Description
A
The GVA-24 Goldline Valve Actuator rotates 2-port and 3 port valves automatically.
Use it with the Aqua Logic system or GL-235 Solar Controller to automate pool/spa
operation, solar heating, cleaner operation, water features, or a variety of other uses.
The industry standard configuration of the GV A-24 means that it is compatible with all
major manufacturer's valves and pool automation systems. The unique cam setting
feature ensures a quick and easy installation with the precise control of water flow .
Installation
Mounting Options
Three Port Valve
The Model GVA-24 Actuator may be mounted to the valve in four different positions
(Fig. 1). Depending on the location of the common port (where water enters valve)
and exit port (where water leaves valve), the cam settings may have to be changed.
See diagrams/tables on the following pages to determine which configuration matches
your system.
Port
1
Port
1
Port
2
(Standard)
Port
2
Port
B
3
Port
3
Port
2
Port
1
Port
2
Port
3
C
D
2
Fig. 1
Using the chart below to determine correct cam setting using standard clock positions. Refer to the "Cam Adjustment" section in this manual to change upper and
lower cam positions if necessary.
GVA
MOUNTING
OPTION
A
(Standard)
B
C
D
PORT
WHERE
WATER
ENTERS
LOWER CAM UPPER CAM PORT PORT
1 6 o'clock 9 o'clock 2 3
2 (std) 12 o'clock 12 o'clock 1 3
3 3 o'clock 6 o'clock 1 2
1 9 o'clock 12 o'clock 2 3
2 3 o'clock 3 o'clock 1 3
3 6 o'clock 9 o'clock 1 2
1 3 o'clock 6 o'clock 2 3
2 9 o'clock 9 o'clock 1 3
3 12 o'clock 3 o'clock 1 2
1 12 o'clock 3 o'clock 2 3
2 6 o'clock 6 o'clock 1 3
3 9 o'clock 12 o'clock 1 2
CAM SETTING
PORT
WATER
WHERE
EXITS
Two Port Valve
The Model GVA-24 Actuator may be mounted to the valve in four dif ferent positions.
In all cases, the cam settings are the same. Refer to the chart below for cam settings
for 2 way valves.
CAM SETTING
LOWER CAM UPPER CAM
3 o'clock 6 o'clock
3
Mounting Instructions
If the valve is plumbed with Port 2 as the common port and the main body of the
actuator is mounted over Port 2 (standard mounting), there is no need to adjust the
actuator cams.
1 . Remove Locking Knob and handle. Set aside for reinstallation later .
2 . Remove four (4) screws from the valve. Refer to Fig. 1 (mounting positions) to
determine which screws to remove.
3 . On the back side of the actuator, align the smallest slot on the actuator shaft with
the smallest slot on the valve diverter.
4 . With the two shafts engaged rotate the actuator until holes on the actuator align
with the screw holes on the cover.
5 . Use four (4) ¼-14x1½" long screws (packaged with the actuator) to secure it in
place. Do not overtighten - be careful if using a power screwdriver.
6. Place valve handle on actuator shaft and tighten Locking Knob.
Cam Adjustment
1. When changing the cam settings, move toggle switch at bottom of actuator to
the OFF (center) position.
2 . Unscrew and remove Locking Knob and handle from actuator shaft.
3 . Remove the four (4) screws which hold the actuator cover on and remove cover .
4 . The upper and lower cam are located on the actuator shaft. Slide the cams off the
shaft splines and rotate to the desired position. Refer to the charts on the
previous pages to determine the correct cam setting for your installation. Some
installations may require settings not found on the chart (partial open, partial
close, etc.) All settings are referenced from the small slot on the shaft, which is
always 12 o'clock (Fig. 2). The upper cam effects the clockwise position stop
point. The lower cam to effects the counterclockwise rotation stop point.
12 o’clock
(small slot)
9 o’clock
6 o’clock
4
3 o’clock
Fig. 2
5 . The toggle switch on the bottom of the valve actuator can be used to verify if the
new adjustment is correct (flip between ON1 and ON2).
6. Replace cover and handle and tighten screws and Locking Knob.
7 . Put toggle switch back to ON1 or ON2 position.
Synchronization Instruction
After installation of the actuator(s), they may need to be synchronized. Out of synchronization refers to the condition where one actuator is rotating incorrectly in
relation to another actuator. To correct this, simply flip the toggle switch at the
bottom of the actuator which is out of synchronization between the ON1 and ON2
position.
Manual Override
In the event of a power failure, you may need to move the valve position manually.
Before performing this procedure, turn off pool filtration just in case power resumes.
Follow the instructions below for manual override of the GV A-24 actuator .
1 . Put the toggle switch in the OFF (center) position.
2 . Unscrew the Locking Knob above the handle approximately 4 full turns (Fig. 3).
3 . Push down on the Locking Knob. This will disengage the gear train and allow the
handle and thus the diverter to be moved in any position.
4 . To return the actuator to automatic position, pull up on the handle while turning
it clockwise or counterclockwise until you feel the shaft slide up into the gear
train. Screw the Locking Knob down until snug.
5 . Put the toggle switch back in the ON1 or ON2 position.
Locking Knob
4X
Fig. 3
5
Maintenance
The GV A-24 has two seals which should be lubricated every year . These O-ring seals
are located at the top and bottom of the actuator, where the shaft exits the actuator
housing. The top O-ring requires the removal of the handle, and the bottom requires
that the gear train is disengaged. Follow the procedure below for instructions on how
to lubricate the O-ring seals. Before performing this procedure, turn off pool filtration.
1 . Put the toggle switch in the OFF (center) position.
2 . Remove the actuator from the valve. Remove the Locking Knob and handle.
3 . Spread a small amount of Jacks 327 or other silicone based lubricant around the
actuator shaft where it enters the cover.
4 . Reinstall handle and Locking Knob but only tighten one (1) turn.
5 . Push down on the Locking Knob to disengage the gear train. This will allow the
handle and the shaft to be moved in any position.
6 . Spread a small amount of lubricant around the actuator shaft where it protrudes
from the bottom of the actuator enclosure.
7. Turn the handle once around to spread the lubricant.
8 . Pull up on the handle, let it click into place and tighten Locking Knob.
Troubleshooting
If you believe your actuator is not operating properly or have questions regarding the
operation, call the Goldline Technical Service Dept. from Monday through Friday,
8AM to 8PM EST at 888-921-7665.
1. Actuator handle oscillates.
This condition may happen when the GVA-24 O-ring seals are not lubricated sufficiently. See "Maintenance" section in this manual.
2. Actuator motor works but the valve diverter does not turn.
On a pool/spa combination, the symptom of this problem would be a draining or
overflowing spa. This condition will occur if the actuator is in the manual position. T o
correct this, pull up on the handle while rotating the handle in any direction until it
clicks, then tighten the Locking Knob.
3. Actuator motor does not turn
The motor will not turn if the switch is in the OFF position or if there is no power to the
actuator. If the switch is in the OFF position, move to ON1 or ON2. T o check power
to the actuator, measure AC volts between the black (common) and each switch leg
(red then white). If there is no AC volts on either leg, check the 24VAC power source.
