Gold Medal Products 2396-00-111 Service Manual

Popcorn Topping

DANGER

WARNING

Dispenser Model Series 2396-00-100 (101, 110, 111, and 140)

Care and Cleaning

Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. DO NOT clean appliance with a water jet. Always unplug the equipment before cleaning or servicing.

To avoid burns, DO NOT touch heated surfaces. DO NOT place or leave objects in contact with heated surfaces.

Good sanitation practice demands that all food preparation equipment be cleaned regularly (only use non-toxic, food grade cleaners). A clean looking, well-kept machine is one of the best ways of advertising your product.

025_111616

009_092414

Follow the directions below to clean and sanitize the unit each day after use.

1. Turn machine OFF, unplug the unit and allow it to cool before attempting to clean.

2. The exterior surfaces can be cleaned by wiping oil spills with a clean dry towel, then

wipe with another clean towel dampened with mild soap and warm water.

3. Wipe the stainless steel parts with a clean cloth and cleaner designed for stainless

steel, such as Gold Medal Watchdog Stainless Cleaner (Item No. 2088).

DO NOT use oven cleaners or abrasive materials as they will damage parts of machine.

4. Where applicable, drip pan/drip pan insert may be taken to the sink to clean with mild

soap and warm water. Allow to dry, then reassembly.

5. Clean plastic panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No.

2588) is recommended.

Ammonia cleaners will damage plastic panels. Use only non-ammonia cleaners, such as Gold Medal Watchdog Glass Cleaner (Item No. 2588).

Sanitizing the Tubing and Pump

Items Needed: (2) Empty Pails

(1) Cleaning Bracket (Item No. 12594)

Gold Medal Chlor-Tech Sanitizer (Item No. 1109)

Measure Cup (for priming unit)

1. Make sure Topping Dispenser has cooled completely before attempting to clean.

2. Fill a clean, empty pail half-full with hot water and Gold Medal Chlor-Tech Sanitizer

(reference instructions on sanitizer container for appropriate amount).

Page 12

gmpopcorn.com

Popcorn Topping

2396

-00-

100

2396

-00-

101

COMPLETE RACK ASSEMBLY

77461

1

CONTROL BOX

79375

2

CONTROL BOX COVER

79377

3 8-

32 X 3/8 SLT. HWH M/S

(screws to hold cover)

42044

4

B.I.B. BUTTER PUMP

79888

7988

8 5 RETAINING STRAP

38998

6

RED PILOT LIGHT

41033

7

3 POSITION ROCKER SWITCH

39410

8 SWITCH LABEL

39413

9

FUSE HOLDER

74636

10 1 AMP FUSE

79341

11

SOCKET ASSEMBLY

100299

12 6-

32 X 3/8 PHIL PAN M/S

(fastens socket assy.)

39000

13

#6 INT. TOOTH L/W 410SS

(fastens socket assy.)

39001

14 6-

32 M/S NUT 18

-8

(fastens socket assy.)

14221

15* LEAD

-

IN CORD 15 AMP PLUG

22038

16

R 31-2 STRAIN RELIEF

41735

17

HEAT DEFLECTOR

38995

18 8-32 X 1/4 HX HD WHIZLOCK

42045

19

ACORN NUT #8

-

32

47702

See Tubing and

5

Single Pedestal Rack Assembly shown for reference

*

CAUTION: If supply

6

1

17 16

2396-00-100

Dispenser Model Series 2396-00-100 (101, 110, 111, and 140)

Rack Assembly - Exterior View
