Grass Valley Triton Plus Revision 5 User Manual

Triton Plus
PORTED RS-422 DATA ROUTER
User Manual
Revision 5
JANUARY 2009
CERTIFICATE
Certificate Number: 510040.001
The Quality System of:
Grass Valley, Inc.
400 Providence Mine Road Nevada City, CA 95945 United States
15655 SW Greystone Ct. Beaverton, OR 97006 United States
10 Presidential Way 3
rd
Floor, Suite 300 Woburn, MA 01801 United States
Nederland B.V. 4800 RP BREDA The Netherlands
Weiterstadt, Germany Brunnenweg 9 D-64331 Weiterstadt Germany
Rennes, France Rue du Clos Courtel Cesson-Sevigne, Cedex France
Technopole Brest Iroise CS 73808 29238 Brest Cedex 3 France
17 rue du Petit Albi-BP 8244 95801 Cergy Pontoise Cergy, France
2300 South Decker Lake Blvd. Salt Lake City, UT 84119 United States
7140 Baymeadows Way Suite 101 Jacksonville, FL 32256 United States
Including its implementation, meets the requirements of the standard:
ISO 9001:2000
Scope: The design, manufacture and support of video hardware and software products and related systems.
This Certificate is valid until: June 14, 2009 This Certificate is valid as of: August 30, 2006 Certified for the first time: June 14, 2000
H. Pierre Sallé President KEMA-Registered Quality
The method of operation for quality certification is defined in the KEMA General Terms And Conditions For Quality And Environmental Management Systems Certifications. Integral publication of this certificate is allowed.
KEMA-Registered Quality, Inc.
4377 County Line Road Chalfont, PA 18914 Ph: (215)997-4519 Fax: (215)997-3809
CRT 001 073004
ccredited By:
ANAB
A
Triton Plus
PORTED RS-422 DATA ROUTER
User Manual
Revision 5
JANUARY 2009
Contacting Grass Valley
International
Support Centers
Local Support
Centers
(available
during normal
business hours)
France
24 x 7
Australia and New Zealand: +61 1300 721 495 Central/South America: +55 11 5509 3443
Middle East: +971 4 299 64 40 Near East and Africa: +800 8080 2020 or +33 1 48 25 20 20
Europe
+800 8080 2020 or +33 1 48 25 20 20 +800 8080 2020 or +33 1 48 25 20 20
Hong Kong, Taiwan, Korea, Macau: +852 2531 3058 Indian Subcontinent: +91 22 24933476
Asia
Southeast Asia/Malaysia: +603 7805 3884 Southeast Asia/Singapore: +65 6379 1313 China: +861 0660 159 450 Japan: +81 3 5484 6868
Belarus, Russia, Tadzikistan, Ukraine, Uzbekistan: +7 095 2580924 225 Switzerland: +41 1 487 80 02 S. Europe/Italy-Roma: +39 06 87 20 35 28 -Milan: +39 02 48 41 46 58 S. Europe/Spain: +34 91 512 03 50 Benelux/Belgium: +32 (0) 2 334 90 30 Benelux/Netherlands: +31 (0) 35 62 38 42 1 N. Europe: +45 45 96 88 70 Germany, Austria, Eastern Europe: +49 6150 104 444 UK, Ireland, Israel: +44 118 923 0499
Copyright © Thomson. All rights reserved. This product may be covered by one or more U.S. and foreign patents.
United States/Canada
24 x 7
+1 800 547 8949 or +1 530 478 4148
Grass Valley Web Site
The www.thomsongrassvalley.com web site offers the following:
Online User Documentation — Current versions of product catalogs, brochures,
data sheets, ordering guides, planning guides, manuals, and release notes in .pdf format can be downloaded.
FAQ Database — Solutions to problems and troubleshooting efforts can be
found by searching our Frequently Asked Questions (FAQ) database.
Software Downloads — Download software updates, drivers, and patches.
4 Triton Plus - Ported RS-422 Data - User Manual

Contents

Triton Plus Ported RS-422 Data Routers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connection Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power Supply Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Configuration Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Audio/Video Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
D1616 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power Up Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Router Orientation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
LED Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Alarm States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Router Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Serial Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Maximum Cable Length (RS-232) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
NCB Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting Control Panels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Pinout and Cable Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Termination Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Control Bus Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maximum Distance Between NCB Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting RS-422 Signal Cables To Data Router . . . . . . . . . . . . . . . . . . . . . . . . 19
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Dynamic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Fixed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Triton Plus - Ported RS-422 Data - User Manual 5
Contents
6 Triton Plus - Ported RS-422 Data - User Manual

Triton Plus Ported RS-422 Data Routers

Product Overview

Professional broadcast installations often include a number of tape recorders and other devices that require RS-422 machine control for remote operation. To meet these requirements, Thomson Grass Valley introduces the Triton Plus TPS-D32P Ported Data Router.
Complex installations, cable cost and system design is kept at a minimum.
Where user friendliness and operational flexibility is appreciated, the TPS-D32P will fit in perfectly.
The Ported Data Routers are bi-directional ports rather than XY. A tradi­tional 32x32 router will have a total of 64 connectors (32 in/32 out). A ported 32 Router will have a maximum of 32 connectors, all configurable to be operated either as Controller or Device.
In the TPS-D32P Ported Data Router the terms Controller and Device are used instead of In/Out, Source/Destination. I.e. a Ported Data Router Con­troller can be both signal Source or Destination.
All ports are coupled according to SMPTE-207M machine control standard.
Triton Plus - Ported RS-422 Data - User Manual 7

Connection Details

Connection Details
Available ports and connectors at the back of the Triton Plus TPS-D32P data
router are shown in
RS-422 connectors: 32 device connectors
RS-232 Port: RS-232 for external control
Power Connectors
A: ±15VDC power input
B: ±15VDC power input, redundant supply
•NCB
IN: Network Control Bus input
OUT: Network Control Bus output
Configuration switches: DIP switches for configuration settings
Ethernet: Not used at this time.
Figure 1 and listed below:
Figure 1. Triton Plus TPS-D32P Ports and Connectors
8 Triton Plus - Ported RS-422 Data - User Manual

Power Supply Pinouts

The DB9 power pinouts for Triton Plus routers and control panels are given in
Tab le 1.
Table 1. Power Supply Pinouts
Pin Number Description
1GND
2 Not Connected
3 Not Connected
4 +15 VDC
5 Not Connected
6 Not Connected
7 Not Connected
8-15 VDC
9 Not Connected
Connection Details
Triton Plus - Ported RS-422 Data - User Manual 9

Configuration

Configuration

Configuration Switches

It is possible to use the router out-of-the-box. Changes to the factory set-
tings can be set with the DIP switches found in the back of the router.
As factory setting, the TPS-D32P is shipped with Dynamic ports. This
means every port can be controller or device depending on the connected
equipment.
You will find 2x10 DIP switches on the backplane of the router (see Figure 1
on page 8).
Switches 1 - 4 set the router Level and the Physical Address for this unit. By
setting routers and Control Panels on same level, routers can be controlled
as one, i.e. Audio-follow-Video.
Panels in a NCB loop must be configured to the same level as the router(s).
The Levels/Physical Addresses can be set according to the following
pattern given in
Tab le 2. The default level is 1.
Table 2. Levels and Physical Addresses Switch Patterns
SW 1 SW 2 SW 3 SW 4 Level
Off Off Off Off 1 0
Off Off Off
Off Off
Off Off
Off
Off
Off
Off
On
On
On
On
On On
On On
On On On
On On On On
On
On
On On
On On On
Off Off Off 9 8
Off Off
Off
Off
On
On On
Off Off 5 4
Off
On
On On
Off Off 13 12
Off
On
Off 3 2
On
Off 7 6
On
Off 11 10
On
Off 15 14
21
43
65
87
10 9
12 11
14 13
16 15
Physical
Address
10 Triton Plus - Ported RS-422 Data - User Manual

Audio/Video Mode

The TPS-D32P router can be assigned to either the video level or the audio level of a router system, selectable with switch switch. If you’re using the Data Router in an Audio-follow-video setting, the Data Router can be set as Video, giving an Audio-follow-Data function. Breakaway is also possible with this set-up. SW 5. The Default mode is Off.
Table 3. Audio/Video Modes – SW 5
SW 5 Router Mode
Off Controlled as Audio
On Controlled as Video

D1616 Mode

If The TPS-D32P Ported Data Router is to be configured as a D1616 router, this DIP switch ( as 16 inputs (1-16) and 16 outputs (17-32) and will be identical with the existing Triton Plus D1616 Data Router. The Default mode is Off.
Configuration
SW 5 on the configuration
Ta bl e 3 gives the settings for
SW 6) must be ON. The TPS-D32P will then be configured
Ta bl e 3 gives the settings for SW 6.
Table 4. D1616 Mode – SW 6

Power Alarm

The Power Alarm is set with DIP switch SW 7. When using a redundant power supply, the power alarm should be ON. If only one power supply is connected, this DIP must be off. Settings are shown in mode is Off.
The TPS-D32P will give an alarm and the front LED will blink red when one of the power supplies connected fails.
Tab l e 5 . Po wer Ala rm Settings – SW 7
SW 6 D1616 Mode
Off TPS-D32P mode
On D1616 mode
Tab le 5. The default
SW 7 Power Alarm
Off Disables power alarms
On Enables power alarms
Triton Plus - Ported RS-422 Data - User Manual 11
Configuration

Power Up Mode

Switch SW 8 on the configuration switch defines the power up mode. The
TPS-D32P router provides two modes for powering up the system:
Mode 1 switches all ports as disconnected.
Mode 2 switches all ports according to the latest setting buffered in the
• router’s processor system.
Settings for
Tab l e 6 . Po wer up Settings – SW 8
SW 8 Power Up Mode
Off Mode 2
On Mode 1

Router Orientation

Crosspoint commands in control protocols are using source and destina­tion when controlling routers. This must be mapped to ports in the router. When controlling RS-422, every port is bi-directional and includes both a source and a destination. The mapping is different in D1616 mode and TPS-D32P mode.
Router Orientation in TPS-D32P Mode
By default, the router is destination oriented (SW 9 DIP is OFF). A bi-direc­tional connection is made between the two ports. If both ports are config­ured as dynamic, the port referred as source will be used as a controller and the port referred as destination will be used as a device.
When the router is source oriented (SW 9 DIP is ON) the mapping is dif­ferent. If both ports are configured as dynamic, the port referred as source will be used as a device and the port referred as destination will be used as a controller. This makes it possible to use a single-bus panel to select one-of-several machines to control from a single location.
SW 8 are given in Tabl e 6. The default mode is Off.
Router Orientation in D1616 Mode
In D1616 mode all ports are fixed, port 1-16 as controllers and port 17-32 as devices. The control system will see the router as a 16x16 matrix. When the router is destination oriented, destinations 1-16 are mapped to ports 17-32 while sources 1-16 are mapped to ports 1-16.
When the router is source oriented, destinations 1-16 are mapped to ports 1-16 while sources 1-16 are mapped to ports 1-16. As in TPS-D32P mode this makes it possible to use a single-bus panel to select one-of-several machines to control from a single location.
12 Triton Plus - Ported RS-422 Data - User Manual
Configuration
Switch SW 9 on the configuration switch defines the router orientation as shown in
Table 7. Router Orientation Settings – SW 9
Ta bl e 7. The default setting is Off.
SW 9 D1616 Mode
Off Destination oriented
On Source oriented
Future Use
Switches 10 -17 are currently not in use.
Ext Address
Switches 18 -20 are currently not in use.
Triton Plus - Ported RS-422 Data - User Manual 13

LED Status

LED Status

Alarm States

The LED located at the front of the router indicates the status of the router. At start-up, the LED will alternate between red (R) and green (G) every 500ms for about two seconds. After the start-up sequence the LED will indicate the Alarm state of the router.
The LED can either be red (R), green (G), or have no light (N).
The LED state is described in Tabl e 8 below with twenty letters, each repre­senting 100ms, which totals an alarm sequence of two seconds. The X indi­cates that the LED keeps the color it has the moment the alarm sequence begins (green or no light).
Table 8. LED Alarm States
Description LED State Alarm Comment
Continuous Green Light GGGGG GGGGG GGGGG GGGGG
Long Red Blinking RRRRR NNNNN RRRRR NNNNN Power is too low
One Short Red Blink RXXXX XXXXX XXXXX XXXXX Power A failed
Two Short Red Blinks XXXXX XXXXX RXRXX XXXXX Power B failed
No Alarm Status OK
Only active if power alarm DIP is set.
14 Triton Plus - Ported RS-422 Data - User Manual

Router Communication

You gain access to the router for communication purposes by connecting the router’s serial port to your computer.

Serial Connection

Connection can by made trough the serial port(s) of the router; see also Con-
nection Details on page 8 for connection details.
The communication parameters are configurable. Please refer to the pro­tocol documentation of the appropriate communication/control protocol.
Example: The protocol parameters of the Triton Plus Compact routers are as follows:
Bit rate 19200 bit/s
Data bits 8 bits
Stop bits 1
Router Communication
Parity: No parity
For further detail concerning this protocol, please refer to the following manual: Compact Router Control Protocol.
The DB9 female connector for the serial port(s) of the router has the fol­lowing pinout (Tab le 9 ):
Table 9. Serial Connection Pinout
Pin # RS-232 Mode
1 Not in use
2Tx
3Rx
4 Not in use
5GND
6GND
7RTS
8CTS
9 Do Not Connect!
Note If the standard RS-232 cable specification (DCE) is followed:
A cable with Male+Male or Female+Female connectors at the cable ends is used for Rx/Tx crossed connection.
A cable with Male+Female connectors at the cable ends is used for a straight through connection.
Triton Plus - Ported RS-422 Data - User Manual 15
Router Communication
Maximum Cable Length (RS-232)

NCB Connection

Connecting Control Panels
IEEE has specified the maximum cable length for an RS-232 connection to 15 meters. Longer distances can be installed depending on the environ mental conditions of the installation site. It is the responsibility of the installer/user to secure a proper installation of the RS-232 connection.
Via the Network Control Bus system, several routers and control panels can be interconnected.
Up to 16 levels of routers, or combinations of routers, can be controlled. The NCB system and all RS-232 ports interchange the system status. This means that any control system, either from Grass Valley, or from a third party manufacturer, connected to any RS-232 port in the NCB loop, will have access to all communication data on the bus.
-
To get a control panel working with a specific router, configure the control panel to the same level as the router. Several panels can be configured to control the same router. Panels can also be connected to a router via the RS-232 interface. Please refer to your control panel manual for installation.
Pinout and Cable Type
Triton Plus routers and Control Panels use RJ45 connectors for the Network Control Bus ports. The following pinout shown in
Table 10. RJ45 Connector Pinouts
Pin # Description Illustration
1 Not Connected
2 Not Connected
3 Data (retour)
4Data
5Data
6 Data (retour)
7 Not Connected
8 Not Connected
Ta bl e 10 is used:
16 Triton Plus - Ported RS-422 Data - User Manual
The following connection example (Figure 2) shows connection of four
Pin 3 is connected to Pin 4 Pin 5 is connected to Pin 6
Triton Plus devices with RJ45 connectors and bus termination:
Figure 2. Four Devices Connected Together Using RJ45
Note Each device at the end of the chain has a termination plug, indicated with the
Termination Plug
Router Communication
letter T. This termination plug must be inserted in the correct connection port. If not, no NCB communication is possible.
The termination plug that is mentioned in the previous section is necessary when you want to avoid closing the loop with a (long) cable.
The termination plug is a standard RJ45 plug with the following internal wiring shown in Figure 3.
Figure 3. RJ45 Termination Plug Wiring
Triton Plus - Ported RS-422 Data - User Manual 17
Router Communication
Control Bus Structure
Maximum Distance Between NCB Devices
The Network Control Bus structure follows the standard MIDI bus defini­tion. The NCB is defined as a closed chain of units. This means that the NCB OUT of the last unit must be connected to the NCB IN of the first unit in the NCB chain. To avoid problems with the control of Triton Plus units the installer/user has to assure that the bus structure is installed according to this definition.
Note The total number of Triton Plus devices in an NCB chain is limited to 50.
The standard MIDI definition allows a maximum cable length of 200-250 meters between two devices. Longer distances can be made with MIDI repeater units. To avoid grounding problems all NCB ports have opto-cou pled inputs.
-
18 Triton Plus - Ported RS-422 Data - User Manual

Connecting RS-422 Signal Cables To Data Router

All router ports on the TPS-D32P are coupled in accordance to the SMPTE-270M standard. This is the broadcast standard for RS-422 machine control.
Refer to Tabl e 11 for pin connections.
Table 11. RS-422 Signal Connections
Device Controller
Pin # 2 Tx- Pin # 2 Rx-
Pin # 3 Rx+ Pin # 3 Tx+
Pin # 4 GND Pin # 4 GND
Pin # 5 Future use Pin # 5 Future use
Pin # 6 GND Pin # 6 GND
Pin # 7 Tx+ Pin # 7 Rx+
Pin # 8 Rx- Pin # 8 Tx-
The RS-422 connectors on the rear of each unit are arranged as given in
Tab le 1 2:
Router Communication
Table 12. RS-422 Connector Arrangement
1591317212529
2 6 10 14 18 22 26 30
3 7 11 15 19 23 27 31
4 8 12 16 20 24 28 32
Triton Plus - Ported RS-422 Data - User Manual 19
Router Communication

Applications

Dynamic
The first example (Figure 4) shows how to connect two Video Tape Recorders (VTRs) with traditional AV Routers for signal transport and a TPS-D32P Ported Data Router for RS-422 Machine Control.
Both VTRs can be used as Player or Recorder depending on their local/remote setting.
Figure 4. Dynamic Application Example
Fixed
The second example (Figure 5) shows a VTR and NLE Computer (i.e. NLE=Non-Linear Editor). The units can both be Player or Recorder for audio and video, while the Computer is Controller (Master) and always controlling the device/VTR (Slave). This leaves RS-422 Machine Control Data to always operate in one mode,
Figure 5. Fixed Application Example
Fixed.
20 Triton Plus - Ported RS-422 Data - User Manual

Specifications

Note All specifications are subject to change without notice.
Table 13. Triton Plus Ported RS-422 Data Router Specifications
Parameter Value
Router
Signal type RS-422 data
Data rate 115200 kbps
Connector DB9 pin female, according to SMPTE-207M
AC power External power supplies 100-260VAC
Maximum power consumption <20W
Mechanical
Dimensions 483 x 45 mm (19 in., 2RU)
Safety/Emissions standards Compliant with CE EN55103-1 and 2, FCC part 15
Power Supply
TPS-PWR-40 40W power supply unit Triton Plus router series
AC supply voltage range 100-240VAC, 50-60Hz, max 1.6A
AC mains connector IEC 320
DC output +15V, max. 2.2A/-15V, max 1.35A. Maximum 43W
DC connector DB9, female
Status monitoring Via LED in front of router/CP
Control
Standard Features
Serial port RS-232 for protocol conversion, to Triton Plus compact control protocol, or to
Connector DB9, female
NCB ports 1 in/ 1 out
Connectors (2) RJ45
Ethernet port 10/100BaseT Ethernet is not supported at this time
Connector RJ45
Optional Features
Control panel External control panels available
Environmental
Equipment will meet guaranteed performance specifications under the following conditions:
Operating room temperature range
Operating relative humidity range < 95% (non-condensing)
Equipment will operate without damage under the following conditions:
Temperature range -10º C to 55º C
Relative humidity range
3rd party protocols
0º C to 45º C
< 95% (non-condensing)
Specifications
Triton Plus - Ported RS-422 Data - User Manual 21
Specifications
22 Triton Plus - Ported RS-422 Data - User Manual
Loading...
