MODEL G0714

35" X 48" INDUSTRIAL

BLAST CABINET

OWNER'S MANUAL

(For models manufactured since 03/24)

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#CR1339 9 PRINTED IN CHINA

***Keep for Future Reference***

V5.05.24

This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators.

Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

The owner of this machine/tool is solely responsible for its safe use. This responsibility includes but is not limited to proper installation in a safe environment, personnel training and usage authorization, proper inspection and maintenance, manual availability and comprehension, application of safety devices, cutting/sanding/grinding tool integrity, and the usage of personal protective equipment.

The manufacturer will not be held liable for injury or property damage from negligence, improper training, machine modifications or misuse.

Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:

• Lead from lead-based paints.

• Crystalline silica from bricks, cement and other masonry products.

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: Work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles.

Table of Contents

INTRODUCTION ............................................................................................................................... 2

Manual Accuracy Contact Info Machine Description Identification Machine Data Sheet

.........................................................................................................................2

.................................................................................................................................2

....................................................................................................................2

................................................................................................................................3

....................................................................................................................4

SECTION 1: SAFETY

Safety Instructions for Machinery Additional Safety for Blast Cabinets

SECTION 2: POWER SUPPLY

SECTION 3: SETUP

Needed for Setup Unpacking Inventory Site Considerations Mounting Air System Setup Pneumatic Diagram Assembly Test Run

SECTION 4: OPERATIONS

Preparation Basic Operation Operation Tips Blasting Media

SECTION 5: ACCESSORIES

.................................................................................................................................11

....................................................................................................................................12

....................................................................................................................................14

...................................................................................................................................17

....................................................................................................................................21

................................................................................................................................23

....................................................................................................................... 6

........................................................................................................................11

......................................................................................................................11

...................................................................................................................13

......................................................................................................................15

...................................................................................................................16

............................................................................................................ 23

.........................................................................................................................24

...........................................................................................................................25

...........................................................................................................................26

......................................................................................................... 29

................................................................................................6

............................................................................................8

........................................................................................................ 9

SECTION 6: MAINTENANCE

Schedule Cleaning

SECTION 7: SERVICE

Troubleshooting Filter Replacement Motor Brush Replacement LED Replacement

SECTION 8: WIRING

Wiring Safety Instructions Wiring Diagram Wiring Components

SECTION 9: PARTS

Blast Cabinet Stand & Cabinet Base Labels & Cosmetics

WARRANTY & RETURNS

...................................................................................................................................30

....................................................................................................................................30

................................................................................................................... 31

.........................................................................................................................31

....................................................................................................................32

.....................................................................................................................36

...................................................................................................................... 38

.........................................................................................................................39

...................................................................................................................40

....................................................................................................................... 41

.............................................................................................................................41

...............................................................................................................43

..................................................................................................................44

.............................................................................................................. 45

........................................................................................................ 30

........................................................................................................33

.........................................................................................................38

INTRODUCTION

We stand behind our machines! If you have questions or need help, contact us with the information below. Before contacting, make sure you get the

serial number

from the

machine ID label. This will help us help you faster.

We want your feedback on this manual. What did you like about it? Where could it be improved? Please take a few minutes to give us feedback.

Email: manuals@grizzly.com

We are proud to provide a high-quality owner’s manual with your new machine!

instructions, specifications, drawings, and photographs in this manual. Sometimes we make mistakes, but our policy of continuous improvement also means that

you receive is

slightly different than shown in the manual

If you find this to be the case, and the difference between the manual and machine leaves you confused or unsure about something

check our

website for an updated version. W

current

manuals and

on our web-

site at

Alternatively, you can call our Technical Support for help. Before calling, make sure you write down the

serial number

from the machine ID label (see below). This information is required for us to provide proper tech support, and it helps us determine if updated documentation is available for your machine.

Manual Accuracy

made every effort to be exact with the

sometimes the machine

www.grizzly.com.

manual updates for free

manufacture date and

e post

Contact Info

and manufacture date

Grizzly Technical Support

1815 W. Battlefield

Springfield, MO 65807 Phone: (570) 546-9663

Email: techsupport@grizzly.com

Grizzly Documentation Manager

P.O. Box 2069

Bellingham, WA 98227-2069

Manufacture Date

Serial Number

Machine Description

This blast cabinet is designed for high-use media blasting operations, where airflow up to 35 CFM and air pressure up to 125 PSI can be used. Air pressure is fully adjustable with an air pressure regulator, and the media output can be adjusted with the media flow valve. Blasting operations through a hand-held blast gun are controlled by a foot valve, and most operations can be carried out with all types of blasting media.

An internal set of LED lights provide illumination during blasting operations, and a built-in dust collector maintains blasting environment visibility. The front of the cabinet is equipped with a large gas-assisted folding door for easy workpiece loading and unloading. Media can be quickly unloaded through the hopper dump port and reloaded through the loading door.

-2-

Model G0714 (Mfd. Since 03/24)

Identification

F G

A. Viewing Window B. Gas-Assisted Door Support System C. DUST COLLECTOR ON/OFF Switch D. LIGHT ON/OFF Switch E. Filter Cleaning Plunger F. Dust Collector G. LED Light Assembly

H. Fresh Air Intake Port I. Hopper Dump Port J. Dust Collector Dump Port K. Loading Door L. Foot Valve for Blast Gun Control M. Air Regulator w/Gauge N. Blasting Gloves

Model G0714 (Mfd. Since 03/24)

-3-

Machine Data Sheet

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G0714

35" X 48" INDUSTRIAL BLAST CABINET

Product Dimensions:

Weight ............................................................................................................................................................................ 352 lbs.

Width (side-to-side) x Depth (front-to-back) x Height ........................................................................... 51-1/2 x 47 x 69-1/2 in.

Footprint (Length x Width) ...................................................................................................................................24 x 47-1/2 in.

Shipping Dimensions:

Type ........................................................................................................................................................................... Wood Box

Content .......................................................................................................................................................................... Machine

Weight ............................................................................................................................................................................ 436 lbs.

Length x Width x Height .....................................................................................................................................53 x 38 x 42 in.

Electrical:

Power Requirement ........................................................................................................................ 110V, Single-Phase, 60 Hz

Full-Load Current Rating ...................................................................................................................................................... 11A

Minimum Circuit Size ........................................................................................................................................................... 15A

Connection Type ..................................................................................................................................................... Cord & Plug

Power Cord Included ............................................................................................................................................................Yes

Power Cord Length ............................................................................................................................................................72 in.

Power Cord Gauge .......................................................................................................................................................14 AWG

Plug Included ........................................................................................................................................................................Yes

Included Plug Type ..............................................................................................................................................................5-15

Switch Type ..............................................................................................................................Sealed ON/OFF Rocker Switch

Number of Lights .......................................................................................................................................................................3

Lighting Type ................................................................................................................................................... 18W LED, 36 in.

Motors:

Main

Horsepower .................................................................................................................................................................. 1-1/2 HP

Phase .................................................................................................................................................................... Single-Phase

Amps .................................................................................................................................................................................... 11A

Type .............................................................................................................................................................................Universal

Power Transfer ................................................................................................................................................................. Direct

Bearings ............................................................................................................................. Shielded & Permanently Lubricated

Main Specifications:

Operation Information

Suggested Operating Air Pressure Range ................................................................................................... 60 - 125 PSI

Maximum Air Pressure .........................................................................................................................................125 PSI

Recommended Air Supply .............................................................................................................................. 5 - 35 CFM

Maximum Abrasive Capacity ................................................................................................................................ 250 lbs.

Suggested Abrasive Capacity ................................................................................................................................55 lbs.

Abrasive Type .....................................................................................................................................................Dry Only

Load & Unload Access ............................................................................................................................................. Front

Maximum Load Capacity ...................................................................................................................................... 132 lbs.

Design Type ..............................................................................................................................................................Floor

Blast Compartment Door ................................................................................................ 37-1/2 in. Wide x 29-1/4 in. Tall

-4-

Model G0714 (Mfd. Since 03/24)

Dust Collector Filter Information

Dimensions .......................................................................................................................................6-3/4" Dia. x 12" Tall

Type .......................................................................................................................................................................Pleated

Rating ................................................................................................................................................................ 5 Microns

Construction Information

Body ........................................................................................................................................ Welded Heavy-Duty Steel

Paint Type/Finish ...................................................................................................................................... Powder Coated

Other Specifications:

Country of Origin ............................................................................................................................................................... China

Warranty ........................................................................................................................................................................... 1 Year

Serial Number Location ................................................................................................................................................ ID Label

Assembly Time ......................................................................................................................................................... 60 Minutes

Features:

Front-Loading Door Natural Rubber/Vinyl Blast Gloves Blast Gun Includes 4 Ceramic Tips Perforated Steel Work Table Powder Coated Inside and Out 12-Gauge Steel Legs (16-Gauge Panels) Extra-Rugged, Heavy-Duty Foot Valve Assembly Internal LED Lighting System

Model G0714 (Mfd. Since 03/24)

-5-

SECTION 1: SAFETY

For Your Own Safety, Read Instruction

Manual Before Operating This Machine

The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words intended to convey the level of importance of the safety messages. The progression of symbols is described below. Remember that safety messages by themselves do not eliminate danger and are not a substitute for proper accident prevention measures. Always use common sense and good judgment.

Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury. It may also be used to alert against unsafe practices.

Alerts the user to useful information about proper operation of the

NOTICE

machine to avoid machine damage.

Safety Instructions for Machinery

OWNER’S MANUAL. Read and understand this

owner’s manual BEFORE using machine.

TRAINED OPERATORS ONLY. Untrained operators have a higher risk of being hurt or killed. Only allow trained/supervised people to use this machine. When machine is not being used, disconnect power, remove switch keys, or lock-out machine to prevent unauthorized use—especially around children. Make your workshop kid proof!

DANGEROUS ENVIRONMENTS. Do not use machinery in areas that are wet, cluttered, or have poor lighting. Operating machinery in these areas greatly increases the risk of accidents and injury.

MENTAL ALERTNESS REQUIRED. Full mental alertness is required for safe operation of machinery. Never operate under the influence of drugs or alcohol, when tired, or when distracted.

ELECTRICAL EQUIPMENT INJURY RISKS. You can be shocked, burned, or killed by touching live electrical components or improperly grounded machinery. To reduce this risk, only allow qualified service personnel to do electrical installation or repair work, and always disconnect power before accessing or exposing electrical equipment.

DISCONNECT POWER FIRST. nect machine from power supply BEFORE making adjustments, changing tooling, or servicing machine. This prevents an injury risk from unintended startup or contact with live electrical components.

EYE PROTECTION. Always wear ANSI-approved safety glasses or a face shield when operating or observing machinery to reduce the risk of eye injury or blindness from flying particles. Everyday eyeglasses are NOT approved safety glasses.

Always discon-

-6-

Model G0714 (Mfd. Since 03/24)

may damage the wires inside. Do not handle

WEARING PROPER APPAREL. Do not wear loose clothing, gloves, neckties, or jewelry that can become entangled in moving parts. Always tie back or cover long hair. Wear non-slip footwear to reduce risk of slipping and losing control or accidentally contacting cutting tool or moving parts.

HAZARDOUS DUST. Dust created by machinery operations may cause cancer, birth defects, or long-term respiratory damage. Be aware of dust hazards associated with each workpiece material. Always wear a NIOSH-approved respirator to reduce your risk.

HEARING PROTECTION. Always wear hearing protection when operating or observing loud machinery. Extended exposure to this noise without hearing protection can cause permanent hearing loss.

REMOVE ADJUSTING TOOLS. Tools left on machinery can become dangerous projectiles upon startup. Never leave chuck keys, wrenches, or any other tools on machine. Always verify removal before starting!

USE CORRECT TOOL FOR THE JOB. Only use this tool for its intended purpose—do not force it or an attachment to do a job for which it was not designed. Never make unapproved modifications—modifying tool or using it differently than intended may result in malfunction or mechanical failure that can lead to personal injury or death!

AWKWARD POSITIONS. Keep proper footing and balance at all times when operating machine. Do not overreach! Avoid awkward hand positions that make workpiece control difficult or increase the risk of accidental injury.

CHILDREN & BYSTANDERS. Keep children and bystanders at a safe distance from the work area. Stop using machine if they become a distraction.

GUARDS & COVERS. Guards and covers reduce accidental contact with moving parts or flying debris. Make sure they are properly installed, undamaged, and working correctly BEFORE operating machine.

FORCING MACHINERY. Do not force machine. It will do the job safer and better at the rate for which it was designed.

NEVER STAND ON MACHINE. Serious injury may occur if machine is tipped or if the cutting tool is unintentionally contacted.

STABLE MACHINE. Unexpected movement during operation greatly increases risk of injury or loss of control. Before starting, verify machine is stable and mobile base (if used) is locked.

USE RECOMMENDED ACCESSORIES. Consult

this owner’s manual or the manufacturer for rec-

ommended accessories. Using improper accessories will increase the risk of serious injury.

UNATTENDED OPERATION. To reduce the risk of accidental injury, turn machine OFF and ensure all moving parts completely stop before walking away. Never leave machine running while unattended.

MAINTAIN WITH CARE. Follow all maintenance instructions and lubrication schedules to keep machine in good working condition. A machine that is improperly maintained could malfunction, leading to serious personal injury or death.

DAMAGED PARTS. Regularly inspect machine for damaged, loose, or mis-adjusted parts—or any condition that could affect safe operation. Immediately repair/replace BEFORE operating machine. For your own safety, DO NOT operate machine with damaged parts!

MAINTAIN POWER CORDS. When disconnecting cord-connected machines from power, grab and pull the plug—NOT the cord. Pulling the cord

cord/plug with wet hands. Avoid cord damage by keeping it away from heated surfaces, high traffic areas, harsh chemicals, and wet/damp locations.

EXPERIENCING DIFFICULTIES. If at any time you experience difficulties performing the intended operation, stop using the machine! Contact our Technical Support at (570) 546-9663.

Model G0714 (Mfd. Since 03/24)

-7-

Additional Safety for Blast Cabinets

PERSONAL PROTECTION EQUIPMENT.

Media blasting presents a real hazard of silicosis and other lung contamination injuries! These injuries are permanent and can get worse over time. If you use media blasting equipment without the proper hood, eye protection, and respirator, your lungs and eyes may become permanently damaged. Protect yourself correctly, and keep all unprotected bystanders away. For the latest types of protective equipment and acceptable respirator types, contact your local OSHA or NIOSH office.

WORK AREA SAFETY. To prevent accidental contamination of shop air, clean dust collector and filters often, and repair any suction hose leaks immediately.

MAINTAINING MACHINE. To pr e v e nt accidental contamination of shop air, check the blast cabinet for any leaks before use, and reseal immediately.

AVOIDING ENTRAPMENT. To prevent an entrapment hazard for animals or children, always close and latch the blast cabinet door when not in use.

LEAVING THE AREA. To prevent accidental blasting injury, disconnect air supply when leaving the blast cabinet.

MAINTAINING COMPONENTS. To prevent accidental contamination or blast injury, replace tips, hoses, lenses, and gloves when they become worn.

SAFE MEDIA BLASTING. Do not use system over the rated PSI or lines and seals may burst and cause injury.

SAFE MAINTENANCE. To prevent accidental blasting injury or shock, disconnect air supply and power before loading and unloading a workpiece, and before doing maintenance or changing blast tips.

SAFE ENVIRONMENT. To avoid media escaping from the cabinet, never use the blast cabinet if the dust collector is OFF or its filter is clogged. If you do, media will exit through the cabinet air intake and enter the shop work environment. Always close and latch the blast cabinet door shut before and after operation.

Like all machinery there is potential danger when operating this machine. Accidents are frequently caused by lack of familiarity or failure to pay attention. Use this machine with respect and caution to decrease the risk of operator injury. If normal safety precautions are overlooked or ignored, serious personal injury may occur.

-8-

No list of safety guidelines can be complete. Every shop environment is different. Always consider safety first, as it applies to your individual working conditions. Use this and other machinery with caution and respect. Failure to do so could result in serious personal injury, damage to equipment, or poor work results.

Model G0714 (Mfd. Since 03/24)

SECTION 2: POWER SUPPLY

Before installing the machine, consider the availability and proximity of the required power supply circuit. If an existing circuit does not meet the requirements for this machine, a new circuit must be installed. To minimize the risk of electrocution, fire, or equipment damage, installation work and electrical wiring must be done by an electrician or qualified service personnel in accordance with all applicable codes and standards.

or equipment damage

not properly grounded

The full-load current rating is the amperage a machine draws at 100% of the rated output power. On machines with multiple motors, this is the amperage drawn by the largest motor or sum of all motors and electrical devices that might operate at one time during normal operations.

The full-load current is not the maximum amount of amps that the machine will draw. If the machine is overloaded, it will draw additional amps beyond the full-load rating.

If the machine is overloaded for a sufficient length of time, damage, overheating, or fire may result— especially if connected to an undersized circuit. To reduce the risk of these hazards, avoid overloading the machine during operation and make sure it is connected to a power supply circuit that meets the specified circuit requirements.

This machine is prewired to operate on a power supply circuit that has a verified ground and meets the following requirements:

For your own safety and protection of

Note: Circuit requirements in this manual apply to

a dedicated circuit—where only one machine will be running on the circuit at a time. If machine will be connected to a shared circuit where multiple machines may be running at the same time, consult an electrician or qualified service personnel to ensure circuit is properly sized for safe operation.

A power supply circuit includes all electrical equipment between the breaker box or fuse panel in the building and the machine. The power supply circuit used for this machine must be sized to safely handle the full-load current drawn from the machine for an extended period of time. (If this machine is connected to a circuit protected by fuses, use a time delay fuse marked D.)

Availability

Electrocution, fire, shock,

may occur if machine is

and connected to power supply.

Full-Load Current Rating

Circuit Requirements

Nominal Voltage .................... 110V, 115V, 120V

..........................................................60 Hz

Cycle Phase Minimum Circuit Size

........................................... Single-Phase

......................... 15 Amps

property, consult an electrician if you are unsure about wiring practices or electrical codes in your area.

Full-Load Current Rating at 110V ..... 11 Amps

Model G0714 (Mfd. Since 03/24)

-9-

Improper connection of the equipment-grounding wire can result in a risk of electric shock. The wire with green insulation (with or without yellow stripes) is the equipment-grounding wire. If repair or replacement of the power cord or plug is necessary, do not connect the equipment-grounding wire to a live (current carrying) terminal.

Check with a qualified electrician or service personnel if you do not understand these grounding requirements, or if you are in doubt about whether the tool is properly grounded. If you ever notice that a cord or plug is damaged or worn, disconnect it from power, and immediately replace it with

We do not recommend using an extension cord with this machine. If you must use an extension cord, only use it if absolutely necessary and only on a temporary basis.

Extension cords cause voltage drop, which can damage electrical components and shorten motor life. Voltage drop increases as the extension cord size gets longer and the gauge size gets smaller (higher gauge numbers indicate smaller sizes).

Any extension cord used with this machine must be in good condition and contain a ground wire and matching plug/receptacle. Additionally, it must meet the following size requirements:

Grounding & Plug Requirements

This machine is equipped with a power cord that has an equipment-grounding wire and a grounding plug. Only insert plug into a matching receptacle (outlet) that is properly installed and grounded in accordance with all local codes and ordinances. DO NOT modify the provided plug!

Serious injury could occur if you connect

process. DO NOT connect to power until

Two-prong outlets do not meet the grounding requirements for this machine.

provided—if it will not fit the outlet, have a

machine to power before completing setup

instructed later in this manual.

GROUNDED

5-15 RECEPTACLE

Grounding Pin

Extension Cords

5-15 PLUG

Neutral Hot

Figure 1. Typical 5-15 plug and receptacle.

SHOCK HAZARD!

Do not modify or use an adapter on the plug

qualified electrician install the proper outlet with a verified ground.

-10-

Minimum Gauge Size ........................... 14 AWG

Maximum Length (Shorter is Better)

Model G0714 (Mfd. Since 03/24)

.......50 ft.

SECTION 3: SETUP

This machine was carefully packaged for safe transport. When unpacking, separate all enclosed items from packaging materials and inspect them for shipping damage.

please

IMPORTANT: Save all packaging materials until you are completely satisfied with the machine and have resolved any issues between Grizzly or the shipping agent. You MUST have the original pack-

aging to file a freight claim. It is also extremely helpful if you need to return your machine later.

The following items are needed, but not included, for the setup/assembly of this machine.

This machine presents serious injury hazards to untrained users. Read through this entire manual to become familiar with the controls and operations before starting the machine!

Wear safety goggles during the entire setup process!

Needed for Setup

Description Qty

• Safety Goggles ........................................... 2

• Leather Gloves ....................................2-Pair

• Wrench 17mm ............................................ 1

• Ratchet ....................................................... 1

• Socket 10mm .............................................. 1

• An Assistant ............................................... 1

• Phillips Screwdriver #2 ............................... 1

• Fast Drying Silicone Sealant ...................... 1

Unpacking

HEAVY LIF T! Straining or crushing injury may occur from improperly lifting machine or some of its parts. To reduce this risk, get help from other people and use a forklift (or other lifting equipment) rated for weight of this machine.

If items are damaged

call us immediately at (570) 546-9663.

Model G0714 (Mfd. Since 03/24)

-11-

Inventory

The following is a list of items shipped with your machine. Before beginning setup, lay these items out and inventory them.

If any non-proprietary parts are missing (e.g. a nut or a washer), we will gladly replace them; or for the sake of expediency, replacements can be obtained at your local hardware store.

Inventory (Figures 2–3) Qty

A. Blast Cabinet Assembly ............................. 1

B. Dust Collector ............................................. 1

C. Left Work Table .......................................... 1

D. Right Work Table ........................................ 1

E. Hopper Support .......................................... 1

F. Hopper ........................................................ 1

G. Legs ............................................................ 4

H. Light Window Adhesive Film 351⁄2 " x 10" ... 5

I. Viewing Window Film 26" x 12" .................. 5

J. Blast Tip Set ............................................... 1

—Blast Tip 6mm ID

— Blast Tip 7mm ID .................................... 2

K. Teflon Tape (Pipe Fittings) .......................... 1

L. Regulator & Foot Valve w/Hoses ............... 1

M. Leg Supports (43 3⁄4") ................................. 2

N. Leg Supports (32 1⁄4") ................................. 2

O. Bolt Bag ...................................................... 1

—Hex Bolts M8-1.25 x 20 (Stand)

— Flat Washers 8mm (Stand) ................... 32

— Lock Washers 8mm (Stand) ................. 32

— Hex Nuts M8-1.25 (Stand) .................... 16

—Phillips Head Screws M6-1 x 16

(Hopper)

— Flat Washers 6mm (Hopper) ................ 22

—Cabinet Screws M6-1 x 12 (Regulator)

— Flange Nuts M6-1 (Regulator) ................ 2

—Cabinet Screws M6-1 x 12

(Dust Collector) ....................................... 4

— Flange Nuts M6-1 (Dust Collector) ......... 4

................................................ 22

.................................... 2

........... 32

.. 2

Figure 2. Main inventory.

Figure 3. Small items inventory.

NOTICE

If you cannot find an item on this list, carefully check around/inside the machine and packaging materials. Often, these items get lost in packaging materials while unpacking or they are pre-installed at the factory.

-12-

Model G0714 (Mfd. Since 03/24)

Site Considerations

Weight Load

Refer to the of your machine. Make sure that the surface upon which the machine is placed will bear the weight of the machine, additional equipment that may be installed on the machine, and the heaviest workpiece that will be used. Additionally, consider the weight of the operator and any dynamic loading that may occur when operating the machine.

Space Allocation

Consider the largest size of workpiece that will be processed through this machine and provide enough space around the machine for adequate operator material handling or the installation of auxiliary equipment. With permanent installations, leave enough space around the machine to open or remove doors/covers as required by the maintenance and service described in this manual.

See below for required space allocation.

Physical Environment

The physical environment where the machine is operated is important for safe operation and longevity of machine components. For best results, operate this machine in a dry environment that is free from excessive moisture, hazardous chemicals, airborne abrasives, or extreme conditions. Extreme conditions for this type of machinery are generally those where the ambient temperature range exceeds 41°–104°F; the relative humidity range exceeds 20%–95% (non-condensing); or the environment is subject to vibration, shocks,

Place this machine near an existing power source. Make sure all power cords are protected from traffic, material handling, moisture, chemicals, or other hazards. Make sure to leave enough space around machine to disconnect power supply or

Lighting around the machine must be adequate enough that operations can be performed safely. Shadows, glare, or strobe effects that may distract or impede the operator must be eliminated.

Machine Data Sheet for the weight

or bumps.

Electrical Installation

Children or untrained people may be seriously injured by this machine. Only install in an access restricted location.

Air

Supply

12"

Min.

Fresh Air Input

apply a lockout/tagout device, if required.

Lighting

Wall

Dust

Collector

Air Output

53"

Min.

Power Supply

24"

Min.

48"

Model G0714 (Mfd. Since 03/24)

Figure 4. Working clearances.

-13-

Mounting

Although not required, we recommend that you mount your new machine to the floor. Because this is an optional step and floor materials may vary, floor mounting hardware is not included. Generally, you can either bolt your machine to the floor or mount it on machine mounts. Both options are described below. Whichever option you choose, we recommend leveling your machine with a precision level placed on the table surface.

Bolting to Concrete Floors

Lag shield anchors with lag screw and anchor studs (see Figure 5) are two popular methods for anchoring an object to a concrete floor. We suggest you research the many options and methods for mounting your machine and choose the best that fits your specific application.

Using Machine Mounts

Using machine mounts, shown in Figure 6, gives the advantage of fast leveling and vibration reduction. The large size of the foot pads distributes the weight of the machine to reduce strain on the floor.

Figure 6. Machine mount example.

Anchor Stud

Lag Shield Anchor

and Lag Screw

Figure 5. Typical fasteners for mounting to

concrete floors.

NOTICE

Anchor studs are stronger and more permanent alternatives to lag shield anchors; however, they will stick out of the floor, which may cause a tripping hazard if you decide to move your machine.

NOTICE

We strongly recommend securing your machine to the floor if it is hardwired to the power source. Consult with your electrician to ensure compliance with local codes.

-14-

Model G0714 (Mfd. Since 03/24)

Air System Setup

Air Supply

The ability of this blast cabinet to accomplish its task is directly related to how well the air supply system is designed. For this blast cabinet to operate at its maximum potential for large blasting jobs, with the largest blast tip and widest spray pattern, the volume of compressed air feeding the regulator should be 35 CFM at 125 PSI. This requirement demands an industrial grade twostage compressor that is designed for near continuous duty.

Refer to your compressor Owner’s Manual and

make sure that the compressor can handle the load of this industrial blast cabinet. Smaller compressors can be used, but the duration of the work shift and tip size installed must be reduced so a safe compressor duty cycle is maintained. Not allowing the compressor to cool will lead to compressor or motor failure. The smaller the compressor, the longer cool-down time that will be required between the work cycles. However, with that said, if a smaller diameter blast tip is used with a sharp type of media, less air pressure and a lower CFM can be sufficient for smaller projects.

If using smaller compressors, make sure to service the compressor more frequently, and verify that your compressor has the best cooling airflow possible.

When filling or servicing the blast cabinet, there is a risk of subjecting the compressor to airborne media or dust. Be sure to locate the blast cabinet away from the compressor operating environment. If even small amounts of media dust enter the compressor through the intake or during general service, the piston rings, valves, and bearings can be quickly destroyed.

If an air compressor is not available or the blast cabinet is to be used at a remote location, NEVER connect this blast cabinet to pressurized bottled gasses such as oxygen bottles used in welding operations. Line ruptures or explosions can occur, causing equipment damage, serious injury, or death.

Air Plumbing

Usually, when installing a new supply line for a blast cabinet where the complete system does not exceed 125 feet, the inside diameter of the air line should be line with a 1" inside diameter is recommended. Be sure to make the supply line long enough to allow the compressed air to cool as much as possible, so the moisture vapors can condensate on the inner walls of the air line instead of accumulating in the blast cabinet or the media.

Install the air supply lines with a slight tilt back towards the compressor tank, so the moisture that accumulates from condensation will drain back into the compressor tank instead of puddling in the low areas of the air lines. Install one or more in-line water separators or an air dryer as close to the blast cabinet as possible where the air has had the most time to cool. Water separators typically work best on cool air rather than on hot air that comes right out of the compressor tank.

For an overview of the typical air system for this blast cabinet and its supply system, refer to the Pneumatic Diagram on Page 16.

If using an existing air system, eliminate air supply restrictions and pressure drops that may occur at small quick-disconnect fittings, elbows, small supply piping, undersized water separators, kinked lines, or rust-filled piping.

Remove any in-line oilers that are installed directly in the blast cabinet air supply line, or the media and blast cabinet will become contaminated with oil and blasting operations will quickly come to a halt. Air supply lines for other machines that have in-line oilers need not be removed, providing that these lines only feed from the blast cabinet supply line.

Make sure to install an air supply quick-disconnect fitting or a shut-off valve that can be locked out to prevent the air pressure from accidentally being turned on. These items allow for the blast cabinet to be serviced safely or allow it to sit idle when not in use.

⁄4". For runs up to 300', a supply

Model G0714 (Mfd. Since 03/24)

-15-

Two-Stage

Air Compresssor

Pneumatic Diagram

WARNING!

DISCONNECT THE AIR SUPPLY BEFORE ADJUSTMENTS, MAINTENANCE, OR SERVICE.

Blast Cabinet

Blast Gun

-16-

Dedicated Media Blasting

Air Dryer System

Blast Cabinet Air Regulator

Blast Cabinet

Foot Valve

Cabinet Hopper

with Media

Model G0714 (Mfd. Since 03/24)

Assembly

The machine must be fully assembled before it can be operated. Before beginning the assembly process, refer to

and gather

all

To ensure the assembly process

goes smoothly, first clean any

covered or coated in heavy-duty rust preventative (if applicable).

listed items.

Needed for Setup

parts that are

Invert hopper to expose hopper seal, as

shown in Figure 8.

Hopper Seal

Figure 8. Hopper seal location.

Drill or punch out hopper mounting holes in

hopper seal.

Note: Pre-punching holes in hopper seal will

allow fasteners to be started and installed without the tendency to cross thread.

To assemble blast cabinet:

Disassemble crate and place sheet of card-

board on floor to protect cabinet.

Tilt cabinet off of hopper, as shown in Figure

2. 7, and place cabinet on its back. Leave hop-

per in place on pallet.

Cabinet

Hopper

Figure 7. Unpacking cabinet.

In next step, remember that door is springloaded and handles must be held firmly before door is unlatched and opened. Otherwise, door may suddenly swing open and cause injury or damage.

With one hand, grasp cabinet door handle.

With other hand, unlatch door and let it open slowly, as shown in Figure 9.

Model G0714 (Mfd. Since 03/24)

Figure 9. Opening cabinet door.

-17-

6. Make sure latch on hopper dump door faces forward, and position hopper next to bottom of cabinet, as shown in Figure 10.

Latch

Position hopper and hopper support against

underside of blast cabinet, as shown in Figure 12.

Upper Front Support

Latch

Figure 10. Positioning hopper latch.

7. Fasten (4) stand legs and cross braces to

hopper support, as shown in Figure 11, using (24) M8-1.25 x 20 hex bolts, (24) 8mm flat washers, (24) 8mm lock washers, and (16) M8-1.25 nuts. When mounting legs, only use (2) holes shown in Figure 11.

Support in

Upper Position

Figure 11. Stand assembly.

Hopper

Support

Hopper

Figure 12. Installing stand and hopper.

In next two steps, to avoid cross-threading screws caused by any foam gasket interference, carefully start screws by hand.

9. Starting at inside-bottom of blast cabinet,

install (6) M6-1 x 16 Phillips head screws with 6mm flat washers in order shown in Figure 13 so all mounting holes line up.

To eliminate pinch hazard, in next step, keep fingers clear of hopper support and blast cabinet mating surfaces. When items become aligned, they can slide together without warning, causing a severe pinch injury.

-18-

Figure 13. Aligning hopper with cabinet.

10. Install remaining (16) M6-1 x 16 Phillips head

screws with their flat washers.

Model G0714 (Mfd. Since 03/24)

11. Install remaining (8) M8-1.25 x 20 hex bolts, 8mm flat washers, and 8mm lock washers into holes in leg flanges shown in Figure 14.

Figure 14. Final leg installation.

15. Fasten pressure gauge and regulator "L"

bracket (see Figure 16) to left-front leg using (2) M6-1 x 12 cabinet screws and M6-1 flange nuts.

12. Close and latch door. With help of assistant, tilt blast cabinet upright onto its legs.

Place work tables into cabinet, so work table

13.

with corner cut off is positioned at front-right corner of blast cabinet.

Route blast gun hoses past notch in right

14.

table, and hang blast gun on its hook on right side of cabinet wall, as shown in Figure 15.

Blast Gun

and Hook

Figure 16. Regulator installation.

16. Connect foot valve output line to fitting located

on front-right of hopper shown in Figure 17.

Position foot pedal (see Figure 17) between

17.

legs. Fasten it to floor, if desired.

Hopper

Bulkhead

Fitting

Foot Valve Output Line

Figure 15. Blast gun stowage.

Model G0714 (Mfd. Since 03/24)

Figure 17. Foot valve installation.

18. Locate dust collector canister assembly and

unlatch dust collector motor, lift dust collector out of canister, and set it aside.

-19-

19. Working from inside of canister, insert plunger through canister wall so it can be seen protruding from outside of canister (see Figure 18).

Place spring on plunger, thread hex nut

20.

and knob onto plunger, and tighten hex nut against knob, as shown in Figure 18.

Knob

Hex Nut

Spring

and

Plunger

Dust Collector

Canister

Figure 18. Canister plunger installation.

21. Using (4) M6-1 x 12 cabinet screws and M6-1

flange nuts, fasten dust collector to rear of cabinet so suction port protrudes through hole cut into back of cabinet (see Figure 19).

Remove inside-right baffle shown in Figure

22. 20 from cabinet wall.

Baffle

Figure 20. Inside-right baffle.

Note: Removing this baffle provides access

to full circumference of dust collector suction pipe so sealant can be evenly applied without leaks. When dust collector is in operation, and gap shown in Figure 21 is sealed, good left-to-right cross cabinet airflow can be achieved for optimum visibility, especially when CFM drops off.

Using silicone (not supplied), seal gap shown

23.

in Figure 21 between suction port and hole in cabinet wall.

Gap

Figure 21. Dust collector gap to be sealed.

24. Re-install baffle in blast cabinet and dust col-

lector in canister.

-20-

Figure 19. Dust collector installation.

Model G0714 (Mfd. Since 03/24)

25. Install dust collector power cord in plastic

Once assembly is complete, test run the machine to ensure it is properly connected to power and safety components are functioning correctly.

If you find an unusual problem during the test run, immediately stop the machine, disconnect it from power, and fix the problem BEFORE operating the machine again. The

table in the

SERVICE section of this manual can help.

DO NOT start machine until all preceding setup instructions have been performed. Operating an improperly set up machine

Serious injury or death can result from

raceway and snap cover in place, as shown in Figure 22.

Cover

30. Verify that plastic dust sheet is affixed to inside of cabinet viewing window and light window. If blasting operations begin without these dust sheets installed, media will permanently etch window glass and require replacement.

Test Run

Figure 22. Dust collector power cord installation.

26. Plug dust collector into power supply recepta- cle on rear of control box shown in Figure 23.

Figure 23. Dust collector connected to power

supply.

27.

Pour desired amount of media into cabinet

through front door. DO NOT overfill.

Allow silicone sealant to fully cure. Otherwise,

28.

when machine is turned ON and media blasting begins, seal may be broken, causing leakage.

Troubleshooting

The Test Run consists of verifying the following: 1) The lights and the dust collector motor power up and run correctly, 2) the ON/OFF switches work, and 3) the air regulator and system are functional.

using this machine BEFORE understanding its controls and related safety information. DO NOT operate, or allow others to operate, machine until the information is understood.

may result in malfunction or unexpected results that can lead to serious injury, death, or machine/property damage.

Inspect all seals, hose clamps, glove clamps,

29.

and window seals for loose fittings, cracks or leaks. Correct as required.

Model G0714 (Mfd. Since 03/24)

-21-

To test run machine:

Clear all setup tools away from machine.

2. Make sure that DUST COLLECTOR ON/OFF

rocker switch is in OFF position, as shown in

Figure 24.

Figure 24. DUST COLLECTOR ON/OFF rocker

switch.

Connect machine to power source.

4. Verify that dust collector and lights oper-

ate correctly by toggling LIGHT and DUST COLLECTOR switches to ON position.

— When operating correctly, dust collector

runs smoothly with little or no vibration or rubbing noises, and all LED lights are brightly illuminated.

— Investigate and correct strange or unusu-

al noises or vibrations before operating machine further. Always disconnect machine from power when investigating or correcting potential problems.

Put on safety glasses and connect blast cabi-

net to air supply.

7. Adjust regulator knob to 125 PSI, as shown

on gauge.

Whenever closing blast cabinet door, make sure that gloves are out of the way of door seal before door is latched shut. Otherwise gloves and door seal will be pinched and can be damaged.

8. Lower door and latch it shut.

9. Grasp blast gun and press foot pedal. Air

should exit from tip of blast gun.

Note: If, after this test, regulator gauge

needle drops more than a few PSI when you press foot pedal, verify that air supply is not restricted. With proper air supply volume and pressure, blast gun media suction tube should draw 15–17 inches of mercury on manometer.

10. Listen and watch for air leaks. Spray solution

of warm water and dish soap on air lines, valves, and fittings. When leak is found, soap bubbles will form. Correct and reseal as required.

11. Adjust air pressure down to 60 PSI, and dis-

connect air supply and power supply.

Toggle DUST COLLECTOR switch to OFF

position.

-22-

Model G0714 (Mfd. Since 03/24)

SECTION 4: OPERATIONS

To reduce your risk of serious injury, read this entire manual BEFORE

ry or lung damage from dust, always wear safety goggles and a respirator

Media blasting presents hazard of silicosis and other lung contamination injuries! These injuries are permanent and can get worse over time. If you use media blasting equipment without proper eye protection and respirator, eyes and lungs may become irreversibly contaminated. Only use blast cabinet if you are properly trained in how to use it, correctly protect yourself, and keep all unprotected bystanders away. For latest types of protective equipment and acceptable respirator types, contact local

OSHA or NIOSH ofce.

Preparation

NEVER sand blast with door open, point gun at yourself or anyone else, or attempt to service any part of machine while it is connected to power or air supply. ALWAYS disconnect blast cabinet from power and air supply when not in use, or during maintenance or adjustments. Ignoring this warning may lead to severe injury.

To prepare for a typical media blasting operation:

Conduct daily inspection of cabinet as listed

in Maintenance on Page 30.

using machine.

To reduce risk of eye inju-

when operating machine!

If you are not experienced with this type of machine, WE STRONGLY RECOMMEND that you seek additional training outside of this manual. Read books/magazines or get formal training before beginning any projects. Regardless of the content in this section, Grizzly Industrial will not be held liable for accidents caused by lack of training.

Select and install required blast tip, load

media, and empty dust collector canister.

Empty air supply water separators, connect

power and air to cabinet, and adjust regulator to required air pressure.

Remove water, oil, grease, and loose paint or

scale from workpiece, then place workpiece into blast cabinet.

Put on safety goggles and respirator, and

begin media blasting operation.

Model G0714 (Mfd. Since 03/24)

-23-

Basic Operation

During blasting operations, make sure to keep the water separators drained. Keep in mind that, depending on the temperature and the amount of humidity in the ambient air, water separators may have to be drained once a day or multiple times during your blasting project.

For tips on basic blast cabinet use and how to prevent common problems with blasting operations, refer to Operation Tips on Page 25.

To use blast cabinet:

Prepare cabinet and workpiece for blasting,

as discussed in Preparation on Page 23.

Put on safety goggles and respirator.

Select and load blasting media through front

cabinet door. Refer to Page 26 for media types if needed.

Connect media blasting cabinet to power and

air supply.

Pull down on regulator knob shown in Figure

7. 26 to unlock it, and turn knob clockwise to

increase air pressure for desired blasting operation. Push knob in to lock setting.

Avoid using media that contains free silica, as this is a leading source of silicosis that can lead to serious injury or death!

4. Install correct tip into blast gun, in position

shown in Figure 25. Typically, 6mm tip is used, but refer to Blasting Media section on Page 26 to understand when to use largersized tips.

Blast Tip

Figure 25. Blast tip installation.

5. Use canister plunger to tap filter clean and

make sure canister is empty.

Regulator

Knob

Figure 26. Air pressure regulator.

When loading and unloading heavy or awkward workpiece, you should cover seal with thick cardboard, get lifting assistance, and never rest workpiece on lower door frame. Otherwise you can damage door seal, which will cause cabinet seal to leak.

8. Place workpiece into blast cabinet.

When closing blast cabinet door, move gloves out of the way of door seal before door is latched shut. Otherwise gloves and door seal can be pinched and damaged.

-24-

Model G0714 (Mfd. Since 03/24)

9. Lower door and latch it shut, as shown in

Figure 27.

Figure 27. Properly latched door.

10. Toggle LIGHT and DUST COLLECTOR switches to ON position (see Figure 28).

Operation Tips

Improving Productivity

Clean workpieces as much as possible by removing grease, oils, paint, rust, scale and other matter before beginning blasting operations (pressure washers can work well for this). Select the correct media for the task, and do not use air pressure settings that are too high for the media as it will cause media breakdown and dulling.

Maintaining Visibility

Should poor visibility become a problem during blasting operations, do not wipe the windows clean with wet or dry rags. Doing so will scratch the protective plastic sheet, further reducing visibility. Instead, vacuum media away with a soft brush attachment, or use a soft paint brush to brush the dust off of the protective sheets.

Figure 28. DUST COLLECTOR and LIGHT

switches.

11. Point blast gun tip at workpiece in direction where ricochetting spray of abrasive will not hit windows.

Slowly press foot pedal and move blast tip

12.

in slow, circular motion. Abrasive media will begin spraying from blast gun tip.

13. Every 20–30 minutes during blasting operations, use filter cleaning plunger (see Page 3) to knock off material that is caked onto outside of filter. Push plunger in until it stops, then let thumb slide off of button so spring slaps plunger back against inside wall of canister.

When blasting operation is complete,

14.

disconnect cabinet from power and air supply.

Protecting Window Glass

Always make sure to inspect and replace the protective sheets BEFORE the ricochetting media wears through and permanently etches the underlying glass. If using an aggressive media, this is especially true and you may have to double the sheets to protect from wear-through before the blasting project is finished.

Extending Protective Film Life

For most media blasting operations, maintain a distance of six inches. Keep the spray at a 45°–60° degree angle to the workpiece, so the media will ricochet off it and not directly impact the light or viewing window. Doing this will help maintain workpiece visibility and make the protective window film and media last longer. Avoid pointing the gun at the workpiece with the tip perpendicular or 90° from the surface.

Maintaining Workpiece Finish

Blast media will wear the blast gun tip causing an inconsistent abrasive pattern. A poor blast pattern will leave streaks or spots on the workpiece finish. To avoid this situation, rotate the media blasting

⁄4-turn every 10 to 12 hours of use, and replace

tip any tip that has worn larger than from original size.

⁄16 " in diameter

Model G0714 (Mfd. Since 03/24)

-25-

Media Amounts

Loading only enough media for the job at hand will help you prevent over-using or having to screen excess media. Use just enough media to cover the suction tube opening at the bottom of the hopper by 6" to 8". Experiment with using the least amount of media as possible. The result of using less media is that you will have less material to screen or discard and more fresh media for mixed projects. Store media in a dry place.

Recycling Media

Screen used media with a series of wire mesh screens to refine it to one consistent size.

Air Pressure Settings

Most operations are done with air pressure settings between 60 –80 PSI. However, the optimum air pressure is derived from a trial-and-error process based on the factors discussed in the Blasting

Media section. If required, refer to that section

for help.

Blasting Media

Some of the common blasting media types are listed in this section with the MOH scale hardness value listed in parenthesis. All media have benefits and drawbacks, such as the quality of surface finish, media life, toxicity, and the precautions that must be taken to prevent environmental damage or personal injury to your respiratory system. However, all media presents a health risk. Never use media that contains free silica as this is linked to silicosis.

Media Cost vs. Productivity

It is a common assumption that using low-cost media such as basic builder's sand or play sand, is an economical option for blasting. However, since sand is a "dull media," the velocity at which the media must strike the workpiece must be much higher than what is required for "sharp media."

Air Pressure Exceptions

When blasting thin materials made of aluminum, copper, brass, wood, or other delicate parts, select a fine or soft media and begin blasting at a low pressure, such as 45 PSI. Next, slowly increase the air pressure until you achieve the finish required. When using glass bead media, you may have to keep the operating pressure between 50–80 PSI, or the media will shatter and break down prematurely. However, if using media like silicon carbide and aluminium oxide, you can keep pressures between 100–125 PSI.

Preventing & Clearing Clogs

During blasting operations the gun may periodically clog or become restricted with workpiece debris. If this occurs, cover the blast tip hole tightly, and press the foot valve. Air pressure will be diverted back through the suction circuit in the gun and piping, blowing out the clog. Blasting operations can be resumed afterwards; however, if clogging persists and the cause is other than workpiece debris, refer to Troubleshooting on Page 31 for further solutions.

Another requirement when using sand is that the hole in the blast tip must be larger in diameter to avoid clogging caused by the inconsistent grit size, and to prevent caking of other minerals and organic matter mixed in with the sand.

Given the conditions above, the compressor must deliver a high CFM of airflow maintained at a high air pressure, which can generate increased wear and can overheat smaller compressors. Compressors that operate for extended periods at maximum output have higher maintenance costs and a shorter life, not to mention the increased hazard of silicosis for the user and bystanders.

With correct research, excellent productivity can be achieved using sharp media with a smaller tip and less air pressure than with dull media at a higher pressure. Below is a list of Grizzly media that works well in our blast cabinets.

Grizzly Blast Media Part Numbers

G6535: 15 lbs. Aluminum Oxide 220 Grit. G6536: 15 lbs. Aluminum Oxide 120 Grit. G6537: 15 lbs. Aluminum Oxide 60 Grit. G6538: 15 lbs. Glass Bead 50-Micron Grit.

-26-

Model G0714 (Mfd. Since 03/24)

Aluminum Oxide (8.5–9)

Aluminum oxide is commonly used for surface finishing. It has an angular shape, is extremely sharp, has extended blast times, and is highly recyclable.

Slag Media (7–8, 6–7)

Slag media are by-products of various types of smelting and coal burning processes. Be aware that some slag media may contain unwanted byproducts from these processes.

Silicon Carbide (9–9.5)

This blast media is considered to be the hardest available. The crystal structure is sharp and cutting is fast and aggressive. This media is often used to engrave and etch glass and stone. It has shorter blasting periods. Silicon carbide has no free silica and it can be recycled many times.

Sand Media (6–7)

This media is easy to find and gives an average finish for many projects. Sand has a good recycling life and is economical. However, as discussed in Media Cost vs. Productivity, the weak cutting ability and high CFM requirements can lead to additional compressor maintenance. Also, if using sand that contains free silica, there is an increased health hazard for silicosis.

Steel Media (8.9–6)

This aggressive media creates a rough finish that accepts paint well. It is durable and has a long life; however, it MUST be kept very dry to prevent rusting. The main types are as follows:

—Steel Grit (8–9): Compared to aluminum

oxide, steel grit is softer and has a low habit of fracture, which leaves an excellent etched surface on rubber, paints, and other coatings. Steel grit comes in many grit sizes and hardness, and is a popular choice for aircraft applications.

—Steel Shot (6–7.5): Steel shot is widely

used for stripping, cleaning, and general improvements of metal surfaces. It has a rounded-ball shape and comes in many grades, sizes, and hardness, and usually gives the surface a shiny or polished look. Steel shot peening is also used to de-stress machinery parts such as impeller fins, bearing parts, springs, and torsional components. Steel shot does not create high amounts of dust and it has a superior recycle rate.

—Copper Slag (7–8): Copper slag is a by-

product from the copper manufacturing process. It is very economical but nonreusable. It is considered a better alternative to sand and does not present a hazard for silicosis. Best suited for cleaning rust, mill scale, and paint from steel. Copper slag leaves a good surface to anchor and bond coatings and paints. The structure is blocky and sharp-edged.

—Coal Slag (6–7): This blast media is made

from liquid coal slag that is collected from utility boilers. It then is hardened and crushed. The resulting media is sharp, angular, and fast-cutting with little dust. However, copper slag can release hazardous pollutants into the environment. Various grit sizes can be used from light blasting operations to heavy-duty rust, paint, and mill scale removal. The resulting finish is a good surface ready to anchor and bond coatings and paints.

Glass & Garnet Media (7.5–5.5)

Glass media contains no free silica or heavy metals and is non-toxic and inert. It works well for soft metals and is a common choice when critical tolerances of machine parts must not be affected.

—Glass Beads (5.5): Just as the name

indicates, this media is round in shape. Glass beads come in various grit sizes and hardness. It is manufactured from lead-free, soda lime-type glass. Unlike angular abrasives that cut, beads burnish and leave a bright finish that typically has no dimensional change. Glass beads can be recycled many times. Common applications are honing wood, blending surfaces, polishing, peening, finishing surfaces, removing scratches, and basic cleaning of most materials.

Model G0714 (Mfd. Since 03/24)

-27-

—Crushed Glass (5.5): This media is cre-

ated from recycled bottles and other glass. It has a sharp cutting behavior and is often used to remove epoxy coatings, glues, polyurethanes, vinyls, elastomers, rubbers and tar. Crushed glass embeds less particles while blasting, which results in a very light and clean-looking finish.

—Garnet (6.5–7.5): Garnet is very effec-

tive at cleaning steel, works well on brick, stone, and stainless steel. It is very dense and hard, and is naturally occurring. The recyclability is good, and it is a common choice for use in blast cabinets, the oil and gas industry, and shipyards.

Plastic Bead Media (3–4)

Plastic abrasives are available in a variety of types such as urea, melamine, and acrylic compositions. The beads are round and give reliable, consistent stripping results. Excellent for paints, varnishes, rusts, and oxidation from soft metals, plastics, and wood. The aerospace and automotive industry are chief consumers of this blast media.

—Urea (3–4): Urea is the most common-

ly used plastic media. It is considered to be an environmentally-friendly choice because it is a much safer option than using chemical strippers. It is recyclable and is an excellent choice for stripping tough coatings when speed is a high priority and the surface is not critical.

—Melamine (3–4): A long-lasting, recyclable

media, this abrasive is the most aggressive of the plastic beads. Due to its hardness, it can strip hard-to-remove coatings and be substituted for some of the other types of glass beads.

Soft Media (4.5–2.4)

There are many types of "Soft" blast media, many of which are inert minerals and organic material. Some blast cabinets with dust collection systems require special filters or dust collectors for soft types of media where, the media becomes pulverized and turns to a cloudy dust that can cake onto filters quickly. When used with the Model G0714, the filter cleaning interval will have to be increased to maintain flow.

—Ground Walnut: (4.5–5) This is a soft

media produced from crushed or ground walnut shells. The structure is multi-faceted and angular with no free silica. Durability is excellent, making this media a good choice for blasting operations where the paint, varnish, or coating must be cleaned but not marred or removed. Great for cleaning hardwoods, jewelry, and electrical items. Using a larger grit under higher pressure settings, ground walnut shells can also be used to strip away paint and varnishes. Also works great for cleaning coke and other carbon deposits from engine parts.

—Pumice (6–7):

volcanic ash that is inert and can be used for the most sensitive blasting operations where the painted or finished surface must be entirely unaffected by the removal of the foreign matter. The structure is honeycombed and block-shaped.

—Ground Corn Cob (4.5): An organic, soft-

blasting grit that has an angular shape, and has excellent surface cleaning behavior similar to ground walnut and peanut shells. It is available in a selection of grit sizes, and is commonly used to strip light coatings , thin bark, and dirt off of wood without surface damage or grain blowout.

This mineral is a natural

—Acrylic (3–4): This multipurpose blast

media is one of the longest lasting types available, and is available in a wide range of grit sizes. It is often used for stripping sensitive surfaces or delicate parts that may consist of multiple types of compounds.

-28-

—Sodium Bicarbonate (2.4): Baking soda

is inert, water-soluble, and has an excellent ability to remove and absorb dirt or contaminants from a surface. It will not peen or cut the underlying workpiece. This important media can be used where small ports and bores must be cleaned without clogging the passages. After blasting operations, any remaining media can be removed with water.

Model G0714 (Mfd. Since 03/24)

ACCESSORIES

Installing unapproved accessories may

order online at www.grizzly.com or call 1-800-523-4777

SECTION 5: ACCESSORIES

cause machine to malfunction, resulting in serious personal injury or machine damage. To reduce this risk, only install accessories recommended for this machine by Grizzly.

NOTICE

Refer to our website or latest catalog for additional recommended accessories.

G0957—80-Gallon 5 HP Extreme-Series Air Compressor

This compressor operates with a maximum pressure of 175 PSI and delivers 18.5 CFM at 90 PSI and 24 CFM at 40 PSI. The fan pulley and cooling fin design provide efficient cooling to keep the unit from overheating. Includes a tank pressure gauge, threaded fitting, and an oil sight glass.

⁄2 " NPT

G0572—Hanging Air Filter w/Remote

This filter has a convenient remote control and features a three-speed motor, automatic shutoff timer, and 1-micron inner filter and 5-micron outer filter. Air flow is 556, 702 and 1044 CFM. Overall size is 26”L x 19

Figure 30. G0572 Hanging Air Filter w/Remote.

H2499—Small Half-Mask Respirator H3631—Medium Half-Mask Respirator H3632—Large Half-Mask Respirator H3633—Cartridge Filter

If you work around dust everyday, a half-mask respirator can be a lifesaver. Also compatible with safety glasses!

⁄2 ”W x 15”H.

Figure 31. Half-mask respirator with disposable

cartridge filters.

Figure 29. G0957 80-Gallon 5 HP Extreme-

Series Air Compressor.

Model G0714 (Mfd. Since 03/24)

-29-

SECTION 6: MAINTENANCE

Always disconnect power and air supply to machine before performing maintenance. Failure to do this may result in serious personal injury.

Schedule

For optimum performance from this machine, this maintenance schedule must be strictly followed.

Ongoing

To minimize your risk of injury and maintain proper machine operation, shut down the machine immediately if you ever observe any of the items below, and fix the problem before continuing operations:

Cleaning

Wear safety goggles and respirator when cleaning cabinet or filter. Failure to comply can cause serious personal injury.

Wipe down the exterior of the cabinet with a light solution of mild dish soap and water, then dry with a clean towel. To avoid scratching windows, never clean them with wet or dry rags. Instead, vacuum media away with a brush attachment, or gently brush the window with a soft paint brush.

• Loose mounting bolts.

• Leaks, cracks, abrasions, and wear in fittings, hoses, and cabinet seals.

Incorrect air pressure for media.

•

Dirty filter.

•

Worn window protective films.

•

Worn or damaged wires/cords.

•

Any other unsafe condition.

•

Daily Maintenance

• Drain water separators.

• Empty dust collector canister.

• Clean filter.

• Rotate blast tip to compensate for wear.

Monthly Maintenance

• Use soapy water on fittings/hoses. Bubbles indicate leak.

• Clean/vacuum dust buildup from inside cabinet/off motor. Inspect for leaks or damage.

• Inspect suction lines carefully for spots that collapse or leak during operation.

• Inspect work gloves for holes or wear.

• Repaint bare metal portions of cabinet (with windows covered).

Every five hours of use, empty the canister through the dump port shown in Figure 32. Typically this media is discarded as it has a high ratio of fine dust contaminants. For major cleaning, unlatch the top of the dust collector and remove the filter element. Inspect all sealing foam and replace as required. Clean the filter canister pleats by carefully blowing them from the inside out with compressed air. If the filter is clogged, or has holes or tears, replace the filter.

Figure 32. Dust collector service.

-30-

Model G0714 (Mfd. Since 03/24)

SECTION 7: SERVICE

Review the troubleshooting and procedures in this section to fix or adjust your machine if a problem develops. If you need replacement parts or you are unsure of your repair skills, then feel free to call our Technical Support at (570) 546-9663.

Troubleshooting

Operation

Symptom Possible Cause Possible Solution

Intermittent, clogging, or no media spray at blast gun; or striping is occurring on workpiece.

Dust collector won't start or circuit breaker trips.

LED lights are dim or will not illuminate.

1. Suction tube has been clogged from contaminant.

2. Incorrect or worn-out media.

3. Worn or incorrect blast tip.

4. Low airflow or pressure up to cabinet.

5. Blasting system has incorrect airflow or pressure.

6. Cabinet is overloaded with media.

7. Blast gun is damaged or has bad seals.

8. Foot valve or lines are at fault.

1. Damaged or loose power cord.

2. ON/OFF switch at fault.

3. Circuit breaker/fuse has tripped.

4. Wiring at fault.

5. Motor brushes at fault.

6. Motor at fault.

1. LED light(s) at fault.

2. ON/OFF switch at fault.

3. Wiring at fault.

1. Cover blast tip and press foot pedal to use air pressure to purge foot valve and suction system. Repeat step periodically during blasting operations.

2. Verify that media chosen is correct material for blasting operation (Page 26). Make sure that media is not worn-out, saturated with debris, or contaminated with moisture, causing it to cake inside of lines. Screen or replace media as required.

3. Disconnect machine from air and rotate blast tip 1⁄4 -turn to compensate for wear. Replace or install with correct blast tip.

4. Troubleshoot air supply system and verify compressor, supply lines, moisture separators, and air dryers have correct airflow and are in good working order.

5. Adjust air regulator on cabinet to maintain correct air pressure and flow, and verify no hose kinks or clogs exist.

6. Remove media but leave just enough for blasting operation.

7. Disassemble blast gun, clean and reseal.

8. Clean and reseal foot valve, fittings, and lines.

1. Re-secure and test power cord. Replace as required.

2. Test and replace open switch.

3. Replace fuse on control box, reset power supply circuit breaker.

4. Repair for open or shorted wiring connections.

5. Replace motor brushes (Page 33).

6. Test and replace motor as required.

1. Replace LED light(s).

2. Test and replace open switch.

3. Repair for open or shorted wiring connections.

Model G0714 (Mfd. Since 03/24)

-31-

Symptom Possible Cause Possible Solution

Poor visibility during blasting operations.

1. Lighting is at fault.

2. Protective sheet on windows are worn.

3. Workpiece is excessively dirty.

4. Media selected is too fine or soft for good visibility.

5. No dust collection.

6. Dust collector filter is worn out.

7. Dust collector motor is at fault.

1. Replace one or more LED lights as required

to establish correct illumination (Page 36). Dim surrounding shop lighting near blast cabinet, or eliminate exterior glare on viewing window with sun shroud.

2. Replace protective sheets on viewing window

and light window (Page 36).

3. Prepare workpiece properly. Remove water, oil, grease, and excessive amounts of paint or scale that can be easily removed.

4. Chose another media (Page 26) with lower potential for clouding.

5. Clean dust collector filter (Page 30), empty canister, and turn on dust collector. Verify cabinet air intake is unblocked.

6. Replace filter (below).

7. Replace motor brushes (Page 33), or motor if required.

Filter Replacement

Wear safety goggles and respirator when cleaning cabinet or filter. Failure to comply can cause serious personal injury.

If, after a full filter cleaning, the cabinet still clouds up and general blasting visibility is poor, or if the dust collector has lost a considerable amount of CFM, the filter must be replaced.

To replace filter:

DISCONNECT MACHINE FROM POWER!

2. Unlatch dust collector, lift entire motor and

filter unit out of canister (see Figure 33), then place it on workbench upside down.

3. Spin wing nut off of retaining stud, and remove filter (see Figure 33).

Dust

Collector

Filter

Wing Nut

Latch

Canister

Figure 33. Dust collector and filter.

4. Place new filter over retaining stud, then re-

install wing nut and dust collector.

-32-

Model G0714 (Mfd. Since 03/24)

Motor Brush

Replacement

4. While pulling fan cover upwards, use stan-

dard screwdriver to carefully pry out cover lock tangs just enough to clear hooks (see Figure 35), then remove cover from motor.

During the life of your blasting cabinet, you may find it necessary to replace the dust collector motor brushes. If the motor operates loudly, or the dust collector still has low suction after a new filter has been installed, the motor brushes likely have reached the end of their usable life and need to be replaced.

Items Needed Qty

Phillips Screwdriver #2 ..................................... 1

Standard Screwdriver #2 Acetone and Cotton Rag Crocus Cloth (From Local Auto Parts Store) Carbon Brush Set (P0714101-11)

To replace brushes:

DISCONNECT MACHINE FROM POWER!

2. Unlatch dust collector, lift entire motor and fil-

ter unit out of canister, and place it on a workbench for ease of service (see Figure 34).

.................................. 1

................................... 1

..... 1

....................... 1

Fan Cover

Lock

Tang

and

Hook

Figure 35. Brush removal.

5. Remove (2) screws that secure each

brush housing and remove retainers (see Figure 36).

Motor

Cover

Canister

Figure 34. Dust collector components.

Remove motor cover shown in Figure 34. It

is attached with (4) screws.

Motor Cover Screw

Latch

Retainer

Screw

Brush

Housing

Figure 36. Retainer removal.

Model G0714 (Mfd. Since 03/24)

-33-

6. Lift each brush housing out of its seat and unplug power wire (see Figure 37).

Power Wire

Brush

Housing

Figure 37. Brush housing removal.

7. Slide brush assembly apart, clean housings

and brass sleeves with acetone, and allow parts to dry (see Figure 38).

— If brushes have worn deep grooves in

commutator, we recommend replacing motor. Typically, labor involved with returning commutator on lathe then undercutting insulator segments far exceeds price of new motor.

— If commutator only has minor wear and

black-colored carbon tracking (see Figure

39), use fine crocus cloth to polish surface where brushes ride. DO NOT use emery cloth or sandpaper to clean commutator, or you could make it "out-of-round," which will cause new brushes to arc, overheat, and wear out quickly.

Finish cleaning process by using acetone

10.

and cotton rag to wipe off any oils or contaminants from commutator.

Insert power wire spade terminal into brush

11.

assembly between brass sleeve and housing (see Figure 40).

Housing

Figure 38. Brush assembly components.

Re-assemble housings with brass sleeves

and new carbon brushes.

Inspect commutator surface for carbon track-

ing (see Figure 39).

Brass

Sleeve

Carbon

Brush

Insert Power Wire Spade Terminal Here.

Figure 40. Brush power lead location.

Spade Terminal

Inserts Here

Carbon Tracking

Figure 39. Carbon tracking on commutator

surface.

-34-

Model G0714 (Mfd. Since 03/24)

Place brush housing into brush seat on motor,

12.

and place retainer over brush housing so lock lug drops into lock slot in brush housing (see Figure 41).

Lock Lug

15. Place fan cover back onto motor so tangs lock onto brush housings, as shown in Figure 43.

Lock Slot

Figure 41. Brush retainer installation.

13.

Install and tighten brush housing retaining

screws.

When brush housings are installed, make

14.

sure to route brush power wires well away from commutator, as shown in Figure 42, or commutator will wear into wire, causing electrical short.

Tangs

Figure 43. Fan cover installation.

16.

Install motor cover and insert dust collector

assembly into canister, then latch dust collector in place.

Incorrect

Figure 42. Safe power wire routing.

Model G0714 (Mfd. Since 03/24)

Correct

Test dust collector operation as outlined in

17. Test Run on Page 21.

-35-

LED Replacement

The three LED lights are accessed through the outside top of the cabinet (not from the inside of the cabinet).

Items Needed Qty

LED Light Assembly (Part # P0714011V2-1) ...... 1

Phillips Head Screwdriver #2 Small Step Ladder Safety Goggles Leather Gloves Soft Cotton Rags Mineral Spirits Solution of Warm Water and Dish Soap Assistant

........................................................... 1

............................................ 1

................................................. 1

............................................... 3

...............................................1 Pt

........................... 1

...... 1 Qt

Have assistant hold work hanger shown in

Figure 45 to avoid possibility of it falling when (4) front cover screws are removed in next step.

Work Hanger

To replace LED lights:

DISCONNECT MACHINE FROM POWER!

2. Remove raceway covers by sliding them

off of their tracks, then lift power cord out of raceways, as shown in Figure 44.

Figure 44. Power cord removal.

Figure 45. Work hanger location.

5. Loosen (but do not remove) (4) work hanger

screws shown in Figure 46, then remove remaining (8) LED cover screws.

Work Hanger Screws

Figure 46. Location of work hanger screws.

6. Put on leather gloves and safety goggles.

3. Open blast cabinet door.

-36-

7. Lift LED cover, as shown in Figure 46, and carefully pull it toward you so cover slides out from under (4) screws. Make sure not to break sheet of glass that is resting on rubber cabinet seal under LED cover.

Model G0714 (Mfd. Since 03/24)

8. With help of assistant, place LED housing on

top of cabinet, facing upwards, as shown in

Figure 47.

Figure 47. LED housing facing upwards.

Lift sheet of glass off cabinet, and set it on

workbench for cleaning.

Disconnect any cords attached to LED you

10.

want to replace, and remove LED (see Figure 48).

Connect machine to power and toggle LIGHT

12.

switch to ON position to test new lights.

— If all lights light quickly without much flick-

ering or lag, lights are fully functional.

— If any lights struggle for more than five

seconds, are dim, or do not light, check cord/wire connections.

Note: Refer to wiring diagram on Page 39 if

you are unsure about wiring connections.

DISCONNECT MACHINE FROM POWER!

13.

Inspect window seal and its surface for evi-

14.

dence of dust streaking between glass and seal, and cabinet and seal.

Make sure that seal is free of any physical

damage. Replace or reseal accordingly, but never use glue, caulking, or silicone of any kind between window and its seal, as this will permanently fasten glass to cabinet. Seal is established my means of vacuum created by dust collector.

Note: LEDs are held in place by spring

clamps.

Cord

(1 of 3)

LED

(1 of 3)

Figure 48. Cords attached to LEDs.

11.

Install new LED and connect to cord(s) dis-

connected in Step 10.

Peel off old adhesive window protection film

15.

from glass window.

Using paint brush with solution of warm water

16.

and dish soap, rinse all dust and abrasives off of window. Do not rub glass with rag or abrasives will scratch surface.

Use mineral spirits to break down any adhe-

17.

sive residue leftover from protective film.

Clean window with glass cleaner and soft cot-

18.

ton rag.

When window is fully dry, affix new protective

19.

film.

Re-assemble cabinet in reverse order, mak-

20.

ing sure to install glass window so protective film is toward inside of blast cabinet.

Model G0714 (Mfd. Since 03/24)

-37-

SECTION 8: WIRING

These pages are current at the time of printing. However, in the spirit of improvement, we may make changes to the electrical systems of future machines. Study this section carefully. If there are differences between your machine and what is shown in this section, call Technical Support at (570) 546-9663 for assistance BEFORE making any changes to the wiring on your machine.

Wiring Safety Instructions

SHOCK HAZARD. Working on wiring that is con-

nected to a power source is extremely dangerous. Touching electrified parts will result in personal injury including but not limited to severe burns, electrocution, or death. Disconnect the power from the machine before servicing electrical components!

MODIFICATIONS. Modifying the wiring beyond what is shown in the diagram may lead to unpredictable results, including serious injury or fire. This includes the installation of unapproved aftermarket parts.

WIRE CONNECTIONS. All connections must be tight to prevent wires from loosening during machine operation. Double-check all wires disconnected or connected during any wiring task to ensure tight connections.

CIRCUIT REQUIREMENTS. You MUST follow the requirements at the beginning of this manual when connecting your machine to a power source.

WIRE/COMPONENT DAMAGE. Damaged wires or components increase the risk of serious personal injury, fire, or machine damage. If you notice that any wires or components are damaged while performing a wiring task, replace those wires or components.

MOTOR WIRING. The motor wiring shown in these diagrams is current at the time of printing but may not match your machine. If you find this to be the case, use the wiring diagram inside the motor junction box.

CAPACITORS/INVERTERS. Some capacitors and power inverters store an electrical charge for up to 10 minutes after being disconnected from the power source. To reduce the risk of being shocked, wait at least this long before working on capacitors.

EXPERIENCING DIFFICULTIES. If you are experiencing difficulties understanding the information included in this section, contact our Technical Support at (570) 546-9663.

The photos and diagrams included in this section are best viewed in color. You can view these pages in color at www.grizzly.com.

-38-

Model G0714 (Mfd. Since 03/24)

DUST COLLECTOR

GND

Ground

GND

Wiring Diagram

LED LIGHT ASSEMBLY

LED 18W 36"

ASSEMBLY

Dust

Collector

Motor

SWITCH BOX

ASSEMBLY

110 VAC

5-15 Plug

(As Recommended)

Neutral

Hot

LED 18W 36"

DUST COLLECTOR

SWITCH

(viewed from behind)

FLUORESCENT LAMP

SWITCH

(viewed from behind)

DUST COLLECTOR

POWER RECEPTACLE

(viewed from behind)

Ground

Main Power Cord

Model G0714 (Mfd. Since 03/24)

Slow-Blow

Fuse 15A

DUST COLLECTOR

POWER CORD w/PLUG

READ ELECTRICAL SAFETY

ON PAGE 38!

-39-

Switch Box

Assembly

Wiring Components

LED Light Assembly

Dust Collector

Motor

Dust Collector

Assembly

-40-

Figure 49. Wiring component locations.

READ ELECTRICAL SAFETY

ON PAGE 38!

Model G0714 (Mfd. Since 03/24)

10V3

SECTION 9: PARTS

We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability.

Blast Cabinet

11V2-2

11V2-1

11V2-5

11V2-3

2V2

1V2

11V2

15V2

16V3

41A

31V2

28V2

18-1

24V2

11V2-4

17-1

Model G0714 (Mfd. Since 03/24)

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Par ts Store.

-41-

Blast Cabinet Parts List

REF PART # DES CRIPTI ON REF P ART # DESCRIPTION

1V2 P0714001V2 HANGER BRACKET V2.03.24 24V2 P0714024V2 SWITCH BOX COVER V2.03.24 2V2 P0714002V2 FRONT DOOR V2.03.24 25 P0714025 TAP SCREW M4 X 6 3 P0714003 FRONT WINDOW SEAL 26 P0714026 FUSE HOLDER ASSEMBLY 4 P0714004 FRONT WINDOW REPLACEMENT FILM 27 P0714027 POWER CORD 14AWG 3C 6' 5-15 5 P0714005 INNER FRONT WINDOW 28V2 P0714028V2 SWITCH BOX V2.03.24 6 P0714006 OUTER FRONT WINDOW 29 P0714029 LATCH 7 P0714007 PHLP HD SCR M6-1 X 35 30 P0714030 LATCH BRACKET 8 P0714008 FRONT WINDOW FRAME 31V2 P0714031V2 WORK HANGER V2.03.24 9 P0714009 FRONT DOOR SEAL 32 P0714032 FRONT DOOR HANDLE 10V3 P0714010V3 LIGHT COVER V3.03.24 33 P0714033 GLOVE CLAMP 11V2 P0714011V2 LED LIGHT ASSEMBLY V2.05.22 34 P0714034 INNER GLOVE RING 11V2-1 P0714011V2-1 LED 18W 36" 35 P0714035 OUTER GLOVE RING 11V2-2 P0714011V2-2 LIGHT BRACKET 36 P0714036 GLOVE SET LEFT AND RIGHT 11V2-3 P0714011V2-3 LED 3-PIN CABLE 37 P0714037 NOZZLE CAP 11V2-4 P0714011V2-4 MAIN LED CORD 20G 3W 8" 38 P0714038 BLAST NOZZLE 6MM ID 11V2-5 P0714011V2-5 RIVET 4 X 10MM BLIND 39 P0714039 SEAL 12 P0714012 LIGHT WINDOW 40 P0714040 BLAST GUN BODY 13 P0714013 LIGHT WINDOW PROTECT FILM 41 P0714041 SLEEVE 14 P0714014 LIGHT WINDOW SEAL 41A P0714041A HOSE CONNECTOR 1/4" ASSEMBLY 15V2 P0714015V2 VENT COVER V2.03.24 42 P0714042 LOCK COLLAR 16V3 P0714016V3 BLAST CABINET V3.03.24 43 P0714043 HOSE CONNECTOR 1/4" 17 P0714017 FRONT DOOR SUPPORT 44 P0714044 QUICK CONNECTOR 12-G 1/4" 17-1 P0714017-1 SIDE ANCHOR POINT 45 P0714045 ADAPTER 18 P0714018 GAS SPRING 46 P0714046 AIR HOSE 18-1 P0714018-1 SIDE ANCHOR POINT 47 P0714047 HOSE CONNECTOR 3/8" 19 P0714019 CORD RACEWAY 48 P0714048 HOSE CLAMP 20 P0714020 ON/OFF SWITCH 49 P0714049 SAND HOSE 21 P0714021 LIGHT CORD 16AWG 3C 5' 50 P0714050 FUSE 15A 20 X 80MM 22 P0714022 WIRE CLIP 51 P0714051 BLAST NOZZLE 7MM ID 23 P0714023 ELECTRICAL RECEPTACLE 5-15

-42-

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Par ts Store.

Model G0714 (Mfd. Since 03/24)

116

118

115V2

Stand & Cabinet Base

102V2

103

104V2

105V2

101V2

102-1

101-12

101V2-1

114

112

106V2

101-11

107

101-2

101-3

101V2-4

101-10

117

101-6

113

101-5

101V2-7

111V2

108V2

101V2-8

109V2

101V2-9

110V2

REF PART # DES CRIPTI ON REF PART # DE SCRIPTIO N

101V2 P0714101V2 DUST COLLECTOR ASSY V2.03.24 104V2 P0714104V2 HOPPER V2.03.24 101V2-1 P0714101V2-1 MOTOR COVER 105V2 P0714105V2 HOPPER SUPPORT V2.03.24 101-2 P0714101-2 MOTOR 1.5HP 110V 1-PH 106V2 P0714106V2 HOPPER DUMP DOOR V2.03.24 101-3 P0714101-3 PHLP HD SCR M6-1 X 12 107 P0714107 HEX BOLT M8-1.25 X 20 101V2-4 P0714101V2-4 FILTER HOUSING 108V2 P0714108V2 LEG V2.03.24 101-5 P0714101-5 POWER CORD 14AWG 3C 4' 5-15 109V2 P0714109V2 SHORT BRACE 32-1/4" V2.03.24 101-6 P0714101-6 CARTRIDGE FILTER 5 MICRON 110V2 P0714110V2 LONG BRACE 43-3/4" V2.03.24 101V2-7 P0714101V2-7 CANISTER 111V2 P0714111V2 FOOT VALVE ASSEMBLY V2.03.24 101V2-8 P0714101V2-8 CANISTER PLUNGER ASSEMBLY 112 P0714112 AIR REGULATOR BRACKET 101V2-9 P0714101V2-9 DOOR W/HINGE & LATCH ASSY 113 P0714113 AIR HOSE 101-10 P0714101-10 HOUSING LATCH ASSEMBLY 114 P0714114 FUNNEL DRAIN DOOR LATCH 101-11 P0714101-11 CARBON BRUSH SET 1-PAIR 115V2 P0714115V2 LEFT WORK TABLE V2.03.24 101-12 P0714101-12 BRUSH HOLDER 116 P0714116 SUCTION TUBE 102V2 P0714102V2 RIGHT WORK TABLE V2.03.24 117 P0714117 AIR REGULATOR ASSEMBLY 0-125MPA 102-1 P0714102-1 RUBBER PROTECTOR 118 P0714118 PHLP HD SCR M6-1 X 16 103 P0714103 HOPPER SEAL

Model G0714 (Mfd. Since 03/24)

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Par ts Store.

-43-

grizzly.com

Labels & Cosmetics

207

206

WARNING!

205

NOTICE

• Recommended Operating Air Pressure is 80 PSI.

• Clean dust collector cartridge regularly. Blow air through the cartridge from the inside out.

• Check and drain the moisture trap regularly.

• With every use, inspect gloves and hoses for leaks. Replace worn or damaged parts as needed.

• With every use, inspect spray hose for soft spots. Replace worn or damaged parts as needed.

• Do not over-fill the hopper. Periodically drain the hopper completely and refill with new media.

• Every three months, perform a full inspection on all fittings, gun parts, hoses, and cartridge filter. Replace worn or damaged parts as needed.

Troubleshooting

If flow of media is obstructed, check metering valve and media hose for obstructions. Blow compressed air back through gun and hoses to free any clogs. If flow of media begins, then stops again, drain and replace all media. Disassemble and clean the gun, hoses, and metering valve, then reassemble. If air still does not

flow, drain and clean moisture trap. See Owner’s

manual for more troubleshooting information.

213

204

WARNING!

BLAST INJURY/

SHOCK HAZARD! Disconnect power and air supply before adjustments, maintenance, or service.

203

WARNING!

AIR PRESSURE

HAZARD!

DO NOT exceed

125 PSI

when using this

product.

202

G0714

201

Specifications

Motor: 1.5 HP, 110V, 1-Ph, 60 Hz Full-Load Current Rating: 11A Max. Air Pressure: 125 PSI Air Volume Required: 5–35 CFM Abrasive Media Type: Glass Beads, Silicon Carbide, Emery, Plastic, Sand Weight: 352 lbs.

Date

S/N

Mfd. for Grizzly in China

203

WARNING!

AIR PRESSURE

HAZARD!

DO NOT exceed

125 PSI

when using this

product.

212V2

MODEL G0714

INDUSTRIAL BLAST CABINET

WARNING!

To reduce the risk of serious personal injury while using this machine:

1. Read and understand manual before using machine.

2. Always wear approved eye protection and NIOSH-approved respirator.

3. Keep all guards in place at all times, and make sure cabinet remains sealed.

4. Operate machine only when stable and on flat, level ground.

5. Disconnect air supply and power before loading and unloading workpiece, changing blast tips, and prior to servicing,

maintaining, or adjusting machine.

6. Do not operate under influence of drugs or alcohol, or if tired.

7. Prevent unauthorized use by children or untrained users.

208

WARNING!

EYE / FACE / LUNG

INJURY HAZARD! Always wear a face shield and a respirator when using this machine.

210

WARNING!

To reduce risk of death or serious injury, read manual BEFORE using machine. To get a new manual, call (800) 523-4777 or go to www.grizzly.com.

211

PINCH HAZARD!

Keep hands away from door opening and use the handles when closing the door.

204

WARNING!

BLAST INJURY/

SHOCK HAZARD! Disconnect power and air supply before adjustments, maintenance, or service.

209

CANISTER PLUNGER

PUSH IN, THEN RELEASE RAPIDLY TO KNOCK DUST LOOSE FROM THE FILTER CARTRIDGE.

Filter cartridge should be cleaned with compressed air after every 5 hours of

operation. See Owner’s Manual for more

information on this procedure.

REF PART # DESCRI PTION REF PART # DESCRI PTION

201 P0714201 MACHINE ID LABEL 208 P0714208 GOGGLES/RESP. WARNING LABEL 202 P0714202 MODEL NUMBER LABEL 209 P0714209 PLUNGER INSTRUCTION LABEL 203 P0714203 AIR PRESSURE HAZARD LABEL 210 P0714210 READ MANUAL LABEL 204 P0714204 DISCONNECT WARNING LABEL 211 P0714211 PINCH HAZARD LABEL 205 P0714205 NOTICE/TROUBLESHOOTING LABEL 212V2 P0714212V2 TOUCH-UP PAINT, GRIZZLY BLACK 206 P0714206 DUST HAZARD WARNING LABEL 213 P0714213 TOUCH-UP PAINT, GRIZZLY GREEN 207 P0714207 GRIZZLY.COM LABEL

Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes off or becomes unreadable, the owner of this machine MUST replace it in the original location before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.

-44-

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Par ts Store.

Model G0714 (Mfd. Since 03/24)

WARRANTY & RETURNS

Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse,

negligence, accidents, repairs or alterations or lack of maintenance. This is Grizzly’s sole written warranty

and any and all warranties that may be implied by law, including any merchantability or fitness, for any particular purpose, are hereby limited to the duration of this written warranty. We do not warrant or represent that the merchandise complies with the provisions of any law or acts unless the manufacturer so warrants.

In no event shall Grizzly’s liability under this warranty exceed the purchase price paid for the product and

any legal actions brought against Grizzly shall be tried in the State of Washington, County of Whatcom.

We shall in no event be liable for death, injuries to persons or property or for incidental, contingent, special, or consequential damages arising from the use of our products.

The manufacturers reserve the right to change specifications at any time because they constantly strive to achieve better quality equipment. We make every effort to ensure that our products meet high quality and durability standards and we hope you never need to use this warranty.

In the event you need to use this warranty, contact us by mail or phone and give us all the details. We will

then issue you a “Return Number,’’ which must be clearly posted on the outside as well as the inside of

the carton. We will not accept any item back without this number. Proof of purchase must accompany the merchandise.

Please feel free to write or call us if you have any questions about the machine or the manual.

Thank you again for your business and continued support. We hope to serve you again soon.

For further information about the

scan the QR

code below

to be automatically directed to our warranty page.

warranty, visit https://www.grizzly.com/forms/warranty or

WARRANTY

Grizzly G0714 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

INTRODUCTION

Manual Accuracy

Contact Info

Machine Description

Identification

Machine Data Sheet

SECTION 1: SAFETY

Safety Instructions for Machinery

Additional Safety for Blast Cabinets

SECTION 2: POWER SUPPLY

SECTION 3: SETUP

Needed for Setup

Unpacking

Inventory

Site Considerations

Mounting

Air System Setup

Pneumatic Diagram

Assembly

Test Run

SECTION 4: OPERATIONS

Preparation

Basic Operation

Operation Tips

Blasting Media

SECTION 5: ACCESSORIES

SECTION 6: MAINTENANCE

Schedule

Cleaning

SECTION 7: SERVICE

Troubleshooting

Filter Replacement

LED Replacement

SECTION 8: WIRING

Wiring Safety Instructions

Wiring Diagram

Wiring Components

SECTION 9: PARTS

Blast Cabinet

Stand & Cabinet Base

Labels & Cosmetics

WARRANTY & RETURNS
