Operating Instructions Food Slicer
MASTER M 80
2
Table of content
Safety instructions
3
Unpacking 5
Requirements on the installation location 5
Safety hazards 5
Cutting material 5
Cutting operation 5
Holder for remainders 6
Tilting by 30 deg. 6
Cleaning 6
Preservation of value - blade 7
Removing the blade 7
Slide 7
After-sales service 8
Disposal 8
Motor guarantee 8
Troubleshooting 9
3
Safety instructions
This unit is in conformity with the safety
instructions mentioned hereinbefore. However,
incorrect handling may lead to injury and
damage.
For safe handling of this unit, please observe
the following safety instructions:
● Before using the unit check for any external
visible damage of the housing, the connection
cable and plug. Do not operate a damaged
unit.
● In case of a damage of the connection cable
of the machine, the unit may be replaced by
the manufacturer or the after-sales service or
a similarly qualied person only, in order to
avoid any danger.
● Repairs may be carried out only by an expert
or by Graef after-sales service. Incorrect
repairs may cause considerable hazards
for the user. In addition, any claim under
guarantee is forfeited.
● A repair of the unit during the guarantee
period may be carried out by Graef after-
sales service only as otherwise there is no
claim under guarantee in case of subsequent
damage.
● Defective parts must be replaced by original
spare parts only. It is only with these parts
that the safety requirements are met.
● This unit must not be used by children. This
unit and its power cable must be kept away
from children.
● This unit may be used by persons with
reduced physical, sensory or mental abilities
or deciencies in experience and knowledge,
if they are supervised or have been instructed
in the safe use of the unit, and in addition
understand the resulting dangers.
● Children must not play with this unit.
● In the absence of supervision and prior to
assembly, during cleaning disconnect the unit
from the mains.
● The unit is not intended to be used with an
external timer or a separate remove control.
● This unit is intended for use in households and
4
similar use, such as: Staff kitchens in shops
and ofce; in agricultural estates; by guests
in hotels, motels and other living quarters; in
bed and breadfast boarding houses.
● Always disconnect the connection cable by
using plug; do not pull the connecting cable.
● Before connecting the unit compare the
connection data (voltage and frequency) on
the typeplate and your mains. These data
have to be in conformity so that no damage
can occur.
● Do not use the unit when the connection
cable or the plug is damaged.
● Before reusing, have the unit tted with a
new connection cable by the Graef aftersales service or an authorised specialist.
● By no means open the housing of the unit.
An electric shock may be caused by touching
life connection and electrical mechanical
structures.
● Never touch live parts. They can cause an
electric shock or may result in death.
● Never carry the unit by its power cable.
● Never transport the unit during operation.
● Never operate the unit with wet hands.
● In idle state, turn the adjustment know
clockwise to zero setting so that the stop
plate covers the knife blade.
● Packaging materials must not be used for
playing. There is a danger of suffocation.
● Do not touch the blade of the knife with your
ngers. This is very sharp and may cause
serious injury.
● Make sure that the unit has been switched
off before cleaning or non-use and is not
connected up to the mains.
● Check whether the stop has been closed
(blade covered).
● Do not use any aggressive or scouring
detergent and no solvents.
● Do not scape off any persistent dirt with a
hard object.
● Do not rinse the unit in water or immerge in
5
water.
● The unit must not be used without the food
holder for remainders unless the size and
shape of the food permits use without.
Unpacking
Proceed as follows to unpack the unit:
● Remove the unit from the box.
● Remove the packaging parts.
● Remove any stickers on the unit (do not
remove the typeplate).
Requirements on the installation location
For safe and faultfree operation of the unit,
the following requirements of the installation
location have to be met:
● The unit has to be placed on a solid, at,
horizontal and non-slipping surface mit a
sufcient weight-carrying capacity.
● Choose the location in such a way that children
cannot reach the sharp blade of the unit.
Safety hazards
The very sharp blade can cut off parts of the
body. Your ngers are especially endangered.
For this reason, do not reach into the space
between the stop plate and the blade as long
as the stop plate is not closed completely, i.e.
set to “0”.
Cutting material
● The unit can be used to cut bread, ham,
sausage, cheese, fruit, vegetables, et cetera.
● By no means cut hard objects, such as frozen
food, bones, wood, sheet metal or similar.
Cutting operation
● Place a tray, a plate or something similar
below the unit.
● Choose the requested slicing thickness.
● Switch the unit on.
● Press the material gently to the stop plate
and the slide to the blade evenly.
Note: Soft food (such as cheese or ham) can
6
be sliced best when cooled. Soft food can be
cut better when pushed slowly. When slicing
cucumbers or carrots, it is advantagous if they
are cut to equal lengths rst which are then
fed using the holder for remainders.
Holder for remainders
The unit must not be used without the food
holder for remainders unless the size and shape
of the food permits use without.
As soon as the size or shape of the food permits
the use of the holder for remainers, this has to
be used.
● Place the remainders or smaller food on the
slide.
● Place the holder for remainders at the rear
wall of the slide and move the holder for
remainders up to the food to be cut.
● Proceed as described above in chapter
“Cutting”.
The holder for remainders permit slicing of
smaller food, such as mushrooms or tomatoes.
Tilting by 30 deg.
The tilting function is especially useful
for cutting bread, hard-cured sausage and
vegetables. By means of the tilting function,
the natural gravity force of the product to be
cut is used for feeding.
Proceed as follows to tilt the unit:
● Press the lock knob. The unit is unlocked.
● Use the swivelling lever to pull the unit up
forcefully until it locks in audibly.
● When the unit has been locked in audibly, it
is secured.
● Now continue as described in the chapter
titled “Cutting operation”.
● After nishing the cutting process, swivel the
unit back.
● Turn the swivelling lever down.
Press the rear part of the prole to lock the
locking bolt.
Cleaning
Use a soft and moist cloth to clean the outer
7
surfaces of the unit. Use a mild detergent in
case of heavy soiling.
Preservation of value - blade
For a long-lasting sharpness and for a
preservation of the value of your Graef blade
we recommend that the blade be cleaned
in regular intervals, especially after cutting
cured meat or ham. They contain salts which
when on the blade surface for a longer period
of time could produce so-called “rust lm”
( on “stainless steel” as well). When cutting
products which contain a lot of water, such as
tomatoes or cucumbers, a lack or wrong (too
“wet”) cleaning may produce rust on the blade
surface.
For this reason we recommend that you use a
moist cloth and a bit of detergent, if and when
necessary, to clean the blade directly after
use. Never put the blade in a dishwasher, rstly
due to decrease in sharpness and corrosion
resistance (salts attack the blade), and
secondly due to safety in handling the blade
whilst loading and unloading the dishwasher.
Removing the blade
Unscrew the blade from time to time and
clean the unit on the inside. Do this, especially
“juicy” cutting material (tomatoes, fruit,
roasts, et cetera) are cut. Handle the blade
with great care.
● Remove the slide.
● Use the black handle grip to turn the blade
cover plate in the direciton of the arrow
upwards until it is vertical over the motor
body. During this action in the initial position,
the snap point has to be overcome rst of all.
● Applying slight pressure, the blade can be
removed.
● Undo the blade by using a coin to turn the
blade screw clockwise.
● Use a moist cloth to clean the inside of the
blade and the black ring.
● Place the blade in reverse order.
Slide
In order to clean the slide better, it can be
8
removed from the unit.
● To remove the carriage, simply fold it to the
side.
● Use a moist cloth or running water to clean
all parts.
Important: Do not clean the slide in a
dishwasher!
● Once a month, add some drops of resin-free
oil or petroleum jelly to the slideway. Use a
soft cottonwool cloth to remove excessive oil
/ petroleum jelly.
● To t it to the machine, hold it vertically over
the table and hook the carriage slide in the
appropriate guide rail on the table.
● Then fold the carriage back onto the table
and into horizontal position.
After-sales service
If you Graef unit should be damaged, please
get in touch with your specialist dealer or with
a Graef after-sales service.
Disposal
At the end of its service life, this product
cannot be disposed of in normal domestic
waste but has to be disposed of at a collection
point for recycling electonic household waste.
The symbol on the product and in the operating
instructions point out to this fact. Reuse the
materials according to their marking. By
reusing, recycling or other applying other
forms of use of old units, you render an
important contribution to the protection of
our environment. Please ask your municipal
administration for the disposal point.
10 year motor guarantee
For this product we assume an additional
guarantee on the motor of 120 months beginning
with the date of sale. Your legal warranty
claim in conformity with Section 439 ff. of The
German Civil Code E shall be unaffected by this
regulation. The guarantee does not cover any
damage which is caused by incorrect handling
or use as well as defects which only slightly
inuence the function or the value of the unit.
9
Troubleshooting
Problem Cause Solution
Slide moves sluggishly. Slide slide is dirty. Clean and grease the slide
slide.
Blade moves slugglishly. Cogwheels of the blade are not
greased or are dirty.
Undo and clean the blade; use
petroleum jelly to grease the
inside of the blade (cogwheel
of blade) and the black ring.
Grinding noise caused by
blade.
Food residues on the blade potentially
Remove, clean and grease the
blade.
Operating noises increase
with increasing use.
Gear is not greased sufciently. Undo and clean the blade; use
petroleum jelly to grease the inside of the blade (cogwheel of
blade) and the black ring.
Moreover, transport damage provided we are not
responsible shall be excluded from the claims
under guarantee. Guarantee shall be ruled out
for damage, the repair of which has not been
carried out by us or one of our represenations.
In case of justied complaints, we shall repair
the defective product or replace it by a product
without defects at our discretion.
Loading...
