ORATOR-G

User Guide

Introduction

Congratulations on your purchase of the GN Netcom Orator-G headset. This guide contains instructions for the
Orator-G OG-I and OG-II headsets. To derive maximum benefit from these products, please take a few minutes to review
this user’s guide.

If after reviewing this guide you have any questions concerning the Orator-G headset, please call your distributor or contact
GN Netcom, Inc. Customer Service at 800-826-4656.

Orator-G Components

Figure 1
Orator-G Monaural

1.

4.

1. Noise Canceling Microphone

2. Flexible Microphone Boom Arm

5.

3.

2.

3. Receiver with Foam Cover

4. Click Stop Headband

5. Stabilizer Cushion

6. Clothing Clip

7. Quick Disconnect

Figure 2
Orator-G Binaural

4.

3.

3.

1.

2.

7.

6.

7.

6.

Orator -G Wearing

Position the headset lightly on your head (see Figure 3). The click-stop
headband lengthens and shortens to the desired length for a custom fit (pull to
lengthen, push to shorten). The headband retains its length and will not need
adjusting each time it is put on. The stabilizer cushion rests just above the ear
on the side of your head opposite the receiver.

To move the microphone and boom aside without removing your headset, for
example to take a sip of coffee, use your finger to swing the boom back and
forth.

Refer to the Microphone Positioning section for additional information.

Changing Ears

To accommodate left or right ear wearing styles, bend the microphone boom at
the hinge beneath the receiver (see Figure 4). Do not force the microphone
boom beyond the built in stops!

Figure 3
Headband Wearing

Figure 4
Changing Ears

1
