Grandstream Networks GXV Series Overview

Innovative IP Voice and Video

GRANDSTREAM

NETWORKS

Grandstream Presents:

The GXV Series

SIP / VOIP TECHNOLOGY

All of Grandstream’s IP surveillance products offer industry-leading SIP / VoIP technology that allow s
two-way communication w ith c amer as and encoders. You can register a Grandstr eam IP
surveillance product as a SIP extension and “call” the unit using an IP video or mult imedia phone.

But SIP / VoIP technology is n’t just an easy way to establis h two-way audio and video between
Grandstream’s cameras and mult imedia SIP phones. The real value of SIP / VoIP technology is that
it essentially eliminates the learni ng curv e for providers, r eseller s, and integr ator s. If you already
know how to provision and install SIP telephony pr oducts , y ou’ll k now how to integrate our G XV
Series surveillance products. You can also achieve easy video recording through Asterisk®.

You can look for this functionality in Axis, Cisco, Panasonic, and Sony pr oduc ts, but you won’t f ind i t.

EXCEPTIONAL VALUE

Grandstream uses premium image sensors and pr oc es s or s to pr oduc e max video resolution that
exceeds industry st andards .

We ship each product with ever y thing you’ll actually need to use it. If you buy a G X V3601 series
box camera, it comes with a lens . G X V3615 units come with mounts. Our vandal-resi stant HD
dome camera is IP66 weather-proof and you w on’t have t o purchase heaters as optional add-ons.

SUPERIOR QUALITY

Analog cameras can’t compete with our GX V S er ies IP surv eil lanc e pr oduc t s . Our cameras offer
better picture and audio, mor e advanced featur es, and gr eater flexi bility – all at a lower price. We
encourage you to tes t our pr oduc ts against other leading IP cameras because we know you won’t

find a better solution or a better value.

Industry leading technology. Superior quality. A ffordable pric ing. That’s the way Grandstream does

surveillance.

Event Trigger Snapshots

Multi-Steaming Rate

Two-Way Audio Paging

Alarm Buffer

SIP / VoIP Technology

Standard Features for all GXV Series IP Surveillance Models

Video Watermark

HTTPS

G.711 and G.726 Audio Codecs

Free GSurf Video Management Software

Free Provisioning Tools

Free Firmware Upgrades

Every GXV Camera Ships Wit h A Basic / Standard Lens Included

View live demos at

www.grandstream.com

IP VIDEO ENCODERS

IP video encoders are like analog telephone adapters for standard analog video surveillance
cameras, converting the analog signal and preparing it for IP transmi s s ion. If you have invested in
analog cameras and don’t want to replace them, IP video encoders are a cost-effective option that
allows you take advantage of IP without sac r ificing any of the functionalit y your analog c amer as
already provide.

Grandstream offers two models of IP video encoder. The GXV3501
is a single channel encoder supporting f ull D 1 resolution.

The GXV3504 is a four channel encoder that supports either four
ports CIF resolution at full rate, or two ports D 1 r es olut ion and 2
ports CIF.

Both models offer full PTZ control (subject to the capabi lities of your
analog camera), integrated Pow er over Ethernet, v ideo watermar ks ,
and a 24MB alarm buffer with event trigger for email / FTP
notification.

ENCODER / DECODER / PA

The GXV3500 is an advanced first-of-its-kind IP video encoder + decoder + public announcement
system 3-in-1 combo product for professional surv eillanc e and s ecuri ty monitoring appli cations .
video encoders are lik e analog telephone adapters for standar d analog video s ur v eillance cameras,
converting the analog s ignal and prepari ng it for IP transmission. If you have invest ed in analog
cameras and don’t want to replace them, IP video encoders are a cost-effective option that allows
you take advantage of IP without sacrific ing any of the functionality your analog c ameras already
provide.

The GXV3500 features H.264 real-time video c ompres sion for
analog video as well as IP video dec oding with excellent image
clarity. It offers industry leading SIP/VoIP for 2-way audio, video
streaming to mobile phones and v ideo phones, integrate d PoE, a
large pre-/post-event r ecording buffer, and advanced security
protection.

Its integration of comprehensive peripherals incl uding microphone
input, alarm control and TV/audio output allow s the devic e to also
function as a powerful and flexible voice/video public announcem ent
system using microphones, IP phones, or IP video phones.

GXV3500 SCENARIO

IP CUBE CAMERAS

An exceptional value, cube cameras are per fect for small office or home s ecurity applications. They
don’t offer the widest viewing range, but for cov erage of a particular door or small-to-medium s ized
room the cube camera will certainly do the trick.

Grandstream’s GXV3615 standard definiti o n cube camera has a low­light CMOS sensor, so it’s ready for both normal and low-light conditions.
It’s also got an integrated microphone and speak er for two way audio
paging and SIP / VoIP communication. This is one of the mos t f lex ible,
easiest to deploy IP cameras on the market today.

The GXV3615 offers Power over Ethernet, but G r ands t ream also makes
a non-PoE model called the GXV3615_W with built-in WiFi support.

IP BOX CAMERAS

Box cameras are very popular because they’re so versatile. Whether y ou need detail at a dis t anc e
or clarity up close, you c an c hange the lens on a box c amer a and adjust the filed of v iew quit e
easily. Box cameras are perfect for focusing in on a fixed point li ke an entrance or an exit and
they’re quite conspicuous, making them a great crime deterrent.

Grandstream offers three models of IP Box Camera. The GXV3601 is
a standard definition c amera that’s simple to inst all and easy to use.
It’s a great fit for most home and SMB security projects.

Where you might require a bit mor e det ail, ie. high traffic public-facing
environments, Grands t ream offers a 720p High Defi nition version
called the GXV3601_HD.

Grandstream has also developed the GXV3601_LL, a Low Light
model for 24 / 7 monitoring of dimly lit areas like parking lots.

PREMIUM FULL HD IP BOX CAMER A

The GXV3651_FHD i s a next gener ation High Definition IP camera built on power and innovati on. I t
features cutting edge H.264 real -time video c ompress ion at 1080p resolution with excellent image
clarity at low-to-modest bandwidth, a 5MP-capable CMOS sensor, Motion JPEG, indust ry leading
SIP/VoIP for full duplex 2-way audio and video streaming to mobile phones and v ideo phones,
integrated PoE, embedd e d analyti cs , large pre-/post-event recording buffer, and advanced security
protection.

IP MINI DOME CAMERAS

Dome cameras are easy to mount, largely unobtrusiv e, and they can be hidden a bit better than box
cameras. Because of the dark dome, y ou can’t tell fr om the outside ex actly where the fixed lens is
pointing.

Grandstream offers two models of IP Mini Dome Cameras. The
GXV3611_HD is a 720p High Definition camera. It mounts beautifully
to the ceiling and has a sleek low-profile design, perfect for
professional environments. A built-in high performance streaming
server allows 6+ simultaneous H D viewers.

For low light environments, Grandstream also offers the GXV3611_LL.
A built-in high performance streaming ser ver allows up to 16
simultaneous D1 view ers or 25 CIF viewers.

Both cameras in the GX V3611 series also f eatur e Power over Ethernet
and an integrated mi c rophone and speaker.

PREMIUM IP DOME CAMERA

The GXV3662 is a premium quality wide dy namic r ange IP dome camera. It’s built for both indoor
and, with the proper accessor ies, outdoor us e. It’s IP66 weather -proof , v andal resis tant, and
features both high definition and low-light capabilities. This is the tr ue pr ofes s i onal’s I P secur ity
camera, made to handle the heavy lifting.

Grandstream’s GXV3662 is built with a professional grade
heating and cooling sys tem allowing it to operate at
temperatures from -30 °C to 60°C (-22°F to 140°F). This unit
fits three different mounts, sold separ ately, including a flush
ceiling mount, standar d wall mount, and penda nt mount. You
will not find a more versatile HD dome camera, and it’s all but
impossible to find a comparison at or near this price point. The
GXV3662 offers unmatched value.

GRANDSTREAM FOR IPHONE™

Wouldn’t it be really cool if there was an easy-to-use IPhone™ app that let s y ou remotely monitor
Grandstream IP cameras?

Introducing IP Vision™, a third party app that supports
Grandstream IP cameras. The picture quality is excellent, and i t’s
really quite easy to configure the app t o follow mult iple
Grandstream cameras. You will find a thorough guide available at
www.grandstream.com.

This is an absolute no-brainer for iPhone™ owners.

Not to be outdone, several third party applicati on dev elopers inc luding Tiny
Cam Monitor have developed st unning mobile surv eillanc e apps for
Android ™.

Easy to use and completely interoperable with Grandstream’s GXV Series
Surveillance Products , t he Tiny Cam Monitor app lets you take your f ull
Grandstream surveillance s uite with you on the go.

GRANDSTREAM FOR ANDROID™

Home Automation (HA) can mean many different things to many different people, but the leading
HA applications usually inc lude a video s urv eillance and monitoring component. Grandstream’s
award-winning IP Cameras and IP multimedia phones are a perfec t fit for HA projects.

HOME AUTOMATION

Control4 is a leading provider of operating sys tems for the smart home, delivering intelligent
control over consumer electronics produc ts, applianc es and netw orki ng sy stems through an easy­to-use and intuitive software interface. Grandstream is proud to have established inter operability
with Control 4 Home Automation. Drivers are available through Extra Vegetables.

All the above are registered trademarks of their respective entities. All rights reserved.

GSURF

Grandstream’s GSurf is a monitoring and recording system for up to 36 camer as . GSurf supports
remote viewing, control and recording f rom anywhere on the Internet or local access network. GSurf
is powerful, easy to configure, and supports advanced video management featur es including alarm
triggers, groups, patrol play, electronic mapping, and automatic recording.

GSurf is available 100% f ree of charge at
www.grandstream.com where you can also
download the complete program user manual.

ASTERISK®

Grandstream’s video surveillanc e cameras and encoder s feature an option to oper ate as a SIP end
point. This option allows installers to i ntegr ate the cameras and encoders with the popular open
source Asterisk® softswitch. Users can dial in from their video phones to their cameras to monitor
activity. The cameras and encoders are able
to send video in H.264 format.

Grandstream has created an easy to follow
configuration guide at www.grandstream.com.

VMS PARTNERS

Grandstream is committed to ensuring that integrating our GXV3xxx video surveil lance portfolio is
seamless. We conduct thorough testing w it h 3rd party video monitoring systems to make it eas ier
for end users, integrators, c onsult ants and manuf acturer s to tak e advantag e of the pos sibil ities
offered by network video, resulting in more cos t -effective and flexible s olutions, ex panded mark et
opportunities and reduc ed ris k.

Current Partners:
Milestone

Digifort
Codestuff
Logiware
Genetec
Netcamara
NUUO

Blue Cherry
Seventh
Video Insight
Zone Minder

…and more

All the above are registered trademarks of their respective entities. All rights reserved.

ONVIF

ONVIF is an open industry forum for the developmen t of a global st andard for the interface of IP­based physical security products. ONVIF is committed to the adoption of IP-based physical s ecurity
in the security market. The ONVIF specification will ensure interoperability between IP-based
physical security products regardless of manufacturer.

Acti
Axis
Bosch
Canon
Cisco
D-Link

LG
Panasonic
Pelco
Samsung
Siemens
Sony

ONVIF partners include:

All the above are registered trademarks of their respective entities. All rights reserved.

VIDEO MONITORING STATION

You already know Grandstream’s award-winning GXV3140 IP Multimedia Phone as a leading SIP
desk phone, a Skype-enabled v ideo phone, a cos t -effective S MB video confer encing solution, and a
do-it-all consumer product. You should also think of it as a dynamic IP video monitoring station.

Grandstream’s IP surveillance solutions offer industry -leading SIP /
VoIP technology, and they w ere designed to work in tandem with our
video phone products like the GXV3140. You can call any
Grandstream IP camera, access the feed, and communic ate with
the camera right from your GX V3140.

Perfect for front desk, hospitality, and building access solutions, a
video monitoring s t ation like the GXV3140 mak es i t s igni fic ant ly
easier for users at all sk il l levels t o get the most out of IP
surveillance cameras.

GXV3140 IP MU LTIMEDIA PHONE

The GXV3140 combines best-in-class technology to
enable free video and voice calling w orldwide w ith
just one simple step: plug-in. The GXV3140 allow s
you to keep in touch w ith f riends and family around
the world as well as information that impacts y our
daily life without interr uption, any time of day.

•Make free voice and video calls upon installation.

•Access real time information through an integrated web browser, RSS

feeds of weather/news/stocks and internet radio.

•Access to Yahoo Flickr web photo album, alarm clock, calendar, games,
music ring tones.

•A full-duplex speakerphone and popular voice codec support ensure
best-in-class telephony features.

The GXV3175 represents the future in personal IP multimedia
communication. Stunning v ideo quality, intriguing user
interface with delightful details , rich W eb appl icat ions
embodied in a sleek tablet-like design, distinguished t his
product as the ultimate desktop multimedia phone.

• 7 Inch T ouch Screen

• Dual network ports with integrated PoE, integrated WiFi,

comprehensive auxiliary ports , and support f or advanced
video compression standard H.264/H.263/ H.263+.

• Personalized rich media presentati on and deliv ery,
popular Web and social networking applic ations , and
advanced business productivity tools.

GXV3175 IP MU LTIMEDIA PHONE

GXV3175 IP MU LTIMEDIA PHONE

Visual Busy Lamp Field (BLF) Visual BLF Home Screen Widget

The GXV3175 offers more than video calling, more than a brilliant touch screen, and more than a
next-generation multimedia experience. It’s also the world’s best exec ut iv e desk phone with new
premium business productiv i ty apps like visual BLF.

QUESTIONS AND ANSWERS

• Q: Does GSurf only work with Grandstream cameras?

• A: Yes, GSURF is Grandstream’s free VMS software for use only with Grandstream cameras and ecoders.

• Q: What are the rough prices per encoder channel?

• A: Please contact one of our distribution partners to get MSRP and reseller pricing.

• Q: In GSURF it always asks for administrator password?

• A: Admin user does require a password but you can setup access without a password. Please refer to user

manual link below.

http://www.grandstream.com/products/surveillance/general/documents/gsurf_usermanual_english.pdf

• Q: What if want to view more than 36 cameras?

• A: I would recommend using multiple versions of Gsurff running on multiple machines. You c an also tak e a

look at our certified partners list and use one of those scalable NVR applications.

• Q: If GSurf can record on triggers, why or when would I use GSNVR? When do we use GSurf and when is

GSNVR used?

• A: GSurf is the monitoring tool and GSNVR is the recorder. You would need to use both of them together to

record and monitor.

• Q: Has it been installed with Allworx?

• A: To my knowledge Allworx does not currently support video. We have however deployed Grandstream IP

Phone with an Allworx PBX.

CONTACT US

JOAO SANTOS – [email protected]

MICHAEL RYBACKI – [email protected]

WWW.GRANDSTREAM.COM
