Grundfos R100 Installation And Operating Istructions

R100

GRUNDFOS INSTRUCTIONS

Installation and operating instructions

>

>

>

>

OK

+

-

R 100

For Sales & Service Contact

2650 E. 40th Ave. • Denver, CO 80205

Phone [phone] • Fax [phone]

1-800-833-7958

www.geotechenv.com

2

Declaration of Conformity

We Grundfos declare under our sole responsibility that the product R100, to which this declaration
relates, is in conformity with the Council Directives on the approximation of the laws of the EC Member
States relating to

– Electromagnetic compatibility (89/336/EEC).

Standards used: EN 61000-6-2 and EN 61000-6-3.

Konformitätserklärung

Wir Grundfos erklären in alleiniger Verantwortung, dass das Produkt R100, auf das sich diese Erklärung
bezieht, mit den folgenden Richtlinien des Rates zur Angleichung der Rechtsvorschriften der EG-Mit­gliedstaaten übereinstimmt:

– Elektromagnetische Verträglichkeit (89/336/EWG).

Normen, die verwendet wurden: EN 61000-6-2 und EN 61000-6-3.

Déclaration de Conformité

Nous Grundfos déclarons sous notre seule responsabilité que le produit R100 auquel se réfère cette
déclaration est conforme aux Directives du Conseil concernant le rapprochement des législations des
Etats membres CE relatives à

– Compatibilité électromagnétique (89/336/CEE).

Standards utilisés: EN 61000-6-2 et EN 61000-6-3.

Dichiarazione di Conformità

Noi Grundfos dichiariamo sotto la nostra esclusiva responsabilità che il prodotto R100 al quale questa
dichiarazione si riferisce è conforme alle Direttive del Consiglio concernente il ravvicinamento delle legi­slazioni degli Stati membri CE relative a

– Compatibilità elettromagnetica (89/336/CEE).

Standard usati: EN 61000-6-2 e EN 61000-6-3.

Declaración de Conformidad

Nosotros Grundfos declaramos bajo nuestra única responsabilidad que el producto R100 al cual se
refiere esta declaración es conforme con las Directivas del Consejo relativas a la aproximación de las
legislaciones de los Estados Miembros de la CE sobre

– Compatibilidad electromagnética (89/336/CEE).

Normas aplicadas: EN 61000-6-2 y EN 61000-6-3.

Declaração de Conformidade

Nós Grundfos declaramos sob nossa única responsabilidade que o produto R100 a qual se refere esta
declaração está em conformidade com as Directivas do Conselho das Comunidades Europeias relativas
à aproximação das legislações dos Estados Membros respeitantes à

– Compatibilidade electromagnética (89/336/CEE).

Normas utilizadas: EN 61000-6-2 e EN 61000-6-3.

Δήλωση Συμμόρφωσης

Εμείς η Grundfos δηλώνουμε με αποκλειστική μας ευθύνη ότι το προιόν R100, με το οποίο σχετίζεται η
παρούσα δήλωση, είναι σε συμφωνία με την Οδηγία του Συμβουλίου επί της σύγκλισης των νόμων των
Κρατών Mελών της Ευρωπαικής Ενωσης σε σχέση με τα

– Ηλεκτρομαγνητική συμβατότητα (89/336/EEC).

Πρότυπα που χρησιμοποιήθηκαν: EN 61000-6-2 και EN 61000-6-3.

3

Overeenkomstigheidsverklaring

Wij Grundfos verklaren geheel onder eigen verantwoordelijkheid dat het product R100, waarop deze
verklaring betrekking heeft in overeenstemming zijn met de Richtlijnen van de Raad inzake de onderlinge
aanpassing van de wetgevingen van de Lid-Staten betreffende

– Elektromagnetische compatibiliteit (89/336/EEG).

Normen: EN 61000-6-2 en EN 61000-6-3.

Försäkran om överensstämmelse

Vi Grundfos försäkrar under ansvar, att produkten R100, som omfattas av denna försäkran, är i över-
ensstämmelse med Rådets Direktiv om inbördes närmande till EU-medlemsstaternas lagstiftning,
avseende

– Elektromagnetisk kompatibilitet (89/336/EC).

Använda standarder: EN 61000-6-2 och EN 61000-6-3.

Vastaavuusvakuutus

Me Grundfos vakuutamme yksin vastuullisesti, että tuote R100, jota tämä vakuutus koskee, noudattaa
direktiivejä jotka käsittelevät EY:n jäsenvaltioiden koneellisia laitteita koskevien lakien yhdenmukai­suutta seuraavasti:

– Elektromagneettinen vastaavuus (89/336/EY).

Käytetyt standardit: EN 61000-6-2 ja EN 61000-6-3.

Overensstemmelseserklæring

Vi Grundfos erklærer under ansvar, at produktet R100, som denne erklæring omhandler, er i overens-
stemmelse med Rådets direktiver om indbyrdes tilnærmelse til EF medlemsstaternes lovgivning om

– Elektromagnetisk kompatibilitet (89/336/EØF).

Anvendte standarder: EN 61000-6-2 og EN 61000-6-3.

Deklaracja zgodności

My, Grundfos, oświadczamy z pełną odpowiedzialnością, że nasz wyrób R100 którego deklaracja
niniejsza dotyczy, zgodny jest z następującymi wytycznymi Rady d/s ujednolicenia przepisów prawnych
krajów członkowskich EG:

– zgodność elektromagnetyczna (89/336/EWG),

zastosowane normy: EN 61000-6-2 i EN 61000-6-3.

Декларация о соответствии

Компания Grundfos заявляет о своей исключительной ответственности за то, что изделия модели
R100, на которые распространяется эта декларация, соответствуют нижеследующим

рекомендациям Совета по унификации правовых норм стран - членов Европейского Союза:
– Электромагнитная совместимость (89/336/ЕЭС).

Применявшиеся стандарты: Евростандарт EN 61000-6-2 и EN 61000-6-3.

Konformitási nyilatkozat

Mi, a Grundfos egyedüli felelősséggel kijelentjük, hogy a R100 termék, amelyre jelen nyilatkozat
vonatkozik, megfelel az Európai Unió tagállamainak jogi irányelveit összehangoló tanács alábbi
irányelveinek:

– Elektromágneses összeférhetőség (89/336/EGK).

Alkalmazott szabványok: EN 61000-6-2 és EN 61000-6-3.

Izjava o ustreznosti

Mi, Grundfos, pod polno odgovornostjo izjavljamo, da so izdelki R100, na katere se ta izjava nanaša, v
skladu z naslednjimi smernicami Sveta za uskladitev pravnih predpisov držav članic Evropske skupnosti:

– Elektromagnetna kompatibilnost (89/336/EWG).

Uporabljeni normi: EN 61000-6-2 in EN 61000-6-3.

4

Izjava o usklađenosti

Mi, Grundfos, izjavljujemo uz punu odgovornost da je proizvod R100, na kojeg se ova izjava odnosi,
sukladan smjernicama Savjeta za prilagodbu propisa država članica EZ:

– Elektromagnetska kompatibilnost (89/336/EEZ).

Korištene norme: EN 61000-6-2 i EN 61000-6-3.

Izjava o konformitetu

Mi, Grundfos, izjavljujemo pod potpunom odgovornošću da su proizvodi R100 na koje se odnosi ova
izjava u saglasnosti sa smernicama i uputstvima Saveta za usaglašavanje pravnih propisa članica
Evropske unije:

– elektromagnetna usaglašenost (89/336/EWG),

korišćeni standardi: EN 61000-6-2 i EN 61000-6-3.

Declaraţie de conformitate

Noi, Grundfos, declarăm asumându-ne întreaga responsabilitate că produsele R100 la care se referă
această declaraţie sunt în conformitate cu Directivele Consiliului în ceea ce priveşte alinierea legislaţiilor
Statelor Membre ale CE, referitoare la:

– Compatibilitate electromagnetică (89/336/CEE).

Standarde aplicate: EN 61000-6-2 şi EN 61000-6-3.

Декларация за съответствие

Ние, фирма Grundfos заявяваме с пълна отговорност, че продуктите R100, за които се отнася
настоящата декларация, отговарят на следните указания на Съвета за уеднаквяване на правните
разпоредби на държавите членки на ЕО:

– Електромагнетична поносимост (89/336/EИO).

Приложени норми: EN 61000-6-2 и EN 61000-6-3.

Prohlášení o konformitě

My firma Grundfos prohlašujeme na svou plnou odpovědnost, že výrobek R100 na nějž se toto
prohlášení vztahuje, je v souladu s ustanoveními směrnice Rady pro sblížení právních předpisů
členských států Evropského společenství v oblastech:

– elektromagnetická kompatibilita (89/336/EWG),

použité normy: EN 61000-6-2 a EN 61000-6-3.

Prehlásenie o konformite

My firma Grundfos, na svoju plnú zodpovednost’ prehlasujeme, že výrobok R100, na ktorý sa toto
prehlásenie vzt’ahuje, je v súlade s nasledovnými smernicami Rady pre zblíženie právnych predpisov
členských zemí Európskej únie:

– Elektromagnetická kompatibilita (89/336/EWG),

Použité normy: EN 61000-6-2 a EN 61000-6-3.

Uygunluk Bildirgesi

Biz Grundfos olarak, bu beyanda belirtilen R100 ürününün,
– Elektromanyetik uyumluluk (89/336/EEC).

Kullanılan standartlar: EN 61000-6-2 ve EN 61000-6-3.

ile ilgili olarak Avrupa topluluğu'na Üye Devletlerin yasalarında yer alan Belediye Yönetmeliklerine uygun
oldugunu, tüm sorumluluğu bize ait olmak üzere beyan ederiz.

5

Vastavuse deklaratsioon

Meie, Grundfos, deklareerime enda ainuvastutusel, et toode R100, mille kohta käesolev juhend käib, on
vastavuses EL nõukogu Direktiividega EMÜ liikmesriikide seaduste ühitamise kohta, mis käsitlevad:

– Elektromagnetilist ühilduvust (89/336/EEC).

Kasutatud standardid: EN 61000-6-2 ja EN 61000-6-3.

Atitikties deklaracija

Mes, Grundfos, su visa atsakomybe pareiškiame, kad gaminys R100, kuriam skirta ši deklaracija,
atitinka Tarybos Direktyvas dėl Europos Ekonominės Bendrijos šalių narių įstatymų suderinimo šiose
srityse:

– Elektromagnetinis suderinamumas (89/336/EEC).

Naudojami standartai: EN 61000-6-2 ir EN 61000-6-3.

Paziņojums par atbilstību prasībām

Sabiedrība Grundfos ar pilnu atbildību dara zināmu, ka izstrādājums R100, uz kuru attiecas šis
paziņojums, atbilst šādām Padomes direktīvām par tuvināšanos EK dalībvalstu likumdošanas normām:

– Elektromagnētiskā savienojamība (89/336/EEK).

Piemērotie standarti: EN 61000-6-2 un EN 61000-6-3.

Свідчення про відповідність вимогам

Ми, фірма Grundfos, із усією відповідальністю заявляємо, що вироби R100 до яких і відноситься
дане свідоцтво відповідають вимогам наступних указівок Ради ЄЕС про уніфікацію законодавчих
розпоряджень країн-членів ЄЕС:

– Електромагнітна сумісність (89/336/EEC).

Стандарти, що застосовувалися: Євростандарт EN 61000-6-2 і EN 61000-6-3.

Bjerringbro, 1st March 2007

Jan Strandgaard

Technical Director

6

7

R100

Installation and operating instructions 8
Montage- und Betriebsanleitung 18
Notice d'installation et d'entretien 29
Istruzioni di installazione e funzionamento 40
Instrucciones de instalación y funcionamiento 50
Instruções de instalação e funcionamento 61
Οδηγίες εγκατάστασης και λειτουργίας 72
Installatie- en bedieningsinstructies 83
Monterings- och driftsinstruktion 94
Asennus- ja käyttöohjeet 104
Monterings- og driftsinstruktion 114
Instrukcja montażu i eksploatacji 124
Руководство по монтажу и эксплуатации 134
Szerelési és üzemeltetési utasítás 145
Navodila za montažo in obratovanje 155
Montažne i pogonske upute 166
Uputstvo za montažu i upotrebu 177
Instrucţiuni de instalare şi utilizare 187
Упътване за монтаж и експлоатация 197
Montážní a provozní návod 208
Návod na montáž a prevádzku 219
Montaj ve kullanım kılavuzu 230
Paigaldus- ja kasutusjuhend 242
Įrengimo ir naudojimo instrukcija 252
Uzstādīšanas un ekspluatācijas instrukcija 263
Інструкції з монтажу та експлуатації 274

8

CONTENTS

Page

1. General description 8

1.1 Switching on the R100 10

1.2 Switching off the R100 10

2. Setting the R100 10

2.1 Language 11

2.2 Real-time setting 11

2.3 Name and address 11

2.4 Character editor 12

3. Starting the communication 12

4. Menu structure 13

4.1 Menu GENERAL 14

4.2 File structure 15

5. USB connection 16

5.1 Programming the R100 16

5.2 Upgrading of the R100 application software 16

6. Technical data 17

7. Disposal 17

1. General description

The Grundfos R100 remote control is designed for wireless IR communica­tion with Grundfos products.

The functions available depend on the product with which the R100
communicates. See installation and operating instructions for the product in
question.

Read these operating instructions before using the R100 remote
control.

9

Fig. 1 R100 remote control

TM02 4710 1502

Buttons Description

and

Used to navigate in a menu and to change values in
a display.

Only values in framed setting fields can be changed.
and Steps from one menu to the other.
and Moves one display forwa rds or backwards.

Accepts the entered value or function, resets fault indica-

tions, exchanges data between the R100 and the product.

>

>

>

>

OK

+

-

R 100

10

1.1 Switching on the R100

Press to switch on the R100.

Press and the entry display will appear.

Light and contrast in display

In all displays, the light can be switched on or off by simultaneously pressing

and any of the arrow buttons.

If the buttons are not pressed for 2 minutes, the light in the R100 is automat­ically switched off.

The display contrast can be adjusted by simultaneously pressing a nd

or .

1.2 Switching off the R100

Press and simultaneously to switch off the R100.
If the buttons are not pressed for 5 minutes, the R100 is automatically

switched off.

2. Setting the R100

Settings to be made:

• Language

• Real-time setting

• Name and address.

Communication

Contrast

Setting

Light

11

2.1 Language

The R100 has been factory-preset to show texts and data in English.
The user can select any of the supported languages.

If US English is selected, the units of the displayed data will change as
follows:

2.2 Real-time setting

In this display, the real time can be entered.
This entry is only of importance for the function Store status data where

the information will appear in the generated file.

2.3 Name and address

In this display, the name and address can be entered.
This entry is only of importance for the function Store status data where

the information will appear in the generated file.

Measurement

Unit

SI US

Flow [m

3

/h] [US gpm]
Head [m] [ft]
Temperature [°C] [°F]
Specific energy consumption [Wh/m

3

] [Wh/kgal]

12

2.4 Character editor

2.4.1 Tool line

2.4.2 Character list

1. Use or to move one line forwards or backwards in the character list.

2. Use or to move the cursor to the desired character.

3. Accept the desired character with .

3. Starting the communication

Point the R100 at the product and select START with . A red indicator
light on the product will flash rapidly, indicating that communication takes
place.

Note: During the entire communication, the R100 must be pointed at the
product in question.

The data transmission time depends on the amount of data to be transferred,
which differs from product to product.

End of entry

Next text line

Previous text line

Move text cursor to the left

Move text cursor to the right

Delete backwards

Space

Character list

Text line number

Tool line

Text line

13

More than one product?

The R100 can only communicate with one product at a time. If the R100
comes into contact with more than one product, it is necessary to select a
product.

Possible solutions:

• Move the R100 closer to the product i n question and press .

• Hide the line of sight to the product next to the desired product, for exam­ple with your hand, and press .

If the product has already been given a uniq ue number, you can select the
number of the product you want to communicate with.

4. Menu structure

Each product has a specific menu structure.
The functions in the GENERAL menu are common to all products. The main

functions are described on the next pages.
The displays relating to the individual product are described in detail in

the installation and operating instructions for the product in question.

Setting field

The current/last transferred value will appear as light-coloured text on a dark
background.

When values are changed, the text will be dark-coloured on a light back­ground.

When has been pressed and the new data have been transferred to
the product, the text will again be light-coloured.

Continuous display of status values

When is pressed continuously in a display under OPERATION or
STATUS, the displayed value is being updated continuously.

14

4.1 Menu GENERAL

4.1.1 Return to start

4.1.2 Delete all changes

4.1.3 Store settings

4.1.4 Call up settings

Options:

• DELETE: Deletes the selected setting file. A warning appears in the
display.

• USE: Transfers the selected setting file to the product in question
(point at the product).

• RENAME: Renames the selected setting file. The character editor
appears.

• CANCEL: Cancels the operation.

4.1.5 Store status data

Returns to start.
The R100 can now communicate with another product.

Changes the product back to the original setting,
i.e. before communication was started.

Stores the product settings in the R100. The settings
will remain stored as a file (*.set) even if the R100 is
switched off.

Can be used to transfer the factory presetting or stored
product settings in the R100 to the product you com­municate with.

When is pressed, a file (*.txt) is generated.

15

4.1.6 Call up status data

Options:

• DELETE: Deletes the selected status data file. A warning appears in the
display.

• RENAME: Renames the selected status data file. The character editor
appears.

• CANCEL: Cancels the operation.

4.2 File str uct ure

When the R100 is connected to a PC, it will be displayed as "Removable
Disk".

The folder structure is shown in fig. 2. For PC connection via USB connec­tion, see fig. 3.

Fig. 2 Folder structure

Each of the main folders contains the product folders: CU 3, CU 300,
CU 301, E-pump, IO 351, MAGNA, MGE, MP 20 4, Multi-E, U PE, UPS.
Each of the product folders contains the R100 auto-generated files.

Note: The service folder SERVDATA is displayed, but cannot be changed.

Accesses the data files generated by Store status
data.

16

5. USB connection

The USB connection is used for

• transfer of updated application program from a PC to the R100

• transfer of status data files (type *.txt) and setting files (type *.set) from
the R100 to the PC.

When the status data files have been transferred to the PC via the USB con­nection, the data can be displayed, examined and organised by any text
processing software and be printed on any printer.

Fig. 3 Connection to P C via USB connection

5.1 Programming the R100

If "Unknown product" appears in the R100 display during communication
with a product, the R100 must be upgraded with a new application software
version. To get the new software, please contact Grundfos.

5.2 Upgrading of the R100 application software

1. Switch off the R100.

2. Connect the R100 to the PC via the USB cable.

3. Press all four arrow buttons and s imultaneously. The R100 will then

be switched on and open in "Programming mode" showing the message
"USB link established". In a Windows browser, it will appear as
"Removable Disk" and the application program file (type *.mk2) will
appear.

4. Delete the application program file. "Device busy" appears in the R100

display during the deletion, which takes 30 seconds. After the deletion,
"USB link established" appears in the R10 0 displa y.

5. Copy the new application program file to "Removable Disk". "Device

busy" appears in the R100 display during the file transfer, which takes
approximately 50 seconds. After the file transfer, "Device safe to remove"
appears in the R100 display.

6. Perform a safe removal of the R100 USB connection.

The R100 display will show "Application program download comp lete".
This will take 5 to 10 seconds. The update procedure has now been
successfully completed.

Type A

Type B

mini

USB

17

7. Press and simultaneously to switch off the R100.

8. Switch on the R100. After start-up, the R100 updates its file structure for
the new application software. This takes approximately 45 seconds.
"Updated successfully" appears in the display.

6. Technica l da ta

Ambient temperature

–10°C to +50°C during operation.
–20°C to +60°C during storage.

Relative air humidity

Maximum 95%.

Voltage supply

2 batteries, 1.5 V, type AA.

Enclosure class

IP 40.

IR communication

Reach: Minimum 3 metres.
Transmission angle: ±12°.

Batteries

During battery replacement, the R100 will store its settings (Language, R eal­time setting, Name and address, d isplay contrast) for a t least 10 m inutes.

Low-battery indicator.

7. Disposal

This product or parts of it must be disposed of in an environmentally sound
way:

1. Use the public or private waste collection service.

2. If this is not possible, contact the nearest Grundfos company or service
workshop.

Subject t o alte ra tion s.

285

286

1. OPERATION0. GENERAL

GRUNDFOS MAGNA is shown as an example.

287

3. INSTALLATION2. STATUS

288

289

290

Denmark

GRUNDFOS DK A/S
Tlf.: [phone]
E-mail:
[e-mail]
www.grundfos.com/DK

Argentina

Bombas GRUNDFOS de
Argentina S.A.
Phone: [phone]
Telefax: [phone]

Australia

GRUNDFOS Pumps Pty. Ltd.
Phone: [phone]
Telefax: [phone]

Austria

GRUNDFOS Pumpen
Vertrieb Ges.m.b.H.
Tel.: [phone]
Telefax: [phone]

Belgium

N.V. GRUNDFOS Bellux S.A.
Tél.: [phone]
Télécopie: [phone]

Belorussia

Представительство
ГРУНДФОС в Минске
Телефо н: [phone]
Факс: [phone]

Bosnia/Herzegovina

GRUNDFOS Sarajevo
Phone: [phone]
Telefax: [phone]

Brazil

GRUNDFOS do Brasil Ltda.
Phone: [phone]
Telefax: [phone]

Bulgaria

GRUNDFOS Pumpen
Vertrieb
Phone: [phone],
2963 5653
Telefax: [phone]

Canada

GRUNDFOS Canada Inc.
Phone: [phone]
Telefax: [phone]

China

GRUNDFOS Pumps
(Shanghai) Co. Ltd.
Phone: [phone]
Telefax: [phone]

Croatia

GRUNDFOS predstavništvo
Zagreb
Phone: [phone]
Telefax: [phone]

Czech Republic

GRUNDFOS s.r.o.
Phone: [phone]
Telefax: [phone]

Estonia

GRUNDFOS Pumps Eesti
OÜ
Tel: + 372 606 1690
Fax: + 372 606 1691

Finland

OY GRUNDFOS Pumput AB
Phone: [phone]
Telefax: [phone]

France

Pompes GRUNDFOS
Distribution S.A.
Tél.: [phone]
Télécopie: [phone]

Germany

GRUNDFOS GMBH
Tel.: [phone]
e-mail:
[e-mail]
Service in Deutschland:
e-mail:
[e-mail]

Greece

GRUNDFOS Hellas A.E.B.E.
Phone: [phone]
Telefax: +0030-210-66 46
273

Hong Kong

GRUNDFOS Pumps (Hong
Kong) Ltd.
Phone: [phone]/
27861741
Telefax: [phone]

Hungary

GRUNDFOS Hungária Kft.
Phone: [phone]
Telefax: [phone]

India

GRUNDFOS Pumps India
Private Limited
Phone: [phone]

Indonesia

PT GRUNDFOS Pompa
Phone: [phone]
Telefax: [phone]/
460 6901

Ireland

GRUNDFOS (Ireland) Ltd.
Phone: [phone]
Telefax: [phone]

Italy

GRUNDFOS Pompe Italia
S.r.l.
Tel.: [phone]
Telefax: [phone]/
95838461

Japan

GRUNDFOS Pumps K.K.
Phone: [phone]
Telefax: [phone]

Korea

GRUNDFOS Pumps Korea
Ltd.
Phone: [phone]
Telefax: [phone]

Latvia

SIA GRUNDFOS Pumps
Latvia
Tālr.: + 371 714 9640, 7 149
641
Fakss: + 371 914 9646

Lithuania

GRUNDFOS Pumps UAB
Tel: + 370 52 395 430
Fax: + 370 52 395 431

Malaysia

GRUNDFOS Pumps Sdn.
Bhd.
Phone: [phone]
Telefax: [phone]

México

Bombas GRUNDFOS de
México S.A. de C.V.
Phone: [phone]
Telefax: [phone]

Netherlands

GRUNDFOS Nederland B.V.
Tel.: [phone]
Telefax: [phone]/
492299

New Zealand

GRUNDFOS Pumps NZ Ltd.
Phone: [phone]
Telefax: [phone]

Norway

GRUNDFOS Pumper A/S
Tlf.: [phone]
Telefax: [phone]

Poland

GRUNDFOS Pompy Sp. z
o.o.
Phone: [phone]
Telefax: ([phone]

Portugal

Bombas GRUNDFOS
Portugal, S.A.
Tel.: [phone]
Telefax: [phone]

România

GRUNDFOS Pompe
România SRL
Phone: [phone]
E-mail: [e-mail]

Russia

ООО Гру ндфос
Тел. [phone], 564

88 00
E-mail
grundfos.moscow@grundfos.
com

Serbia

GRUNDFOS Predstavništvo
Beograd
Phone: [phone],
11 26 47 496
Telefax: [phone]

Singapore

GRUNDFOS (Singapore)
Pte. Ltd.
Phone: [phone]
Telefax: [phone]

Slovenia

GRUNDFOS PUMPEN VER­TRIEB Ges.m.b.H.,
Phone: [phone]
Telefax: [phone]

Spain

Bombas GRUNDFOS
España S.A.
Tel.: [phone]
Telefax: [phone]

Sweden

GRUNDFOS AB
Tel.: [phone]
Telefax: [phone]

Switzerland

GRUNDFOS Pumpen AG
Tel.: [phone]
Telefax: [phone]

Taiwan

GRUNDFOS Pumps (Taiwan)
Ltd.
Phone: [phone]
Telefax: [phone]

Thailand

GRUNDFOS (Thailand) Ltd.
Phone: [phone] ... 91
Telefax: [phone] ... 6

Turkey

GRUNDFOS POMPA San. ve
Tic. Ltd. Sti.
Phone: +90 - 262-679 7979
Telefax: +90 - 262-679 7905
E-mail: [e-mail]

Ukraine

ТОВ ГРУНДФОС Украина
Тел. [phone]
Факс [phone]

United Arab Emirates

GRUNDFOS Gulf Distribution
Phone: [phone]
Telefax: [phone]

United Kingdom

GRUNDFOS Pumps Ltd.
Phone: [phone]
Telefax: [phone]

U.S.A.

GRUNDFOS Pumps
Corporation
Phone: [phone]
Telefax: [phone]

Usbekistan

Представительство
ГРУНДФОС в Ташкен те
Телеф он: [phone]
Факс: [phone]

Addresses revised 10.01.2007

Being responsible is our foundation

Thinking ahead makes it possible

Innovation is the essence

www.grundfos.com

96692345 0307

186

L- EA-TL-00 1

03/07 (US)
