GN Netcom STRATUS ULTRA-G User Manual

User Guide

STRATUS

ULTRA-G

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Stratus Ultra-G Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Ear Capsule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Headband . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Microphone Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Clothing Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Connecting To Your Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Cautionary Notes to Computer Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

FCC Notice to Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

To Obtain Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Copyright ®1999 GN Netcom, Inc., all rights reserved.

1

Introduction

Congratulations on your purchase of the GN Netcom Stratus Ultra-G headset. This guide contains instructions for the
Stratus Ultra-G ST-I headset. To derive maximum benefit from this versatile product, please take a few minutes to review
this user’s guide.

If after reviewing this guide you have any questions concerning the Stratus Ultra-G headset, please call your distributor or
contact GN Netcom, Inc. Customer Service at 800-826-4656.

Stratus Ultra-G Components

1. Noise Canceling Microphone

2. Flexible Microphone Boom Arm

3. Receiver

4. Adjustable Lobe Hinge™

5. Ear Capsule

6. Flexible Wire Headband

7. Ear Cushion (for Headband Wearing)

8. Foam Windscreen

9. Clothing Clip

10. Quick Disconnect

5.

4.

7.

9.

1.

6.

8.

2.

Figure 1

10.

3.

2

Ear Capsule

The Stratus Ultra-G headset comes out of the box with the ear capsule installed
in the right ear wearing style (see Figure 2). The ear capsule is worn on the ear
and features an Adjustable Lobe Hinge™ for a custom fit.

Ear Capsule Wearing

To put on your new Stratus Ultra-G ear capsule (see Figure 3):

1. Straighten out the Adjustable Lobe Hinge

2. Swing the ear capsule away from the receiver and slide the ear capsule
behind your ear until the saddle of the hook rests on the uppermost part
of your ear.

3. With your thumb, close the ear lobe hinge until it is snug, secure and
comfortable to wear, but not tight on your ear.

4. Lightly press the speaker against the ear for proper positioning.

To remove, simply lift the Stratus Ultra-G off your ear.

Figure 2

Stratus Ultra-G Ear Capsule

Figure 3

Ear Capsule Wearing
