Triton Plus Control Panels
Product Overview
Thomson Grass Valley is proud to present the second generation of the
compact small and medium routing switcher family – Triton Plus. With
Triton Plus, Thomson Grass Valley now provides a stable and proven
product line including the most complete signal format and size offering
available.
With the new ultra-slim, multi-format and flexible product range, Triton
Plus fulfils the most demanding requirements from the professional broad
cast market.
This User Manual presents the features, installation, and operation of the
control panels available with the Triton Plus series.
-
Triton Plus - Control Panels - User Manual 7
Product Overview
Product Versions
The following control panel versions are available for the Triton Plus series:
• 19 in. 1 RU (Tabl e 1 )
• 19 in. 2 RU (Tabl e 2 )
• 19 in. 4 RU (Tabl e 3 )
Table 1. 19 in. 1 RU Control Panels
Control Panel Model Descriptions
TPS-16XY-CP Multi bus X-Y 16x16 panel
TPS-8XY-CP Multi bus X-Y 8x8 panel
TPS-16D-CP Dual bus 16x2 panel
TPS-32S-CP Single bus 32x1 panel
TPS-32S-CP-GPI Single bus 32x1 panel with GPI/Joystick/Tally interface
TPS-16S-CP Single bus 16x1 panel
TPS-16S-CP-GPI Single bus 16x1 panel with GPI/Joystick/Tally interface
TPS-8S-CP Single bus 8x1 panel
TPS-8S-CP-GPI Single bus 8x1 panel with GPI/Joystick/Tally interface
TPS-16XY-CP Multi bus X-Y 16x16 panel
Table 2. 19 in. 2 RU Control Panels
Control Panel Model Descriptions
TPS-32XY-CP Multi bus X-Y 32x32 panel
TPS-64S-CP Single bus 64x1 panel
TPS-64S-CP-GPI Single bus 64x1 panel with GPI/Joystick/Tally interface
Table 3. 19 in. 4 RU Control Panels
Control Panel Model Descriptions
TPS-64XY-CP Multi bus X-Y 64x64 panel
8 Triton Plus - Control Panels - User Manual
Connection Details
Available service connectors at the back panel of the Triton Plus Routers are
shown in
Note Figure 1 shows a 1 RU Triton Plus router. However, the connectors are iden-
Figure 1. Rear View of Triton Plus Control Panel
• SYNC: Not in use on control panels.
• LOOP: Not in use on control panels.
• NCB IN: Network Control Bus Input. The protocol of this bus is equal,
and compatible to the MIDI bus protocol.
Connection Details
Figure 1.
tical to the 1 RU also on the 2 RU and 4 RU units. The only connectors that
differ are the applicable signal connectors.
• NCB OUT: Network Control Bus Output.
• ETHERNET: Not supported at this time.
• RS-232: RS-232 for external control protocols.
• POWER A: ±15VDC Power Input.
• POWER B: ±15VDC Power Input, redundant supply.
• CONFIGURATION: Configuration switches (8 pcs).
Triton Plus - Control Panels - User Manual 9
Connection Details
Power Supply Pinouts
The DB9 power pinouts for Triton Plus routers and Control Panels are
given in
Table 4. Power Supply Pinouts
Pin Number Description
Tab le 4.
1Gnd
2 Not Connected
3 Not Connected
4 +15 VDC
5 Not Connected
6 Not Connected
7 Not Connected
8-15 VDC
9 Not Connected
10 Triton Plus - Control Panels - User Manual
Configuration
Level Configuration
Configuration
This section highlights the main configuration options, available on the DIP
switches on the rear of the unit.
Switches 1-4 on the configuration switch set the router’s level for communication with the Router Management System and other units in the NCB
system. The panels on the NCB dedicated to operate with the router must
be configured to the same level as that router.
The levels can be switched according to the patterns given in Tab le 5. The
default level is 1.
Table 5. Level Switch Patterns
SW 1 SW 2 SW 3 SW 4 Level NCB Address
Off Off Off Off 1 0
Off Off Off
Off Off
Off Off
Off
Off
Off
Off
On
On
On
On
On On
On On
On On On
On On On On
On
On
On On
On On On
Off Off Off 9 8
Off Off
Off
Off
On
On On
Off Off 5 4
Off
On
On On
Off Off 13 12
Off
On
Off 3 2
On
Off 7 6
On
Off 11 10
On
Off 15 14
21
43
65
87
10 9
12 11
14 13
16 15
Triton Plus - Control Panels - User Manual 11
Configuration
Fallback Mode
Note This information is applicable only on GPI versions.
Switch SW 5 on the configuration switch sets the fallback mode of the GPI
panel, either to
Note This is only useful when the GPI panel is in Joystick release mode, see Joy-
stick Mode on page 14.
dynamic or to hard-set.
Dynamic Fallback Mode
When the GPI is activated the X-point status is saved before switching.
When the GPI is released again, the panel will switch back to the previous
saved X-point status.
Hard-set Fallback Mode
When the GPI is released, the panel will switch to a previously configured
fallback input. The fallback input is configured using the input buttons, see
Button Description on page 21.
The modes can be switched as described in Tabl e 6. The default mode is
Hard-set.
Table 6. Fallback Mode Switching
SW 5 Fallback Mode
Off Hard-set
On Dynamic
12 Triton Plus - Control Panels - User Manual
Joystick Priority
Note This information is applicable only on GPI versions.
Switch SW 6 on the configuration switch set the Joystick priority of the GPI
panel, either to release before switch or to switch before release.
Release Before Switch
This is used in both GPI and Joystick mode. The activation of a new input
line will have no effect until the previous line is released. If more lines are
activated in sequence, the latest activated one will result in a switching as
soon as the previously active is released.
Switch Before Release
This is used in both GPI and Joystick mode. The activation of a new input
line will generate a switching, regardless of how many other lines that are
already set.
Configuration
Power Alarm
The priority can be switched with switch SW 6 according to the pattern
given in Tabl e 7. The default setting is
Table 7. Joystick Priority Mode Switching
SW 6 Joystick Priority
Off Switch before release
On Release before switch
The power alarm can be switched with switch SW 7 according to the pattern
given in
Table 8. Power Alarm Mode Switching
Tab le 8. The default setting is power alarm disabled (Off).
SW 7 Power Alarm
Off Disables Power Alarm
On Enables Power Alarm
Switch Before Release (Off)..
Triton Plus - Control Panels - User Manual 13
Configuration
Joystick Mode
Note This information is applicable only on GPI versions.
Switch SW 8 on the configuration switch set the Joystick mode of the GPI
panel to either
GPI Mode or to Joystick Release Mode.
GPI Mode
Releasing the input lines will keep the previous status. Operation of the
front panel is allowed with any number of active GPI-lines simultaneously.
Joystick Release Mode
When all the input lines are released, a default input (either dynamically
chosen or static) is set. The front panel is locked if any of the input lines are
active.
The modes can be switched with switch SW 8 according to the pattern given
in Tab le 9 . The default mode is
GPI Mode (Off).
Table 9. Joystick Mode Switching
SW 8 Joystick Mode
Off GPI Mode
On Joystick Release Mode
Configuring Output on Single Bus Panels
Refer to Input on page 22 for configuring default output to be controlled
from a single bus control panel.
14 Triton Plus - Control Panels - User Manual
LED Status Indication
Start Up
The LED located at the front of the router indicates the status of the router.
At start-up, the LED will alternate between red (R) and green (G) every
500ms for about two seconds. After the start-up sequence the LED will
indicate the Alarm state of the router.
Alarm States
The LED can either be red (R), green (G), or have no light (N).
The LED state is described in Tab le 1 0 below with twenty letters, each representing 100ms, which totals an alarm sequence of two seconds. The X
indicates that the LED keeps the color it has the moment the alarm
sequence begins (green, yellow or no light).
LED Status Indication
Table 10. LED Alarm States
Description LED State Alarm Comment
Continuous Green Light GGGGG GGGGG GGGGG GGGGG
Long Red Blinking RRRRR NNNNN RRRRR NNNNN Power is too low
One Short Red Blink RXXXX XXXXX XXXXX XXXXX Power A failed
Two Short Red Blinks XXXXX XXXXX RXRXX XXXXX Power B failed
No Alarm
Status OK
Only active if power
alarm DIP is set.
Triton Plus - Control Panels - User Manual 15
Router Communication
Router Communication
You gain access to router for communication purposes by connecting either
the router’s serial port to your computer.
Serial Connection
Connection can by made trough the serial port(s) of the router; see also Con-
nection Details on page 9 for connection details.
The communication parameters are configurable. Please refer to the protocol documentation of the appropriate communication/control protocol.
Example: The protocol parameters of the Triton Plus Compact routers are
as follows:
• Bit rate 19200 bit/s
• Data bits 8 bits
• Stop bits 1
• Parity: No parity
For further detail concerning this protocol, please refer to the following
manual: Compact Router Control Protocol.
The DB9 female connector for the serial port(s) of the router has the following pinout (Tab le 11 ):
Table 11. Serial Connection Pinout
Pin # RS-232 Mode
1Not in use
2Tx
3Rx
4Not in use
5GND
6GND
7RTS
8CTS
9 Do Not Connect!
Note If the standard RS-232 cable specification (DCE) is followed:
A cable with Male+Male or Female+Female connectors at the cable ends is
used for Rx/Tx crossed connection.
A cable with Male+Female connectors at the cable ends is used for a straight
through connection.
16 Triton Plus - Control Panels - User Manual
Maximum Cable Length (RS-232)
IEEE has specified the maximum cable length for an RS-232 connection to
15m. Longer distances can be installed depending on the environmental
conditions of the installation site. It is the responsibility of the
installer/user to secure a proper installation of the RS-232 connection.
NCB Connection
Via the Network Control Bus system, several routers and control panels can
be interconnected.
Up to 16 levels of routers, or combinations of routers, can be controlled. The
NCB system and all RS-232 ports interchange the system status. This means
that any control system, either from Grass Valley, or from a third party
manufacturer, connected to any RS-232 port in the NCB loop, will have
access to all communication data on the bus.
Connecting Control Panels
Router Communication
To get a control panel working with a specific router, configure the control
panel to the same level as the router. Several panels can be configured to
control the same router. Panels can also be connected to a router via the
RS
232 interface. Please refer to your control panel manual for installation.
Pinout and Cable Type
Triton Plus routers and Control Panels use RJ45 connectors for the Network
Control Bus ports. The following pinout shown in
Table 12. RJ45 Connector Pinouts
Pin # Description Illustration
1 Not Connected
2 Not Connected
3 Data (retour)
4Data
5Data
6 Data (retour)
7 Not Connected
8 Not Connected
Ta bl e 12 is used:
Triton Plus - Control Panels - User Manual 17
Router Communication
Pin 3 is connected to Pin 4 Pin 5 is connected to Pin 6
Termination Plug
The following connection example (Figure 2) shows connection of four
Triton Plus devices with RJ45 connectors and bus termination:
Figure 2. Four Devices Connected Together Using RJ45
Note Each device at the end of the chain has a termination plug, indicated with the
letter T. This termination plug must be inserted in the correct connection port.
If not, no NCB communication is possible.
The termination plug that is mentioned in the previous chapter is necessary
when you want to avoid closing the loop with a (long) cable.
The termination plug is a standard RJ45 plug with the following internal
wiring shown in Figure 3.
Figure 3. RJ45 Termination Plug Wiring
18 Triton Plus - Control Panels - User Manual
Control Bus Structure
The Network Control Bus structure follows the standard MIDI bus definition. The NCB is defined as a closed chain of units. This means that the NCB
OUT of the last unit must be connected to the NCB IN of the first unit in the
NCB chain. To avoid problems with the control of Triton Plus units the
installer/user has to assure that the bus structure is installed according to
this definition.
Note The total number of Triton Plus devices in an NCB chain is limited to 50.
Maximum Distance Between NCB Devices
The standard MIDI definition allows a maximum cable length of 200-250
meters between two devices. Longer distances can be made with MIDI
repeater units. To avoid grounding problems all NCB ports have opto-cou
pled inputs.
Router Communication
-
Triton Plus - Control Panels - User Manual 19
GPI Connections
GPI Connections
Note This information is applicable only on GPI panel versions.
The GPI / Joystick / Tally signals are connected to the Triton Plus Control
Panel with GPI options using DB25 male connectors. Each Triton Plus CP
with GPI I/O has 32 GPI inputs and 32 GPI outputs available, independent
of panel size.
Note The GPI connectors on the CP are DB25 females.
The GPI pinouts are given in Tab le 1 3.
Table 13. GPI Pinouts
GPI I/O Channel # Connector Pin #
1 and 17 12
2 and 18 24
3 and 19 23
4 and 20 10
5 and 21 09
6 and 22 21
7 and 23 20
8 and 24 07
9 and 25 06
10 and 26 18
11 and 27 17
12 and 28 04
13 and 29 03
14 and 30 15
15 and 31 14
16 and 32 01
All inputs internally connected to +5V via a pull-up resistor. The inputs will
be activated when pulling them to ground. Ground is available on the following pins: 2, 5, 8, 11, 13, 16, 19, 22, 25 and on the connector chassis.
All outputs are of open collector type. An output can switch a maximum
load of 100mA at 30V. Any device to be controlled by the GPI outputs
(lamp, LED or similar) needs to be connected to an external supply voltage
on one end and to the GPI output on the other end.
WARNING Do not connect external supply voltages higher than 30V DC.
20 Triton Plus - Control Panels - User Manual
Control Panel Operation
All local control panels are given a default configuration, which includes
the buttons
Output buttons are pre-configured.
Note The extra buttons on the 2RU and 4RU panels are not preconfigured. They
Note The GPI functions are not programmable on Triton Plus GPI control panels.
Button Description
A/V Toggle
The A/V Toggle button enables/disables audio and video on a specified
address. The address can either be read from the DIP switches or be fixed.
The button toggles between three states.
A/V Toggle, Panel Enable, Take On/Off, and Take . In addition, Input and
may be configured by the user.
They have a fixed, preconfigured function as described earlier in Configura-
tion on page 11.
Control Panel Operation
Note If the button is pressed for more than 1 second, it will go into a fourth state
where both audio and video are disabled.
In this state the button will be dimmed. If the button is pressed for more
than 1 second again, it will enable both audio and video if present. Refer to
Tab le 1 4.
Table 14. A/V Toggle Button
Button Color Video Enabled Audio Enabled
Yel low Yes Yes
Green Yes No
Red No Yes
Dimmed No No
If neither audio nor video is present, it will be marked as disabled and the
toggle state will not be used.
Toggle status changes will be stored in flash and used when the panel is
powered up later.
Triton Plus - Control Panels - User Manual 21
Control Panel Operation
Panel Enable
Take On/Off
Take
If a Panel Enable button is present, the panel will start up not enabled. In this
state the button will be red and all the other buttons will be disabled. When
pressing the button the panel will be enabled and the color will change to
green. A status request will also be sent to get information on active levels.
If no Panel Enable button is present, the panel will start up enabled.
The Take On/Off button enables or disables the Tak e button. If no Take button
is defined,
enabled. Later it will read the last status from the flash memory.
Note Activating a GPI I/O will not influence the Take on/off function, nor will a Ta ke
Take On/Off is always off. On first start-up the Take button is
on/off function influence the activation of a GPI I/O function.
Output
Input
The Take buttons LED is normally off. If the Take On/Off button is set to on, no
commands will be sent from the panel until the
last selected buttons and the
pressed and the command is sent from the panel.
Note Activating a GPI I/O will not influence the Take on/off function, nor will a Ta ke
on/off function influence the activation of a GPI I/O function.
An Output button is used for selecting an output. Selecting an output activates it, so that it is switched to the next input that is selected.
An Input button switches the active output to the selected input. If the Take
button is enabled, the switch will not be executed until the
pressed.
When switching using the Input button, all enabled audio- and video-levels
will be switched from the selected input to the active output.
Note The Input button can also be used to select the active output for single bus
panels and fallback inputs for GPI panels. Press and hold the Panel Enable
button while selecting the active output by pressing an Input button. Press
and hold the Panel Enable button while first toggling A/V Toggle and then
selecting the fallback input by pressing an Input button.
Unlike the buttons on the front of the panel, GPI inputs 1-32 cannot be reconfigured to represent other inputs, i.e. they are fixed inputs (1-32), operating
on the selected output.
Take button will blink, until the Take button is
Take button is pressed. The
Take button is
22 Triton Plus - Control Panels - User Manual
Specifications
Note All specifications are subject to change without notice.
Table 15. Triton Plus Control Panel Specifications
Parameter Value
Mechanical
Dimensions
Safety/Emission standards Compliant with CE EN55103-1 and 2
Power Supply
TPS-PWR-40 40W power supply unit for 8x8 to 32x32
AC supply voltage range 100-240VAC, 50-60Hz max 1.6A
AC mains connector IEC 320
DC output
DC connector DB9, female
Status monitoring Via LED in front of router/CP
Control
Standard Features
Serial port RS-232 for protocol conversion, to Triton Plus compact control protocol, or
Connector
NCB ports For integration with Triton Plus compact router configuration
Connectors (2) RJ45 (1 in/1 out)
Ethernet port 10/100BaseT Ethernet is not supported at this time
Connector RJ45
Environmental
Equipment will meet guaranteed performance specifications under the following conditions:
Operating room temperature range 0º C to 45º C
Operating relative humidity range < 95% (non-condensing)
Equipment will operate without damage under the following conditions:
Temperature range -10º C to 55º C
Relative humidity range < 95% (non-condensing)
• HxWxD = 44x483x50mm (19 in., 1 RU)
• HxWxD = 88x483x50mm (19 in., 2 RU)
• HxWxD = 176x483x50mm (19 in., 4 RU)
• +15V, max. 2.2A/-15V, max 1.35A.
• Maximum 43W for 8x8–32x32 versions
to 3rd party protocols
DB9, female
Specifications
Triton Plus - Control Panels - User Manual 23
Specifications
24 Triton Plus - Control Panels - User Manual
Loading...
