GN Netcom 9000MWD User Manual
MARQUIS 9000MWD
SINGLE LINE CORDLESS
HOTEL TELEPHONE
Congratulations on the purchase of your TeleMatrix Marquis
TM
9000MWD telephone.The 9000MWD includes advanced features
suitable for use in hotel/motel guest room environment.
TeleMatrix has designed the telephone to be simple to install and
easy to use. Cordless performance provides convenience and
mobility for all your guest rooms.
Your 9000MWD telephone is a precision electronic device that
requires minimum maintenance. Please be sure to read the
contents set forth in the user’s guide to become familiar with the
wiring and functionality of this product.
2
CAUTION
To reduce the risk of fire or injury, read and follow these instructions:
1. Use only the designated battery pack for cordless handset and power adapter for the base.
2. Do not dispose of the battery(ies)in a fire. The cell may explode. Check with the local codes for
possible special disposal instructions.
3. Do not open or mutilate the battery(ies). Released electrolyte is corrosive and may cause damage to the
eyes or skin. It may be toxic if swallowed.
4. Exercise care in handling batteries in order not to short the battery with conducting materials such as
rings, bracelets and keys. The battery or conductor may overheat and cause burns.
5. Do not attempt to recharge the battery(ies) provided with or identified for use with this product. The
batteries may leak corrosive electrolyte or explode.
6. Do not attempt to rejuvenate the battery(ies) provided with or identified for use with this product by
heating them. Sudden release of the battery electrolyte may occur causing burns or irritation to the eyes
or skin.
7. When replacing the batteries, all batteries should be replaced at the same time. Mixing fresh and
discharged batteries could increase internal cell pressure and rupture the discharged battery(ies).
(Applies to products employing more than one separately replaceable primary battery).
8. When inserting batteries into this product, the proper polarity or direction must be observed. Reverse
insertion of batteries can cause charging, and that may result in leakage or explosion (applies to product
employing more than one separately replaceable primary battery).
9. Remove the batteries from this product if the product will not be used for a long period of time (several
months or more) since during this time the battery could leak in the product.
10. Discard dead batteries as soon as possible since dead batteries are more likely to leak in a product.
11. Do not store this product, or the batteries provide with or identified for use with this product in h i g h
temperature areas. Batteries that are stored in a freezer or refrigerator for the purpose of extending the
shelf life should be protected from condensation during storage and defrosting. Batteries should be
stabilized at room temperature prior to use after cold storage.
3
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning.
4. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation, to protect it from overheating, these
openings must not be blocked or covered. The openings should never be blocked by placing the product on the bed, sofa,
rug, or other similar surface. This product should never be placed near or over a radiator or heat register. This product
should not be placed in a built-in installation unless proper ventilation is provided.
IF UNIT IS EQUIPPED WITH POWER ADAPTER:
7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your dealer or local power company.
IF ADAPTER IS PROVIDED WITH A GROUNDED TYPE ATTACHMENT PLUG:
8. This product is equipped with a three wire grounding type plug, a plug having a third (grounding) pin. This plug will only fit
into a grounding type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.
IF ADAPTER IS PROVIDED WITH A POLARIZED ATTACHMENT PLUG:
This product is equipped with a polarized line plug (a plug having one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are unable to inset the plug fully into the outlet, try reversing the
plug. If the plug should still not fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
9. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by persons walking on it.
10. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock.
11. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short
out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.
12. To reduce the risk of electric shock, do not disassemble this product, but take it to a qualified serviceman when some
service or repair work is required. Opening or removing covers may expose you to dangerous voltages or other risks.
Incorrect re-assembly can cause electric shock when the appliance is subsequently used.
13. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating instructions. Adjust only those controls, that
are covered by the operating instructions because improper adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to restore the product to normal operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance.
14. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electrical
shock from lightning.
15. Do not use the telephone to report a gas leak in the vicinity of the leak.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
FCC Part 15 C omplia nce
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for
Class B digital device, pursuant to Part 15 of the FCC Rules, These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and, can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio TV technician for help.
Canadian Emissions Compliance
"This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference Regulations of
the Canadian Department of Communications. "
5
DOC - NOTICE AND LOAD NUMBER STATEMENT
NOTICE: The Canadian Department of Communications label identifies certified equipment. This
certification means that the equipment meets certain telecommunications network protective, operational
and safety requirements. The Department does not guarantee the equipment will operate to the user's
satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of
the local telecommunications company. The equipment must also be installed using an acceptable method
of connection. In some cases, the company's inside wiring associated with a single line individual service
may be extended by means of a certified connector assembly (telephone extension cord). The customer
should be aware that compliance with the above conditions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated
by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions,
may give the telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility,
telephone lines and internal metallic water pipe system, if present, are connected together. This precaution
may be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact the appropriate
electric inspection authority, or electrician, as appropriate.
The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be
connected to a telephone loop, which is used by the device, to prevent overloading. The termination on a
loop may consist of any combination of devices subject only to the requirement that the total of the Load
Numbers of all the devices does not exceed 100. An alphabetic suffix is also specified in the Load Number
for the appropriate ringing type (A or B), if applicable. For example, LN = 20 A designates a Load Number
of 20 and an "A" type ringer.
6
NOTIFICATION TO THE TELEPHONE COMPANY
Before you may connect your telephone you must notify the telephone company of particular
line(s) to which such connections is to be made, and provided to the telephone company the
FCC registration number and ringer equivalence number of the registered protective circuitry.
The customer shall give notice to the telephone company upon final disconnection of such
equipment or circuitry from the particular line(s).
MALFUNCTION OF TELEPHONE
In the event that your telephone fails to work properly during your ownership and use of it,
you should disconnect it from the telephone line to determine if it is your phone, which is not
working properly, or if it is problem in the telephone company's network. If the problem is
with your telephone you should discontinue its use until it is repaired.
TELEPHONE CONNECTION REQUIREMENTS
Except for telephone company- provided ringers, all connections to the telephone network
shall be made through standard telephone company provided jacks, in such a manner to allow
for easy and immediate disconnection of the terminal equipment. Standard jacks shall be so
arranged that if the plug connected thereto is withdrawn, no interference to the operation of the
equipment at the customer's premises which remains connected to the telephone net work shall
occur by reason of such withdrawal. These telephones may not be used on party lines or coin
operated lines.
CHANGES IN TELEPHONE COMPANY EQUIPMENT OR FACILITIES
The telephone company is entitled to make changes in its facilities equipment, operations, and
procedures. Should these changes be expected to render your terminal equipment incompatible
with the telephone company's facilities you will be given sufficient notice to allow you to
make the necessary modification to your terminal equipment without any interruption of your
service.
7
Consumer Information:
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bot-
tom of this equipment is a label that contains, among other information, a product identifier in the format
US:2N3WI29B95339 If requested, this number must be provided to the telephone company.
An applicable certification jacks Universal Service Order Codes (USOC) f or the equipment is provided (i.e.,
RJ11C) in the packaging with each piece of approved terminal equipment.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with
the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See installation instructions for details.
The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs
on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas,
the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to a
line, as determined by the total RENs, contact the local telephone company. [For products approved after July 23,
2001, the REN for this product is part of the product identifier that has the format US:2N3WI29B95339 The digits
represented by 29 are the REN without a decimal point (e.g., 29 is a REN of 2.9). For earlier products, the REN is
separately shown on the label.]
If this equipment 95339/953391 causes harm to the telephone network, the telephone company will notify you in
advance that temporary discontinuance of service may be required. But if advance notice is n't pract ic al, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations or procedures that could affect
the operation of the equipment. If this happens the telephone company will provide advance notice in order for
you to make necessary modifications to maintain uninterrupted service.
Please follow instructions for repairing if any (e.g. battery replacement section); otherwise do not alternate or repair any parts of device except specified.
Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service
commission or corporation commission for information.
This equipment is hearing aid compatible.
NOTICE: If your home has specially wired alarm equipment connected to the telephone line, ensure the instal l a-
tion of this [equipment ID] does not disable your alarm equipment. If you have questions about what will di sable
alarm equipment, consult your telephone company or a qualified installer.
Should you experience trouble with this equipment, please contact (TeleMatrix, Inc.Customer Care Center 5025
Galley Road Colorado Springs, CO. 80915 . Toll Free:1-800-462-9446 Direct:719-638-8821 Fax:719-638-8815
www.telematrixusa.com) for repair or warranty information. If the equipment is causi ng harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.
[NOTICE: According to telephone company reports, AC electrical surges, typically resulting from
lightning strikes, are very destructive to telephone equipment connected to AC power sources. To
minimize damage from these types of surges, a surge arrestor is recommended.]
8
Features .........................................................…………………........................ 8
Controls .............…..............………………….................................................. 9
Installation …………………............................................................................. 15
Wall Mounting .....…..............................................…………………................ 16
Battery Preparation ......................………………….......................................... 17
Switch Settings .…………………..…............................................................... 21
Programming ..........….........................................………………….................. 22
Operation .................…........................................................…………………. 25
Service ......................…........................................…………………................ 33
Warranty .....................…............………………….......................................... 34
Spare Part List ……………………………………………...………………… 35
9
• One Line Operation
• Cordless Handset, 900 Mhz Operation, with Handshake Technology
• Long Life Rechargeable NiCd Battery
• Speakerphone with volume control
• 10 Guest Service Keys (Speed Dial Locations)
• TouchLite
TM
Message Waiting Indicator/Retrieval Feature
• Convenient Data Port
• “Soft-Key” Volume Control (Handset -- 8 step/ADA Compliant)
• HI/Low Ringer Volume Controls (Handset)
• Speaker Volume Control Rocker Switch
• Line Status Indicators (In-Use/Hold/Mute/Ringing)
• Mute Key (Base)
• Redial/Pause Key (submerged)
• Flash Key (submerged)
• Handset Locator Key (On Base)
• Charge Light Indicator
• Extended Memory Back-up (Lithium Battery)
• Desk Or Wall Mountable
• Operates Behind 24/48 Volt Systems
• Hearing Aid Compatible
10
TOP VIEW
(1)
(14)
(13)
NEON L ED
123
456
GHI
789
PQRS
*0#
ABC
JKL
TUV
STORE
DEF
MNO
WXYZ
MUTE
(11)
(10)
FLASH
(12)
FOR MESSAGES
(9)
PRESS HERE
(8)
REDIAL
(7)
(6)
(3)
SPEAKER
(2)
(5)
(4)
11
Loading...
