Instructions - Parts List

High-Flo

Designed for low pressure, medium volume circulation of finishing materials. For professional use only.

Important Safety Instructions

Read all warnings and instructions in your High-Flo Pump manual 311211. Save these instructions.

See page 2 for Table of Contents and page 2 for

List of Models and Maximum Working Pressures.

Lowers

311690M

ENG

Patent Pending

TI8732a

TI8733a

Models

Contents

Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

750cc Lowers . . . . . . . . . . . . . . . . . . . . . . . . 2

1000cc Lowers . . . . . . . . . . . . . . . . . . . . . . . 2

1500cc Lowers . . . . . . . . . . . . . . . . . . . . . . . 3

2000cc Lowers . . . . . . . . . . . . . . . . . . . . . . . 3

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Pressure Relief Procedure . . . . . . . . . . . . . . . . . 6

Disconnect the Lower . . . . . . . . . . . . . . . . . . . . . 7

Reconnect the Lower . . . . . . . . . . . . . . . . . . . . . 7

Reassemble the Coupling Rod and Tie Rods

to the Motor . . . . . . . . . . . . . . . . . . . . . . . . . 8

Replace the Throat Packings Without

Disconnecting the Lower . . . . . . . . . . . . . . . 8

Repair Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Lower Disassembly . . . . . . . . . . . . . . . . . . . . . . . 9

Clean and Inspect Parts . . . . . . . . . . . . . . . . . . 10

Lower Reassembly . . . . . . . . . . . . . . . . . . . . . . 10

Models

Lower Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Pump Seal Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Pump Seal Repair Kit 289548 . . . . . . . . . . . 20

Pump PTFE Seal Conversion Kit 289549 . . 20

Pump Seal Repair Kit 277360 . . . . . . . . . . . 20

Pump PTFE Seal Conversion Kit 277361 . . 20

Pump Seal Repair Kit 277362 . . . . . . . . . . . 20

Pump PTFE Seal Conversion Kit 277363 . . 20

Pump Seal Repair Kit 277358 . . . . . . . . . . . 20

Pump PTFE Seal Conversion Kit 277359 . . 20

Throat Packing Kits . . . . . . . . . . . . . . . . . . . . . . . . 21

Throat Packing Kit 239868 . . . . . . . . . . . . . 21

Throat Packing Kit 239872 . . . . . . . . . . . . . 21

Throat Packing Kit 239866 . . . . . . . . . . . . . 21

Throat Packing Kit 277356 . . . . . . . . . . . . . 21

Throat Packing Kit 277357 . . . . . . . . . . . . . 21

Throat Packing Kit 24C405 . . . . . . . . . . . . . 21

Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 22

Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 22

750cc Lowers

Maximum Pump

Model

No. Series Material Seat

289366 A SST Tungsten

Carbide

Size

Working Pressure

(cc)

750 500 (3.4, 34) Chromex/Chrome Inlet/Outlet 1-1/2 in. tri-clamp 15

psi (MPa, bar)

Rod/Cylinder

Material Connection Style

1000cc Lowers

Maximum Pump

Model

No. Series Material Seat

253033 A SST Tungsten

Carbide

24E783 A SST SST 1000 400 (2.8, 28) Chromex/Chrome Inlet: 1-1/2 in. npt

253061 A CST Tungsten

Carbide

253398 A SST Tungsten

Carbide

253423 A SST Tungsten

Carbide

253520 A SST Tungsten

Carbide

253523 A SST Tungsten

Carbide

253568 A SST Tungsten

Carbide

Size

Working Pressure

(cc)

1000 400 (2.8, 28) Chromex/Chrome Inlet: 1-1/2 in. npt

1000 400 (2.8, 28) Chromex/Nitride Inlet: 1-1/2 in. npt

1000 400 (2.8, 28) Chromex/MaxLife Inlet: 1-1/2 in. bspp

1000 400 (2.8, 28) Chromex/Chrome Inlet: 1-1/2 in. bspp

1000 400 (2.8, 28) Chromex/Chrome Inlet/Outlet 1-1/2 in. tri-clamp 16

1000 400 (2.8, 28) Chromex/MaxLife Inlet/Outlet 1-1/2 in. tri-clamp 16

1000 400 (2.8, 28) Chromex/MaxLife Inlet: 1-1/2 in. npt

psi (MPa, bar)

Rod/Cylinder

Material Connection Style

Outlet: 1 in. npt

Outlet: 1-1/4 in. bspp

Outlet: 1 in. npt

Parts Page

2 311690M

1500cc Lowers

Maximum Pump

Model

No. Series Material Seat

253034 A SST Tungsten

Carbide

24E784 A SST SST 1500 460 (3.2, 32) Chromex/Chrome Inlet: 1-1/2 in. npt

253062 A CST Tungsten

Carbide

253085 A SST Tungsten

Carbide

253397 A SST Tungsten

Carbide

253521 A SST Tungsten

Carbide

253524 A SST Tungsten

Carbide

253569 A SST Tungsten

Carbide

Size

Working Pressure

(cc)

1500 460 (3.2, 32) Chromex/Chrome Inlet: 1-1/2 in. npt

1500 460 (3.2, 32) Chromex/Nitride Inlet: 1-1/2 in. npt

1500 460 (3.2, 32) Chromex/Chrome Inlet: 1-1/2 in. bspp

1500 460 (3.2, 32) Chromex/MaxLife Inlet: 1-1/2 in. bspp

1500 460 (3.2, 32) Chromex/Chrome Inlet/Outlet 1-1/2 in. tri-clamp 17

1500 460 (3.2, 32) Chromex/MaxLife Inlet/Outlet 1-1/2 in. tri-clamp 17

1500 460 (3.2, 32) Chromex/MaxLife Inlet: 1-1/2 in. npt

psi (MPa, bar)

Rod/Cylinder

Material Connection Style

Outlet: 1 in. npt

Outlet: 1-1/4 in. bspp

Outlet: 1 in. npt

Models

Parts Page

2000cc Lowers

Maximum Pump

Model

No. Series Material Seat

253035 A SST Tungsten

Carbide

24E785 A SST SST 2000 460 (3.2, 32) Chromex/Chrome Inlet: 1-1/2 in. npt

253063 A SST Tungsten

Carbide

253086 A SST Tungsten

Carbide

253396 A SST Tungsten

Carbide

253522 A SST Tungsten

Carbide

253525 A SST Tungsten

Carbide

253570 A SST Tungsten

Carbide

Wetted Parts: Carbon Steel, Stainless Steel, Leather, PTFE,

Ultra High Molecular Weight Polyethylene (UHMWPE), Tungsten Carbide

Size

Working Pressure

(cc)

2000 460 (3.2, 32) Chromex/Chrome Inlet: 1-1/2 in. npt

2000 460 (3.2, 32) Chromex/Chrome Inlet: 1-1/2 in. bspp

2000 460 (3.2, 32) Chromex/MaxLife Inlet: 1-1/2 in. bspp

2000 460 (3.2, 32) Chromex/Chrome Inlet/Outlet 1-1/2 in. tri-clamp 18

2000 460 (3.2, 32) Chromex/MaxLife Inlet/Outlet 1-1/2 in. tri-clamp 18

2000 460 (3.2, 32) Chromex/MaxLife Inlet: 1-1/2 in. npt

psi (MPa, bar)

Rod/Cylinder

Material Connection Style

Outlet: 1 in. npt

Outlet: 1-1/4 in. bspp

Outlet: 1 in. npt

Parts Page

311690M 3

Warnings

The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.

WARNING

FIRE AND EXPLOSION HAZARD

Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent fire and explosion:

• Use equipment only in well ventilated area.

• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop cloths (potential static arc).

• Keep work area free of debris, including solvent, rags and gasoline.

• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes are present.

• Ground all equipment in the work area. See Grounding instructions.

• Use only grounded hoses.

• Hold gun firmly to side of grounded pail when triggering into pail.

• If there is static sparking or you feel a shock, stop operation immediately. Do not use equipment until you identify and correct the problem.

• Keep a working fire extinguisher in the work area.

PRESSURIZED EQUIPMENT HAZARD

Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the eyes or on skin and cause serious injury.

• Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning, checking, or servicing equipment.

• Tighten all fluid connections before operating the equipment.

• Check hoses, tubes, and couplings daily. Replace worn or damaged parts immediately.

EQUIPMENT MISUSE HAZARD

Misuse can cause death or serious injury.

• Do not operate the unit when fatigued or under the influence of drugs or alcohol.

• Do not exceed the maximum working pressure or temperature rating of the lowest rated system component. See Technical Data in all equipment manuals.

• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information about your material, request MSDS forms from distributor or retailer.

• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manufacturer’s replacement parts only.

• Do not alter or modify equipment.

• Use equipment only for its intended purpose. Call your distributor for information.

• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.

• Do not kink or over bend hoses or use hoses to pull equipment.

• Keep children and animals away from work area.

• Comply with all applicable safety regulations.

4 311690M

Warnings

WARNING

MOVING PARTS HAZARD

Moving parts can pinch or amputate fingers and other body parts.

• Keep clear of moving parts.

• Do not operate equipment with protective guards or covers removed.

• Pressurized equipment can start without warning. Before checking, moving, or servicing equipment,

follow the Pressure Relief Procedure in this manual. Disconnect power or air supply.

TOXIC FLUID OR FUMES HAZARD

Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or swallowed.

• Read MSDS’s to know the specific hazards of the fluids you are using.

• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.

• Always wear impervious gloves when spraying or cleaning equipment.

PERSONAL PROTECTIVE EQUIPMENT

You must wear appropriate protective equipment when operating, servicing, or when in the operating area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic fumes, burns, and hearing loss. This equipment includes but is not limited to:

• Protective eyewear

• Clothing and respirator as recommended by the fluid and solvent manufacturer

•Gloves

• Hearing protection

311690M 5

Repair

• To service the pump assembly, see manual

311211.

• To service the air motor, see manual 311238.

• To service the hydraulic motor, see manual

308330.

Hydraulic power supply: follow manufacturer’s recommendations.

Surge tank: use a ground wire and clamp.

Spray gun: ground through a connection to a properly

grounded fluid hose and pump.

Fluid supply container: follow local code.

Grounding

The equipment must be grounded. Grounding reduces the risk of static and electric shock by providing an escape wire for the electrical current due to static build up or in the event of a short circuit.

Pump: Use the ground screw (Z) and lockwasher on the motor to attach ground wire 244524 (Y). Tighten the screw securely. Connect the other end of the ground wire to a true earth ground. See F

IG. 1.

Object being sprayed: follow local code.

Solvent pails used when flushing: follow local code.

Use only conductive metal pails, placed on a grounded surface. Do not place the pail on a nonconductive surface, such as paper or cardboard, which interrupts grounding continuity.

To maintain grounding continuity when flushing or relieving pressure: hold metal part of the spray gun

firmly to the side of a grounded metal pail, then trigger the gun.

Pressure Relief Procedure

1. Engage trigger lock.

2. Air-Powered Pumps only: Close the bleed-type master air valve.

Z Y

TI8250a

FIG. 1

Air and fluid hoses: use only electrically conductive

hoses with a maximum of 500 ft. (150 m) combined hose length to ensure grounding continuity. Check the electrical resistance of hoses. If total resistance to ground exceeds 29 megohms, replace hose immediately.

Air compressor: follow manufacturer’s recommendations.

6 311690M

Hydraulic-Powered Pumps only: Close the hydraulic

supply line valve first, then the return line valve.

3. Disengage the trigger lock.

4. Hold a metal part of the gun firmly to a grounded metal pail. Trigger the gun to relieve pressure.

5. Engage the trigger lock.

6. Open all fluid drain valves in the system, having a waste container ready to catch drainage. Leave drain valve(s) open until you are ready to spray again.

7. If you suspect the spray tip or hose is clogged or that pressure has not been fully relieved after following the steps above, VERY SLOWLY loosen tip

Repair

guard retaining nut or hose end coupling to relieve pressure gradually, then loosen completely. Clear

hose or tip obstruction.

CAUTION

Hydraulic-Powered Pumps only: When shutting down the hydraulic system, always shut off the hydraulic supply line shutoff valve first, and then the return line shutoff valve to prevent overpressurizing the motor or its seals. When starting the hydraulic system, open the return line shutoff valve first.

Disconnect the Lower

To disconnect the lower, follow the procedure on this page. See pages 8-11 for procedures to repair lower. To disconnect pump from an electric circulation assembly, EPXXXX, see manual 311594.

In stand or wall-mounted installations, you do not have to remove the entire pump from its mounting.

1. Relieve the pressure, see Pressure Relief Procedure page 6.

3. Insert the collars (G) into the coupling nut (K). Tighten the coupling nut onto the piston rod (H) and torque to 90-100 ft-lb (122-135 N•m).

4. Flush and test the pump before reinstalling it in the system. Connect hoses and flush the pump. While it is pressurized, check for smooth operation and leaks. Adjust or repair as necessary before reinstalling in the system. Reconnect the pump ground wire before operating.

NXT Pump

Shown

Torque to 90-100 ft-lb (122-135 N•m).

Torque to 50-60 ft-lb (68-81 N•m).

Apply anti-seize lubricant.

2. Disconnect the hoses from the lower and plug the ends to prevent fluid contamination.

3. Loosen the coupling nut (K) and remove the collars (G). Remove the coupling nut from the piston rod (H). Unscrew the locknuts (B) from the tie rods (C). Pull the lower (D) off the motor (E). See F F

IG. 3.

IG. 2 and

Reconnect the Lower

If the coupling rod (F) and tie rods (C) have been disassembled from the motor, see Reassemble the Coupling Rod and Tie Rods to the Motor on page 8.

1. Assemble the coupling nut (K) to the piston rod (H).

2. Orient the lower (D) to the motor (E). Position the lower on the tie rods (C). Lubricate the threads of the tie rods. Screw the tie rod locknuts (B) onto the tie rods. Tighten the locknuts and torque to 50-55 ft-lb (68-75 N•m).

TI8394a

FIG. 2

311690M 7

Repair

5. Insert the collars (G) and screw the coupling nut (K) onto the coupling rod (F) and torque to 90-100 ft-lb (122-135 N•m).

Viscount I+ Pump Shown

Torque to 90-100 ft-lb (122-135 N•m).

Torque to 50-55 ft-lb (68-75 N•m).

Apply anti-seize lubricant.

IG. 3

6. Torque the screws holding the adapter plate (J) to

the motor (E) to 15-17 ft-lb (20-23 N•m). Torque the tie rod locknuts (B) to 50-55 ft-lb (68-75 N•m).

Replace the Throat Packings Without Disconnecting the Lower

To replace the throat packings as part of a complete service of the lower, see page 9.

Throat packing kits are available. See page 21 to order. Parts supplied in the throat packing kit are marked with a symbol, for example (19†). For the best results, use all the parts in the kit.

1. Flush the pump, if possible.

TI7674b

2. Stop the pump at the middle of its stroke.

3. Shut off the air or hydraulic supply.

Reassemble the Coupling Rod and Tie Rods to the Motor

Use this procedure only if the coupling rod (F) and tie rods (C) have been disassembled from the motor, to ensure proper alignment of the motor shaft to the piston rod.

1. Loosen, but do not remove, the screws holding the adapter plate (J) to the motor (E) on Viscount I+ pumps. See F

2. Screw the tie rods (C) into the adapter plate (J) and torque to 50-55 ft-lb (68-75 N•m). On Viscount I+ pumps, the tie rods will engage threaded holes in the base of the motor.

3. Fill the cavity in the bottom of the motor shaft with grease. Screw the coupling rod (F) into the motor shaft until the pin holes align. On Viscount I+ pumps, install the pin (A) in the first hole from the end of the coupling.

4. Align the lower (D) with the tie rods (C) and loosely install the tie rod locknuts (B).

IG. 3.

4. Unscrew the coupling nut (K) from the piston rod (H). Allow the nut and collars (G) to rest on the piston rod. See F

IG. 2.

5. Cycle the pump slowly to the bottom of its stroke.

6. Relieve the pressure, see Pressure Relief Procedure, page 6.

7. Lift the motor shaft and remove the coupling nut (K) and collars (G). See F

8. Loosen the packing nut (21). See F

IG. 2 and FIG. 3.

IG. 8.

Keep packing nut installed, but loose.

9. Loosen and remove the throat cartridge (35). Remove the PTFE o-ring (36). See F

IG. 8.

10. Remove the glands (19, 26) and packings (20, 25).

8 311690M

Repair

11. Lubricate the throat packings and glands. Install one male gland (19†), then five v-packings with the lips facing down: one UHMWPE (20†), one leather (25†), UHMWPE, leather, UHMWPE. Install the female gland (26†). Install three v-packings with the lips facing up: UHMWPE, leather, UHMWPE. Install the other male gland (19†). Install the packing nut (21) finger-tight. See F

IG. 8.

Inspect the surface of the piston rod (17). If it is scratched, replace the piston rod.

12. Install the o-ring (36†) on the throat cartridge (35). Apply lubricant to the throat cartridge threads then screw the cartridge into the upper pump housing (1). Torque the throat cartridge to 100 ft-lb (135 N•m).

13. Tighten the packing nut (21) firmly and then turn the nut another 1/4 turn. If you have a torque wrench, tighten the packing nut to 30 ft-lb (40 N•m), then re-tighten to 15-20 ft-lb (20-27 N•m).

14. Screw the coupling nut (K) and collars (G) onto the piston rod (H). Torque to 145-150 ft-lb (197-203 N•m). See F

IG. 2.

15. On Viscount I+ pumps, reinstall the pin (A). If necessary, reconnect the hydraulic supply and move the pump to the middle of its stroke. Install the pin in the first hole from the end of the coupling.

4. Remove the four capscrews (9) and washers (8) from around the outlet manifold (22).

5. Remove the outlet manifold (22), balls (23), seats (24), and gaskets (7).

6. Remove the three cylinder bolts (13) and lockwashers (14). Lift off the outlet housing (16), along with the fluid tubes (3), cylinder (1), and piston assembly (17, 10, 11, 12, 39).

7. Remove the throat cartridge (35) and o-ring (36).

8. Remove the glands (19, 26) and packings (20, 25).

9. Remove the tubes (3) and cylinder (1) from the inlet housing (15). Pull the piston assembly out of the cylinder.

10. Remove the inlet manifold (18) from the vise.

11. Remove the four capscrews (9) and washers (8) from the inlet manifold (18). Use a flatblade screwdriver inserted between the inlet housing (15) and the inlet manifold (18) to separate them.

One intake seat (6) includes a pressure relief valve (V). This seat must be located exactly where shown (the left side as viewed in F

IG. 7). Use the text cast

into the inlet housing as a guide.

12. Remove the balls (5), intake seats (6 and 34), and gaskets (7).

Repair Kits

Pump seal kits are available for each pump size. Throat packing kits are also available. See page 19 to order.

13. Inspect the pressure relief valve in the seat (6) to make sure it is not clogged. Press down on the valve's ball to see if the ball and the spring are free to move. See F

IG. 4.

Parts supplied in the pump seal kit are marked with one asterisk in the text and drawings, for example (2*). Parts supplied in the throat packing kit are marked with a symbol, for example (19†). For the best results, use all the

parts in the kit.

Lower Disassembly

1. Remove the pump from the motor as described on page 6. See also F

IG. 7.

2. Secure the inlet manifold (18) in a vise.

3. Loosen, but do not remove, the packing nut (21) and cartridge (35). See F

311690M 9

IG. 7.

IG. 4

ball spring

pressure relief valve

TI8407a

Repair

CAUTION

If the pressure relief valve in the seat (6) is clogged or filled with material, soak the seat in a compatible solvent. Make sure all material residue is cleaned from the ball and seat area.

If the relief valve cannot be thoroughly cleaned so that the ball and spring are free to move, replace the seat (6).

the positioning of the seat, ensuring that the vent hole (V) is not blocked by part of the housing. See F

IG. 5.

14. Place the flats of the piston nut (12) in a vise. Unscrew the rod (17) from the nut and spacer. Disassemble the piston (10) and remove the seal (11).

Clean and Inspect Parts

Clean all parts in a compatible solvent. Inspect all parts for wear or damage. If you are using a repair kit, use all the new parts in the kit, discarding the old ones they replace. Replace any other parts as needed. Worn or damaged parts may cause the pump to perform poorly or cause premature wear of the new seals and packings.

Lower Reassembly

1. Place the halves of the piston (10) around the packing (11) and snap them together. See F

2. Apply thread sealant (Loctite

263 or 2760) to the piston rod (17) threads. Screw the rod through the piston, packing, and spacer and into the piston nut (12). Torque the nut to 95-100 ft-lb (129-135 N•m). Allow to cure for at least 12 hours before use.

3. With the lower pump housing (11) turned upside down, install the balls (5) and the gaskets (7*).

IG. 8.

ball spring

pressure relief

TI8407a

valve

FIG. 5

5. Install the inlet seat without a relief valve (34) in the right side of the inlet housing (15).

The seats (6 and 34) are not reversible; the chamfered side must face the ball.

6. Place the inlet manifold (18) on the inlet housing (15). Install the lockwashers (8) and capscrews (9). Torque to 25-30 ft-lb (34-40 N•m). See F

IG. 8.

7. Place the intake manifold (18) in a vise. Place one o-ring (2*) in each side of the inlet housing (15), where the tubes (3) sit. Place o-rings (2*) in the grooves at each end of the tubes. Place a gasket (4) in both the inlet and outlet housing (15 and 16). Position the tubes and cylinder (1) in the lower housing.

It may be necessary to use a rubber mallet to set

COMPONENT RUPTURE HAZARD

the fluid tubes (3) and cylinder (4) in place.

The relief valve seat (6) must be installed at the fluid intake, as shown in F

IG. 8. The relief valve reduces the

risk of pump overpressurization. The seat cannot relieve pressure if installed on the other side of the inlet housing.

4. Install the relief valve intake seat (6) in the left side of the lower housing (11), as viewed in F

IG. 8. (Text

cast into the lower housing identifies the correct location for the relief valve seat.) The pin (P) on the seat must point up into the housing. The pin limits

10 311690M

Repair

8. Lubricate the inside of the cylinder (4). Slide the piston assembly into the cylinder. Rotate the piston as shown in F

IG. 6

IG. 6.

TI8734a

9. Install the o-ring (39†) on the throat cartridge (35), then screw the throat cartridge into the outlet housing (16).

washers (8) and screws (9), and torque to 25-30 ft-lb (34-40 N•m).

Seat (24) is reversible.

15. Reconnect the lower to the motor. See page 7.

10. Lubricate the throat packings and glands. Install one male gland (19†), then five v-packings with the lips facing down: one UHMWPE (20†), one leather (25†), UHMWPE, leather, UHMWPE. Install the female gland (26†). Install three v-packings with the lips facing up: UHMWPE, leather, UHMWPE. Install the other male gland (19†). Install the packing nut (21) finger-tight.

11. Install the outlet housing (16). It may not seat well on the tubes and cylinder. Install the bolts and lockwashers (14) from the inlet housing (15). As you tighten the bolts into the outlet housing (16), they will draw the housings firmly onto the tubes and cylinders. Tighten the bolts uniformly and torque to 25-30 ft-lb (34-40 N•m).

12. Apply lubricant to the throat cartridge threads and torque the cartridge (35) to 100 ft-lb (135 N•m).

14. Place a ball (23), seat (24) and gasket (7*) in each side of the outlet manifold (22). Install the outlet manifold on the outlet housing (16). Install the lock-

311690M 11

Repair

17 20 25

11 20 25

8 22

Apply lubricant to all packings.

Apply Loctite 243 (blue) to threads. Allow to cure for at least 12 hours before use.

Apply Loctite 263 or 2760 (red) to threads. Allow to cure for at least 12 hours before use.

Tighten uniformly until cylinder (4) is seated. Torque to 25-30 ft-lb (34-40 N•m).

Torque 25-30 ft-lb (34-40 N•m).

Torque 95-100 ft-lb (129-135 N•m).

Apply thread lubricant.

Torque to 30 ft-lb (40 N•m), then back off and retighten to 15-20 ft-lb (20-27 N•m).

TI7668b

FIG. 7

12 311690M

OUTLET

Repair

19 20

25 20

26 20

25 20 25

TI7668a-1

TI7666a

INLET

FIG. 8

311690M 13

Lower Parts

750cc Lower parts list, see page 15 1000cc Lower parts list, see page 16 1500cc Lower parts list, see page 17 2000cc Lower parts list, see page 18

20 25

26 20

8 22

Apply lubricant to all packings.

Apply Loctite 243 (blue) to threads. Allow to cure for at least 12 hours before use.

Apply Loctite 263 or 2760 (red) to threads. Allow to cure for at least 12 hours before use.

Tighten uniformly until cylinder (4) is seated. Torque to 25-30 ft-lb (34-40 N•m).

Torque 25-30 ft-lb (34-40 N•m).

Torque 95-100 ft-lb (129-135 N•m).

Apply thread lubricant.

Torque to 30 ft-lb (40 N•m), then back off and retighten to 15-20 ft-lb (20-27 N•m).

14 311690M

TI7668b

750cc Lowers

Part No. 289366, Series A, Stainless Steel

Ref. No. Part No. Description Qty.

1 183049 CYLINDER, pump, sst 1 2* 108526 PACKING, o-ring; PTFE 6 3 183085 TUBE, fluid; sst 2 4* 181875 GASKET, cylinder; UMWPE 2 5 101968 BALL, intake; 1.25 in. dia; sst 2 6 253483 SEAT, intake valve, with relief valve; sst 1 7* 181877 GASKET, seat, valve; UHMWPE 4 8 111003 WASHER, flat; 8.4 mm; sst 8 9 112084 CAPSCREW, hex hd; M8 x 1.25 x 25; sst 8 10 183081 PISTON; 2.5 in.; sst 2 11* 181680 PACKING, piston; 2.5 in.; UHMWPE 1 12 108528 NUT, piston; hex hd; sst 1 13 108523 CAPSCREW, hex hd; 9/16-12 unc x 7.5 in.; sst 3 14 108525 LOCKWASHER, spring; 9/16 in.; sst 3 15 181905 HOUSING, inlet; sst 1 16 192512 HOUSING, outlet; sst 1 17 16A462 ROD, piston; sst 1 18 15H663 MANIFOLD, inlet; sst 1 19† 192263 GLAND, male; sst 2 20† 183295 V-PACKING, throat; UHMWPE 5 21 181684 NUT, packing; sst 1 22 15H664 MANIFOLD, outlet; sst 1 23 110259 BALL, outlet; 1 in. (25 mm) dia.; sst 2 24 15H746 SEAT, valve; tungsten carbide 2 25† 120238 V-PACKING, throat; leather 3 26† 192264 GLAND, female; sst 1 34 239865 SEAT, intake valve; sst 1 35 192490 ADAPTER; sst 1 36† 107313 PACKING, o-ring; PTFE 1 37▲ 172479 TAG, warning (not shown) 1

Lower Parts

▲ Replacement Danger and Warning labels, tags, and cards are available at no cost. * Parts included in Seal Repair Kit (purchase separately). See page 20. † Parts included in Throat Packing Repair Kit (purchase separately). See page 21.

311690M 15

Lower Parts

1000cc Lowers

Part No. 253033, Series A, Stainless Steel Part No. 253061, Series A, Carbon Steel Part No. 253398, Series A, Stainless Steel Part No. 253423, Series A, Stainless Steel Part No. 253520, Series A, Stainless Steel Part No. 253523, Series A, Stainless Steel Part No. 253568, Series A, Stainless Steel

Lower

Ref. No. Description 253033 24E783 253061 253398 253423 253520 253523 253568 Qty.

1 CYLINDER, pump, sst 183047 183047 15H452 183047 183047 15H452 15H452 1

CYLINDER, pump, cst 2* PACKING, o-ring; PTFE 108526 108526 108526 108526 108526 108526 108526 108526 6 3 TUBE, fluid; sst 183085 183085 183085 183085 183085 183085 183085 183085 2 4* GASKET, cylinder; UMWPE 183094 183094 183094 183094 183094 183094 183094 183094 2 5 BALL, intake; 1.25 in. dia; sst 101968 101968 101968 101968 101968 101968 101968 101968 2 6 SEAT, intake valve, with relief valve; sst 253483 253483 253483 253483 253483 253483 253483 253483 1 7* GASKET, seat, valve; UHMWPE 181877 181877 181877 181877 181877 181877 181877 181877 4 8 WASHER, flat; 8.4 mm; sst 111003 111003 111003 111003 111003 111003 111003 111003 8 9 CAPSCREW, hex hd; M8 x 1.25 x 25; sst 112084 112084

CAPSCREW, hex hd; M8 x 1.25 x 25; cst 10 PISTON; 3 in.; sst 15G883 15G883 15G883 15G883 15G883 15G883 15G883 15G883 2 11* PACKING, piston; 3 in.; UMWPE 15G886 15G886 15G886 15G886 15G886 15G886 15G886 15G886 1 12 NUT, piston; hex hd; sst 15H989 15H989 15H989 15H989 15H989 15H989 15H989 15H989 1

CAPSCREW, hex hd; 9/16-12 unc x 7.5 in.; 13

sst

CAPSCREW, hex hd; 9/16-12 unc x 7.5 in.;

cst 14 LOCKWASHER, spring; 9/16 in.; sst 108525 108525

LOCKWASHER, spring; 9/16 in.; cst 15 HOUSING, inlet; sst 15G770 15G770 15G770 15G770 15G770 15G770 15G770 1

HOUSING, inlet; cst 15G891 1 16 HOUSING, outlet; sst 15G771 15G771

HOUSING, outlet; cst 15G892 1 17 ROD, piston; sst 16A462 16A462 16A462 16A462 16A462 16A462 16A462 16A462 1 18 MANIFOLD, inlet; sst 192259 192259

MANIFOLD, inlet; cst 19† GLAND, male; sst 192263 192263 192263 192263 192263 192263 192263 192263 2 20† V-PACKING, throat; UHMWPE 183295 183295 183295 183295 183295 183295 183295 183295 5 21 NUT, packing; sst 181684 181684 181684 181684 181684 181684 181684 181684 1 22 MANIFOLD, outlet; sst 15G873 15G873

MANIFOLD, outlet; cst 23 BALL, outlet; 1 in. (25 mm) dia.; sst 110259 110259 110259 110259 110259 110259 110259 110259 2 24 SEAT, valve; tungsten carbide 15H746 15H746 15H746 15H746 15H746 15H746 15H746 2

SEAT, valve; sst 25† V-PACKING, throat; leather 120238 120238 120238 120238 120238 120238 120238 120238 3 26† GLAND, female; sst 192264 192264 192264 192264 192264 192264 192264 192264 1 34 SEAT, intake valve; sst 239865 239865 239865 239865 239865 236865 239865 239865 1 35 ADAPTER; sst 192490 192490 192490 192490 192490 192490 192490 192490 1 36† PACKING, o-ring; PTFE 107313 107313 107313 107313 107313 107313 107313 107313 1 37▲ TAG, warning (not shown) 172479 172479 172479 172479 172479 172479 172479 172479 1 39 SPACER 16D850 16D850 16D850 16D850 16D850 16D850 16D850 16D850 1

120199 120199 120199 120199 120199 120199 120199 3

183095 2

183032 1

112084 112084 112084 112084 112084 8

107558 8

120446 3

108525 108525 108525 108525 108525 3

101333 3

15G771 15G771 15G771 15G771 15G771 1

193205 193205 15H663 15H663 192259 1

192260 1

15G874 15G874 15G664 15H664 15G873 1

181728 1

▲ Replacement Danger and Warning labels, tags, and cards are available at no cost.

* Parts included in Seal Repair Kit (purchase separately). See page 20. † Parts included in Throat Packing Repair Kit (purchase separately). See page 21.

16 311690M

Lower Parts

1500cc Lowers

Part No. 253034, Series A, Stainless Steel Part No. 253062, Series A, Carbon Steel Part No. 253085, Series A, Stainless Steel Part No. 253397, Series A, Stainless Steel Part No. 253521, Series A, Stainless Steel Part No. 253524, Series A, Stainless Steel Part No. 253569, Series A, Stainless Steel

Lower

Ref. No. Description 253034 24E784 253062 253085 253397 253521 253524 253569 Qty.

1 CYLINDER, pump, sst 183048 183048 183048 15H453 183048 15H453 15H453 1

CYLINDER, pump, cst 2* PACKING, o-ring; PTFE 108526 108526 108526 108526 108526 108526 108526 108526 6 3 TUBE, fluid; sst 183085 183085 183085 183085 183085 183085 183085 183085 2 4* GASKET, cylinder; UMWPE 181876 181876 181876 181876 181876 181876 181876 181876 2 5 BALL, intake; 1.25 in. dia; sst 101968 101968 101968 101968 101968 101968 101968 101968 2 6 SEAT, intake valve, with relief valve; sst 253483 253483 253483 253483 253483 253483 253483 253483 1 7* GASKET, seat, valve; UHMWPE 181877 181877 181877 181877 181877 181877 181877 181877 4 8 WASHER, flat; 8.4 mm; sst 111003 111003 111003 111003 111003 111003 111003 111003 8 9 CAPSCREW, hex hd; M8 x 1.25 x 25; sst 112084 112084

CAPSCREW, hex hd; M8 x 1.25 x 25; cst 10 PISTON; 3.5 in.; sst 15G884 15G884 15G884 15G884 15G884 15G884 15G884 15G884 2 11* PACKING, piston; 3.5 in.; UMWPE 15G887 15G887 15G887 15G887 15G887 15G887 15G887 15G887 1 12 NUT, piston; hex hd; sst 15H989 15H989 15H989 15H989 15H989 15H989 15H989 15H989 1

CAPSCREW, hex hd; 9/16-12 unc x 7.5 in.; 13

sst

CAPSCREW, hex hd; 9/16-12 unc x 7.5 in.;

cst 14 LOCKWASHER, spring; 9/16 in.; sst 108525 108525

LOCKWASHER, spring; 9/16 in.; cst 15 HOUSING, inlet; sst 15G770 15G770 15G770 15G770 15G770 15G770 15G770 1

HOUSING, inlet; cst 15G891 1 16 HOUSING, outlet; sst 15G771 15G771

HOUSING, outlet; cst 15G892 1 17 ROD, piston; sst 16A462 16A462 16A462 16A462 16A462 16A462 16A462 16A462 1 18 MANIFOLD, inlet; sst 192259 192259

SEAT, valve; sst 25† V-PACKING, throat; leather 120238 120238 120238 120238 120238 120238 120238 120238 3 26† GLAND, female; sst 192264 192264 192264 192264 192264 192264 192264 192264 1 34 SEAT, intake valve; sst 239865 239865 239865 239865 239865 239865 239865 239865 1 35 ADAPTER; sst 192490 192490 192490 192490 192490 192490 192490 192490 1 36† PACKING, o-ring; PTFE 107313 107313 107313 107313 107313 107313 107313 107313 1 37▲ TAG, warning (not shown) 172479 172479 172479 172479 172479 172479 172479 172479 1 39 SPACER 16D851 16D851 16D851 16D851 16D851 16D851 16D851 16D851 1

120199 120199 120199 120199 120199 120199 120199 3

183095 2

181900 1

112084 112084 112084 112084 112084 8

107558 8

120446 3

108525 108525 108525 108525 108525 3

101333 3

15G771 15G771 15G771 15G771 15G771 1

192259 193205 15H663 15H663 192259 1

192260 1

15G874 15G874 15H664 15H664 15G873 1

181728 1

▲ Replacement Danger and Warning labels, tags, and cards are available at no cost.

* Parts included in Seal Repair Kit (purchase separately). See page 20. † Parts included in Throat Packing Repair Kit (purchase separately). See page 21.

311690M 17

Lower Parts

2000cc Lowers

Part No. 253035, Series A, Stainless Steel Part No. 253063, Series A, Carbon Steel Part No. 253086, Series A, Stainless Steel Part No. 253396, Series A, Stainless Steel Part No. 253522, Series A, Stainless Steel Part No. 253525, Series A, Stainless Steel Part No. 253570, Series A, Stainless Steel

Lower

Ref. No. Description 253035 24E785 253063 253086 253396 253522 253525 253570 Qty.

1 CYLINDER, pump, sst 15G882 15G882 15G882 15G882 15H451 15G882 15H451 15H451 1 2* PACKING, o-ring; PTFE 108526 108526 108526 108526 108526 108526 108526 108526 6 3 TUBE, fluid; sst 183085 183085 183085 183085 183085 183085 183085 183085 2 4* GASKET, cylinder; UMWPE 15G881 15G881 15G881 15G881 15G881 15G881 15G881 15G881 2 5 BALL, intake; 1.25 in. dia; sst 101968 101968 101968 101968 101968 101968 101968 101968 2 6 SEAT, intake valve, with relief valve; sst 253483 253483 253483 253483 253483 253483 253483 253483 1

7* GASKET, seat, valve; UHMWPE 181877 181877 181877 181877 181877 181877 181877 181877 4 8 WASHER, flat; 8.4 mm; sst 111003 111003 111003 111003 111003 111003 111003 111003 8 9 CAPSCREW, hex hd; M8 x 1.25 x 25; sst 112084 112084

CAPSCREW, hex hd; M8 x 1.25 x 25; cst 10 PISTON; 4 in.; sst 15G885 15G885 15G885 15G885 15G885 15G885 15G885 15G885 2 11* PACKING, piston; 4 in.; UMWPE 15G888 15G888 15G888 15G888 15G888 15G888 15G888 15G888 1 12 NUT, piston; hex hd; sst 15H989 15H989 15H989 15H989 15H989 15H989 15H989 15H989 1

CAPSCREW, hex hd; 9/16-12 unc x 7.5 in.; 13

sst

CAPSCREW, hex hd; 9/16-12 unc x 7.5 in.;

cst 14 LOCKWASHER, spring; 9/16 in.; sst 108525 108525

LOCKWASHER, spring; 9/16 in.; cst 15 HOUSING, inlet; sst 15G770 15G770 15G770 15G770 15G770 15G770 15G770 1

HOUSING, inlet; cst 15G891 1 16 HOUSING, outlet; sst 15G771 15G771

HOUSING, outlet; cst 15G892 1 17 ROD, piston; sst 16A462 16A462 16A462 16A462 16A462 16A462 16A462 16A462 1 18 MANIFOLD, inlet; sst 192259 192259

SEAT, valve; sst 25† V-PACKING, throat; leather 120238 120238 120238 120238 120238 120238 120238 120238 3 26† GLAND, female; sst 192264 192264 192264 192264 192264 192264 192264 192264 1 34 SEAT, intake valve; sst 239865 239865 239865 239865 239865 239865 239865 239865 1 35 ADAPTER; sst 192490 192490 192490 192490 192490 192490 192490 192490 1 36† PACKING, o-ring; PTFE 107313 107313 107313 107313 107313 107313 107313 107313 1 37▲ TAG, warning (not shown) 172479 172479 172479 172479 172479 172479 172479 172479 1 39 SPACER 16D852 16D852 16D852 16D852 16D852 16D852 16D852 16D852 1

120199 120199 120199 120199 120199 120199 120199 3

183095 2

107558 8

120446 3

101333 3

192260 1

181728 1

112084 112084 112084 112084 112084 8

108525 108525 108525 108525 108525 3

15G771 15G771 15G771 15G771 15G771 1

193205 193205 15H663 15H663 192259 1

15G874 15G874 15H664 15H664 15G873 1

▲ Replacement Danger and Warning labels, tags, and cards are available at no cost.

* Parts included in Seal Repair Kit (purchase separately). See page 20. † Parts included in Throat Packing Repair Kit (purchase separately). See page 21.

18 311690M

Lower Parts

311690M 19

Pump Seal Kits

Pump Seal Repair Kit 289548 Pump PTFE Seal Conversion Kit 289549

Lower Model 289366

Part No. Description Qty.

181877 GASKET, seat, valve 4 108526 PACKING, o-ring 6 181875 SEAL, gasket, cylinder 2 181680 PACKING, piston, 2.5 in., UHMWPE

(Kit 289548)

187761 PACKING, piston, 2.5 in., PTFE

(Kit 289549)

Pump Seal Repair Kit 277360 Pump PTFE Seal Conversion Kit 277361

Lower Models: 253033, 253061, 253398, 253423, 253520, 253523, 253568

Part No. Description Qty.

181877 GASKET, seat, valve 4 108526 PACKING, o-ring 6 183094 GASKET, cylinder 2 15G886 PACKING, piston, 3 in., UHMWPE

(Kit 277360)

15H467 PACKING, piston, 3 in., PTFE

(Kit 277361)

Pump Seal Repair Kit 277362 Pump PTFE Seal Conversion Kit 277363

Lower Models: 253034, 253062, 253085, 253397, 253521, 253524, 253569

Part No. Description Qty.

181877 GASKET, seat, valve 4 108526 PACKING, o-ring 6 181876 GASKET, cylinder 2

15G887 PACKING, piston, 3.5 in., UHMWPE

15H468 PACKING, piston, 3.5 in., PTFE

(Kit 277362)

(Kit 277363)

Pump Seal Repair Kit 277358 Pump PTFE Seal Conversion Kit 277359

Lower Models: 253035, 253063, 253086, 253396, 253522, 253525, 253570

Part No. Description Qty.

181877 GASKET, seat, valve 4 108526 PACKING, o-ring 6 15G881 SEAL, gasket, cylinder 2

15G888 PACKING, piston, 4 in., UHMWPE

15H469 PACKING, piston, 4 in., PTFE

(Kit 277358)

(Kit 277359)

20 311690M

Throat Packing Kits

Throat Packing Kit 239868

With leather throat packings. For pumps with 750cc lowers.

Part No. Description Qty.

192264 GLAND, female 1 183294 PACKING, vee, leather 8 192263 GLAND, male 2 107313 PACKING, o-ring 1

Throat Packing Kit 239872

With leather and UHMWPE throat packings. For pumps with 750cc lowers.

Part No. Description Qty.

192264 GLAND, female 1 183295 PACKING, vee, uhmwpe 5 183294 PACKING, vee, leather 3 192263 GLAND, male 2 107313 PACKING, o-ring 1

Throat Packing Kit 239866

With PTFE throat packings. For pumps with 750cc, 1000cc, 1500cc and 2000cc lowers.

Throat Packing Kit 277356

With leather throat packings. For pumps with 1000cc, 1500cc and 2000cc lowers.

Part No. Description Qty.

192264 GLAND, female 1 120238 PACKING, vee, leather 8 192263 GLAND, male 2 107313 PACKING, o-ring 1

Throat Packing Kit 277357

With leather and UHMWPE throat packings. For pumps with 1000cc, 1500cc and 2000cc lowers.

Part No. Description Qty.

192264 GLAND, female 1 183295 PACKING, vee, uhmwpe 5 120238 PACKING, vee, leather 3 192263 GLAND, male 2 107313 PACKING, o-ring 1

Throat Packing Kit 24C405

With UHMWPE and PTFE throat packings. For pumps with 750cc, 1000cc, 1500cc and 2000cc lowers.

Part No. Description Qty.

192264 GLAND, female 1 183352 PACKING, vee, ptfe 8 192263 GLAND, male 2 107313 PACKING, o-ring 1

Part No. Description Qty.

192264 GLAND, female 1 183295 PACKING, vee, uhmwpe 5 183352 PACKING, vee, ptfe 3 192263 GLAND, male 2 107313 PACKING, o-ring 1

311690M 21

Graco Standard Warranty

Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written recommendations.

This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of Graco equipment with structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture, installation, operation or maintenance of structures, accessories, equipment or materials not supplied by Graco.

This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for verification of the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect in material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts, labor, and transportation.

THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.

Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other remedy (including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the date of sale.

GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, IN CONNECTION WITH ACCESSORIES, EQUIPMENT, MATERIALS OR COMPONENTS SOLD BUT NOT MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, switches, hose, etc.), are subject to

the warranty, if any, of their manufacturer. Graco will provide purchaser with reasonable assistance in making any claim for breach of these warranties.

In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment hereunder, or the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract, breach of warranty, the negligence of Graco, or otherwise.

FOR GRACO CANADA CUSTOMERS

The Parties acknowledge that they have required that the present document, as well as all documents, notices and legal proceedings entered into, given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English. Les parties reconnaissent avoir convenu que la rédaction du présente document sera en Anglais, ainsi que tous documents, avis et procédures judiciaires exécutés, donnés ou intentés, à la suite de ou en rapport, directement ou indirectement, avec les procédures concernées.

Graco Information

For the latest information about Graco products, visit www.graco.com.

TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor. Phone: 612-623-6921 or Toll Free: 1-800-328-0211 Fax: 612-378-3505

All written and visual data contained in this document reflects the latest product information available at the time of publication.

Graco reserves the right to make changes at any time without notice.

Original instructions. This manual contains English. MM 311690

Graco Headquarters: Minneapolis

International Offices: Belgium, China, Japan, Korea

GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441

www.graco.com

Revised 02/2011

Graco 311690M User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Models

Warnings

Repair

Grounding

Pressure Relief Procedure

Disconnect the Lower

Reconnect the Lower

Replace the Throat Packings Without Disconnecting the Lower

Reassemble the Coupling Rod and Tie Rods to the Motor

Repair Kits

Lower Disassembly

Clean and Inspect Parts

Lower Reassembly

Lower Parts

Pump Seal Kits

Throat Packing Kits

Graco Standard Warranty

Graco Information
