Goldine Controls AQL-WW-RF-PS-4, AQL-WW-RF-PS-8, AQL-Tx-RF-PS-4, AQL-Tx-RF-PS-8, AQL-Tx-RF-PS-16 User Manual
...
Wireless Remote Display
for
Aqua LogicAqua Logic
Aqua Logic
Aqua LogicAqua Logic
Automation and Chlorination
wall mount model
table top model
Installation/Operation Manual
Wall Mount models
Table Top models
C
LD
ON
TROLS
G
for models
AQL-WW-RF-PS-4
AQL-WW-RF-PS-8
AQL-WW-RF-PS-16
&
AQL-Tx-RF-PS-4
AQL-Tx-RF-PS-8
AQL-Tx-RF-PS-16
LINE
INC
.
www.goldlinecontrols.com
888-921-7665
Compatibility
This product is compatible with all Aqua Logic controls operating with software
revision r2.00 or higher and Base Receivers with software revision r1.20 or higher. To
verify the software level of your Aqua Logic control, press the Menu button (possibly multiple times) until "Diagnostic Menu" is displayed. Press the ">" or "<" keys
(possibly multiple times) until the main software revision level is displayed (the revision should be 2.00 or higher). Next, press the ">" key (possibly multiple times) until
the "RF Base" revision level is shown (the revision should be 1.20 or higher).
If the software revision level is less than those specified above, contact the Goldline
T echnical Service Dept. from Monday through Friday, 8AM to 8PM Eastern at 888921-7665 for information on upgrades.
Installation
Installation - AQL-WW-RF-PS-x Wall Mount models
1. Base Receiver required: For operation of the AQL-WW-RF-PS-x, the Aqua
Logic control unit must have a base receiver (AQL-BASE-RF) installed. The
receiver also allows the Aqua Logic control unit to communicate with an optional spa-side remote.
2. Select Location: There are several considerations in choosing the location for
the wireless remote display/keypad:
Protected from the weather: The wireless remote display/keypad must be
mounted indoors or in a weather protected area (rain should never hit the
wireless remote display/keypad). The wireless remote display/keypad is
designed to mount onto a standard electrical utility box (same size as used
for a triple light switch) or can be mounted directly onto any wall surface.
Within range of Base Receiver: The wireless remote display/keypad must
be installed within 200 ft. (assuming the signal will have to travel through
walls) or 400 ft. (line of sight) from the Base Receiver which is typically
mounted on the Aqua Logic main control unit at the pool equipment pad.
The Base Receiver can also be mounted up to 500 ft. away from the main
control unit to shorten the distance between it and any wireless remote. See
the "Remote Mounting of the Base Receiver" section of the Base Receiver
manual for more details.
Near 120V wall outlet: The wireless remote display/keypad uses a plug-in
power supply with a 6 ft. cable.
3. Mount on wall: The wireless remote display/keypad must be mounted indoors
or in a weather protected area (rain should never hit the display/keypad). Refer
to the diagram on the following page.
a. Remove the wireless remote display/keypad baseplate from the cover by
lifting up on the cover at the lower end of the keypad.
b. Thread the wall mount power supply’s output connector from behind and
through the opening in the left side of the baseplate.
c. Screw the baseplate in the desired position (screws supplied by installer).
1
d. Plug the power supply’s output connector into the mating connector on the
back of the wireless remote display/keypad.
e. Reattach the wireless remote display/keypad to the baseplate.
f. Plug the power supply into a 120VAC outlet.
Wireless Remot e
Display unit
Pull up on bottom edge
to remove cover
Installation - AQL-Tx-RF-PS-x Table T op models
1. Base Receiver required: For operation of the AQL-Tx-RF-PS-x, the Aqua Logic
control unit must have a base receiver (AQL-BASE-RF) installed. The receiver
also allows the Aqua Logic control unit to communicate with an optional spaside remote.
2. Select Location: Because the AQL-Tx-RF-PS-x is battery operated and de-
signed to be portable, there are no power supply or mounting concerns like the
Wall Mount units. The Table Top units are intended to be used in the normal
living space, with these considerations:
Protected from the weather: The wireless remote display/keypad should be
used indoors or in a weather protected area (rain should never hit the wire-
less remote display/keypad). Understand that areas that protect the unit
from rain, may still allow condensing humidity (dew, mist, fog, etc.) which
can damage the AQL-Tx-RF-PS-x over time. Because the unit is portable and
may be used in different areas around the pool and home, it's important to
understand that it is NOT water resistant and can be easily damaged if used
in the wrong manner.
Within range of Base Receiver: The wireless remote display/keypad must
be used within 200 ft. (assuming the signal will have to travel through walls)
or 400 ft. (line of sight) from the Base Receiver which is typically mounted on
2
the Aqua Logic main control unit at the pool equipment pad. The Base
Receiver can also be mounted up to 500 ft. away from the main control unit to
shorten the distance between it and any wireless remote. See the "Remote
Mounting of the Base Receiver" section of the Base Receiver manual for
more details.
2. Powering the AQL-Tx-RF-PS-x: The AQL-Tx-RF-PS-x uses a rechar geable
built-in battery pack which will require an initial charge when you first receive
the unit. Charge the unit for at least 15 hours before attempting to use it without
the charger. Note that the AQL-Tx-RF-PS-x can be used normally while connected to the charger.
Charging the battery:
Plug the included wall mount charger into a standard 120VAC wall outlet,
away from the pool area. It is not recommended that you use an extension
cord with this product. Plug the power connector into the rear of the AQLTx-RF-PS-x. Charge for 15 hours. A fully charged battery will provide over
400 one-minute uses under typical conditions.
About battery power:
When the charger is not plugged into the AQL-Tx-RF-x, the unit uses battery power and will take steps to extend battery life. After one minute of no
button presses by the user, the unit will show a brief display and will go into
"sleep" mode (pg. 5). T o wake it up, simply press any button on the keypad.
The button press will not perform any function except waking the unit. Once
awake, any subsequent button presses will perform their normal functions.
When the charger is plugged in, the unit uses wall power while it also charges
the batteries. It will always be "awake", as long as it's plugged into the
charger.
Note that the batteries will slowly lose charge if the unit is not plugged into
the wall, even if it is not used. The batteries will need to be charged every 1
-2 months, depending on usage.
The AQL-Tx-RF-PS-x will display a series of information about its status and
the status of the battery. Refer to the "Operation" section of this manual for
an explanation of each of these displays.
NOTE: The built-in NiCad battery pack is available only through Goldline
and should offer at least 5 years of service, depending upon use. If the
battery pack needs to be replaced, contact Goldline Customer Service.
3
Installation - all models
1. T each the unique Aqua Logic ID code: The base receiver attached to the Aqua
Logic control unit has a unique ID code that ensures that your unit will not affect
other systems in the neighborhood, and likewise, their remote will not affect
your system. To teach the ID code to the wireless remote unit:
a. On any other wired Aqua Logic display/key-
Settings
Menu
pad unit, press the "Menu" button (possibly
multiple times) until "Settings Menu" is displayed.
Teach Wireless:
+ to start
b. Press "<" or ">" (again, possibly multiple times)
until "Teach Wireless" is displayed.
c. Press the "+" button to start the teaching pro-
cess.
Press and hold
wireless button
Teach Wireless:
Successful
d. Press and hold any button on the wireless re-
mote display/keypad for 4 seconds. At this
point the LCD on the wireless remote display/
keypad will indicate "T each W ireless Successful" and the local display/keypad on the Aqua
Logic control unit will also confirm "Teach
Wireless Successful". If this process is not
successful, then refer to the Troubleshooting
section of this manual for additional information.
2. Apply labels: The Aqua Logic PS series of controls allow each output (e.g.
AUX1) to be renamed to what is actually being controlled. The wireless remote
display/keypad comes with a sheet of name labels—simply peel the appropriate
label off the sheet and apply to the appropriate set of buttons on the wireless
remote display/keypad.
3. Installation is complete: Y ou can now use the wireless remote display/keypad.
4
OPERA TION
Operation - all models
The wireless remote display/keypad communicates with the base receiver on the
Aqua Logic control unit using RF (radio frequency) technology. All of the display
information is transmitted from the Aqua Logic control unit to the wireless remote
display/keypad and all the button press information is transmitted by the wireless
remote display/keypad unit back to the Aqua Logic control unit.
If the display information is not being updated on a regular basis or if the Aqua Logic
is not responding to buttons being pressed, then refer to the Troubleshooting section for assistance in resolving these problems.
When power is turned on to Wall Mount models, or when the Table Top models
"wake up", all the LED indicators will flash briefly , the display backlight will illuminate,
and the following display will appear for a short period of time:
Goldline Aqua Logic
RF Display r2.00
The "r2.00" is the software revision level. The actual revision level for your wireless
remote display/keypad may be different. Refer to the Aqua Logic Operation Manual
for complete operating instructions.
Operation - AQL-Tx-RF-PS-x T able T op models
Because the AQL-Tx-RF-PS-x is battery operated, it displays various information
about its condition and the status of its batteries. Refer to the section below for an
explanation of these displays:
Shutting down to
save battery power
After one minute of no button presses, the AQL-Tx-RF-PS-x will briefly show this
display and go into "sleep" mode. This mode conserves the battery power while the
remote is not in use. While asleep, all lights and the display will be off. To "wake" the
unit up, push any button on the keypad.
Refreshing display
When the AQL-Tx-RF-PS-x "wakes" up, it will show this display while it collects
status information from the Aqua Logic control unit.
Please plug in to
charge battery
When the batteries are low , the T able T op unit will alternate between this display and
the normal status display. Under typical conditions, there are at least 50 more oneminute uses available when this display is first shown. The batteries will slowly lose
charge if the unit is not plugged into the wall, even if it is not used.
5
Batteries dead!
Please charge now!
This display is shown briefly, immediately before the unit shuts down. The AQL-TxRF-PS-x will not operate again (to protect the batteries) until it is plugged into the
charger . It can be used immediately while connected to the char ger.
TROUBLESHOOTING
1. Can’t find the "Teach Wireless" display: From the Aqua Logic control (or any
direct wired display/keypad) press the "menu" button (possibly more than once)
until "Settings Menu" is displayed. Next, press the "<" or ">" buttons (possibly
more than once) until the "Teach Wireless" display appears. If you get to the
point where "Settings Menu" appears again, then this means that the Aqua
Logic control unit is not communicating with the base receiver. Check that the 4
wire cable from the base receiver is plugged into the "wireless" connector on the
main printed circuit board. If this connector is already plugged in (for more than
30 seconds), then call Goldline T echnical Service for assistance.
2. "Teach Wireless" failed: Ensure that the remote is powered when pressing the
button. This is indicated by any message on the display of the remote. If the
remote is powered, then the next most likely cause is that the distance between
the base receiver and the remote is too great—try moving the remote closer to the
receiver. Lastly , there may be other equipment in the neighborhood that is using
the same frequency. To see if this is the case, go to the Settings Menu/Wireless
Channel and select another channel. Note that after you change the channel you
will have to "re-teach" every wireless remote device in the system.
3. Unreliable communication with remote devices: The most likely cause is that
the distance between the base receiver and the remote is too great—try moving
the remote closer to the receiver. Lastly, there may be other equipment in the
neighborhood that is using the same frequency. To see if this is the case, go to
the Settings Menu/Wireless Channel and select another channel. Note that after
you change the channel you will have to "re-teach" every wireless remote device
in the system.
4. Wireless display/keypad not functioning (no display , no LEDs illuminated):
AQL-WW-RF-PS-x models: If the display/keypad located on the main unit is
working correctly, check that there is input power to the wireless display/keypad. Make sure that the wall mount power supply is plugged into an active
120VAC outlet and its output connector is plugged into the wireless remote
display/keypad.
AQL-Tx-RF-PS-x models: If the display/keypad located on the main unit is
working correctly, check that there is input power to the wireless display/keypad. Plug the charger into an active 120VAC outlet and its output connector into
the wireless remote display/keypad. If this doesn't work, plug charger into the
unit, plug the charger into an active 120VAC outlet, wait 5 seconds, unplug the
charger , wait 5 seconds, and then plug it back in again.
6
5. Display backlight turns off after a period of time:
AQL-WW-RF-PS-x models and AQL-Tx-RF-PSx models running off wall power:
The display backlight should always illuminate when you press any key on the
unit. If it turns off after a period of time, you can stop this by pressing the menu
key (possibly multiple times) until "Settings Menu" appears. Next press the "<"
or ">" key (possibly multiple times) until "Display Light" appears. At this point,
pressing either "+" or "-" will allow you to select either "Always On" or "On for
60 sec.". After you have selected the desired operation, press the "Menu"
button to lock in your setting. Note that this selection applies to this wireless
remote display/keypad only. Repeat the process of each display/keypad in the
system.
6. Display backlight always on
AQL-WW-RF-PS-x models and AQL-Tx-RF-PSx models running off wall power:
The display backlight should always illuminate when you press any key on the
unit. If it remains on after 60 seconds have elapsed since the last button push,
you can stop this by pressing the menu key (possibly multiple times) until "Settings Menu" appears. Next press the "<" or ">" key (possibly multiple times)
until "Display Light" appears. At this point, pressing either "+" or "-" will allow
you select either "Always On" or "On for 60 sec.". After you have selected the
desired operation, press the "Menu" button to lock in your setting. Note that this
selection applies to this display/keypad only. Repeat the process for each display/keypad in the system.
7.
The last keypress
was not received
This is usually a temporary problem caused by interference from other equipment that is using the same radio frequency. Try pressing the button again. If
this doesn’t work, go to the Settings Menu/Wireless Channel on any other
Aqua Logic display/keypad and select another channel. Note that after you
change the channel you will have to "re-teach" every wireless remote device in
the system.
8.
The base receiver
is not responding
If this is the first time you are using your remote, or if you have just installed a
new base receiver, run the "Teach Wireless" procedure from any other Aqua
Logic display/keypad. Also, the radio signal may be too weak—try pointing the
remote in the direction of the pool equipment or try moving closer to the pool
equipment. If that doesn’t work, then there may be other equipment that is using
the same frequency. Go to the Settings Menu/Wireless Channel on any other
Aqua Logic display/keypad and select another channel. Note that after you
change the channel you will have to "re-teach" every wireless remote device in
the system.
Teach Wireless needs
9.
to be run
This is caused by the remote not knowing the ID code of the base receiver. Run
the "Teach Wireless" procedure from any other direct wired Aqua Logic display/keypad.
7
Teach Wireless Fail.
10.
Please try again.
This is usually caused by a button being held down for more than 3 seconds,
falsely triggering the T each W ireless mode. It can also be displayed if the Aqua
Logic is not in the T each W ireless mode. If the Aqua Logic is in T each W ireless,
then the radio signal may be too weak—try moving closer to the Aqua Logic
main control unit base receiver.
11.
Display Error 1
call 888-921-7665
Display Error 2
call 888-921-7665
Display Error 3
call 888-921-7665
An internal problem has occurred in the wireless remote display/keypad. Remove the display/keypad from the wall mount base (see diagram on page 2) and
write down the model number and serial number. Call the Goldline T ech support
department (Monday through Friday , from 8AM to 8PM eastern time) to find out
how to obtain a replacement wireless remote display/keypad.
8
Limited Warranty—Pool Automation & Chlorination Products
10/1/2004
This warranty statement is applicable to all pool automation and chlorination products manufactured by Goldline
Controls, Inc. (Goldline) on or after October 1, 2004. See the appropriate warranty statement for other Goldline
products or for pool automation and chlorination products produced prior to October 1, 2004.
Aqua Rite/Trol/Logic—Residential pools in USA or Canada:
Goldline warrants Aqua Rite, Aqua Trol, and Aqua Logic products (products with Goldline part numbers starting with
AQ-RITE-, AQ-TROL-, AQ-LOGIC-, AQL-P-, AQL-PS-,or AQL-CL-) installed on private, residential swimming
pools within the USA or Canada to be free from defects in material or workmanship, under normal use and service for
years from date of the initial system installation, provided it is installed in accordance with the Goldline installation
instructions and specifications provided with the product. If written proof of the date of the initial system installation
is not provided to Goldline, the manufacturing datecode on the Aqua Rite, Aqua Trol, or Aqua Logic electronics unit
will be the sole determinant of the date of the initial system installation.
If a product is defective, in workmanship or materials and is removed and returned freight prepaid within three (3) years
after the date of the initial system installation, Goldline Controls will, at its option, either repair or replace the defective
product and return it freight prepaid. If the defective product is returned freight prepaid to Goldline more than three (3)
years but within five (5) years of the date of the initial system installation, Goldline, at its option, will either repair or
replace the defective product and will charge sixty percent (60%) of the current list price for such repairs or replacements,
plus shipping charges. The costs incurred in removal and/or reinstallation of the product are NOT covered under this
warranty.
Aqua Rite/Trol/Logic-- Commercial pools or any pool outside of the USA or Canada:
Goldline warrants Aqua Rite, Aqua Trol, and Aqua Logic products (products with Goldline part numbers starting with
AQ-RITE-, AQ-TROL-, AQ-LOGIC-, AQL-P-, AQL-PS-,or AQL-CL-) installed on commercial pools anywhere or any
non-private single family residential pool or any pool outside of the USA or Canada to be free from defects in material or
workmanship, under normal use and service for
installed in accordance with the Goldline installation instructions and specifications provided with the product. If
written proof of the date of the initial system installation is not provided to Goldline, the manufacturing datecode on the
Aqua Rite, Aqua Trol, or Aqua Logic electronics unit will be the sole determinant of the date of the initial system
installation.
If a product is defective, in workmanship or materials and is removed and returned freight prepaid within one (1) year after
the date of the initial system installation, Goldline will, at its option, either repair or replace the defective product and
return it freight prepaid. The costs incurred in removal and/or reinstallation of the product are NOT covered under this
warranty.
Accessory Products and Replacement parts—any pools, anywhere:
Goldline warrants any replacement parts or accessory products (any pool automation or chlorination product or part
with a part number other than AQ-RITE-, AQ-TROL-, AQ-LOGIC-, AQL-P-, AQL-PS-,or AQL-CL-) to be free from
defects in material or workmanship, under normal use and service for
provided it is installed in accordance with the Goldline installation instructions and specifications provided with the
product. If written proof of the date of the initial system installation is not provided to Goldline, the manufacturing
datecode on the product or part will be the sole determinant of the date of the initial system installation.
If a product is defective, in workmanship or materials and is removed and returned freight prepaid within one (1) year after
the date of the initial system installation, Goldline will, at its option, either repair or replace the defective product and
return it freight prepaid. The costs incurred in removal and/or reinstallation of the product are NOT covered under this
warranty.
Warranty exclusions:
1. Material supplied or workmanship performed by others in the process of installation
2. Damage resulting from improper installation including installation on pools larger than the product rating.
3. Problems resulting from failure to operate the products in accordance with recommended instructions contained
in product’s owners manual.
4. Problems resulting from failure to maintain pool water chemistry in accordance with recommended levels.
5. Problems resulting from tampering, accident, abuse, negligence, unauthorized repairs or alterations, fire, flood,
lightning, freezing, external water, war, or acts of God.
THE EXPRESS LIMITED W ARRANTY ABOVE CONSTITUTES THE ENTIRE WARRANTY OF GOLDLINE CONTROLS, INC. WITH RESPECT TO ITS POOL AUTOMATION AND CHLORINA TION PRODUCTS AND IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING W ARRANTIES OF MERCHANT ABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL GOLDLINE CONTROLS, INC. BE
RESPONSIBLE FOR ANY CONSEQUENTIAL, SPECIAL OR INCIDENT AL DAMAGES OF AN Y NATURE WHA T SOEVER.
NO WHOLESALER, AGENT, DEALER, CONTRACTOR, OR OTHER PERSON IS AUTHORIZED TO GIVE ANY
W ARRANTY ON BEHALF OF GOLDLINE CONTROLS, INC. THIS WARRANTY IS VOID IF THE PRODUCT HAS
BEEN ALTERED IN ANY W AY AFTER LEA VING THE FACTOR Y.
one year from date of the initial system installation, provided it is
one year from date of the initial system installation,
five
9
NICAD BA TTERY DISPOSAL (AQL-Tx-RF-PS-x models)
At the end of the batteries’ useful life, they must be recycled or disposed of
properly. Contact your local county, or state hazardous waste management authorities for information on recycling or disposal programs in your area.
FCC Statement
(Compliance Statement, Part 15.19): This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
W ARNING (Part 15.21): Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this
equipment.
Industry Canada Statement
The term “IC” before the certification/registration number only signifies that the
Industry Canada technical specifications were met.
Interference
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, then the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into a power source on different circuit than the
receiver.
Refer to www.goldlinecontrols.com for latest
manual revisions, additional information and helpful service.
Or, you may visit your local Authorized Goldline Dealer or
call 888-921-POOL (7665) for assistance.
G
LD
C
ON
North Kingstown, RI 02852 USA
LINE
TROLS
Questions?
INC
.
Copyright © 2004 Goldine Controls, Inc
092045E
Loading...
