CS1000EV/1100EV
COLOR IMAGE SCANNER
USER’S MANUAL
MANUAL NO. CS1000-UM-153
TO ENSURE SAFE AND CORRECT USE
• To ensure safe and correct use of your Image Scanner, read this Manual thoroughly before
use.
• After having read this Manual, keep it in a handy location for quick reference as needed.
• Do not permit small children to touch the Image Scanner.
• The following describes important points for safe operation. Please be sure to observe
them strictly.
Conventions Used in This Manual
To promote safe and accurate use of the Image Scanner as well as to prevent human injury
and property damage, safety precautions provided in this manual are ranked into the three
categories described below. Be sure you understand the difference between each of the
categories.
This category provides information that, if ignored, is highly
DANGER
WARNING
:
likely to cause fatal or serious injury to the operator.
This category provides information that, if ignored, is likely
:
to cause fatal or serious injury to the operator.
This category provides information that, if ignored, could
cause injury to the operator or physical damage to the
CAUTION
Description of Safety Symbols
The symbol indicates information that requires careful attention (which includes
warnings). The point requiring attention is described by an illustration or text within
or next to the symbol.
The symbol indicates action that is prohibited. Such prohibited action is
described by an illustration or text within or next to the symbol.
The symbol indicates imperative action (that must be performed). Such imperative action is described by an illustration or text within or next to the symbol.
:
Image Scanner.
– i –
Safety Precautions
WARNING
Do not disassemble, repair, or remodel this scanner.
• Such action may cause a fire hazard or electrical
shock.
• Such action could impair the scanner’s performance
and cause it to malfunction or break down.
If the scanner generates smoke, is abnormally hot,
emits a strange odor, or otherwise functions abnormally, do not continue using it. Turn off its
power and unplug its power cord from the electrical socket.
• Use of the scanner in such status may result in a
fire hazard or electrical shock.
• Request repair by contacting your sales representative or nearest Graphtec vendor.
• Never try to perform repair yourself. Repair work
by inexperienced personnel is extremely dangerous.
No disassembly
Unplug the power
cord from the socket
If the scanner is damaged from being dropped or
other impact, turn off its power and unplug its
power cord from the electrical socket.
• Use of the scanner in such status may result in a
fire hazard or electrical shock.
• Request repair by contacting your sales representative or nearest Graphtec vendor.
• Never try to perform repair yourself. Repair work
by inexperienced personnel is extremely dangerous.
If water or foreign matter enters the scanner, turn
off its power and unplug its power cord from the
electrical socket.
• Use of the scanner in such status may result in a
fire hazard or electrical shock.
• Request repair by contacting your sales representative or nearest Graphtec vendor.
• Never try to perform repair yourself. Repair work
by inexperienced personnel is extremely dangerous.
Unplug the power
cord from the socket
Unplug the power
cord from the socket
– ii –
Safety Precautions (Continued)
WARNING
Do not connect the scanner to a non-rated power
supply.
• Use of a different supply voltage may result in a
fire hazard or electrical shock.
CAUTION
Be sure to ground the earth terminal.
• Unless the scanner is grounded, the operator could
suffer an electrical shock in case of current leakage.
Insert the scanner’s power plug securely into the
electrical socket.
• After first connecting the power cord’s female plug
to the scanner, connect its male plug to the electrical
socket.
• Using the scanner with its power plug incompletely
inserted into the electrical socket could cause a fire
hazard or electrical shock.
Prohibited
Ground the
scanner
Securely insert
the power plug
into the socket
Do not allow dust or metallic matter to adhere to
the power cord’s plug.
• If the power cord’s plugs become dirty, thoroughly
wipe them clean.
• The use of a dirty power cord plug could result in
a fire hazard or electrical shock.
When the scanner will not be used for an extended
period, unplug its power cord from the electrical
socket.
• Leaving the scanner connected to a power supply
increases its risk of short-circuiting and overheating.
– iii –
Prohibited
Beware of electrical shock
Unplug the power
cord from the socket
Safety Precautions (Continued)
CAUTION
Be careful not to damage the power cord or SCSI
interface cable and never use a damaged cord or
cable.
• Do not use unnecessary force to bend, pull, twist,
or bind the cord and cable, place a heavy object
on them, nor remodel them. Such actions could
result in scratches or damage to the cord or cable.
• Use of a damaged power cord or interface cable
may result in electrical shock or a fire hazard.
• Replace the damaged cord or cable with a new one.
When disconnecting the power cord or the SCSI
interface cable, do not pull on the cord/cable.
• Such action will damage the cord/cable, resulting
in a fire hazard or electrical shock. Be sure to hold
the power cord’s plug or the interface cable’s connector.
Before disconnecting the power cord or SCSI
interface cable, be sure to turn off the scanner.
• Failure to do so may damage the scanner’s performance and cause it to malfunction or break down.
• Failure to do so may result in electrical shock.
Never damage or
use when damaged
Pulling prohibited
Turn off the Power
switch
Before cleaning the scanner, be sure to unplug
its power cord from the electrical socket.
• Failure to do so may result in electrical shock.
Do not install, use, or store the scanner in a
location exposed to direct sunlight and/or the
direct draft of an air conditioner or heater.
• Such location may impair the scanner’s performance
due to deformation or other damage and cause the
scanner to malfunction or break down.
– iv –
Unplug the power
cord from the socket
Prohibited
Safety Precautions (Continued)
CAUTION
Do not install, use, or store the scanner in a
location that does not meet the specified temperature and humidity ranges.
• Such location may impair the scanner’s performance and cause the scanner to malfunction or break
down.
Do not install, use, or store the scanner in a
location subject to excessive mechanical vibration or electrical noise.
• Such location may impair the scanner’s performance and cause the scanner to malfunction or break
down.
Do not install the scanner on an unstable surface.
• The scanner could break due to impact from falling
from the surface or cause injury to the operator.
Prohibited
Prohibited
Install on a level surface
While the scanner is operating (reading or ejecting
a document), keep hands, clothing, and other
objects away from the document.
• Injury could result from an object getting tangled in
the scanner’s rollers.
Do not place any receptacle containing water or
other fluid on top of the scanner.
• Fluid falling inside the scanner may cause a fire
hazard or electrical shock due to a short circuit or
overheating.
Do not place heavy objects on the scanner.
• Such action may impair the scanner’s performance
due to deformation or other damage, and cause the
scanner to malfunction or break down.
Prohibited
Keep away
Avoid water areas
Beware of electrical shock
Prohibited
– v –
Safety Precautions (Continued)
CAUTION
Do not use sharp, pointed articles on the scanner.
• Such action may impair the scanner’s performance
and cause the scanner to malfunction or break
down.
Do not exert pressure on the scanner.
• Such action may impair the scanner’s performance
and cause the scanner to malfunction or break
down.
• Such action could cause injury to the operator.
Do not attempt to lubricate the scanner’s mechanisms.
• Such action may impair the scanner’s performance
and cause the scanner to malfunction or break
down.
• Such action may cause a fire hazard or electrical
shock due to a short circuit or overheating.
Prohibited
Prohibited
Prohibited
Do not clean the scanner using a volatile solvent
such as thinner or benzine.
• Such action may impair the scanner’s performance
and cause the scanner to malfunction or break
down.
Clean off the scanner’s soiled areas using a soft
cloth that has been moistened with water or a
neutral detergent (diluted with water) and then
firmly wrung out, then wipe the scanner using a
dry cloth.
For more details, see Chapter 5, “Daily Maintenance.”
Prohibited
– vi –
INTRODUCTION
Thank you for purchasing the CS1000EV/CS1100EV Image Scanner. The CS1000EV/
CS1100EV is capable of accurately performing high-speed scanning of documents ranging
in size from ISO A4 to ANSI E (CS1000EV) or ANSI D (CS1100EV).
An image scanner scans an image by illuminating a document and then reading the reflected
light using linear image sensors. The CS1000EV/CS1100EV converts the scanned image
data to 8-bit color, 256-tone grayscale or bilevel (monochrome) data, which is then transmitted
rapidly to the host system via the SCSI interface.
This User’s Manual describes how to operate the CS1000EV/CS1100EV, and also includes
usage precautions. Read the manual thoroughly prior to use in order to ensure full
understanding of the product’s features, and to ensure effective use. Keep the manual
in a safe place where it can be accessed easily whenever necessary.
Items in this manual marked are precautions to ensure safe use.
Please be sure to observe them strictly.
Notes Regarding This Manual
• All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, without the prior written permission
of Graphtec Corporation.
• The specifications and other information in this manual are subject to change without
notice.
• While every effort has been made to provide complete and accurate information, please
contact your sales representative or nearest Graphtec vendor if you find any unclear
or mistaken information or have other comments or suggestions.
• Notwithstanding the stipulation in the preceding paragraph, Graphtec Corporation assumes no liability for damages resulting from either the use of the information contained
herein or from use of the product.
• All names of companies, brands, logotypes, and products appearing in this manual are
the trademarks or registered trademarks of their respective companies.
Trademarks
Windows is a U.S. registered trademark of Microsoft Corp. Other product names mentioned
herein are trademarks or registered trademarks of their respective owners.
– vii –
Usage precautions
Do not lift or move the unit by holding
the top cover, as doing so may damage
the unit. Always lift the unit by holding
the underside of the side covers.
Side cover
Top cover
Side cover
CS1000EV
Side cover
Top cover
Side cover
CS1100EV
Take care to prevent your fingers from being caught in the gap between the top cover
and the main unit when opening and closing the top cover.
Top cover
<Opening the top cover>
Do not hold the rear section of
the top cover when opening it.
<Closing the top cover>
Keep your hands away from
the front of the main unit when
closing it.
Top cover
Before beginning scanner operation, be sure to remove the plastic sheet from the bottom
of the document hold-down unit. Please refer to Section 4.5, “Removing the Document HoldDown Unit” and Section 4.6, “Mounting the Document Hold-Down Unit” of this manual for
the removal and mounting procedures.
Scanner Warm-up
A warm-up period is not usually required for the CS1000EV/CS1100EV. However, if you
plan to scan a color document (in particular a document with many light colors), we
recommend that you allow the CS1000EV/CS1100EV to warm up for 10 minutes before
scanning the document.
– viii –
Contents
TO ENSURE SAFE AND CORRECT USE .................................................... i
Conventions Used in This Manual ........................................................................... i
Description of Safety Symbols ................................................................................. i
Safety Precautions .................................................................................................... ii
Introduction................................................................................................................. vii
1. OVERVIEW ........................................................................................................... 1-1
1.1 Features .......................................................................................................... 1-1
1.2 Unpacking the Scanner ................................................................................. 1-2
2. PREPARATION ................................................................................................... 2-1
2.1 Assembling the Scanner (CS1000EV) ......................................................... 2-1
2.2 Part Names and Functions............................................................................ 2-3
2.3 Attaching the Document Support Wires ....................................................... 2-6
2.4 Storing the EV Document Hold-Down Unit .................................................. 2-8
3. PREPARING TO OPERATE THE SCANNER ....................................... 3-1
3.1 System Requirements .................................................................................... 3-1
3.2 Connecting the Scanner to a Power Supply ............................................... 3-2
3.3 Connecting the SCSI Cable .......................................................................... 3-3
3.4 Setting the ID Number ................................................................................... 3-5
3.5 Turning the Scanner On or Off .................................................................... 3-6
3.6 Connecting the Scanner to a Computer ...................................................... 3-7
3.7 Checking the Interface Connection .............................................................. 3-16
3.8 Installing the Scanning Master 21+ Application .......................................... 3-18
3.9 Installing the Scanning Master Copy Color Application ............................. 3-19
4. LOADING A DOCUMENT .............................................................................. 4-1
4.1 Compatible Document Types ........................................................................ 4-1
4.2 Loading a Document ...................................................................................... 4-3
4.3 Using the Carrier Sheet................................................................................. 4-5
4.4 Using the EV Document Hold-Down Unit .................................................... 4-6
4.5 Removing the Document Hold-Down Unit ................................................... 4-7
4.6 Mounting the Document Hold-Down Unit ..................................................... 4-9
5. DAILY MAINTENANCE ................................................................................... 5-1
5.1 Cleaning the Image Sensors ......................................................................... 5-1
5.2 Cleaning the Paper Sensors ......................................................................... 5-3
5.3 Cleaning the Document Hold-Down Unit ..................................................... 5-4
5.4 Removing a Jammed Document................................................................... 5-5
5.5 Calibration ....................................................................................................... 5-7
– ix –
6. TROUBLESHOOTING PROCEDURES ..................................................... 6-1
6.1 The Scanner Is Turned On But Doesn’t Operate at All ............................. 6-1
6.2 The Scanner Operates Improperly After Connection to the Computer ..... 6-1
6.3 The Control Panel’s Red ERROR Lamp Is Lit ........................................... 6-2
6.4 The Control Panel’s Red ERROR Lamp Is Flashing ................................. 6-3
6.5 The Document Isn’t Properly Fed to the Initial Scanning Position ........... 6-3
6.6 After Scanning, Image Data Becomes Black or White .............................. 6-3
6.7 The Image Quality Has Dropped .................................................................. 6-3
6.8 The Input Image Data Is Incorrectly Aligned .............................................. 6-4
6.9 Smudges Not Appearing in the Original Document Appear
in the Scanned Data ...................................................................................... 6-6
6.10 The Image-Data Color Intensity Differs ........................................................ 6-6
6.11 The Document Length Differs from the Scanned Data Length ................. 6-6
6.12 Stripes or Moire Patterns Which Are Not in the Original Document
Appear in the Scanned Data ........................................................................ 6-6
APPENDIX A. OPTIONAL AND MISCELLANEOUS ITEMS ................ A-1
APPENDIX B. STANDARD SPECIFICATIONS .......................................... B-1
APPENDIX C. EXTERNAL VIEW ..................................................................... C-1
INDEX............................................................................................................................ Idex-1
– x –
1. OVERVIEW
1. OVERVIEW
1.1 Features
600-dpi optical resolution for high-precision image scanning
Scanning with an optical resolution of 600 dpi allows even complex and difficult-to-scan
documents, such as CAD drawings, electronic files, and mapping data to be scanned
rapidly and with high precision. Scanning Master 21+ (scanner software included as
a standard accessory) can be used to adjust the resolution in five levels (200 dpi to
800 dpi) to suit the scanned document.
Compatible document widths range from 210 mm to 1000 mm (CS1000EV), or to
630 mm (CS1100EV)
Compatible with document sizes from ISO A4 up to ANSI E (CS1000EV) or ANSI D
(CS1100EV)
Capable of color and grayscale scanning
Capable of scanning in color (8-bit color) or grayscale (256 shades)
Capable of reading long-axis data
Long-axis images are supported with a maximum length of approximately four meters
each.
Compact and lightweight design
A compact design was achieved by using a document travel system that employs closelyadhered image sensors in the sensor unit (five rows arranged in a zigzag pattern).
Image-processing functions
Use of the scanning software provided lets you set image-processing functions for the
scanning of a document.
Interface
The interface conforms to the SCSI-2 standard.
CS1000EV/1100EV 1 – 1
1. OVERVIEW
1.2 Unpacking the Scanner
After unpacking the Image Scanner, check its outer casing and check that the standard
accessories listed below are all present. If you detect a surface flaw or a missing accessory,
please promptly contact your sales representative or nearest Graphtec vendor.
Standard Accessories
Power cable 1 Carrier sheet IS0907 (CS1000EV) 1
or
IS0908 (CS1100EV)
User’s Manual 1
MANUAL NO. CS1000-UM-152
USER’S MANUAL
1000EV/1110EV
COLOR IMAGE SCANNER
CS
CS1000 Series User Guide CD-ROM 1
CS1000 Series User Guide
CD-ROM
Cable clamp (CS1000EV) 1
Document support wires 3
Stock brackets (CS1000EV) 2
EV document hold-down unit 1
Calibration sheet 1
1 – 2 CS1000EV/1100EV
2. PREPARATION
2. PREPARATION
2.1 Assembling the Scanner (CS1000EV)
Assemble the stand before mounting the scanner unit. Eight bolts and an Allen wrench
are provided with the stand.
(1) Using four bolts, loosely attach the center bar (3) to side stay R (1) and side stay L
(2).
(2)
(1)
Attach the center bar loosely. Tighten the bolts securely after the scanner unit has
been mounted on the stand.
(3)
CS1000EV/1100EV 2 – 1
2. PREPARATION
(2) Hold the scanner unit by the side covers on both sides, and mount the scanner so
that the positioning pins on the stand align with the positioning holes on the underside
of the scanner. Secure using the four bolts.
Holding the scanner by the rear part of the top cover may cause damage to the scanner
or to the person doing the installation. Always hold the scanner by the side covers.
Positioning pin
Side cover
Side cover
(3) Fully tighten the four bolts on the center bar to secure the side stays ( see the diagram
for step (1)).
(4) Before beginning scanner operation, be sure to remove the plastic sheet from the bottom
of the document hold-down unit. Please refer to Section 4.5, “Removing the Document
Hold-Down Unit” and Section 4.6, “Mounting the Document Hold-Down Unit” of this
manual for the removal and mounting procedures.
2 – 2 CS1000EV/1100EV
2.2 Part Names and Functions
Front View
Cover sensor
Paper sensor
2. PREPARATION
Top cover
Caster
Control panel
Stand
CS1000EV
CS1100EV
Top cover
Opening the top cover allows the document hold-down unit to be removed.
Cover sensor
This senses whether the top cover is open or closed, and interrupts scanner operation if
the top cover is opened during operation.
Stand
The stand unit is assembled for mounting of the scanner unit.
Casters
Release the lock on the casters to allow the unit to be moved.
Paper sensor
This senses whether a document is present in the scanner.
Do not touch the cover sensor or paper sensor.
CS1000EV/1100EV 2 – 3
2. PREPARATION
Control panel
POWER LED
Unlit : Is unlit while the scanner is turned off.
Lit : Lights (green) when the scanner is turned and remains lit
while it is operating normally.
PAPER LED
Unlit : Normal status (Local status).
Lit : Lights (green) when the scanner enters Scan READY status.
Flashing : Flashes (green) while image data is being scanned.
ERROR LED
Lit : Lights (red) to indicate a hardware error.
Flashing : Flashes (red) when a document is detected during the self-
test when the scanner is turned on or when the scanning is
suspended by pressing the STOP key.
Unlit : Normal status
FORWARD key
Advances the document into the scanner. When this key is pressed
in Scan READY status, the Scan READY status is cancelled and the
document is ejected toward the rear of the scanner.
REVERSE key
Feeds the document toward you. When this key is pressed in Scan
READY status, the Scan READY status is cancelled and the document
is ejected toward the front of the scanner.
STOP key
Compulsorily stops scanning of the document.
2 – 4 CS1000EV/1100EV
Rear View
2. PREPARATION
SCSI-ID switches
CS1000EV
SCSI-ID switches
DIP switch
2
DIP switch
AC line inlet
Power switch
4321
Power switch
AC line inlet
SCSI connectors
4321
CS1100EV
SCSI connectors
SCSI-ID switches
Used to specify the ID numbers of the SCSI interfaces.
DIP switch
Used to set the scanner’s functions.
Power switch
Controls the on/off status of the power supply to the scanner.
AC line inlet
Connect the power cord’s female plug here.
SCSI connectors
Used to connect SCSI interface cables. The two connectors are connected in parallel inside
the scanner.
CS1000EV/1100EV 2 – 5
2. PREPARATION
2.3 Attaching the Document Support Wires
With the CS1000EV, the document support wires should be attached when using the carrier
sheet or when heavy documents are scanned.
CS1000EV
Document support wires
With the CS1100EV, always attach the document support wires, regardless of the type of
document being scanned.
CS1100EV
Document support wires
If you are using the CS1100EV model, make sure that the document support wires
are attached before beginning a scanning operation. If you perform scanning without
the wires attached, the document may be damaged if it comes into contact with the
SCSI cable.
Attaching the document support wires
(1) Insert one end of the document support wire provided into the slot at the rear of the
scanner.
2 – 6 CS1000EV/1100EV
(2) Squeeze the document support wire, and insert the other end.
(3) Press down on both sides of the document support wire.
2. PREPARATION
(4) Attach the other document support wires in the same manner.
Detach the document support wires when moving or packing the scanner. Squeeze
softly and lift them to detach.
CS1000EV/1100EV 2 – 7
2. PREPARATION
2.4 Storing the EV Document Hold-Down Unit
Attach the two stock brackets to the stand’s center bar, and then mount the hold-down
unit on the brackets (CS1000EV, CS1100EV model mounted on the optional stand).
If you have a CS1100EV model without the optional stand, store the document hold-down
unit in the box in which it came.
Stock brackets
EV Document hold-down unit
How to attach the stock brackets (CS1000EV, CS1100EV model mounted on
the optional stand)
(1) Hook the two stock brackets onto the center bar as shown in the figure below.
(2) Lift up the handle-rings provided at each side of the document hold-down unit, and
then mount the unit onto the brackets with the handle-rings left in the raised position.
EV Document hold-down unit
Stock brackets
Note: The stand is optional for the CS1100EV model.
2 – 8 CS1000EV/1100EV
3. PREPARING TO OPERATE THE SCANNER
3. PREPARING TO OPERATE THE SCANNER
3.1 System Requirements
The minimum system requirements for running the scanner’s hardware and software are
listed below.
Operating system: Windows 95/98/Me, Windows NT 4.0, Windows 2000/XP or later
CPU: Pentium 133 MHz or higher
Memory: 32 MB or more
Monitor: 1024 × 768 pixels, 256 colors or more
Enough disk space to store data
Mouse
SCSI board by Adaptec
Recommended environment
For binary monochrome data
CPU: Pentium 200 MHz or higher
Memory: 64 MB or more
SCSI board by Adaptec (PCI type)
For grayscale data
CPU: Pentium III 550 MHz or higher
Memory: 256 MB or more
Monitor: 1024 × 768 pixels, High Color or higher resolution
SCSI board by Adaptec (PCI type)
For 8-bit color data
CPU: Pentium III 866 MHz or higher
Memory: 512 MB or more
Monitor: 1024 × 768 pixels, True Color or higher
SCSI board by Adaptec (PCI type)
The system configuration should correspond to the recommended specifications listed
here, in order to ensure the optimum capabilities of the scanner.
Use with a system configuration below the recommended specifications will affect the
scanning speed and prevent the scanner from operating to its specified capabilities.
To edit an A1-size or larger grayscale document with a resolution of 400 dpi or higher,
or an 8-bit color document, you may need more than the recommended memory sizes
above. Depending on the type of document, you may not be able to scan in the document
even if you increase the memory size.
CS1000EV/1100EV 3 – 1
3. PREPARING TO OPERATE THE SCANNER
3.2 Connecting the Scanner to a Power Supply
Insert the female plug of the power cord provided into the scanner’s AC line inlet and insert
its male plug into an electrical socket supplying AC voltage.
Check that the scanner’s Power switch remains in the Off position until the connection of
both the power cord and SCSI interface cable has been completed.
If you have a CS1100EV model, please refer to Section 2.2, “Part Names and Functions”,
page 2-5, for the location of the AC line inlet.
Ensure that the scanner’s Power switch is in the Off position.
3 – 2 CS1000EV/1100EV
Loading...
