Split Air Conditioner
Owner's Manual Residential Air Conditioners
Thank you for choosing Residential Air Conditioners,please read this owner’s
manual carefully before operation and retain it for future reference.
GWC07NA-K3NNB1A
GWH07NA-K3NNB1A
GWH18ND-K3NNB1A
GWH09NA-K3NNB1A GWH12NB-K3NNB1A GWH24ND-K3NNB1A
GWC07NA-K3NNB2A
GWH07NA-K3NNB2A
GWC09NA-K3NNB2B GWC12NB-K3NNB2B GWC18ND-K3NNB2B
GWH18ND-K3NNB2A
GWH09NA-K3NNB3A
GWH18ND-K3NNB3A GWH24ND-K3NNB3A
GWH07NA-K3NNB4A
GWH09NA-K3NNB3B GWC09NA-K3NNB3C GWC09NA-K3NNB3B
GWH12NB-K3NNB3A
GWH09NA-K3NNB4A GWH18ND-K3NNB4A
GWH09NA-K3NNB2A GWH12NB-K3NNB2A GWH24ND-K3NNB2A
GWC12MB-K3NNC1A
GWH12NB-K3NNB4A GWH24ND-K3NNB4A
GWH24ND-K3NNB5A
GWH24ND-K3NNB6A
GWH12NB-K3NND2A
GWH24ND-K3NNB8A
GWH24ND-K3NNB7A
GWH24ND-K3NNA1A
GWH07NA-K3NNA2A GWH12NB-K3NNA2A
GWH07NA-K3NNA3A
GWH18ND-K3NNA3A
GWH07NA-K3NNA4A GWH09NA-K3NNA4A
GWH24ND-K3NNA4A
GWH09NA-K3NNA2A
GWH24ND-K3NNA2A
GWH12NB-K3NNA3A
GWH18ND-K3NNA4AGWH12NB-K3NNA4A
GWH09NA-K3NNA3A
GWH24ND-K3NNA3A
GWH07NA-K3NNA5A GWH09NA-K3NNA5A GWH12NB-K3NNA5A GWH18ND-K3NNA5A
GWH24ND-K3NNA5A
GWH24ND-K3NNA7A
GWH18ND-K3NNA8A
GWH09NA-K3NNA8AGWH07NA-K3NNA8A
GWH24ND-K3NNA8A
GWH12NB-K3NNA8A
CONTENTS
Operation and maintenance
Notices for operation
■
Notices for use
■
Specificate Model and Technical Data
■
Names and functions of each part
■
Operation of wireless remote control
■
Emergency Operation
■
■ ................................................................. 13
Clean and care
Troubleshooting
■
............................................................ 1
................................................................... 3
..................................... 5
.......................................... 8
....................................... 9
......................................................... 12
............................................................... 15
Installation service
Notices for installation
■ ........................................................ 18
Installation dimension diagram
■ ............................................. 20
Install indoor unit
■ .............................................................. 21
■
Install outdoor unit
............................................................. 24
Check after installation and test operation
■
Installation and Maintenance of Healthy Filter
■ .......................... 26
Configuration of connection pipe and additional volume of refrigerant............
■
This symbol stands for the items should be forbidden.
The products in this manual may be different with the real one, according to different models, some models have displayer and some models without displayer, the position and shape of the displayer please refer to the real one.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary.
.............................. 25
27
This symbol stands for the items should be followed
Operation and maintenance-notices for operation
Earth: The ground be
★
connected!
If not, please ask the qualified person­nel to install. Furthermore, don't conn­ect each wire to the gas pipe, water pipe, drainage pipe or any other impr­oper places.
★
Don't leave windows and doors open for a long time while operating the air conditioner.
Be sure to pull out the power plug
★
when not using the air conditioner for a long time.
Otherwise, the accumulated dust may cause fire or electric shock.
Don't block the air intake or outlet
★
vents of both the outdoor and indoor units.
★
Select the most appropriate temper-
ature.
Keep room cool­er than outside about 5 degree.
It can preclude the electricity wasted.
★
Keep combustible spray away from the units more than 1m.
It can decrease the air conditioning capacity.
Please note whether the installed
★
stand is firm enough or not.
If it is damaged, it may lead to the fall of the unit and cause the injury.
It can decrease the air conditioning capacity or cause a malfunction.
Don't step on the top of the
★
outdoor unit or place something on it.
As falling off the outdoor unit can be dangerous.
1
It can cause a fire or explosion.
★
Don't attempt to repair the air conditioner by yourself.
The wrong repair will lead to an electric shock or fire, so you should contact the service center to repair.
Notices for operation
If the supply cord is damaged, it must be replaced
★
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
The airflow direction can be adjusted appro-
★
priately. At operating, adjust the vertical airflow direction by adjusting the louvers of upward/do­wnward direction. And then, hold two ends of left and right louver to adjust the horizontal air­flow.
Don't insert your hands or stick into the air
★
intake or outlet vents.
Otherwise it will cause accident.
Don't apply the cold wind to the body for a
★
long time.
It can cause the health problems.
★
Splashing water on the air conditioner can
cause an electric shock and malfunction.
Louver of left/right direction Louver of upward/
Don't blow the wind to animals and plants
★
directly. It can cause a bad influence to them.
Don't use the air conditioner for other purposes,
★
such as drying clothes, preserving foods, etc.
★
Don't place a space heater near the air conditioner.
downward direction.
Or CO toxicosis may occur for imcomplete burning.
2
Notices for use
Working principle and special functions for cooling
Principle:
Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature.
Anti-freezing function:
If the unit is running in COOL mode and in low te the heat exchanger, when indoor heat exchanger temperature decreased below 0 , the indoor unit microcomputer will stop compressor running and protect the unit.
Working principle and special functions for heating
Principle:
Air conditioner absorbs heat from outdoor and transmits to indoor, in this way to increase
*
room temperature. This is the heat pump heating principle, its heating capacity will be reduced due to outdoor temperature decrease. If outdoor temperature becomes very low, please operate with other heating equipments.
*
Defrosting:
When outdoor temperature is low but high humidity, after a long while running, frost will
*
form on outdoor unit, that will effect the heating effect, at this time, the auto defrosting function will act, the heat running will stop for 8-10mins. During the auto defrosting, the fan motors of indoor unit and outdoor unit will stop.
*
During the defrosting, the indoor indicator flashes, the outdoor unit may emit
*
This is due to the defrosting, it isn't malfunction.
After defrosting finished,the heating will recover automatically.
*
mperature, there will be frost formed on
vapor.
℃
Anti-cool wind function:
In "Heat" mode, under the following three kinds of state, if indoor heat exchanger doesn't arrive at certain temp., indoor fan will not act, in order to prevent cool wind blowing(within 2 mins):
1. Heating starts.
2. After Auto Defrost finished.
3. Heating under the low temperature.
3
Notices for use
Gentle Breeze
In the following situation, the indoor unit may blow gentle breeze, and the guide louver rotate to a certain position:
1. In “Heat” mode, the unit turned on, the compressor doesn’t arrive the starting condition
2. In “Heat” mode, the temperature arrive at the setting value and the compressor stop running about 1min.
Working temperature range
Maximum cooling
Maximum heating
Indoor sideDB/WB(oC)
32/23
27/---
Outdoor sideDB/WB(oC)
43/26
24/18
.
The operating temperature range (outdoor temperature) for cooling only unit is 18℃~ 43℃ for heat pump unit is -7℃~ 43℃.
;
4
Specificate Model and Technical Data
1004
GWC12NB-K3NNB1B
GWC12NB-K3NNB2B
GWC12NB-K3NNA2B
GWC12MB-K3NNC1A GWC12NB-K3NNB3B
GWC09NA-K3NNB2C
GWC09NA-K3NNA8C
GWC12NB-K3NNA3B
GWC12NB-K3NNA8B
220-240V～
50Hz
1075
821
1450
1500
1000
0.90kg
1.04kg
0.75kg
R410A R410A R410A
Indoor unit:
Indoor unit：
Indoor unit：
Outdoor unit:
790X265X177
Outdoor unit:
790X265X175
Outdoor unit:
730X255X174
776X540X320
848X540X320
776X540X320
GWC09NA-K3NNB1B
GWC09NA-K3NNB2B
GWC09NA-K3NNA2B
GWC09NA-K3NNB3B GWC09NA-K3NNB3C
GWC07NA-K3NNB1A
GWC07NA-K3NNB2A
Model
GWC09NA-K3NNA3B
GWC09NA-K3NNA8B
GWC09NA-K3NNA5B
Cooling Cooling Cooling Cooling Cooling
Function
Rated voltage(V)
778
700
Rated frequency
Cooling power(W)
5
1100
1000
Rated power input(W)
0.64kg
R410A
R410A
Indoor unit:
0.62kg Indoor unit:
Refrigerant volume(kg)
Outdoor unit:
730X255X174
730X255X174
(Indoor/outdoor) outline
776X540X320
Outdoor unit:
720X428X310
dimension(W X H X D)mm
Specificate Model and Technical Data
Cooling
GWC24ND-K3NNA8B
GWC24ND-K3NNB1B
GWC24ND-K3NNA3B
GWC24ND-K3NNB2B
GWC24ND-K3NNB3B
GWC24ND-K3NNA2B
1900
2600
1.3kg
R410A
Indoor unit:
Outdoor unit:
940X298X200
913X680X378
GWC18ND-K3NNB1B
GWC18ND-K3NNB2B
GWC18ND-K3NNA2B
GWC18ND-K3NNA3B
GWC18ND-K3NNB3B
GWC18ND-K3NNA5B
GWC18ND-K3NNA8B
GWC18ND-K3NNB4B
GWC18ND-K3NNA4B
GWC18ND-K3NNB1C
Model
Cooling
220-240V～
Cooling
Function
Rated voltage(V)
1460
50Hz
1495
power(W)
Rated frequency
Cooling
1980
2040
Rated power input(W)
1kg
R410A
R410A
Refrigerant volume(kg)
Indoor unit:
0.8Kg
Indoor unit:
Outdoor unit:
940X298X200
940X298X200
(Indoor/outdoor) outline
848X540X320
Outdoor unit:
848X540X320
dimension(W X H X D)mm
6
Specificate Model and Technical Data
GWH24ND-K3NNB1A
GWH24ND-K3NNB2A
GWH24ND-K3NNB3A
GWH24ND-K3NNB4A
GWH24ND-K3NNB5A
GWH24ND-K3NNB6A
GWH24ND-K3NNB7A
GWH24ND-K3NNB8A
GWH24ND-K3NNA1A
GWH24ND-K3NNA2A
GWH18ND-K3NNB1A
GWH18ND-K3NNB2A
GWH18ND-K3NNB3A
GWH18ND-K3NNA3A
GWH18ND-K3NNA5A
GWH18ND-K3NNB4A
GWH18ND-K3NNA2A
GWH18ND-K3NNA8A
GWH18ND-K3NNA4A
GWH12NB-K3NNB1A
GWH12NB-K3NNB2A
GWH12NB-K3NNB3A
GWH12NB-K3NNA3A
GWH12NB-K3NNA5A
GWH12NB-K3NNA4A
GWH12NB-K3NNA2A
GWH12NB-K3NNA8A
GWH12NB-K3NNB4A
GWH09NA-K3NNB1A
GWH09NA-K3NNB2A
GWH09NA-K3NNA3A
GWH09NA-K3NNA5A
GWH09NA-K3NNA4A
GWH09NA-K3NNB4A
GWH09NA-K3NNA2A
GWH09NA-K3NNA8A
GWH09NA-K3NNB3A
GWH09NA-K3NNB3B
8A
GWH24ND-K3NNA3A
GWH24ND-K3NNA4A
GWH24ND-K3NNA5A
GWH24ND-K3NNA7A
GWH12NB-K3NND2A
Cooling and Heating
GWH24ND-K3NNA8A
Cooling and Heating
Cooling and Heating
Cooling and Heating
Cooling and Heating
1900/1900
2600/2700
1460/1430
1980/1980
1004/973
821/779
778/734
1450/1400
1000/1120
1100/1120
～
50Hz
220-240V
1.45kg
1.15kg
0.84kg
0.76kg
R410A R410A R410A R410A
0.85kg
R410A
Indoor unit:
Outdoor unit:
940X298X200
Indoor unit:
Outdoor unit:
940X298X200
Indoor unit:
Outdoor unit:
790X265X175
Indoor unit:
Outdoor unit:
730X255X174
Indoor unit:
Outdoor unit:
730X255X174
t:
913X680X378
848X540X320
776X540X320
776X540X320
776X540X320
GWH07NA-K3NNB1A
GWH07NA-K3NNB2A
GWH07NA-K3NNA3A
GWH07NA-K3NNA5A
GWH07NA-K3NNA4A
GWH07NA-K3NNB4A
GWH07NA-K3NNA2A
GWH07NA-K3NNA
Model
GWH07NA-K3NNB3A
Cooling and Heating
Function
685/659
Rated voltage(V)
Rated frequency
Cooling / heating
power(W)
7
0.76kg
R410A
1000/1060
Rated power input(W)
Refrigerant volume(kg)
Indoor uni
Outdoor unit:
720X430X310
730X255X174
(Indoor/outdoor) outline
dimension(W X H X D)mm
Names and functions of each part
Indoor unit
Air in
⑶
⑴
⑷
⑸
The pattern in displayer：
：Cool
：Dry
：Heat
Run
：
：Set temp.
Outdoor unit
Air in
Air out
⑵
Wireless
remote control
⑹
⑻
⑺
⑴ ⑵ ⑶ ⑷ ⑸ ⑹
⑺ ⑻ ⑼
⑼
Power cable
Remote control
Front panel
Filter
Guide louver
Wall pipe
Bind tape
Connection wire
Drainage pipe
Air out
8
Operation of wireless remote control
Remote Controller Description
1
ON/OFF
Press it to start or stop operation.
2
MODE
Press it to select operation mode (AUTO/COOL/DRY/FAN/HEAT).
3
: Press it to decrease temperature
1
3
5
7
2
4
6
8
-
setting.
4
+
: Press it to increase temperature
setting.
5
FAN
Press it to set fan speed.
6
SWING
Press it to set swing angle.
7
SLEEP( page 10)
8
TIMER (page 11)
Press it to set auto-on/auto-off timer.
9
Operation of wireless remote control
Remote controller description
1
ON/OFF :
Press this button to turn on the unit. Press this button again to turn off the unit.
2
MODE :
Each time you press the button, a mode is selected in a sequence that goes from AUTO, COOL, DRY, FAN,and HEAT
AUTO
, as the following:
*
COOL
DRY
FAN HEAT *
*Note: Only for models with heating
:
3
-
Press this button to decrease set temperature. Hold it down for above 2 seconds to
rapidly decrease set temperature. In AUTO mode, set temperature is not adjustable.
+
4
:
Press this button to increase set temperature. Hold it down for above 2 seconds to rapidly increase set temperature. In AUTO mode, set temperature is not adjustable.
5
FAN
:
This button is used for setting Fan Speed in the sequence that goes from AUTO,
to
,
6
SWING
:
Press this key to activate or deactivate the swing.
7
SLEEP :
Press this button to go into the SLEEP operation mode. Press it again to cancel this function. This function is available in COOL, HEAT (Only for models with heating function) or DRY
mode to maintain the most comfortable temperature for you.
, then back to Auto.
Auto
Speed 1 Speed 2 Speed 4
function.
Speed 3
,
10
Operation of wireless remote control
TIMER:
8
Press this button to initiate auto-on/auto-off timer. To cancel auto-timer program, press this button twice.
Combination of "+" and "-" buttons: About lock
9
4
Press "+ " and "-" buttons simultaneously
10
Combination of "MODE" and "-" buttons: About switch between fahrenheit and cenrigrade
At unit OFF, press
11
Combination of "+" and "FAN" buttons: About Lamp
Under switch-on or switch-off state, you may hold "+" and "FAN" buttons simultaneously for 3 seconds to set the lamp on or off and send the code. After being energized, the lamp is
defaulted on.
1.Remove the battery cover plate from the rear of the remote controller.
(As shown in the figure)
2.Take out the old batteries.
3.Insert two new AAA1.5V dry batteries, and pay attention to the polarity.
4. Reinstall the battery cover plate.
★
Notes:
When replacing the batteries, do not use old or different types of batteries,
●
otherwise, it may cause malfuncti
If the remote controller will not be used for a long time, please
●
remove batteries to prevent batteries from leaking.
The operation should be performed in its receiving range.
●
It should be kept 1m away from the TV set or stereo sound sets.
●
If the remote controller does not operate normally, please take the
●
batteries out and reinsert them after 30 seconds. If it still can't operate properly,
replace the batteries.
"
MODE
"
and
- " "
Replacement of Batteries
on.
to lock or unlock the keypad.
buttons simultaneously to switch between and .
℃
Fig.1
2
Fig.
℉
11
Emergency Operation
Emergency operation
If the wireless remote control is lost or broken,
please use the manual switch button. At this time, the unit will run at the Auto mode, but the temperature
and fan speed cannot be changed. The operation was shown as below:
To open the panel, the manual switch is on the
displayer box.
●
Turn on the unit: At unit turned off, press the button, the unit will run at Auto mode immediately.The microcomputer will accord to the indoor temperature to select (Cooling, Heating, Fan) and obtain the comfortable effect.
●
Turn off the unit: At unit turned on, press the button, the unit will stop working.
Manual switch
Fig.3
12
Clean and care
Caution
●
Disconnect the power supply
Never sprinkle water on the indoor unit and the outdoor unit for cleaning because it can cause an
●
electric shock.
Volatile liquid (e.g. thinner or gasoline) will damage the air conditioner. (So wipe the units with a
●
dry soft cloth, or a cloth slightly moistened with water or cleanser.)
When cleaning the front panel, please dip the cloth into the water temperature of 45 below, then to dry the cloth and wipe the dirty part.
Note: Please do not to immerse the front panel in water, due to there are microcomputer components and
circuit diagrams on the front panel.
Clean the air filter (Recommended once every three months)
NOTE: If dust is much more around the air conditioner, the air filters should be cleaned many times. After taking off the filter, don't touch the fin of indoor unit, in order to avoid hurt your fingers.
①
Take down the air filter
At the slot of surface panel to open an angle, pull the air filter downward and take it out, please see the Fig. 4(a, b).
before cleaning air conditioner, or it may cause electric shock.
Clean the front panel
℃
( a)
② Clean the air filter
To clean the dust adhering to the filters, you can either use a vacuum cleaner, or wash them with warm water the water with the neutral detergent should below 45 degree) ,and dry it in the shade.
NOTE: Never use water above 45 to clean, or it can cause deformation or discoloration. Never parch it by fire, or can cause a fire or deformation.
③
Insert the air filter
Reinsert the filters along the direction of arrowhead, and then to cover the cover and clasp it.
℃
13
( b)
Fig.4
Clean and care
Check before use
① Be sure that nothing obstructs the air outlet and intake vents.
Check that whether ground wire is properly connected or not.
②
Check that whether the batteries of air conditioner are
③
changed or not.
④ Check that whether the installation stand of the outdoor
unit is damaged or not. If damaged, please contact the dealer.
Maintain after use
Switch off the power supply.
①
Clean the filter and indoor and outdoor units' bodies.
②
Clear dust and obstructions from the outdoor unit.
③
④
Repaint the rubiginous place on the outdoor unit to prevent it from spreading.
Adopt the special shield to cover the outdoor unit, avoid the rain water, dust enter into
⑤
the unit and get rust.
14
Troubleshooting
CAUTION
Don't attempt to repair the air conditioner by yourself, it can cause an electric shock or fire. Please check the following items before asking for repair, it can save your time and money.
Phenomenon
Not operate immediately when the air conditioner is restarted.
There's unusual smell blowing from the outlet after operation is started.
Sound of water flow can be heard during the operation.
In COOL mode, sometimes the mist emitted from the air outlet vent.
Waiting
Troubleshooting
●
Once the air conditioner is stopped, it will not operate in approximately 3 minutes to protect itself.
●
The unit has no peculiar smell by itself. If has, that is due to the smell accumulated in the ambient.
●
Solution method: Cleaning the filter. If problem still has, so need to clean air conditioner. (Please contact with the authorized maintenance center.)
●
The air conditioner is started, when it is running the compressor started or stopped running, or the unit is stopped, sometimes there is swoosh or gurgle, the sound is due to refrigerant flowing they are not malfuncti­ons.
When the indoor temperature and humidity
●
are very high, this phenomenon would
happen. This is caused by the room air is swiftly cooled down. After running for a while, indoor temperature and humidity will fall down, the mist will die awa y.
Creaking noise can be heard when start or stop the unit.
●
This is caused by the deformation of plastic due to the changes of temperature.
15
Troubleshooting
Phenomenon
The unit can not run.
Breaking off
Cooling(Heating) efficiency is not good.
Wireless remote control is not available.
Troubleshooting
●
Has the power been shut down?
●
Is power plug loosed?
●
Is the circuit protection device tripped off or not?
Is voltage higher or lower?
●
(Tested by professionals)
●
Is the TIMER correctly used?
Is Temp. setting suitable?
●
●
Were inlet and outlet vents obstructed?
●
Is filter dirty?
●
Are the windows and doors clothed?
●
Did Fan speed set at low speed? Is there any heat sources in the room?
●
●
The unit is interfered by abnormal or frequent
functions switchover occasionally the controller
cannot operate. At this time, you need to pull out
of the plug, and reinsert it.
Is it in its receiving range? Or obstructed?
●
To check the voltage in wireless remote control inside
is charged, otherwise to replace the batteries.
●
Whether the wireless remote control is damaged.
If water leakage in the room. The air humidity is on the high side.
●
Condensing water over flowed.
●
●
The connection position of indoor unit drainage pipe is loosed.
If water leakage in outdoor unit. When the unit is running in COOL mode, the pipe
●
and connection of pipe would be condensed due to the water cooled down.
●
When the unit is running in Auto Defrosting mode the ice thawed and flowed out.
●
When the unit is running in HEAT mode, the water adhered on heat exchanger dripped off.
Noise from indoor unit emitted. The sound of fan or compressor relay is switching
●
on or off.
●
When the defrosting is started or stop running,
it will sound. That is due to the refrigerant flowed
to the reverse direction.
16
Troubleshooting
Phenomenon
Indoor unit cannot deliver air.
Moisture on air outlet vent.
H1: Defrosting
Immediately stop all operations and plug out, contact the dealer in following situations.
Troubleshooting
●
In HEAT mode, when the temperature of indoor heat exchanger is very low, that will stop deliver air in order to prevent cool air. (Within 2min)
●
In HEAT mode, when the outdoor temperature is low or high humidity, there are much frost be formed on the outdoor heat exchanger, that the unit will automatically defrost, indoor unit stop blowing air for 3-12min. During the defrosting, there is water flowing out or vapor be produced.
●
In dehumidifying mode, sometimes indoor fan will stop, in order to avoid condensing water be vapo­rized again, restrain temperature rising.
●
If unit is running under the high humidity for a long time, the moisture will be condensed on the air outlet grill and drip off.
● It is normal.
There is harsh sound during operation.
The terrible odors emitted during operation.
Water is leaking in the room.
Air switch or protection switch often breaks.
Carelessy splash water or something into unit.
There is an abnormal heat in power supply cord and power plug.
17
Stop running and disconnect the power supply.
Notices for installation
Important Notices
1. The unit installation work must be done by qualified personnel according to the local rules and this manual.
2. Before installation, please contact with local authorized maintenance center, if unit is not installed by the authorized maintenance center, the malfunc tion may not solved,
due to discommodious contacts.
3. When removing the unit to the other place, please firstly contact with the authorized
Maintenance Center in the local ar
Basic Requirements For Installation Position
Install in the following place may cause malfunction. If it is unavoidable contact with service center please:
●
Place where strong heat sources, vapors, flammable gas or volatile object are emitted.
●
Place where high-frequency waves are generated by radio equipment, welders and medical equipment.
●
Place where a lot of salinities such as coast exists.
●
Place where the oil (machine oil) is contained in the air.
●
Place where a sulfured gas such as the hot spring zones is generated.
●
Other place with special circumstance.
Indoor Unit Installation Position Selection
The air inlet and outlet vent should be far from the obstruction, make sure that the air
1. can be blown through the whole room.
2. Select a position where the condensing water can be easily drained out, and the place is easily connected for outdoor unit .
3. Select a location whe
re the children can not reach .
4. Can select the place where is strong enough to withstand the fu ll weight and vibration of the unit. And will not increase the noise . Be sure to leave enough space to allow access for routine maintenance. The height of the
5. installed location should be 250cm or more from the floor. Select a place about 1m or more away from TV set or any other electric appliances.
6. Select a place where the filter can be easily taken out.
7. Make sure that the indoor unit installation should accord with installation dimension
.
8
diagram requirements.
. Do not use the unit in the immediate surroundings of a laundry a bath a shower or a
9
swimming pool.
Outdoor Unit Installation Position Selection
1. Select a location from which noise and outflow air emitted by unit will not inconvenience neighbors, animals, plants.
2. Select a location where there should be sufficient ventilation.
3. Select a location where there should be no obstructions cover the inlet and outlet vent.
4. The location should be able to withstand the full weight and vibration of the outdoor unit and permit safe installation.
5. Select a dry place, but do not expose under the direct sunlight or strong wind. Make sure that the outdoor unit installation dimension should accord with installation
6. dimension diagram, convenient for maintenance, repair.
7.
The height difference of connecting the tubing within 5m, the length of connecting the tubing within 10m.
8.
Select a place where it is out of reach for the children.
9.
Select a place where will not block the passage and do not influence the city appearance.
ea.
18
Notices for installation
Safety Requirements For Electric Appliances
1. The power supply should be used the rated voltage and AC exclusive circuit,the power
cable diameter should be satisfied.
2. Don't drag the power cable emphatically.
It should be reliably earthed, and it should be connected to the special earth device,
3.
the installation work should be operated by the professional.
4. The min. distance from the unit and combustive surface is 1.5m.
5. The appliance shall be installed in accordance with national wiring regulations.
An all-pole disconnection switch having a contact separation of at least 3mm in all poles
6. should be connected in fixed wiring. For models with a power plug, make sure the plug is within reach after installation.
7. Including an air switch with suitable capacity, please note the following table. Air switch should be included magnet buckle and heating buckle function, it can protect the circuit-short and overload. (Caution: please do not use the fuse only for protect the circuit)
Air switch capacityAir-conditioner (W)
07、09K
12K
24K
、18
Note:
●
Make sure that the Live wire or Zero line as well as the earth wire in the family power socket can not be wrong connected, there should be reliable and no short circuit in the diagram.
●
wrong connection may cause fire.
●
GWH18ND-K3NNA2A, GWH18ND-K3NNA4A, GWH18ND-K3NNA8A, GWH18ND-K3NNB3A, GWH18ND-K3NNB4A can be connected only to a supply with system impedance no more than 0.232 ohm. In case necessary, please consult your
supply authority for system impedance information.
Earthing requirements
10A
16A
25A
1. Air conditioner is type I electric appliance, thus please do conduct reliable earthing measure.
2. The yellow-green two-color wire in air conditioner is earthing wire and cannot be used
for other propose. It cannot be cut off and be fix it by screw, otherwise it would cause electric shock.
3. The earth resistance should accord to the National Criterion.
4. The user power must offer the reliable earthing terminal. Please don't connect the
earthing wire with the following place:
① ②
Tap water pipe. Gas pipe.
④
Other places that professional personnel consider them unreliable.
③
Contamination pipe.
5. The model and rating values for fuses according the silk print on fuse cover or related PCB board.
19
Installation dimension diagram
Installation dimension diagram
Space to the ceiling
15cm
Above
15cm
Above
Space to the wall
Space to the wall
15cm Above
300cm
Above
Air outlet side
250 cm
Above
Space to the floor
●
The dimensions of the space necessary for correct installation of the appliance including the minimum permissible distances to adjacent structures
Space to the obstruction
30cm Above
Space to the wall
200cm Above
Air outlet side
evob
50cm A
Air inlet side
30cm Above
Space to the wall
50cm A
bove
20
Install indoor unit
Install the rear panel
1.Always mount the rear panel horizontally. Due to the water tray of indoor unit has been adopted the both-way drainage design, the outlet of water tray should be adjusted slightly down when installing, that is taking the outlet of the water tray as the center of a circle, the included angle between the evaporator and level should be 0 or more, that is good for condensing water drainage.
2.Fix the rear panel on the wall with screws. (Where is pre-covered with plastic granula)
3.Be sure that the rear panel has been fixed firmly enough to withstand the weight of an
adult of 60kg, further more, the weight should be evenly shared by each screw.
1.Make the piping hole (Ф55) in the wall at a slight downward slant to the outdoor side.
2.Insert the piping-hole sleeve into the hole to prevent the connection piping and wiring from being damaged when passing through the hole.
Install the water drainage pipe
1. Connect the drain hose to the outlet pipe of the indoor unit.Bind the joint with rubber belt.
Wall
Mark on the middle of it
Space to the wall
mm 0 5 1
above
Left
(Rear piping hole)
mm5 5 Φ
Install the piping hole
Fig.5
Gradienter
(Rear piping hole)
Indoor Outdoor
Wall pipe
Space to the wall
above
Right
Seal pad
Wall
mm0 5 1
mm5 5 Φ
Φ55
2.
Put the drain hose into insulating tube.
3.
Wrap the insulating tube with wide rubber belt to prevent the shift of insulating tube. Slant the drain hose downward slightly for smooth drainage of condensate.
Note: The insulating tube should be connected reliably with the sleeve outside the outlet pipe. The drain hose should be slanted downward slightly, without distortion, bulge or fluctuation. Do not put the outlet in the water.
21
outlet pipe of indoor unit
rubber belt
outlet pipe of indoor unit
outlet pipe of indoor unit
bulge
drain hose
rubber belt
rubber belt
connected
outlet pipe of indoor unit
drain hose
insulating tube
insulating tube
distortion
Flooded
Install indoor unit
Connect indoor and outdoor electric wires
1.Open the surface panel.
2.Remove the wiring cover Fig.6.
3.Route the power connection cord and signal control wire (for heat pump type only) from the back of the indoor unit and pull it toward the front through the wiring hole for connection.
4.Connect the interconnection cord to the terminal block, and then fix the cord with cord anchorage.
5.Reassemble the clamp and wiring cover.
05 、07、09 、1 2、1 4 、15K、24K
GWC18ND-K3NNB1C
Heat pump type:
09、05、07、 12K
violet
Cool only type:
yellow-
green
yellow-
green
18K Cool only type
(for some model)
yellow-
green
18K
Heat pump type: Heat pump type:
yellow­green
violet
24K
yellow-
green
brown
violet
Fig.6
NOTE:
When connecting the electric wire if the wire length is not enough, please contact with the authorized service shop to buy a exclusive electric wire that is long enough and the joint on the wire are not allowed.
●
The electric wiring must be correctly connected, wrong connection may cause spare parts malfunction.
●
Tighten the terminal screw in order to prevent loose.
●
After tighten the screw, slight pull the wire and confirm whether is it firm or not.
●
If the earth wire is wrong connection, that may cause electric shock.
● The cover plate must be fixed, and tighten the connection wire, if it is poor installed, that
the dust, moisture may enter in or the connection terminal will be affected by outside force, and will cause fire or electric shock.
22
Install indoor unit
Install the indoor unit
External connection
●
The piping can be lead out from right, right rear, left
Gas side pipe
left rear.
When routing the piping and wiring from the left
1. or right side of indoor unit, cut off the tailings from the chassis in necessary(Show in Fig.7)
(1)Cut off the tailings 1 when routing the wiring only;
Fig.7
Tailing 2
Tailing 1
Gas side piping insulation
Finally wrap it with tape
(2)Cut off the tailings 1 and tailings 2 when routing both the wiring and piping.
2.
Take out the piping from body case, wrap the piping electric wire, water pipe with tape and pull them through the piping hole (As show in Fig.8)
3.
Hange the mounting slots of the indoor unit on the
upper tabs of the rear panel and check if it is firm
enough.(As show in Fig.9)
The height of the installed location should be 2. m
4.
or more from the floor.
Right
Right rear
Fixing hook
Mounting
5
plate
Fig.9
Install the connection pipe
1.
Align the center of the piping flare with the relevant valve.
2.
Screw in the flare nut by hand and then tighten the nut with spanner and torque wrench refer to the
following:
Hex nut diameter
Ф6
Ф 9.52
Ф 12
Tightening torque
(N·m)
15~20 31~35 50~55
Indoor unit piping
Spanner
Ф 16 60~65 Ф 19 70~75
NOTE: Firstly connect the connection pipe to indoor unit, then to outdoor unit; pay attention to the piping bending, do not damage the connection
much, otherwise it may cause leakage.
pipe; the joint nut couldn't tighten too
Water drainage pipe
Left
Left rear
Fig.8
Taper nut
Torque wrench
electric wire Liquid side piping
Piping insulation
Mounting baord
Piping
Liquid side
23
Install outdoor unit
Electric wiring
Disassemble the handle on the outdoor unit right side plate.
1.
Take off cord anchorage. Connect and fix power connect
2.
cord (for heat pump type,connect and fix power connect cord and signal control wire)to terminal block.
Fix the power connection cable with cord anchorage,
3.
(for heat pump type,use the cord anchorage to fix the power connection cable and the signal control wire).
Ensure wire has been fixed well.
4.
5.
Install the handle.
NOTE:
●
Wrong wiring may cause spare parts malfunction.
●
After the cable fixed, make sure there should be a free space between the connection and connection and fixing place on the lead wire.
Air purging and leakage test
1. Connect charging hose of manifold valve to charge end of low pressure valve (both high/low pressure valves must be tightly shut).
2. Connect joint of charging hose to vacuum pump.
3. Fully open handle handle of Lo manifold valve.
4. Open the vacuum pump to evacuate. At the beginning, slightly
loosen joint nut of low pressure valve to check if there
is air coming inside. (If noise of vacuum pump has
been changed, the reading of multimeter is 0) Then tighten the nut.
5. Keep evacuating for more than 15mins and make sure the reading of multi-meter is
-1.0 10 pa
(-76cmHg)..
6. Fully open high/low pressure valves.
7. Remove charging hose from charging end of low pressure valve.
8. Tighten bonnet of low-pressure valve. (As shown in Fig.10)
Condensate drainage of outdoor unit (no for cooling only)
The condensate and defrosting water formd during heating in the outdoor unit can be properly discharged by drainage pipe . Installation method:set the drain connection in 25 hole of the chassis has been installed and then connect drainage pipe with drain nozzle,so that condensate and defrosting waer can be properly discharged
5
Ø
Handle
05K、07K、09K、12K、14K、 15K、18K、24K cool only type:
N(1)
2
black
blue
(brown)
Indoor unit connection
18K Heatpump type:
2 4
N(1)
blue
black violet
Indoor unit connection
Multimeter
-76cmHg
Lo Handle
Charging hose
Low pressure valve
yellow-green
5
orange
yellow­green
Manifold Valve
Fig.10
05、 、07 、09 12K
Heat pump type:
2 4
N(1)
blue
24K Heatpump type:
N(1)
blue
Manometer
Charging hose
black violet
Indoor unit connection
2 43 5
brown
black
violet
Indoor unit connection
Hi handle
Vacuum pump
5
orange
orange
Chassis Drain
connection
yellow­green
yellow­green
24
Check after installation and test operation
Check after installation
Items to be checked Possible malfunction
Has it been fixed firmly?
Have you done the refrigerant leakage test?
Is heat insulation sufficient?
The unit may drop, shake or emit noise.
It may cause insufficient cooling(heating) capacity
It may cause condensation and dripping.
Is water drainage well?
Is the voltage in accordance with the rated voltage marked on the nameplate?
Is the electric wiring and piping connection installed correctly and securely? Has the unit been connected to a secure earth connection?
Is the power cord specified?
Is the inlet and outlet been covered? It may cause insufficient cooling(heating)
Has the length of connection pipes and refrigerant capacity been recorded?
Test Operation
Before test operation
1.
(1) Do not switch on power before installation isfinished completely.
(2) Electric wiring must be connected correctly and securely.
(3) Cut-off valves of the connection pipes should be opened.
All the impurities such as scraps and thrums must be cleared from the unit.
(4)
Test operation method
2.
(1) Switch on power, press "ON/OFF" button on the wireless remote control to start the operation.
Press MODE button, to select the COOL, HEAT (Cooling only unit is not available),
(2)
FAN to check whether the operation is normal or not.
It may cause condensation and dripping.
It may cause electric malfunction or damage the part.
It may cause electric malfunction or damage the part.
It may cause electrical leakage.
It may cause electric malfunction or damage the part.
capacity.
The refrigerant capacity is not accurate.
25
Installation and Maintenance of Healthy Filter
Installation Instructions
1. Forcibly pull the panel for a specific angle from the two ends of the front panel according to the arrow direction. Then pull the air filter downwards to remove it. (See Fig.a)
Fig. a
2. Mount the healthy filter onto the air filter,(as shown in Fig.b). If the air filter cannot be in­stalled, please mount the healthy filter on
Fig. b
Air filter
Healthy filter
the front case. (as shown in Fig.c)
Healthy filter
Fig. c
3. Mount the air filter properly along the arrow direction in Fig.d, and then close the panel cover.
Fig. d
Cleaning and Maintenance
Take out the healthy filter before cleaning and reinstall it after cleaning according to the installation instruction. Pay special attention to that silver ion filter can't be cleaned with water, while active carbon, photocatalyst, low temperature conversion (LTC) catalyst, formaldehyde eliminator, ca­techin or mite killing filter can, but can't with brush or hard things. Dry it in the shade or sun after cleaning, but not by wiping.
Service Life
The healthy filter commonly has its usage lifetime for one year under normal condition. As for silver ion filter, it is invalid when its surface becomes black (green).
●
This supplementary instruction is provided for reference to the unit with healthy filter. If the graphics provided herein is different from the physical goods, the latter one shall prevail. The quantity of healthy filters shall be based on the actual delivery.
26
Configuration of connection pipe and additional volume of refrigerant
1. Standard length of connection pipe
5m、7.5m、8m
2. Min length of connection pipe For the unit with standard connection pipe of 5m, there is no limitation for the min length of connection pipe. For the unit with standard connection pipe of 7.5m and 8m, the min length of connection pipe is 3m.
3. Max length of connection pipe
Sheet 1 Max length of connection pipe Unit: m
Capacity
5000 Btu/h
（1465 W）
7000 Btu/h
（2051 W）
9000 Btu/h
（2637 W）
12000 Btu/h （3516 W）
18000 Btu/h （5274 W）
Max length of
connection pipe
15
15
15
20
25
24000 Btu/h （7032 W）
28000 Btu/h （8204 W）
36000 Btu/h
（10548 W）
42000 Btu/h
（12306 W）
48000 Btu/h
（14064 W）
Capacity
Max length of
connection pipe
25
30
30
30
30
4. The calculation method of additional refrigerant oil and refrigerant charging
amount after prolonging connection pipe
After the length of connection pipe is prolonged for 10m at the basis of
standard length, you should add 5ml
of refrigerant oil for each additional
5m of connection pipe.
The calculation method of additional refrigerant charging amount (on the
basis of liquid pipe):
(1) Additional refrigerant charging amount= prolonged length of liquid pipe × additional
refrigerant charging amount per meter
(2) When the length of connection pipe is above 5m, add refrigerant according
to the prolonged length of liquid pipe. The additional refrigerant charging
amount per meter is different according to the diameter of liquid pipe. See Sheet 2.
27
Configuration of connection pipe and additional volume of refrigerant
Sheet 2. Additional refrigerant charging amount
for R22 R407C R410A
and R134a
Diameter of connection pipe mm Indoor unit throttle Outdoor unit throttle
Liquid pipe Gas pipe Cooling only,
cooling and heating
(g / m)
Ф6 Ф9.5 or Ф12 20 15 20
Ф6 or Ф9.5 Ф16 or Ф19 50 15 50
Ф12 Ф19 or Ф22.2 100 30 120 Ф16 Ф25.4 or Ф31.8 170 60 120 Ф19 - 250 250 250
Ф22.2 - 350 350 350
Cooling only
(g / m)
Cooling and
heating (g /
m)
Note: The additional refrigerant charging amount in Sheet 2 is recommended
value, not compulsory.
28
GREE ELECTRIC APPLIA NCES, INC. OF ZHUHAI
Add: West Jinji Rd, Qianshan, Zhuhai, Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn www.gree.com
66162819
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
