GPX HT119B User Manual
HT119B
DVD Player
TAB LE OF CONT ENT S
Warnings and Precautions .......................................................2
Important Safety Instructions ..................................................3
In the Box & Features .............................................................4
Powering the Unit ...................................................................5
Changing the Remote Battery .................................................5
Connecting the Speaker System/DVD Player .........................6
Connecting the Speaker System/DVD Player .........................7
Composite Video Output & S-Video Output ..........................8
Component Video Output & Coaxial Audio Output ...............9
Programming a DVD or CD .................................................10
Setup Menu ...........................................................................11
Locations of Controls & Definitions ............................... 12-19
Parts & Service Information .................................................20
HT119B-IB.indd 1 12/17/2008 3:21:06 PM
Warnings and Precautions
This symbol, located on back or
bottom of the unit, is intended to alert
the user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufcient magnitude to constitute a
risk of electric shock to persons.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
To reduce the risk of electric shock, do not remove cover (or back).
There are no user-serviceable parts inside. Please refer any servicing
This symbol, located on back or
bottom of the unit, is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
This product utilizes a Class 1 laser
to read Compact Discs. This laser
Compact Disc Player is equipped with
safety switches to avoid exposure
when the CD door is open and
the safety interlocks are defeated.
Invisible laser radiation is present
when the CD Player’s lid is open and
the system’s interlock has failed or
been defeated. It is very important
that you avoid direct exposure to the
laser beam at all times. Please do not
attempt to defeat or bypass the safety
switches.
to qualied service personnel.
WARNING: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
WARNING: To prevent re or shock hazards, do not expose this unit to rain or moisture.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
PRÉCAUTION: Danger d’explosion si les piles sont remplacées de façon incorrect. Remplacer les piles
seulement par le même type de pile ou l’équivalent.
WARNING: The remote control’s button cell battery contains mercury. Do not put in the trash, instead
recycle or dispose of as hazardous waste
WARNING: Use of this unit near uorescent lighting may cause interference regarding use of the remote.
If the unit is displaying erratic behavior move away from any uorescent lighting, as it may be the cause.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
2
HT119B-IB.indd 2 12/17/2008 3:21:07 PM
Important Safety Instructions
1. Read Instructions - All the safety and operating
instruction should be read before the product is
operated.
2. Retain Instructions - The safety and operating
instruction should be retained for future reference.
3. Heed Warnings - All warning on the product and
in the operating instructions should be adhered to.
4. Follow instructions - All operating and use
instructions should be followed.
5. Cleaning - Unplug this product from the wall
outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Clean only with a dry cloth.
6. Attachments - Do not use attachments not
recommended by the product manufacturer as they
may cause hazards.
7. Water and Moisture - Do not use this product
near water - for example, near a bath tub, wash
bowl, kitchen sink, or laundry tub; in a wet
basement, or near a swimming pool, and the like.
The apparatus shall not be exposed to dripping or
splashing and that no objects lled with liquids,
such as vases, shall be placed on apparatus.
L’ appareil ne doit pas être exposê aux écoulements
ou aux éclaboussures et aucun objet ne contenant
de liquide, tel qu’un vase, ne doit être placé sur
l’objet.
8. Accessories - Do not place this product on an
unstable cart, stand tripod, bracket, or table. The
product may fall, causing serious injury to a child
or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
9. Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
See gure:
10. Ventilation - Slots and openings in the cabinet
are provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, and these openings must not be
blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug,
or other similar surface. This product should not be
placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided or the
manufacturer’s instruction have been adhered to.
11. Power Sources - This product should be operated
only from the type of power source indicated on
the marking label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company. For products
intended to operate from battery power, or other
sources, refer to the operating instruction.
12. Grounding or Polarization - This product may
be equipped with a polarized alternating-current
line plug (a plug having one blade wider than the
other). This plug will t into the power outlet only
one way. This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to t, contact
your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarizes plug.
Alternate Warnings - This product is equipped
with a three-wire grounding-type plug, a plug
having a third (grounding) pin. This plug will only
t into a grounding-type power outlet. This is a
safety feature. If you are unable to insert the plug
into the outlet, contact your electrician to replace
your obsolete outlet. Do not defeat the safety
purpose of the grounding-type plug.
13. Power-Cord Protection - Power supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords
at plugs, convenience receptacles, and point where
they exit from the product.
14. Protective Attachment Plug - The product is
equipped with an attachment plug having overload
protection. This is a safety feature. See Instruction
Manual for replacement or resetting of protective
device. If replacement of the plug is required, be
sure the service technician has used a replacement
plug specied by the manufacturer that has the
same overload protection as the original plug.
15. Outdoor Antenna Grounding - If an outside
antenna is connected to the receiver, be sure the
antenna system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Article 810 of the National Electrical
Code, ANSI/NFPA 70, provides information
with regard to proper grounding of the mast and
supporting structure, grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna-discharge unit, size of grounding
conductors, location of antenna-discharge
unit, connection to grounding electrodes, and
requirements for the grounding electrode.
See gure:
16. Lightning - For added protection for this product
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage
to the product due to lightning and power-line
surges.
17. Power Lines - An outside antenna system should
not be located in the vicinity of overhead power
lines or other electric light or power circuits, or
where it can fall into such power lines or circuits.
When installing an outside antenna system,
extreme care should be taken to keep from
touching such power lines or circuits as contact
with them might be fatal.
18. Overloading - Do not overload wall outlets,
extension cords, or integral convenience
receptacles as this can result in a risk of re or
electric shock.
19. Object and Liquid Entry - Never push objects of
any kind into this product through openings as they
may touch dangerous voltage points or short-out
parts that could result in a re or electric shock.
Never spill liquid of any kind on the product.
20. Servicing - Do not attempt to service this product
yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer all servicing to qualied service personnel.
21. Damage Requiring Service - Unplug this product
from the wall outlet and refer servicing to qualied
service personnel under the following conditions:
a) When the power-supply cord or plug is
damaged,
b) If liquid has been spilled, or objects have fallen
into the product,
c) If the product has been exposed to rain, water
or moisture.
d) If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualied technician to
restore the product to its normal operation.
e) If the product has been dropped or damaged in
any way, and
f) When the product exhibits a distinct change in
performance - this indicates a need for service.
22. Replacement Parts - When replacement parts are
required, be sure the service technician has used
replacement parts specied by the manufacturer
or have the same characteristics as the original
part. Unauthorized substitutions may result in re,
electric shock, or other hazards.
23. Safety Check - Upon completion of any service or
repairs to this product, ask the service technician
to perform safety checks to determine that the
product is in proper operating condition.
24. Wall or Ceiling Mounting - The product
should be mounted to a wall or ceiling only as
recommended by the manufacturer.
25. Heat - The product should be situated away from
heat sources such as radiators, heat registers,
stoves, or other products (including ampliers)
that produce heat. Battery shall not be exposed to
excessive heat such as sunshine, re, or the like.
Les piles ne doivent pas être exposées à de forte
chaleur, tel qu’à la lumière du soleil, au feu ou
autres choses de semblable.
26. Main plug is used as disconnect device and it
should remain readily operable during intended
use. In order to disconnect the apparatus from
the mains completely, the mains plug should
be disconnected from the mains socket outlet
completely.
La prise du secteur ne doit pas être obstruée
ou doit être facilement accessible pendant son
utilisation. Pour être complètement déconnecté
de l’alimentation d’entrée, la prise doit être
débranchée du secteur.
27. Excessive sound pressure from earphones and
headphones can cause hearing loss.
Des pressions acoustiques excessives provenant
d’écouteurs ou de casques peuvent provoquer des
pertes de l’audition.
28. To prevent re or shock hazard, do not use this
plug with an extension cord, receptacle or other
outlet unless the blades can be fully inserted to
prevent blade exposure.
29. Symbol is used to indicate that a
30. This symbol indicates that this product
31. Caution marking is located at the rear of apparatus.
Les précautions d’emploi sont inscrites en bas de
32. The marking information is located at the rear of
Les marquages sont inscrits en bas de l’appareil.
specic component shall be replaced
only by the component specied in that
documentation for safety reasons.
incorporates double insulation.
l’appareil.
apparatus.
3
HT119B-IB.indd 3 12/17/2008 3:21:07 PM
In the Box
• HT119B
• Remote Control
• Speaker Connection Cables
• A/V RCA Cables
• Documentation
Features
2.1 Channel Speaker System
Full-Range Stereo Speakers
Subwoofer
--Rotary Bass and Volume Controls
--DVD/AUX Source Selector Button
Drawer-Load DVD Player
Plays DVD, DVD-R/RW, DVD+R/RW, CD, CD-
R/RW
Plays JPEG Picture Discs
Multi-Language OSD: On-Screen Display in
English, French & Spanish
Supports Multiple Languages and Language
SubTitles
Fast-Forward / Fast-Backward / Slow Motion /
Zoom
TV Display Aspect Ratio Conversion: 4:3 / 16:9
NTSC
Progressive Scan
--Audio Out Jacks, L&R
--S-Video Output Jack
--Coaxial Digital Audio Output
Speaker:
--Audio-In L&R Jack, RCA type
--Stereo Line-In Jack for other Audio Players,
3.5mm type
--Aux-In Jack for other Audio Players, L&R RCA
type
Full-Feature Remote Control for DVD
Uses 2-”AAA” Batteries, (not included)
AC-Powered:
DVD: 120V, Built-In AC Cord
SubWoofer: Built-In 120V AC Cord
Jacks
DVD Player:
--Video Out Jack, RCA type
--Progressive Scan Output
4
HT119B-IB.indd 4 12/17/2008 3:21:07 PM
Powering the Unit
To power the unit, plug the attached AC cord into a standard AC outlet (120V~60Hz)
Changing the Remote Battery
To power the remote battery, insert two AAA batteries into the battery compartment on
the back of the remote.
AAA Battery
AAA Battery
5
HT119B-IB.indd 5 12/17/2008 3:21:08 PM
Connecting the Speaker System/DVD Player
AUDIO IN
DVDAUX
POWER
120V 60Hz
ON
OFF
L
R
L
MODEL: HT119BS
POWER SOURCE: 120V ~ 60Hz 30W
* SUBWOOFER: 4”
* IMPEDANCE: 8 OHM
GPX, a brand of DPI, Inc. 2116 Carr Street, St. Louis,
MO 63106 USA
MADE IN CHINA
Connect the external speakers to the
subwoofer using the speaker cables.
Connect the DVD Player to the
subwoofer using the included A/V Cable.
• When connecting the included
A/V Cable, match the colored
connections with the colored ports
(White to white, red to red, and
yellow to yellow).
Connect the Video Connection to a
television or other display.
External Speaker
DVD Player
6
HT119B-IB.indd 6 12/17/2008 3:21:08 PM
Loading...
