Grandstream DP752, DP730, DP722 User Manual

Grandstream Networks, Inc.
DP752/DP730/DP722 DECT Cordless VoIP System
DP752
DECT Cordless VoIP
Base Station
DP730
DECT Cordless
HD Handset
DP722
DECT Cordless
HD Handset
P a g e | 1
DP752/DP722/DP730 User Guide
Version 1.0.15.6
COPYRIGHT
©2021 Grandstream Networks, Inc. http://www.grandstream.com
All rights reserved. Information in this document is subject to change without notice. Reproduction or
transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose without
the express written permission of Grandstream Networks, Inc. is not permitted. The latest electronic version of this user manual is available for download here:
http://www.grandstream.com/support
Grandstream is a registered trademark and Grandstream logo is trademark of Grandstream Networks, Inc.
in the United States, Europe and other countries.
CAUTION
Changes or modifications to this product not expressly approved by Grandstream, or operation of this product in any way other than as detailed by this User Manual, could void your manufacturer warranty.
WARNING
Please do not use a different power adaptor with your devices as it may cause damage to the products and void the manufacturer warranty.
P a g e | 2
DP752/DP722/DP730 User Guide
Version 1.0.15.6
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Any Changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Exposure to Radio Frequency (RF) Signals
For Handset
This is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S.
Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on the safety standards previously set by both U.S. and
international standards bodies. These standards include a substantial safety margin designed to assure the
safety of all persons, regardless of age and health. This device and its antenna must not be collocated or
operating in conjunction with any other antenna or transmitter. This product has been shown to be capable
of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population
exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the
measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE 1528.
For Base
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
P a g e | 3
DP752/DP722/DP730 User Guide
Version 1.0.15.6
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Operating Frequency Band (RF):
DECT: 1881.792 MHz - 1897.344 MHz (TX/RX)
Modulation Mode:
DECT: GFSK
Max. Of Transmit Power:
DP752
DP730
DP722
22.9 dBm
22.5 dBm
22.3 dBm
P a g e | 4
DP752/DP722/DP730 User Guide
Version 1.0.15.6
GNU GPL INFORMATION
DP752 firmware contains third-party software licensed under the GNU General Public License (GPL).
Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License
(GPL) for the exact terms and conditions of the license.
Grandstream GNU GPL related source code can be downloaded from Grandstream web site from:
http://www.grandstream.com/support/faq/gnu-general-public-license/gnu-gpl-information-download
P a g e | 5
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Table of Content
DOCUMENT PURPOSE .................................................................................................. 11
CHANGE LOG ................................................................................................................. 12
Firmware Version 1.0.15.6 ...................................................................................................................... 12
Firmware Version 1.0.15.3 ...................................................................................................................... 12
Firmware Version 1.0.15.2 ...................................................................................................................... 12
Firmware Version 1.0.13.8 ...................................................................................................................... 12
Firmware Version 1.0.13.0 ...................................................................................................................... 12
Firmware Version 1.0.11.12 .................................................................................................................... 12
Firmware Version 1.0.11.4 ...................................................................................................................... 12
Firmware Version 1.0.11.2 ...................................................................................................................... 13
Firmware Version 1.0.9.9 ........................................................................................................................ 13
Firmware Version 1.0.9.1 ........................................................................................................................ 13
Firmware Version 1.0.7.5 ........................................................................................................................ 13
GUI INTERFACE EXAMPLES ......................................................................................... 14
WELCOME ...................................................................................................................... 15
PRODUCT OVERVIEW ................................................................................................... 16
Feature Highlights ................................................................................................................................... 16
DP752 Technical Specifications .............................................................................................................. 17
DP730 Technical Specifications .............................................................................................................. 19
DP722 Technical Specifications .............................................................................................................. 21
GETTING STARTED ........................................................................................................ 23
Equipment Packaging ............................................................................................................................. 23
Connecting DP752 .................................................................................................................................. 25
Connecting via AC power ................................................................................................................ 25
Connecting via PoE ......................................................................................................................... 25
Setting up DP730/DP722 Handsets ....................................................................................................... 25
Battery Information .......................................................................................................................... 26
P a g e | 6
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Setting up the Charge Station ................................................................................................................. 26
DP752 LED Patterns............................................................................................................................... 27
DP730/DP722 Handsets Description ...................................................................................................... 27
DP730/DP722 Icons Description ............................................................................................................ 31
DP730/DP722 Handsets Menu ............................................................................................................... 33
BASIC OPERATIONS ...................................................................................................... 39
Turning the Handsets ON / OFF ............................................................................................................. 39
Setup Wizard .......................................................................................................................................... 39
Register DP730/DP722 Handsets to DP752 Base Station..................................................................... 39
Using DP730/DP722 with Multiple DP752 Base Stations ...................................................................... 40
Registering DP730/DP722 to an additional DP752 base station .................................................... 40
Switching Between Different Base Stations .................................................................................... 41
Unregister the DP730/DP722 ................................................................................................................. 41
Setting the Key Lock ............................................................................................................................... 42
Locating a DP730/DP722 Handset from DP752 Base station ............................................................... 43
Locate via DP752 Web UI ............................................................................................................... 43
Locate via DP752 Base station ....................................................................................................... 44
Checking System Status ......................................................................................................................... 44
Basic Network Settings ........................................................................................................................... 45
Change Menu and LCD Timeout ............................................................................................................ 46
Return to Idle Screen .............................................................................................................................. 46
Register SIP Account .............................................................................................................................. 46
Register Account via Web User Interface ........................................................................................ 46
PHONE SETTINGS.......................................................................................................... 49
Editing the Handset Name ...................................................................................................................... 49
Changing the Base PIN Code ................................................................................................................. 50
Selecting Phone Language ..................................................................................................................... 51
Activate/Deactivate Hands-Free Mode ................................................................................................... 52
Muting the Microphone ........................................................................................................................... 52
Adjusting Speaker and Earpiece Volume ............................................................................................... 52
P a g e | 7
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Ringtones ................................................................................................................................................ 52
Setting the Ringer Volume on the Handsets ................................................................................... 52
Setting Ringtones on the Handsets ................................................................................................. 53
Advisory Tones ................................................................................................................................ 54
Ringtones Customization ................................................................................................................. 54
Date and Time ......................................................................................................................................... 57
Gestures (DP730 only) ........................................................................................................................... 57
Facedown Hangup........................................................................................................................... 58
Close-to-Ear Backlight ..................................................................................................................... 58
Factory Functions ................................................................................................................................... 59
DP722/DP730 Handsets Firmware Upgrade .......................................................................................... 60
Reboot DP752 Base Station ................................................................................................................... 61
Reset DP722/DP730 Handsets .............................................................................................................. 61
CALL OPERATIONS ....................................................................................................... 63
Outgoing Default Line ............................................................................................................................. 63
Placing calls ............................................................................................................................................ 63
Make a Call using a Line ................................................................................................................. 63
Dialing from Call history ................................................................................................................... 64
Dialing from Phonebook .................................................................................................................. 65
Intercommunication ......................................................................................................................... 65
Answering Calls ...................................................................................................................................... 66
Auto Answer ..................................................................................................................................... 66
Off-Cradle Pickup ............................................................................................................................ 67
Ending Calls ............................................................................................................................................ 67
On-Cradle Hang-up ......................................................................................................................... 67
Rejecting Calls ........................................................................................................................................ 68
Direct IP Call ........................................................................................................................................... 68
Call Hold/Resume ................................................................................................................................... 69
Call Waiting ............................................................................................................................................. 69
Do Not Disturb ........................................................................................................................................ 70
P a g e | 8
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Call Forward ............................................................................................................................................ 70
Paging ..................................................................................................................................................... 71
Call Transfer ............................................................................................................................................ 71
Blind Transfer ................................................................................................................................... 71
Attended Transfer ............................................................................................................................ 71
Transfer between handsets ............................................................................................................. 72
Speed Dial .............................................................................................................................................. 72
3-Way Conference .................................................................................................................................. 73
Voice Mail ................................................................................................................................................ 73
Set Voice Mail Feature Code ........................................................................................................... 73
Play Voice Mail Messages ............................................................................................................... 74
PTT (Push-To-Talk) ................................................................................................................................. 75
Call Features ........................................................................................................................................... 77
RESTORE FACTORY DEFAULT SETTINGS .................................................................. 79
EXPERIENCING DP752/DP722/DP730 .......................................................................... 80
P a g e | 9
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Table of Tables
Table 1: DP752 Features at a Glance ............................................................................................................ 16
Table 2: DP730 Features at a Glance ............................................................................................................ 16
Table 3: DP722 Features at a Glance ............................................................................................................ 16
Table 4: DP752 Technical Specifications ....................................................................................................... 17
Table 5: DP730 Technical Specifications ....................................................................................................... 19
Table 6: DP722 Technical Specifications ....................................................................................................... 21
Table 7: Equipment Packaging – DP752 ....................................................................................................... 23
Table 8: Equipment Packaging – DP730 ....................................................................................................... 23
Table 9: Equipment Packaging – DP722 ....................................................................................................... 24
Table 10: DP722/DP730 Battery Specifications ............................................................................................. 26
Table 11: DP752 LED Patterns ...................................................................................................................... 27
Table 12: Keypad Keys Description ............................................................................................................... 28
Table 13: Keypad Keys Description ............................................................................................................... 29
Table 14: DP730/DP722 Icons Description .................................................................................................... 31
Table 15: DP752 Info description ................................................................................................................... 44
Table 16: DP722/DP730 Info description ....................................................................................................... 44
Table 17: Call Features .................................................................................................................................. 77
Table of Figures
Figure 1: DP752 Package Content ................................................................................................................ 23
Figure 2: DP730 Package Content ................................................................................................................ 24
Figure 3: DP722 Package Content ................................................................................................................ 24
Figure 4: DP752 Back View ........................................................................................................................... 25
Figure 5: Setting up the DP730/DP722 .......................................................................................................... 26
Figure 6: Setting up Charging Stations .......................................................................................................... 27
Figure 7: DP752 LED Patterns ...................................................................................................................... 27
Figure 8: DP722 Keys Description ................................................................................................................. 28
Figure 9: DP730 Keys Description ................................................................................................................. 29
Figure 10: DP730/DP722 Menu Structure ..................................................................................................... 34
Figure 11: Registration Process .........................................................................................................................
Figure 12: Multiple Base Stations Registration .............................................................................................. 40
Figure 13: Switching Between Base Stations ................................................................................................ 41
Figure 14: Unregister DP730/DP722 from DP752 web UI ............................................................................. 42
Figure 15: Locate Handsets via Web UI ........................................................................................................ 43
Figure 16: Network Settings Configuration .................................................................................................... 45
Figure 17: SIP Settings .................................................................................................................................. 47
Figure 18: SIP Accounts Settings.......................................................................................................................
Figure 19: Account Status .............................................................................................................................. 48
P a g e | 10
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Figure 20: Handsets Name editing ................................................................................................................ 49
Figure 21: Edit Handsets Name from DP752................................................................................................. 50
Figure 22: Changing Admin Base PIN Code from DP722/DP730 ................................................................. 50
Figure 23: Changing Admin Base PIN Code from DP752 ............................................................................. 51
Figure 24: Handsets Language ...................................................................................................................... 51
Figure 25: Ringer Volume .............................................................................................................................. 53
Figure 26: Advisory Tone ................................................................................................................................ 54
Figure 27: Generating Custom Ringtone (Windows) ..................................................................................... 55
Figure 28: Downloading Custom Ringtones .................................................................................................. 56
Figure 29: Date and Time Settings ................................................................................................................ 57
Figure 30: DP730 Gestures ........................................................................................................................... 58
Figure 31: DP730 Gestures – Facedown Hangup ......................................................................................... 58
Figure 32: DP730 Gestures – Close-to-Ear Backlight ................................................................................... 58
Figure 33: Factory Functions ......................................................................................................................... 60
Figure 34: Firmware Notification .................................................................................................................... 60
Figure 35: Firmware Upgrade ........................................................................................................................ 61
Figure 36: Rebooting the Base Station .......................................................................................................... 61
Figure 37: Resetting the Base Station ........................................................................................................... 62
Figure 38: Outgoing Default Line ................................................................................................................... 63
Figure 39: Shortcut Setting ............................................................................................................................ 65
Figure 40: PTT Call Establishment ................................................................................................................ 75
Figure 41: PTT Transmission ......................................................................................................................... 75
Figure 42: Enable PTT ................................................................................................................................... 76
Figure 43: Set a Softkey for PTT ................................................................................................................... 76
P a g e | 11
DP752/DP722/DP730 User Guide
Version 1.0.15.6

DOCUMENT PURPOSE

This document describes the basic concept and tasks necessary to use and configure your DP722/DP730
via the LCD menu and also using the DP752 base station. And it covers the handsets installation, basic
operations and call features. Please visit http://www.grandstream.com/support to download the latest
“DP752/DP722/DP730 User Guide”.
This guide covers following topics:
• Product Overview
• Getting Started
• Basic Operations
• Phone settings
• Call Operations
• Restore Factory Default Settings
P a g e | 12
DP752/DP722/DP730 User Guide
Version 1.0.15.6

CHANGE LOG

This section documents significant changes from previous versions of user guide for DP752/DP722/DP730.
Only major new features or major document updates are listed here. Minor updates for corrections or editing
are not documented here.

Firmware Version 1.0.15.6

• No major changes.

Firmware Version 1.0.15.3

• No major changes

Firmware Version 1.0.15.2

• Add support to input provisioning server username and password on handset UI when base station is trying to download a config file from a password protected server.
• Added support to delete a paired base station from the handset.

Firmware Version 1.0.13.8

• Added support for handsets to internally page other handsets without accounts registered. [Paging][Call Features]
• Updated the CPE to 1.0.1.141 to better support GDMS.

Firmware Version 1.0.13.0

• No major changes

Firmware Version 1.0.11.12

• Added support for intercom feature without SIP account. [Intercommunication]
• Added support for transfer between HS internally without SIP. [Transfer between handsets]
• Add handset option for blind transfer and attended transfer. [Call Transfer]

Firmware Version 1.0.11.4

• No major changes
P a g e | 13
DP752/DP722/DP730 User Guide
Version 1.0.15.6

Firmware Version 1.0.11.2

• Added Chile time zone.

Firmware Version 1.0.9.9

• No major changes.

Firmware Version 1.0.9.1

• Added support for Intercom feature. [Intercommunication]

Firmware Version 1.0.7.5

• This is the initial version for DP752/DP730/DP722.
P a g e | 14
DP752/DP722/DP730 User Guide
Version 1.0.15.6

GUI INTERFACE EXAMPLES

http://www.grandstream.com/sites/default/files/Resources/DP752_web_gui.zip
1. Screenshot of Login Page
2. Screenshots of Status Pages
3. Screenshots of Profiles Pages
4. Screenshots of DECT Pages
5. Screenshots of Settings Pages
6. Screenshots of Maintenance Pages
7. Screenshots of Phonebook Pages
P a g e | 15
DP752/DP722/DP730 User Guide
Version 1.0.15.6

WELCOME

Thank you for purchasing Grandstream DP752 DECT Cordless VoIP Base Station and DP722/DP730 DECT Cordless HD Handsets.
The DP752 is a powerful DECT VoIP base station that pairs with up to 5 of Grandstream’s DP series DECT
handsets to offer mobility to business and residential users. It supports a range of up to 400 meters with
DP730 and up to 350 meters with DP722/DP720 outdoors and 50 meters indoors to give users the freedom
to move around their work or home space, delivering efficient flexibility. This DECT VoIP base station supports
up to 10 SIP accounts and 5 concurrent calls while also offering 3-way voice conferencing, full HD audio and
integrated PoE. A shared SIP account on all handsets will add seamless unified features that gives users the
ability to answer all calls regardless of location in real-time. The DP752 supports a variety of auto-provisioning
methods and TLS/SRTP/HTTPS encryption security. When paired with Grandstream’s DP720, DP722 or
DP730 handsets, the DP752 offers a powerful cordless DECT solution for any business or residential user.
The DP730 is a DECT cordless IP phone that allows users to mobilize their VoIP network throughout any
business, warehouse, retail store and residential environment. It is supported by Grandstream’s DP750 and
DP752 DECT VoIP base stations and delivers a combination of mobility and top-notch telephony performance.
Up to five DP730 handsets are supported on each base station while each DP730 supports a range of up to
400 meters outdoors and 50 meters indoors from the base station. It touts a suite of robust telephony features
including support for up to 10 SIP accounts and 2 concurrent calls per handset, full HD audio, a 3.5mm
headset jack, push-to-talk, a speakerphone and more. When paired with Grandstream’s DECT Base Stations,
the DP730 offers a powerful cordless DECT solution for any business or residential user.
The DP722 is a DECT cordless IP phone that allows users to mobilize their VoIP network throughout any
business, warehouse, retail store and residential environment. It is supported by Grandstream’s DP750 and
DP752 DECT VoIP base stations and delivers a combination of mobility and top-notch telephony performance.
Up to five DP722 handsets are supported on each base station while each DP722 supports a range of up to
350 meters outdoors and 50 meters indoors from the base station. It touts a suite of robust telephony features
including support for up to 10 SIP accounts and two concurrent calls per handset, full HD audio, a 3.5mm
headset jack, push-to-talk, a speakerphone and more. When paired with Grandstream’s DECT Base Stations,
the DP722 offers a powerful cordless DECT solution for any business or residential user.
P a g e | 16
DP752/DP722/DP730 User Guide
Version 1.0.15.6

PRODUCT OVERVIEW

Feature Highlights

The following tables contain the major features of the DP752 / DP730 / DP722:
Table 1: DP752 Features at a Glance
Table 2: DP730 Features at a Glance
Table 3: DP722 Features at a Glance
DP752
5 Handsets. 10 accounts. 10 Lines. 5 Concurrent calls. PoE power support. Range: Up to 400m with DP730 and up to
350m with DP722/DP720 outdoor / 50m range
indoor.
DP730
DECT cordless HD. 2.4 inch (240x320) color TFT LCD 500 hours standby / 40 hours talk time. 15 languages embedded. 10 accounts. 10 lines. 2 concurrent calls. 5 ring modes.
DP722
DECT cordless HD. 1.8 inch (128x160) color TFT LCD 250 hours standby / 20 hours talk time. 15 languages embedded. 10 accounts. 10 lines. 2 concurrent calls 5 ring modes.
P a g e | 17
DP752/DP722/DP730 User Guide
Version 1.0.15.6

DP752 Technical Specifications

The following table resumes all the technical specifications including the protocols / standards supported,
voice codecs, telephony features, languages and upgrade/provisioning settings for the Base station DP752.
Table 4: DP752 Technical Specifications
Air Interface
Telephony standards: DECT Frequency bands:
▪ 1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US) ▪ 1910 – 1920 MHz (Brazil), 1786 – 1792 MHz (Korea) ▪ 1893 – 1906 MHz (Japan), 1880 – 1895 MHz (Taiwan)
Number of channels: 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8 (Taiwan)
Range: Up to 400 meters with DP730 and up to 350 meters with DP722/DP720
outdoor / 50m range indoor.
Peripherals
3 LED indicators: Power, Network, DECT. Pairing/Paging button. One 10/100 Mbps auto-sensing Ethernet port with integrated PoE
Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS
(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-
MED, LDAP, TR-069, 802.1x, TLS, SRTP
Voice Codecs
G.711μ/a-law, G.723.1, G.729A/B, G.726-32, iLBC, G.722, OPUS, G.722.2/AMR-
WB (special order), in-band and out-of-band DTMF (in audio, RFC2833, SIP
INFO), VAD, CNG, PLC, AJB
Telephony Features
Hold, transfer, forward, 3-way conference, push to talk, intercom, downloadable
phonebook (XML, LDAP, up to 3000 entries), call waiting, call log (up to 300
records), auto answer, flexible dial plan, server redundancy and fail-over
QoS
Layer 2 QoS (802.1Q, 802.1p) and Layer 3 QoS (ToS, DiffServ, MPLS)
Security
User and administrator level access control, MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS,
802.1x media access control, DECT authentication & encryption
Multi-language
Chinese Simple, Chinese Tradition, Czech, Danish, Dutch, English, Estonian,
Finnish, French, German, Hebrew, Hungarian, Japanese, Korean, Norwegian,
Portuguese, Romanian, Spanish, Swedish, Turkish.
Upgrade/
Provisioning
Firmware upgrade via TFTP, HTTP/HTTPS or FTP/FTPS, mass provisioning using
TR-069 or AES encrypted XML configuration file
Multiple SIP
Accounts
Up to ten (10) distinct SIP accounts per system
Each handset may map to any SIP account(s) Each SIP account may map to any handsets(s)
P a g e | 18
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Ring Group
Flexible options when multiple handsets share the same SIP account
▪ Circular Mode:
All phones ring sequentially, starting with the phone after the one which
rang last.
▪ Linear Mode:
All phones ring sequentially in the predetermined order, starting with the
first phone each time.
▪ Parallel Mode:
All phones ring concurrently; after one phone answers, the remaining
available phones can make new calls
Power & Green
Energy Efficiency
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC, 1A; Micro-
USB connection; PoE: IEEE802.3af Class 1, 0.44W–3.84W
Package Content
Base unit, Universal Power Supply, Ethernet cable, Quick Installation Guide, GPL
Statement
Dimensions
(H x W x D)
140.31 x 64.98 x 105 mm
Weight
Base unit: 140g; Universal power supply: 50g; Package: 370g
Temperature
and Humidity
Operation: -10º to 50ºC (14 to 122ºF); Storage: -20º to 60ºC (-4 to 140ºF); Humidity: 10% to 90% non-condensing
Compliance
FCC: FCC Part 15B; FCC Part 15D;MPE; FCC ID
CE：EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 60950-1; EN 301
489-1/-6; EN 301 406; EN 50385; RED NB Cert RCM：AS/NZS 32; AS/NZS 60950.1. ANATEL, EAC, UL(adapter).
P a g e | 19
DP752/DP722/DP730 User Guide
Version 1.0.15.6

DP730 Technical Specifications

The following table resumes all the technical specifications including the protocols / standards supported,
voice codecs, telephony features, languages and upgrade/provisioning settings for the DP730 handsets.
Table 5: DP730 Technical Specifications
Air Interface
Telephony standards: DECT Frequency bands:
▪ 1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US) ▪ 1910 – 1920 MHz (Brazil), 1786 – 1792 MHz (Korea) ▪ 1893 – 1906 MHz (Japan), 1880 – 1895 MHz (Taiwan)
Number of channels: 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8 (Taiwan) Range: up to 400 meters outdoor and 50 meters indoor
Peripherals
2.4 inch (240x320) color TFT LCD
27 keys including 3 soft keys, 5 navigation/ menu keys, 4 dedicated function keys
for SEND, POWER/END, SPEAKERPHONE, MUTE, 3 side keys including 2
volume (up and down) and 1 Push-to-Talk key 3-color MWI LED
3.5mm headset jack Proximity and accelerometer sensors Backlit keypad Removable belt clip Micro-USB port for alternative charging and non-battery operation
Protocols/Standards
Hearing Aid Compatibility (HAC) compliant
Voice Codecs
G.722 codec for HD audio and G.726 codec for narrow band audio (G.711μ/a-law,
G.723.1, G.729A/B, iLBC and OPUS are supported via companion DECT base
station DP752), AEC, AGC, Ambient noise reduction on microphone capturing and
advanced noise suppression on audio playing
Telephony Features
Hold, transfer, forward, 3-way conference, push-to-talk, intercom, call park, call
pickup, downloadable phonebook, call waiting, call log, auto answer, click-to-dial,
flexible dial plan
HD Audio
Yes, in both Handsets and Speakerphone modes
Security
DECT authentication & encryption
Multi-language
Chinese Simple, Chinese Tradition, Czech, Danish, Dutch, English, Estonian,
Finnish, French, German, Hebrew, Hungarian, Japanese, Korean, Norwegian,
Polish, Portuguese, Romanian, Spanish, Turkish.
Upgrade/
Provisioning
Software Upgrade Over-The-Air (SUOTA), handsets provisioning Over-The-Air
Multiple Line
Access
Each handset may access up to 10 lines
P a g e | 20
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Power & Green
Energy Efficiency
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB
connection; Rechargeable Li-ion battery (500 hours of standby time and 40 hours of talk time)
Package Content
Handset unit, universal power supply, charger cradle, belt clip, 1 battery, Quick
Start Guide
Dimensions
(H x W x D)
Handset: 168.5 x 52.5 x 21.8mm; Charger cradle: 76 x 73 x 81mm
Weight
Handset: 180g; Charger cradle: 78g; Universal power supply: 50g; Package: 465g
Temperature
and Humidity
Operation: -10º to 50ºC (14 to 122ºF); Charging: 0 to 45ºC (32 to 113ºF); Storage:
-20º to 60ºC (-4 to 140ºF); Humidity: 10% to 90% non-condensing
Compliance
FCC: FCC Part 15B; FCC Part 15D; SAR (FCC 47 CFR Part2.1093; IEEE 1528;
IEC 62209-2); FCC Part68 HAC; FCC ID
CE：EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 60950-1;EN 301
489-1/-6; EN 301 406; EN 50332-2; SAR(EN50360;EN50566;EN 50663;EN62209-
1; EN62209-2; EN 62479); RED NB Cert RCM：AS/NZS CISPR32; AS/NZS 60950.1;AS/CA S004;AS/ACIF S040. ANATEL, EAC, UL(adapter).
P a g e | 21
DP752/DP722/DP730 User Guide
Version 1.0.15.6

DP722 Technical Specifications

The following table resumes all the technical specifications including the protocols / standards supported,
voice codecs, telephony features, languages and upgrade/provisioning settings for the DP722 handsets.
Table 6: DP722 Technical Specifications
Air Interface
Telephony standards: DECT Frequency bands:
▪ 1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US) ▪ 1910 – 1920 MHz (Brazil), 1786 – 1792 MHz (Korea) ▪ 1893 – 1906 MHz (Japan), 1880 – 1895 MHz (Taiwan)
Number of channels: 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8 (Taiwan) Range: up to 350 meters outdoor and 50 meters indoor
Peripherals
1.8 inch (128x160) color TFT LCD
23 keys including 2 softkeys, 5 navigation / menu keys, 4 dedicated function keys
for SEND, POWER/END, SPEAKERPHONE, MUTE 3-color MWI LED
3.5mm headset jack Removable belt clip Micro-USB port for alternative charging and non-battery operation
Protocols/Standards
Hearing Aid Compatibility (HAC) compliant
Voice Codecs
G.722 codec for HD audio and G.726 codec for narrow band audio (G.711μ/a-law,
G.723.1, G.729A/B, iLBC and OPUS are supported via companion DECT base
station DP752), AEC, AGC, Ambient noise reduction on microphone capturing and
advanced noise suppression on audio playing
Telephony Features
Hold, transfer, forward, 3-way conference, push to talk, call park, call pickup,
downloadable phonebook, call waiting, call log, auto answer, click-to-dial, flexible
dial plan
HD Audio
Yes, in both Handsets and Speakerphone modes
Security
DECT authentication & encryption
Multi-language
Chinese Simple, Chinese Tradition, Czech, Danish, Dutch, English, Estonian,
Finnish, French, German, Hebrew, Hungarian, Japanese, Korean, Norwegian,
Polish, Portuguese, Romanian, Spanish, Turkish
Upgrade/
Provisioning
Software Upgrade Over-The-Air (SUOTA), handsets provisioning Over-The-Air
Multiple Line
Access
Each handset may access up to 10 lines
Power & Green
Energy Efficiency
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB
connection; Rechargeable 800mAh Ni-MH Low Self-Discharge (LSD) AAA
batteries (250 hours of standby time and 20 hours of talk time)
P a g e | 22
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Package Content
Handsets unit, universal power supply, charger cradle, belt clip, 2 batteries, Quick
Installation Guide
Dimensions
(H x W x D)
Handset: 158 x 50 x 28.1mm; Charger cradle: 81.15 x 75.89 x 36.36mm
Weight
Handset: 110g; Charger cradle: 44g; Universal power supply: 50g; Package: 328g
Temperature
and Humidity
Operation: -10º to 50ºC (14 to 122ºF); Charging: 0 to 45ºC (32 to 113ºF); Storage:
-20º to 60ºC (-4 to 140ºF); Humidity: 10% to 90% non-condensing
Compliance
FCC: FCC Part 15B; FCC Part 15D; SAR (FCC 47 CFR Part2.1093; IEEE 1528;
IEC 62209-2); FCC Part68 HAC; FCC ID
CE：EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 60950-1;EN 301
489-1/-6; EN 301 406; EN 50332-2; SAR(EN50360;EN50566;EN 50663;EN62209-
1; EN62209-2; EN 62479); RED NB Cert RCM：AS/NZS CISPR32; AS/NZS 60950.1;AS/CA S004;AS/ACIF S040. ANATEL, EAC, UL(adapter).
P a g e | 23
DP752/DP722/DP730 User Guide
Version 1.0.15.6

GETTING STARTED

This chapter provides basic installation instructions including the list of the packaging contents and also
information for obtaining best performance with the DP730/DP722 DECT Cordless HD Handsets and the
DP752 DECT Cordless VoIP Base Station.

Equipment Packaging

Table 7: Equipment Packaging – DP752
Figure 1: DP752 Package Content
Table 8: Equipment Packaging – DP730
DP752
• 1 Base unit
• 1 Universal power supply 5V
• 1 Bracket
• 1 Ethernet cable
• 1 Quick Installation Guide
• 1 GPL Statement
DP730
• 1 Handset unit
• 1 Universal power supply 5V
• 1 Charging station
• 1 Handset Belt
• 1 Rechargeable Li-ion battery
• 1 Quick Installation Guide
P a g e | 24
DP752/DP722/DP730 User Guide
Version 1.0.15.6
Figure 2: DP730 Package Content
Table 9: Equipment Packaging – DP722
Figure 3: DP722 Package Content
Note: Check the package before installation. If you find anything missing, contact your system administrator.
DP722
• 1 Handset unit
• 1 Universal power supply 5V
• 1 Charging station
• 1 Handset Belt
• 2 Rechargeable batteries
• 1 Quick Installation Guide
Loading...
+ 56 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
