Gold Medal Products 5024ET User Manual

General Instructions (Standard Machine)

1. Always use fresh batter and do not allow it to warm up too much.

2. Frequent cleaning with a soft-bristled brush, and re-seasoning the grids as needed
during operation, will ensure a great tasting product.

3. Leave the grids in the closed position whenever possible because open grids cause
excessive carbon build-up.

4. If the baker is on for over an hour with no baking, lightly brush Free-N-Easy (Gold Medal
Item #2250QT) on the grids before baking.

5. Never apply beeswax, paraffin, or any other waxes to grid surfaces.

Removing Excess Carbon

1. Make sure appliance is cool and dry.

2. Un-plug machine from outlet.

3. Place a shallow drip pan under the grids.

4. Open top grid and spray a generous portion of Kleen-Sweep (Gold Medal Item #

2173CN) on grids, and allow to soak for at least a 1/2 hour. See Kleen-Sweep warning

below.

5. Using a bristle brush, do a general scrubbing on all grid surfaces that had Kleen-Sweep
applied to them. Using a spray bottle, spray GRIDS ONLY with cold water to rinse away
Kleen-Sweep.

6. Scrub grid surfaces with warm-soapy water (also applied with spray bottle) to remove
remaining Kleen-Sweep.

7. Use a damp cloth or sponge to wipe down the rest of the baker, to remove any splatter.

8. Re-season grids as described in GRID SEASONING section on previous page.

5 Models: 5021, 5021ET, 5021T, 5024, 5024ET, 5025, 5025,

5038, 5042, 5044, 5044ET, 5044T, 5051, 5051ET, 5055ET

/

STANDARD GENERAL BAKER EXPLODED VIEW (Refer to parts list)

Baker Handle

P/N 76074

Toggle Switch Boot

P/N 76382

Toggle Switch

P/N 47201

Switch Panel Decal

(Round Grid)

P/N 76309

(Square Grid)

P/N 76197

Hinge Pin
P/N 76056

Top Support Assembly

(Round Grid)

(Square Grid)

Pilot Light - Green

P/N 41469

Pilot Light - Red

P/N 41033

P/N 76244

N 76146

P

Timer Knob

P/N 76301

Drip Pan

P/N 76104

Front Support Assembly

P/N 76145

Interval Timer

P/N 76300

Pivot Cam

P/N 76069

Hinge Nut
P/N 76130

Conduit

P/N 76651-11

Wire Harness

P/N 76558

(5021 Only)

P/N 76557

Thermostat

P/N 76054

(5042 Only)

P/N 76557

Element Clamp

P/N 76072

Pivot Block Assy.

P/N 76065

Steel Tab

P/N 76070

Lead-In Cord
(Round Grid)

P/N 22038

(Square Grid)

P/N 87085
