuse

• external charge switch not closed

Note! This fault is activated only if
the drive is in Run state.

In case of temporary supply
voltage break reset the fault and
restart the AC drive. Check the
supply voltage. If it is adequate,
an internal failure has occurred.
Contact the distributor near to
you.

81

Undervoltage
(alarm)

10 91 Input phase Input line phase is missing.

Check supply voltage, fuses and
cable.

11 100

Output phase
supervision

Current measurement has detected
that there is no current in one motor
phase.

Check motor cable and motor.

Fault
code

Fault

ID

Fault name Possible cause Remedy

English (GB)

16

12

110

Brake chopper
supervision
(hardware fault)

No brake resistor installed.
Brake resistor is broken.
Brake chopper failure.

Check brake resistor and
cabling.
If these are ok, the chopper is
faulty. Contact the distributor
near to you.

111

Brake chopper
saturation alarm

13 120

AC drive
undertemperature
(fault)

Too low temperature measured in
power unit's heat sink or board. Heat
sink temperature is under -10 °C.

Check the ambient temperature

14

130

AC drive
overtemperature
(fault, heat sink)

Too high temperature measured in
power unit's heat sink or board. Heat
sink temperature is over 100 °C.

Check the correct amount and
flow of cooling air.
Check the heat sink for dust.
Check the ambient temperature.
Make sure that the switching
frequency is not too high in
relation to ambient temperature
and motor load.

131

AC drive
overtemperature
(alarm, heatsink)

132

AC drive
overtemperature
(fault, board)

133

AC drive
overtemperature
(alarm, board)

15 140 Motor stalled Motor is stalled. Check motor and load.

16 150

Motor
overtemperature

Motor is overloaded.

Decrease motor load.
If no motor overload exists,
check the temperature model
parameters.

17 160 Motor underload Motor is underloaded. Check load.

19

180

Power overload
(short-time
supervision)

Drive power is too high. Decrease load.

181

Power overload
(long-time
supervision)

25

240

Motor control fault

Start angle identification has failed.

Reset the fault and restart.
Should the fault re-occur,
contact the distributor near to
you.

241 Generic motor control fault.

26 250

Start-up
prevented

Start-up of the drive has been
prevented. Run request is ON when
a new software (firmware or
application), parameter setting or
any other file, which has affects the
operation of the drive, has been
loaded to drive.

Reset the fault and stop the AC
drive.
Load the software and start the
AC drive.

30 530 STO fault

Emergency stop button has been
connected or some other STO
operation has been activated.

When the STO function is
activated, the drive is in safe
state.

32 312 Fan cooling Fan life time is up.

Change fan and reset fan life
time counter.

33 320

Fire mode
enabled

Fire mode of the drive is enabled.
The drive's protections are not in
use.

Check the parameter settings

Fault
code

Fault

ID

Fault name Possible cause Remedy

English (GB)

17

37 360

Device changed
(same type)

Option board changed for one
previously inserted in the same slot.
The board's parameter settings are
saved.

Device is ready for use. Old
parameter settings will be used.

38 370

Device changed
(same type)

Option board added. The option
board was previously inserted in the
same slot. The board's parameter
settings are saved.

Device is ready for use. Old
parameter settings will be used.

39 380 Device removed Option board removed from slot. Device no longer available.

40 390 Device unknown

Unknown device connected (power
unit/option board)

Device no longer available.

41 400 IGBT temperature

IGBT temperature (unit temperature
+ I

2

T) is too high.

Check loading.
Check motor size.
Make identification run.

44 430

Device changed
(different type)

Option board changed or Power unit
changed. No parameter settings are
saved.

Set the option board parameters
again if option board was
changed. Set converter
parameters again if power unit
was changed.

45 440

Device changed
(different type)

Option board added. The option
board was not previously present in
the same slot. No parameter settings
are saved.

Set the option board parameters
again.

46 662 Real Time Clock

RTC battery voltage level is low and
the battery should be changed.

Replace the battery.

47 663 Software updated

Software of the drive has been
updated (either the whole software
package or application).

No actions needed.

50 1050 AI low fault

At least one of the available
analogue input signals has gone
below 50 % of the defined minimum
signal range.
Control cable is broken or loose.
Signal source has failed.

Change the failed parts.
Check the analog input circuit.
Check that parameter AI1 signal
range is set correctly.

51 1051 External Fault Fault activated by digital input.

Check the digital input or the
device connected to it.
Check the parameter settings.

52

1052
1352

Keypad
communication
fault

The connection between the control
keypad and frequency converter is
broken

Check keypad connection and
possible keypad cable

53 1053

Fieldbus
communication
fault

The data connection between the
fieldbus master and fieldbus board is
broken

Check installation and fieldbus
master.

54

1654 Slot D fault

Defective option board or slot Check board and slot.

1754 Slot E fault

57 1057 Identification Identification run has failed.

Check that motor is connected
to the drive.
Ensure that there is no load on
the motor shaft.
Ensure that the start command
will not be removed before
completion of identification run.

Fault
code

Fault

ID

Fault name Possible cause Remedy

English (GB)

18

58 1058 Mechanical brake

Actual status of mechanical brake
remains different from the control
signal for longer than what is
defined.

Check the status and
connections of the mechanical
brake.

63 1063 Low water level The minimum water level is not ok.

Check settings and water level
status.

64 1064 Max water level The maximum water level is not ok.

Check settings and water level
status.

65 1065

PC
communication
fault

The data connection between the PC
and frequency converter is broken

66 1066 Thermistor fault

The thermistor input has detected an
increase of motor temperature

Check motor cooling and load.
Check thermistor connection.
(If thermistor input is not in use
it has to be short circuited)

68

1301

Maintenance
counter 1 alarm

Maintenance counter has reached
the alarm limit.

Carry out the needed
maintenance and reset counter.

1302

Maintenance
counter 2 alarm

Maintenance counter has reached
the alarm limit.

Carry out the needed
maintenance and reset counter.

1303

Maintenance
counter 3 alarm

Maintenance counter has reached
the alarm limit.

Carry out the needed
maintenance and reset counter.

1304

Maintenance
counter 4 alarm

Maintenance counter has reached
the alarm limit.

Carry out the needed
maintenance and reset counter.

69

1310

Fieldbus mapping
error

Non-existing ID number is used for
mapping values to Fieldbus Process
Data Out.

Check parameters in Fieldbus
Data Mapping menu.

1311

Not possible to convert one or more
values for Fieldbus Process Data
Out.

The value being mapped may
be of undefined type. Check
parameters in Fieldbus Data
Mapping menu.

1312

Overflow when mapping and
converting values for Fieldbus
Process Data Out (16-bit).

76 1076 Start prevented

Start command is active and was
blocked in order to prevent
unintentional rotation of the motor
during the first power-up.

Reset drive to restore the
normal operation. The need of
restart depends on the
parameter settings.

77 1077 > 5 connections

Maximum number of 5 simultaneous
active fieldbus or PC tool
connections supported by the
application exceeded.

Remove excessive active
connections.

100 1100 Soft fill time-out

The Soft fill function in the PID
controller has timed out. The wanted
process value was not achieved
within time.

Reason might be a pipe burst.

101 1101

Process
supervision fault
(PID1)

PID controller: Feedback value
outside of supervision limits (and the
delay if set).

Check settings.

105 1105

Process
supervision fault
(PID2)

PID controller: Feedback value
outside of supervision limits (and the
delay if set).

Check settings.

Fault
code

Fault

ID

Fault name Possible cause Remedy

English (GB)

19

109

1109

Input pressure
supervision

Input pressure supervision signal
has gone below the alarm limit.

Check the process.
Check the parameters
Check the input pressure sensor
and connections.

1409

Input pressure supervision signal
has gone below the fault limit.

111

1315

Temperature fault
1

At least one of the selected
temperature input signals has
reached the alarm limit.

Find the cause of temperature
raise.
Check the temperature sensor
and connections.
Check that the temperature
input is hardwired if no sensor is
connected.
See option board manual for
further information.

1316

At least one of the selected
temperature input signals has
reached the fault limit.

112

1317

Temperature fault
2

At least one of the selected
temperature input signals has
reached the fault limit.

1318

At least one of the selected
temperature input signals has
reached the fault limit.

Fault
code

Fault

ID

Fault name Possible cause Remedy

English (GB)

20

6.2 Fault codes reset

When a fault appears and the RSI stops, examine
the cause of fault, perform the actions advised in
section 6.1 and reset the fault as instructed below.

1. With a long (1 s) press on the Reset button on
the keypad or

2. By entering the Diagnostics Menu (M4), entering
Reset faults (M4.2) and selecting Reset faults
parameter.

3. For keypad with LCD display only: By selecting
value Yes for the parameter and clicking OK.

6.3 Fault history

The inverter will record the forty most recent fault
codes. Searching this information will help
investigate the fault cause. Fault information is
stored together with additional informationsin the
fault history menu.

7. Service and maintenance

7.1 Routine inspection

To ensure the inverter runs stably, carry out an
annual inspection.

7.1.1 Inspection and maintenance requirements

1. If it is necessary to conduct an insulation test on
the inverter, all input and output terminals must
have a proper short-circuit. Insulation tests must
not be performed on a single terminal. Use a 500
V mega ohm meter to conduct the test.

2. When conducting an insulation test on the motor,
dismantle the connection between motor and
inverter.

Caution

Check the fault cause thoroughly and
remedy it before resetting. If it cannot be
reset or persists after resetting, check the
cause again as continuous resetting will
damage the inverter.

Caution

In case of overload and overheat
protection, delay the resetting for 5
minutes.

Warning
Maintenance and inspection must be

performed by a qualified electrician.
Do not dismantle the inverter when it is

running. The inverter must be powered off
at least 5 minutes before conducting
maintenance and inspection.

It is absolutely forbidden for unauthorised
persons to repair the inverter as this can
cause personal injury or equipment
damage.

Note

Any service performed on the inverter by
unqualified staff will void the warranty.

Warning
The inspection must be performed by

trained and qualified technical staff.
Disconnect the power supply to the
inverter before starting inspection

Caution

Do not use the mega ohm meter to test the
control circuit.

English (GB)

21

7.1.2 Main inspection and maintenance points

1)

Every 1000 running hours.

2)

Every month.

Inspection frequency

Inspection issue Inspection item Criteria or requirements

Routine

1)

Regular

2)

√

Running
environment

1. Temperature.

2. Humidity.

3. Gas.

4. Dust.

1. Temperature < 50 °C.

2. Humidity < 90 %, no
condensation.

3. No flammable, explosive gas.

4. Non-corrosive environment.

√ Cooling system

1. Installation
environment.

2. Radiator.

3. Fan.

1. Good ventilation in installation
environment.

2. Radiator air duct not blocked.

3. Fan should be running
smoothly, if equipped.

√ Inverter cabinet

1. Vibration.

2. Temperature rise.

3. Noise.

4. Leads, terminals.

1. A vibration that appears steady
and normal

2. Normal temperature.

3. No abnormal noise.

4. Leads and terminals fastened
properly.

√ Motor

1. Vibration.

2. Temperature rise.

3. Noise.

1. Steady running.

2. Normal temperature.

3. No abnormal noise.

√

Input and output
parameters

1. Input voltage.

2. Output current.

1. Input voltage within limit.

2. Output current under the rated
value.

English (GB)

22

7.2 Inspection and replacement of wear
parts

7.2.1 Cooling fan

Inverters are equipped with cooling fans. The
cooling fan's service life is about 15000 hours. If the
fan generates abnormal noise or produces
vibrations, replace it immediately. The cooling fan
will start automatically when the internal temperature
of inverter is higher than 55 °C and stop when the
internal temperature of inverter is lower than 45 °C.

7.3 Storage and warranty

7.3.1 Storage

If the product is stored for a long time after
purchasing, comply with the following requirements:

1. Avoid placing the inverter in high-temperature or

humid areas or areas with vibration and metal
dust. Ensure ventilation.

2. The performance of the capacitor inside the

inverter can be reduced if the equipment is not
used for a long period of time. It is thus
necessary to start up the equipment every two
years to restore the performance of the capacitor
and inspect the inverter function at the same
time. The voltage must be increased gradually
through a DC power supply with power-on time
being not less than 5 hours.

7.3.2 Warranty

The following situations are not covered by the
warranty:

• Faults caused by failure to comply with this

manual or standard specifications.

• Faults caused by self-repairing and modification

without permission.

• Faults caused by poor storage and maintenance.

• Faults caused by abnormal use of the inverter.

• Damage caused by fire, salt corrosion, gas

corrosion, earthquake, storm, flooding, lightning,
abnormal voltage or other force majeure
situations.

8. Disposal

This product or parts of it must be disposed of in an
environmentally sound way:

1. Use the public or private waste collection service.

2. If this is not possible, contact the nearest

Grundfos company or service workshop.

Subject to alterations.

23

Grundfos companies

Argentina

Bombas GRUNDFOS de Argentina S.A.
Ruta Panamericana km. 37.500 Centro
Industrial Garin
1619 Garín Pcia. de B.A.
Phone: [phone]
Telefax: [phone]

Australia

GRUNDFOS Pumps Pty. Ltd.
P.O. Box 2040
Regency Park
South Australia 5942
Phone: [phone]
Telefax: [phone]

Austria

GRUNDFOS Pumpen Vertrieb
Ges.m.b.H.
Grundfosstraße 2
A-5082 Grödig/Salzburg
Tel.: [phone]
Telefax: [phone]

Belgium

N.V. GRUNDFOS Bellux S.A.
Boomsesteenweg 81-83
B-2630 Aartselaar
Tél.: [phone]
Télécopie: [phone]

Belarus

Представительство ГРУНДФОС в
Минске
220125, Минск
ул. Шафарнянская, 11, оф. 56, БЦ
«Порт»
Тел.: [phone]
Факс: [phone]

E-mail: [e-mail]

Bosna and Herzegovina

GRUNDFOS Sarajevo
Zmaja od Bosne 7-7A,
BH-71000 Sarajevo
Phone: [phone]
Telefax: [phone]
www.ba.grundfos.com
e-mail: [e-mail]

Brazil

BOMBAS GRUNDFOS DO BRASIL
Av. Humberto de Alencar Castelo
Branco, 630
CEP 09850 - 300
São Bernardo do Campo - SP
Phone: [phone]
Telefax: [phone]

Bulgaria

Grundfos Bulgaria EOOD
Slatina District
Iztochna Tangenta street no. 100
BG - 1592 Sofia
Tel. [phone]
Fax. [phone]
email: [e-mail]

Canada

GRUNDFOS Canada Inc.
2941 Brighton Road
Oakville, Ontario
L6H 6C9
Phone: [phone]
Telefax: [phone]

China

GRUNDFOS Pumps (Shanghai) Co. Ltd.
10F The Hub, No. 33 Suhong Road
Minhang District
Shanghai 201106
PRC
Phone: [phone]
Telefax: [phone]

Croatia

GRUNDFOS CROATIA d.o.o.
Buzinski prilaz 38, Buzin
HR-10010 Zagreb
Phone: [phone]
Telefax: [phone]
www.hr.grundfos.com

Czech Republic

GRUNDFOS s.r.o.
Čajkovského 21
779 00 Olomouc
Phone: [phone]
Telefax: [phone]

Denmark

GRUNDFOS DK A/S
Martin Bachs Vej 3
DK-8850 Bjerringbro
Tlf.: [phone]
Telefax: [phone]
E-mail: [e-mail]
www.grundfos.com/DK

Estonia

GRUNDFOS Pumps Eesti OÜ
Peterburi tee 92G
11415 Tallinn
Tel: + 372 606 1690
Fax: + 372 606 1691

Finland

OY GRUNDFOS Pumput AB
Trukkikuja 1
FI-01360 Vantaa
Phone: [phone]
Telefax: [phone]

France

Pompes GRUNDFOS Distribution S.A.
Parc d’Activités de Chesnes
57, rue de Malacombe
F-38290 St. Quentin Fallavier (Lyon)
Tél.: [phone]
Télécopie: [phone]

Germany

GRUNDFOS GMBH
Schlüterstr. 33
40699 Erkrath
Tel.: [phone]
Telefax: [phone]
e-mail: [e-mail]
Service in Deutschland:
e-mail: [e-mail]

Greece

GRUNDFOS Hellas A.E.B.E.
20th km. Athinon-Markopoulou Av.
P.O. Box 71
GR-19002 Peania
Phone: [phone]
Telefax: +0030-210-66 46 273

Hong Kong

GRUNDFOS Pumps (Hong Kong) Ltd.
Unit 1, Ground floor
Siu Wai Industrial Centre
29-33 Wing Hong Street &
68 King Lam Street, Cheung Sha Wan
Kowloon
Phone: [phone]
Telefax: [phone]

Hungary

GRUNDFOS Hungária Kft.
Park u. 8
H-2045 Törökbálint,
Phone: [phone]
Telefax: [phone]

India

GRUNDFOS Pumps India Private
Limited
118 Old Mahabalipuram Road
Thoraipakkam
Chennai 600 096
Phone: [phone]

Indonesia

PT. GRUNDFOS POMPA
Graha Intirub Lt. 2 & 3
Jln. Cililitan Besar No.454. Makasar,
Jakarta Timur
ID-Jakarta 13650
Phone: [phone]
Telefax: [phone] / 460 6901

Ireland

GRUNDFOS (Ireland) Ltd.
Unit A, Merrywell Business Park
Ballymount Road Lower
Dublin 12
Phone: [phone]
Telefax: [phone]

Italy

GRUNDFOS Pompe Italia S.r.l.
Via Gran Sasso 4
I-20060 Truccazzano (Milano)
Tel.: [phone]
Telefax: [phone] / 95838461

Japan

GRUNDFOS Pumps K.K.
Gotanda Metalion Bldg., 5F,
5-21-15, Higashi-gotanda
Shiagawa-ku, Tokyo
141-0022 Japan
Phone: [phone]
Telefax: [phone]

Korea

GRUNDFOS Pumps Korea Ltd.
6th Floor, Aju Building 679-5
Yeoksam-dong, Kangnam-ku, 135-916
Seoul, Korea
Phone: [phone]
Telefax: [phone]

Latvia

SIA GRUNDFOS Pumps Latvia
Deglava biznesa centrs
Augusta Deglava ielā 60, LV-1035, Rīga,
Tālr.: + 371 714 9640, 7 149 641
Fakss: + 371 914 9646

Lithuania

GRUNDFOS Pumps UAB
Smolensko g. 6
LT-03201 Vilnius
Tel: + 370 52 395 430
Fax: + 370 52 395 431

Grundfos companies

Malaysia

GRUNDFOS Pumps Sdn. Bhd.
7 Jalan Peguam U1/25
Glenmarie Industrial Park
40150 Shah Alam
Selangor
Phone: [phone]
Telefax: [phone]

Mexico

Bombas GRUNDFOS de México S.A. de
C.V.
Boulevard TLC No. 15
Parque Industrial Stiva Aeropuerto
Apodaca, N.L. 66600
Phone: [phone]
Telefax: [phone]

Netherlands

GRUNDFOS Netherlands
Veluwezoom 35
1326 AE Almere
Postbus 22015
1302 CA ALMERE
Tel.: [phone]
Telefax: [phone]
E-mail: [e-mail]

New Zealand

GRUNDFOS Pumps NZ Ltd.
17 Beatrice Tinsley Crescent
North Harbour Industrial Estate
Albany, Auckland
Phone: [phone]
Telefax: [phone]

Norway

GRUNDFOS Pumper A/S
Strømsveien 344
Postboks 235, Leirdal
N-1011 Oslo
Tlf.: [phone]
Telefax: [phone]

Poland

GRUNDFOS Pompy Sp. z o.o.
ul. Klonowa 23
Baranowo k. Poznania
PL-62-081 Przeźmierowo
Tel: [phone]
Fax: [phone]

Portugal

Bombas GRUNDFOS Portugal, S.A.
Rua Calvet de Magalhães, 241
Apartado 1079
P-2770-153 Paço de Arcos
Tel.: [phone]
Telefax: [phone]

Romania

GRUNDFOS Pompe România SRL
Bd. Biruintei, nr 103
Pantelimon county Ilfov
Phone: [phone]
Telefax: [phone]
E-mail: [e-mail]

Russia

ООО Грундфос Россия
109544, г. Москва, ул. Школьная, 39-
41, стр. 1
Тел. [phone] (495) 737-30­00
Факс [phone]
E-mail [e-mail]

Serbia

Grundfos Srbija d.o.o.
Omladinskih brigada 90b
11070 Novi Beograd
Phone: [phone]
Telefax: [phone]
www.rs.grundfos.com

Singapore

GRUNDFOS (Singapore) Pte. Ltd.
25 Jalan Tukang
Singapore 619264
Phone: [phone]
Telefax: [phone]

Slovakia

GRUNDFOS s.r.o.
Prievozská 4D
821 09 BRATISLAVA
Phona: [phone]
sk.grundfos.com

Slovenia

GRUNDFOS LJUBLJANA, d.o.o.
Leskoškova 9e, 1122 Ljubljana
Phone: [phone]
Telefax: [phone]
E-mail: [e-mail]

South Africa

GRUNDFOS (PTY) LTD
Corner Mountjoy and George Allen
Roads
Wilbart Ext. 2
Bedfordview 2008
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]

Spain

Bombas GRUNDFOS España S.A.
Camino de la Fuentecilla, s/n
E-28110 Algete (Madrid)
Tel.: [phone]
Telefax: [phone]

Sweden

GRUNDFOS AB
Box 333 (Lunnagårdsgatan 6)
431 24 Mölndal
Tel.: [phone]
Telefax: [phone]

Switzerland

GRUNDFOS Pumpen AG
Bruggacherstrasse 10
CH-8117 Fällanden/ZH
Tel.: [phone]
Telefax: [phone]

Taiwan

GRUNDFOS Pumps (Taiwan) Ltd.
7 Floor, 219 Min-Chuan Road
Taichung, Taiwan, R.O.C.
Phone: [phone]
Telefax: [phone]

Thailand

GRUNDFOS (Thailand) Ltd.
92 Chaloem Phrakiat Rama 9 Road,
Dokmai, Pravej, Bangkok 10250
Phone: [phone]
Telefax: [phone]

Turkey

GRUNDFOS POMPA San. ve Tic. Ltd.
Sti.
Gebze Organize Sanayi Bölgesi
Ihsan dede Caddesi,

2. yol 200. Sokak No. 204
41490 Gebze/ Kocaeli
Phone: +90 - 262-679 7979
Telefax: +90 - 262-679 7905
E-mail: [e-mail]

Ukraine

Бізнес Центр Європа
Столичне шосе, 103
м. Київ, 03131, Україна
Телефон: [phone]
Факс.: [phone]

E-mail: [e-mail]

United Arab Emirates

GRUNDFOS Gulf Distribution
P.O. Box 16768
Jebel Ali Free Zone
Dubai
Phone: [phone]
Telefax: [phone]

United Kingdom

GRUNDFOS Pumps Ltd.
Grovebury Road
Leighton Buzzard/Beds. LU7 4TL
Phone: [phone]
Telefax: [phone]

U.S.A.

GRUNDFOS Pumps Corporation
17100 West 118th Terrace
Olathe, Kansas 66061
Phone: [phone]
Telefax: [phone]

Uzbekistan

Grundfos Tashkent, Uzbekistan The Rep­resentative Office of Grundfos Kazakhstan
in Uzbekistan
38a, Oybek street, Tashkent
Телефон: [phone] / 71 150
3291
Факс: [phone]

Addresses Revised 25.01.2016

www.grundfos.com

98464145 0516

ECM: 1184037

The name Grundfos, the Grundfos logo, and be think innovate are registered trademarks

owned by Grundfos Holding A/S or Grundfos A/S, Denmark. All rights reserved worldwide.

© Copyright Grundfos Holding A/S
