GXV3500
IP Video Encoder/Decoder
QuickStart
Guide
For Warranty and RMA information, please visit www.grandstream.com
Content |
|
English...................................................... |
1 |
................................................ |
11 |
Español................................................... |
21 |
Français.................................................. |
31 |
Deutsch................................................... |
41 |
Italiano.................................................... |
51 |
EN PRECAUTIONS
•Do not attempt to open, disassemble, or modify the device
•Do not use a third party power adapter
•Do not expose this device to temperatures outside the range of -10oC to +55oC
•Do not expose the GXV3500 to environments outside of the following humidity range: 10-90% RH (non-condensing)
PACKAGE CONTENTS
GXV3500 |
12V Power Supply |
TV out RCA cable |
Quick Start Guide |
CONNECTING THE GXV3500
Refer to the illustration below when following the instructions on the next page.
NOTE: Choose Option A if using the power supply. Or choose Option B if using a Power over Ethernet (PoE) switch.
~1~ |
~2~ |
Option A
Step 1: Insert the power adapter’s positive (+) bare wire into the +12V DC port on the GXV3500.
Insert the negative (-) bare wire into the ground (GND) port of the GXV3500 using a screwdriver to press on the terminals. Plug the other end of the adapter into an AC power outlet.
Step 2: Plug an RJ45 Ethernet cable into the network port. Plug the other end into a hub, switch or router.
Option B
Step 1: Plug an RJ45 Ethernet cable into the network port. Plug the other end into a Power over Ethernet (PoE) switch.
GXV3500 CONFIGURATION
Configuring the GXV3500 using Microsoft Internet Explorer
Connect the GXV3500 to the DHCP server
Step 1: Navigate your browser to: http://www.grandstream.com/products/ tools/surveillance/gsurf_pro.zip
Step 2: Run Gurf_Pro -> Manage tool -> Search tool.
Step 3: Click on the
button in order to begin the device detection.
Step 4: The detected devices will appear in the output field.
~3~ |
~4~ |
Step 5: Open Microsoft Internet Explorer on your PC. Type in the IP in the address bar.
Step 6: A pop-up window will appear with prompts for a user name and password. The default administrator user name and password are both set to “admin” at the default factory configuration.
~5~
Step 7: Once you log into the GXV3500’s web interface, the device will indicate that you need to install or update the video plug in.
Step 8: Save the VideoPlugine.exe file and run it on your computer. Then restart Internet Explorer.
You should get a confirmation message regarding the installation of the plug in.
Step 9: Once the installation of the plug in is completed, you will see the web page shown in the screenshot on the next page. Click on the play button to view the video feed.
~6~
Step 10: Click through the menu of the left hand side of the web GUI for more advanced configuration parameters.
Connect the GXV3500 using Static IP
If the camera does not get a response from the DHCP server after 3 minutes, it can be accessed by the default IP 192.168.1.168
Step 1: Connect your PC and the GXV3500 to the same network.
~7~
Step 2: Set the IP address of your PC to 192.168.1.X.
Set the subnet mask of your PC to 255.255.255.0.
~8~
Step 3: Open Microsoft Internet Explorer on your PC. Type 192.168.1.168 in the address bar.
Step 4: Please refer to Steps 6-10 above.
Please download the user manual and FAQ for more detailed configuration instructions: http://www.grandstream.com/support/ gxv_series_sur-veillance/gxv3500/documents/ gxv3500_usermanual_english.pdf
GXV3500 SAMPLE
CONNECTION DIAGRAM
~9~ |
~10~ |
•-10 55
•GXV3500 10-90%
GXV3500 |
12V DC |
~11~
GXV3500
B: RJ45 |
A: 12V |
PoE |
DC |
|
|
: A B PoE
~12~
A
1: + GXV3500 +12V DC- GXV3500 GND AC
2: RJ45
B
1: RJ45 GXV3500
PoE
Gxv3500
GXV3500 DHCP ,GXV3500
DHCP IP
1: IP
http://www.grandstream.com/products/ tools/surveillance/gsurf_pro.zip
2 Manage Tool->
3
,IP
4 IP HTTP
~13~ |
~14~ |
5: IE IP
6: admin
~15~
7: GXV3500 , IE
8: VideoPlugine.exeIE
9:
~16~
