T2
INTELLIGENT DIGITAL DISK RECORDER
Additional Function Manual SP4.4
www.grassvalley.com
F39514 012 8 3
January 2014
Copyright
Copyright 2009-2014 Grass Valley K.K. All rights reserved. Portions of software © 2000 –
2014, Microsoft Corporation. All rights reserved. This document may not be copied in whole
or in part, or otherwise reproduced except as specifically permitted under U.S. copyright law,
without the prior written consent of Grass Valley, Inc., P.O. Box 59900, Nevada City, California
95959-7900. This product may be covered by one or more U.S. and foreign patents.
Grass Valley is a trademark of GVBB Holdings S.a.r.l.
Disclaimer
U.S. Government
Restricted Rights Legend
Trademarks and Logos
Product options and specifications subject to change without notice. The information in
this manual is furnished for informational use only, is subject to change without notice, and
should not be construed as a commitment by Grass Valley, Inc. Grass Valley, Inc. assumes
no responsibility or liability for any errors or inaccuracies that may appear in this publication.
Use, duplication, or disclosure by the United States Government is subject to restrictions as
set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software
clause at DFARS 252.277-7013 or in subparagraph c (1) and (2) of the Commercial Computer
Software Restricted Rights clause at FAR 52.227-19, as applicable.
Grass Valley is a trademark of GVBB Holdings S.a.r.l. Grass Valley USA, LLC products are
covered by U.S. and foreign patents, issued and pending. Additional information regarding
Grass Valley USA, LLC trademarks and other proprietary rights may be found at www.
grassvalley.com.
Other trademarks and logos used in this document are either registered trademarks or
trademarks of the manufacturers or vendors of the associated products, such as Microsoft®
Windows® operating system, Windows Media® player, Internet Explorer® internet browser, and
SQL Server™. QuickTime and the QuickTime logo are trademarks or registered trademarks
of Apple, Inc., used under license therefrom. Intel and Core i7 are the trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United States of America
and other countries. Adobe and Adobe Premiere are registered trademarks of Adobe Systems
Incorporated. Final Cut Pro is a trademark of Apple Inc., registered in USA and other countries.
XDCAM, MPEG HD422 and XDCAM EX are trademarks or registered trademarks of Sony
Corporation. XDCAM EX, SxS, and their logos are trademarks of Sony Corporation. GF and
GFPAK are trademarks of Toshiba Corporation.
Grass Valley Web Site
2
T2 Additional Function Manual SP4.4 January 28, 2014
Manufactured under license from Dolby Laboratories. Dolby and the double-D
symbol are trademarks of Dolby Laboratories. Confidential unpublished works.
Copyright 1993–2005 Dolby Laboratories. All rights reserved.
This public Web site contains all the latest manuals and documentation, and additional
support information. Use the following URL.
http://www.grassvalley.com.
Manual Explanation
• If there are any variations between the explanation in this manual and the actual application
method, priority is given to the actual application method.
• Screenshots and illustrations in this manual may vary from those of the actual product.
• The screenshots used as examples in this manual are those of the development stage, so
they may vary from those in the final product.
• This manual is written for users who have a basic knowledge of how to use a computer.
If there are no special instructions, perform the same operation as a normal computer
operation.
• The contents of this product may modify without prior notice.
T2 Additional Function Manual SP4.4
Ver 1.0
Copyright © 2014 Grass Valley K.K.
All rights reserved.
January 28, 2014 T2 Additional Function Manual SP4.4
3
Contents
1 Introduction
About this manual .......................................................................... 5
2 Export of the logs
Checking logs of operations and processes ........................................... 6
Displaying a log ..................................................................................6
3 Select style of the clip when the input signal has discontinued
R1 settings .................................................................................. 7
R1 – Capture settings ............................................................................7
4 Customize frame of play start delay in remote cotrol
Other settings ............................................................................... 8
Miscellaneous – Remote settings .............................................................8
5 Other additional / improve functions
Keyboard shortcut list in workstation mode .................................................9
Support exporting to Sony XDCAM drive (PDW-U1, PDW-U2)............................9
Growing clip icon ................................................................................. 9
Support full-screen preview of R1/P1/P2 in workstation mode ........................ 10
Lock of front panel operation in workstation mode....................................... 10
Improve "E to E" icon .......................................................................... 11
Support current position in play growing files ............................................ 11
4
T2 Additional Function Manual SP4.4 January 28, 2014
Introduction
About this manual
This manual describes additional functions included in SP4.4. For basic
functionality please refer to the User Manual.
The steps described in this manual is operated in front panel mode.
Section 1
January 28, 2014 T2 Additional Function Manual SP4.4
5
(1)
Section 2 ― Export of the logs
Export of the logs
Export the logs without to change maintenance mode.
Checking logs of operations and processes
Displaying a log
You can output logs of operations and processes. Use it to nd out the cause of
troubles.
1. Click [Option] on the menu bar, and then click [Log] -> [Show
log...].
Section 2
¾ [Log] dialog box
(1)
[Export]
Export the logs to external folder which is
selected.
6
T2 Additional Function Manual SP4.4 January 28, 2014
Section 3
(1)
Select style of the clip when the input signal has discontinued
The clips are splited before SP4.3 when input signal has discontinued.
R1 settings
R1 – Capture settings
You can set whether to automatically export les being recorded in the R1
channel.
1. Tap [R1], and then tap the [Capture] tab in the seing screen.
¾ [Capture] tab
[Split the clip
when the input
(1)
signal has
discontinued.]
January 28, 2014 T2 Additional Function Manual SP4.4
By checking, divides clips when the input
sinal has discontinued.
7
Section 4 ― Customize frame of play start delay in remote cotrol
Section 4
Customize frame of play start delay in remote cotrol
Other settings
Miscellaneous – Remote settings
You can make seings for the remote actions when you control T2 from an
external device with the GPI/Rs422 command.
1. Tap [Miscellaneous], and then tap the [Remote] tab in the seing
screen.
¾ [Remote] tab
Selecting [No (Minimum)] doesn't set delay.
[Remote(GPI/RS422)
Start/Stop Delay:]
Selecting [Yes (Sync Multiple T2s)] sets delay.
When multiple T2s are used, this is selected.
Selecting [Custom] sets delay. You can set
custom delay frames.
2. Set each item and tap [OK].
Tap [Apply] to keep on making seings of o
8
T2 Additional Function Manual SP4.4 January 28, 2014
Other additional / improve functions
Keyboard shortcut list in workstation mode
Section 5
[VARPlay+0.1]
[VARPlay-0.1]
[VARPlay+0.01]
[VARPlay-0.01]
[Keyboard Shortcut]
Increase playback speed by x0.1.
Decrease playback speed by -x0.1.
Increase playback speed by x0.01.
Decrease playback speed by -x0.01.
Assign GPI Input 1 - 6 to a key on the
keyboard. When GPI input is active, the
keyboard shortcuts will be active.
Support exporting to Sony XDCAM drive (PDW-U1, PDW-U2)
If you export to XDCAM drive (PDW-U1, PDW-U2), you tap [Export], and then tap [Export Media Files to
XDCAM Deive...].
Growing clip icon
(1)
Indicates that the contents is being recorded.
(1)
Recording
January 28, 2014 T2 Additional Function Manual SP4.4
The sub clip of recording contents is not shown
this icon.
9
Section 5 ― Other additional / improve functions
Support full-screen preview of R1/P1/P2 in workstation mode
In full screen mode, right-click on it, and then click [Full Screen Mode] or doubleclick on it.
(1)
Displays the video currently played back.
(1)
Preview
In full screen mode, right-click on it, and
then click [Full Screen Mode] or doubleclick on it.
Lock of front panel operation in workstation mode
In lock and unlock front panel, select [Sysmte] in menu bar, and then click [Lock Front Panel]. This mode is
unlocked to push [R1]+[P1]+[P2]+ [SHTL/VAR] buons same time also.
(1)
[Lock Front Panel]
[System]
Lock and unlock front panel. This mode is unlocked
to push [R1]+[P1]+[P2]+ [SHTL/VAR] buons same time
also.
10
T2 Additional Function Manual SP4.4 January 28, 2014
Improve "E to E" icon
In E to E mode, the E to E indicator will display blue text when R1 channel is played, and white text when P1/
P2 is played.
(1)
The E to E indicator will display blue text when
R1 channel is played, and white text when P1/
P2 is played.
(1)
E to E mode
indicator
Support current position in play growing files
Support to seek current position in play growing les. If you select [Move to next edit point] in P1/P2 when
you play recording data, move to latest recording point..
(1)
In the TRIM mode of the clip view or
playlist view, moves to the next edit point
(In/Out point aer trimmed, end of the
[Move to next edit
(1)
point]
clip) by every click.
In the playlist view, moves to the In point
of the next event.
If you play recording data, move to latest
recording point.
January 28, 2014 T2 Additional Function Manual SP4.4
11
