Operation
Pro Pack™ Portable Spray Pack
- For use with Graco hand-held sprayers (except Fine-Finish sprayers) -
- For portable spray applications of water-based and oil-based (mineral spirit-type)
architectural paints and coatings only -
- Not approved for use in explosive atmosphere locations -
IMPORTANT SAFETY INSTRUCTIONS
For complete warnings and safety
instructions, see sprayer manual.
Model 24F893
Maximum Working Pressure 12 psi (0.83 bar, 0.083 MPa)
3A1292C
EN
ti16502a
WARNING
WARNINGWARNINGWARNING
FIRE AND EXPLOSION HAZARD
Use only water-based or oil-based (mineral spirit-type) materials with flash point greater than 100° F
(38° C). Do not use materials which state “FLAMMABLE” on the packaging. For more information about
your material, request MSDS from distributor or retailer.
Use oil-based material outdoors or in a well-ventilated indoor area with a flow of fresh air.
Component / Replacement Kit Identification
Component / Replacement Kit Identification
1
9
2a
2b
2
2c
10
2d
11a
11
3
5
ti16522a
6
8
4a
12
4
4b
7
12b
12a
Ref. Part Description
1 115489 Hose clamp
2 24H367 Gasket kit
2a 125026 Grommet
2b 115099 Washer, garden hose
2c 16G375 Seal, reservoir
2d 106553 O-ring, packing (1)
3 24J023 Suction tube with strainer
4 24H365 Reservoir (1 gallon) with storage lid and
gasket
4a 24D425 Storage lid with seal
4b 16F731 Reservoir (1 gallon)
5 24J691 Fitting, intake with o-rings
2 3A1292C
Ref. Part Description
6 24J692 Lid with seals
7 24H366 Reservoir liners (5)
8 16P667 G2 adapter plate (for use with models
16N657, 16M886, 16N664, 16N665,
16N666, 16N668, 16N669, 16N670)
9 Hose set velcro strap
10 24G609 Back pack
11 24H362 Air compressor with 9V battery
11a Air compressor switch
12 24H363 Hose set
12a Drain hose
12b Suction hose
Before You Start
Before You Start
The ProPack Portable Spray Pack is shipped with a battery inside the air compressor which must be connected
before operation.
1. Remove contents from backpack including any
packing materials.
2. Remove air compressor from reservoir lid.
ti16510a
3. Open battery door on flat side of air compressor.
6. Connect battery and place inside air compressor.
ti17824a
7. Replace battery door.
ti17595a
8. Turn on power switch to test battery (red LED light
should turn on).
ti17593a
4. Remove 9V alkaline battery and remove shipping
seal from battery terminals.
ti17825a
5. Pull battery connector out of air compressor.
ti17591a
ti17596a
3A1292C 3
