Grandstream Door Phone User Manual

Door Camera Solutions

Door Camera Solutions

1. Using Grandstream devices with 3rdparty IP Door Cameras

2. Creating a Door Camera Solution with Grandstream IP Cameras and IP
Video Phones

UCM6100 series IP PBX Appliance

UCM6102
UCM6104

UCM6108
UCM6116

Asterisk is a Registered Trademark of Digium

UCM6100 series IP PBX Appliance

The Anchor of Your Door Camera Solution & Voice/Video/Data/Mobility Communications

Delivering high quality, secure and reliable voice, video,

data & mobility for SMBs

 Enterprise-grade features in an affordable,

compact & easy-to-manage PBX designed

specifically for the SMB market

 No licensing fees
 Fast and easy setup & management

 ALL hardware/software included as

well as lifetime firmware updates

 Full SIP Video support

UCM6100 series

Voice

Secure, clear, and reliable

Conferencing

Comprehensive Codec Support

Endless Customizable Voice

features

Data

Phonebook files

CDR

Codec Transcoding

System Backup

Call Recording

Voicemail/fax to email

Mobility

Softphone apps

Monitor your business

Connect Multiple Offices

Video

Face to face video calls

Video Surveillance Integration

SIP Video

Video Codec Support

UCM6100 series

UCM6100 series – Full SIP Video Support

Full SIP Video Support

 Any SIP video endpoint, such as

 Video Phones
 Video Conferencing Solutions

 Door/Facility Access Cameras/Modules

 IP Video Surveillance cameras

UCM6100 Series - Video

Delivering high quality, secure and reliable video communications

Door Camera Solutions

1. Using Grandstream devices with 3rdparty IP Door Cameras

2. Creating a Door Camera Solution with Grandstream IP Cameras and IP
Video Phones

Integrate Surveillance with Your IP PBX

A Door Camera Solution…

Extension 801

(or direct phone number)

Extension 802

Extension 803

Extension 804

Extension 805

Office on Floor 1

Office on Floor 2

Office on Floor 3

Office on Floor 4

DTMF Codes to Open the Door on the

Grandstream phone

Also use the UCM6100 series to supply all

communications for a full office building

The Upper West Side Apartments

Melbourne, Australia

Extension 801

Extension 802

Extension 803

Extension 804

Extension 805

Extension 806

Extension 807

DTMF Codes to
Open the Door on
the Grandstream
phone

Visit our case studies page for more

Also use the UCM6100 series to supply all

communications for a full apartment building

A True Unified Communications Solution

Easily Integrate a Door Camera Solution With Your Business Communications

Solutions

 All Grandstream phone, cameras, and UCM6100 series –

as well as IP Door Cameras are SIP-based devices

 A true Unified Communications solution offering voice,

video, data and mobility features

 All devices can be easily setup, customized and

managed from one central location

 Add functionality to devices by combining them onto

the same network

 Even add/include analog phones and analog cameras

Communicate with Any SIP Door Camera on Any Network

Communicate With Cameras/Door Cameras on Any Network

 IP Camera’s and Door Cameras can send alerts or be

contacted from outside networks thanks to their SIP
registration when registered to an IP PBX

 You set the phone number the cameras contact

when an alert is triggered

 With a SIP registration, any IP camera or Door

Cameras is given a phone number/IP address that

can be called to view the camera’s live feed

 View camera’s live feed from any device that has an

internet connection

Internet

UCM6100 Series

Integrating Surveillance and Door Access Solutions with Your IP PBX

1. Visitor can call from door phone to

video phone in apartment or office

2. From video phone, user can unlock
door using a pre-configured DTMF key

• H.263

• H.263+

• H.264

Enable Video Codecs

UCM6100 - Video

Delivering high quality, secure and reliable video communications

Supports all major

video codecs

Make sure you enable the proper video codecs on the
UCM6100 series and the IP Door Camera. This simple

mistake is the most common configuration mistake

Door Camera Solutions

1. Using Grandstream devices with 3rdparty IP Door Cameras

2. Creating a Door Camera Solution with Grandstream IP Cameras and IP
Video Phones

Door Access Solution

Turn a Grandstream IP Surveillance Camera into a Door Opener when Paired with a

Grandstream Video Phone

Step 1: Configure the Grandstream Video Phone
and the IP Camera

Step 2: Enable Alert Event

Step 3: Connect Doorbell and IP Camera

Step 4: Open Door via Incoming Video Call

1. Receive video calls from cameras

whenever alerts/alarms are triggered

2. Make video calls to cameras to see the
live feed

Video Features

The Kovalevo Center

Kastroma, Russia

Visit our case studies page for more

Camera, with motion detection

enabled and alarm event set to “SIP

Call”

DTMF Codes to Open the Door on the

Grandstream phone

Many Grandstream cameras includes a

variety of inputs/outputs to integrate

with other devices, such as a door bell,

so that when the door bell is ringed, the

camera will send the alert.

Motion Detection

• Available on all Grandstream cameras

• Up to 16 target areas per camera

• Easily setup in 3 steps using a camera’s Web UI

• Grandstream’s ONVIF-compliancy will allow

motion detection on our camera to interact with
any ONVIF VMS, NVR, etc.

Important

Settings

• Sensitivity

• Minimum duration required by motion detection trigger

• Minimum interval of different motion detection event

• Time Schedule Config

• Alarm Action (what should the camera do when motion is

detected)

• Record Video

• Voice Alarm to SIP phone

• Upload to Alarm Center (Gsurf_Pro V2)

• Upload to Alarm HTTP (3rdparty Application/VMS)

• Upload to FTP

• Email and FTP screenshots

Set Up Alarm Actions…

Choose this option to have video call made to video phone. If the phone

being called is SIP video enabled, the call will go through as a video call

Voice Alerts to SIP Phone
