Kingpad mc-edition switch-module
Bus system control pad for installation in the Graupner mc-16 / mc-20 /
mc-26 / mc-28 transmitter
EN
No. 3974.2
Use example
Copyright © Graupner/SJ GmbH
2 / 16
3974.2_MP_V1
Index
Introduction ............................................................................. 5
Service Centre .......................................................................... 5
Intended use ........................................................................... 6
Package content ....................................................................... 6
Required accessories ............................................................... 6
Technical data .......................................................................... 7
Characteristics .......................................................................... 7
Symbols explication ................................................................. 8
Safety notes.............................................................................. 8
For your safety by handling the transmitter .................................9
Declaration of conformity ...................................................... 10
Product description ............................................................................10
Notes on environmental protection ...................................... 11
Care and maintenance ........................................................... 11
Warranty ................................................................................ 11
Installation / Connection ....................................................... 12
Setting the Kingpad ................................................................ 14
Operation ............................................................................... 15
3974.2_MP_V1
3 / 16
4 / 16
3974.2_MP_V1
Introduction
Thank you very much for purchasing the Graupner Kingpad mc-edition. This is extremely versatile. This manual is valid for all the modu-
les listed on the cover sheet.
Read this manual carefully to achieve the best results with your King-
pad mc-edition and first of all to safely control your models. If you
experience any trouble during operation, take the instructions to
help or ask your dealer or
Due to technical changes, the information may be changed in this
manual without prior notice. Be always updated by checking periodically on our website,
the products and firmwares.
This product complies with national and European legal requirements.
To maintain this condition and to ensure safe operation, you must
read and follow this user manual and the safety notes before using
the product!
Note
This manual is part of that product. It contains important information concerning operation and handling. Keep these instructions for
future reference and give it to third person in case you gave the product.
Graupner Service Centre.
www.graupner.de to be always uptodate with
Service centre
Graupner Central Service
Graupner GmbH
Henriettenstraße 96
D-73230 Kirchheim / Teck
Graupner in Internet For the service centers outside Germany please refer to our web site
www.graupner.de
Servicehotline
(+49) (0)7021/722-130
Monday - Thursday:
9:15 am -4:00 pm
Friday:
9:15 am - 1:00 pm
service@graupner.de
3974.2_MP_V1
5 / 16
Intended use
The Kingpad mc-edition regulates and controls the lighting and spe-
cial functions in a vehicle model over only 1 channel of the transmitter.
The Kingpad mc-edition is designed exclusively to be used in bat-
tery-powered, radio controlled models, any other use is not allowed.
For any improper use no guarantee or liability is assumed.
Read through this entire manual before you attempt to install or use
the Kingpad mc-edition.
Graupner constantly works on the development of all products; we
reserve the right to change the item, its technology and equipment.
Target group
The item is not a toy. It is not suitable for children under 14. The installation and operation of the Kingpad mc-edition must be performed by experienced modellers. If you do not have sufficient
knowledge about dealing with radio-controlled models, please contact an experienced modeller or a model club.
Package content
Required accessories
Kingpad mc-edition with connection cable and ZH connector
Manual
Graupner Kingpad light module (No. 3974.1)
Adapter mc-26/mc-28 (No.3974.3) with mc-16/mc-20 (No.3974.4)
Kingbus Central Module (No.3975)
LEDs for model lightning.
The IRAM Module so as IR-TX are required to use the functions pad.
Please refer to
www.pistenking.de
6 / 16
3974.2_MP_V1
Technical data
Characteristics
Kingpad mc-edition
Connection cable 4 poles
keys 12
Dimensions 62 x 30 x 4 mm
Attachment to the transmitter Glue pads
Connector type 4 poles ZH
Note
You will find the technical description of the required Kingbus central module on www.graupner.de directly at the product page
(No.3975)
12 keys for controlling special functions
Requires only 1 transmitter channel
3974.2_MP_V1
7 / 16
Symbol description
!
!
Safety notes
Always observe the information indicated by this warning sign. Particularly those which are additionally marked with the words CAUTION or WARNING. The signal word WARNING indicates the
potential for serious injury, the signal word CAUTION indicates pos-
sibility of lighter injuries.
The signal word Note indicates potential malfunctions.
Attention indicates potential damages to objects.
General
These safety instructions are intended not only to protect your own
and other people’s safety, but also to protect the product. Therefore
please read this section very carefully before using the product!.
Do not leave the packaging material lying around, this could be
a dangerous toy for children.
Persons, including children, with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge, or not
capable to use safely the transmitter must not use the transmitter without supervision or instruction by a responsible person.
Operation and use of radio-controlled models needs to be learnt!
If you have never driven such a model, then start extra carefully
and make sure to be familiar with the reactions of the model to
the remote control commands. Proceed always responsibly. This
also means that you have for your own protection liability
insurance.
Protect all equipment from dust, dirt, moisture. All equipment
must be protected from vibration as well as excessive heat or
cold. The models may only be operated remotely in normal outside temperatures such as from -10°C to +55°C.
8 / 16
3974.2_MP_V1
For your safety by handling the transmitter
!
WARNING
Also while programming the transmitter, make sure that a connected motor cannot accidentally start. Disconnect the fuel supply or
drive battery beforehand.
3974.2_MP_V1
9 / 16
Declaration of conformity
Product description
Kingpad mc-edition
Graupner/SJ declares that the product is conform to EU norms.
WEEE-Reg.-Nr.: DE 42466037
The Kingpad (KP) is made with the SMD technology.
With this module, the Graupner / Kingbus lighting system can be
controlled.
This item has been tested in accordance with EU directives and
complies with the legal requirements.
10 / 16
3974.2_MP_V1
Notes on environmental protection
P
Disposal notes
If this symbol is on the product, instructions for use or packaging, it
indicates that the product may not be disposed with normal household waste once it has reached the end of its service life. It must be
turned over to a recycling collection point for electric and electronic
apparatus.
Individual markings indicate which materials can be recycled. You
make an important contribution to protection of the environment by
utilizing facilities for reuse, material recycling or other means of
exploiting obsolete equipment.
Batteries must be removed from the unit and disposed of separately
at an appropriate collection point. Please inquire with local authorities about the responsible waste collection locations.
Care and maintenance
Notes on care
The product does not need any maintenance, it works so as it is
without any special care. In your own interest please protect the
model from dust, dirty and humidity!
Warranty certificate
The Graupner, Henriettenstrassee 96, 73230 Kirchheim/Teck grants
from the date of purchase of this product for a period of 24 months.
The warranty applies only to the material or operational defects
already existing when you purchased the item. Damage due to
misuse, wear, overloading, incorrect accessories or improper handling are excluded from the guarantee. The legal rights and claims are
not affected by this guarantee. Please check exactly defects before a
claim or send the product, because we have to ask you to pay shipping costs if the item is free from defects.
The present construction or user manual is for informational purposes only and may be changed without prior notice. The current version can be found on the Internet at
vant product page. In addition, the company
responsibility or liability for any errors or inaccuracies that may
appear in construction or operation manuals.
Not liable for printing errors.
www.graupner.de on the rele-
Graupner has no
3974.2_MP_V1
11 / 16
Installation / Connection
Procedure: For the use the Adapter No.3974.3 or No.3974.4 must
be switched between the pads.
Kingpad Licht und Funktion
1
1
1
1
1
F
+
F2F
-
3
S
3974.2
Adapter MC-26/28
3974.3
3974.1
ZH
Adapter MC-16/20
3974.4
UVR/XH
First, remove the built-in switches and the aluminium trim board.
In this case proceed carefully and cautiously with a heat gun.
With the mc-28 4d, the two blind plugs on the front sides can be
replaced with switches of your choice. There are enough free
slots available in the transmitter.
12 / 16
Now the cables and plugs are led through the hole of the former
Ctl 6 switch.
Now remove the protective foil and place the pad in the recess
3974.2_MP_V1
of the transmitter. Please push gently and carefully!
Bundle the cables of the Kingpad with the existing switch cables
in the transmitter.
Both Kinkpads are plugged to the ZH/XH connectors. This can be
fixed centrally by means of an adhesive pad. The adapter is plug-
The ZH slot for the adapter is located on the lower right side of
the channel-port board.
ged into the ZH input.
The installation of the hardware is complete.
3974.2_MP_V1
13 / 16
Setting the Kingpad
A co-ordination between the Graupner / Kingpad mc Edition and
the Kingpad Central Module must take place so that the perfect
function is guaranteed. Proceed as follows:
Make sure there is a connection between the remote control
and the receiver.
Kingpad assignation in the transmitter:
In the transmitter call up the menu "Control setting" and assign the
Kingpad like a normal switch to the desired channel. On the model
side, this selected control channel must be connected by means of
the enclosed patch cable from the receiver output to the "Kingpad"
input on the Kingbus Central Module. Driving and steering channel
must continue to remain connected to the central module as well!
Press the white Prog button on the KBCM for more than 2 seconds
until the yellow LED flashes in a second rhythm
Push the upper left button (sidelights) on the light module. As
confirmation for a detected key, the Prog-LED on the KBCM goes
off and remains off when pressed!
Release the button. The Prog-LED flashes again and the next key
can be read.
Now press the individual buttons of the light module one after
the other; followed by the buttons of the switch module. Always
starting from top left to right and then bottom left to right!
After the 24th key (F3) the Kingbus Central Module automati-
cally exits the programming mode and returns to normal mode.
The Kingpads are now set and they can be used
14 / 16
3974.2_MP_V1
Operation
By pressing a key, the function is switched on, it is switched off by
pressing again.
Seat posts: function not maintained
Semitrailer ramps: function not maintained
Manual use
Axle steering "plus"
Special function F1
Fifth wheel plate unlock
Reverse use
Axle steering "minus"
Special function F2
Special function F3
Manual
use
Fifth wheel
plate
Reverse use
Seat posts
Semitrailer ramps
Axle steering "+"
Special function
F1
Special function
F3
Special function
F2
Axle steering "+"
3974.2_MP_V1
15 / 16
Loading...
