Graco 406699C User Manual

GENUINE GRACO PARTS AND ACCESSORIES

7 Gallon Hopper

406699C

Installation Kits

Kit 256260 (Green Hopper)
Kit 24N011 (Blue Hopper)

Important Safety Instructions

Read all warnings and instructions in manual

312359. Save those instructions.

Ref. Part Description Qty.

1† 256252 BRACKET, hopper, back-

mount, upper
2 121488 SCREW, hex hd, flanged 2
3 256251 BRACKET, hopper, 7 gal-

lon
4 112395 SCREW, cap, flng hd 2
6 122198 VALVE, ball 1
7 112580 SWIVEL, union, 90° 1
8 234097 HOPPER, fluid, green

(256260 only)

234017 HOPPER, fluid, blue

(24N011 only)
8b 124450 CLAMP 1
8c C20490 FITTING 1

† Only used to mount hopper (8) on back of

frame.

A Parts for back mounted hoppers.
B Parts for side mounted hoppers.

1

1

1

1

1

A

2

4

3

2

7

6

8c

8b

8

Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441

406699, Revision C 02/2012
Copyright 2009, Graco Inc. is registered to ISO 9001

B

4

3

EN
