Operation
Formula Gun GC-1387J
ENG
Low emission internal-mix dispense gun for use with polyester resin and gel coat.
For professional use only.
Maximum fluid working pressure:
2000 psi (14 MPa, 138 bar)
Maximum air pressure:
100 psi (0.7 MPa, 7 bar)
Important Safety Instructions
Read all warnings and instructions in
this manual. Save these instructions.
Contents
Warnings .......................................................... 3
Important Safety Information ......................... 5
Grounding ........................................................ 6
Set-Up ............................................................... 7
Parts .................................................................9
Pressure Relief Procedure ........................... 14
Maintenance ................................................... 15
Accessories ...................................................18
Graco Ohio Standard Warranty .................... 28
Graco Information ......................................... 28
2 GC-1387H
Warnings
tiple times to ensure it is thoroughly clean.
compatibility.
ISO on the B side.
side. Polyureas often have amines on the B (resin)
side.
WARNING
SPLATTER HAZARD
Hot or toxic fluid can cause serious injury if splashed in the eyes or on skin. During blow off of platen,
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment.
The exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure-
specic risk. Refer back to these warnings. Additional, product-specic warnings may be found throughout the
body of this manual where applicable.
• See Important Safety Information - MEKP, Polyester Resins and Gel-Coats and Spraying and Lamination
Operations section of this manual.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help
prevent re and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic
drop cloths (potential static arc).
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when ammable
fumes are present.
• Ground all equipment in the work area. See Grounding instructions.
• Use only grounded hoses.
• Hold gun rmly to side of grounded pail when triggering into pail.
• If there is static sparking or you feel a shock, stop operation immediately. Do not use
equipment until you identify and correct the problem.
• Keep a working re extinguisher in the work area.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in the
operating area of the equipment to help protect you from serious injury, including eye injury,
inhalation of toxic fumes, burns, and hearing loss. This equipment includes but is not limited to:
• Protective eyewear
• Clothing and respirator as recommended by the uid and solvent manufacturer
• Gloves
• Hearing protection
WARNING
TOXIC FLUID OR FUMES HAZARD
Toxic uids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read MSDS’s to know the specic hazards of the uids you are using.
• Store hazardous uid in approved containers, and dispose of it according to applicable
guidelines.
• Always wear impervious gloves when spraying or cleaning equipment.
3GC-1387H
Warnings
WARNING
PRESSURIZED ALUMINUM PARTS HAZARD
Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or fluids
WARNING
SKIN INJECTION HAZARD - Basic
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look like just
a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Do not spray without tip guard and trigger guard installed.
WARNING
SKIN INJECTION HAZARD
High-pressure uid from gun, hose leaks, or ruptured components will pierce skin. This may look
like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical
treatment.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the dispense outlet.
• Do not stop or deect leaks with your hand, body, glove, or rag.
• Engage trigger lock when not spraying.
• Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning,
checking, or servicing equipment.
MOVING PARTS HAZARD
Moving parts can pinch or amputate ngers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurized equipment can start without warning. Before checking, moving, or servicing
equipment, follow the Pressure Relief Procedure in this manual. Disconnect power or air
supply.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the inuence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Data in all equipment manuals.
• Use uids and solvents that are compatible with equipment wetted parts. See Technical Data
in all equipment manuals. Read uid and solvent manufacturer’s warnings. For complete
information about your material, request MSDS forms from distributor or retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from trafc areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
PRESSURIZED ALUMINUM PARTS HAZARD
Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or
uids containing such solvents in pressurized aluminum equipment. Such use can cause serious
chemical reaction and equipment rupture, and result in death, serious injury, and property damage.
4 GC-1387H
Important Safety Information
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
Methyl Ethyl Ketone Peroxide (MEKP)
MEKP is among the more hazardous materials
found in commercial channels. Proper handling
of the “unstable (reactive)” chemicals presents a
denite challenge to the plastics industry. The
highly reactive property which makes MEKP
valuable to the plastics industry in producing the
curing reaction of polyester resins and gel-coats
also produces the hazards which require great care
and caution in its storage, transportation, handling,
processing and disposal.
Workers must be thoroughly informed of the hazards
that may result from improper handling of MEKP,
especially in regards to contamination and heat.
They must be thoroughly instructed regarding the
proper action to be taken in the storage, use and
disposal of MEKP and other hazardous materials
used in the laminating operation.
MEKP is ammable and potentially explosive,
as well as potentially damaging to the eyes and
skin.
Read material manufacturer’s warnings and
material MSDS to know specic hazards and
precautions related to MEKP.
Contaminated MEKP can become explosive.
Prevent contamination of MEKP with other materi-
als, which includes, but is not limited to polyester
overspray, polymerization accelerators and promot-
ers, and non-stainless metals. Even small amounts
of contaminates can make MEKP explosive. This re-
action may start slowly, and gradually build-up heat,
which can accelerate until re or an explosion result.
This process can take from seconds to days.
Heat applied to MEKP, or heat build-up from con-
tamination reactions can cause it to reach what is
called its Self-Accelerating Decompisition Tempera-
ture (SADT), which can cause re or explosion.
Spills should be promptly removed, so no residues
remain. Spillage can heat up to the point of self-
ignition. Dispose in accordance with manufacture’s
recommendation.
Store MEKP in a cool, dry and well-ventilated area
in the original containers away from direct sunlight
and away from other chemicals. It is strongly recommended that the storage temperature remain below
86° F (30° C). Heat will increase the potential for ex-
plosive decomposition. Refer to NFPA 432.
Keep MEKP away from heat, sparks and open
ames.
Current catalysts are premixed and do not require
any diluents. GlasCraft strongly recommends that diluents not be used. Diluants add to the possibility of contaminates entering the catalyst system. Never dilute
MEKP with acetone or any solvent since this can pro-
duce an extremely shock-sensitive compound which
can explode.
Use only original equipment or equivalent parts
from GlasCraft in the catalyst system (i.e.: hoses, t-
tings, etc.) because a hazardous chemical reaction
may result between substituted parts and MEKP.
To prevent contact with MEKP, appropriate personal
protective equipment, including chemically impermeable gloves, boots, aprons and goggles are required
for everyone in the work area.
Polyester Resins and Gel-Coats
Spraying materials containing polyester resin and
gel-coats creates potentially harmful mist, vapors and
atomized particulates. Prevent inhalation by providing
sufcient ventilation and the use of respirators in the
work area.
Read the material manufacturer’s warnings and ma-
terial MSDS to know specic hazards and precautions
related to polyester resins and gel-coats.
To prevent contact with polyester resins and gelcoats, appropriate personal protective equipment,
including chemically impermeable gloves, boots,
aprons and goggles are required for everyone in the
work area.
Spraying and Lamination Operations
Remove all accumulations of overspray, FRP sand-
ings, etc. from the building as they occur. If this waste
is allowed to build up, spillage of catalyst is more likely
to start a re.
If cleaning solvents are required, read material
manufacture’s warnings and material MSDS to know
specic hazards and precautions. (GlasCraft recom-
mends that clean-up solvents be nonammable.)
GlasCraft recommends that you consult OSHA
Sections 1910.94, 1910.106, 1910.107 and NFPA
No. 33, Chapter 16,17, and NFPA No. 91 for further
guidance.
5GC-1387H
Grounding
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
This equipment needs to be grounded.
Ground the dispense gun through connection to a
GlasCraft approved grounded uid supply hose.
Check your local electrical code and related manuals
for detailed grounding instructions of all equipment in
the work area.
A grounding wire and clamp are provided,
assembly p/n 17440-00 with all FRP equipment.
6 GC-1387H
Set-Up
Hose Attachment
1. Push in and rotate the trigger lock to stop the trigger
from being activated.
2. Attach the (black p/n 21694-25) material hose to
the material inlet tting on the back of the gun.
5. Attach the (Clear) trigger air tubing to the
trigger air inlet tting on the back of the gun.
6. If the optional berglass roving chopper is being used,
attach the “red” chopper air line to the chopper air
inlet tting on the back of the gun.
3. Attach the (yellow p/n 236) solvent line to the solvent
inlet tting on the back of the gun.
4. Attach the (stainless steel p/n 20190-00) catalyst
hose to the catalyst inlet tting on the back of the
gun.
7. Mixing element assembly
A - Insert mixing element,
p/n: 20634-01, straight
into the gun front housing,
p/n: 23760-00
B - Place retaining nut, p/n: 23002-00
along with spray tip, p/n: 23005-XX
and spray tip spacer, p/n: 23046-00
onto gun housing.
7GC-1387H
Set-Up
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
Overnight Shut Down Procedure
The following steps should be followed for overnight
shutdown:
1. The yellow air valve located where the air
enters the machine should be pushed to
the “OFF” (closed) position. To do this simply
push on the lever protruding out the side of
the valve. This will also cause all the system
air to bleed out of the system in a matter of a
few seconds thus making the system
incapable of operating.
Step 2 is a precautionary step and should be
followed whenever the emergency stop valve is
activated to the stop mode. Failure to do so will
damage regulators and components when
reactivating to the ON position.
2. Turn all system regulators to OFF (counter clockwise) position.
Verify that the Catalyst Pressure Relief Line and
the Resin Return Line are secured before relieving
catalyst and resin uid pressure.
3. Catalyst pressure in the Slave Pump can be
eliminated by rotating the yellow valve handle
on the Slave Pump 90 degrees to the “ON”
position.
The “ON” position the valve handle is parallel
(in line) with the valve body .
The “OFF” position the valve handle is
perpendicular (across) the valve body.
4. Resin pressure can be eliminated by rotating
the yellow handled valve on the bottom of
the uid lter 90 degrees. Place a container
under the bottom of the valve to catch any
resin that is ejected from the valve.
8 GC-1387H
Parts
23750-00 Formula Dispense Gun
Part
Number
23750-00 Formula Dispense Gun
23005-J5 Standard Spray Tip
Description
Repair Kits
Part
Number
23792-00 GUN AIR KIT
23793-00 GUN SEAL KIT
23732-00 GUN FLUID VALVE KIT
Description
9GC-1387H
Parts
23750-00 Formula Dispense Gun
10 GC-1387H
Parts
23750-00 Formula Dispense Gun
23721-04
11GC-1387H
Parts
23750-00 Formula Dispense Gun
Part Description Qty
13867-05 O-RING,EPR,2-008 1
13867-07 O-RING,EPR,2-010 1
13867-08 O-RING,EPR,2-011 2
13867-09 O-RING,EPR,2-012 1
15845-01 TOOL,DRIVER,BALL,5/32 1
18353-12C SCREW,SHDC,SS,.138-32X .375 2
1880-00 FITTING,HOSE 2
20514-00 FITTING,HOSE 1
20634-01 ELEMENT,MIXING,SPIRAL 1/4 1
20796-00 FITTING,CONNECTOR 1
21044-02 O-RING,O-RING,SILICONE,2-002 1
21491-00 TUBE,PIVOT,CUTTER 1
21614-20F SCREW,SET,CPPT,.375-24X .625 1
222385 TAG,WARNING 1
22904-00 STEM,VALVE,CHECK 1
22908-00 NUT,ROUND,5/32 FLATS,4-40 2
23002-00 NUT,RETAINING 1
23005-J5 TIP,SPRAY,20/50,INDY GUN,SST 1
23016-02 HOUSING,CHECK,VALVE,SOLVNT,INDY2 1
23046-00 SPACER,TIP,SPRAY,INDY-GUN 1
23513-00 BRACKET,MOUNT,ROTATING,CHOPPER 1
23515-00 RESISTOR,CATALYST 1
23518-00 VALVE,BALL,2-WAY,1/8NPTF BR 1
23520-00 FITTING,CATALYST,INDY 2 1
23524-01 SPRING,COMPRESSION,13.28RATE 2
23526-01 WASHER,NYLON,.625 OD,.441 ID 1
23528-01 STEM,VALVE,CHECK,SOLVENT 1
23529-00 HOUSING,VALVE,CHECK,CATALYST 1
23540-00 HOUSING,BODY,VALVE,CHECK,CATALYST 1
23721-04
23743-00 VALVE,FLUID,FORMULA GUN 2
23751-00 HANDLE,MACHINED,FORMULA GUN 1
23753-00 HOUSING,BODY,FORMULA GUN 1
23754-00 PISTON,AIR,15/16 1
23755-00 PISTON,AIR,3/4” 1
23756-00 COVER,GEAR,FORMULA GUN 1
23757-00 ADAPTER,HANDLE,FORMULA GUN 1
23758-00 CAP,REAR,FORMULA GUN 1
23759-00 HEAD,MIXING,FORMULA GUN 1
23760-00 MIXER,FRONT,FORMULA,.247DIA. 1
23761-00 SPACER,CYLINDER 1
23763-00 SEAL,FORMULA GUN 2
23764-00 NUT,PACKING,FORMULA GUN 2
WASHER,PTFE,.228ID
7
Part Description Qty
23765-00 BRACKET,MOUNT,CHOPPER,FORMULA GUN 1
23766-00 BRACKET,MOUNT,FRONT,CHOP,FORMULA G 1
23767-00 PISTON,CHOPPER,FORMULA GUN 1
23768-01 BEARING,FORUMLA GUN 4
23769-00 ADAPTER,5/8-18 X 1/8-27 BR 1
23770-00 INSERT,SOLVENT 1
23771-00 ADAPTER,SLEEVE,SOLVENT 1
23772-00 STOP,TRIGGER,FORMULA GUN 1
23773-00 INSERT,TRIGGER STOP 1
23774-00 CAP,TRIGGER STOP 1
23775-01 GUN,ASSY,GEAR,FORMULA GUN 2
23776-00 VALVE,BALL,GUN 1
23778-00 SPRING,COMPRESSION,.240 OD 1
23779-00 BALL,STEEL,3/8 OD 1
23780-00 SPRING,TAPERED,.31 X .25 OD 1
23782-00 KIT,SEAL,FORMULA GUN 1
23783-00 KIT,AIR,FORMULA GUN 1
23784-00 RING,RETAINING,INTER,7/8 BORE 1
23964-00 GUARD,PROBLER 2/FORMULA 1
23965-00 PISTON,TRIGGER,PROBLER 2 1
2594-06 PIN,ROLL,1/8 DIA X 5/16 LG 1
7486-05 WASHER,FLAT,FENDER,1/4 1
7554-03
7554-05
7554-09
7554-10
7554-14
7554-16
7554-21
7554-27
7554-28
7716-06C SCREW,SET,FLPT,#8,3/16,SST 5
7958-16C SCREW,HXHD,CS,.250-20X .500ZP 1
8115-02 FITTING,PIPE,NIPPLE,HEX,1/8X1/8 1
8212-12F SCREW,SHDC,SS,.190-32X .375 3
8212-20F SCREW,SHDC,SS,.190-32X .625 5
8212-32F SCREW,SHDC,SS,.190-32X1.000 4
8301-12C SCREW,SHDC,SS,.164-32X .375SST 1
9869-19 SCREW,SHOULDER,1/4X10-24 STL 1
CC-116 O-RING,O-RING,SILICONE,2-012 2
CJ-137 O-RING,O-RING,SILICONE,2-008 1
PG-18 TRIGGER,PROBLER 1
O-RING,O-RING,FKM,2-006
O-RING,O-RING,FKM,2-008
O-RING,O-RING,FKM,2-012
O-RING,O-RING,FKM,2-013
O-RING,O-RING,FKM,2-018
O-RING,O-RING,FKM,2-107
O-RING,O-RING,FKM,2-113
O-RING,O-RING,FKM,2-109
O-RING,O-RING,FKM,2-116
5
1
1
1
2
3
1
1
1
12 GC-1387H
Notes
13GC-1387H
Pressure Relief Procedure
To relieve uid and air pressures:
1. Push down Yellow slide valve, P/N 21402-00 to
bleed off air to system.
2. Open P/N 21228-00 on catalyst pump to recirculation
position.
4. Verify the Trigger lock is engaged.
Daily Maintenance
It is recommended that the following service be per-
formed on a daily basis.
1. Remove gear cover, p/n: 23756-00, and inspect valves
to see if there is any leakage on the top or bottom
side of the valves. If there is leakage, with pressure
relieved, tighten packing nut, p/n: 23764-00 1/8 to 1/4
turn until leak stops. Verify that there is no leakage.
3. Open P/N 21192-00 on bottom of material pump.
2. Maintain a reasonable stock level of “wear” items
such as Packings, Seals and O-Rings
3. If dispense gun is leak tested, be sure to dry gun
thoroughly.
4. Never leave dispense gun immersed in any liquid.
14 GC-1387H
Maintenance
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
Parts Replacement Procedure
Formula Gun
Before performing maintenance on the dispense gun,
follow Pressure Relief Procedure.
Notice
Due to the different o-ring materials and lubricants used
in the dispense guns, never submerge or soak any dispense gun in any type of solvent. Submerging or soak-
ing any dispense gun will immediately void the gun warranty.
1. Read each procedure entirely before beginning
and refer to the illustration views as needed.
2. Flush and clean all passages as they become
accessible.
3. Clean all parts before assembly.
4. Replace all O-Rings, Valves and Seals with new
parts from the appropriate kit.
5. Inspect all parts for wear or damage and replace
as required with new GENUINE GlasCraft
REPLACEMENT PARTS from your authorized
GlasCraft Distributor.
6. Inspect all threads for wear or damage and
replace as required.
7. Tighten all threaded parts securely, but not
excessively, upon assembly.
8. O-rings can fail if subjected to any of the
following conditions.
a. Swelling - coming in contact with
solvent or oil from compressor.
b. Cut - sharp, unlubricated edge in gun
head or handle.
c. Sticky - contaminated with oil, water,
solvent, catalyst, resin or gel-coat.
d. Chafng - dry sliding surfaces (needs
lubrication).
9. Lightly lubricate all O-Rings with petroleum jelly.
10. Check all springs for resilience. They should
return quickly to their original (new) length.
11. Clean the exterior of the Gun and Hoses with
an appropriate, clean solvent and cloth or brush.
Hose Removal
1. Relieve pressure (See page 14).
2. Remove resin Hose with an 11/16” wrench.
(Hold delivery tube with an 11/16” wrench.)
3. Remove catalyst Hose with a 9/16” wrench.
(Hold delivery tube with a 9/16” wrench.)
4. Remove solvent hose with a 5/8” wrench.
(Hold delivery tube with a 9/16” wrench)
5. Remove trigger air tubing by pushing in on
trigger air tting and pulling the tubing out.
6. If optional berglass chopper is being used,
remove the chopper air hose with a 11/16”
wrench. (Hold the air hose inlet tting with
a 9/16” wrench)
Tape a clean polyethylene bag over the end of each
Hose to prevent spillage and to keep clean.
Gun Service
Dispense Gun Component Service
and Assembly Procedures
If Seal, P/N 23763-00 and Packing Disks, P/N 23721-04
are removed from the Gun Body GlasCraft recommends
that these parts always be replaced with NEW seals and
packing disks.
15GC-1387H
Maintenance
O-Ring Chart
ORANGE
BLACK
16 GC-1387H
Maintenance
Material Valve Assembly Procedure
1. Ensure bores are clean before building material
valves.
2. Insert bearing, p/n: 23768-01 into gun body.
3. Insert seal, p/n: 23763-00 into gun body. (Ensure
holes in seal are aligned with holes in gun body.)
4. Place PTFE washers, p/n: 23721-04 on top and
bottom of uid valve, p/n: 23743-00.
5. Lubricate outside of uid valve, p/n: 23743-00 with a
generous amount of Aqua lube (21266-00) and insert
into seal with holes aligned with holes in the gun body.
6. Insert bearing, p/n: 23768-01 into gun body.
7. a. Use 3/8 in. twelve point socket to rst snug P/N
23764-00 to hand tight, continue ½ turn past
snug. Torque reading 20 ft lbs / 88 Newton.
b. Loosen ¼ turn and return until snug, continue ¼
turn past snug. Torque reading 25 ft lbs / 110 Newton.
c. Loosen ¼ turn and return until snug, continues 1/8
turn past snug. Torque reading 30 ft lbs/ 133 Newton.
8. With piston, p/n: 23755-00 pushed back (in the “on”
position), Place packing disks, p/n: 23721-04 followed
by the gears, p/n: 23775-01 and tighten set screw.
9. Activate air and retract gun trigger. Loosen P/N
23764-00 until valve rotate, alternate adjustment if both
valves were adjusted.
17GC-1387H
Accessories
Dispense Tip Reference Chart
PART
NUMBER
23005- C4 0.040 7 16.5 5.4 10.02
C5 0.050 8.5 15.5 6.36 12.23
C6 0.060 7 17 7.31 11.01
C7 0.070 7 13 8.53 10.58
C8 0.080 10 12.5 10.28 13.03
C9 0.090 7.5 10 11.49 12.36
E4 0.040 6 21 4.01 9.16
E5 0.050 11 21 5.71 10.23
E6 0.060 6.5 18.5 5.48 11.48
E7 0.070 7.5 15 7.96 10.58
E8 0.080 6 15.5 8.61 12.03
E9 0.090 7.5 15 9.61 12.36
G4 0.040 6 24 4.01 9.16
G5 0.050 10.5 32 4.31 10.23
G6 0.060 8.5 24 5.48 11.48
G7 0.070 6.5 25.5 6.43 10.58
G8 0.080 10 22 8.61 12.03
G9 0.090 7 16 8.53 12.36
J4 0.040 7 36.5 4.01 9.16
J5 0.050 7 30.5 4.31 10.23
J6 0.060 10 28 5.48 11.48
J7 0.070 7.5 26 6.43 10.58
J8 0.080 10 24 8.61 12.03
J9 0.090 11 20 8.53 10.58
K3 0.040 N/A N/A N/A N/A
K4 0.040 9.5 38 4.01 9.16
K5 0.050 12 34 4.31 10.23
K6 0.060 16 34 5.48 11.48
K7 0.070 13 30 6.43 10.58
K8 0.080 8 28 6.21 12.03
K9 0.090 11 25 7.88 12.36
M4 0.040 11 61 4.01 9.16
M5 0.050 13 38 4.31 10.23
M6 0.060 9 38 4.33 11.48
P4 0.040 N/A N/A N/A N/A
ORIFICE Min.
Width (in.)
Max.
Width (in.)
Min.
Output (lbs.)
Max
Output (lbs.)
18 GC-1387H
Accessories
Dispense Tip Reference Chart
PART
NUMBER
23005- TC6 0.060
TC7 0.070
TC8 0.080
TE7 0.070
TG7 0.070
*INDICATES THAT THESE TIPS ARE MADE WITH HARDEN STEEL
ORIFICE
*
*
*
*
*
PART
NUMBER
23047- J1 .012
J2 .014
J3 .022
M1 .012
M2 .014
M3 .022
N1 .012
N2 .014
N3 .022
P1 .012
P2 .014
P3 .022
ORIFICE
19GC-1387H
Accessories
Dispense Tip Reference Chart
PART
NUMBER
LPA2-147-1525 0.015
1540 0.015
1550 0.015
1565 0.015
1825 0.018
1840 0.018
1850 0.018
1865 0.018
2125 0.021
2140 0.021
2150 0.021
2165 0.021
2325 0.023
2340 0.023
2350 0.023
2365 0.023
2625 0.026
2640 0.026
2650 0.026
2665 0.026
ORIFICE
PART
NUMBER
3125 0.031
3140 0.031
3150 0.031
3165 0.031
3625 0.036
3640 0.036
3650 0.036
3840 0.038
3850 0.038
4325 0.043
4340 0.043
4350 0.043
4365 0.043
5225 0.052
5240 0.052
5250 0.052
5265 0.052
PART
NUMBER
LPA2-147-6225 0.062
7250 0.072
ORIFICE
ORIFICE
6240 0.062
6250 0.062
6265 0.062
7240 0.072
7840 0.078
20 GC-1387H
Accessories
Small Diameter Airless Or Non Atomized Material Tip
23002-00
22274-00
LPA 2-147-XXXX
23047-XX
(See page 19&20)
OR
20333-00
23760-00
Part
Number
20333-00 GASKET
22274-00 TIP SPACER
23002-00 RETAINING NUT
23047-XX SPRAY TIP
23760-00 GUN FRONT HOUSING
Description
21GC-1387H
Accessories
Internal Mix Gel - Screw-On AAC Gun Head Kit (23750-00)
22 GC-1387H
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
Accessories
Internal Mix Gel - Screw-On AAC Gun Head Kit (23570-00)
23570-00 ASSY.
Part
Number
11021-23 PLUG
21464-00 ELBOW FITTING
23565-00 AIR ASSIST RING
23566-00 RETAINING RING
23571-00 AIR ASSIST NOZZLE BODY
LPA2-147-2150 SPRAY TIP
REGULATOR ASSY.
Part
Number
3165 BALL VALVE
4342-04 ELBOW FITTING
7884-07 ELBOW FITTING
8115-03 NIPPLE FITTING
9704-53 BLACK AAC TUBING
18199-02 REGULATOR
18318-02 GAUGE
20182-00 AAC DECAL
Description
Description
The following is not included in this kit, but required:
(1) 7716-06C Set screw
XX-9704-53 Black AAC Tubing (XX= YOU MUST SPECIFY TUBING LENGTH BY FEET)
EXAMPLE: If standard machine hose length is 25ft, it is recomended to order 28ft. of 9704-53.
Remove: 23765-00 Chopper mounting assembly and place 7716-06C set screw in middle tapped
hole - (USE THREAD LOCKER MEDIUM STRENGTH TO KEEP FROM LEAKING)
Reason: To remove extra weight and bulk from the gun, for gelcoat application.
Add regulator assembly shown on page 23 to air manifold.
Reason: This will allow user to regulate AAC air to the gun.
23GC-1387H
Isocyanate Conditions
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO lube pump reservoir (if installed) filled
with Graco Throat Seal Liquid (TSL), Part 206995.
The lubricant creates a barrier between the ISO and
the atmosphere.
• Use moisture-proof hoses specifically designed for
ISO, such as those supplied with your system.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Never use solvent on one side if it has been contam-
inated from the other side.
• Always lubricate threaded parts with ISO pump oil
or grease when reassembling.
Keep Components A and
B Separate
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure, especially
if agitated. To reduce frothing, minimize preheating in a
circulation system.
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized partic-
ulates.
Read material manufacturer’s warnings and material
MSDS to know specific hazards and precautions
related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufficient ventila-
tion in the work area. If sufficient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate per-
sonal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
The amount of film formation and rate of crystalli-
zation varies depending on the blend of ISO, the
NOTICE
To prevent cross-contamination of the equipment’s
wetted parts, never interchange component A (isocy-
anate) and component B (resin) parts.
Accessories
Internal Mix Gel - Bolt-On AAC Gun Head Kit (23560-00)
Part
Number
103C02 SET SCREW
13867-03 O-RING
13867-64 O-RING
21464-00 ELBOW FITTING
21523-90 SPIRAL MIXING ELEMENT
23561-00 AIR ASSIST ADAPTER
The following is not included in this kit, but required:
(1) 7834-07 Elbow Fitting (Connection To Air Manifold)
XX-9704-53 Black AAC Tubing (XX= YOU MUST SPECIFY TUBING LENGTH BY FEET)
EXAMPLE: If standard machine hose length is 25ft, it is recomended to order 28ft. of 9704-53.
Description
Part
Number
23562-00 DUAL AIR ASSIST BODY
23563-00 AIR ASSIST NEEDLE
23564-00 AIR ASSIST SEAL
23565-00 AIR ASSIST RING
23566-00 RETAINING RING
23573-00 RING INSERT
23721-01 WASHER
8212-16F SCREW
8212-48F SCREW
LPA2-147-XXXX SPRAY TIP
Description
Required: qty. (1) 7716-06C set screw.
Remove: 23765-00 Chopper mounting assembly and place 7716-06C set screw in middle tapped
hole - (USE THREAD LOCKER MEDIUM STRENGTH TO KEEP FROM LEAKING)
Reason: To remove extra weight and bulk from the gun, for gelcoat application.
Delete: qty. (4) 8212-48F shoulder screw, Keep and use existing 8212-32F shoulder screws.
24 GC-1387H
Accessories
High Volume / High Filled Resin
Part
Number
20310-90 3/8” MIXING ELEMENT
23760-01 3/8” FRONT MIXER HOUSING
Description
25GC-1387H
Technical Data
Category Data
Maximum Fluid Working Pressure 2000 psi (14 MPa, 138 bar)
Maximum Air Inlet Pressure 100 psi (0.7 MPa, 7 bar)
Typical Flow Rate of Pattern Guns Dependent of spray tip (See page 18)
Maximum Fluid temperature 100° F (38° C)
Trigger Air 1/4in. Tube
Air Inlet Size (Chopper) 1/4-18 NPS Male
A Component (Catalyst) Inlet Size 1/4 in. Tube
B Component (Resin) Inlet Size 1/4-18 NPS Male
Solvent Flush 1/4-18 NPS Male
Sound Pressure 75.8 dB(A)
Sound Power, measured per ISO 9614-2 60.2 dB(A)
Dimensions 9.24 L X 4.12 W X 8.34 H (234.77 X 104.70 X 211.79 mm)
Weight 3.4 Lbs.
Wetted Parts
Catalyst- Chemically coated aluminum, stainless steel,
chemically resistant o-rings
Resin- Carbon steel, carbide, chemically resistant o-rings.
26 GC-1387H
Notes
27GC-1387H
Graco Ohio Standard Warranty
Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in
material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty
published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by
Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written
recommendations.
This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty instal-
lation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco
component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of Graco equipment with structures,
accessories, equipment or materials not supplied by Graco, or the improper design, manufacture, installation, operation or maintenance of
structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for verification of
the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The equipment will be returned
to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect in material or workmanship, repairs
will be made at a reasonable charge, which charges may include the costs of parts, labor, and transportation.
THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIM-
ITED TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other remedy
(including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any other incidental
or consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the date of sale.
GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, IN CONNECTION WITH ACCESSORIES, EQUIPMENT, MATERIALS OR COMPONENTS SOLD BUT NOT MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, switches, hose, etc.), are subject to the warranty,
if any, of their manufacturer. Graco will provide purchaser with reasonable assistance in making any claim for breach of these warranties.
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment hereunder,
or the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract, breach of warranty, the
negligence of Graco, or otherwise.
FOR GRACO CANADA CUSTOMERS
The Parties acknowledge that they have required that the present document, as well as all documents, notices and legal proceedings entered
into, given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English. Les parties reconnaissent avoir convenu
que la rédaction du présente document sera en Anglais, ainsi que tous documents, avis et procédures judiciaires exécutés, donnés ou intentés,
à la suite de ou en rapport, directement ou indirectement, avec les procédures concernées.
Graco Ohio Information
TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor.
Toll Free: 1-800-746-1334 Fax: 330-966-3006
For the latest information about Graco products, visit www.graco.com.
All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Original instructions. This manual contains English. MM GC-1387
